HP X1800sb User Manual

HP StorageWorks Automated Storage Manager User Guide

HP Part Number: 5697-0816 Published: April 2011 Edition: Second

Confidential computer software. Valid license from HP required for possession, use or copying. Consistent with FAR 12.211 and 12.212, Commercial Computer Software, Computer Software Documentation, and Technical Data for Commercial Items are licensed to the U.S. Government under vendor's standard commercial license.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Acknowledgments

Microsoft, Windows, Windows XP, and Windows NT are U.S. registered trademarks of Microsoft Corporation.

1 Automated Storage Manager Overview........................................................5

Software requirements...............................................................................................................5

Software support.................................................................................................................5

Using ASM with HP StorageWorks Storage Mirroring software..................................................6

Support for LUNs over 2TB in size...............................................................................................6

2 Configuring Automated Storage Manager.....................................................7

Installing the Automated Storage Manager Agent.........................................................................7

Installing the Automated Storage Manager Agent on network application servers.........................7

Add an HP Storage System........................................................................................................7

Remove an HP Storage System...................................................................................................7

Configure display options..........................................................................................................7

Configure Application Credentials..............................................................................................8

Configure Storage Networks......................................................................................................8

Resetting iSCSI connections...................................................................................................9

3 Hosting storage for applications and shared folders......................................10

Using the Host an Exchange Storage Group Wizard...................................................................10

Entering a name of a server that hosts Exchange....................................................................11

Selecting Exchange storage group components......................................................................11

Local Continuous Replication (LCR).......................................................................................12

Using the Create a Shared Folder Wizard.................................................................................12

Choosing shared folder types..............................................................................................13

Naming a shared folder ....................................................................................................13

Setting permissions for a shared folder.................................................................................13

Using the Host a SQL Server Database Wizard..........................................................................14

Selecting a server that hosts SQL Server................................................................................14

Selecting SQL Server database components..........................................................................14

Selecting a database workload type.....................................................................................15

Using the Host a User-Defined Application Wizard.....................................................................15

Choose type of application.................................................................................................16

Entering an application name..............................................................................................17

Using the Create a Virtual Library Wizard.................................................................................17

Accessing the Virtual Library Wizard....................................................................................17

Configure your virtual library..........................................................................................17

Allocating space for components..............................................................................................17

Setting advanced storage properties.....................................................................................18

Selecting data protection.........................................................................................................22

Reviewing task summary and scheduling tasks............................................................................24

Monitoring task completion status.............................................................................................25

Cancelling tasks................................................................................................................25

Migrating user-defined application data from a remote application...............................................25

4 Managing data protection.........................................................................27

Scheduling and running snapshots............................................................................................27

Managing snapshots..............................................................................................................27

Taking and deleting snapshots.............................................................................................27

Exposing a snapshot..........................................................................................................28

Unexposing a snapshot......................................................................................................28

Contents 3

Reverting data to snapshots.................................................................................................29

Scheduling backups................................................................................................................29

Managing backups.................................................................................................................29

Running a device backup....................................................................................................29

Running a virtual library backup..........................................................................................30

Restoring data from backups...............................................................................................30

Using DPX to restore data...............................................................................................30

Setting the password for the ASMbackup user account.......................................................31

Using the Administrator account to change the ASMbackup password.................................31

Installing Data Protector Express on other machines...........................................................32

5 Managing storage....................................................................................33

Increasing or reducing the allocated storage..............................................................................33

Changing the percent full warning threshold..............................................................................33

Removing application areas from view.......................................................................................34

Changing permissions, names, descriptions, or paths of shared folders..........................................34

Deleting shared folders............................................................................................................35

6 Monitoring storage...................................................................................36

Application View....................................................................................................................36

Accessing application and shared folder properties................................................................37

Storage View.........................................................................................................................46

Accessing storage area properties.......................................................................................47

Application Server View..........................................................................................................48

Accessing application server properties................................................................................49

Storage Utilization View..........................................................................................................50

Automated Storage Manager Alerts..........................................................................................51

7 Troubleshooting Automated Storage Manager..............................................52

Troubleshooting Data Protector Express......................................................................................52

8 Support and other resources......................................................................54

Contacting HP........................................................................................................................54

Subscription service............................................................................................................54

Index.........................................................................................................55

4 Contents

1 Automated Storage Manager Overview

This documentation is intended for the person who administers HP StorageWorks X1000 Network Storage Systems running Automated Storage Manager software.

