Huawei HG532t Owner's Manual

HG532t Home Gateway

HUAWEI TECHNOLOGIES CO., LTD.

User Guide

HG532t Home Gateway

V100R001

User Guide

Issue

Date

Part Number

2012-10-26

202534

Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service. Please feel free to contact our local office or company headquarters.

Huawei Technologies Co., Ltd.

Address: Huawei Industrial Base

Bantian, Longgang

Shenzhen 518129

People's Republic of China

Website: http://www.huawei.com

Email: mobile@huawei.com

No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.

The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses.

Trademarks and Permissions

, , and

Technologies Co., Ltd.

Other trademarks, product, service and company names mentioned are the property of their respective owners.

are trademarks or registered trademarks of Huawei

Notice

Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers. Thus the descriptions herein may not exactly match the product or its accessories you purchase.

Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.

NO WARRANTY

THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS’’. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.

Import and Export Regulations

Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.

Contents

1 Connecting the Cables and Getting Started ........................... 1

1.1 Adjusting the Antenna ................................................................... 1

1.2 Connecting Cables Using the ADSL Port ........................................ 1

1.3 Connecting Cables Using the USB Port .......................................... 3

1.4 Getting Started ............................................................................. 3

2 Setting Network Access Parameters ....................................... 4

2.1 Logging In to the Web-based Configuration Utility .......................... 4

2.2 Configuring a Dial-up Connection for Internet Access ..................... 5

3 Setting Up a Wireless Connection ........................................... 6

3.1 Setting Up a Wireless Connection With the WPS Button .................. 6

3.2 Setting Up a Wireless Connection Manually.................................... 7

4 Using the USB Port ...................................................................... 9

4.1 Going Online Using a USB Modem ............................................... 9

4.2 Accessing a Portable Storage Device Using the Samba Server ........ 10

4.3 Accessing a Printer Using the Printer Server ................................. 11

5 Maintenance Guide ................................................................. 12

5.1 Changing the User Name and Password for the Web-Based

Configuration Utility ......................................................................... 12

5.2 Enabling or Disabling the Wireless Network Function ................... 12

5.3 Changing the Wireless Network Name and Password ..................... 13

5.4 Changing the PIN code for your SIM card .................................... 13

5.5 Restoring Default Settings ........................................................... 14

6 FAQs ......................................................................................... 15

7 Appendix .................................................................................. 18

7.1 Indicators ................................................................................... 18

7.2 Ports and Buttons ........................................................................ 20

7.3 Default Settings .......................................................................... 22

7.4 Technical Specifications .............................................................. 22

1 Connecting the Cables and Getting

Started

Thank you for purchasing the HG532t.

HG532t supports the ADSL broadband services and USB modem services, and you can go online using the ADSL port or USB port.

1.1 Adjusting the Antenna

When adjusting the antenna, refer to the following direction.

1.2 Connecting Cables Using the ADSL Port

If your home has opened Asymmetric Digital Subscriber Line (ADSL) broadband services, you can access the internet using the telephone wall jack available in your home.

The following figure shows an example of how to connect cables using the ADSL port. In this example, the HG532t is connected to a desktop computer, a laptop computer, and a telephone.

1. Power adapter

2. Desktop computer

3. Laptop computer

4. Telephone

5. Splitter

6. Telephone wall jack

7. HG532t

a. Splitter MODEM port

b. Splitter PHONE port

c. Splitter LINE port

1.3 Connecting Cables Using the USB Port

1 2

The following figure shows an example of how to connect cables using the USB port. In this example, the HG532t is connected to a desktop computer, a laptop computer, and a telephone.

1. Power adapter 2. HG532t 3. USB modem

4. Desktop computer 5. Laptop computer

1.4 Getting Started

After connecting the cables, press the On/Off button on the side of the HG532t to power on the HG532t.

After you power on the HG532t, the Power indicator turns on, indicates that the HG532t is working properly.

To power off the HG532t, press the On/Off button on the side panel, and then unplug the power adapter.

2 Setting Network Access Parameters

2.1 Logging In to the Web-based Configuration

Utility

Most of the HG532t parameters are preset before delivery to meet common home application scenarios. To check the HG532t's working status or configure certain advanced network functions, use the web-based configuration utility.

To log in to the web-based configuration utility:

Step 1

Set up network access for your computer. Set the network connection of your computer to obtain an IP address automatically.

By default, the Dynamic Host Configuration Protocol (DHCP) function is enabled. The HG532t then assigns an IP address to your computer automatically. If you disable the DHCP function, please ensure that the IP address of the computer and that of the HG532t LAN port are in the same network segment to enable the computer to access the web-based configuration utility.

Step 2

Open a web browser on your computer and ensure that the browser does not use any proxy servers.

Using Internet Explorer 8.0 as an example to ensure no proxy servers are used:

1. Choose Tools > Internet Options.

2. On the Connections tab of the Internet Options dialog box, click

LAN Settings.

3. In the Proxy server area, ensure that Use a proxy server for your LAN is cleared. If Use a proxy server for your LAN is selected, clear Use a proxy server for your LAN, and then click OK.

Step 3

http://192.168.1.1

Enter

in the address bar, and then press

Enter
