The HP 20/40-GB DAT 8 Cassette Autoloader includes an integrated DDS-4 DAT Drive and changer mechanism with convenient access to an eight
cassette magazine, allowing you to develop a media management tape rotation scheme for scheduled backups of servers 40 GB or less.
Models
20/40-GB DAT DDS-4 8 Cassette Autoloader (Internal)
166504-B21
20/40-GB DAT DDS-4 8 Cassette Autoloader (External)
166505-001
QuickSpecs
HP StorageWorks 20/40-GB DAT DDS-4 8 Cassette
Autoloader
Overview
DA - 10518 Worldwide — Version 16 — October 22, 2003
Page 1
Industry Standard
DDS-4
The DDS-4 technology has a drum rotation speed of 8,503 rpm while the tape moves at 11.6 mm/s. Features of the
format allow a linear bit density greater than DDS-3, which increases transfer rate and capacity.
Investment Protection
The 20/40-GB DAT autoloader uses a compatibility mode to read and write DDS-1, DDS-2, DDS-3 and DDS-4 tapes.
This offers investment protection for users who have standardized with the DAT technology. Users will also have
the ability to restore archived media from previous backups and interchange with previously shipping DDS-3 6 and 8
cassette Autoloader drives.
Lowers TCO with
Automation
Automated DAT backup systems offer lower total cost of ownership with a higher storage capacity and
performance than a stand alone tape backup drive and is targeted at the price sensitive environments.
Operating Environment
Support
Microsoft® Windows®
NT®/2000
Supported on NT v4.0 with VERITAS Backup Exec v7.3 for NT and CA ARCserveIT
v6.61 for NT. Both software packages require optional autoloader modules. Dantz
Retrospect v5.6 for NT/2000 (Server Version).
Novell NetWare v4.x & 5.x
Supported on NetWare v4.x and 5.x with VERITAS Backup Exec v8.5 for NetWare
and CA ARCserveIT v6.61 for NetWare. Both software packages require optional
autoloader modules.
Software Support
VERITAS Backup Exec v8.6 for NT
VERITAS Backup Exec v8.5 for NetWare
Computer Associates ARCserve v7.0 for NT
Computer Associates ARCserve v7.0 for NetWare
Computer Associates ARCserve 2000 for 2000
Dantz Retrospect Backup v5.x
Option Kit Contents
20/40-GB DAT DDS-4 8
Cassette Autoloader
Internal
20/40-GB DAT drive with loader mechanism
Documentation
8 Cassette Magazine
1 Data Cassette and 1 Cleaning Cassette
20/40-GB DAT DDS-4 8
Cassette Autoloader
External
20/40-GB DAT drive with loader mechanism in an enclosure
Documentation
8 Cassette Magazine
1 Data Cassette and 1 Cleaning Cassette
Power Cord
External LVD SCSI Cable
Rackmount Tape Options
Supported on StorageWorks 3U Rackmount Kit by Compaq. Allows customer to install up to 2 internal DAT
AutoLoaders in a 3U rackmount space. Standard configuration provides two internal SCSI buses (channels)
supporting 1 DAT AutoLoader per bus. Please refer to "Rackmount Tape Drive Kits" QuickSpec for further
information.
Qualified with HP's Data
Protection Suite for Tape
Utilities
Complete set of Data Protection Tools focused on simplifying the process of configuring, implementing, and
maintaining a data protection strategy. Includes software applications such as Tape Storage Management Console
and Insight Manager, as well as product information tools including technology White Papers, Service Advisories,
and the Storage Products CD. For information on the Data Protection Software Suite, please check the "Related
Options" section of this QuickSpec or visit the Web site at:
http://h18000.www1.hp.com/storage/software.html
.
NOTE:
This Web site is available in English only.
QuickSpecs
HP StorageWorks 20/40-GB DAT DDS-4 8 Cassette
Autoloader
Product Highlights
DA - 10518 Worldwide — Version 16 — October 22, 2003
Page 2
Server and Tape Compatibility
ProLiant Servers
Internal
External
DL320
X
DL360G2
X
DL380
X X
DL380G2
X
DL580
X
PL8500
X
ML 330G2 X X
ML350G2
X X
ML370G2
X X
ML530G2
X X
ML570
X X
PL8000
X X
CL380
X X
CL1850
X X
NOTE:
When upgrading a Non-Hot Plug Model to Hot Plug, the purchase of the Hot Plug Cage Upgrade Option Kit (161275-B21) is required.
Host Bus Adapters and
Controllers for Intel
Based Servers
64-Bit/66-MHz Single Channel Wide Ultra3 SCSI Adapter
154457-B21,
-291
64-Bit/66-MHz Dual Channel Wide Ultra3 SCSI Adapter
129803-B21,
-291
AlphaServer and Tape Compatibility
AlphaServers
Internal
External
Alpha Server 4100
X X
AlphaServer DS10
X X
DS10L
X
AlphaServer DS20E
X X
AlphaServer ES40
X X
AlphaServer ES45
X X
GS60E
X X
GS80/160/320
X X
*
NOTE:
These platforms also have internal disk enclosures support of the hot plug option, in addition to support in external LVD enclosures.
