The product is a pedestrian-controlled rotary lawn mower. The grass is collected in a grass catcher. Remove the grass catcher to get rear discharge of the grass. Attach a mulch kit (accessory) to cut the grass into fertilizer.
Use the product to cut grass in private gardens. Do not use the product for other tasks.
(Fig. 1 )
1.Motor brake handle
2.Start inhibitor
3.Drive bail (LC 141VLi)
4.Handle / handlebar
5.Control panel
6.ON/OFF button
7.SavE button
8.Battery indicator button
9.Battery charge indicator
10.Warning indicator (ERROR LED)
11.Decrease speed button (LC 141VLi)
12.Speed level indicator (LC 141VLi)
13.Increase speed button (LC 141VLi)
14.Rear cover
15.Symbols
16.Battery lid
17.Safety key
18.Cutting cover
19.Cutting height lever
20.Rating plate
21.Grass catcher
22.Mulch plug for LC 141VLi (Accessory)
23.Mulch plug for LC 141Li (Accessory)
24.Battery charger (Accessory)
25.Battery (Accessory)
26.Operator's manual
(Fig. 2 )
1.Motor brake handle
2.Start inhibitor
3.Power cord socket
4.Power cord holder
5.Handle / handlebar
6.Rear cover
7.Symbols
8.Cutting cover
9.Rating plate
10.Cutting height lever
11.Mulch plug (Accessory)
12.Grass catcher
13.Operator's manual
|
Injury or death can occur |
|
to the operator or |
|
bystanders if the product |
|
is not used carefully and |
(Fig. 3 ) |
correctly. |
|
Read the operator's |
|
manual and make sure |
(Fig. 4 ) |
that you understand the |
10 |
71 - 005 - 18.05.2018 |
|
instructions before you |
|
Warning: Do not operate |
|
|
use this product. |
|
the product across the |
|
|
Keep persons and |
|
power cord as this can |
|
|
animals at a safe distance |
|
result in electrical shock |
|
(Fig. 5 ) |
from the work area. |
|
or damage to the product. |
|
|
Look out for thrown |
(Fig. 14 ) |
(model LC 141C) |
|
|
|
This product is in |
||
(Fig. 6 ) |
objects and ricochets. |
|
||
|
Warning: Keep hands and |
|
accordance with |
|
|
(Fig. 15 ) |
applicable EC directives. |
||
|
feet away from the |
|
Noise emission to the |
|
(Fig. 7 ) |
rotating blade. |
|
||
|
Warning: Keep hands and |
|
environment according to |
|
|
|
the European |
||
|
feet away from rotating |
|
||
|
|
Community’s Directive. |
||
|
parts. |
|
||
(Fig. 8 ) |
|
The product’s emission is |
||
|
Remove the safety key |
|
specified in the Technical |
|
|
before you do |
|
data chapter and on the |
|
|
maintenance on the |
(Fig. 16 ) |
label. |
|
|
product. (model |
(Fig. 17 ) |
Direct current. 36V |
|
(Fig. 9 ) |
LC 141VLi/LC 141Li) |
|||
(Fig. 18 ) |
Double insulation. |
|||
|
Disconnect the product |
|||
|
(Fig. |
Recycle this |
||
|
from electrical outlet |
|||
|
19 ) |
|||
|
before you do |
|
product at a re- |
|
|
maintenance on the |
|
cycling location |
|
(Fig. 10 ) |
product. (model LC 141C) |
|
for electrical |
|
|
IPX1 - The product has |
|
and electronic |
|
|
|
equipment. |
||
|
protection against |
|
||
|
|
(Applies to Eu- |
||
|
dripping water (model |
|
||
|
|
rope only) |
||
(Fig. 11 ) |
LC 141VLi/LC 141Li) |
|
||
|
|
|||
|
IPX4 - The product has |
|
|
|
|
protection against |
|
|
|
|
splashing water (model |
|
|
|
(Fig. 12 ) |
LC 141C) |
|
|
|
|
Do not let rain fall on the |
|
|
|
|
product (model |
|
|
|
(Fig. 13 ) |
LC 141VLi/LC 141Li) |
|
|
|
|
|
|
||
71 - 005 - 18.05.2018 |
|
11 |
(Fig. |
Start procedure |
20 ) |
|
|
for model |
|
LC 141VLi/ |
|
LC 141Li: push |
|
ON/OFF but- |
|
ton, loosen |
|
start inhibitor, |
|
push motor |
|
brake handle |
|
down. |
|
Start procedure for model |
|
LC 141C: loosen start |
|
inhibitor, push motor |
(Fig. 21 ) |
brake handle down. |
|
Release motor brake |
(Fig. 22 ) |
handle to stop. |
(Fig. 23 ) |
Slow |
(Fig. 24 ) |
Fast |
Note: Other symbols/decals on the product refer to certification requirements for some markets.
(Fig. |
Recycle this |
25 ) |
|
|
product at a re- |
|
cycling station |
|
for electrical |
|
and electronic |
|
equipment. |
|
(Applies to Eu- |
|
rope only) |
(Fig. 26 ) |
Fail-safe transformer. |
|
Use and keep the battery |
(Fig. 27 ) |
charger indoors only. |
(Fig. 28 ) |
Double insulation. |
As referred to in the product liability laws, we are not liable for damages that our product causes if:
•the product is incorrectly repaired.
•the product is repaired with parts that are not from the manufacturer or not approved by the manufacturer.
•the product has an accessory that is not from the manufacturer or not approved by the manufacturer.
•the product is not repaired at an approved service center or by an approved authority.
12 |
71 - 005 - 18.05.2018 |
Warnings, cautions and notes are used to point out specially important parts of the manual.
