HPE ProLiant BL460c Gen9 Server Blade

Overview

Page 1

HPE ProLiant BL460c Gen9 Server Blade

HPE ProLiant BL460c Gen9 Server Blade – Internal View

FlexibleLOM adapter

USB 3.0 and TPM

Nand Flash & Micro SD

Embedded SATA Connector

3. Mezzanine Slots (x16 PCI 3.0)

9. Solid State Device Connector

Sixteen (16) DDR4 DIMM slots (8 per processor)

10.

Two hot-plug drive bays

Up to two (2) Intel® Xeon® E5-2600 v3 or v4 family processors

11.

HPE Smart Controller Options

6. HPE BLc 12W Smart Storage Battery connector

12.

iLO Management Engine

What's New

• Some drives have changed

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

NOTE: This document covers the HPE ProLiant BL460c Gen9 server blade only. For information on HPE BladeSystems c-Class

NOTE:

Processor

E5-2600 v4 series Processors

HPE BL460c Gen9 Intel® Xeon® E5-2690v4 (2.6GHz/14-core/35MB/135W)

HPE BL460c Gen9 Intel® Xeon® E5-2683v4 (2.1GHz/16-core/40MB/120W)

HPE BL460c Gen9 Intel® Xeon® E5-2680v4 (2.4GHz/14-core/35MB/120W)

HPE BL460c Gen9 Intel® Xeon® E5-2660v4 (2.0GHz/14-core/35MB/105W)

HPE BL460c Gen9 Intel® Xeon® E5-2650v4 (2.2GHz/12-core/30MB/105W)

HPE BL460c Gen9 Intel® Xeon® E5-2650Lv4 (1.7GHz/14-core/35MB/65W)

HPE BL460c Gen9 Intel® Xeon® E5-2640v4 (2.4GHz/10-core/25MB/90W)

HPE BL460c Gen9 Intel® Xeon® E5-2630v4 (2.2GHz/10-core/20MB/85W)

HPE BL460c Gen9 Intel® Xeon® E5-2623v4 (2.6GHz/4-core/10MB/85W)

HPE BL460c Gen9 Intel® Xeon® E5-2620v4 (2.1GHz/8-core/20MB/85W)

HPE BL460c Gen9 Intel® Xeon® E5-2699v4 (2.2GHz/22-core/55MB/145W)

HPE BL460c Gen9 Intel® Xeon® E5-2698v4 (2.2GHz/20-core/50MB/135W)

HPE BL460c Gen9 Intel® Xeon® E5-2697v4 (2.3GHz/18-core/45MB/145W)

HPE BL460c Gen9 Intel® Xeon® E5-2697Av4 (2.6GHz/16-core/40MB/145W)

HPE BL460c Gen9 Intel® Xeon® E5-2695v4 (2.1GHz/18-core/45MB/120W)

HPE BL460c Gen9 Intel® Xeon® E5-2667v4 (3.2GHz/8-core/25MB/135W)

HPE BL460c Gen9 Intel® Xeon® E5-2643v4 (3.4GHz/6-core/20MB/135W)

HPE BL460c Gen9 Intel® Xeon® E5-2637v4 (3.5GHz/4-core/15MB/135W)

NOTE:

'Memory Speed by Processor Model' table in the Memory section of the QuickSpecs.

Enclosures and HPE BladeSystem c-Class Interconnect and Mezzanine Components, please see the following: HPE BladeSystem c-Class Enclosures QuickSpecs:

• HPE BladeSystem c3000 Enclosure QuickSpecs at https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128340.pdf

NOTE: The c3000 HPE c-Class enclosures have full backwards and forwards compatibility, existing server blades are supported in the new enclosures and any future server blades will be supported in the existing enclosures.

• HPE BladeSystem c7000 Enclosure QuickSpecs at https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128339.pdf

NOTE: The c7000 HPE c-Class enclosures have full backwards and forwards compatibility, existing server blades are supported in the new enclosures and any future server blades will be supported in the existing enclosures.

• HPE BladeSystem c-Class Interconnect and Mezzanine Components at

https://www.hpe.com/us/en/integrated-systems/bladesystem.html#portfolio https://www.hpe.com/us/en/integrated-systems/bladesystem.html#portfolio

NOTE: For optimal cooling and system performance the BL460c Gen9 Server Blade requires the c7000 enclosure to be

configured with 10 fans and the c3000 enclosure to be configured with 6 fans. NOTE: For proper BladeSystem operation, the minimum required versions of HPE Onboard Administrator and HPE Virtual Connect are required and available via the HPE Service Pack for ProLiant, please see http://h17007.www1.hpe.com/us/en/enterprise/servers/products/service_pack/spp/index.aspx

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information -

Factory Integrated Models" section.

One of the following depending on Model

All processors within the server must be identical. NOTE: DIMM slots 4 and 5 are not accessible when the E5-2699 v4, E5-2697 v4, E5-2697A v4, E5-2667 v4, E5-2643 v4, E5-2637 v4, E5-2699 v3, the E5-2697 v3, the E5-2643 v3, the E5-2637 v3, or the E52667 v3 is used. In a 2 processor configuration, there are twelve (12) total available DIMM slots. NOTE: For the maximum supported memory speeds for each processor listed above, please reference the

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 3

NOTE: All processors support Intel® Hyper-Threading and Intel® Turbo Boost Technologies except the E5-

Cache Memory

55MB (1x55MB) L3 cache

NOTE: For Twenty two-core processors.

50MB (1x50MB) L3 cache

NOTE: For Twenty-core processors.

45MB (1x45MB) L3 cache

NOTE: For Eighteen-core processors.

40MB (1x40MB) L3 cache

NOTE: For Sixteen-core processors.

35MB (1x35MB) L3 cache

NOTE: For Fourteen-core processors.

30MB (1x30MB) L3 cache

NOTE: For Twelve-core processors.

25MB (1x25MB) L3 cache

NOTE: For Ten or Eight-core processors.

20MB (1x20MB) L3 cache

NOTE: For Six, Eight, or Ten-core processors.

15MB (1x15MB) L3 cache

NOTE: For Quad or Six-core processors.

10MB (1x10MB) L3 cache

NOTE: For Quad-core processors.

Chipset

Intel® C610 Series Chipset

Intel® E5-2600 v3 or v4 Processor Family

NOTE: For more information regarding Intel chipsets, please see the

Upgradeability

Upgradeable to two (2) processors

On System

HPE iLO (Firmware HPE iLO4 2.0), 4GB NAND with 1GB USB user space configurable via UEFI and

iLO QuickSpecs.

NOTE:

https://www.hpe.com/us/en/servers/integrated-lights-out-ilo.html

One of the following depending on Model

2609 v4, E5-2603 v4, E5-2603 v3 and E5-2609 v3. NOTE: DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the quantity and type of DIMMs installed.

NOTE: Supports 1 or 2 processors. Mixing different processor models is not supported. NOTE: For the Intel® C610 Chipset E5-2600 v3 and v4 Series, the letter preceding the model number

indicates the Product Line (E3, E5, E7); 2600x, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 = Processor SKU, and x = L for low power SKUs. NOTE: The BL460c Gen9 includes two I/O mezzanine expansion slots. A processor must be installed in processor slot 1 for access to the first mezzanine expansion slot (expansion slot 1). A processor must be installed in processor slot 2 for access to the second mezzanine expansion slot (expansion slot 2). NOTE: The letter "L" following the model number indicates denotes lower wattage.

following: http://www.intel.com/content/www/us/en/chipsets/chipsets-overview.html

Management Chipset

accessible via iLO. Read and learn more in the

For more information, visit:

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 4

Memory Protection

Advanced ECC

Memory Mirroring

Memory Online Spare Mode (Rank Spare Mode)

Memory

Type

HPE SmartMemory

DDR4 Load Reduced (LRDIMM), or Registered (RDIMM)

Standard (Pre-

256GB (8 x 32GB) DDR4 2400MT/s LDIMMs at 1.2V

Maximum (LRDIMM)

2TB (16 x 128GB) up to 2400MT/s at 1.2V

Maximum (RDIMM)

512GB (16 x 32GB) up to 2133MT/s at 1.2V

NOTE:

Network Controller

One (1) 20Gb 2-port FlexFabric FLB, 10Gb 2-port HPE FlexFabric FLB, or 10Gb 2-port Ethernet FLB

Expansion Slots

Two (2) I/O expansion mezzanine slots:

NOTE: This expansion slot supports dual-port and quad-port mezzanine cards. For dual-port

One of the following depending on Model

configured Models)

128GB (4x 32GB) DDR4 2400MT/s LDIMMs at 1.2V 64GB (4 x 16GB) DDR4 2400MT/s RDIMMs at 1.2V 32GB (2 x 16GB) DDR4 2400MT/s RDIMMs at 1.2V 16GB (2 x 8GB) DDR4 2400MT/s RDIMMs at 1.2V

HPE memory from previous generation servers (DDR3) is not compatible with this server. HPE SmartMemory is required to realize the memory performance improvements and enhanced functionality listed in this document for Gen9. For additional information, please see the HPE SmartMemory QuickSpecs

https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111535

at:

NOTE: LRDIMM and RDIMM are distinct memory technologies and cannot be mixed within a server. NOTE: Depending on the memory configuration and processor model, the memory speed may run at

2400MT/s, 2133MT/s, 1866MT/s, or 1600MT/s. Please see the Online Memory Configuration Tool at:

https://memoryconfigurator.hpe.com/DDR4memoryconfig/Home/SelectServer

One of the following depending on Model

NOTE: Supports FCoE, TCP/IP offload engine, hardware-based accelerated iSCSI, iSCSI boot, and autosensing 10Gb/1Gb Ethernet. NOTE: Each port is autosensing the speed, and can interoperate with 1Gb HPE BladeSystem c-Class interconnect components. Both ports will operate at the same speed. NOTE: FlexFabric capabilities require the use of an HPE Virtual Connect FlexFabric or Flex10/10D module module. Fibre Channel over Ethernet (FCoE) is supported with HPE interconnects. Learn more at: https://www.hpe.com/us/en/integrated-systems/virtual-connect.html

One (1) HPE FlexFabric 10Gb 2-port 536FLB FlexibleLOM One (1) HPE Ethernet 10Gb 2-port 560FLB FlexibleLOM One (1) HPE FlexFabric 20Gb 2-port 650FLB FlexibleLOM

NOTE: FlexibleLOMs are not compatible with prior generation c-Class server blades

Standard iLO Network Controller: One (1) 10/100 Mbps port for the HPE iLO 4 to Onboard Administrator link. The Onboard Administrator (with 10/100/1000 Mbps) to BladeSystem link is 1Gbps

• x16 PCIe 3.0 Type A (supports Type A mezzanine cards) (expansion slot 1).

NOTE: This expansion slot supports dual-port mezzanine cards: one port is routed to interconnect module bay 3 and the other to bay 4.

• x16 PCIe 3.0 Type B (supports Type A and Type B mezzanine cards (expansion slot 2).

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 5

cards, one port is routed to interconnect module bay 5 and the other to bay 6. For quad-port

HPE Server ROM

HPE ROM (read only memory) is now digitally signed using the HPE Corporate Signing Service. This

HPE Server UEFI

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and

cards, one port is routed to interconnect module bay 5, one to bay 6, one to bay 7, and one to bay

8. NOTE: A second processor must be installed (in processor slot 2) to have access to the second expansion slot (expansion slot 2).

Mezzanine card options include:

• Dual-port 20Gb FlexFabric, Dual-port 10Gb FlexFabric, 10GbE options, and quad-port 1Gb Ethernet

server adapter mezzanine options for additional network ports.

• Dual-port 16Gb Fibre Channel HBA for SAN connectivity.

• QDR and FDR InfiniBand for low latency and high bandwidth server interconnectivity.

• I/O accelerator mezzanine options for high transaction rate local storage

signature is verified before the flash process starts, reducing accidental programming and preventing malicious efforts to corrupt system ROM.

HPE ROM provides for essential initialization and validation of hardware components before control is passed to the customer-installed operating system. The ROM also provides the capability of booting from various fixed media (HDD, CD-ROM) and removable media (USB), to continue operation to the operating system.

HPE ROM performs very early configuration of the video controller, to allow monitoring of initialization progress via an attached monitor. If configuration or hardware errors are discovered during this early phase of hardware initialization, suitable messages are now displayed on the connected monitor. Additionally, these configuration or hardware errors are logged to the Integrated Management Log (IML) to assist in diagnosis. The HPE ProLiant ROM is used to configure the following:

• Processor and chipset status registers

• System memory, memory map, and memory initialization

• System hardware configuration (integrated PCI devices and optional PCIe cards).

• Customer-specific BIOS configuration using the HPE ROM-Based Setup Utility (RBSU).

