HP StorageWorks 1900ux, StorageWorks 1000ux, StorageWorks 2300ux User Manual

Download

User’s Guide

hp StorageWorks

1000ux/1900ux/2300ux

Optical Jukebox

First Edition (May 2004)

Part Number: AA966-90901

This guide describes procedures for operating and troubleshooting the HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox.

the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard. The information contained in this document is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.

Microsoft®, MS-DOS®, MS Windows® and Windows® are U.S. registered trademarks of Microsoft Corporation. UNIX® is a registered trademark of The Open Group. Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The

information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Hewlett-Packard Company products are set forth in the express limited warranty statements for such products. Nothing herein should be construed as constituting an additional warranty.

Printed in the U.S.A.

HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

First Edition (May 2004) Part Number: AA966-90901 Regulatory Model Number: N3620N3Z

Contents

About this Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Related documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Document conventions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Text symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Getting help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

HP technical support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

HP storage web site . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

HP authorized reseller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

1 Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Identifying panel features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Front panel features and descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Back panel features and descriptions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Using Ultra Density Optical (UDO) disks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Choosing a disk type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Labeling a disk cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Write-protecting an UDO disk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Loading a disk into the drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Maintaining UDO media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Using mixed media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Using application software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Contents

2 Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

Control panel features and descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Using selection buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Jukebox menu tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Top-level menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Second-level menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Control panel operations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

3HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Contents

Ejecting a disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Entering the administration menu password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Changing the administration menu password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Viewing the current SCSI IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Default SCSI IDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Changing the current SCSI IDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Configuring the jukebox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Setting an operating configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Retrieving log history. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Running an internal test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

3 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Troubleshooting common problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Retrieving log history. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Running an internal test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

Using HP StorageWorks Library and Tape Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

A Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Environmental specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Jukebox specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Drive specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Media specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Safety and regulatory specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

B Safety and Regulatory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Federal Communications Commission Notice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Class A Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Modifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Declaration of Conformity for products marked with the FCC logo -

United States only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Canadian Notice (Avis Canadien) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Class A Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

European Union Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

EC radio frequency interference statement (Europe only). . . . . . . . . . . . . . . . . . . . . . . . . . . 68

United Kingdom Telecommunications Act 1984. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Herstellerbescheinigung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

English translation of German sound emission directive. . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Turvallisuusyhteenveto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

4 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Contents

Laserturvallisuus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Huolto. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

English translation of Finland regulatory information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

BSMI notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Japanese Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Laser Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Laser Safety Warnings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

CDRH regulations (USA only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Compliance with International Regulations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

5HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Contents

6 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

About This

Guide

This user guide provides information to help you:

■ Operate the jukebox

■ Troubleshoot the jukebox

About this Guide

“About This Guide” topics include:

■ Related documentation, page 8

■ Conventions, page 8

■ Getting help, page 10

7HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

About this Guide

Related documentation

In addition to this guide, HP provides corresponding information:

■

HP StorageWorks Optical 1000ux/1900ux/2300ux Jukebox Setup Guide

■

HP StorageWorks Optical 1000ux/1900ux/2300ux Jukebox Getting Started Poster

Conventions

Conventions consist of the following:

■ Document conven tions

■ Text symbols

Document conventions

This document follows the conventions in Table 1.

Table 1: Document conventions

Element Convention

Cross-reference links

Key and field names, menu items, buttons, and dialogue box titles

File names, application names, and text emphasis

User input, commands and directory names, and system responses (output and messages)

Blue text:

Bold

Italics

Monospace font COMMAND NAMES

font unless they are case sensitive Variables

Web site addresses Blue underlined sans serif font text

<monospace, italic font>

(

http://www.hp.com

Figure 1

are uppercase monospace

)

8 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Text symbols

About this Guide

The following symbols may be found in the text of this guide. They have the following meanings:

WARNING: Text set off in this manner indicates that failure to follow

directions in the warning could result in bodily harm or death.

AVERTISEMENT : le non-respect de ces instructions expose l'utilisateur

à des risques potentiellement très graves.

AVVERTENZA: La mancata osservanza delle indicazioni fornite in un

messaggio così evidenziato, può provocare lesioni personali o mettere in pericolo la vita dell'utente.

VORSICHT: In dieser Form hervorgehobener Text weist darauf hin, dass die

Nichtbeachtung der Anleitungen zu Verletzungen oder zum Tod führen kann.

ADVERTENCIA: el texto con esta marca indica que si no se siguen las

instrucciones, pueden producirse lesiones corporales o incluso la muerte.

HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

About this Guide

Caution: Text set off in this manner indicates that failure to follow directions

could result in damage to equipment or data.

Note: Text set off in this manner presents commentary, sidelights, or interesting points

of information.

Getting help

If you still have a question after reading this guide, contact an HP authorized service provider or access our web site:

HP technical support

Telephone numbers for worldwide technical support are listed on the following HP web site:

http://www.h p.com

http://www.hp.com/support/

Note: For continuous quality improvement, calls may be recorded or monitored.

Be sure to have the following information available before calling:

■ Technical support registration or contract number (if applicable)

■ Product serial numbers

■ Product model names and numbers

■ Applicable error messages

■ Operating system type and revision leve l

■ Detailed, specific questions

■ HP StorageWorks Library and Tape Tools (L&TT) Support Ticket (if

applicable)

10 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

HP storage web site

The HP web site has the latest information on this product. Access storage at:

http://www .hp.com/country/us/eng/prodserv/storag e.html

select the appropriate product or solution. You can also visit

http://www.hp.com/go/udo

HP authorized reseller

For the name of your nearest HP authorized reseller:

■ In the United States, call 1-800-345-1518

■ In Canada, call 1-800-263-5868

■ Elsewhere, see the HP web site for locations and telephone numbers:

http://www.hp.com

About this Guide

. From this web site,

HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

About this Guide

12 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

This chapter describes the following:

■ Identifying panel features, page 14

■ Using Ultra Density Optical (UDO) disks, page 18

■ Using mixed media, page 24

■ Using application software, page 26

13HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

Identifying panel features

Identify the following panel features before you install the jukebox (see Figure 1 and Figure 2 on page 15).

Front panel features and descriptions

1 Control panel 2 Power switch

3 Mailslot 4 Front service access panel

Figure 1: Front panel features

■ Control panel—Used to manually control and monitor operation of the

jukebox. See the user’s guide for information on using the control panel.

■ Power switch—Turns power to the jukebox on and off. Located un der the

panel through an access hole.

■ Mailslot—Used to insert and remove disks from the jukebox.

■ Front service access panel—A panel for service access that should only be

removed by qualified personnel.

14 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Back panel features and descriptions

Operations

1 Active bus indicator 2 SCSI ports

3 Power receptacle 4 Back access panel

Figure 2: Back panel features

■ Active bus indicator—Lit when the SCSI bus is active.

■ SCSI ports—68-pin high-density SCSI connectors (Micro D-type). Used for

attaching the SCSI cable from the jukebox to the host computer. One port must have a SCSI cable connected, and the other must have a SCSI terminator connected to it.

■ Power receptacle—Used for connecting the power cord to the jukebox.

Located on the bottom of the power distribution assembly.

■ Back access panel—Covers the interface aseembly (1, 2 and 3 in Figure 2).

This panel is removed by pushing up on the panel (from the bottom) and then pulling the panel out and away from the jukebox.

15HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

WARNING: TThis product can only be used with an HP approved power cord

for your specific geographic region. Use of a non-HP approved power cord may result in: 1) noncompliance with individual, country-specific safety requirements; 2) insufficient conductor ampacity that could result in overheating with potential personal injury and/or property damage; and 3) a fractured power cord, which could cause the internal contacts to be exposed, which potentially could subject the user to a shock hazard. HP disclaims all liability when HP-approved power cords are not used.

AVERTISEMENT : ce produit ne peut être utilisé qu'avec un cordon

d'alimentation approuvé par HP pour votre zone géographique. L'utilisation d'un cordon d'alimentation non approuvé par HP vous expose à ce qui suit :

1) non-conformité aux spécifications de sécurité du pays concerné ;

2) intensité admissible du conducteur insuffisante pouvant provoquer une surchauffe créant un risque de blessure ou d'endommagement du produit ; et 3) rupture de cordon pouvant exposer les contacts internes et créer un risque d'électrocution pour l'utilisateur. HP décline toute responsabilité en cas d'utilisation d'un cordon d'alimentation non approuvé.