ASM provides storage-allocation wizards that walk you through the process of allocating and configuring storage on your HP Storage System to host application data and shared folders. The storage-allocation wizards also allow you to schedule backups and snapshots of hosted application data and shared folders.

Other wizards are provided to help you set up Exchange Server storage, SQL Server database storage, user-defined application storage, and shared folders storage.

ASM is designed to work seamlessly with Windows administrator tools, HP Storage System Management applications, Microsoft iSCSI Target, and Data Protector Express. For example, you can change your HP Storage System's:

• Storage allocations (quotas), shared folder permissions and names, and snapshot schedules

using ASM, Windows administrator tools, and the HP Storage System Management applications.

• Media rotation type using ASM and Data Protector Express.

IMPORTANT: Do not use Windows administrator tools to change the paths to storage configured

on your HP Storage System or file directories created by ASM on application servers with storage hosted on your HP Storage System. Doing so will break the iSCSI communication paths between your application servers and HP Storage System, and make it so ASM can no longer locate allocated storage areas on your HP Storage System.

Software requirements

ASM comes preinstalled on your HP Storage System. A license key is not required for ASM.

Software support

Storage for application servers running on Windows Server 2003 with SP1 through Windows Server 2008 R2 that are on the same domain as your HP Storage System can be hosted. Windows domain controllers (such as Windows Small Business Server) are supported by ASM as managed application servers.

ASM provides storage-management services for the following applications:

Table 1 Storage support on ASM

Microsoft Exchange Server 2003 with SP1 or later, Exchange Server 2007, and Exchange Server 2010

Microsoft SQL Server 2000 with SP4 or later, SQL Server 2005 with SP2 or later, SQL Server 2008, and SQL Server 2008 R2*

User-defined applications

* ASM does not support SQL Server 2008 databases that utilize FILESTREAM data type storage. ASM does not support Internet Protocol version 6 (IPv6). When entering or configuring IP address

settings using ASM, use Internet Protocol version 4 (IPv4) addresses. In order to use some Automated Storage Manager features, your HP Storage System must have

supporting software installed. Microsoft iSCSI Software target is preinstalled. HP Data Protector

See “Using the Host an Exchange Storage Group Wizard”

(page 10).

See “Using the Create a Shared Folder Wizard” (page 12).File sharing services on local storage

See “Using the Host a SQL Server Database Wizard”

(page 14).

See “ Using the Host a User-Defined Application Wizard”

(page 15).

Software requirements 5

Express is not preinstalled. For more information about Data Protector Express, see the X1000 Network Storage System QuickSpecs at http://www.hp.com/go/X1000. To obtain an evaluation version of HP Data Protector Express, see the HP Data Protector Express Web site at http://

www.hp.com/go/dataprotectorexpress.

The following table lists the supporting software and installation requirements.

Table 2 Required software for ASM features

Required for:Software

Microsoft iSCSI Software Target

and SQL Server) and iSCSI-based User-Defined application storage

HP Data Protector Express

or other types of storage media

Preinstalled on X1000 Network Storage Systems

Yes (license key not required)Hosting application storage (Exchange

NoCreating backups to tape, other disks,

Using ASM with HP StorageWorks Storage Mirroring software

As of ASM version 4.0, HP StorageWorks Storage Mirroring (SWSM) software is no longer integrated directly with ASM.

Support for LUNs over 2TB in size

ASM supports the provisioning of LUNs over 2TB in size on systems running Windows Storage Server 2003 and Windows Storage Server 2008 and greater. ASM uses GUID Partition Table (GPT) partitions to enable this new feature. All storage that is provisioned using ASM now uses GPT partitions by default.