NOTE: For further information, please refer to the HPE RBSU (ROM based setup utility) user guide:

http://h20628.www2.hpe.com/km-ext/kmcsdirect/emr_na-c00191707-19.pdf

/Legacy ROM

more secured configuration while interacting with your server at boot time. HPE ProLiant Gen9 platform defaults to UEFI and can be factory or field configured for Legacy BIOS Boot Mode.

NOTE: The UEFI System Utilities function is analogous to the HPE ROM-Based Setup Utility (RBSU) of legacy BIOS. For more information, please visit

https://www.hpe.com/us/en/product-catalog/detail/pip.6935826.html

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot

• Operating system specific functionality

• Support for > 2.2 TB (using GPT) boot drives

• USB 3.0 Stack

• Embedded UEFI Shell

• Mass Configuration Deployment Tool using HPE RESTful API

• PXE boot support for IPv6 networks

• Boot support for option cards that only support a UEFI option ROM

NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI.

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 6

NOTE: HPE UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in

Storage Controller

All BTO Models

One (1) HPE Smart Array P244br Controller with 1GB Flash-Backed Write Cache

Maximum Internal

Hot Plug SFF SAS

4.0TB

2 x 2.0TB

Hot Plug SFF SATA

4.0TB

2 x 2.0TB

Hot Plug SFF SAS SSD

7.68TB

2 x 3.84TB

Hot Plug SFF SATA SSD

7.68TB

2 x 3.84TB

Hot Plug SFF NVMe SSD

4.0TB

2 x 2.0TB

NOTE: The ProLiant BL460c Gen9 server includes the HPE hot plug small form factor (SFF) SmartDrive

Interfaces

Micro SDHC Slot

One (1) internal Micro Secure Digital High Capacity (Micro SDHC) card slot

USB 3.0 Port

One (1) internal USB 3.0 connector for USB flash media drive keys

NOTE: The above options are intended for integrated hypervisor virtualization environments.

Industry Standard

ACPI 2.0

Operating Systems and Virtualization

Microsoft Windows Server Red Hat Enterprise Linux (RHEL)

the factory.

Storage

One of the following depending on Model

(FBWC) supporting RAID 0 and RAID 1, or HPE H244br Smart HBA.

NOTE: The HPE Smart Array P244br, the HPE H244br Smart HBA, and the HPE B140i (chipset SATA). Support two (2) small form factor (SFF) hot plug drive bays. NOTE: For NVMe support, please select the NVMe FIO setting (825555-B21) available on CTO models only.

carrier for enhanced management and reduced maintenance errors. HPE drives from previous generation servers (prior to Gen8) are not compatible with the ProLiant BL460c Gen9 drive bays.

Compliance

Microsoft® Logo certifications USB 3.0 Support IPMI 2.0 Secure Digital 2.0 TPM 1.2 Support IEEE (specific IEEE standards depending on Ethernet adapter card(s) installed) Advanced Encryption Standard (AES) Triple Data Encryption Standard (3DES) SNMP SSL 2.0 DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP) Active Directory v1.0 PCIe 3.0 ASHRAE A3 FIPS 140-2 Level-1 certification Energy Star

NOTE: Energy Star Family level certification covering all BL460c Gen9 E5-2600 v3 configurations that do not include the Intel Xeon E5-2699v3 processor. For more information, visit https://www.hpe.com/us/en/about/environment/eco-labels.html

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 7

Software Support

SUSE Linux Enterprise Server (SLES)

VMware

NOTE: For more information on the HPE Certified and Supported ProLiant Servers for OS and

server-balde.7271227.html

Enclosures

Hewlett Packard Enterprise offers two different c-Class server blade enclosures to meet your individual needs:

Graphics

Integrated Matrox G200eh video controller

HPE iLO Management On System Management Memory

Form Factor

HPE ProLiant BL460c Gen9 is a half-height server blade that plugs into the HPE BladeSystem c3000 and

Embedded

HPE Integrated Lights

Monitor your servers for ongoing management, service alerting, reporting and

UEFI

Configure and boot your servers securely with industry standard Unified Extensible

HPE RESTful API

RESTful API is an application programming interface. RESTful Web Service API

Intelligent

Provision servers by discovering and deploying 1 to few servers with Intelligent

Server Utilities

HPE Smart Update

Optimize firmware and driver updates with HPE Smart Update solutions. Learn more

http://h17007.www1.hpe.com/us/en/enterprise/servers/products/service_p

for ProLiant Servers

Canonical Ubuntu Oracle Solaris

Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at:

https://www.hpe.com/us/en/servers/server-operating-systems.html and our driver

download page:

https://www.hpe.com/us/en/product-catalog/servers/proliant-servers/pip.hpe-proliant-bl460c-gen9-

• The HPE BladeSystem c7000 rack enclosure is 10U high and holds up to sixteen (16) ProLiant

BL460c Gen9 servers plugged vertically.

• The HPE BladeSystem c3000 rack enclosure is 6U high and holds up to eight (8) HPE ProLiant

BL460c Gen9 servers plugged horizontally.

Server blades, interconnect modules, power supplies, fans, and redundant Onboard Administrator modules are all designed to fit into the c3000 and c7000 enclosures.

NOTE: For additional enclosure information, please see:

https://www.hpe.com/us/en/integrated-

systems/bladesystem.html#portfolio

• 1600 x 1200 (32 bpp)

• 1920 x 1200 (16 bpp)

• 16 MB Flash Video Memory

• 256 MB DDR 3 with ECC (112 MB after ECC and video)

c7000 enclosures.

Management

Out

remote management with iLO. Learn more at

https://www.hpe.com/us/en/servers/integrated-lights-out-ilo.html

Firmware Interface (UEFI). Learn more at https://www.hpe.com/us/en/product- catalog/detail/pip.6935826.html

served by iLO’s web server.

https://www.hpe.com/us/en/servers/restful-api.html.

Provisioning

Provisioning. Learn more at https://www.hpe.com/us/en/productcatalog/detail/pip.5219984.html

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 8

ack/hpsum/index.aspx

HPE Systems Insight

HPE SIM allows you to monitor the health of your HPE ProLiant Servers and HPE

Scripting Tool Kit and

Provision 1 to many servers using your own scripts to discover and deploy them with

HPE RESTful Interface

HPE RESTful API tool is a scripting tool to provision servers using RESTful API

HPE iLO Mobile

Enables the ability to access, deploy, and manage your server anytime from

Security

• Power-on password

Availability

Memory

supporting multiple data paths routed to redundant interconnect modules.

Manager (HPE SIM)

Integrity Servers, and also provides you with basic support for non-Hewlett Packard Enterprise servers. HPE SIM also integrates with HPE SUM to provide quick and seemless firmware updates. Learn more at

https://www.hpe.com/us/en/product-

catalog/detail/pip.489496.html

Windows PowerShell

HPE Scripting Tool Kit for Windows and Linux or HPE Scripting Tools for Windows PowerShell.

Tool

Application

• Administrator's password

• Keyboard password (QuickLock)

• HPE iLO Management On System Management Chipset with:

− SSL encryption

− Secure Shell version 2

− Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on

Interface to discover and deploy servers at scale. Learn more at

https://www.hpe.com/us/en/servers/restful-api.html

anywhere from select smartphones and mobile devices. For additional information please visit:

https://www.hpe.com/us/en/servers/integrated-lights-out-ilo.html

browser, CLP and XML scripting interface

− AES and RC4 encryption of video

• External USB port enable/disable

• Network server mode

• Serial interface control

• TPM (Trusted Platform Module) 2.0 option

• Advanced Encryption Standard (AES)

• Intel® Advanced Encryption Standard-New Instructions (AES-NI)

• FIPS 140-2 Level-1 certification

• Advanced ECC uses single device data correction (SDDC) to detect and correct single and all multi-

bit error that occurs within a single DRAM chip. Both x4 and x8 SDDC are supported (x8 requires lockstep mode).

• Memory online spare mode (also known as rank spare mode) detects a rank that is degrading and

switches operation to the spare rank.

• Memory demand and patrol scrubbing to prevent accumulation of correctable errors and reducing

the likelihood of unplanned downtime.

• Failed DIMM isolation improves the service time thus improving the overall system availability.

• Address parity protection available on RDIMMs and LRDIMMs detects address bit errors to improve

service time and overall system availability.

Mezzanine options and I/O

• Support for one (1) FlexibleLOM, providing two (2) (i.e. redundant) Ethernet ports

• Multiple mezzanine I/O expansion slots that support a wide variety of mezzanine cards each

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Standard Features

Page 9

• Network Adapter Teaming (bonding) provides network fault tolerance, transmit load balancing, and

Warranty

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network

available at https://support.hpe.com/hpsc/wc/public/home

switch-assisted load balancing.

Storage

• Two (2) Small Form Factor hot-plug SAS/SATA HDD or SSD or NVMe SSD drive bays.

• Choice of the HPE Smart Array P244br Controller with 1GB FBWC, HPE Smart HBA H244br, or the

HP B140i (chipset SATA). RAID 0 and 1 support for all three storage controller offerings.

• Optional dual-port Fibre Channel mezzanine card(s) for redundant SAN connections.

NOTE: For NVMe support, please select the NVMe FIO setting (825555-B21) available on CTO models only.

Processor/Chipset

• Processor internal sensors & thermal control protection against over-temperature conditions.

• Cache parity/ECC protects cache data from accidental data corruption.

• Machine Check Architecture (MCA) detects and captures hardware errors such as system bus,

memory ECC, parity, and cache, and improves service time.

• Intel® QPI Protocol Protection allows detection of data errors using a checksum of 8-bits.

• Core Disable for FRB (fault resilient boot) allows a system to power-on despite a failing core-pair. It

uses BIST (built-in self-test) results to detect a failure and disables the target core-pair upon subsequent boot.

Server Blade Enclosure Infrastructure

• Pooled power for true N+N power redundancy through up to six (6) hot-plug, high-efficiency,

common slot enclosure-based power supplies (configuration dependent).

• Up to ten (10) enclosure-based hot-plug HPE Active Cool fans that scale to meet future demands,

optimize airflow, reduce power draw, and improve acoustic performance.

• Dual grid power providing redundant rack enclosure power feeds to the server blade enclosure.

• HPE Dynamic Power Saver Mode monitors the total enclosure power consumption in real time and

automatically adjusts with change in demand for improved efficiency and reliability.HPE Dynamic Power Capping safely limits power usage without impacting performance by capping peak usage instead of average power usage, removes risk to electrical infrastructure with a fast-acting, hardwarebased capping algorithm, and reclaims more power by dynamically controlling power limits based on workload demand.

• Up to eight interconnect modules per server blade enclosure providing four simultaneous redundant

fabrics for FlexFabric, Virtual Connect Ethernet, Fibre Channel, InfiniBand, Pass Thru Ethernet, etc.

• Enclosure crosslinks between adjacent enclosures to provide interconnect module-to-module

connections or as Virtual Connect module stacking links.

• Optional enclosure redundant Onboard Administrator system management module.

of Hewlett Packard Enterprise Authorized Channel Partners. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Pointnext operational services or customized service agreements. Certain restrictions and exclusions apply. Hard drives have either a one year or three year warranty; refer to specific hard drive QuickSpecs for details.

NOTE: Server warranty includes 3-year Parts, 3-year Labor, 3-year on-site support. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories:

1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HPE replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is

QuickSpecs

Optional Features

Fibre Channel

Up to two (2) optional Fibre Channel mezzanine HBAs are supported on the HPE ProLiant BL460c Gen9.

Compatible SAN

HPE ProLiant BL460c Gen9 server blades are optimized for HPE MSA, EVA, 3PAR and XP.

HPE Virtual

HPE Virtual Connect is an interconnect option for c-Class BladeSystem that simplifies server connectivity to

Embedded

iLO Advanced for

HPE iLO Advanced for BladeSystem licenses offer smart remote functionality without

Server Management

HPE OneView

Powerful converged management of servers, storage, and network for IT service

HPE Matrix

The HPE Matrix Operating Environment (Matrix OE) for ProLiant and Integrity servers

demands. This advanced infrastructure management software lets you reduce the cost

HPE Insight Cluster

Support

HPE ProLiant BL460c Gen9 Server Blade

HPE ProLiant BL460c Gen9 server blades are compatible with select 3rd party SANs. Please see blade storage page for more details at https://www.hpe.com/us/en/integrated-systems/bladesystem.html

Connect

Management

data and storage networks, and reduces costs. Unique HPE Flex-10 technology makes maximum use of network bandwidths, provide dynamic tuning and enable extreme flexibility to meet individual server and infrastructure requirements by allocating up to 4 network connections per server port. Virtual Connect FlexFabric modules extend those capabilities to allocate one function per port to storage connections (FCoE).

