HP SPLIT X2 Schematics

5

www.schematic-x.blogspot.com

4

3

2

1

Wolverine (13.3") Intel Chief River Platform Block Diagram

Slate

DDR3 SODIMM1

D D

Maxima 8GBs

PAGE 12

DDR3

Intel Ivy Bridge

Processor : Daul Core

Power : 7 (Watt)

Package : BGA1023
Size : 31x 27 (mm)

PAGE 2~5

eDP

eDP

PAGE 14

PCB 8L STACK UP

LAYER 1 : TOP
LAYER 2 : SGND
LAYER 3 : IN1(High)
LAYER 4 : IN2(Low)

01

LAYER 5 : SVCC
LAYER 6 : IN3(High)
LAYER 7 : SGND
LAYER 8 : BOT

I2C

Gyrometer
HP3GD20HTR

PAGE 13 PAGE 13

ALS-Sensor

Capella

PAGE 13

PCH

FDI x 8

PAGE 6~11

SATA port0 6GB/s

USB2.0 Interface

Touch Screen

PCIE Gen 1 x 1 Lane

Card Reader

RTS5237-GR

Port11

PAGE 15

PAGE 19

Port2

Camera

PAGE 13

Half Mini Card
WLAN / BT Combo

mSATA

PAGE 14

SENSOR HUB
STM32F103RB

Port10

PAGE 18

Port1

PAGE 13

Acceleometer +
Magentometer
HP303DLHCTR

DMI x 4

System BIOS
SPI ROM

PAGE 7

SPI Interface

LPC Interface

Package : FCBG989

EC SPI ROM

C C

PAGE 21

Embedded Controller

FAN PAGE 15

Package : LQPF128

Size : 14 x 14 (mm)

PAGE 21

Audio CodecEnE KB3940QF

92HD95 40_QFN

Package : MQFN

Size : 6 x 6 (mm)

Azalia

Size : 25 x 25 (mm)

PAGE 16

Digital MIC

PAGE 13

Speaker

B B

PAGE 17

Combo Jack

PAGE 17

HeadPhone AMP

TPA6130A2

PAGE 18

Docking Connector

Base

DP PortB

Embedded Controller

Keyboard

ENE IO3730B

Package : LQFP-64

Size : 7 x 7 x 1.4

5

Combo Jack

I2c

4

USB 2.0 Port 8

3

STM32F103CBSTTouch Pad

A A

SATA port2

USB3.0 Interface

USB 3.0 Port 1 / USB 2.0 Port0

USB2.0 Interface

USB 2.0 Port 3

USB2.0 InterfaceUSB2.0 Interface

USB 2.0 Port 9

HDMI Conn

SATA HDD

USB3.0 Port x 1
USB2.0 Port x 1

CardReader IC

USB2.0 Port x 1

2

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

Block Diagram

Block Diagram

NB5

NB5

NB5

Block Diagram

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

1A

1A

1A

1 29Monday, April 22, 2013

1 29Monday, April 22, 2013

1 29Monday, April 22, 2013

5

4

3

2

1

Ivy Bridge Processor (DMI,PEG,FDI)

PEG_COMP connect to PIN G3&G4 W:4mils/S:15mils/L: 500mils.

U19A

P10

P11

W11

AA6

AC9

W10

AA7

AA3
AC8

AA11
AC12

U11

AA10

AG8

AF3
AD2

AG11

AG4

AF4

AC3
AC4

AE11

AE7
AC1

AA4

AE10

AE6

EDP_HPD_L 14

5

M2

DMI_RX#[0]

P6

DMI_RX#[1]

P1

DMI_RX#[2]
DMI_RX#[3]

N3

DMI_RX[0]

P7

DMI_RX[1]

P3

DMI_RX[2]
DMI_RX[3]

K1

DMI_TX#[0]

M8

DMI_TX#[1]

N4

DMI_TX#[2]

R2

DMI_TX#[3]

K3

DMI_TX[0]

M7

DMI_TX[1]

P4

DMI_TX[2]

T3

DMI_TX[3]

U7

FDI0_TX#[0]
FDI0_TX#[1]

W1

FDI0_TX#[2]
FDI0_TX#[3]

W6

FDI1_TX#[0]

V4

FDI1_TX#[1]

Y2

FDI1_TX#[2]
FDI1_TX#[3]