Limitations

• Existing Master Boot Record (MBR) LUNs cannot be grown beyond 2TB. This includes local

volumes and iSCSI volumes.

• iSCSI LUN volumes greater than 2TB are supported only if the iSCSI Target is running a

minimum of iSCSI Target version 3.2.

• The maximum size allowed for a LUN is 256TB.

IMPORTANT: If you want to grow existing MBR partitions to a size exceeding 2TB, you must first

convert the MBR partition to a GPT partition. This can be accomplished by backing up the data on the MBR partition and then deleting the MBR partition. A new GPT partition can then be created and the data can be restored. For more information about GPT partitions, refer to Microsoft Knowledge Base article KB302873.

6 Automated Storage Manager Overview

2 Configuring Automated Storage Manager

Installing the Automated Storage Manager Agent

If you plan to perform data migration tasks for any application servers on your network using the wizards that are available in the Automated Storage Manager, you must first install the Automated Storage Manager Agent on those application servers. Follow these instructions before performing any data migration operations.

Installing the Automated Storage Manager Agent on network application servers

To install the Automated Storage Manager Agent on a network application server:

1. Locate the file at c:\\hpnas\components\allinonestoragemanager\agent.

2. Copy the file to the application server(s) you will use to perform data migration tasks.

3. Run the copied file on each application server to install the Automated Storage Manager Agent.

1. On the application server that stores data to be migrated, insert the HP StorageWorks Storage System Recovery DVD.

NOTE: If the application server is in a remote location, use Remote Desktop Connection to

access the server, copy the Agent installation files, and run the Agent installation.

2. Navigate to the \Automated Storage Manager\Agent folder on the DVD.

3. Double-click asmagentinstaller.exe.

4. Follow the on-screen installation instructions.

After completing the Automated Storage Manger Agent installation on the application servers, you can then schedule data migration using the HP Automated Storage Manager wizards.

Add an HP Storage System

You may add another HP Storage System for the ease of managing more than one server from the same console. To add another HP Storage System:

1. Click on Add HP Storage System in the Actions pane.

2. A dialog box will open. Enter the hostname or IP address (IPv4) of the HP Storage System to

add.

3. The added HP Storage System will appear in the Navigation pane.

Remove an HP Storage System

To remove an added HP Storage System:

1. Click on Remove HP Storage System.

2. A window will appear, asking if you would like to remove the HP Storage System.

3. Click Yes.

Configure display options

ASM allows you to customize the user interface color and scale settings.

Installing the Automated Storage Manager Agent 7

Changing color settings

Changing color settings customizes the color used in the content pane to display the different types of storage, volumes, and servers. Colors help distinguish the different types of storage, storage areas, and servers from each other.

1. In the Actions pane, click Configure Display Options. The Display Options dialog box opens.

2. Select an item in the Items list and a color in the Color drop-down menu.

3. When your color selections are complete, click Apply to apply the color settings to the content pane.

4. Click OK.

Scaling display settings

Changing the scaling settings customizes the size at which each application area or shared folder is displayed in the content pane. You can choose to scale each application area and shared folder so that it is displayed in proportion to its capacity (allocated storage size), or so that all the application areas and shared folders are displayed at the same size.

1. In the Actions pane, click Configure Display Options. The Display Options dialog box opens.

2. Click the Scaling tab.

3. Select the storage-display proportion setting:

• According to capacity, using automatic scaling—Displays logical disks and volumes, and

application areas according to relative size, but leaves the display readable.

• All as the same size—Displays logical disks and volumes, and application areas as the

same size.

4. Click Apply to apply your change.

5. Click OK.

Configure Application Credentials

Use the Application Credentials dialog box to set or update user name and password security credentials applicable to the HP Storage System.

1. Expand the nodes of the tree in order to view the credential status of an application server.

2. If the Credential Status column reads OK or Not required, no action is required for that application.

3. If the Credential Status column reads Failed or Not set, select the application row and then click Update Credentials. An Enter Credentials dialog box is displayed.