HPE OneView’s software-defined approach to infrastructure management enables central console to administer network connections and workloads for thousands of servers, see

https://www.hpe.com/us/en/integrated-systems/management-software.html

For more information on Virtual Connect Ethernet, Fibre Channel, Converged Network and management options, see https://www.hpe.com/us/en/integrated-systems/virtual-connect.html

BladeSystem

compromise, for all HPE ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and replay, and GUI-based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management functionality. Learn more about HPE iLO Advanced

https://www.hpe.com/us/en/servers/integrated-lights-out-ilo.html

automation and infrastructure simplicity.

Operating Environment

is an integrated command center that helps you instantly adjust to dynamic business

of common data center tasks by up to 40 percent while keeping pace with your changing business. The HPE Matrix OE includes the automated provisioning, optimization, and recovery management capabilities for HPE CloudSystem Matrix, the ideal platform for private cloud and Infrastructure as a Service (IaaS).

For more information, visit:

http://h20392.www2.hpe.com/portal/swdepot/displayProductInfo.do?prod

uctNumber=HPID

Management Utility (CMU)

HPE Insight Cluster Management Utility is a Hyperscale management framework that includes software for the centralized provisioning, management and monitoring of nodes and infrastructure.

Learn more at

https://www.hpe.com/us/en/product-

catalog/detail/pip.3296361.html

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Optional Features

Page 11

High Performance

HPE Cluster

HPE Cluster Platforms are specifically engineered, factory-integrated large-scale

HPE HPC

High Performance Computing (HPC) interconnect technologies are available for this

Storage Software

Whether you need to solve a specific data protection, archiving, or storage command and control challenge, or

HPE Insight Online

HPE Insight Online is part of the HPE Support Center for one stop, secure access to product and HPE support

anytime. https://h20392.www2.hpe.com/portal/swdepot/displayProductInfo.do?productNumber=RSS

Clusters

Platforms

ProLiant clusters optimized for High Performance Computing, with a choice of servers, networks and software. Operating system options include specially priced offerings for Red Hat Enterprise Linux and SUSE Linux Enterprise Server, as well as Microsoft Windows HPC Server. A Cluster Platform Configurator simplifies ordering.

https://www.hpe.com/us/en/solutions/hpc-high-performance-computing.html

Interconnects

server as part of the HPE Cluster Platform portfolio. These high-speed InfiniBand and Gigabit interconnects are fully supported by Hewlett Packard Enterprise when integrated within an HPE cluster.

deliver on strategic consolidation, compliance, or continuity initiatives, look no further than HPE storage software. Our storage software helps you reduce costs, simplify storage infrastructure, protect vital assets and respond faster to business opportunities.

Storage software that gets the job done:

• Data Protection and Recovery Software

Whether you're a large enterprise or a smaller business, HPE data protection and recovery software will cost-effectively protect you against disaster and ensure business continuity.

• Data Archive and Migration Software

The HPE storage software enables you to comply with data retention and retrieval requirements, improve application performance, and reduce costs by efficiently migrating infrequently accessed or less valuable data to lower cost storage.

• Storage Resource Management Software (SRM)

The HPE storage resource management software reduces operational costs and provides the command and control foundation you need to efficiently manage and visualize your physical and virtual environments.

• Data Replication Software

Hewlett Packard Enterprise offers array-based and host-based replication software for use in disaster recovery, testing, application development and reporting.

• Storage Device Management Software

Maximize your investment in HPE storage and networking with software that enables hardwarespecific configuration, performance tuning and connectivity management.

• HPE StoreVirtual VSA

HPE StoreVirtual VSA allows you to create fully featured shared storage on a VMware vSphere or Microsoft Hyper-V virtualized server. This server model starting November 2013, includes a limited license for HPE StoreVirtual VSA software with 1TB of capacity. To download the license key and StoreVirtual VSA software, visit:

https://www.hpe.com/us/en/product-catalog/storage/storagesoftware.hits-12.html

NOTE: You will need your server serial number in order to complete the registration form. Fully

functional, capacity-based licenses are available in 4TB, 10T and 50TB sizes.

see: http://www.hpe.com/storage

information personalized to your IT environment. Insight Online can automatically display devices remotely

NOTE: For more information available Storage Software including QuickSpecs, please

monitored by HPE Remote Support tools. With Insight Online's easy navigation you can efficiently track your IT support contracts and device status from anywhere and at

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Optional Features

Page 12

WMBASE

Get connected to

To get the most from your investment in Hewlett Packard Enterprise servers, get connected to Hewlett

Expansion Blade

Supports one (1) optional D2220sb storage or PCI expansion blade

NOTE:

Factory Express

HPE Factory Express offers configuration, customization, integration and deployment services for Hewlett

HPE Simple

SCE is a guided self-service tool to help sales and non-technical people provide customers with initial

https://h22174.www2.hpe.com/SimplifiedConfig/Welcome

HPE

Support

Portfolio for Servers and Storage

Packard Enterprise using our innovative remote support technology which provides system health monitoring, pre-failure alert notification and more.

Expansion blade support requires the use of either the HPE Dynamic Smart Array B140i or the

HPE Smart Array P246br controller. NOTE: Expansion blade support requires server firmware versions from SPP 2015.04 or later.

Packard Enterprise servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. Hewlett Packard Enterprise products supported through Factory Express include a wide array of servers and storage: HPE Integrity, HPE ProLiant, HPE ProLiant Server Blades, HPE BladeSystem, HPE 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services on your specific server model please contact your sales representative or go to:

https://www.hpe.com/us/en/services/factory-express.html

Configurator

configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "custom" rack configuration or configuration for products not available in SCE, please contact the HPE Customer Business Center or an Authorized Partner for assistance.

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Recommended Support Services for BL460

Service and Support

Protect your business beyond warranty with HPE Support Services

Optimized Support recommendation

Standard Support recommendation

HPE Proactive Care - 24x7 coverage, three year Support Service

HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and stability. Connect to Hewlett Packard Enterprise to help prevent problems and solve issues faster HPE Support Services enable you to choose the right service level, length of coverage and response time as you purchase your new server, giving you full entitlement for the support for need for your IT and business.

Connect your devices

Unlock all of the benefits of your technology investment by connecting your products to HP Enterprise. Achieve up to 77%

reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting, you will receive 24x7monitoring, pre-failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimization. All of these benefits are already available to you with your server storage and networking products, securely connected to Hewlett Packard Enterprise support. 1 – IDC 2 – HP CSC reports 2014 - 2015

HPE Proactive Care Advanced - 24x7 coverage, three year Support Service This services helps achieve a higher return on your product investment with personalized support from a

local assigned Account Support Manager who will share best practice advice and personalized recommendations designed to help improve availability and performance to increase stability and reduce unplanned downtime. Leverage your system’s ability to connect to Hewlett Packard Enterprise for prefailure alerts, automatic call logging and parts dispatch. For business critical incidents, this service offers critical event management to reduce mean time to resolution. This recommendation provides 24x7 coverage with four-hour response for hardware and collaborative support that offers two-hour callback for supported software issues. Collaborative software management is included with independent software vendors unless you have your software support from Hewlett Packard Enterprise where we own all cases from start through to resolution.

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA5-3259ENW&cc=us&lc=en

HPE Proactive Care gives customers an enhanced call experience plus helps preventing problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice when your products are connected to Hewlett Packard Enterprise. This Service combines three years’ proactive reporting and advice with our 24x7 coverage, four hour hardware response time when there is a problem. In addition, this service includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc) running on your HPE servers.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

Parts and Materials

Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product quick-specs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by Hewlett Packard Enterprise due to malfunction.

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Recommended Support Services for BL460

Page 14

Related Services

HPE Server Hardware Installation

For more information: http://www.hpe.com/services

Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.

https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf

Data Center Care Services

HPE Datacenter Care helps improve IT stability and security, increase the value of IT, and enable agility and innovation. It is a structured framework of repeatable, tested, and globally available services “building blocks.” You can deploy, operate, and evolve your datacenter wherever you are on your IT journey. With HPE Datacenter Care, you benefit from a personalized relationship with Hewlett Packard Enterprise via a single point of accountability for HPE and others’ products. For more information, visit https://www.hpe.com/us/en/services/datacenter-hybrid-services.html

Data Privacy Services

Protect your data through better media management. HPE Data privacy services help manage and protect sensitive data to reduce the risk of unauthorized access to private information and help meet compliance requirements. Our retention services allow you to keep drives and other devices upon failure with Defective Media Retention and Comprehensive Defective Material Retention, our removal services provide convenient data sanitization and our recovery services allow you to safely retire IT assets and capture any remaining value from the hardware.

https://www.hpe.com/us/en/services/platform-consulting-services.html

HPE Education Services

Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes. Book on a class today and learn how to get the most from your technology investment.

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Models

NOTE: For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information Factory Integrated Models" section.

NOTE:

section of this QuickSpecs.

NOTE:

options purchased will be shipped separately.

NOTE:

QuickSpecs.

NOTE: NOTE:

availability.

E5-2600 v4 series Processors

HPE ProLiant

Processor(s)

(1) Intel® Xeon® E5-2620 v4 (2.1GHz/8-core/20MB/8GT-s QPI/85W, DDR4-2133)

Cache Memory

20MB (1x20MB) Level 3 cache

Memory

16GB (2x 8GB) 2400MT/s (DDR4-2400) Registered DIMMs at 1.2V)

NOTE: Total of 16 DIMM slots. Only eight (8) usable with single processor.

Network Controller

HPE FlexFabric 10Gb 2-port 536FLB FlexibleLOM

Storage Controller

HPE Smart HBA H244br Controller with RAID 0,1

Hard Drive

None ship standard

NOTE: NVMe SSDs not available on this model.

Internal Storage

SAS: 2.0TB; SATA: 2.0TB; SAS SSD: 3.84TB; SATA SSD: 3.84TB

Optical Drive Bay

None

Expansion Slots

2 standard - Slot 1 supports Type A mezzanine Cards. Slot 2 supports Type A and Type B mezzanine cards.

Management

HPE iLO Management (standard) Optional: HPE OneView or HPE Insight Control

Form Factor

Up to eight (8) half-height blades supported in the HPE BladeSystem c3000 Enclosure

Up to sixteen (16) half-height blades supported in HPE BladeSystem c7000 Enclosure

Warranty

Server warranty includes 3-year Parts, 3-year Labor, 3-year on-site support.

HPE ProLiant

Processor(s)

(1) Intel® Xeon® E5-2640 v4 (2.4GHz/10-core/25MB/8GT-s QPI/90W, DDR4-

2133)

Cache Memory

25MB (1x25MB) Level 3 cache

Memory

32GB (2x 16GB) 2400MT/s (DDR4-2400) Registered DIMMs at 1.2V)

NOTE: Total of 16 DIMM slots.

Network Controller

HPE FlexFabric 10Gb 2-port 536FLB FlexibleLOM

Storage Controller

HPE Smart Array P244br Controller with RAID 0,1

Hard Drive

None ship standard

NOTE: NVMe SSDs not available on this model.

Internal Storage

SAS: 2.0TB; SATA: 2.0TB; SAS SSD: 3.84TB; SATA SSD: 3.84TB

Optical Drive Bay

None

Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options

Hewlett Packard Enterprise does not allow factory integration of options into pre-configured models. Any additional

If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this

All Pre-configured Models come populated with some hard drive blanks installed. Not all models are available in all regions. Check with your local country Hewlett Packard Enterprise offices for

BL460c Gen9 E52620v4 1P 16GB-R Server

813193-B21

Supports up to two (2) HPE hot-plug SFF SAS/SATA/SDD drives

BL460c Gen9 E52640v4 1P 32GB-R Server

813194-B21

Supports up to two (2) HPE hot-plug SFF SAS/SATA/SDD drives

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Models

Page 16

Expansion Slots

2 standard - Slot 1 supports Type A mezzanine Cards. Slot 2 supports Type A and Type B mezzanine cards.

Management

HPE iLO Management (standard) Optional: HPE OneView or HPE Insight Control

Form Factor

Up to eight (8) half-height blades supported in the HPE BladeSystem c3000 Enclosure

Up to sixteen (16) half-height blades supported in HPE BladeSystem c7000 Enclosure

Warranty

Server warranty includes 3-year Parts, 3-year Labor, 3-year on-site support.

HPE ProLiant

Processor(s)

(2) Intel® Xeon® E5-2650 v4 (2.2GHz/12-core/30MB/9.6GT-s QPI/90W, DDR4-

2400)

Cache Memory

30MB (1x30MB) Level 3 cache

Memory

64GB (4x 16GB) 2400MT/s (DDR4-2400) Registered DIMMs at 1.2V)

NOTE: Total of 16 DIMM slots.

Network Controller

HPE FlexFabric 10Gb 2-port 536FLB FlexibleLOM

Storage Controller

HPE Smart Array P244br Controller with RAID 0,1

Hard Drive

None ship standard

NOTE: NVMe SSDs not available on this model.