AVVERTENZA: È possibile utilizzare questo prodotto solo con un cavo di

alimentazione approvato da HP specifico per il paese di utilizzo. L'utilizzo di cavi di alimentazione non approvati da HP può produrre: 1) non conformità ai requisiti di sicurezza specifici del paese di utilizzo; 2) amperaggio del conduttore insufficiente con conseguente surriscaldamento e potenziale rischio di lesioni a persone e/o cose; 3) rottura del cavo di alimentazione con conseguente esposizione dei contatti interni e potenziale rischio di scosse elettriche per l'utente. HP declina qualsiasi responsabilità in caso di utilizzo di cavi di alimentazione non approvati da HP.

16 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

VORSICHT: Dieses Produkt darf ausschließlich mit einem von HP für die

Verwendung in Ihrem Land zugelassenen Netzkabel verwendet werden. Die Verwendung eines nicht von HP zugelassenen Netzkabels kann folgende Konsequenzen haben: 1) Nichteinhaltung spezifischer, nationaler Sicherheitsbestimmungen; 2) Überschreiten der Strombelastbarkeit des Netzkabels, was zu einer Überhitzung und in der Folge zu Verletzungen und/oder Sachschäden führen kann; 3) Stromschlaggefahr durch offen liegende Adern bei Kabelbruch. Für den Fall, dass nicht von HP zugelassene Netzkabel verwendet werden, übernimmt HP keinerlei Haftung.

ADVERTENCIA: este producto sólo puede utilizarse con un cable de

alimentación aprobado por HP para su región geográfica específica. El uso de un cable de alimentación no aprobado por HP puede provocar lo siguiente: 1) el incumplimiento de requisitos de seguridad individuales y específicos del país; 2) insuficiente corriente permanente admisible de conductor que puede provocar un sobrecalentamiento y posibles lesiones personales o daños a la propiedad; y 3) un cable de alimentación puede romperse y exponer los contactos internos, lo que supone un peligro potencial de descarga eléctrica para el usuario. HP renuncia a toda responsabilidad en caso de utilizarse cables de alimentación no aprobados por HP.

17HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

Using Ultra Density Optical (UDO) disks

UDO media is an integral part of the storage process. This section describes the following:

■ Choosing a disk type, page 18

■ Labeling a disk cartridge, page 19

■ Write-protecting an UDO disk, page 20

■ Maintaining UDO media, page 22

Note: For UDO media specifications, see “Media specifications” on page 63.

Choosing a disk type

Two disk types can be used in the jukebox.

Table 2: UDO disk types

Disk Type Description HP Part Number

Rewritable Designed for virtually

unlimited read and write cycles

Write once, ready many times (WORM)

Designed for permanent storage of data that cannot be altered or erased

Q2031A

Q2030A

T o order HP UDO media, contact your local HP Au thorized Reseller or b uy online from

http://www .hp.com/go/storagemedia

18 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Labeling a disk cartridge

Make it a practice to label your UDO disk cartridges. Adhesive labels come with each UDO disk for this purpose (see Figure 3).

Caution: In order to avoid damaging the drives and media:

Only apply labels to the areas designated in Figure 3. Never place labels over the disk cartridge shutter or open the shutter for any reason.

Make sure the media is free of moisture and that all label corners are securely fastened to the media shell.

Do not use disks with loosely attached labels.

Do not use disks with multiple labels applied. Always remove old labels before applying new ones.

Operations

Figure 3: Labeling an UDO disk

19HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

Write-protecting an UDO disk

Each side of an UDO disk can be write-protected. With rewritable disks, this prev ents existing f iles from being altered or erased, and

new files from being written to the disk. With WORM disks, existing files cannot be altered or erased regardless of whether

or not the disks have been write-protected. However, write-protecting a WORM disk prevents additional files from being written to the disk.

To write-protect an UDO disk, slide the red write-protect switch to the left, as indicated by the arrow on the cartridge (see Figure 4).

Write-protect switch

Figure 4: Write-protecting an UDO disk

20 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Loading a disk into the drive

Note: Label all disks before loading them into the jukebox. Some application software

packages require that you load and eject disks by using instructions in the software. If you use a software application to manage files in the jukebox, check the software documentation before proceeding with these steps.

1. Start with READY, or LOAD *displaying on the control panel.

2. Load UDO media into the drive by inserting the disk gently b ut firmly into the mailslot, shutter end first, and with the side you w ant to access facing up (A or B). See Figure 5.

An incorrectly inserted disk will be rejected with CART IN WRONG displaying briefly.

Operations

Figure 5: Loading media

3. LOAD SLOT # will display, with # flashing to indicate the number of the first available storage slot in the jukebox. To select this storage slot number, press LOAD or ENTER. To choose a different storage slot, press NEXT or PREV until the desired slot number displays, and then press ENTER.

4. LOADING displays as the jukebox moves the disk to a slot. After the disk is loaded into the storage slot, LOAD * displays. You can now load additional disks by inserting them into the mailslot and repeating step 3 until you are finished loading disks.

21HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

5. Press CANCEL to return to the READY state.

Maintaining UDO media

Follow these guidelines to ensure that your UDO disks remain in good condition.

■ Do not open the disk’s shutter and touch the disk surface.

■ Do not store the disk in a dusty location.

■ Do not store the disk in temperatures outside of 5ºC to 55ºC (41ºF to 122ºF).

■ Do not disassemble the disk.

22 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

■ Do not expose the disk to direct sunlight.

■ Do not drop the disk.

Operations

23HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

Using mixed media

Mixed media refers to the option to backup to more than one drive type, such as MO and UDO, within the same physical jukebox.

General considerations when using mixed media are as follows:

■ Some independent software vendor application packages do not support

mixed media. Consult your software pro vider to verify that your con figuration is supported.

■ The proper version of HP StorageWorks Library and Tape Tools (L&TT) is

required for diagnostic support. Please see the online quick specs of HP L&TT for the most up to date information. They can be found at the follo wing web address.

http://www.hp.com/support/lttcompatibility

■ When loading media into a mixed media unit, the media will first be moved to

a media test station, where its drive co mpatibility can be determined, then it will be moved to its final destination. This drive compatibility information is reported over SCSI to the application software to identify which disks are compatible with the installed drives.

■ In the TEST* control panel menu, an additional test called MEDIA TEST is

available that will move all of the disks in the unit (except those in drives) to the media test station, then back to their original locations. This test can take about 15 minutes in a fully loaded unit. This test can be used to establish the drive compatibility of all of the disks in the unit if this information is thought to be incorrect. This should only be necessary if disks have been moved around by hand (during service, for example). During normal operation the jukebox will automatically keep track of this information.

■ When a disk inventory occurs (by selecting the INIT ELEM STATUS front

panel command, or through a SCSI command) any disks that are found in the unit that have an unkno wn type will be mo v ed into the media test station, then back to their original location to determine their drive compatibility. Again, this should only occur if disks are inserted by hand (during service) rather than through the mailslot. When firmware is downloaded into the jukebox controller, an initial inventory will occur automatically, and all of the disks will be checked for their drive compatibility type.

24 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

■ Some of the front panel tests will work differently and have different initial

requirements in a mixed media unit. For example, the DRIVE IO test will require disks of both types in the unit and will only be able to load disks into drives of the same type.

■ MO drives can only accept a SCSI address from 0 to 7.

25HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Operations

Using application software

Note: While HP-UX does provide native file system support for UDO media, this

support is only for rewritable UDO media. Refer to the “Configuration” chapter in the

HP StorageWorks 1000ux/1900ux/2300ux Jukebox Setup Guide

this product for more information.

The HP StorageWorks 1000ux/1900ux/2300ux Jukebox supports a variety of off-the-shelf software packages to manage your storage operations. For the latest information on which application software packages are compatible with this product, visit

http://www.hp.com/go/udo

that shipped with

26 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

This chapter describes the following:

■ Control panel features and descriptions, page 28

■ Jukebox menu tree, page 30

■ Control panel operations, page 33

27HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Control panel features and descriptions

The control panel enables manual control of all jukebox operations using four buttons and an LED display. The SCSI IDs of the jukebox and its optical drives can be set and changed, disks may be loaded and ejected, configurations can be monitored and changed, performance information can be viewed, internal tests can be run, and the jukebox can be secured from unauthorized use. See Figure 6

1 Swivel feature 2 Activity light 3 16-character display 4 Selection buttons

Figure 6: Control panel features

■ Swivel feature—The control panel assembly can be rotated either right or left.

■ Activity light—Lights up differently to indicate status:

— Steady green—Power is on. — Flashing green—A drive is being accessed. — Amber—A fault occurred.

■ 16-character display—Shows information about the current operation.

28 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

■ Selection buttons—Press to perform the operations:

— CANCEL cancels the current operation or menu selection. — PREV scrolls the display choice backwards by one. — NEXT scrolls the display choice forward by one. — ENTER selects the displayed choice.