4. Type the user name and password of a user with sufficient privileges as described in the dialog and then click OK.

5. Repeat steps 1 through 4 for each application server.

Configure Storage Networks

Use the Storage Networks dialog box to configure a preferred private storage network for iSCSI traffic between your HP Storage System and any connected servers that use the iSCSI protocol. This dialog box appears the first time you use the Host an Exchange Storage Group wizard, Host a SQL Server Database wizard, or Host a User-Defined Application wizard. Settings configured in this dialog box affect only iSCSI traffic.

8 Configuring Automated Storage Manager

HP strongly recommends configuring all iSCSI-based storage for application servers on a dedicated Ethernet subnet. The purpose of a private LAN for iSCSI traffic is to is to guarantee dedicated network bandwidth for storage as well as increased security.

To configure storage networks for iSCSI traffic:

1. Under Preferred Storage Network, select a network that will be designated to manage all

iSCSI traffic.

2. Under Available for Failover, select a network that can be used to manage iSCSI traffic in the

event that the preferred storage network fails. In the event of iSCSI initiator failure, iSCSI traffic fails over to the designated network.

NOTE: Any existing iSCSI connections must be reset before changes take effect.

Resetting iSCSI connections

If you use the Storage Networks dialog box to configure a preferred private storage network for iSCSI traffic and there are one or more existing iSCSI connections on the system, the new setting will not take effect until the existing connections are reset through iSCSI Initiator on the connected systems.

WS2008 R2. To reset an iSCSI connection:

1. On the system that contains the iSCSI initiator whose connection has been changed, open Microsoft iSCSI Initiator.

2. On the Favorite Targets tab, select the iSCSI target that resides on your HP Storage System and then click Remove.

3. On the Targets tab, select the iSCSI target that resides on your HP Storage System and then click Disconnect.

4. On the Discovery tab under Target Portals, select the IP address that was previously designated for iSCSI traffic between the application server and the HP Storage System and click Remove.

5. Back on the Targets tab, under Quick Connect, enter the IP address (IPv4) that was enabled for iSCSI traffic in the Automated Storage Networks dialog box and then click Quick Connect. A Quick Connect dialog should show Login Succeeded. Click Done.

6. Click OK to close the iSCSI Initiator Properties dialog box.

WS2003. To reset an iSCSI connection:

1. On the system that contains the iSCSI initiator whose connection has been changed, open Microsoft iSCSI Initiator.

2. On the Persistent Targets tab, select the iSCSI target that resides on your HP Storage System and then click Remove.

3. On the Targets tab, select the iSCSI target that resides on your HP Storage System and then click Details.

4. Select the target identifier from the list, click Log off, and then click OK.

5. On the Discovery tab, under Target Portals select the IP address that was previously designated for iSCSI traffic between the application server and the HP Storage System and click Remove.

6. Click Add. In the IP address or DNS name field, type the IP address (IPv4) that was enabled for iSCSI traffic in the Automated Storage Networks dialog box and then click OK.

7. On the Targets tab, click Log On.

8. Check the Automatically restore this connection when the system boots check box and then click OK.

9. Click OK to close the iSCSI Initiator Properties dialog box.

Configure Storage Networks 9

3 Hosting storage for applications and shared folders

The Automated Storage Manager (ASM) radically simplifies hosting application storage and shared folders on your HP Storage System, using storage-allocation wizards. Use storage-allocation wizards to allocate and configure storage for these applications:

NotesDescriptionApplication

Exchange

Shared Folders

SQL Server

User-Defined Applications

Allocate and configure storage for one or more Exchange storage group components. A wizard assists you by discovering Exchange storage group components (such as mail stores, public stores, and logs), suggesting default storage configurations based on best practices for Exchange, migrating the Exchange storage group components you selected to your HP Storage System, and configuring Exchange to store data on your HP Storage System.