WARNING: Used if there is a risk of injury or death for the operator or bystanders if the instructions in the manual are not obeyed.
CAUTION: Used if there is a risk of damage to the product, other materials or the adjacent area if the instructions in the manual are not obeyed.
Note: Used to give more information that is necessary in a given situation.
WARNING: Read the warning instructions that follow before you use the product.
•This product is dangerous if used incorrectly or if you are not careful. Injury or death can occur if you do not obey the safety instructions.
•This product produces an electromagnetic field during operation. This field may under some circumstances interfere with active or passive medical implants. To reduce the risk of serious or fatal injury we recommend persons with medical implants to consult their physician and the medical implant manufacturer before operating this product.
•Always be careful and use your common sense. If you are not sure how to operate
•
•
•
•
•
•
•
the product in a special situation, stop and speak to your Husqvarna dealer before you continue.
Keep in mind that the operator will be held responsible for accidents that involve other persons or their property.
Keep the product clean. Make sure that you can clearly read signs and decals.
Do not let a person use the product unless you make sure that they read and understand the contents of the operator's manual.
Do not let a child operate the product.
Do not let a person, without knowledge of the instructions, operate the product.
Always monitor a person, with decreased physical capacity or mental capacity, that uses the product. A responsible adult must be there at all times.
Do not use the product if you are tired, ill, or under the influence of alcohol, drugs or medicine. This has a negative effect on your vision, alertness, coordination and judgment.
71 - 005 - 18.05.2018 |
13 |
•Do not use the product if it is defective.
•Do not change this product or use it if it is possible that it has been changed by others.
WARNING: Read the warning instructions that follow before you use the product.
•Remove objects such as branches, twigs and stones from the work area before you use the product.
•Objects that hit against the cutting equipment can eject and cause damage to persons and objects. Keep bystanders and animals at a safe distance from the product.
•Never use the product in bad weather such as fog, rain, strong winds, intense cold and risk of lightning. To use the product in bad weather or in moist or wet locations is tiring. Bad weather can cause dangerous conditions, such as slippery surfaces.
•Look out for persons, objects and situations that can prevent safe operation of the product.
•Look out for obstacles, such as roots, stones, twigs, pits and ditches. Long grass can hide obstacles.
•To cut grass on slopes can be dangerous. Do not use the product on ground that slopes more than 15°.
•Operate the product across the face of slopes. Do not move up and down.
•Be careful when you go near hidden corners and objects that prevent a clear view.
WARNING: Read the warning instructions that follow before you use the product.
•Use this product to cut grass lawns only. It is not permitted to use it for other tasks.
•Use personal protective equipment. See Personal protective equipment on page 15.
•Do not operate the product in rain or wet conditions. The risk of electrical shock increases if water enters the product.
•Do not operate the product unless the blade and all covers are attached correctly. An incorrectly attached blade can come loose and cause personal injury.
•Make sure that the blade does not hit objects such as stones and roots. This can do damage to the blade and bend the motor shaft. A bent axle
14 |
71 - 005 - 18.05.2018 |
•
•
•
•
•
•
•
causes heavy vibration and a very high risk that the blade becomes loose.
If the blade hits an object or if vibrations occur, stop the product immediately. Stop the motor, turn the safety key to 0 and remove the battery (model LC 141VLi and LC 141Li) or disconnect the power cord (model LC 141C). Examine the product for damages. Repair damages or let an authorised service agent do the repair.
Never attach the motor brake handle permanently to the handle when the motor is started.
Put the product on a stable, flat surface and start it. Make sure that the blade does not hit the ground or other objects.
Always stay behind the product when you operate it.
Let all the wheels stay on the ground and keep 2 hands on the handle when you operate the product. Keep your hands and feet away from the rotating blades.
Do not tilt the product when the motor is started.
Be careful when you pull the product rearward.
•Never lift up the product when the motor is started. If you must lift the product, first stop the motor, turn the safety key to 0 and remove the battery (model LC 141VLi and
LC 141Li) or disconnect the power cord (model LC 141C).
•Do not walk rearward when you operate the product.
•Stop the motor when you move across areas without grass, for example paths made of gravel, stone and asphalt.
•Do not run with the product when the motor is started. Always walk when you operate the product.
•Stop the motor before you change the cutting height. Never make adjustments with the motor started.
•Never let the product stay out of view with the motor started. Stop the motor and make sure that the cutting equipment does not rotate.
WARNING: Read the warning instructions that follow before you use the product.
•Personal protective equipment cannot fully prevent injury but it decreases the degree of
71 - 005 - 18.05.2018 |
15 |
injury if an accident does occur. Let your dealer help you select the right equipment.
•Use heavy-duty slip-resistant boots or shoes. Do not use open shoes or go with bare feet.
•Use heavy, long pants.
•Use protective gloves when necessary, for example when you attach, examine or clean the cutting equipment.
WARNING: Read the warning instructions that follow before you use the product.
•Do not use a product with defective safety devices.
•Do a check of the safety devices regularly. If the safety devices are defective, speak to your Husqvarna service agent.
•Examine the cutting cover to make sure that there are no damages such as cracks.
The motor brake handle stops the motor. When the motor brake handle is released, the motor stops.
To do a check of the motor brake, start the motor and then release the motor brake handle. If the motor does not stop in 3 seconds, let an approved Husqvarna service agent adjust the motor brake.
(Fig. 29 )
The safety key is below the battery lid. The safety key connects the battery that supplies the motor with power.
•Start and stop the motor to do a check of the safety key.
•If the safety key functions correctly, the motor only starts when the key is in position 1.
