ICOM IC-T10 Instructions manual

PROGRAMMING SOFTWARE

CS-T10

The CS-T10 is a software application to set up the IC-T10 from your PC. This manual shows system

requirements and how to use the software.

INSTRUCTIONS

System requirements

To use the software, you will need the following:

Operating System (OS)

• Microsoft Windows 11 (64bit)

• Microsoft Windows 10 (32/64bit)

• Microsoft Windows 8.1 (32/64bit)
Except for Windows on ARM, such as Windows RT.

L The instructions are based on using Microsoft Windows 10.

USB Port

A USB 1.1 or 2.0 port

Cable (Purchase separately)

• OPC-478UC programming cable or

OPC-478UC-1 programming cable

NOTE for the OPC-478UC programming cable

• The OPC-478UC is not usable with Windows 11.

• Conrm your OPC-478UC has a “B” on its label. Only

the cables with a “B” are usable with Windows 8.1 and

Windows 10.

TIP: When using the cable, you must install a USB driver.
See the cable’s instruction manual for details.

Programming information

• To prevent data loss, you should rst read the
transceiver settings into the CS-T10. Then edit or
enter new software parameters.

• Before making any changes to the transceiver

settings, create a backup le onto your PC. A
backup le enables easy restoring even if the

setting data is accidentally deleted.

• While reading or writing (uploading) the data
via a programming cable, NEVER turn OFF the
transceiver or the PC, or NEVER disconnect the
cable. Otherwise, the data could be damaged or
lost.

Updating the CS-T10

The rmware and programming software may be

updated for expansion or improvement of functions.
You can update the programming software to the
latest version by downloading the update program
from the Icom website and installing it.
https://www.icomjapan.com/support/

L If you get an error dialog that says the transceiver’s

rmware and the programming software versions do

not match, update both to the latest versions.

Icom, Icom Inc. and the Icom logo are registered
trademarks of Icom Incorporated (Japan) in Japan,
the United States, the United Kingdom, Germany,
France, Spain, Russia, Australia, New Zealand,
and/or other countries.
Microsoft and Windows are trademarks of the
Microsoft group of companies.
All other products or brands are registered
trademarks or trademarks of their respective holders.

1

Installing the programming software

1. Sign in to the PC as an administrator.

L Conrm that no other applications are running.

2. Download and unzip the file.

3. Double-click “setup.exe.”

L If the “User Account Control” dialog is displayed,

click <Yes>.

• “Choose Setup Language” is displayed.

4. Select “English” (or “Japanese”) and then
click<N ext>>.

L In this document, “English” is selected.

Click

7. After the installation has been completed, click
<Finish>.

Click

8. An “Icom CS-T10” item is created in the Windows
Start menu, and a shortcut icon is added to your
desktop.

5. On the “Welcome to the InstallShield Wizard for

CS-T10” screen, click <Next>>.

Click

6. On the “Choose Destination Location” screen,
click <Nex t>>.

L If desired, click <Browse...> and select another

destination folder before clicking <Next >>.

TIP:

• Refer to the software’s Help le for assistance
with the functions or settings. To open the Help

le, click <Help> in the top menu of the software
and select “Contents”, or simply press the [F1]
key on the PC’s keyboard.

• You can uninstall the programming software from

“Apps & features” in “Apps.”
Go to Start > Settings > Apps > Apps & features.

Conrm

Click