Internal Storage

SAS: 2.0TB; SATA: 2.0TB; SAS SSD: 3.84TB; SATA SSD: 3.84TB

Optical Drive Bay

None

Expansion Slots

2 standard - Slot 1 supports Type A mezzanine Cards. Slot 2 supports Type A and Type B mezzanine cards.

Management

HPE iLO Management (standard) Optional: HPE OneView or HPE Insight Control

Form Factor

Up to eight (8) half-height blades supported in the HPE BladeSystem c3000 Enclosure

Up to sixteen (16) half-height blades supported in HPE BladeSystem c7000 Enclosure

Warranty

Server warranty includes 3-year Parts, 3-year Labor, 3-year on-site support.

HPE ProLiant

Processor(s)

(2) Intel® Xeon® E5-2660 v4 (2.0GHz/14-core/35MB/9.6GT-s QPI/105W, DDR4-

2400)

Cache Memory

35MB (1x35MB) Level 3 cache

Memory

128GB (4x 32GB) 2400MT/s (DDR4-2400) Registered DIMMs at 1.2V)

NOTE: Total of 16 DIMM slots.

Network Controller

HPE FlexFabric 20Gb 2-port 650FLB FlexibleLOM

Storage Controller

HPE Smart Array P244br Controller with RAID 0,1

Hard Drive

None ship standard

NOTE: NVMe SSDs not available on this model.

Internal Storage

SAS: 2.0TB; SATA: 2.0TB; SAS SSD: 3.84TB; SATA SSD: 3.84TB

Optical Drive Bay

None

Expansion Slots

2 standard - Slot 1 supports Type A mezzanine Cards. Slot 2 supports Type A and Type B mezzanine cards.

Management

HPE iLO Management (standard)

BL460c Gen9 E52650v4 2P 64GB-R Server

813195-B21

BL460c Gen9 E52660v4 2P 128GBServer

813196-B21

Supports up to two (2) HPE hot-plug SFF SAS/SATA/SDD drives

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Models

Page 17

Optional: HPE OneView or HPE Insight Control

Form Factor

Up to eight (8) half-height blades supported in the HPE BladeSystem c3000 Enclosure

Up to sixteen (16) half-height blades supported in HPE BladeSystem c7000 Enclosure

Warranty

Server warranty includes 3-year Parts, 3-year Labor, 3-year on-site support.

HPE ProLiant

Processor(s)

(2) Intel® Xeon® E5-2680 v4 (2.4GHz/14-core/35MB/9.6GT-s QPI/120W, DDR4-

2400)

Cache Memory

35MB (1x35MB) Level 3 cache

Memory

256GB (8x 32GB) 2400MT/s (DDR4-2400) Registered DIMMs at 1.2V)

NOTE: Total of 16 DIMM slots.

Network Controller

HPE FlexFabric 20Gb 2-port 650FLB FlexibleLOM

Storage Controller

HPE Smart Array P244br Controller with RAID 0,1

Hard Drive

None ship standard

NOTE: NVMe SSDs not available on this model.

Internal Storage

SAS: 2.0TB; SATA: 2.0TB; SAS SSD: 3.84TB; SATA SSD: 3.84TB

Optical Drive Bay

None

Expansion Slots

2 standard - Slot 1 supports Type A mezzanine Cards. Slot 2 supports Type A and Type B mezzanine cards.

Management

HPE iLO Management (standard) Optional: HPE OneView or HPE Insight Control

Form Factor

Up to eight (8) half-height blades supported in the HPE BladeSystem c3000 Enclosure

Up to sixteen (16) half-height blades supported in HPE BladeSystem c7000 Enclosure

Warranty

Server warranty includes 3-year Parts, 3-year Labor, 3-year on-site support.

BL460c Gen9 E52680v4 2P 256GBServer

813197-B21

Supports up to two (2) HPE hot-plug SFF SAS/SATA/SDD drives

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Configuration Information

NOTE: This section lists some of the steps required to configure a Factory Integrated Model (configure-to-order or CTO server).

drives ordered with the server.

HPE Recommended Options have the best performance, value and availability.

Step 1: Base Server Blade Configuration (Select a configurable Blade)

Models

HPE ProLiant BL460c Gen9 E5-v4 10Gb/20Gb FlexibleLOM Configure-to-order Blade Server

813198-B21

Configurable Models ship with:

One (1) FlexibleLOM connector providing a choice for one (1) of the supported 10Gb/20Gb

Step 2: Choose Required Options (one of the following from each list unless otherwise noted)

HPE Processors

NOTE: All configure-to-order processor kits (i.e. xxxxxx-L21) contain one (1) processor.

B21 in Step 4.

E5-2600 v4 series Processors - Recommended

HPE BL460c Gen9 Intel Xeon E5-2690v4 (2.6GHz/14-core/35MB/135W) FIO Processor Kit (Recommended)

819852-L21

HPE BL460c Gen9 Intel Xeon E5-2683v4 (2.1GHz/16-core/40MB/120W) FIO Processor Kit (Recommended)

819851-L21

HPE BL460c Gen9 Intel Xeon E5-2680v4 (2.4GHz/14-core/35MB/120W) FIO Processor Kit (Recommended)

819842-L21

HPE BL460c Gen9 Intel Xeon E5-2650v4 (2.2GHz/12-core/30MB/105W) FIO Processor Kit (Recommended)

819840-L21

HPE BL460c Gen9 Intel Xeon E5-2640v4 (2.4GHz/10-core/25MB/90W) FIO Processor Kit (Recommended)

819839-L21

- Factory Integrated Models

To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an Hewlett Packard Enterprise approved configurator. Contact your local sales representative for information on CTO product offerings and requirements.

NOTE: Configure-to-order server blades must start with a CTO Blade Server. NOTE: FIO indicates that this option is only available as a factory installable option. NOTE: All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard

Recommended Options have been selected by Hewlett Packard Enterprise experts to provide the right technology for a range of workloads and market segments. Fully integrated into the ProLiant management and security experience, Recommended Options provide the best fit with timely availability. View the list for your region.

Extended Options provide an extended catalog of products tailored for customers in specific markets or with specific workloads, requiring the utmost in performance or value. Fully integrated into the ProLiant management and security experience, Extended Options represent great value and performance but typically have a longer lead-time.

FlexibleLOMs (see Step 2) Two (2) HPE small form factor hot-plug SAS/SATA/ HDD or SSD hard drive bays Two (2) x16 PCIe I/O expansion slots (one Type A, one Type A/B) One (1) integrated USB connector and one (1) MicroSDHC connector One (1) TPM connector HPE iLO Management (standard)

NOTE: If two processors are desired, select one xxxxxx-L21 here in Step 2 and one xxxxxx-

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Configuration Information

Page 19

HPE BL460c Gen9 Intel Xeon E5-2630v4 (2.2GHz/10-core/25MB/85W) FIO Processor Kit (Recommended)

819845-L21

HPE BL460c Gen9 Intel Xeon E5-2620v4 (2.1GHz/8-core/20MB/85W) FIO Processor Kit (Recommended)

819838-L21

HPE BL460c Gen9 Intel Xeon E5-2698v4 (2.2GHz/20-core/50MB/135W) FIO Processor Kit (Recommended)

819855-L21

HPE BL460c Gen9 Intel Xeon E5-2697v4 (2.3GHz/18-core/45MB/145W) FIO Processor Kit (Recommended)

819854-L21

HPE BL460c Gen9 Intel Xeon E5-2697Av4 (2.6GHz/16-core/40MB/145W) FIO Processor Kit (Recommended)

819857-L21

(Recommended)

HPE BL460c Gen9 Intel Xeon E5-2667v4 (3.2GHz/8-core/25MB/135W) FIO Processor Kit (Recommended)

819850-L21

E5-2600 v4 series Processors - Extended

HPE BL460c Gen9 Intel Xeon E5-2650Lv4 (1.7GHz/14-core/35MB/65W) FIO Processor Kit (Extended)

819849-L21

HPE BL460c Gen9 Intel Xeon E5-2623v4 (2.6GHz/4-core/10MB/85W) FIO Processor Kit (Extended)

819844-L21

HPE BL460c Gen9 Intel Xeon E5-2699v4 (2.2GHz/22-core/55MB/145W) FIO Processor Kit (Extended)

819856-L21

HPE BL460c Gen9 Intel Xeon E5-2643v4 (3.4GHz/6-core/20MB/135W) FIO Processor Kit (Extended)

819848-L21

HPE BL460c Gen9 Intel Xeon E5-2637v4 (3.5GHz/4-core/15MB/135W) FIO Processor Kit (Extended)

819847-L21

NOTE: All processors within the server must be identical.

orted memory speeds for each processor listed above, please

Threading and Intel® Turbo Boost Technologies

The BL460c Gen9 includes two I/O mezzanine expansion slots. A processor must be

installed in processor slot 1 for access to the first mezzanine expansion slot (expansion slot

HPE Memory

NOTE: HPE memory from previous generation servers (DDR3) is not compatible with this

https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111535

- Factory Integrated Models

HPE BL460c Gen9 Intel Xeon E5-2695v4 (2.1GHz/18-core/45MB/120W) FIO Processor Kit

NOTE: DIMM slots 4 and 5 are not accessible when the E5-2699 v4, E5-2697 v4, E52697A v4, E5-2667 v4, E5-2643 v4, E5-2637 v4, E5-2699 v3, the E5-2697 v3, the E52643 v3, the E5-2637 v3, or the E5-2667 v3 is used. In a 2 processor configuration, there are twelve (12) total available DIMM slots. NOTE: For the maximum supp reference the 'Memory Speed by Processor Model' table in the Memory section of the QuickSpecs. NOTE: All processors support Intel® Hyperexcept the E5-2609 v4, E5-2603 v4, E5-2603 v3 and E5-2609 v3. NOTE: DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the quantity and type of DIMMs installed.

NOTE: Supports 1 or 2 processors. Mixing different processor models is not supported. NOTE: For the Intel® C610 Chipset E5-2600 v3 and v4 Series, the letter preceding the

model number indicates the Product Line (E3, E5, E7); 2600x, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 = Processor SKU, and x = L for low power SKUs. NOTE:

819853-L21

1). A processor must be installed in processor slot 2 for access to the second mezzanine expansion slot (expansion slot 2). NOTE: The letter "L" following the model number indicates denotes lower wattage.

server. HPE SmartMemory is required to realize the memory performance improvements and enhanced functionality listed in this document for Gen9. For additional information, please see the HPE SmartMemory QuickSpecs at:

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Configuration Information

Page 20

NOTE: LRDIMM and RDIMM are distinct memory technologies and cannot be mixed within

HPE SmartMemory

Registered DIMMs (RDIMMs) - E5-2600 v4 series Processors – Recommended

HPE 16GB (1x16GB) Single Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Recommended)

805349-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2400 CAS-17-17-17 Registered Smart Memory Kit (Recommended)

P00423-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Recommended)

805351-B21

Registered DIMMs (RDIMMs) - E5-2600 v4 series Processors – Extended

HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Extended)

805347-B21

HPE 16GB (1x16GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Extended)

836220-B21

Load Reduced DIMMs (LRDIMMs) - E5-2600 v4 series Processors - Recommended

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit (Recommended)

805358-B21

Load Reduced DIMMs (LRDIMMs) - E5-2600 v4 series Processors - Extended

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit (Extended)

805353-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2400 CAS-20-18-18 Load Reduced Memory Kit (Extended)

809208-B21

NOTE: For more information on ProLiant Energy Efficient Features, see:

HPE Networking

FlexibleLOM Adapters

NOTE: The server requires one (1) FlexibleLOM that is installed in the FlexibleLOM

1 and the other to bay 2.

20Gb FlexibleLOM Adapters - Recommended

HPE FlexFabric 20Gb 2-port 630FLB Adapter (Recommended)

700065-B21

HPE FlexFabric 20Gb 2-port 650FLB Adapter (Recommended)

700763-B21

10Gb FlexibleLOM Adapters - Recommended

HPE FlexFabric 10Gb 2-port 536FLB Adapter (Recommended)

766490-B21

HPE Ethernet 10Gb 2-port 560FLB Adapter (Recommended)

655639-B21

NOTE: Please see the QuickSpecs for Technical Specifications and additional information.

Step 3: Choose Additional Factory Integration Options

HPE OneView with iLO Advanced - Server hardware required on same purchase order

- Factory Integrated Models

a server.