Create shared folders on your HP Storage System. A wizard assists you in allocating and configuring storage space for shared folders, and creating shared folders.

Allocate and configure storage for SQL Server databases. A wizard assists you by discovering servers that host SQL Server and SQL Server database components (such as data files and logs), suggesting default storage configurations based on best practices for SQL Server, migrating the SQL Server database components you selected to your HP Storage System, optionally deleting the SQL Server database components you selected from the server that hosts SQL Server, and configuring SQL Server to store data on your HP Storage System.

Allocate and configure storage for any remote application over the iSCSI protocol or any other application that requires storage on the HP Storage System. A wizard assists you in allocating and configuring storage space. The wizard does not migrate user-defined application data to your HP Storage System or reconfigure the application to store data on your HP Storage System. You must do this manually as described in “Migrating user-defined application data from a

remote application” (page 25), and as described in the

application's documentation.

See “Using the Host an Exchange

Storage Group Wizard” (page 10).

See “Using the Create a Shared

Folder Wizard” (page 12).

See “Using the Host a SQL Server

Database Wizard” (page 14).

See “ Using the Host a

User-Defined Application Wizard” (page 15).

Data Protection

Create a virtual library that backs up data from a remote system on your HP Storage System. A wizard assists you in choosing size and storage allocation.

Using the Host an Exchange Storage Group Wizard

The Host an Exchange Storage Group Wizard automatically discovers the Exchange storage groups on your application server and helps you allocate and configure storage space for these components:

• Mail stores—Contain the data in user mailboxes.

• Public stores—Contain the data in public folders.

• Logs—Provide a record of every message stored in a storage group.

Before you begin configuring storage for Exchange

• Make sure the ASM agent is installed on each server with Exchange data you plan to host.

• Make sure you have a current backup of your Exchange data and logs.

10 Hosting storage for applications and shared folders

See “Using the Create a Virtual

Library Wizard” (page 17).

Accessing the Host an Exchange Storage Group Wizard

1. In the Actions pane, select Host an Exchange Storage Group. The Host an Exchange Storage Group Wizard welcome page opens.

2. Click Next to open the Specify Exchange Server page (see “Entering a name of a server that

hosts Exchange” (page 11)).

Migrating Microsoft Exchange 2010 mail stores

If you are attempting to migrate Microsoft Exchange 2010 mail stores that are replicated (that is, configured in a DAG environment), it is not mandatory that the ASM agent be installed on the other mailbox servers participating in the DAG to facilitate the replication. ASM can still migrate the mailbox and the log files for the replicated database by stopping replication between the participating servers, and then restarting replication after the migration is complete.

If your replicated mail stores share their mail box database path or the log file path with another mail store (replicated or not) they will not be shown as candidates for migration.

For a replicated Exchange 2010 mailbox, if the mailbox database path and the log files path for an Exchange 2010 mailbox are on the same folder before migration, discovery is required after migration for a proper reconciliation. After migration and before the subsequent discovery, you will see only one app area for the migrated Exchange 2010 mailbox. After the discovery, ASM will properly reconcile the app areas to show two different app areas under the storage group instance.

Entering a name of a server that hosts Exchange

Use the Specify Exchange Server page to provide ASM with the name or the Internet Protocol address (IPv4) of a remote server in your current domain that hosts Exchange.

1. Do one of the following:

• Enter the host name of a server that hosts Exchange (exactly as it is registered in the

domain).

• Enter the IP address (IPv4) of a server that hosts Exchange.

2. Click Next to open the Select Storage Group Components page (see “Selecting Exchange

storage group components” (page 11)).

Selecting Exchange storage group components

Use the Select Storage Group Components page to select the Exchange storage group and storage group components (mail stores, public stores, and logs) you want to host on your HP Storage System and manage using ASM.

Using the Host an Exchange Storage Group Wizard 11

1. Do one of the following:

• Select the entire storage group (including all of its components) by checking the box next

to the storage group.

• Select individual storage group components by expanding the list and checking the boxes

next to the components.