U6

FDI0_TX[0]
FDI0_TX[1]

W3

FDI0_TX[2]
FDI0_TX[3]

W7

FDI1_TX[0]

T4

FDI1_TX[1]
FDI1_TX[2]
FDI1_TX[3]

FDI0_FSYNC
FDI1_FSYNC

FDI_INT
FDI0_LSYNC

FDI1_LSYNC

eDP_COMPIO
eDP_ICOMPO
eDP_HPD#

eDP_AUX#
eDP_AUX

eDP_TX#[0]
eDP_TX#[1]
eDP_TX#[2]
eDP_TX#[3]

eDP_TX[0]
eDP_TX[1]
eDP_TX[2]
eDP_TX[3]

IC,IVB_2CBGA,0P7

eDP_COMPIO and ICOMPO signals should be shorted
near balls and routed with typical impedance <25 mohms

4mils
12mils

+1.05V

+1.05V

+1.05V

XDP_BPM6

XDP_BPM7

DMI Intel(R) FDI

eDP

ph

DMI_TXN06
DMI_TXN16
DMI_TXN26
DMI_TXN36

+1.05V

Q25

ME2N7002E

DMI_TXP06
DMI_TXP16
DMI_TXP26
DMI_TXP36

DMI_RXN06
DMI_RXN16
DMI_RXN26
DMI_RXN36

DMI_RXP06
DMI_RXP16
DMI_RXP26
DMI_RXP36

FDI_TXN06
FDI_TXN16
FDI_TXN26
FDI_TXN36
FDI_TXN46
FDI_TXN56
FDI_TXN66
FDI_TXN76

FDI_TXP06
FDI_TXP16
FDI_TXP26
FDI_TXP36
FDI_TXP46
FDI_TXP56
FDI_TXP66
FDI_TXP76

FDI_FSYNC06
FDI_FSYNC16

FDI_INT6

FDI_LSYNC06
FDI_LSYNC16

eDP_COMP

INT_eDP_HPD_Q

R306
1K/F_2

3

2

1

INT_eDP_AUXN
INT_eDP_AUXP

INT_eDP_TXN0
INT_eDP_TXN1

INT_eDP_TXP0
INT_eDP_TXP1

R304
100K/F_2

D D

C C

INT_eDP_AUXN14

INT_eDP_AUXP14

INT_eDP_TXN014
INT_eDP_TXN114

B B

INT_eDP_TXP014
INT_eDP_TXP114

INT_eDP_HPD_Q

A A

PEG_COMP connect to PIN G1 W:12mils/S:15mils/L: 500mils.

PEG_ICOMPI

PEG_ICOMPO

PEG_RCOMPO

PEG_RX#[10]
PEG_RX#[11]
PEG_RX#[12]
PEG_RX#[13]
PEG_RX#[14]
PEG_RX#[15]

PEG_TX#[10]
PEG_TX#[11]
PEG_TX#[12]
PEG_TX#[13]
PEG_TX#[14]

PCI EXPRESS -- GRAPHICS

PEG_TX#[15]

R365 24.9/F_4

R178 24.9/F_4

R305 *10K/F_2

TP25
TP44

For iFDIM
Trigger Point

TP26
TP43

PEG_RX#[0]
PEG_RX#[1]
PEG_RX#[2]
PEG_RX#[3]
PEG_RX#[4]
PEG_RX#[5]
PEG_RX#[6]
PEG_RX#[7]
PEG_RX#[8]
PEG_RX#[9]

PEG_RX[0]
PEG_RX[1]
PEG_RX[2]
PEG_RX[3]
PEG_RX[4]
PEG_RX[5]
PEG_RX[6]
PEG_RX[7]
PEG_RX[8]

PEG_RX[9]
PEG_RX[10]
PEG_RX[11]
PEG_RX[12]
PEG_RX[13]
PEG_RX[14]
PEG_RX[15]

PEG_TX#[0]
PEG_TX#[1]
PEG_TX#[2]
PEG_TX#[3]
PEG_TX#[4]
PEG_TX#[5]
PEG_TX#[6]
PEG_TX#[7]
PEG_TX#[8]
PEG_TX#[9]

PEG_TX[0]

PEG_TX[1]

PEG_TX[2]

PEG_TX[3]