NOTE: 128GB DIMMs cannot be mixed with other DIMM capacities within the server NOTE: Depending on the memory configuration and processor model, the memory speed

may run at 2400MT/s, 2133MT/s, 1866MT/s, or 1600MT/s. Please see the Online Memory Configuration Tool at:

https://memoryconfigurator.hpe.com/DDR4memoryconfig/Home/Legal

https://www.hpe.com/us/en/about/environment/eco-labels.html

connectors. All FlexibleLOMs are dual port: One port is routed to interconnect module bay

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Configuration Information

Page 21

Converged

HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU

E5Y35AAE

HPE OneView for Blade Server including 3yr 24x7 Support FIO Bundle Physical 1-server LTU

F6Q89A

HPE Storage

Storage Controllers - Recommended

HPE Smart Array P244br/1GB FBWC 12Gb 2-ports Int SAS Controller (Recommended)

749680-B21

HPE Smart Array P246br/1GB FBWC 12Gb 4-ports Int SAS Controller (Recommended)

726793-B21

Storage Controllers - Extended

HPE H244br 12Gb 2-ports Int Smart Host Bus Adapter (Extended)

726809-B21

HPE FIO Enable Smart Array B140i Setting

784308-B21

HPE Smart Array P741m/2GB FBWC 12Gb 4-ports Ext Mezzanine SAS Controller

726782-B21

NOTE: The HPE Gen9 Broadwell NVMe FIO Setting (825555-B21) is required to support

s are chosen, a SATA cable will be provided to

support SATA devices for the two internal drives. If RAID is required when using the B140i,

expansion blade or D2220sb storage blade with the BL460c Gen9.

Step 4: Choose Additional Options for Factory Integration

NOTE: For additional options, please refer to the "Core Options" and "Additional Options" section below. For additional options,

NOTE: For optimal cooling and system performance the BL460c Gen9 Server Blade requires the c7000 enclosure to be

configured with 10 fans and the c3000 enclosure to be configured with 6 fans.

Infrastructure Management Software

Controllers

- Factory Integrated Models

SFF NVMe SSDs within the system. This option is not compatible with the HPE Smart Array P244br, HPE Smart Array P246br, or HPE Smart HBA H244br. Hewlett Packard Enterprise recommends the use of a dual M.2 solid state drive kit for boot when using this option. NOTE: The HPE Smart Array B140i Controller (chipset SATA) comes standard with the HPE BL460c Gen9 10Gb/20Gb FLB CTO Blade (727021-B21). If neither the HPE Smart Array P244br nor the HPE H244br controller

please choose ‘HPE FIO B140i RAID Enable Kit - BIOS Setting’ (784308-B21). NOTE: The HPE Smart Array P246br controller is only required when using a PCI

including server blade enclosures interconnect, mezzanine options and power subsystem options; please see the Core Options and Additional sections below; or the following:

• HPE BladeSystem c3000 Enclosure QuickSpecs:

https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128340.pdf

NOTE: The c3000 HPE c-Class enclosures have full backwards and forwards compatibility, existing server blades are

supported in the new enclosures and any future server blades will be supported in the existing enclosures.

• HPE BladeSystem c7000 Enclosure QuickSpecs:

https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128339.pdf

NOTE: The c7000 HPE c-Class enclosures have full backwards and forwards compatibility, existing server blades are

supported in the new enclosures and any future server blades will be supported in the existing enclosures.

• HPE BladeSystem c-Class Interconnect and Mezzanine Components:

https://www.hpe.com/us/en/integrated-systems/bladesystem.html#portfolio https://www.hpe.com/us/en/integrated-systems/bladesystem.html#portfolio

and

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Core Options

HPE Recommended Options have the best performance, value and availability.

HPE Networking

NOTE: A 10 Gigabit Ethernet adapter supports linking at 1Gbps or 10Gbps when

20 Gigabit Ethernet Mezzanine Cards - Recommended

HPE FlexFabric 20Gb 2-port 630M Adapter (Recommended)

700076-B21

NOTE: Please see QuickSpecs for technical specifications and additional information at https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04312720

HPE FlexFabric 20Gb 2-port 650M Adapter (Recommended)

700767-B21

NOTE:

10 Gigabit Ethernet Mezzanine Cards - Recommended

HPE FlexFabric 10Gb 2-port 534M Adapter (Recommended)

700748-B21

NOTE:

at: https://www.hpe.com/us/en/product-catalog/servers/server-adapters.html

HPE Ethernet 10Gb 2-port 560M Adapter (Recommended)

665246-B21

NOTE: Please see QuickSpecs for technical specifications and additional information

1 Gigabit Ethernet Mezzanine Cards - Recommended

HPE Ethernet 1Gb 4-port 366M Adapter (Recommended)

615729-B21

NOTE: Please see QuickSpecs for technical specifications and additional information

FlexibleLOM Adapters

to change these original FlexibleLOMs.

20Gb FlexibleLOM Adapters - Recommended

HPE FlexFabric 20Gb 2-port 630FLB Adapter (Recommended)

700065-B21

NOTE: Please see QuickSpecs for technical specifications and additional information at https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04312719

connected to an interconnect module with 10Gb Ethernet downlinks. NOTE: A 10 Gigabit Ethernet adapter supports linking at only 1Gbps when connected to an interconnect module with 1Gb Ethernet downlinks. NOTE: The 10 Gigabit Ethernet adapters on each server blade connect to a 10Gb interconnect in bays 3-6 (HPE BladeSystem c7000 Enclosure) or bays 2-4 (HPE BladeSystem c3000 Enclosure).

Please see QuickSpecs for technical specifications and additional information

https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04347342

Please see QuickSpecs for technical specifications and additional information

at: https://www.hpe.com/h20195/v2/GetPDF.aspx/c04111406.pdf

at: https://www.hpe.com/h20195/v2/getpdf.aspx/c04111456.pdf?ver=10

NOTE: The server supports one (1) FlexibleLOM that is installed in the FlexibleLOM connectors and is already included in the pre-configured models. However, it must be added in Step 2 for Configure-to-Order Models. The FlexibleLOM options below are used

Page

QuickSpecs

Core

Page 23

HPE FlexFabric 20Gb 2-port 650FLB Adapter (Recommended)

700763-B21

NOTE: Please see QuickSpecs for technical specifications and additional information

10Gb FlexibleLOM Adapters - Recommended

HPE FlexFabric 10Gb 2-port 536FLB Adapter (Recommended)

766490-B21

NOTE: Please see QuickSpecs for technical specifications and additional information at https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04347246

HPE Ethernet 10Gb 2-port 560FLB Adapter (Recommended)

655639-B21

NOTE: Please see QuickSpecs for technical specifications and additional information

HPE Infiniband Mezzanine Adapters - Extended

NOTE: When an InfiniBand adapter is installed in mezzanine slot 1, only one port is active

(regardless of operating mode). When installed in mezzanine slot 2, both ports are active.

NOTE: InfiniBand QDR and FDR speeds are only supported on the HPE BladeSystem

https://www.hpe.com/h20195/v2/getpdf.aspx/c04126044.pdf?ver=26

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+M Adapter (Extended)

764283-B21

NOTE: The FDR InfiniBand adapter must be installed in mezzanine slot 1 for FDR mode and may be installed in either mezzanine slot if operated in any other mode.

HPE InfiniBand FDR 2-port 545M Adapter (Extended)

702213-B21

HPE Fibre

HPE Fibre Channel Adapters - Recommended

HPE LPe1605 16Gb Fibre Channel HBA for BladeSystem c-Class (Recommended)

718203-B21

NOTE: Please see QuickSpecs for technical specifications and additional information at https://www.hpe.com/h20195/v2/getpdf.aspx/c04315132.pdf?ver=2

HPE QMH2672 16Gb Fibre Channel Host Bus Adapter (Recommended)

710608-B21

NOTE: Please see QuickSpecs for technical specifications and additional information

https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04126962

HPE Fibre Channel Adapters - Extended

NOTE: Please see QuickSpecs for technical specifications and additional information

at https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04163733

HPE QMH2572 8Gb Fibre Channel Host Bus Adapter for BladeSystem c-Class (Extended)

651281-B21

NOTE: Please see QuickSpecs for technical specifications and additional information at

HPE Processors

E5-2600 v4 series Processors - Recommended

HPE BL460c Gen9 Intel Xeon E5-2690v4 (2.6GHz/14-core/35MB/135W) Processor Kit (Recommended)

819852-B21

HPE BL460c Gen9 Intel Xeon E5-2683v4 (2.1GHz/16-core/40MB/120W) Processor Kit (Recommended)

819851-B21

HPE BL460c Gen9 Intel Xeon E5-2680v4 (2.4GHz/14-core/35MB/120W) Processor Kit (Recommended)

819842-B21

HPE ProLiant BL460c Gen9 Server Blade

Options

at https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04347341

at https://www.hpe.com/h20195/v2/GetPDF.aspx/c04111516.pdf

c7000 Enclosure. For additional information, please see the HPE BladeSystem c7000 Enclosure and InfiniBand QuickSpecs at:

https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128339.pdf

Channel

HPE LPe1205A 8Gb Fibre Channel Host Bus Adapter for BladeSystem c-Class (Extended) 659818-B21

https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04126040

QuickSpecs

Core

Page 24

HPE BL460c Gen9 Intel Xeon E5-2650v4 (2.2GHz/12-core/30MB/105W) Processor Kit (Recommended)

819840-B21

HPE BL460c Gen9 Intel Xeon E5-2640v4 (2.4GHz/10-core/25MB/90W) Processor Kit (Recommended)

819839-B21

HPE BL460c Gen9 Intel Xeon E5-2630v4 (2.2GHz/10-core/25MB/85W) Processor Kit (Recommended)

819845-B21

HPE BL460c Gen9 Intel Xeon E5-2620v4 (2.1GHz/8-core/20MB/85W) Processor Kit (Recommended)

819838-B21

HPE BL460c Gen9 Intel Xeon E5-2698v4 (2.2GHz/20-core/50MB/135W) Processor Kit (Recommended)

819855-B21

(Recommended)

HPE BL460c Gen9 Intel Xeon E5-2697Av4 (2.6GHz/16-core/40MB/145W) Processor Kit (Recommended)

819857-B21

HPE BL460c Gen9 Intel Xeon E5-2695v4 (2.1GHz/18-core/45MB/120W) Processor Kit (Recommended)

819853-B21

(Recommended)

E5-2600 v4 series Processors - Extended

HPE BL460c Gen9 Intel Xeon E5-2660v4 (2.0GHz/14-core/35MB/105W) Processor Kit (Extended)

819841-B21

HPE BL460c Gen9 Intel Xeon E5-2650Lv4 (1.7GHz/14-core/35MB/65W) Processor Kit (Extended)

819849-B21

HPE BL460c Gen9 Intel Xeon E5-2623v4 (2.6GHz/4-core/10MB/85W) Processor Kit (Extended)

819844-B21

HPE BL460c Gen9 Intel Xeon E5-2699v4 (2.2GHz/22-core/55MB/145W) Processor Kit (Extended)

819856-B21

HPE BL460c Gen9 Intel Xeon E5-2643v4 (3.4GHz/6-core/20MB/135W) Processor Kit (Extended)

819848-B21

HPE BL460c Gen9 Intel Xeon E5-2637v4 (3.5GHz/4-core/15MB/135W) Processor Kit (Extended)

819847-B21

NOTE: All processors within the server must be identical.

be installed in processor slot 1 for access to the first mezzanine expansion slot (expansion

mezzanine expansion slot (expansion slot 2).

HPE ProLiant BL460c Gen9 Server Blade

Options

HPE BL460c Gen9 Intel Xeon E5-2697v4 (2.3GHz/18-core/45MB/145W) Processor Kit

HPE BL460c Gen9 Intel Xeon E5-2667v4 (3.2GHz/8-core/25MB/135W) Processor Kit

819854-B21

819850-B21

NOTE: DIMM slots 4 and 5 are not accessible when the E5-2699 v4, E5-2697 v4, E52697A v4, E5-2667 v4, E5-2643 v4, E5-2637 v4, E5-2699 v3, the E5-2697 v3, the E52643 v3, the E5-2637 v3, or the E5-2667 v3 is used. In a 2 processor configuration, there are twelve (12) total available DIMM slots. NOTE: For the maximum supported memory speeds for each processor listed above, please reference the 'Memory Speed by Processor Model' table in the Memory section of the QuickSpecs. NOTE: All processors support Intel® Hyper-Threading and Intel® Turbo Boost Technologies except the E5-2609 v4, E5-2603 v4, E5-2603 v3 and E5-2609 v3. NOTE: DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the quantity and type of DIMMs installed.

NOTE: Supports 1 or 2 processors. Mixing different processor models is not supported. NOTE: For the Intel® C610 Chipset E5-2600 v3 and v4 Series, the letter preceding the

model number indicates the Product Line (E3, E5, E7); 2600x, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 = Processor SKU, and x = L for low power SKUs. NOTE: The BL460c Gen9 includes two I/O mezzanine expansion slots. A processor must

slot 1). A processor must be installed in processor slot 2 for access to the second

QuickSpecs

Core

Page 25

NOTE: The letter "L" following the model number indicates denotes lower wattage.