You must select all the storage group components in a storage group if you want to run backups or take snapshots of the Exchange storage group using ASM.

The table below lists the action ASM will perform for each storage group component selected.

Table 3 Selecting storage group components to host

DescriptionAction

None

Allocate Space, Move Data

None, Already Managed

2. To view the properties for a storage group component, select the storage group component

name and then click Properties. See “Mail Store tab: Exchange storage group component properties” (page 39), PublicStore

database properties, and “Log tab: Exchange storage group component properties” (page 40)

for descriptions of the properties displayed.

3. When you are done, click Next to open the Storage Allocation page (see “Allocating space

for components” (page 17)).

Local Continuous Replication (LCR)

If the Local Continuous Replication (LCR) feature is enabled in Microsoft Exchange 2007, you have the option of migrating LCR components to your HP Storage System. LCR components are shown in the Select Storage Group Components page in the wizard if this feature is enabled. They are selected in the same manner as other Exchange components.

Component's check box is not selected, so ASM will not perform any action. Select check box to change action.

Storage space will be allocated and configured on your HP Storage System. Component's data will be migrated to your HP Storage System.

Component's data is already hosted on your HP Storage System and already managed by ASM. No action is possible.

NOTE: It is not recommended to host both the LCR and the original Exchange components on a

single HP Storage System.

Using the Create a Shared Folder Wizard

The Create a Shared Folder Wizard walks you through the process of creating a top-level shared folder (file share) on your HP Storage System, including allocating and configuring the required storage.

NOTE: You cannot create nested shared folders on your HP Storage System using ASM. You

may use other applications, such as Windows Explorer or the Shared Folder MMC snap-in, to create nested shared folders on your HP Storage System.

In addition, ASM does not support enforcing an allocated storage limit (or quota) for parent folders of shared folders that are created and managed using ASM.

Accessing the Create a Shared Folder Wizard

1. In the Actions pane, select Create a Shared Folder.

The Create a Shared Folder Wizard welcome page opens.

12 Hosting storage for applications and shared folders

2. Click Next to open the Choose Shared Folder Types page (see “Choosing shared folder types”

(page 13)).

Choosing shared folder types

Use the Choose Shared Folder types page to enable the types of client protocols that are allowed to connect to the shared folder.

1. Select the Share this folder as a Windows share check box to allow Windows clients and clients running the Server Message Block (SMB) and Common Internet File System (CIFS) protocols to connect to the shared folder.

2. Select the Share this folder as a UNIX/Linux share check box to allow clients running the Network File System (NFS) protocol to connect to the shared folder.

NOTE: If the folder is shared as a UNIX/Linux share, NFS user names must be mapped to

Windows users before clients can connect to the share.

If you are running a Windows-only environment, you should not select the UNIX/Linux share option.

Naming a shared folder

Use the Enter a Shared Folder Name and Description page to provide ASM with a name and description for the shared folder.

1. Enter the name for the shared folder.

NOTE: The path to the shared folder is created by ASM and is based on the shared folder

name. The Share Path field is Read Only.

2. Enter a description of the shared folder (optional).

3. Click Next to open the Set Shared Folder Permissions page (see “ Setting permissions for a

shared folder” (page 13)).

Setting permissions for a shared folder

Use the Set Shared Folder Permissions page to set network user read and write permissions for the shared folder.

NOTE: Permissions can be further customized using Windows administration tools, such as

Windows Explorer and the Shared Folder MMC snap-in.

This page will display either Windows Share Security options, UNIX/Linux Share Security options, or both Windows and UNIX/Linux options depending on which shared folder types you previously selected on the Choose Shared Folder types page.

For Windows Share Security:

1. For Windows Share Security, select a permission level. Users can have read/write permissions (full control), read-only, or no access.

2. For UNIX/Linux Share Security, select the Allow anonymous access check box to allow anonymous access with the default user identifer (UID) and group identifier (GID) of 2. Select the level of anonymous access (No Access, Read-Only, or Read-Write) from the Type of access list. Select Allow root access only if you want a UNIX/Linux root user on an NFS client to have Administrator access to the share.