PEG_TX[4]

PEG_TX[5]

PEG_TX[6]

PEG_TX[7]

PEG_TX[8]

PEG_TX[9]
PEG_TX[10]
PEG_TX[11]
PEG_TX[12]
PEG_TX[13]
PEG_TX[14]
PEG_TX[15]

G3

PEG_COMP

G1
G4

H22
J21
B22
D21
A19
D17
B14
D13
A11
B10
G8
A8
B6
H8
E5
K7

K22
K19
C21
D19
C19
D16
C13
D12
C11
C9
F8
C8
C5
H6
F6
K6

G22
C23
D23
F21
H19
C17
K15
F17
F14
A15
J14
H13
M10
F10
D9
J4

F22
A23
D24
E21
G19
B18
K17
G17
E14
C15
K13
G13
K10
G10
D8
K4

PM_DRAM_PWRGD6

eDP_COMP

PEG_COMP

INT_eDP_HPD_Q

Connect a Test Point on
BPM# 6 signal, very close
to processor.

Connect a Test Point on
BPM# 7 signal, very close
to processor.

4

PV-1 4/17: C505 EMI

SM_DRAMPWROK
Processor Input.

PM_DRAM_PWRGD PM_DRAM_PWRGD_R

R215
*3K/F_4

H_PROCHOT#21,27

PLTRST#8,18,19,20,21

MBDATA28,12,15,21

+1.5V_CPU

MBCLK28,12,15,21

BE45

C183
*43P/50V_4

F49

C57

C49

A48

C45

D45

C48

B46

D44

CPU RESET#

󰇤

H_SNB_IVB#7

TP21

TP20

Placement close to EC.

EC_PECI21

C18747P/50V_4

H_PROCHOT#_R

PM_THRMTRIP#9,21

PM_SYNC6

H_PWRGOOD9

R147 1.5K/F_4

C505
*43P/50V_4

SKTOCC#

TP_CATERR#

EC_PECI

R192 56.2/F_2

R188 10K/F_2

C186 *43P/50V_4

PM_DRAM_PWRGD_R

Intel DG request

CPU_RESET#

R146
750/F_4

DDR3 DRAM RESET

DRAMRST_CNTRL_DDR12

+3V_DEEP_SUS

R225
200/F_4

R247 130/F_4

R246

*39_4

3

1

2

Q20
*2N7002K

Local Thermal Sensor

MBCLK2
MBDATA2 IO_THERMDA_L

+3V

R207 *0_4
R200 *0_4

R167 *10K/F_2

3

Place under CPU heat pipe

DRAMRST_CNTRL_PCH8

DRAMRST_CNTRL_EC21

MAIN_ONG 4,29

U12

8

SCLK

7

SDA

6

ALERT#

4

OVERT#

*G781-1P8

VCC
DXP
DXN
GND

U19B

PROC_SELECT#

PROC_DETECT#

CATERR#

PECI

PROCHOT#

THERMTRIP#

PM_SYNC

UNCOREPWRGOOD

SM_DRAMPW ROK

RESET#

IC,IVB_2CBGA,0P7

R367 1K/F_2

C223 *0.01U/25V_4

1
2
3

IO_THERMDC_L

5

MISC THERMAL PWR MANAGEMENT

DRAMRST_CNTRL_DDR

for DS3

R355 *0_4
R356 0_4

C198
*2200P/50V_4

G781-1P8(9Ah)

2

CLOCKS

DDR3

MISC

JTAG & BPM

+3V

IO_THERMDA_IO

IO_THERMDC_IO

DPLL_REF_CLK

DPLL_REF_CLK#

SM_DRAMRST#

SM_RCOMP[0]
SM_RCOMP[1]
SM_RCOMP[2]

C286

0.047U/10V_4

2

*METR3904-G

PRDY#
PREQ#

BPM#[0]
BPM#[1]
BPM#[2]
BPM#[3]
BPM#[4]
BPM#[5]
BPM#[6]
BPM#[7]