(Fig. 30 )
Do a check of the start inhibitor to make sure that it prevents operation of the motor.
1.Pull the motor brake handle in the direction of the handlebar. The start inhibitor stops the movement.
2.Push the start inhibitor out.(Fig. 31 )
3.Release the start inhibitor and make sure that it goes back to its initial position.
The power cord holder decreases the strain on the power socket and the power cord. The power cord holder also decreases the risk that you fall.
1.Bend the power cord to a small loop.
2.Put the loop in to the hole in the power cord holder.
3.Put the loop around the hook.
4.Pull the power cord to tighten the loop around the hook.(Fig. 32 )
WARNING: Read the warning instructions that follow before you use the product.
•Use Husqvarna rechargeable batteries as a power supply for related Husqvarna products only. To prevent injury, do not use the battery as a power supply for other devices.
•Do not use non-rechargeable batteries.
•Risk of electrical shock. Do not connect the battery terminals to keys, coins, screws or other metal. This can cause a short circuit of the battery.
•Do not put objects into the air slots of the battery.
•Keep the battery away from sunlight, heat or open flame. The battery can explode and
16 |
71 - 005 - 18.05.2018 |
cause burns and/or chemical burns.
•Keep the battery away from rain and wet conditions.
•Keep the battery away from microwaves and high pressure.
•Do not try to disassemble or break the battery.
•If the battery leaks, do not let the liquid touch your body or eyes. If you have touched the liquid, clean the area with a large quantity of water and get medical aid.
•Use the battery in temperatures between -10°C and 40°C.
•Do not clean the battery or the battery charger with water. See To clean the battery and the battery charger on page 23.
•Do not use a defective or damaged battery.
•Keep batteries in storage away from metal objects such as nails, coins, jewellery.
WARNING: Read the warning instructions that follow before you use the product.
•Use the QC battery chargers to charge Husqvarna replacement batteries only.
•
•
•
•
•
Risk of electrical shock or short circuit. Do not put objects into the air slots of the charger. Do not try to disassemble the battery charger. Do not connect the charger terminals to metal objects. Use an approved mains socket.
This product produces an electromagnetic field during operation. This field may under some circumstances interfere with active or passive medical implants. To reduce the risk of serious or fatal injury, we recommend persons with medical implants to consult their physician and the medical implant manufacturer before operating this product.
Regularly make sure that the power cord of the battery charger is not damaged and that there are no cracks in it.
Do not lift the battery charger by the power cord. To disconnect the battery charger from a mains socket, pull out the plug. Do not pull the power cord.
Keep the power cord and extension cables away from water, oil and sharp edges. Make sure that the cable is not pinched in doors, fences or
71 - 005 - 18.05.2018 |
17 |
equivalent. It can cause the charger to become energized.
•Do not clean the battery charger with water.
•The battery charger can be used by children aged from 8 years and above and persons with reduced physical, sensory, or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the battery charger in a safe way and understand the hazards involved. Children shall not play with the battery charger. Cleaning and user maintenance shall not be made by children without supervision.
•Do not charge nonrechargeable batteries in the battery charger.
•Do not use the battery charger near flammable materials or materials that can cause corrosion. Do not cover the battery charger. Pull out the plug to the battery charger if there is smoke or fire.
•Do not use a defective or damaged battery charger.
•Only charge the battery indoors in a room with good airflow and away from
sunlight. Do not charge the battery in wet conditions.
For model LC 141C.
•The use of a Residual Current Device (R.C.D.) with a tripping current of not more than 30mA is recommended. Even with an R.D.C. installed, 100% safety cannot be guaranteed and safe work procedures must be obeyed at all times. Do a check of your R.C.D. each time you use it.
•Immediately disconnect from the mains if the power cord is cut or the insulation is damaged.
•Do not touch a cut or damaged power cord until the electrical supply is disconnected.
•Do not repair a cut or damaged power cord. Replace it with a new one.
WARNING: Read the warning instructions that follow before you use the product.
•For models LC 141VLi and LC 141Li: To prevent accidental start during maintenance, turn the safety key to 0 and remove the battery. Wait at minimum 5
18 |
71 - 005 - 18.05.2018 |
seconds before you start the maintenance.
•For model LC 141C: To prevent accidental start during maintenance, disconnect the power cord.
•Do the maintenance work correctly to increase the lifetime of the product and decrease the risk of accidents. Let an approved service agent do the professional repairs. Speak to your nearest service agent for more information.
•Only do the maintenance work written in this operator's manual. More extensive work must be done by an approved service agent.
•Put on heavy duty gloves when you use the cutting equipment. The blade is very sharp and cuts can easily occur.
•Keep the cutting edges sharp and clean for the best and safest performance.
•Let your service agent regularly examine the product and make necessary adjustments and repairs.
•Replace damaged, worn or broken parts.
•Obey the instructions for how to change accessories. Only use accessories from the manufacturer.
•When not in operation, keep the product, battery and battery charger apart in a dry, indoor and locked area. Make sure that children and persons that are not approved cannot get access to the product, battery or battery charger.
WARNING: Before you assemble the product, read the safety chapter.
WARNING: For models LC 141VLi and LC 141Li: To prevent accidental start during assembly, turn the safety key to 0, remove the battery and wait at minimum 5 seconds.
For model LC 141C: To prevent accidental start during assembly, disconnect the power cord.
1.Align the holes in the handlebar with the holes in the lower handle and attach the screws, washers and knobs. Tighten the knobs fully.(Fig. 33 )
2.Attach the cables to the handle with the cable holders.(Fig. 34 )
Note: Make sure that the tension in the cables is not too high. A too high tension can cause damage to the cable if the handle is folded to transport position.