3. Click Next to open the Storage Allocation page (see “Allocating space for components”

(page 17)).

Using the Create a Shared Folder Wizard 13

Using the Host a SQL Server Database Wizard

The Host a SQL Server Database Wizard automatically discovers the servers that host SQL Server and SQL Server databases on your domain, and helps you allocate and configure storage space for each database component you select:

• Data file—Contains pointers to database files, storage for system tables and objects, and

storage for database data and objects.

• Log file—Holds all the transaction log information for the database. Every database has exactly

one log file, which cannot be used to hold any other data.

Before you begin configuring storage for SQL Server

• Make sure the ASM agent is installed on each server with SQL Server data you plan to host.

• Make sure you have a current backup of your SQL Server data and logs.

Accessing the Host a SQL Server Database Wizard

1. In the Actions pane, select Host a SQL Server Database.

The Host a SQL Server Database Wizard welcome page opens.

2. Click Next to open the Select a SQL Server page (see “Selecting a server that hosts SQL Server”

(page 14)).

Selecting a server that hosts SQL Server

Use the Select a SQL Server page to select one of the servers that hosts SQL Server discovered on your domain by the wizard.

1. Do one of the following:

• Enter the host name of a server that hosts SQL (exactly as it is registered in the domain).

• Enter the IP address (IPv4) of a server that hosts SQL.

2. Click Next to open the Select Database Components page (see “Selecting SQL Server database

components” (page 14)).

Selecting SQL Server database components

Use the Select Database Components page to select the SQL Server database and database components you want to host on your HP Storage System.

14 Hosting storage for applications and shared folders

1. Do one of the following:

• Select all components (including all of its components) by checking the box next to the

component.

• Select individual database components by expanding the list and checking the boxes

next to the components.

You must select all the database components, including the log file, in a database if you want to run backups and/or take snapshots of the database using ASM.

NOTE: ASM cannot migrate system databases; for example, ASM cannot migrate master,

model, msdb and tempdb.

The following table lists the action ASM can perform for each database component listed.

Table 4 Selecting database components to host

DescriptionAction

None

Allocate Space, Move Data

None, Already Managed

Component's check box is not selected, so ASM will not perform any action. Select check box to change action.

Storage space will be allocated and configured on your HP Storage System. Component's data will be migrated to your HP Storage System.

Component's data is already hosted on your HP Storage System and already managed by ASM. No action is possible.

2. To view the properties for a database component, select the database component name and then click Properties.

See Data file properties and Log file properties for database for descriptions of the properties displayed.

3. If you do not want ASM to delete the original files for the selected database components from the server that hosts SQL Server after it migrates the data to your HP Storage System, clear the Delete original files after successful migration checkbox.

4. When you are done, click Next to open the Select the Database Workload Type page (see

“Selecting a database workload type” (page 15)).

Selecting a database workload type

Use the Select the Database Workload Type page to select the workload type for the SQL Server database.

NOTE: You can only select the database workload type while using the Host a SQL Server

Database Wizard. The database workload type cannot be changed later.

1. Do one of the following:

• Select Transaction processing (TP) for frequently updated, fast growing databases with

large volumes of data requiring concurrent user access.

• Select Decision support systems (DSS) for databases designed to handle queries on large

amounts of data, typically used for data-mining applications.

2. When you are done, click Next to open the Storage Allocation page (see “Allocating space

for components” (page 17)).

Using the Host a User-Defined Application Wizard

This wizard helps you set up your HP Storage System to store application data for various applications. Storage is allocated for the application, optionally exposed to another server using the iSCSI protocol, and an NTFS file volume may be optionally created on the remote application

Using the Host a User-Defined Application Wizard 15

server. Upon completion, you can monitor and manage storage for the application through the Automated Storage Manager.