Q22
2N7002K

Q9

1 3

J3

BCLK

H2

BCLK#

AG3

CLK_DPLL_SSCLKP_R

AG1

CLK_DPLL_SSCLKN_R

R392 *0_4/S
R389 *0_4/S

PV 3/27: R392/389 Change to shortpad

AT30

CPU_DRAMRST#

BF44

SM_RCOMP_0

BE43

SM_RCOMP_1

BG43

SM_RCOMP_2

SM_RCOMP[0] W:20mils/S:20mils/L: 500mils,
SM_RCOMP[1] W:20mils/S:20mils/L: 500mils,
SM_RCOMP[2] W:15mils/S:20mils/L: 500mils,

N53

XDP_PRDY#

N55

XDP_PREQ#

L56

XDP_TCLK

TCK

L55

XDP_TMS

TMS

J58
M60

TDI

L59

TDO

K58

G58
E55
E59
G55
G59
H60
J59
J61

+1.5VSUS

3

1

CPU_DRAMRST#

R262
1K/F_2

R310

4.99K/F_4

NB5

NB5

NB5

XDP_TRST#
XDP_TDI_R

XDP_TDO

XDP_DBRST#

XDP_BPM6
XDP_BPM7

CPU_DRAMRST#_R

TRST#

DBR#

2

C305 *43P/50V_4

R401 140/F_4
R400 25.5/F_4
R399 200/F_4

TP27

R3711K/F_2

Processor pull-up (CPU)

H_PROCHOT#
XDP_TDO
XDP_TMS
XDP_TDI_R
XDP_PREQ#
XDP_TCLK
XDP_TRST#

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

IVB 1/4 (DMI/PEG/FDI)

IVB 1/4 (DMI/PEG/FDI)

IVB 1/4 (DMI/PEG/FDI)

Date: Sheet of

Date: Sheet of

Date: Sheet of

CLK_CPU_BCLKP 8
CLK_CPU_BCLKN 8

CPU XDP

XDP_DBRST# 6

DDR3_DRAMRST# 12

1

02

CLK_DPLL_SSCLKP 8
CLK_DPLL_SSCLKN 8

R162 62_2
R271 51_2
R253 51_2
R285 51_2
R243 *51_2
R259 51_2
R264 51_2

+1.05V

1A

1A

1A

2 29Monday, April 22, 2013

2 29Monday, April 22, 2013

2 29Monday, April 22, 2013

5

4

3

2

1

03

Ivy Bridge Processor (DDR3)

D D

U19C IC,IVB_2CBGA,0P7

M_A_DQ[63:0]12

C C

B B

M_A_BS#012
M_A_BS#112
M_A_BS#212

M_A_CAS#12
M_A_RAS#12
M_A_WE#12

M_A_DQ0
M_A_DQ1
M_A_DQ2
M_A_DQ3
M_A_DQ4
M_A_DQ5
M_A_DQ6
M_A_DQ7
M_A_DQ8
M_A_DQ9
M_A_DQ10
M_A_DQ11
M_A_DQ12
M_A_DQ13
M_A_DQ14
M_A_DQ15
M_A_DQ16
M_A_DQ17
M_A_DQ18
M_A_DQ19
M_A_DQ20
M_A_DQ21
M_A_DQ22
M_A_DQ23
M_A_DQ24
M_A_DQ25
M_A_DQ26
M_A_DQ27
M_A_DQ28
M_A_DQ29
M_A_DQ30
M_A_DQ31
M_A_DQ32
M_A_DQ33
M_A_DQ34
M_A_DQ35
M_A_DQ36
M_A_DQ37
M_A_DQ38
M_A_DQ39
M_A_DQ40
M_A_DQ41
M_A_DQ42
M_A_DQ43
M_A_DQ44
M_A_DQ45
M_A_DQ46
M_A_DQ47
M_A_DQ48
M_A_DQ49
M_A_DQ50
M_A_DQ51
M_A_DQ52
M_A_DQ53
M_A_DQ54
M_A_DQ55
M_A_DQ56
M_A_DQ57
M_A_DQ58
M_A_DQ59
M_A_DQ60
M_A_DQ61
M_A_DQ62
M_A_DQ63

AG6
AP11
AJ10

AR11

AP6

AU6

AV9

AR6

AP8
AT13
AU13

BC7

BB7
BA13
BB11

BA7

BA9

BB9
AY13
AV14
AR14
AY17
AR19
BA14
AU14
BB14
BB17
BA45
AR43

AW48

BC48
BC45
AR45
AT48
AY48
BA49
AV49
BB51
AY53
BB49
AU49
BA53
BB55
BA55
AV56
AP50
AP53
AV54
AT54
AP56
AP52
AN57
AN53
AG56
AG53
AN55
AN52
AG55
AK56