Using selection buttons

Use the CANCEL, PREV, NEXT, and ENTER buttons to select tasks you want the jukebox to perform. Each time you push the NEXT or PREV button, a task choice appears. An “*” indicates that there is a menu beneath that choice, which you can access by pressing the ENTER button.

Tip: To scroll through the menu options more quickly, push and hold the NEXT or PREV

button.

Navigation

You can return to READY at any time by pressing CANCEL. In some cases, you may need to press CANCEL more than once.

29HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Jukebox menu tree

Figure 7 provides an overview of the jukebox menu tree.

READY

PREV/NEXT PREV/NEXT PREV/NEXT

ADMIN*

ENTER

LOAD* EJECT*

TEST*

(service use)

EXCHANGE DEMO INIT MECHANICS INIT ELEM STATUS MAGAZINE IO DRIVE IO MAILSLOT IO VERTICAL TEST TRANSLATE TEST FLIP TEST PICKER TEST FIND PLUNGE HOME FINF VERT HOME FIND XLATE HOME

PREV/NEXT

VERTICAL ENCODER EMPTY DRIVES EMPTY PICKER FILL PICKER EXERCISE MECH WELLNESS TEST CLEAR SOFT LOG CLEAR HARD LOG PLUNGE FULL SPD PLUNGE 1/2 SPD PLUNGE 1/4 SPD MAILSLOT SENSORS STARWARS BOTTOM THUMB TOP THUMB TRANSLATE SENSOR

PSWD 000 000 000

ENTER

PREV/NEXT

INFO*

REVISION JUKEBOX*

PRODUCT # SN ### FWTYPE xxx DRIVES # SLOTS ##

JKBX ODOMETERS* HOURS MOVES FLIPS XLATES ROTATES

DRIVE LOADS* DRIVE #

• DRIVE FW*

D# REV x.

• DRIVE SN*

D# ####

• HARD ERRORS*

HARDWARE ERR # FRU 1-3 # MOTION <NAME> SOURCE# DESTINATION 1 # DESTINATION 2 # ODOMETER # MICROMOVE 1-6 # MICRONOVE ER # TOP/BOTTOM PICKER NORTH/SOUTH THUMB

SOFT ERRORS* (same logs available as under "HARD ERRORS") RECOVERY ERRORS* (same logs available as under "HARD ERRORS")

LOAD SLOT # EJECT SLOT #

PREV/NEXT

CONFIG* SCSI IDS*

RECOVERY ON/OFF RESTORE DEFAULTS CLEAR ODOMETERS DUAL PICKER ON/OFF STARWARS ON/OFF NEW PASSWORD SCSI LOG ON/OFF SECURE ON/OFF SECURE MAIL OUT/IN POWER SECURE

ON/OFF REP RECOVERED

ON/OFF CONF40 ON/OFF

JKBX ID # DRV 1 ID # DRV 2 ID # . . . UPDATE

PREV/NEXTPREV/NEXT

ENTERENTER

Figure 7: Jukebox menu tree

30 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Top-level menus

The jukebox has four top-level menus.

READY Indicates that jukebox is ready for operation. ADMIN * Provides access to second-level menu choices. A

LOAD * Used to load disks into the jukebox mailslot. EJECT * Used to eject disks from the jukebox mailslot.

Navigation

password is needed to access these choices.

Note: A default password of “000 000 000” is set at the

factory.

Note: An “*” indicates that there are multiple choices available for the displayed menu

item. When an item is flashing, press ENTER to select it, or PREV or NEXT to display additional choices.

Second-level menus

The jukebox has four second-level menus.

TEST * Runs internal tests.

INFO * Retrieves performance information stored in the

CONFIG * Customizes the way the jukebox functions. SCSI IDs * Displays SCSI IDs and allows you to change them.

Note: Internal tests should primarily be run by service

personnel. Only run a test when your service representative requests that you do.

jukebox logs.

31HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Note: An “*” indicates that there are multiple choices available for the displayed menu

item. When an item is flashing, press ENTER to select it, or PREV or NEXT to display additional choices.

32 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Control panel operations

The following operations can be performed from the jukebox control panel:

■ Ejecting a disk, page 33

■ Entering the administration menu password, page 34

■ Changing the administration menu password, page 35

■ Viewing the current SCSI IDs, p age 36

■ Configuring the jukebox, page 37

■ Setting an operating configuration, page 39

■ Retrieving log history, page 40

■ Running an internal test, page 44

Note: For information on loading a disk, see “Loading a disk into the drive” on

page 21.

Navigation

Ejecting a disk

Note: Some application software packages require that you load and eject disks by

following the instructions in the software. If you use application software to manage files in the jukebox, check the software documentation before proceeding with these steps.

1. With READY displaying on the control panel, press NEXT until EJECT *

2. EJECT SLOT # displays, with the “#” flashing to indicate the first storage

displays, and then press ENTER.

slot in the jukebox that contains a disk.

■ To select the stora ge slot number that shows in the display, press

ENTER.

■ T o choose a different storage slot, press NEXT or PREV until the desired

slot number displays, and then press ENTER.

EJECTING displays as the jukebox mov es the disk to the mailslot. When the disk is in the mailslot, the display returns to EJECT SLOT #.

33HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

3. Remove the disk from the mailslot. You can now eject additional disks by pressing ENTER and then following

step 1 through step 3 until you are finished ejecting the disks.

Note: When the last disk is ejected, EMPTY displays briefly before returning to

EJECT *.

4. Press CANCEL to return to the READY state.

Entering the administration menu password

READY > ADMIN* > PSWD 000 000 000

A nine digit numeric password is required to access menu choices beneath the ADMIN* menu of the jukebox. The juk ebox ships with a f act ory def ault passw ord setting of 000 000 000.

Note: To change the administration menu password, see “Changing the administration

menu password” on page 35.

To access administration menu options using the factory default password:

1. With READY displaying on the control panel, press NEXT until ADMIN* displays.

2. Press ENTER. PSWD 000 000 000 displays and the first set of three zeros flashes.

■ If the default password 000 000 000 is still in effect, you can accept this

password by pressing ENTER three times (once for each set of three zeros). TEST* displays, indicating that the password was accepted. You are now in the menu tree below ADMIN*.

■ If you have already changed the password from the factory setting, then

continue with the following steps.

3. Press NEXT or PREV until the first number of your password displays and then press ENTER. The middle set of three zeros flashes.

4. Press NEXT or PREV until the second number of your password displays and then press ENTER. The third set of three zeros flashes.

34 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

5. Press NEXT or PREV until the third number of your password displays and then press ENTER. TEST * displays, indicating that the password was accepted. You are now in the menu tree below ADMIN*.

Changing the administration menu password

READY > ADMIN* > PSWD 000 000 000 >CONFIG*

To protect the system from unauthorized access, change the password from the factory default setting:

1. With READY displaying on the control panel, press NEXT until ADMIN* displays, then press ENTER and enter the password.

2. TEST * displays, indicating that the password was accepted. Press NEXT until CONFIG * displays and then press ENTER.

3. Press NEXT or PREV or until NEW PASSWORD displays and then press ENTER.

4. NEW 000 000 000 displays and the first set of three zeros flashes. Press NEXT or PREV until the new number you want to assign to the first part of the password displays and then press ENTER. The second set of three zeros flashes.

Navigation

5. Press NEXT or PREV until the ne w number you want to assign to the second part of the password displays and then press ENTER. The third set of three zeros flashes.

6. Press NEXT or PREV until the new number you want to assign to the third part of the password displays and then press ENTER.

7. PASSWORD CHANGED displays. Press CANCEL three times to return to READY.

8. Power off the jukebox, then power it back on to save the password to the jukebox flash ROM.

Note: Be sure to document your new password. If you forget it, contact your service

representative to reset the security code to the factory default.

35HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Viewing the current SCSI IDs

READY > ADMIN* > SCSI IDS > VIEW IDS >

To view current SCSI IDs:

1. With READY displaying on the control panel, press NEXT until ADMIN* displays and then press ENTER.

2. Enter the administration password (see “Entering the administration menu

password” on page 34).

3. Press NEXT until SCSI IDS displays and then press ENTER.

4. JKBX ID yy or DRIVE xx ID yy is displayed. Press NEXT or PREV to scroll through the current SCSI IDs.

5. Press CANCEL to exit.

Default SCSI IDs

Table 3 lists the default SCSI IDs for the jukebox and drives

Table 3: Default SCSI IDs

Bus 1 ID

Jukebox 6 Drive 1 5 Drive 2 4 Drive 3 3 Drive 4 2

36 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Changing the current SCSI IDs

READY > ADMIN* > SCSI IDS >

To change the SCSI IDs:

1. Follow the instruction in “Viewing the current SCSI IDs” on page 36 until the list of SCSI IDs is displayed.

2. Press NEXT until the setting you want to change displays, and then press ENTER. The ID begins flashing.

3. Press NEXT or PREV until the new ID that you w ant displays and then press ENTER.

4. Repeat step 2 and step 3 until you have changed all the IDs that need to be updated.

5. Press NEXT until UPDATE displays, and then press ENTER.

6. UPDATE or WAIT FOR UPDATE and then IDS SAVED displays briefly. — If the new settings do not conflict with other SCSI IDs on the b us, SCSI

IDS displays.