After storage is allocated and configured on your HP Storage System for a remote application using the Host a User-Defined Application Wizard, do the following:

• Manually migrate the remote application's data to your HP Storage System. See “Migrating

user-defined application data from a remote application” (page 25) for more information.

• Configure the remote application to store its data on the iSCSI LUN exported by ASM to the

application server as described in the application's documentation.

Before you begin configuring storage for a user-defined application

• Make sure the ASM agent is installed on each application server with data you plan to host.

• Make sure you have a current backup of your remote application data and logs.

• For an iSCSI LUN application, you will need the iSCSI Qualified Name (IQN).

NOTE: For a remote Windows application, you need to know the path to the iSCSI LUN on the

application server to configure the remote application to store data on the iSCSI LUN. The path to the iSCSI LUN is displayed on the application's Properties window on the Storage tab.

To access the Host a User-Defined Application Wizard

1. In the Actions pane, select Host a User-Defined Application.

The Host a User-Defined Application Wizard welcome page opens.

2. Click Next to open the Choose type of Application page (see “Choose type of application”

(page 16)).

Choose type of application

1. Select the type of application for hosting a user-defined application:

• Remote Windows Application: ASM will provision storage for the application and expose the storage to the given server as an NTFS volume over the iSCSI protocol. This is the recommended option for most scenarios. The Automated Storage Manager agent must be installed on the application server to use this option.

• iSCSI LUN: Exposes a LUN to the remote server so the server can store data on the LUN. You will need to install an iSCSI initiator on your host server. Storage is provisioned for these applications.

NOTE: A valid iSCSI Qualified Name (IQN) is required to host a user-defined application

as an iSCSI LUN. IP addresses are not valid IQNs. If you enter a temporary IQN (such as an IP address) in the iSCSI Qualified Name (IQN) field, you must manually configure the iSCSI Target using the Microsoft iSCSI Software Target management console in order for ASM to discover and assign the application server to the iSCSI LUN.

• Local storage only: Creates a volume on your HP Storage System. Storage is provisioned for these applications.

2. Click Next to open the Enter an Application Name page (see “ Entering an application name”

(page 17)).

When hosting a user-defined application as an iSCSI LUN, the volume presented is not automatically initialized with NTFS and mounted. This is because the iSCSI LUN could be presented to a non-Windows server. After completing the wizard, you must manually initialize and mount the volume.

16 Hosting storage for applications and shared folders

Entering an application name

Use the Enter an Application Name page to enter a name for the application. This name will be used anywhere the application is referenced in ASM, so it must be a unique name.

1. Enter a name for the application.

2. When you are done, click Next to open the Storage Allocation page (see “Allocating space

for components” (page 17)).

Using the Create a Virtual Library Wizard

This wizard helps you create a virtual library for disk-to-disk backup of other client or servers to your HP Storage System and manage the storage for the virtual library through ASM. Install Data Protector Express on additional servers you need to backup. See “Installing Data Protector Express

on other machines” (page 32) for more information.

Accessing the Virtual Library Wizard

To access the Create a Virtual Library Wizard

1. In the Actions pane, select Create a Virtual Library.

The Create a Virtual Library welcome page opens.

2. Click Next to open the Configure virtual library page (see “Configure your virtual library”

(page 17)).

Configure your virtual library

To configure your virtual library, do the following:

1. In the name dialog box, type a name for your virtual library.

2. In the Number of slots field, type or use the arrows to indicate how many slots are needed

for your virtual library.

3. When you are done, click Next to open the Storage Allocation page (see “Allocating space

for components” (page 17)).

NOTE: The number of slots needed for your virtual library will depend on the media rotation

type chosen for the backups that will use the virtual library. The number of slots must be high enough to support the rotation type you intend to use for scheduling backups to this virtual library. See Planning for Media Rotation in the Data Protector Express User's Guide and Technical Reference for more information.

Allocating space for components

Use the Storage Allocation page in the wizards to specify the allocated space size and advanced configuration settings for each application component or shared folder listed. Default values are provided.

Using the Create a Virtual Library Wizard 17

+ 38 hidden pages