BD37
BF36
BA28

BE39
BD39
AT41

AJ6
AL6
AJ8

AL8
AL7

SA_DQ[0]
SA_DQ[1]
SA_DQ[2]
SA_DQ[3]
SA_DQ[4]
SA_DQ[5]
SA_DQ[6]
SA_DQ[7]
SA_DQ[8]
SA_DQ[9]
SA_DQ[10]
SA_DQ[11]
SA_DQ[12]
SA_DQ[13]
SA_DQ[14]
SA_DQ[15]
SA_DQ[16]
SA_DQ[17]
SA_DQ[18]
SA_DQ[19]
SA_DQ[20]
SA_DQ[21]
SA_DQ[22]
SA_DQ[23]
SA_DQ[24]
SA_DQ[25]
SA_DQ[26]
SA_DQ[27]
SA_DQ[28]
SA_DQ[29]
SA_DQ[30]
SA_DQ[31]
SA_DQ[32]
SA_DQ[33]
SA_DQ[34]
SA_DQ[35]
SA_DQ[36]
SA_DQ[37]
SA_DQ[38]
SA_DQ[39]
SA_DQ[40]
SA_DQ[41]
SA_DQ[42]
SA_DQ[43]
SA_DQ[44]
SA_DQ[45]
SA_DQ[46]
SA_DQ[47]
SA_DQ[48]
SA_DQ[49]
SA_DQ[50]
SA_DQ[51]
SA_DQ[52]
SA_DQ[53]
SA_DQ[54]
SA_DQ[55]
SA_DQ[56]
SA_DQ[57]
SA_DQ[58]
SA_DQ[59]
SA_DQ[60]
SA_DQ[61]
SA_DQ[62]
SA_DQ[63]

SA_BS[0]
SA_BS[1]
SA_BS[2]

SA_CAS#
SA_RAS#
SA_WE#

SA_CK[0]
SA_CK#[0]
SA_CKE[0]

SA_CK[1]
SA_CK#[1]
SA_CKE[1]

SA_CS#[0]
SA_CS#[1]

SA_ODT[0]
SA_ODT[1]

SA_DQS#[0]
SA_DQS#[1]
SA_DQS#[2]
SA_DQS#[3]
SA_DQS#[4]
SA_DQS#[5]
SA_DQS#[6]
SA_DQS#[7]

SA_DQS[0]
SA_DQS[1]
SA_DQS[2]
SA_DQS[3]
SA_DQS[4]
SA_DQS[5]
SA_DQS[6]
SA_DQS[7]

AU36
AV36
AY26

AT40
AU40
BB26

BB40
BC41

AY40
BA41

AL11
AR8
AV11
AT17
AV45
AY51
AT55
AK55

AJ11
AR10
AY11
AU17
AW45
AV51
AT56
AK54

M_A_DQSN0
M_A_DQSN1
M_A_DQSN2
M_A_DQSN3
M_A_DQSN4
M_A_DQSN5
M_A_DQSN6
M_A_DQSN7

M_A_DQSP0
M_A_DQSP1
M_A_DQSP2
M_A_DQSP3
M_A_DQSP4
M_A_DQSP5
M_A_DQSP6
M_A_DQSP7

M_A_CLKP0 12
M_A_CLKN0 12
M_A_CKE0 12

M_A_CLKP1 12
M_A_CLKN1 12
M_A_CKE1 12

M_A_CS#0 12
M_A_CS#1 12

M_A_ODT0 12
M_A_ODT1 12

M_A_DQSN[7:0] 12

M_A_DQSP[7:0] 12

DDR SYSTEM MEMORY A

SA_MA[0]

SA_MA[1]

SA_MA[2]

SA_MA[3]

SA_MA[4]

SA_MA[5]

SA_MA[6]

SA_MA[7]

SA_MA[8]

SA_MA[9]

SA_MA[10]
SA_MA[11]
SA_MA[12]
SA_MA[13]
SA_MA[14]
SA_MA[15]