Host Bus Adapters and
Controllers Compatibility
for AlphaServers
32-bit Single Channel UltraWide HBA
*not supported with hot plug
KZPBA-CA
32-bit Single Channel LVD LSI SYM 8952Uia HBA
SN-KZPCA-AA
32-bit Single Channel LVD SCSI LSI SYM 8952Uia HBA
3X-KZPCA-AA
32-bit Single Channel LSI SYM 8951Uia
30-56041-01
Comb SCSI/Ether Dual Channel
*not supported with hot plug
KZPCM-DA
64-bit Dual ChannelUltra 3 LVD HBA
3X/-KZPEA-DB
Combo Ultra2 SCSI/2D Video/10-100 Ethernet
3X/-DEPVZ-AA
QuickSpecs
HP StorageWorks 20/40-GB DAT DDS-4 8 Cassette
Autoloader
Compatibility
DA - 10518 Worldwide — Version 16 — October 22, 2003
Page 3
Base Configuration
Select one:
Model Description
Part Number
20/40-GB DAT Autoloader,
Internal
Contains one 8 Cassette 20/40-GB DAT autoloader, US English hard copy manual and translation
CD, Warranty card, 1 DDS-2 data cassette, 1 DAT cleaning cassette, 2-interncal cables.
166504-B21
20/40-GB DAT Autoloader,
External
Contains one 8 Cassette 20/40-GB DAT autoloader enclosed in an external housing, power
cord, SCSI terminator, 1 DDS-4 data cassette, 1 DAT cleaning cassette, external 3¢ cable,
warranty card, US English documentation with translations CD.
166505-001
Related Options
Media
HP DDS-2 8GB 120m Data Cartridge
C5707A
HP DDS-3 24GB 125m Data Cartridge
C5708A
HP DDS-4 40GB 150m Data Cartridge
NOTE:
HP DDS-4 Data Cartridge is recommended.
C5718A
HP DDS Cleaning Cartridge
C5709A
Tape Storage Software
Data Protection Software Suite
259596-B21
Rackmount Tape Options
& Cable Kits
3U Rackmount Kit, All
(Please refer to "Rackmount Tape Drive Kits" QuickSpec for further information)
274338-B21
LVD Cable Kit, 68-pin HD/VHDCI (Internal & External Cables)
168048-B21
LVD Cable Kit, 68-pin HD/68-pin HD (Internal & External Cables)
242381-B21
68-pin HD/VHDCI, 12 ft/3.66 m (External Cable only)
341177-B21
68-pin HD/68-Pin HD, 16.40 ft/ 5 m (External Cable only)
328215-001
68-pin HD/68-Pin HD, 32.81 ft/10 m (External Cable only)
328215-002
QuickSpecs
HP StorageWorks 20/40-GB DAT DDS-4 8 Cassette
Autoloader
Configuration Information
DA - 10518 Worldwide — Version 16 — October 22, 2003
Page 4
Warranty
Maximum
The remaining warranty of the server product in or onto which it is installed to a
maximum three-year limited warranty.
(Certain restrictions and exclusions apply.
Consult the Customer Support Center for details.)
Minimum
Three year parts, one year next-business day exchange
Liquid Crystal Display
(LCD)
The dot matrix front panel information display provides user-friendly information on the autoloader's operating status,
potential error conditions, current cassette and magazine status.
Recommended Maximum
Server Size
40 GB
Performance Specification
Native
Maximum
8.4 GB/hour
Typical
6.0 GB/hour
2:1 Compression
Maximum
16.8 GB/hour
Typical
15 GB/hour
NOTE:
Typically, users will be able to compress their data at a 2 to 1 ratio; however, compression ratios will vary
based on the type of data being compressed.
Cartridge Swap Time
50 seconds/average
Load Time
58 seconds/average
Unload Time
(depending on
tape type and position)
32 seconds to 160 seconds
Search Speed
45 seconds average file access for any part of a 150 meter tape
Maximum Formatted
Capacity (unattended)
8-Cassette Magazine
Without compression
160 GB
Based on typical 2:1
compression ratio
320 GB
NOTE:
Typically, users will be able to compress their data at a 2 to 1 ratio; however, compression ratios will vary
based on the type of data being compressed.
Mechanical
Measurements
Tape Width
0.15 in (0.38 cm)
Tape Length
492 ft (150 m)
Dimensions (HxWxD)
3.25 x 5.75 x 9.51 in (8.26 x 14.61 x 24.16 cm)
Weight
5.258 lb (2.4 kg)
Tape Speed
Read/Write
0.46 ips/11.6 mm/s
Head to Tape Speed
262 ips/6,670 mm/s
Rewind/Fast Forward
130 x Read/Write Speed
Tape Format
Recording Method
Helical Scan
Bytes/Group
38,4296
Data Frame/Group
22
Density/Inch
122,000
Flux Reversal/Inch
1,524,000
Track Density/Inch
2,793
Data Encoding Method
PRML
Data Transfer Rate
2.3 MB/s
Error Detection/
Correction
Reed-Solomon-3 levels
Reliability Cartridge Swaps
> 100,000
MTBF
250,000 hours at 30% duty cycle