3.Put the cables around the hook at the bottom of the handle.(Fig. 35 )
1. Loosen the lower knobs.(Fig. 36 )
71 - 005 - 18.05.2018 |
19 |
2.Remove the knob, washer, and screw on the left and the right side.
3.The handle can be set to 2 different heights. Put the screw in one of the 2 holes on the left and the right side.(Fig. 37 )
4.Attach the screws, washers and knobs.
5.Move the knobs up in the direction of the handle until they stop and you hear a click. Tighten the knobs fully.(Fig. 38 )
1.Push the 2 transportation covers out and down.(Fig. 39 )
2.Put the top part of the grass catcher onto the lower part of the grass catcher. Attach the grass catcher frame with the clips.(Fig. 40 )
3.Lift the rear cover.
4.Attach the hooks on the grass catcher to the top edge of the chassis.(Fig. 41 )
1.Lift up the rear cover and remove the grass catcher.
2.Put the mulch plug into the grass discharge channel. The mulch plug of type A is for LC 141Li and
LC 141C. Type B is for LC 141VLi.(Fig. 42 )
3.Close the rear cover.
4.Replace the blade with the Combi blade, see To remove and replace the blade on page 23.
WARNING: Before you operate the product, you must read and understand the safety chapter.
If the handle is put in transport and storage position (see
To set the product in transport position on page 25), do the procedure that follows to put the handle in operation position.
1.Lift the handle until the lower handle locks into operation position.(Fig. 43 )
2.Move the lower knobs up in the direction of the handle until they stop and you hear a click.(Fig. 44 )
3.Tighten the knobs.
4.Lift the upper handle and tighten the knobs.(Fig. 45 )
1.Move the cutting height lever rearward to increase the cutting height.
2.Move the cutting height lever forward to decrease the cutting height.(Fig. 46 )
CAUTION: Do not set the cutting height too low. The blades can hit the ground if the surface of the lawn is not level.
WARNING: Before you use the battery, you must read and understand the safety chapter. You must also read and understand the operator's manual for the battery and the battery charger.
The display shows the remaining battery capacity and if there are problems with the battery. The battery capacity is shown for 5 seconds after the product is switched off or the battery indicator button is pressed. The warning symbol on the battery is on when an error has occurred. See Battery on page 24.
(Fig. 47 )
LED lights |
Battery status |
|
|
All LEDs are lit |
Fully charged (75-100%) |
|
|
LED 1, LED 2, LED 3 are |
The battery is 50%-75% |
lit |
charged |
|
|
LED 1, LED 2 are lit |
The battery is 25%-50% |
|
charged |
|
|
LED 1 is lit |
The battery is 0%-25% |
|
charged. |
|
|
LED 1 flashes |
The battery is empty. |
|
Charge the battery. |
|
|
Charge the battery before the first use. The battery is only 30% charged when supplied to the customer.
Note: The battery charger must be connected to the voltage and frequency specified on the rating plate.
The battery does not charge if the battery temperature is above 50°C. The battery charger decreases the temperature of the battery before it starts to charge.
1.Connect one end of the power cord for the battery charger into the socket of the battery charger.
20 |
71 - 005 - 18.05.2018 |
2.Connect the other end of the power cord for the battery charger in an grounded mains socket. The LED on the battery charger flashes green one time. (Fig. 48 )
3.Put the battery in the battery charger. The green light on the charger comes on when the battery is correctly connected to the battery charger.(Fig. 49 )
4.When all LEDs on the battery have come on the battery is fully charged. Charge the battery for maximum 24 hours.
5.To disconnect the battery charger from the mains socket, pull the plug, not the power cord.
6.Remove the battery from the battery charger.
A Husqvarna Li-ion battery can be charged or used at all charging levels. The battery is not damaged. A fully charged battery will not decrease its charge when the battery is left in the charger.
LED display |
Charging status |
|
|
LED 1 flashes |
0%-25% |
|
|
LED 1 is lit, LED 2 flashes |
25%-50% |
|
|
LED 1, LED 2 are lit, LED |
50%-75% |
3 flashes |
|
|
|
LED 1, LED 2, LED 3 are |
75%-100% |
lit, LED 4 flashes |
|
|
|
LED 1, LED 2, LED 3, |
Fully charged |
LED 4 are lit |
|
|
|
1.Put a charged battery in the battery compartment.
2.Turn the safety key to 1.(Fig. 50 )
3.Stay behind the product.
4.Press the ON/OFF button (A) on the control panel and the green LED (B) comes on.(Fig. 51 )
5.Loosen the start inhibitor.(Fig. 52 )
6.Push the motor brake handle in the direction of the handlebar.(Fig. 53 )
•Model LC 141VLi. Pull the drive bail in the direction of the handlebar to start the drive.(Fig. 54 )
•Press + and - on the control panel to set the drive speed in 4 steps.(Fig. 55 )
•Release the drive bail to disengage the drive, for example when you go near an obstacle.
The product has a battery saving function (SavE) that gives longer operation time.
1.Press the SavE button (A) to start the function. The green LED comes on.(Fig. 56 )
2.Press the SavE button again to stop the function. The green LED (B) goes out.
The SavE function stops automatically if the ground conditions make it necessary to have a higher output. The SavE function starts automatically when the ground conditions lets it.
When the product cuts long or wet grass, the motor automatically increases rpm. The motor goes back to standard mode when high load is not necessary.
The product stops automatically if you do not operate it for 10 minutes. Always turn the safety key to 0 before you let the product out of view.