Navigation

— If the new settings conflict with other IDs on the SCSI bus,

CONFLICT-ABORTED displays briefly and then VIEW IDS displays. Any changes entered are lost, and you must repeat the above steps to set a new ID.

7. Press CANCEL until READY displays.

8. Power off the jukebox and then power it back on to save the IDs to the jukebox flash ROM.

Configuring the jukebox

You can set configurations to customize the way the jukebox operates. Table 5 lists the jukebox configuration options.

37HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Table 5: Configuration options

Configuration Name Description Default

RECOVERY ON/OFF Toggles between ON and OFF. If the configuration is set

RECOVERY ON

to ON, the jukebox attempts to recover from errors; if the configuration is set to OFF, the jukebox immediately stops moving if an error condition occurs. The default configuration is RECOVERY ON, and recovery should remain ON under normal conditions.

RESTORE DEFAULTS Sets all jukebox configurations to default settings. NA CLEAR ODOMETERS Sets all jukebox odometers to zero.

Note: Used by service personnel only.

DUAL PICKER ON/OFF

Toggles between ON and OFF. (The default setting is DUAL PICKER ON, and dual picker mode should

DUAL PICKER ON

remain ON under normal conditions.) If the configuration is set to ON, the jukebox runs with dual picker (disk transport) addressing ON; if the configuration is set to OFF, the jukebox runs with dual picker (disk transport) addressing OFF.

STARWARS ON/OFF Should be set to ON during normal operation. Toggles

STARWARS ON

between ON and OFF. The ON configuration enables the vertical sensors; the OFF configuration disables the vertical sensors.

Note: Used by service personnel only.

NEW PASSWORD Allows you to change the numerical password required

000-000-000

to access the menu choices under the ADMIN* menu on the jukebox control panel.

SCSI LOG ON/OFF Should be set to OFF during normal operation. Toggles

between ON and OFF. Tracks internal SCSI states and

SCSI LOG OFF

saves the information to a log.

Note: Used by service personnel only.

SECURE MS ON/OFF Toggles between ON and OFF. The ON configuration

disables

configuration

38 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

loading and ejecting disks. The OFF

enables

loading and ejecting disks.

SECURE MS OFF

Navigation

Configuration Name Description Default

SECURE MAIL OUT/IN

POWER SECURE ON/OFF

REP RECOVERED ON/OFF

CONF40 ON/OFF

Toggles between OUT and IN. Determines the orientation of the mailslot when the SECURE configuration is set to IN. When set to OUT, the mailslot remains in its normal orientation. When set to IN, the mailslot rotates in, making it inaccessible.

Toggles between ON and OFF. The ON configuration retains your selection of the SECURE MS configuration through power cycling (or power outage). The OFF configuration allows the jukebox to return to the default setting of this configuration after a power cycling.

Toggles between ON and OFF. When set to ON, recovered errors are reported; when set to OFF, recovered errors are not reported.

Caution: Changing this configuration may

result in a service call. Used by service personnel only.

Setting an operating configuration

READY > ADMIN* > CONFIG*

OUT

POWER SECURE OFF

REP RECOVERED ON

To set an operating configuration:

1. With READY displaying on the control panel, press NEXT until ADMIN* displays.

2. Enter the administration password (see “Entering the administration menu

password” on page 34).

3. TEST* displays. Press NEXT until CONFIG* displays and then press ENTER.

4. Press NEXT or PREV until the name of the configuration you want to set displays and then press ENTER.

If the configuration has multiple settings, the current setting flashes. Proceed to step 5. Otherwise, the configuration is set and a confirmation message displays.

39HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

5. If the current configuration setting is flashing, press NEXT or PREV until the desired setting displays, and then press ENTER. OPTION SAVED displays and then the configuration’s name and setting displays, indicating that the configuration is set.

6. Press CANCEL to return to READY.

7. Power off the jukebox and then power it back on to save the configuration to the jukebox flash ROM.

Retrieving log history

READY > ADMIN* > INFO*

To display information stored in the jukebox operating logs:

1. With READY displaying on the control panel, press NEXT until ADMIN* displays.

2. Enter the administration password (see “Entering the administration menu

password” on page 34).

3. TEST* displays. Press NEXT until INFO* displays, and then press ENTER.

4. Press NEXT until the name of the log you want to access displays and then press ENTER.

5. After you are finished viewing log information, press CANCEL to return to READY.

40 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Information logs are described in Table 6.

Table 6: Information logs

Log name Description

Navigation

REVISION JUKEBOX*

■ PRODUCT #

■ SN #

■ FW TYPE ##

■ DRIVES #

■ SLOTS #

JKBX ODOMETERS*

■ HOURS

■ MOVES

■ FLIPS

■ XLATES

Jukebox firmware version number.

Pressing ENTER allows you to select from the following:

Product identification string

Serial number of the unit.

For factory use only.

Code that identifies the type

of firmware used in the unit. Number of drives in the unit.

Number of storage slots in the unit.

Pressing ENTER allows you to select from the following:

Number of operation hours (time the power was on). Some of the time may be while in power reduction mode.

Total moves and move attempts by the disk transport mechanism.

Total disk transport mechanism flips.

Total disk transport mechanism horizontal moves.

■ ROTATES

DRIVE LOADS*

Total mailslot rotations.

Pressing ENTER allows you to select from the following:

■ DRIVE #

■ DRIVE FW*

Total disk loads for the drive numbered “#.”

Press ENTER to select the logs under this selection.

■ DRIVE SN* Press ENTER to select the logs under this

selection.

41HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Table 6: Information logs (Continued)

Log name Description

HARD ERROR*

SOFT ERROR*

RECOVERY ERROR*

■

HARDWARE ERR #

Log of unrecoverable errors (commands that did not successfully complete). Returns either NO HARD ENTRIES or ENTRY #. (There may be multiple hard error numbers.)

Press ENTER to view the log for the currently displayed error, or press NEXT to select the next error.

Log of recovered errors (commands that did not complete successfully). Returns either NO SOFT ENTRIES or ENTRY #. (There may be multiple soft error numbers.)

Press ENTER to view the log for the currently displayed error, or press NEXT to select the next error.

Log of errors during the most recent move. Returns either NO ENTRIES or the number of recovery errors.

Press ENTER to view the log for the currently displayed error, or press NEXT to select the next error.

Internal diagnostics error number for the failure.

Note: FRUs are listed to show where to focus the troubleshooting efforts. The FRUs

are not listed to suggest that the components need replacement.

— *FRU 1 # —*FRU 2 #

Field replaceable unit most likely to be at fault.

Field replaceable unit second most likely to be at fault.

—*FRU 3 #

Field replaceable unit third most likely to be at fault.

42 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Table 6: Information logs (Continued)

Log name Description

Navigation

— MOTION

<name>

— SOURCE #

— DESTINATION

1 #

— DESTINATION

2 #

<name> indicates one of the following types of movements taking place in the jukebox at the time of the failure:

■ EXCHANGE

■ MOVE

■ POSITION

■ INIT ELEM

■ REZERO

■ ROTATE

■ DIAGNOSTIC

■ RESTORE

SCSI element number to which the source refers. (This information is valid for MOVE, EXCHANGE, and POSITION movements only.)

SCSI element to which the first destination refers. (This information is valid for MOVE and EXCHANGE movements only.)

SCSI element to which the second destination refers. (This information is valid for the EXCHANGE movement only.)

— ODOMETER # —*MICROMOVE 1

—*MICROMOVE 2

—*MICROMOVE 3

— *MICROMOVE 4

—*MICROMOVE 5

Move number in which the error occurred.

First jukebox micro-move for the original move command issued prior to the failure.

Second jukebox micro-move for the original move command issued prior to the failure.

Third jukebox micro-move for the original move command issued prior to the failure.

Fourth jukebox micro-move for the original move command issued prior to the failure.

Fifth jukebox micro-move for the original move command issued prior to the failure.

43HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Table 6: Information logs (Continued)

Log name Description

—

MICROMOVE 6

Sixth jukebox micro-move for the original move command issued prior to the failure. (This is the last to be logged.)