HPE Memory

NOTE: HPE memory from previous generation servers (DDR3) is not compatible with this

within

HPE SmartMemory

Registered DIMMs (RDIMMs) - E5-2600 v4 series Processors - Recommended

HPE 16GB (1x16GB) Single Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Recommended)

805349-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2400 CAS-17-17-17 Registered Smart Memory Kit (Recommended)

P00423-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Recommended)

805351-B21

Registered DIMMs (RDIMMs) - E5-2600 v4 series Processors - Extended

HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Extended)

805347-B21

(Extended)

Load Reduced DIMMs (LRDIMMs) - E5-2600 v4 series Processors - Recommended

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit (Recommended)

805358-B21

Load Reduced DIMMs (LRDIMMs) - E5-2600 v4 series Processors - Extended

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit (Extended)

805353-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2400 CAS-20-18-18 Load Reduced Memory

809208-B21

HPE Drives

NOTE:

(SFF) SmartDrive carrier for enhanced management and reduced maintenance errors. HPE

NOTE: The hard drive options are not required when configuring a drive-less model.

HPE NVMe PCIe Read Intensive SFF (2.5-inch) Solid State Drives - Recommended

HPE 2TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Recommended)

877986-B21

HPE NVMe PCIe Read Intensive SFF (2.5-inch) Solid State Drives - Extended

HPE ProLiant BL460c Gen9 Server Blade

Options

https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111535

NOTE: LRDIMM and RDIMM are distinct memory technologies and cannot be mixed

a server. NOTE: Depending on the memory configuration and processor model, the memory speed may run at 2400MT/s, 2133MT/s, 1866MT/s, or 1600MT/s. Please see table at end of document or the Online Memory Configuration Tool at: https://h22195.www2.hpe.com/DDR4memoryconfig/Home/LEGAL

HPE 16GB (1x16GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

Kit (Extended)

The ProLiant BL460c Gen9 server includes the HPE hot-plug small form factor

drives from generation G7 servers and before are not compatible with the BL460c Gen9 drive bays. NOTE: The mixing of standard SAS drives with SAS SSD is supported within the server, but limits the RAID configuration to two separate RAID 0 volumes. Mixing of other drives types is not supported. NOTE: HPE hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

836220-B21

QuickSpecs

Core

Page 26

HPE 480GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Extended)

875587-B21

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Extended)

875589-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Extended)

875591-B21

HPE 1TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Extended)

877984-B21

HPE 4TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware

877988-B21

HPE NVMe PCIe Mixed Use SFF (2.5-inch) Solid State Drives - Recommended

HPE 400GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Recommended)

875593-B21

HPE 800GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Recommended)

875595-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Recommended)

877994-B21

HPE NVMe PCIe Mixed Use SFF (2.5-inch) Solid State Drives - Extended

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD (Extended)

875597-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware

877998-B21

HPE NVMe PCIe Write Intensive SFF (2.5-inch) SCN Drives - Recommended

HPE 375GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed

878014-B21

SATA Hot Plug SmartDrive SFF (2.5-inch) SSD Drives - Recommended

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

P04556-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

P04560-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

P04564-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

P04566-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

P00896-B21

SATA Hot Plug SmartDrive SFF (2.5-inch) SSD Drives - Extended

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

P04570-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877740-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877746-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877752-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877758-B21

HPE ProLiant BL460c Gen9 Server Blade

Options

SSD (Extended)

Firmware SSD (Recommended)

QuickSpecs

Core

Page 27

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877764-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877776-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877782-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

877788-B21

HPE 240GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

880295-B21

SAS Hot Plug with SmartDrive SFF (2.5-inch) Enterprise Drives – Recommended

HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD (Recommended)

870753-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD (Recommended)

870757-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD (Recommended)

870759-B21

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD (Recommended)

765464-B21

(Recommended)

HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD (Recommended)

765466-B21

HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD (Recommended)

881457-B21

SAS Hot Plug with SmartDrive SFF (2.5-inch) Enterprise Drives – Extended

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e Digitally Signed

870765-B21

SATA (SFF 2.5-inch) Hard Drives – Recommended

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD (Recommended)

655710-B21

HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware

765455-B21

12G SAS Write Intensive SFF (2.5-inch) SC DS SSD – Recommended

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

873351-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

873355-B21

12G SAS Write Intensive SFF (2.5-inch) SC DS SSD – Extended

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873357-B21

12G SAS Read Intensive SFF (2.5-inch) SC SSD – Recommended

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875326-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875313-B21

HPE ProLiant BL460c Gen9 Server Blade

Options

(Extended)

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

Firmware HDD (Extended)

HDD (Recommended)

832514-B21

(Extended)

QuickSpecs

Core

Page 28

HPE 480GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875311-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

872390-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

872392-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

872394-B21

12G SAS Read Intensive SFF (2.5-inch) SC SSD – Extended

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

875330-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Extended)

870144-B21

HPE 15.3TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

870148-B21

12G SAS Mixed Use SFF (2.5-inch) SC SSD - Recommended

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

873359-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

873363-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

873365-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

873367-B21

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

872374-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

872376-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

872382-B21

12G SAS Mixed Use SFF (2.5-inch) SC SSD - Extended

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872386-B21

6G SAS Mixed Use SFF (2.5-inch) SC Solid State Drive – Recommended

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875478-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875474-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875470-B21

HPE 240GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875483-B21

12G SAS SFF (2.5-inch) SC 3yr Wty H2 Drive – Recommended

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD (Recommended)

872481-B21

HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD (Recommended)

872479-B21

HPE ProLiant BL460c Gen9 Server Blade

Options

(Extended)

QuickSpecs

Core

Page 29

HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD (Recommended)

872477-B21

HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872475-B21

12G SATA 2.5in RI-3 SFF SC SSD – Recommended

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

P00896-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)d

875513-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875511-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875509-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD (Recommended)

875503-B21

NOTE: The mixing of standard SAS drives with SAS SSD is supported within the server,

types is not supported

HPE ProLiant BL460c Gen9 Server Blade

Options

(Recommended)

but limits the RAID configuration to two separate RAID 0 volumes. Mixing of other drives

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Additional

HPE Recommended Options have the best performance, value and availability.

HPE iLO Advanced

HPE Integrated Lights-Out (iLO) Advanced for ProLiant BladeSystem Remote Management

HPE iLO Advanced for BladeSystem Electronic License with 3yr Support on iLO Licensed Features

E6U63ABE

HPE iLO Advanced for BladeSystem 1-server License with 3yr Support on iLO Licensed Features

BD502A

HPE iLO Advanced for BladeSystem Electronic License with 1yr Support on iLO Licensed Features

E6U60ABE

HPE iLO Advanced for BladeSystem 1-server License with 1yr Support on iLO Licensed Features

512488-B21

NOTE: Customer will receive a license entitlement certificate, which must be redeemed

HPE OneView

HPE OneView with iLO Advanced

HPE OneView including 3yr 24x7 Support Physical 1-server LTU

E5Y34A

HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU

E5Y35AAE

HPE OneView Physical Media Kit LTU

E5Y37A

HPE OneView w/o iLO including 3yr 24x7 Support 1-server LTU

P8B24A

HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU

P8B26AAE

HPE OneView w/o iLO including 3yr 24x7 Support 1-server FIO LTU

P8B31A

NOTE: For additional license kits please see the QuickSpecs

High Performance

HPE Cluster Management Utility

HPE Insight Cluster Management Utility 1yr 24x7 Flexible LTU

QL803B

HPE Insight Cluster Management Utility 3yr 24x7 Flexible LTU

BD476A

Options

License

Software for Converged Mgmt

online or via fax in order to obtain the license activation key(s). Includes one or three years of 24 x 7 HPE Software Technical Support Service. NOTE: For additional license kits, including electronic delivery options, please see the iLO QuickSpecs at

https://www.hpe.com/us/en/servers/integrated-lights-out-ilo.html

online or via fax in order to obtain the license activation key(s). Includes one or three year of 24 x 7 HPE Software Technical Support Service.

NOTE: For additional license kits, please see the QuickSpecs at:

https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154343

at https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04154343

Clusters

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Additional Options

Page 31

NOTE: These part numbers can be used to purchase one certificate for multiple licenses

to obtain a license key. Customer also will receive a support agreement.

HPE Insight Cluster Management Utility Media

BD477A

NOTE: For additional license kits please see the QuickSpecs

HPE Security

HPE Trusted Platform Module Option (Recommended)

488069-B21

HPE Trusted Platform Module 2.0 Kit (Recommended)

745823-B21

NOTE: The TPM (Trusted Platform Module) is a microcontroller chip that can securely

TPM works with BitLocker to help protect user data and to ensure

HPE Storage

HPE Smart Array P244br/1GB FBWC 12Gb 2-ports Int SAS Controller (Recommended)

749680-B21

HPE Smart Array P246br/1GB FBWC 12Gb 4-ports Int SAS Controller (Recommended)

726793-B21

HPE H244br 12Gb 2-ports Int Smart Host Bus Adapter (Extended)

726809-B21

HPE BL460c G9 Broadwell NVMe FIO Setting

825555-B21

NOTE: The HPE Gen9 Broadwell NVMe FIO Setting (825555-B21) is required to support

HPE Secure

HPE Secure Encryption per Svr Entitlement

C9A82AAE

NOTE: HPE Secure Encryption is supported on the HPE Smart Array P244br and H244br

number of physical drives requiring encryption.

NOTE: For more information about HPE Secure Encryption, go

and support with a single activation key. Each license is for one node (server). Customer will receive a printed end user license agreement and license entitlement certificate via physical shipment. The license entitlement certificate must be redeemed online in order

at https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c04111735

store artifacts used to authenticate the server platform. These artifacts can include passwords, certificates and encryption keys. Windows® BitLocker™ Drive Encryption (BitLocker) is a data protection feature available in Windows Server® 2008 R2 and 2012. BitLocker leverages the enhanced security capabilities of a Trusted Platform Module (TPM) version 1.2. The that a server running Windows Server 2008 R2 and 2012 has not been tampered with while the system was offline.

NOTE: For more information about TPM, including a white paper, go to

https://support.hpe.com/hpsc/doc/public/display?docId=emr_na-hpesbhf03789en_us

NOTE: ProLiant OS pre-installed units will come with the partition required for TPM

deployment. NOTE: The TPM key is unique to every TPM deployed server and must be retained. Misplacing or losing the key could result in data loss.

Controllers

SFF NVMe SSDs within the system. This option is not compatible with the HPE Smart Array P244br, HPE Smart Array P246br, or HPE Smart HBA H244br. HPE recommends recommends the use of a dual M.2 solid state drive kit for boot when using this option. NOTE: The HPE Smart Array B140i Controller (chipset SATA) comes standard with the HPE BL460c Gen9 10Gb/20Gb FLB CTO Blade (727021-B21). If neither the HPE Smart Array P244br nor the HPE H244br controllers are chosen, a SATA cable will be provided

Encryption

to support SATA devices for the two internal drives. If RAID is required when using the B140i, please choose ‘HPE FIO B140i RAID Enable Kit - BIOS Setting’ (784308-B21). NOTE: The HPE Smart Array P246br controller is only required when using a PCI expansion blade or D2220sb storage blade with the BL460c Gen9.

(running in RAID mode) as an option. HPE Secure Encryption licensing is based on the

to https://www.hpe.com/us/en/product-catalog/detail/pip.6532260.html

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Additional Options

Page 32

HPE InfiniBand

NOTE: When an InfiniBand adapter is installed in mezzanine slot 1, only one port is active

are active.

NOTE: InfiniBand QDR and FDR speeds are only supported on the HPE BladeSystem

https://www.hpe.com/h20195/v2/getpdf.aspx/c04126044.pdf?ver=26

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+M Adapter (Extended)

764283-B21

NOTE: The FDR InfiniBand adapter must be installed in mezzanine slot 1 for FDR mode and may be installed in any mezzanine slot if operated in any other mode.