1.Release the motor brake handle to stop the motor. (Fig. 57 )
2.Press the ON/OFF button (A) on the control panel and the green LED (B) goes out.(Fig. 58 )
3.Open the battery lid and turn the safety key to 0.(Fig. 59 )
4.To remove the battery, press the 2 release buttons and pull out the battery.(Fig. 60 )
5.Charge the battery if it is weak. For more information, see To charge the battery on page 20.
Note: For the UK market, use only the 16M extension cable that comes with the product. For all other markets, refer to the information below.
If extension cables are used, these must comply with the minimum cross-sections in the table below:
Voltage |
Cable length |
Cross section |
|
|
|
220-240V/ 50Hz |
Up to 20 m |
1.5 mm2 |
220-240V/ 50Hz |
20–50 m |
2.5 mm2 |
•Mains cables and extension cables are available from your local approved service agent for Husqvarna outdoor products.
•Only use extension cables specifically designed for outdoor use and which conform to one of the following specifications: Ordinary rubber (60245 IEC 53), Ordinary PVC (60227 IEC 53) or Ordinary PCP (60245 IEC 57)
•If the cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
71 - 005 - 18.05.2018 |
21 |
1.Connect a power cord to the socket below the handle.(Fig. 61 )
2.Put the power cord in the power cord holder. Refer to To use the power cord holder (model LC 141C) on page 16.(Fig. 62 )
3.Stay behind the product.
4.Loosen the start inhibitor.(Fig. 63 )
5.Push the motor brake handle in the direction of the handlebar.(Fig. 64 )
1.Release the motor brake handle to stop the motor. (Fig. 65 )
2.Disconnect the power cord from the mains and then from the product.(Fig. 66 )
CAUTION: Pull the plug straight out. Do not pull the power cord.
•Always use a sharp blade. A blunt blade gives an irregular result and the cut surface of the grass becomes yellow. A sharp blade also uses less energy than a blunt blade.
•Do not cut more than ⅓ of the length of the grass. Cut first with the cutting height set high. Examine the result and lower the cutting height to an applicable level. If the grass is very long, drive slowly and cut 2 times if necessary.
•Cut in different directions each time to prevent stripes in the lawn.
WARNING: Before you do maintenance, you must read and understand the safety chapter.
For all servicing and repair work on the product, special training is necessary. We guarantee the availability of professional repairs and servicing. If your dealer is not a service agent, speak to them for information about the nearest service agent.
The maintenance intervals are calculated from daily use of the product. The intervals change if the product is not used daily.
For maintenance identified with *, refer to Safety devices on the product on page 16.
LC 141VLi, LC 141Li and LC 141C |
Daily |
Weekly |
Monthly |
|
|
|
|
Do a general inspection. |
X |
|
|
|
|
|
|
Clean the product. |
X |
|
|
|
|
|
|
Do a check of the start inhibitor *. |
X |
|
|
|
|
|
|
Make sure that the safety devices on the product are not defective *. |
X |
|
|
|
|
|
|
Examine the cutting equipment. |
X |
|
|
|
|
|
|
Examine the cutting cover *. |
X |
|
|
|
|
|
|
Do a check of the motor brake handle *. |
X |
|
|
|
|
|
|
|
|
|
|
LC 141VLi and LC 141Li only |
Daily |
Weekly |
Monthly |
|
|
|
|
Make sure that the ON/OFF button operates correctly and is not defective. |
X |
|
|
|
|
|
|
Examine the battery for damage. |
X |
|
|
|
|
|
|
Do a check of the battery charge. |
X |
|
|
|
|
|
|
Make sure that the release buttons on the battery operates correctly and that the |
X |
|
|
battery locks into the product. |
|
|
|
|
|
|
|
|
|
|
|
22 |
71 - 005 - 18.05.2018 |
LC 141VLi and LC 141Li only |
Daily |
Weekly |
Monthly |
|
|
|
|
Examine the battery charger for damage and make sure that it operates correct- |
|
X |
|
ly. |
|
|
|
|
|
|
|
|
|
|
|
Examine the connections between the battery and the product. Also examine the |
|
|
X |
connection between the battery and the battery charger. |
|
|
|
|
|
|
|
|
|
|
|
•Make sure that the nuts and screws on the product are tightened.
•Make sure that the cables on the product are not in a position where they can get damaged.
•Clean plastic parts with a clean and dry cloth.
•Do not use water to clean the product. Water can enter the battery or the motor and cause short circuit or damage to the product.
•Do not use a high pressure washer to clean the product.
•Do not flush water directly on the motor.
•Use a brush to remove leaves, grass and dirt.
CAUTION: Do not clean the battery or the battery charger with water.
•Make sure that the battery and the battery charger are clean and dry before you put the battery into the battery charger.
•Clean the battery terminals with compressed air or use a soft and dry cloth.
•Clean the surfaces of the battery and the battery charger with a soft and dry cloth.
WARNING: For models LC 141VLi and LC 141Li: To prevent accidental start , turn the safety key to 0, remove the battery and wait at minimum 5 seconds.
For model LC 141C: To prevent accidental start, disconnect the power cord.
WARNING: Use protective gloves when you do maintenance on the cutting equipment.
The blade is very sharp and cuts can easily occur.
1.Examine the cutting equipment for damage or cracks. Always replace a damaged cutting equipment.
2.Look at the blade to see if it is damaged or blunt.
Note: It is necessary to balance the blade after it is sharpened. Let a service center sharpen, replace and balance the blade. If you hit an obstacle that causes the product to stop, replace the damaged blade. Let the service center estimate if the blade can be sharpened or must be replaced.
1.Lock the blade with a block of wood.(Fig. 67 )
2.Remove the blade bolt.
