QuickSpecs
HP USB Keyboard
Overview
c04111508 — 14382 — Worldwide — Version 5 — July 10, 2015
Page 1
HP USB Keyboard
Models
HP USB Keyboard
QY776AA
Introduction
The new HP USB Keyboard features an impressively durable design built for ease of use and everyday business computing.
Key Benefits
Adjustable to 0° or 6° slopes with tilt legs to suit a variety of typing preferences.
Built for durability and heavy usage, including a lifecycle rating up to 20 million keystrokes.
Minimize damage from minor spills with the integrated spill-drain feature.
Expect a fast set-up with quick and easy deployment for your IT atmosphere.
Compatibility
The HP USB Keyboard is compatible with the HP Compaq 4300 Pro AIO, Z230 Tower Workstation, Z230 SFF Workstation, Z420
Workstation, Z620 Workstation, Z820 Workstation, Z1 AiO Workstation, Z1 G2 AiO Workstation, Z440 Workstation, Z640
Workstation, Z840 Workstation
NOTE: Not all models are available in all regions.
Service and Support
Your Option Limited Warranty is a one (1) year (HP Option Limited Warranty Period) parts replacement warranty on any HPbranded or Compaq-branded options (HP Options). If your HP Option is installed in an HP Hardware Product, HP may provide
warranty service either for the HP Option Limited Warranty Period or the remaining Limited Warranty Period of the HP Hardware
Product in which the HP Option is being installed, whichever period is the longer but not to exceed three (3) years from the date
you purchased the HP Option.
QuickSpecs
HP USB Keyboard
Technical Specifications
c04111508 — 14382 — Worldwide — Version 5 — July 10, 2015
Page 2
HP USB Keyboard
Physical characteristics
Keys
104, 105, 106, 107, 109 layout (depending upon country)
Dimensions
(L x W x H)
18.12 x 6.47 x 0.96 in (46.03 x 16.43 x 2.44 cm)
Weight
2 lb (0.9 kg) minimum
Electrical
Operating voltage
+ 5VDC ± 5%
Power consumption
50-mA maximum (with three LEDs ON)
System interface
USB Type A plug connector
ESD
CE level 4, 15-kV air discharge
EMI - RFI
Conforms to FCC rules for a Class B computing device
Microsoft® PC 99 – 2001
Functionally compliant
Mechanical
Keycaps
Low-profile design
Switch actuation
55-g nominal peak force with tactile feedback
Switch life
20 million keystrokes (using Hasco modified tester)
Switch type
Contamination-resistant switch membrane
Key-leveling mechanisms
For all double-wide and greater-length keys
Cable length
6 ft (1.8 m)
Microsoft PC 99 – 2001
Mechanically compliant
Acoustics
43-dBA maximum sound pressure level
Environmental
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating
temperature
–22° to 140° F (–30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
Operating shock
40 g, six surfaces
Non-operating shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating vibration
4-g peak acceleration
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Drop (in box)
30 in (76.2 cm) on concrete, 16-drop sequence
Operating system
support
Windows 8 Pro, Windows 8, Windows 7 Professional, Windows 7, Windows Vista Business 64*,
Windows Vista Business 32*, Windows Vista Home Basic 32*, Windows 2000, Windows XP Professional
or Windows XP Home 32*. No driver is required for this device. Native support is provided by the
operating system.
* Certain Windows Vista product features require advanced or additional hardware. Windows Vista
Upgrade Advisor can help you determine which features of Windows Vista will run on your computer.
To download the tool, visit http://www.windowsvista.com/upgradeadvisor. For Windows Vista system
requirements, visit http://www.windowsvista.com/systemrequirements.
Approvals
UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, KC
Ergonomic compliance
ANSI HFS 100, ISO 9241-4, and TUVGS
Kit contents
Keyboard, installation guide, warranty card, safety and comfort guide