■ *MICROMOVE ER #

■ TOP or BOTTOM

PICKER

■ NORTH or SOUTH

THUMB

Running an internal test

READY > ADMIN* >TEST*

This section describes self-diagnostic tests that are available on the jukebox.

Caution: Diagnostic tests should be run only by an authorized service

representative. Descriptions of the self-diagnostic tests are included in this manual internal diagnostic tests can corrupt your file system. In some rare instances, your service representative may request that you run specific tests to provide information before they come to your site, or you may receive a control panel message to run a specific test.

Micro-move error that occurred. Displays either TOP or BOTTOM indicating

which side of the disk transport mechanism was active at the time of the error.

Displays either NORTH or SOUTH indicating which thumb on the transport mechanism was active at the time of the error.

for information purposes only

. If not properly completed, some of the

1. With READY displaying on the control panel, press NEXT until ADMIN* displays.

2. Enter the administration password (see “Entering the administration menu

password” on page 44).

3. TEST* displays. Press ENTER.

4. Press NEXT until the name of the test you want to run displays and then press ENTER to start the test.

44 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Note: You may press CANCEL at any time to abort a test. A delay may occur while the

current test loop completes.

Table 7: Internal tests

Test Name Description

EXCHANGE DEMO

Used by service personnel only. Do not run this test if the jukebox contains disks with file system data on them.

This test moves randomly-chosen optical disks to random storage slot locations. This test displays FAIL if there are no disks in the jukebox or if all storage slots are full. For best results, the jukebox should contain as many disks as there are drives, plus two additional disks. The transport and mailslot must be empty. For mixed media jukeboxes, this test requires two disks of each media type (MO and UDO).

INIT MECHANICS Runs the FIND PLUNGE HOME, FIND VERTICAL HOME ,

FIND XLATE HOME, and INIT ELEM STATUS tests. Each test is run one time per test loop.

INIT ELEM STATUS Physically scans the entire unit to determine which storage

slots contain disks and if the drives contain disks. This test appears as ISTAT TEST in all control panel error

messages.

MAGAZINE IO Makes a combination of moves with a PASS/FAIL result. It

moves an optical disk from a randomly-chosen full slot to a randomly-chosen empty slot with a random flip. It then moves the disk back to its original storage slot with its original orientation. This test displays FAIL if there are no disks in the jukebox or if all storage slots are full. The drives and mailslot must be empty.

DRIVE IO Makes a combination of moves with a PASS/FAIL result. It

moves an optical disk from a randomly-chosen full slot to a randomly-chosen drive with a random flip. It then moves the cartridge back to its original slot with its original orientation. This test displays FAIL if there are no disks in the jukebox or if all storage slots are full. The drives and mailslot must be empty. For mixed media jukeboxes, this test requires one disk of each media type (MO and UDO).

45HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Table 7: Internal tests (Continued)

Test Name Description

MAILSLOT IO Makes a combination of moves with a PASS/FAIL result. It

moves an optical disk from the lowest-numbered full slot to the mailslot with a random flip. It then moves the cartridge back to its original slot with its original orientation. This test displays FAIL if there are no disks in the jukebox or if all storage slots are full. The drives and mailslot must be empty.

VERTICAL TEST Moves the disk transport mechanism up and down the full

length of the rail. Returns PASS/FAIL. No disks are required.

TRANSLATE TEST Moves the disk transport mechanism from side to side. No

disks are required.

FLIP TEST Makes a combination of moves with a PASS/FAIL result.

Flips the disk transport mechanism at various locations. No disks are required.

PICKER TEST Flips the disk transport mechanism and switches active

thumbs. No disks are required.

FIND PLUNGE HOME

Calibrates the disk transport mechanism, establishes the mechanism’s orientation, and determines the reference points in the picker travel path. Assumes that the mechanics and servo system are functional. No disks are required.

FIND VERT HOME Recalibrates the vertical position of the disk transport

mechanism and verifies that the vertical path is clear. No disks are required.

FIND XLATE HOME Calibrates the reference points for the side-to-side motion of

the disk transport mechanism. No disks are required.

VERTICAL ENCODER

Moves the disk transport mechanism down to the lower stop, moves it back up a short distance, and then moves it back down. On the second downward motion the number of digital pulses is counted and verified. Returns PASS/FAIL. No disks are required.

EMPTY DRIVES

Used by service personnel only. Do not run this test if the jukebox contains disks with file system data on them

Moves disks out of the drive mechanism(s) and returns them to their home storage slot locations if the locations are known. If the home storage location is not known, the jukebox moves the disks into the first available empty storage slot.

EMPTY PICKER Moves a disk from the disk transport mechanism to its home

storage slot location if that location is known, otherwise the disk is placed into the first available empty storage slot.

46 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Table 7: Internal tests (Continued)

Test Name Description

Navigation

FILL PICKER

Used by service personnel only. Do not run this test if the jukebox contains disks with file system data on them

Moves a disk into the disk transport mechanism from the first storage slot containing a disk. This test must be run twice to fill both containers in the disk transport mechanism.

EXERCISE MECH Runs the VERTICAL TEST, TRANSLATE TEST, FLIP

TEST, MAGAZINE IO, DRIVE IO, and MAILSLOT IO tests. Each test runs one time per test loop.

WELLNESS TEST Checks the general capability of the jukebox. Requires one

loaded disk. The drives, transport, and mailslot must be empty. Runs INIT MECHANICS and EXERCISE MECHANICS. Each test runs one time per test loop.

CLEAR SOFT LOG

Used by service personnel only.

Sets the soft error log to

zero.

CLEAR HARD LOG

Used by service personnel only.

Sets the hard error log to

zero.

PLUNGE FULL SPD Allows the disk transport mechanics to run at full speed. This

setting should always be used in normal jukebox operation.

PLUNGE 1/2 SPD

Used by service personnel only.

Allows the disk transport mechanics to run at half speed.

PLUNGE 1/4 SPD

Used by service personnel only.

Allows the disk transport mechanics to run at quarter speed.

MAILSLOT SENSORS

Displays the current state of the mailslot sensors. If a sensor is not blocked, a “0” is displayed. If a sensor is blocked, an “*” is displayed. The display automatically updates when the status changes.

STARWARS The display shows 0 0 0.

Each “0" indicates one of the paths that the disk transport mechanism follows in front of each stack of optical disks. If the path is clear, a “0” displays; if the path is blocked (because of an optical disk that is not inserted fully into its storage slot for example), an “*” will be displayed. This display is automatically updated if the status changes.

47HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Navigation

Table 7: Internal tests (Continued)

Test Name Description

BOTTOM THUMB

Used by service personnel only.

Reports THUMB A, THUMB B, or NO THUMB. Looks at the top and bottom thumb sensors and reports whether the thumbs on the disk transport mechanism are in the forward or back position. If THUMB A or THUMB B is returned, the specified thumb is the forward position. If NO THUMB is returned, both thumbs are in the back position.

TOP THUMB

Used by service personnel only.

Reports ON or OFF. Looks at the top thumb sensor which reports whether or not the thumb that is currently on the top side of the disk transport mechanism is in the forward position. If ON is reported the thumb is in the back position; if OFF is reported the thumb is in the forward position.

TRANSLATE SENSOR

Reports ON or OFF after looking at the translate calibration sensor. Display automatically updates if the status changes.

MEDIA TYPE This is available only in a mixed-media (MO and UDO) unit.

Moves all of the disks in the jukebox, except those in drives, to the media test station, then back to their original positions to determine the drive compatibility of all of the disks.

48 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

This chapter describes the following:

■ Troubleshooting common problems, page 50

■ Retrieving log history, page 56

■ Running an internal test, page 56

■ Using HP StorageWorks Library and Tape Tools, page 57

49HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

Troubleshooting common problems

If the procedures in Table 8 do not address or resolve your problem, visit

http://www.hp.com/go/udo

support (see “Getting help” on page 10).

Table 8: Troubleshooting installation

Problem Solution

Power

for additional assistance, or contact HP technical

Jukebox will not power on

Host computer system does not recognize the jukebox or the drives

■ Check that the power indicator light

on the control panel is on. If it is not, make sure the power switch on the front panel is on.

■ Replace the power cord.

■ Ensure the jukebox is not in an error

or failed state. If so, troubleshoot the error before continuing.

■ Ensure the jukebox is connected and

powered on. The jukebox must be on when booting the host computer for the jukebox to be recognized.

■ If the jukebox is the last device on

the SCSI bus, check that it has been terminated and that the maximum cable length has not been exceeded.

■ Check SCSI ID assignments and

resolve any conflicts.

■ Ensure you are connected to the

correct SCSI bus type. UDO jukeboxes are LVDS devices.