3.Remove the blade.
4.Examine the blade support and blade bolt to see if there are damages.
5.Examine the motor shaft to make sure that it is not bent.
6.When you attach the new blade, point the angled ends of the blade in the direction of the cutting cover. (Fig. 68 )
7.Make sure that the blade is aligned with the center of the motor shaft.
8.Lock the blade with a block of wood. Attach the spring washer and tighten the bolt and washer with a torque of 20 Nm.(Fig. 69 )
9.Pull the blade around by hand and make sure that it turns freely.
WARNING: Use heavy duty gloves. The blade is very sharp and cuts can easily occur.
10.Start the product to do a test of the blade. If the blade is not correctly attached, there is vibration in the product or the cutting result is unsatisfactory.
71 - 005 - 18.05.2018 |
23 |
LED on the battery |
Possible faults |
Possible procedure |
|
|
|
The green LED is flash- |
The battery voltage is low |
Charge the battery. See To charge the battery on |
ing |
|
page 20. |
|
|
|
The error LED flashes |
The battery is weak |
Charge the battery. See To charge the battery on |
|
|
page 20. |
|
|
|
|
The temperature in the work environ- |
Use the battery in temperatures between -10°C |
|
ment is too high or too low |
and 40°C. |
|
|
|
|
Overvoltage |
Check that the mains voltage is the same as on |
|
|
the rating plate on the product. |
|
|
|
|
|
Remove the battery from the battery charger. Wait |
|
|
5 seconds and try again to charge the battery. If |
|
|
the problem continues, speak to an authorised |
|
|
service agent. |
|
|
|
The error LED is on |
Cell difference too much (1V) |
Speak to an approved service agent. |
|
|
|
LED on the battery |
Possible faults |
Possible procedure |
charger |
|
|
|
|
|
The error LED flash- |
The temperature in the work en- |
Use the battery charger in temperatures between 5°C |
es |
vironment is too high or too low |
and 40°C. |
|
|
|
The error LED is on |
|
Speak to an approved service agent |
|
|
|
For problems, other than those in this section, speak to your service agent.
Keypad |
Possible faults |
Possible action |
|
|
|
Error LED flashes |
The motor is overloaded |
Increase the cutting height. See To set the cutting |
|
|
height on page 20. |
|
The motor speed drops too much, |
|
|
|
|
|
and the motor stops |
|
|
|
|
|
The motor control is too hot |
Stop the motor and wait until it has become cool |
|
|
|
|
The blade is blocked |
To prevent accidental start turn the safety key to |
|
|
0, remove the battery and wait a minimum 5 sec- |
|
|
onds. Make sure that the blade can rotate freely. If |
|
|
the problem continues, speak to an authorised |
|
|
service agent |
|
|
|
|
Battery error or no signal from battery |
Put the battery in the product correctly and exam- |
|
|
ine the battery connector. If the error LED on the |
|
|
battery flashes, see Battery on page 24. |
|
|
|
The product stops |
The battery is weak |
Charge the battery. See To charge the battery on |
|
|
page 20. |
|
|
|
|
Battery connector failure |
Examine the battery connector |
|
|
|
24 |
71 - 005 - 18.05.2018 |
1.Remove the grass catcher (if installed).
2.Loosen the knobs on the upper handle and fold the handle down.(Fig. 70 )
3.Loosen the lower knobs.
4.Move the knobs to the lower end of the grooves on the left and the right side of the product.(Fig. 71 )
5.Fold the handle forward.(Fig. 72 )
•The Dangerous Goods Legislation requirements apply to the contained Li-ion batteries.
•For commercial transports special requirements on package and labels must be obeyed.
•Make sure that you obey the regulations for dangerous material when you prepare the product for transport. Local regulations can apply.
•Always remove the battery for transport.
•Put tape on the battery connectors and make sure that the battery cannot move around during transport.
•Attach the product during transport.
•Always remove the battery for storage.
•To prevent accidents, make sure that the battery is not connected to the product during storage.
•Keep the battery charger in a closed and dry space.
•Keep the battery and the battery charger in a dry space where there is no moisture or frost.
•Disconnect the battery from the battery charger during storage.
•Do not keep the battery where static electricity can occur. Do not keep the battery in a metal box.
•Keep the battery where the temperature is between 5°C and 25°C and out of sunlight.
•Keep the battery charger where the temperature is between 5°C and 45°C and out of sunlight.
•Make sure that the battery is charged to 30% - 50% before you put it in storage for long periods.
•Keep the product, battery and battery charger in a locked area out of reach for children and not approved persons.
•Clean the product and do a complete servicing before you put the product in storage for a long time.
Symbols on the product or the packaging of the product indicate that this product cannot be handled as domestic waste. It must be submitted to an appropriate recycling station for the recovery of electrical and electronic equipment.
By ensuring that this product is taken care of correctly, you can help to counteract the potential negative impact on the environment and people that can otherwise result through the incorrect waste management of this product. For more detailed information about recycling this product, contact your municipality, your domestic waste service or the shop from where you purchased the product.