HPE InfiniBand FDR 2-port 545M Adapter (Extended)

702213-B21

HPE Flash Media

HPE Flash Media Kits for USB Drives

HPE Enterprise Mainstream Flash Media Kits for Memory Cards - Recommended

HPE 8GB microSD Flash USB Drive (Recommended)

737953-B21

HPE 8GB microSD Flash Memory Card (Recommended)

726116-B21

HPE 32GB microSD Flash Memory Card (Recommended)

700139-B21

HPE Care Pack

Proactive Care Services

HPE 3 year Proactive Care 24x7 BL4xxc Gen9 Service

U7BN8E

HPE 3 year Proactive Care 24x7 with DMR BL4xxc Gen9 Service

U7BN9E

HPE 3 year Proactive Care Advanced 24x7 BL4xxc Gen9 Service

U7BT6E

HPE 3 year Proactive Care Advanced 24x7 with DMR BL4xxc Gen9 Service

U7CF8E

Installation Services

HPE Install c-Class Server Blade Service

UE493E

Mezzanine Adapters

Kits for USB Drives

Services

(regardless of operating mode). When installed in any other mezzanine slot, both ports

c7000 Enclosure. For additional information, please see the HPE BladeSystem c7000 Enclosure and InfiniBand QuickSpecs at:

https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128339.pdf

HPE 8GB Dual microSD Flash USB Drive (Recommended)

741279-B21

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Memory

For detailed memory configuration rules and guidelines, please use the Online DDR4 Memory Configuration Tool: https://memoryconfigurator.hpe.com/ddr4memoryconfig/home/legal

Memory Subsystem Architecture

Each Intel® Xeon® E5 support two DIMMs each for a total of e Up to 64GB capacity DIMMs are supported for 1TB of memory (16 DIMM slots x 64GB per DIMM).

Memory Population Rules and Guidelines

Load Reduced (LRDIMM)

Single Rank (1R)

Dual Rank (2R)

Quad Rank

(4R)

Octal

Rank(8R)

DIMM

Capacity

8GB

16GB

32GB

64GB

128GB

Voltage

Std

1.2V

Std Voltage

Std Voltage 1.2V

Std Voltage

SLOTS THAT CAN BE POPULATED

16 slot servers

16 16 16 16 16 16

MAXIMUM CAPACITY (GB)*

16 slot servers

128 256 256 512

512

1024

POPULATED DIMM SPEED (MT/s)

1 DIMM

Channel

2400 2400

2400

2400 2400

2400

2 DIMM

Channel

2133

2400

NOTE: Maximum Capacity will vary based on individual serve platform qualification schedule

-2600 v3 family or Intel® Xeon® E5-2600 v3 family processor socket contains four memory channels that ight (8) DIMM per installed processor or a grand total of sixteen (16) DIMMs for the server.

• A minimum of one DIMM is required per processor.

• Install DIMMs only if the corresponding processor is installed.

• If only one processor is installed in a two processor system, only half of the DIMM slots are available.

• DIMM sizes can be mixed in channel. To maximize performance, it is recommended to balance the total memory capacity

between all installed processors and to load the channels similarly whenever possible.

• LRDIMM and RDIMMs are all distinct memory technologies and cannot be mixed within a server. The majority of ProLiant

Gen9 servers support RDIMM and LRDIMM.

• DIMMs of different speeds may be mixed in any order; the server will select a common optimal speed.

• The maximum memory speed is a function of the memory type, memory configuration, and processor model.

• The maximum memory capacity is a function of the memory type and number of installed processors.

• HPE memory from previous generation servers is not compatible with the BL460c Gen9 Server Blade.

• To realize the performance memory capabilities listed in this document, HPE SmartMemory is required. For additional

information, please see the HPE SmartMemory QuickSpecs at: https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04111535

Supported Memory Bandwidth on Intel® Xeon® E5-2600 v4 series Processors

DIMM

Rank

Voltage

1.2V

Per

1.2V

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Memory

Page 34

Memory options part number decoder

Capacity

8 GByte

Rank

1R = Single-rank Data width

x4 = 4-bit Memory generation

DDR4 5

Max. Memory speed

2133MT/s

CasLatency

P = 15

DIMM type

R = RDIMM (registered)

Following are memory options available from Hewlett Packard Enterprise:

HPE Memory

NOTE: HPE memory from previous generation servers (DDR3) is not compatible with this

Registered DIMMs (RDIMMs) - E5-2600 v4 series Processors - Recommended

HPE 16GB (1x16GB) Single Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Recommended)

805349-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Recommended)

805351-B21

Item Description Definition

16 GByte 32 GByte

2R = Dual-rank 4R = Quad-rank

x8 = 8-bit

L = LRDIMM (load reduced)

https://www.hpe.com/us/en/servers/memory.html

NOTE: LRDIMM and RDIMM are distinct memory technologies and cannot be mixed

within a server. NOTE: Depending on the memory configuration and processor model, the memory speed may run at 2400MT/s, 2133MT/s, 1866MT/s, or 1600MT/s.

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Memory

Page 35

HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Extended)

805347-B21

HPE 16GB (1x16GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit (Extended)

836220-B21

Load Reduced DIMMs (LRDIMMs) - E5-2600 v4 series Processors - Extended

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit (Extended)

805353-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2400 CAS-20-18-18 Load Reduced Memory Kit (Extended)

809208-B21

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Storage

1-2

2 x SFF hot-plug SAS, SATA, SAS SDD, and SATA SSD hard drives

Page

QuickSpecs

Technical Specifications

System Unit

Dimensions

7.11 x 2.18 x 20.37 in (18.07 x 5.54 x 51.76 cm)

Weight

Maximum: all processors, 16

installed)

14.00 lb (6.33 kg)

Minimum: one processor and

10.50 lb (4.75 kg)

Power Specifications

For power specifications including input requirements, BTU rating, and power supply

via the online tool located at https://paonline56.itcs.hpe.com.

NOTE: For optimal cooling and system performance the BL460c Gen9 Server Blade

System Inlet

Operating

10° to 35°C (50° to 95°F) at sea level with an altitude

a fan fault or above 30°C (86°F).

Non-operating

-30° to 60°C (-22° to 140°F). Maximum rate of change

Extended Ambient

For Approved hardware configurations, the supported system inlet range is extended

Operating

10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non-condensing.

HPE ProLiant BL460c Gen9 Server Blade

(H x W x D) (with bezel)

(approximate)

DIMMs, hard drives, mezzanine cards, and two flash cache batteries

2 DIMMs installed

output, please see the:

• HPE BladeSystem c3000 Enclosure QuickSpecs

https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=c041

at 23379

• HPE BladeSystem c7000 Enclosure QuickSpecs

https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c042295

To review typical system power ratings use the HPE Power Advisor which is available

requires the c7000 enclosure to be configured with 10 fans and the c3000 enclosure to be configured with 6 fans.

Temperature

derating of 1.0°C per every 305 m (1.8°F per every 1,000 ft) above sea level to a maximum of 3,050 m (10,000 ft), no direct sustained sunlight.

Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed.

System performance may be reduced if operating with

is 20°C/hr (36°F/hr).

Operating Support

to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95° to 104°F) at sea level with an altitude derating of 1.0°C per every 175 m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft)

NOTE: Qualifications for extended ambient configurations are detailed at:

http://www.hpe.com/servers/ashrae

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Technical Specifications

Page 38

Non-operating

5 to 95% relative humidity (Rh), 38.7°C (101.7°F)

Altitude

Operating

3,050 m (10,000 ft). This value may be limited by the

ft/min).

Non-operating

9,144 m (30,000 ft). Maximum allowable altitude

Acoustic Noise

For acoustic noise specifications, please see the HPE BladeSystem c-Class Enclosures

HPE Smart Array

Disk Drive Interface

12Gb/s SAS (Serial Attached SCSI) 6Gb/s SATA (Serial ATA)

Server Interface

x8 PCIe 3.0 provides 8GB/s maximum bandwidth

Cache Memory

1GB flash backed write cache (FBWC) cache standard

Logical Drives Supported

64 (with included 1GB cache)

Host Memory Addressing

64-bit, supporting servers memory space greater than 4GB

RAID Support

Other

Upgradeable firmware with recovery ROM

HPE Smart HBA

Disk Drive Interface

12Gb/s SAS (Serial Attached SCSI) 6Gb/s SATA (Serial ATA)

Server Interface

x8 PCIe 3.0 provides 8GB/s maximum bandwidth

Cache Memory

None

Logical Drives Supported

Host Memory Addressing

64-bit, supporting servers memory space greater than 4GB

RAID Support

RAID 1 (mirroring) and RAID 0 (striping)

Other

Upgradeable firmware with recovery ROM

HPE Dynamic Smart Array B140i

Disk Drive Interface

6Gb/s SATA (Serial ATA)

Server Interface

Embedded x4 PCIe 2.0

SAS Connectors Cache Memory

2 internal SATA ports

SAS Speed

6Gb/s SATA links

Relative Humidity (non-condensing)

QuickSpecs located at:

• HPE BladeSystem c3000 Enclosure

• HPE BladeSystem c7000 Enclosure

QuickSpecs: pdf

QuickSpecs:

pdf

maximum wet bulb temperature, non-condensing.

type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1,500

change rate is 457 m/min (1,500 ft/min).

https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128340.

https://www.hpe.com/h20195/v2/GetPDF.aspx/c04128339.

P244br Controller

H244br Controller

RAID 1 (mirroring), RAID 0 (striping), RAID 10

Online drive flash (with SAS drives)

Controller

None

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Technical Specifications

Page 39

Logical Drives Supported

Up to 10 logical volumes (2 physical drives)

Host Memory Addressing

64-bit, supporting greater than 4GB server memory space

Hot Plug Support

Yes

RAID 0 (Striping)

Other

Upgradeable firmware with recovery ROM

HPE FlexFabric

Type

capability)

Network Processor

QLogic 57840S with integrated MAC/PHY

Data Transfer Method

x8 PCI Express 3.0

Network Transfer

Two ports, each at 20Gbps full duplex; 40Gbps aggregate full duplex theoretical

(theoretical) full duplex.

IEEE Compliance

802.1p, 802.1q, 802.1qau, 802.3ad, 802.3ae, 802.3ap (10GBase-KX4) and 802.3x

Standard Features

Full hardware offload of iSCSI and FCoE storage protocol processing for highest

HPE FlexFabric

Type

Integrated dual-port KR2 20Gb FlexibleLOM with FlexFabric (Flex-20, FCoE, RoCE,

Network Processor

Emulex XE-104

RAID Support

10Gb

RAID 1 (Mirroring)

Integrated dual-port KR 10Gb FlexibleLOM with FlexFabric (Flex-10, FCoE, hardwarebased iSCSI, iSCSI boot, TCP/IP offload engine, and autosensing 1Gb/10Gb Ethernet

2-port 536FLB FlexibleLOM

Rate

bandwidth

NOTE: Each port is autosensing 1Gb/10Gb, and can interoperate with 1Gb or 10Gb HPE BladeSystem c-Class interconnect components. Both ports will operate at the same speed. NOTE: Each port on the 536FLB adapter transmits from the server at 20Gbps

performance converged Ethernet data and storage networks. Dual-port 10GbE Flex-10 FlexibleLOM network adapter that provides the flexibility to choose the type of LOM to meet growing infrastructure needs Industry-leading throughput and latency performance Supports the HPE Flex-10 blade interconnect technology User configurable bandwidth settings when combined with the 10Gb Flex-10 Virtual Connect module. From 100Mb/s to10Gb/s on up to four "Physical Function" NICs per port, in increments of 100Mb/s for NIC. The combined bandwidth of NICs cannot exceed port bandwidth i.e. 10 Gb. Up to 40Gb/s bi-directional near line rate throughput Hardware acceleration and offloads for stateless TCP/IP, TCP Offload Engine (TOE) Improved small packet performance Support for Preboot eXecution Environment (PXE) Integrated PHY and MAC Supports for SR-IOV Support for Network Partitioning (NPAR)

20Gb 2-port 650FLB FlexibleLOM

Tunnel Offload with VXLAN/NVGRE, hardware-based iSCSI, iSCSI boot, TCP/IP offload engine, and autosensing Ethernet speed capability)

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Technical Specifications

Page 40

Data Transfer Method

x8 PCI Express 3.0

Network Transfer

Two ports, each at 40 Gbps bi-directional; 80 Gbps aggregate bi-directional theoretical

IEEE Compliance

802.3ae, 802.1Q, 802.3x, 802.1p, 802.3ad/LACP, 802.1AB(LLDP), 802.1Qbg,

Standard Features

Dual 20Gb ports provide up to 80Gb bi-directional per adapter

Environment-

End-of-life

Hewlett Packard Enterprise offers end-of-life Hewlett Packard Enterprise product

To recycle your product,

OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.