■ If using a narrow (8-bit) HBA, make

sure that all addresses are in the range 0 through 7.

■ For Windows operating systems, use

the device manager to rediscover the jukebox.

■ For HP-UX, use ioscan to verify

that the HBA and attached devices are claimed.

■ For other operating systems, refer to

the system administrators guide for diagnosing missing peripherals.

50 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Table 8: Troubleshooting installation (Continued)

Problem Solution

■ Check that the application software

■ Check that the device is present on

■ Power cycle the jukebox and power

Troubleshooting

is compatible with the jukebox.

the system using HP StorageWorks Library & Tape Tools, available from

http://www.hp.com/support/tape tools

down the host. Wait until the jukebox completes its power cycle before powering up the host.

The power-on selftest failed and

DEVICE FAILED displays

■ Power cycle the jukebox.

■ If the power-on test continues to fail,

press

ENTER, write down the

displayed error code and a micro move error, and contact your support representative.

Power to the jukebox failed while a disk was in the drive and the display did not return to

READY after the power came

back on

■ Power cycle the jukebox.

■ If READY does not display

(power-on test is unsuccessful), switch off the power and contact your support representative.

Caution: Do not move the unit!

Moving the unit risks damaging the optical drive.

No display messages appear ■ Ensure that the power cord is

connected.

■ Ensure that the power switch is on.

■ Power cycle the jukebox.

51HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

Table 8: Troubleshooting installation (Continued)

Problem Solution

Connection Other SCSI devices no longer work

when the jukebox is installed

Media A disk is stuck in a drive

Cannot write to a disk

■ Check SCSI ID assignments and

resolve any conflicts.

■ Ensure that the SCSI ID for the HBA

is different from that of the jukebox.

■ Check for proper SCSI cabling and

termination.

■ Ensure the maximum cable length

for the bus has not been exceeded (12 meters for LVDS and 3 meters for SE).

■ See “Ejecting a disk” on page 33.

■ Attempt to unload the disk using

your application software.

■ If unsuccessful, contact your service

representative.

■ Check the host file system access

permissions.

■ Eject the disk and check that the

write-protect tab on each side of the disk is in the write-enabled position (see “Write-protecting an UDO

disk” on page 20).

■ If unsuccessful, contact your service

representative.

LOAD ERROR or FAILED displays when a disk is inserted into the mailslot

INCOMPATIBLE displays when a disk is loaded.

52 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

■ Press CANCEL. Insert the disk into

the mailslot again.

■ If the light bar on the control panel

is amber, cycle power to the jukebox. When READY displays, try loading the disk again.

■ If unsuccessful, contact your service

representative.

An attempt was made to load an incompatible disk into the drive. Ensure that you use UDO disks in UDO drives, and MO disks in MO drives.

Table 8: Troubleshooting installation (Continued)

Problem Solution

Troubleshooting

RESERVED displays when a disk is inserted into the mailslot

MAILSLOT EMPTY displays when a disk is inserted into the mailslot

DEST NOW FULL displays when a disk is inserted into the mailslot

TRANSPORT FULL displays when a disk is inserted into the mailslot

The SECURE MS configuration is set. Disks cannot be loaded. To change this setting, see “Setting an operating

configuration” on page 39.

■ Remove and then replace the disk

fully into the mailslot.

■ If the same error reappears, then the

mailslot sensors are not detecting a disk and may be defective. Contact your service representative.

The jukebox moved a disk into the slot you chose before your load command executed.

■ Press CANCEL, select another slot

for the disk, and then reattempt a load.

■ Initiate an INIT ELEM STATUS

test (see“Internal tests” on page 45).

■ The disk transport mechanism

already contains a disk. Refer to your host and application software documentation for recovery procedures.

■ Attempt an EMPTY PICKER test

(see “Internal tests” on page 45).

■ If unsuccessful, contact your support

representative.

MAILSLOT SENSOR displays when a disk is inserted into the mailslot

EJECT ERROR displays when a disk eject is attempted

■ Remove and then re-insert the disk.

■ If unsuccessful, the jukebox mailslot

sensors may have failed. Contact your service representative.

■ Press CANCEL. Attempt to eject the

disk again.

■ If the light bar on the control panel

is amber, cycle power to the jukebox and try to eject the disk again when READY displays.

■ If there is no disk in the mailslot and

this error message repeats, contact your service representative.

53HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

Table 8: Troubleshooting installation (Continued)

Problem Solution

RESERVED displays when a disk eject is attempted

EMPTY * displays when a disk eject is attempted

TRANSPORT FULL displays when a disk eject is attempted

SOURCE NOW EMPTY displays when a disk eject is attempted

The application software reserved the element for its use or a security configuration was set to prevent disk ejection.

■ See “Setting an operating

configuration” on page 39.

■ Attempt the operation using your

application software.

This is not an error. There are no disks in the jukebox.

■ The disk transport mechanism

already contains a disk. Refer to your host and application software documentation for recovery procedures.

■ Attempt an EMPTY PICKER test

(see “Internal tests” on page 45).

■ If unsuccessful, contact your service

representative.

The application software moved the disk from the slot you chose before your eject command executed.

■ Press CANCEL. You may have to

wait for the application software to replace the disk into the slot before attempting another eject.

■ Initiate an INIT ELEM STATUS

test (see“Internal tests” on page 45).

MAILSLOT FULL displays when a disk eject is attempted

A disk is in the mailslot. To remove the disk, select EJECT *, select the slot you want the disk ejected from again, and

eject the disk. Operation Forgot the password

■ Enter the default password (000

000 000).

■ If unsuccessful, contact your service

representative.

54 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

Table 8: Troubleshooting installation (Continued)

Problem Solution

You want to stop a test that is running Press CANCEL. The current test loop

continues until finished, then the test

stops.

55HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

Retrieving log history

In addition to the procedures listed in the previous sections, the jukebox log history may assist in the troubleshooting process. See “Retrieving log history” on page 40 for more information on how to access the log using the jukebox control panel.

Running an internal test

If your service representative requests that you run an internal test, see “Running

an internal test” on page 44 for more information on how to access the test options

using the jukebox control panel.

56 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Using HP StorageWorks Library and Tape Tools

HP StorageWorks Library and Tape Tools (L&TT) is a robust diagnostic tool for tape mechanisms, tape automation, magneto-optical and UDO products. L&TT provides functionality for firmware downloads, verification of device operation, maintenance procedures, failure analysis, corrective service actions and some utility functions. Seamless integration is provided with HP’s hardware support organization through generating and emailing support tickets. The support ticket delivers a snapshot, or an in-depth view, of the storage system.

L&TT is a free download from the web and deploys in less than five minutes. It is ideal for customers who want ensured product reliability, self-diagnostics and faster resolution of device issues.

Troubleshooting

For more information, visit

Figure 8: HP StorageWorks L&TT

http://www.hp.com/support/tapetools

57HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Troubleshooting

58 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Specifications

This appendix describes the following:

■ Environmental specifications, page 60

■ Jukebox specifications, page 61

■ Drive specifications, page 62

■ Media specifications, page 63

■ Safety and regulatory specifications, page 64

59HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Specifications

Environmental specifications

Table 9: Environmental specifications

Characteristic Specification

Temperature Operating 10ºC to 32ºC (50ºF to 90ºF) Non-operating (without media) -40ºC to 60ºC (-40ºF to 140ºF) Gradient 10ºC (50ºF) per hour Transportation (<14 consecutive days) -30ºC to 60ºC (-22ºF to 140ºF) Humidity Operating 10% to 80% RH Non-operating (without media) 5% to 90% RH Shock Non-operating (without media) 10 cm tilt, drop test Vibration (5 to 500 Hz) Operating 0.21 g rms Non-operating (random) 2.1 g rms Non-operating (swept-sine) 0.5 g (0 to peak) Power Requirements Line voltage 100 to 240 VAC Line frequency 50 to 60 Hz Power consumption

Energy-saving mode Power savings when robotics are inactive

50 W maximum

60 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Jukebox specifications

Table 10: Jukebox specifications

Characteristic Specification

General Average disk exchange time 6.5 seconds MSBF (robotics) 2,000,000 swaps Physical Height 914 mm (36.0 in) Width 869 mm (33.9 in) Depth 482 mm (19.0 in) Weight (net) 100 kg (220 lb) Weight (shipping) 127 kg (280 lb) Interface

Specifications

SCSI interface Low-voltage differential SCSI (LVDS),

68 pin Certification Safety UL 60950, CSA 60950, EN 60950, IEC

60950 Emissions FCC Class A, CISPR 22, Class A Laser EN 60825-1, CDRH

61HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Specifications

Drive specifications

Table 11: Drive specifications

Disk capacity 30 GB Average seek 35 msec

Characteristic Specification

Rotational speed

Data transfer rate (software and system dependent)

■ 2100 RPM +/- 0.5% WORM

■ 1950 RPM +/- 0.5% Rewritable

■ Reads (max. sustained):

— WORM, 7.96 MB/sec —Rewritable, 7.99 MB/sec

■ Writes (max. sustained):

— WORM, 3.98 MB/sec —Rewritable, 3.99 MB/sec

■ Burst (synchronous): 40 MG/sec

■ Burst (asynchronous, data in):

6.7 MB/sec

■ Burst (asynchronous, data out):

40 MB/sec Disk load time 5 sec typical/ Disk unload time 3 sec typical Read/write compatibility Read/write UDO 1st generation format

only Interface type SCSI LVD (68 pin) MSBF 750,000 load/unload cycles Read/write error rate (uncorrectable) < 1 per 10

bytes read

Seek error rates ■ Recoverable: < 1 per 100,000

Note: This product supports mixed drives. The supported configuration includes two

MO drives and two UDO drives only.