(Fig. 73 )
|
LC 141VLi |
LC 141Li |
|
|
|
Cutting motor |
|
|
|
|
|
Motor type |
BLDC (brushless) 36V |
BLDC (brushless) 36V |
|
|
|
Motor speed – SavE, rpm |
2700 |
2700 |
|
|
|
Motor speed – Nominal, rpm |
3100 |
3100 |
|
|
|
Motor speed – High load, rpm |
3700 |
3700 |
|
|
|
Motor output – max. kW |
0.8 |
0.8 |
|
|
|
Motor output – Nominal, kW |
0.55 |
0.55 |
|
|
|
Drive motor |
|
|
|
|
|
Motor output – Nominal, kW |
0.25 |
NA |
|
|
|
Self walk speed, km/h |
3.0–4.5 |
NA |
|
|
|
71 - 005 - 18.05.2018 |
25 |
|
LC 141VLi |
LC 141Li |
|
|
|
Speed adjustment levels |
4 |
NA |
|
|
|
Weight |
|
|
|
|
|
Weight without battery, kg |
23.2 |
20 |
|
|
|
Battery 1 |
|
|
Type of battery |
Husqvarna Battery Series |
Husqvarna Battery Series |
|
|
|
Battery runtime |
|
|
|
|
|
Battery runtime, min, (free run) with SavE activated, with |
50 |
50 |
Husqvarna 5.0 Ah battery. |
|
|
|
|
|
Battery runtime, min, (free run) with standard mode acti- |
40 |
40 |
vated, with Husqvarna 5.0 Ah battery. |
|
|
|
|
|
Noise emissions 2 |
|
|
Sound power level, measured dB (A) |
92 |
92 |
|
|
|
Sound power level, guaranteed LWA dB (A) |
94 |
94 |
Sound levels 3 |
|
|
Sound pressure level at the operators ear, dB (A) |
83 |
83 |
|
|
|
Vibration levels 4 |
|
|
Handle, m/s2 |
2.0 |
2.0 |
Cutting |
|
|
|
|
|
Cutting height, mm |
25–70 |
25–70 |
|
|
|
Cutting width, cm |
41 |
41 |
|
|
|
Blade |
Collect |
Collect |
|
|
|
Article number |
5011716-10 |
5011716-10 |
|
|
|
Bagger capacity, litre |
50 |
50 |
|
|
|
|
LC 141C |
|
|
Motor |
|
|
|
Motor type |
Series AC Motor |
|
|
Motor speed – Nominal, rpm |
3200 |
|
|
Power |
1800 W |
|
|
Power source |
Corded electric |
|
|
Power cable (included for the UK market only) |
|
|
|
Cable type |
16M extension cord |
|
|
1 For best results and performance the Husqvarna battery BLi200 is recommended.
2Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC.
3 |
Reported data for noise pressure level has a typical statistical dispersion (standard deviation) of 1.2 dB (A). |
4 |
Reported data for vibration level has a typical statistical dispersion (standard deviation) of 0.2 m/s2. |
26 |
71 - 005 - 18.05.2018 |
|
LC 141C |
|
|
Weight, kg |
1.6 |
|
|
Weight |
|
|
|
Weight, kg |
22 |
|
|
Noise emissions 5 |
|
Sound power level, measured dB (A) |
94 |
|
|
Sound power level, guaranteed LWA dB (A) |
96 |
Sound levels 6 |
|
Sound pressure level at the operators ear, dB (A) |
83 |
|
|
Vibration levels 7 |
|
Handle, m/s2 |
2.0 |
Cutting |
|
|
|
Cutting height, mm |
25–70 |
|
|
Cutting width, cm |
41 |
|
|
Blade |
Collect |
|
|
Article number |
5011716-10 |
|
|
Bagger capacity, litre |
50 |
|
|
5Noise emissions in the environment measured as sound power (LWA) in conformity with EC directive 2000/14/EC.
6 |
Reported data for noise pressure level has a typical statistical dispersion (standard deviation) of 1.2 dB (A). |
7 |
Reported data for vibration level has a typical statistical dispersion (standard deviation) of 0.2 m/s2. |
71 - 005 - 18.05.2018 |
27 |
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares that the lawn mowers Husqvarna LC 141VLi and LC 141Li from serial number 15XXXXXXX and onwards, comply with the requirements of the COUNCIL’S DIRECTIVE:
•of June 8, 2011 on the ”restriction of use of certain hazardous substances” 2011/65/EU
•of May 17, 2006 ”relating to machinery” 2006/42/EC
•of February 26, 2014 ”relating to electromagnetic compatibility” 2014/30/EU
•of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC
For information relating to noise emissions, see the Technical data chapter.
The following standards have been applied:
EN 60335-1:2012+A11:2014, EN 60335-2-77:2010, EN 62233:2008, EN 55014-1:2006/+A1:2009/+A2:2011, EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-3:2013
Notified body: 0359, Intertek Testing & Certification Ltd., 58 Jinfeng Road, Yuyao, Zhejiang 315403, P.R. China has performed conformity assessment according to Annex VI of Directive 2000/14/EC and issued a certificate with the number: 71225
Huskvarna, 2016-10-31
Claes Losdal, Development Manager/Garden Products (Authorized representative for Husqvarna AB and responsible for technical documentation.)
Husqvarna AB, SE-561 82 Huskvarna, Sweden, tel: +46-36-146500, declares that the lawn mower Husqvarna LC 141C from the serial number 15XXXXXXX and onwards, complies with the requirements of the COUNCIL’S DIRECTIVE:
•of June 8, 2011 on the ”restriction of use of certain hazardous substances” 2011/65/EU
•of May 17, 2006 ”relating to machinery” 2006/42/EC
•of February 26, 2014 ”relating to electromagnetic compatibility” 2014/30/EU
•of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC
For information relating to noise emissions, see the Technical data chapter.
The following standards have been applied:
EN 60335-1:2012+A11:2014, EN 60335-2-77:2010, EN 62233:2008, EN 55014-1:2006/+A1:2009/+A2:2011, EN 55014-2:2015, EN 61000-3-2:2014, EN 61000-3-11:2000
Notified body: 0499, The Société Nationale de Certification et d'Homologation s.à r.l. (SNCH) Luxemburg certifies in accordance with SNCH procedures that the Manufacturer fulfils the provisions of the Directive 2000/14/EC Annex VI and issued a certificate with the number: SNCH*2000/14*2005/88*2945*00
Huskvarna, 2016-10-31
Claes Losdal, Development Manager/Garden Products (Authorized representative for Husqvarna AB and responsible for technical documentation.)