Rate

bandwidth

802.1Qbb, 802.1Qaz, 802.3ap

Multi-speed adapter operates at either 20GbE or 10GbE Converges FCoE or RoCE with LAN traffic on a single Ethernet wire Tunnel Offload support for VXLAN and NVGRE RDMA over Converged Ethernet (RoCE) for greater server efficiency and lower latency (6125XLG only) Advanced storage offload processing freeing up valuable CPU cycles Supports UEFI and legacy boot options Mixed Storage – supports NIC + FCoE on one port, and NIC + iSCSI on the other Concurrent Storage – concurrently supports NIC, FCoE, and iSCSI storage functions on the same port (NIC + FCoE + iSCSI) Industry-leading throughput and latency performance Supports the HPE Flex-20 blade interconnect technology Over eight million small packets/s, ideal for web/mobile applications, mobile messaging, and social media User configurable bandwidth settings when combined with the 20Gb Flex-20 Virtual Connect module. From 100Mb/s to10Gb/s on up to four "Physical Function" NICs per port, in increments of 100Mb/s for NIC. The combined bandwidth of NICs cannot exceed port bandwidth i.e. 20 Gb/s. Greater bandwidth with PCIe 3.0 Jumbo Frames support Supports Wake On LAN (WOL) Support for Preboot eXecution Environment (PXE) Support for Microsoft Windows SMB Direct Optimized host virtualization density with SR-IOV support

friendly Products and Approach

Management and Recycling

return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to:

http://www.hpe.com/info/recycle .

please go to: http://www.hpe.com/info/recycle or contact your nearest Hewlett Packard Enterprise sales office. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web

http://www.hpe.com/info/recycle .These instructions may be used by

site at: recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Summary of Changes

Date

Version History

Action

Description of Change

06-Aug-2018

Version 31

Changed

Overview, Standard Features, Optional Features, Configuration Information Factory Integrated Models, and Additional Options sections were updated.

Added

SKUs added: 749680-B21, 726793-B21, 726809-B21, 726782-B21.

Removed

Obsolete SKUs were deleted: C6N36A, 761871-B21, 761878-B21, 749975B21, 726782-B21.

04-Jun-2018

Version 30

Changed

Overview, Standard Features, Configuration Information-Factory Integrated

were updated.

Added

SKUs added:

873357-B21.

Removed

SKUs were deleted:

819843-B21, 880875-B21, 880877-B21, C6N27A, 805358-B21.

02-Apr-2018

Version 29

Changed

Standard Features, Models, Configuration Information - Factory Integrated Models, and Additional Options sections

Removed

Obsolete SKUs were deleted:

764282-B21.

06-Nov-2017

Version 28

Added

SKU was added in Core Options section: 651281-B21.

Removed

Obsolete SKUs were deleted:

779168-B21, 779172-B21, 762261-B21, 794603-B21.

23-Oct-2017

Version 27

Changed

Care Pack naming and Service and Support- Parts and Materials updated.

25-Sep-2017

Version 26

Changed

QuickSpecs was updated.

07-Aug-2017

Version 25

Added

SKUs added:

875509-B21, 875511-B21, 875513-B21.

Removed

Obsolete SKUs were removed:

C6N31A.

12-Jun-2017

Version 24

Added

New SKUs added in Core Options section:

875591-B21.

Removed

Obsolete SKUs were deleted:

804665-B21, 804639-B21, 804625-B21, 804613-B21, 762263-B21.

Models, Additional Options, Memory, and Technical Specifications sections

P00423-B21, 809208-B21, 700065-B21, 700763-B21, 766490-B21, 655639-B21, 878014-B21, P04556-B21, P04560-B21, P04564-B21, P04566-B21, P04570-B21, P00896-B21, 873351-B21, 873355-B21,

819846-L21, 819837-L21, 819843-L21, 700066-B21, 700764-B21, 766491-B21, 684214-B21, 825555-B21, 819846-B21, 819837-B21,

727021-B21, 871770-B21, 871768-B21, 872363-B21, 748387-B21, 791034-B21, 652605-B21, 751518-B21, 785069-B21, 781516-B21, 785067-B21, 804631-B21, 832414-B21, 869386-B21, 869384-B21, 869378-B21, 804587-B21, 869376-B21, 869374-B21, 759208-B21, 759210-B21, 759212-B21, 870763-B21, 726720-B21, 759934-B21,

764908-B21, 764906-B21, 764904-B21, 765044-B21, 765038-B21, 765036-B21, 765034-B21, 764892-B21, 736939-B21, 736936-B21, 872855-B21, 872853-B21, 802578-B21, 802586-B21, 816576-B21, 802891-B21, 822567-B21, 822563-B21, 822555-B21, 764927-B21, 804605-B21, 804593-B21, 804575-B21, 779176-B21, 779164-B21,

875470-B21, 875474-B21, 875478-B21, 875483-B21, 870144-B21, 875311-B21, 875313-B21, 875326-B21, 875330-B21, 875503-B21,

846430-B21, 846432-B21, 846436-B21, 794605-B21, 775588-B21, 792278-B21, 846495-B21, 846497-B21, 875503-B21, 846434-B21,

875593-B21, 875595-B21, 875597-B21, 875587-B21, 875589-B21,

C6N28ABE, C6N36ABE, 652572-B21, 652749-B21, 804599-B21, 804581B21, 816929-B21, 838404-B21, 838406-B21, 838408-B21, 838410-B21, 838412-B21, 785233-B21, 802582-B21, 804677-B21, 804671-B21,

Page

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Summary of Changes

Page 42

27-Mar-2017

Version 23

Changed

Overview, Core Options, and Additional Options sections were updated.

Removed

Obsolete SKUs were deleted:

817011-B21, 816995-B21, 816985-B21, 816909-B21.

13-Feb-2017

Version 22

Added

SKUs added:

869374-B21, 869376-B21, 869378-B21, 869384-B21, 869386-B21.

Changed

Memory section was corrected.

Removed

Obsolete SKUs were deleted: 854845-B21

28-Nov-2016

Version 21

Added

SKUs added:

871768-B21, 871770-B21, 872853-B21, 872855-B21

Removed

Turn Off Skus deleted:

789145-B21.

16-Sep-2016

Version 20

Changed

QuickSpecs information was updated.

Added

Obsolete SKUs were deleted:

BD883A, 854845-B21.

06-Jun-2016

Version 19

Changed

Models, Configuration Information - Factory Integrated Models, Core Options, Memory, and Technical Specifications sections were updated.

Added

SKUs added in Related Options and Core Options sections: 854845-B21, 809208-B21, 822559-B21, 846436-B21

31-Mar-2016

Version 18

Changed

Overview, Standard Features, Optional Features, Recomended Support

updated.

Added

SKUs added to QuickSpecs:

838404-B21, 838406-B21, 838408-B21, 838410-B21, 838412-B21.

Removed

Obsolete SKUs were deleted: 756601-B21, 691864-B21

16-Feb-2016

Version 17

Changed

Information updated in different sections.

Added

SKUs Added in Core Options sections: 846495-B21, 846497-B21, 832514-B21.

718162-B21, 652589-B21, 652583-B21, 652564-B21, 652611-B21, 652564-B21, 652611-B21, 764923-B21, 764925-B21, 764929-B21,

872355-B21, 872359-B21, 872363-B21, 870753-B21, 870757-B21, 870759-B21, 870763-B21, 870765-B21, 872475-B21, 872477-B21, 872479-B21, 872481-B21, 872344-B21, 872348-B21, 872352-B21,

868814-B21, 868818-B21, 868822-B21, 868826-B21, 868830-B21,

816879-B21, 816889-B21, 816899-B21, 816919-B21, 816965-B21, 822559-B21, 816975-B21. Obsolete SKUs were deleted: 655708-B21, 652745-B21, 717965-B21, 757339-B21, 717973-B21, 739898-B21, 717971-B21, 691868-B21, 691866-B21, 691862-B21,

651281-B21, 734360-B21, 739888-B21, 717969-B21, 756636-B21,

Services for BL460, Models, Confirguration Information - Factory Integrated,Core Options, Additional Options, and Memory sections were

813198-B21, 819852-L21, 819851-L21, 819842-L21, 819841-L21, 819840-L21, 819849-L21, 819839-L21, 819845-L21, 819846-L21, 819844-L21, 819838-L21, 819837-L21, 819856-L21, 819855-L21, 819854-L21, 819857-L21, 819853-L21, 819850-L21, 819848-L21, 819847-L21, 805347-B21, 805349-B21, 836220-B21, 805351-B21, 805353-B21, 805358-B21, 825555-B21, 819852-B21, 819851-B21, 819842-B21, 819841-B21, 819840-B21, 819849-B21, 819839-B21, 819845-B21, 819846-B21, 819844-B21, 819838-B21, 819837-B21, 819843-B21, 819856-B21, 819855-B21, 819854-B21, 819857-B21, 819853-B21, 819850-B21, 819848-B21, 819847-B21, 764908-B21, 764906-B21, 764904-B21, 765044-B21, 765038-B21, 765036-B21, 765034-B21, 764892-B21, 736939-B21, 736936-B21, 802891-B21, 846430-B21, 846432-B21, 846434-B21, 846436-B21, 816879-B21,

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Summary of Changes

Page 43

Removed

Obsolete SKUs were deleted:

D8584A.

09-Oct-2015

Version 16

Changed

Core Options section was updated.

Added

SKUs added: P8B24A, P8B26AAE, P8B31A

Removed

Obsolete SKUs were deleted: 756621-B21, 756657-B21, 789155-B21

28-Sep-2015

Version 15

Added

SKU added in Additional Options:

28-Aug-2015

Version 14

Changed

Information in Core Options section was updated.

Added

SKUs added in Core Options section: 659818-B21, 651281-B21

Integrated Models, Core Options and Memory sections were updated.

Added

SKUs added in Additional Options and Core Options sections:

804599-B21, 804593-B21, 804587-B21, 804581-B21, 804575-B21.

Removed

Obsolete SKU deleted: F6Q89AAE

19-Jun-2015

Version 12

Changed

Information updated.

1-Jun-2015

Version 11

Changed

Information in Optional Features, Configuration Information- Factory Integrated, and Models sections was updated.

Added

SKUs added: 726724-B21, 748387-B21, 791034-B21, 726793-B21

Removed

SKUs removed: 726793-B21, 741159-B21, 741151-B21

6-Apr-2015

Version 10

Changed

Industry Standard Compliance and Additional Options sections were updated

30-Mar-2015

Version 9

Added

SKUs Added:

794605-B21, 781518-B21, 785069-B21

Removed

Obsolete SKUs Deleted: 741146-B21, 741138-B21

27-Feb-2015

Version 8

Changed

Smart Buy 779805-S01 processor was updated in Product Bulleting US version.

9-Feb-2015

Version 7

Changed

Core Options and Additional Options sections were updated

Added

SKUs Added on Hard Drives section:

764925-B21, 764927-B21, 764929-B21

Removed

SKUs removed: 728935-B21, 718939-B21

12-Dec-2014

Version 6 Changed

Descriptions were updated throughout the QuickSpecs.

Added

SKU Added on HPE Smart Memory: 792278-B21

1-Dec-2014

Version 5

Changed

Overview, Standard Features, Configuration Information - Factory Integrated Models and Core Options sections were updated

Added

SKUs added:

756657-B21, 756621-B21

Removed

SKU E5Y35AAE deleted due to compatibility issues

10-Oct-2014

Version 4

Changed

Smart Buy section added to the NA version only

8-Oct-2014

Version 3

Changed

Network Controller, Enclosures and Compatible SAN sections were updated

789135-B21, E5Y38A, E5Y39AAE, QK763A, QK762A, QK761A, D8585AAE,

745823-B21

17-Aug-2015 Version 13 Changed Standard Features, Optional Features, Configuration Information - Factory

C9A82AAE, 804677-B21, 804671-B21, 804665-B21, 804639-B21, 804631-B21, 804625-B21, 832414-B21, 804613-B21, 804605-B21,

741279-B21, 728629-B21, 726793-B21, 749975-B21, 726782-B21, 727261-B21, 802578-B21, 802582-B21, 802586-B21, 802891-B21, 781516-B21, 785067-B21, 765453-B21, 765455-B21, 765464-B21, 765466-B21, 789135-B21, 789145-B21, 789155-B21, 794603-B21,

779164-B21, 779168-B21, 779172-B21, 779176-B21, 764923-B21,

759934-B21, 726720-B21, 775588-B21, 785233-B21, 757339-B21,

QuickSpecs

HPE ProLiant BL460c Gen9 Server Blade

Summary of Changes

Page 44

Added

HPE I/O Accelerator Options section has been added including following SKUs: QK763A, QK762A, QK761A

Removed

Expansion Blade Support section was deleted

17-Sep-2014

Version 2

Changed

Changes made throughout the Standard Features, Models, SmartMemory, Core Options and Carepacks sections.

09-Sep-2014

Version 1

Created

New QuickSpecs

© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pr Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

Microsoft and Windows NT are US registered trad Xeon and Xeon Inside are trademarks of Intel Corporation in the U.S. and other countries.

For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.

c04347343

oducts and services.

emarks of Microsoft Corporation. Intel, the Intel logo,

- 15052 - Worldwide - V31 - 6-August-2018

HPE 813196-B21 Getting Started Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Optional Features

Recommended Support Services for BL460

Models

Core Options

Memory

Storage

Technical Specifications

Summary of Changes