62 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

seeks

■ Hard error seeks: <1 per 10,000

seeks

Media specifications

Table 12: Media specifications

Characteristic WORM Specification

General Recording capacity 30 GB 30 GB Archival life (recorded) 50 years 50 years Shelf life (unrecorded) 50 years 50 years Warranty Limited Lifetime Warranty Limited Lifetime Warranty Physical Disk thickness 2.4mm (.1in) 2.4mm (.1in) Outer diameter 130mm (5.12in) 130mm (5.12in) Bytes per sector 8192 bytes 8192 bytes Recording layer Phase change Phase change

Specifications

Rewritable

Specification

Performance Load-unload lifetime 20,000 cycles per side 20,000 cycles per side Overwrite capability No Yes Operating Environment Operating humidity range 5ºC to 55ºC, 3% to 85%

Non-operating (storage) humidity range

Note: This product supports mixed media. The supported configuration includes two

MO drives and two UDO drives only.

-10ºC to 55ºC, 3% to 90% RH-10ºC to 55ºC, 3% to

5ºC to 55ºC, 3% to 85% RH

90% RH

63HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Specifications

Safety and regulatory specifications

Table 13: Safety and regulatory specifications

Description Specification

UL Listed Mark UL 60950 (standard for safety of

TUV GS Mark (Germany) EN60950, IEC950 (standard for safety

CE Marking (European Union) Low Voltage Directive, 73/23/EEC,

CUL Mark (Canadian UL) CAN/CSA 22.2 No. 950 (standard for

Regulatory Series ID Number N3620N3Z, Class A

information technology equipment)

of information technology equipment,

third edition)

European Union

safety of information technology

equipment)

64 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

This appendix describes the following safety and regulatory information for the United States, Finland, Sweden, Germany, United Kingdom, European Union, and Japan:

■ Federal Communications Commission Notice, page 66

■ Canadian Notice (Avis Canadien), page 67

■ European Union Notice, page 68

■ EC radio frequency interference statement (Europe only), page 68

■ Herstellerbescheinigung, page 70

■ English translation of German sound emission directive, page 70

■ Turvallisuusyhteenveto, page 70

■ English translation of Finland regulatory information, page 71

■ BSMI notice, page 74

■ Japanese Notice, page 75

■ Laser Device, page 75

■ CDRH regulations (USA only), page 76

Note: In addition to the safety information in this appendix, also refer to the

that shipped with your product.

Guide

HP Safety

65HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

Federal Communications Commission Notice

Part 15 of the Federal Communications Commission (FCC) Rules and Regulations has established Radio Frequency (RF) emission limits to provide an interference-free radio frequency spectrum. Many electronic devices, including computers, generate RF energy incidental to their intended function and are, therefore, covered by these rules. These rules place computers and related peripheral devices into two classes, A and B, depending upon their intended installation. Class A devices are those that may reasonably be expected to be installed in a business or commercial environment. Class B devices are those that may reasonably be expected to be installed in a residential environment (that is, personal computers). The FCC requires devices in both classes to bear a label indicating the interference potential of the device as well as additional operating instructions for the user.

The rating label on the device sho ws which class (A or B) the equipment falls into. Class B devices hav e an FCC logo or FCC ID on the label. Class A de v ices do not have an FCC logo or FCC ID on the label. Once the class of the device is determined, refer to the following corresponding statement.

Class A Equipment

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at personal expense.

Modifications

The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Hewlett-Packard Company may void the user's authority to operate the equipment.

66 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

Cables

Connections to this device must be made with shielded cables with metallic RFI/EMI connector hoods in order to maintain compliance with FCC Rules and Regulations.

Declaration of Conformity for products marked with the FCC logo United States only

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

For questions regarding this FCC declaration, contact:

Hewlett-Packard Company Regulatory Engineer, MS E-200 825 14th Street S.W. Loveland, CO 80537

Or, call

(970) 898-1738

To identify this product, refer to the Part, Series, or Model number found on the product.

Canadian Notice (Avis Canadien)

Class A Equipment

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

67HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

European Union Notice

Products bearing the CE marking comply with the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community and if this product has telecommunication functionali ty , the R&TTE Directive (1999/5/EC).

Compliance with these directives implies conformity to the following European Norms (in parentheses are the equivalent international standards and regulations):

■ EN 55022 (CISPR 22) - Electromagnetic Interference

■ EN55024 (IEC61000-4-2, 3, 4, 5, 6, 8, 11) - Electromagnetic Immunity

■ EN61000-3-2 (IEC61000-3-2) - Power Line Harmonics

■ EN61000-3-3 (IEC61000-3-3) - Power Line Flicker

■ EN 60950 (IEC 60950) - Product Safety

EC radio frequency interference statement (Europe only)

WARNING: This is a class A product. In a domestic environment this product

may cause radio interference in which case the user may be required to take adequate measures.

AVERTISEMENT : matériel de classe A. L'utilisation de ce matériel en zone

résidentielle est susceptible de générer des interférences nuisibles, auquel cas l'utilisateur sera tenu d'y remédier à ses propres frais.

AVVERTENZA: Questo è un prodotto di Classe A. In un ambiente

residenziale, questo prodotto può causare interferenze radio. In tal caso, l'utente è tenuto ad adottare opportune misure per eliminare il problema.

68 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

VORSICHT: Dies ist ein Produkt der Klasse A. Bei Betrieb in Wohnräumen

kann dieses Produkt Störungen im Radio- und Fernsehempfang verursachen. In diesem Fall ist der Benutzer dazu verpflichtet, geeignete Abhilfemaßnahmen zu treffen.

ADVERTENCIA: este es un producto de clase A. En un entorno doméstico

este producto podría causar interferencias de radio, por lo que el usuario debe tomar las medidas oportunas.

United Kingdom Telecommunications Act 1984

The Hewlett-Packard UDO products are approved under Approval Number NS/G/1234/J/100003 for indirect connection to Public Telecommunication Systems within the United Kingdom.

69HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

Herstellerbescheinigung

Diese Information steht im Zusammenhang mit den Anforderungen der Maschinenlärn information sverordnung vom 18 Januar 1991.

Schalldruckpegel Lp < 70 dB(A)

■ am arbeitsplatz

■ normaler betrieb

■ nach ISO 7779:1988/EN 27779:1991 (Typprüfung)

English translation of German sound emission directive

This statement is provided to comply with the requirements of the German Sound Emission Directive, from 18 January 1991.

Sound pressure Lp < 70 dB(A)

■ at operator position

■ normal operation

■ according to ISO 7779: 1988 /EN 27779: 1991 (type test)

Turvallisuusyhteenveto

Laserturvallisuus

LUOKAN 1 LASERLAITE KLASS 1 LASER APPARAT

Hewlett-Packard optiset levymuistiasemat ovat käyttäjän kannalta turvallisia luokan 1 laserlaitteita. Normaalissa käytössä levymuistiaseman kotelointi estää lasersäteen pääsyn laitteen ulkopuolelle.

Laitteen turvallisuusluokka on määritetty standardin EN 60825 mukaisesti.

VAROITUS !

Laitteen käyttäminen muulla kuin käyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän turvallisuusluokan 1 ylittävälle lasersäteilylle.

70 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Huolto

Safety and Regulatory

VARNING !

Om apparaten används på annat sätt än i bruksanvisning specificerats, kan användaren utsättas för laserstrålning, som överskrider gränsen för laserklass 1.

Hewlett-Packard levymuistiasemien sisällä ei ole käyttäjän huollettavissa olevia kohteita. Laitteen saa avata ja huoltaa ainoastaan sen huoltami seen koulutettu henkilö. Levymuistiaseman sisälle asennettujen luku-/kirjoitusyksiköiden suojakoteloa ei tule avata huoltotoimenpiteiden yhteydessä.