28 |
71 - 005 - 18.05.2018 |
Содержание
Въведение................................................................... |
29 |
Отстраняване на проблеми........................................ |
45 |
Безопасност................................................................. |
32 |
Транспортиране, съхранение и изхвърляне............. |
46 |
Монтаж......................................................................... |
40 |
Технически характеристики....................................... |
47 |
Експлоатация.............................................................. |
41 |
Декларация за съответствие на ЕО.......................... |
50 |
Поддръжка................................................................... |
43 |
|
|
Описание на продукта |
Предназначение |
|||
Продуктът е пешеходна ротационна косачка. |
Използвайте продукта, за да косите трева в частни |
|||
Тревата се събира в кош за трева. Свалете коша за |
градини. Не използвайте продукта за други задачи. |
|||
трева, за да се получи задно разтоварване на |
|
|
||
тревата. Поставете комплект за мулчиране |
|
|
||
(допълнителна принадлежност), за да нарежете |
|
|
||
тревата в тора. |
|
|
||
Общ преглед на продукта LC 141VLi/LC 141Li |
||||
(Фиг. 1 ) |
|
|
||
1. |
Ръкохватка за спирачката на двигателя |
14. |
Заден капак |
|
2. |
Инхибитор за стартиране |
15. |
Символи |
|
3. |
Дръжка за задвижване (LC 141VLi) |
16. |
Капак на акумулатора |
|
4. |
Дръжка/управление |
17. |
Ключ за безопасност |
|
5. |
Пулт за управление |
18. |
Капак срещу порязване |
|
6. |
Бутон за ВКЛ./ИЗКЛ. |
19. |
Лост за височината на рязане |
|
7. |
Бутон SavE |
20. |
Табелка за модела |
|
8. |
Бутон за индикатора на батерията |
21. |
Кош за трева |
|
9. |
Индикатор за състояние на акумулатора |
22. |
Щифт за мулчиране за LC 141VLi |
|
10. |
Индикатор за предупреждение (СВЕТОДИОД ЗА |
|
(Принадлежност) |
|
|
ГРЕШКА) |
23. |
Щифт за мулчиране за LC 141Li (Принадлежност) |
|
11. |
Бутон за намаляване на скоростта (LC 141VLi) |
24. |
Зарядно устройство за акумулатор |
|
12. |
Индикатор за изравняване на скоростта |
|
(Принадлежност) |
|
|
(LC 141VLi) |
25. |
Акумулатор (Принадлежност) |
|
13. |
Бутон за увеличаване на скоростта (LC 141VLi) |
26. |
Инструкция за експлоатация |
|
Общ преглед на продукта LC 141C |
|
|
||
(Фиг. 2 ) |
|
|
||
1. |
Ръкохватка за спирачката на двигателя |
12. |
Кош за трева |
|
2. |
Инхибитор за стартиране |
13. |
Инструкция за експлоатация |
|
3. |
Гнездо на захранващия кабел |
Символи върху продукта |
||
4. |
Държач на захранващия кабел |
|||
|
Невнимателното или |
|||
5. |
Дръжка/управление |
|
||
|
|
|||
6. |
Заден капак |
|
погрешното използване |
|
7. |
Символи |
|
||
8. |
Капак срещу порязване |
|
на продукта може да |
|
|
|
|||
9. |
Табелка за модела |
(Фиг. 3 ) доведе до нараняване |
||
10. |
Лост за височината на рязане |
|||
11. |
Щифт за мулчиране (Принадлежност) |
|
|
71 - 005 - 18.05.2018 |
29 |
(Фиг. 4 )
(Фиг. 5 )
(Фиг. 6 )
(Фиг. 7 )
(Фиг. 8 )
(Фиг. 9 )
(Фиг. 10 )
или смърт на оператора или наблюдатели.
Прочетете ръководството за оператора и се уверете, че разбирате инструкциите, преди да използвате този продукт.
Дръжте хората и животните на безопасно разстояние от работната зона.
Пазете се от отскачащи предмети и рикошети.
Предупреждение: Дръжте ръцете и краката си далеч от въртящия се нож.
Предупреждение: Дръжте ръцете и краката си далеч от въртящи се части.
Извадете ключа за безопасност преди извършване на техническа поддръжка на продукта. (модел
LC 141VLi/LC 141Li)
Преди да извършите техническата поддръжка, изключете уреда от електрическия
(Фиг. 11 )
(Фиг. 12 )
(Фиг. 13 )
(Фиг. 14 )
(Фиг. 15 )
(Фиг. 16 )
контакт. (модел
LC 141C)
IPX1 – продуктът е със защита от капеща вода
(модел LC 141VLi/ LC 141Li)
IPX4 – продуктът е със защита от напръскване с вода (модел LC 141C)
Продуктът не трябва да бъде изложен на дъжд
(модел LC 141VLi/ LC 141Li)
Предупреждение: При работа с продукта не преминавайте върху захранващия шнур, тъй като това може да доведе до електрически удар или повреда на продукта. (модел
LC 141C)
Този продукт отговаря на изискванията на приложимите директиви на EO.
Шумови емисии в околната среда в съответствие с Директивата на Европейската общност. Емисиите на продукта са посочени в раздела за технически
30 |
71 - 005 - 18.05.2018 |