VARO !

Mikäli luku-/kirjoitusyksikön suojakotelo avataan ja suojalukitus ohitetaan, olet alttiina lasersäteilylle laitteen ollessa toiminnassa. Älä katso säteeseen.

VARNING !

Om skyddshöljet av den optiska drivmodulen öppnas och spärren urkopplas då apparaten är i funktion, utsättas användaren för laserstrålning. Betrakta ej strålen.

Tiedot luku-/kirjoit usyk sikössä käyte ttävän laserdiodin säteilyominaisuuksista: Aallonpituus 660 nm Teho 60 mW Turvallisuusluokka 3B

English translation of Finland regulatory information

LASER SAFETY SUMMARY LASER SAFETY CLASS 1 LASER PRODUCT Hewlett-Packard jukeboxes are for user sa fe class 1 laser products. In normal use

the enclosure of the optical drives prevents the laser beam from escaping outside of the product.

The jukebox was type approved in Finland for laser safety by the National Board of Labour Protection. The safety class of the products was defined according to the resolution No 472/1985 of the Council of State and the standard EN 60825.

71HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

WARNING: The use of the product otherwise than specified in the user’s

manual may expose the user to laser radiation exceeding safety class 1.

AVERTISEMENT : l'utilisation de ce produit de façon non conforme à ce

qui est indiqué dans le manuel de l'utilisateur peut exposer l'utilisateur à des rayonnements laser dangereux excédant les normes de sécurité établies pour les matériels appartenant à la Classe 1.

AVVERTENZA: Il mancato rispetto delle indicazioni sull'utilizzo del prodotto

riportate nel manuale dell'utente, potrebbe esporre l'utente a radiazioni laser superiori alla Classe 1 di sicurezza.

VORSICHT

: Bei unsachgemäßer Nutzung des Produkts (nicht gemäß der

Ausführungen im Benutzerhandbuch) kann der Benutzer Laserstrahlung ausgesetzt werden, die die Grenzwerte der Laserschutzklasseklasse 1 übersteigt.

ADVERTENCIA: un uso del producto distinto de los especificados en

la guía de usuario puede producir una exposición peligrosa del usuario a las radiaciones superando el nivel de seguridad 1.

72 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

SERVICE There are no user serviceable parts inside the jukebox. The jukebox products can

be serviced only by qualified service personnel. The optical drive mechanism(s) installed inside the library system shall not be opened or disassembled during service.

WARNING: If the enclosure of the optical drive mechanism is opened and the

safety interlock disabled, you may be exposed to the laser radiation when the drive is operating. Avoid exposure to the beam.

AVERTISEMENT : si le boîtier du mécasnime d'entraînement optique s'ouvre et

que le verrou de sécurité est désactivé, vous risquerez d'être exposé aux rayons laser lors du fonctionnement de l'unité. Évitez de vous exposer au faisceau.

AVVERTENZA: Se il contenitore del meccanismo dell'unità ottica è aperto

e il meccanismo di blocco di sicurezza è disabilitato, è possibile che l'utente sia esposto a radiazioni laser durante il funzionamento dell'unità. Evitare l'esposizione al raggio.

VORSICHT

: Wenn das Gehäuse des optischen Laufwerks geöffnet wird und

die Sicherheitssperre deaktiviert ist, können Sie bei Betrieb des Laufwerks Laserstrahlung ausgesetzt werden. Vermeiden Sie es, sich dem Laserstrahl auszusetzen.

ADVERTENCIA: si el receptáculo del mecanismo de la unidad óptica se abre

y se desactiva el interbloqueo de seguridad, es posible que se exponga a la radiación de láser cuando la unidad esté funcionando. Evite la exposición al rayo.

73HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

The information about the radiation characteristics of the laser diode used in the optical drive mechanism:

Wavelength 680 nm Power 60 mW Class 3B laser

BSMI notice

74 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Japanese Notice

Safety and Regulatory

Laser Device

All HP systems equipped with a laser device comply with safety standards, including International Electrotechnical Commission (IEC) 825. With specific regard to the laser, the equipment complies with laser product performance standards set by government agencies as a Class 1 laser product. The product does not emit hazardous light; the beam is totally enclosed during all modes of customer operation and maintenance.

Laser Safety Warnings

WARNING: To reduce the risk of exposure to hazardous radiation:

Do not try to open the laser device enclosure. There are no user-serviceable components inside.

Do not operate controls, make adjustments, or perform procedures to the laser device other than those specified herein.

Allow only HP authorized service technicians to repair the laser device.

75HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Safety and Regulatory

CDRH regulations (USA only)

The Center for Devices and Radiological Health (CDRH) of the U.S. Food and Drug Administration implemented regulations for laser products on August 2,

1976. These regulations apply to laser products manufactured from August 1,

1976. Compliance is mandatory for products marketed in the United States. The labels and artwork shown below indicate compliance with CDRH regulations and must be attached to laser products marketed in the United States.

WARNING: Use of controls or adjustments, or performing procedures other

than those specified in this manual may result in hazardous laser radiation exposure.

Note: Complies with 21 CFR Chapter 1 Subchapter J.

Laser Class Information: A black on yellow label which reads, “Class 1 Laser Product” printed in English, French, German, Finnish, Japan ese, and Spanish.

Compliance with International Regulations

All HP systems equipped with laser devices comply with appropriate safety standards, including IEC825.

76 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Glossary

This glossary defines terms used in this guide or related to this product and is not a comprehensive glossary of computer terms.

cartridge

A plastic enclosure that contains an optical disk. The cartridge is labeled “A” or “B” to denote separate sides of the optical disk. The optical disk is never removed from the cartridge.

driver

A program that allows the operating system to communicate with a peripheral device.

element

A SCSI term for any one of the autochanger components — drive, mailslot, storage slots, or picker.

jukebox

A term synonymous with optical disk library or autochanger. This type of optical storage device is often referred to as a “jukebox” because when a file is requested, the disk containing the file is found, inserted into the drive, and the requested information is sent to the host computer system, similar to the way a musical jukebox finds a record and mov es it to the turntable when a song is requested.

jukebox controller

The part of the jukebox that controls the sending and receiving of SCSI commands, and controls the disk transport mechanism.

Glossary

LAN

Local area network. A group of computers and peripherals physically connected so users can share hardware and software resources.

mailslot

The area where disks are inserted and removed from the jukebox.

multifunction drive

An optical disk drive that supports both rewritable and WORM optical disks. The drive detects the disk type by reading a factory-stamped code on the disk, and automatically determines whether to operate in rewritable or WORM mode.

77HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Glossary

optical disk

A term synonymous with the 5.25-inch optical disk. There are two types of optical disks: rewritable and WORM.

optical disk library

See jukebox.

rewritable optical

An optical disk technology in which data can be repeatedly written using optical reading and writing technology.

SCSI

An acronym for the Small Computer Systems Interface.

storage slot

An autochanger element that holds cartridges when the cartridges are not in a driv e or not being ejected through the mailslot.

terminator

A resistor array device used for electrically terminating a SCSI bus. A SCSI bus must be terminated at its two physical ends. A peripheral device uses a terminator only if it is at the end of the bus.

ultra density optical

UDO (Ultra Density Optical), like HP's DVD+RW, uses Phase Change technology in order to achieve increased data density on a 130mm disk. Phase Change technology uses a laser to read and write from the active layer on the disk. The recording process uses the laser to heat each data bit to a specific temperature. One temperature allows the bit to form a crystalline (reflective) mark and a different temperature allows the bit to form an amorphous (less reflective) mark. Data is read by using a low power laser beam to detect the difference in the levels of reflectivity recorded on the disk.

write-once or WORM

An additional operating mode available with multifunction dri ves. When a write-once (WORM) disk is inserted, the drive will write data, but will not write over data that has been previously written. This feature is useful for applications that need permanent data security and audit trails.

write-protect

A feature that prevents data from being written to a disk. A write-protect tab is located on both sides of the optical disk cartridge to enable write-protection on one or both surfaces of the disk.

78 HP StorageWorks 1000ux/1900ux/2300ux Optical Jukebox User’s Guide

Index

access panel, service 14 administration menu password

changing 35

authorized reseller, HP 11

back panel 15

changing the SCSI IDs 37 configuration

setting 39 control panel 14 conventions

document 8

text symbols 9

diagnostic tests

running 44 disks

labeling 19

loading 21

maintaining 22

rewritable 18, 20

types 18

using 18

WORM 18, 20

write-protecting 20 document

conventions 8

HP StorageWorks 1900ux, StorageWorks 1000ux, StorageWorks 2300ux User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