BG35
BB34
BE35
BD35
AT34
AU34
BB32
AT32
AY32
AV32
BE37
BA30
BC30
AW41
AY28
AU26

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

M_A_A[15:0] 12

U19D IC,IVB_2CBGA,0P7

AL4

SB_DQ[0]

AL1

SB_DQ[1]

AN3

SB_DQ[2]

AR4

SB_DQ[3]

AK4

SB_DQ[4]

AK3

SB_DQ[5]

AN4

SB_DQ[6]

AR1

SB_DQ[7]

AU4

SB_DQ[8]

AT2

SB_DQ[9]

AV4

SB_DQ[10]

BA4

SB_DQ[11]

AU3

SB_DQ[12]

AR3

SB_DQ[13]

AY2

SB_DQ[14]

BA3

SB_DQ[15]

BE9

SB_DQ[16]

BD9

SB_DQ[17]

BD13

SB_DQ[18]

BF12

SB_DQ[19]

BF8

SB_DQ[20]

BD10

SB_DQ[21]

BD14

SB_DQ[22]

BE13

SB_DQ[23]

BF16

SB_DQ[24]

BE17

SB_DQ[25]

BE18

SB_DQ[26]

BE21

SB_DQ[27]

BE14

SB_DQ[28]

BG14

SB_DQ[29]

BG18

SB_DQ[30]

BF19

SB_DQ[31]

BD50

SB_DQ[32]

BF48

SB_DQ[33]

BD53

SB_DQ[34]

BF52

SB_DQ[35]

BD49

SB_DQ[36]

BE49

SB_DQ[37]

BD54

SB_DQ[38]

BE53

SB_DQ[39]

BF56

SB_DQ[40]

BE57

SB_DQ[41]

BC59

SB_DQ[42]

AY60

SB_DQ[43]

BE54

SB_DQ[44]

BG54

SB_DQ[45]

BA58

SB_DQ[46]

AW59

SB_DQ[47]

AW58

SB_DQ[48]

AU58

SB_DQ[49]

AN61

SB_DQ[50]

AN59

SB_DQ[51]

AU59

SB_DQ[52]

AU61

SB_DQ[53]

AN58

SB_DQ[54]

AR58

SB_DQ[55]

AK58

SB_DQ[56]

AL58

SB_DQ[57]

AG58

SB_DQ[58]

AG59

SB_DQ[59]

AM60

SB_DQ[60]

AL59

SB_DQ[61]

AF61

SB_DQ[62]

AH60

SB_DQ[63]

BG39

SB_BS[0]

BD42

SB_BS[1]

AT22

SB_BS[2]

AV43

SB_CAS#

BF40

SB_RAS#

BD45

SB_WE#

BA34

SB_CK[0]

AY34

SB_CK#[0]

AR22

SB_CKE[0]

BA36

SB_CK[1]

BB36

SB_CK#[1]

BF27

SB_CKE[1]

BE41

SB_CS#[0]

BE47

SB_CS#[1]

AT43

SB_ODT[0]

BG47

SB_ODT[1]

AL3

SB_DQS#[0]

AV3

SB_DQS#[1]

BG11

SB_DQS#[2]

BD17

SB_DQS#[3]

BG51

SB_DQS#[4]

BA59

SB_DQS#[5]

AT60

SB_DQS#[6]

AK59

SB_DQS#[7]

AM2

SB_DQS[0]

AV1

SB_DQS[1]

BE11

SB_DQS[2]

BD18

SB_DQS[3]

BE51

SB_DQS[4]

BA61

SB_DQS[5]

AR59

SB_DQS[6]

AK61

SB_DQS[7]

DDR SYSTEM MEMORY B

BF32

SB_MA[0]

BE33

SB_MA[1]

BD33

SB_MA[2]

AU30

SB_MA[3]

BD30

SB_MA[4]

AV30

SB_MA[5]

BG30

SB_MA[6]

BD29

SB_MA[7]

BE30

SB_MA[8]

BE28

SB_MA[9]

BD43

SB_MA[10]

AT28

SB_MA[11]

AV28

SB_MA[12]

BD46

SB_MA[13]

AT26

SB_MA[14]

AU22

SB_MA[15]

A A

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

IVB 2/4 (DDR3 I/F)

IVB 2/4 (DDR3 I/F)

NB5

NB5

5

4

3

2

NB5

IVB 2/4 (DDR3 I/F)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

1A

1A

1A

3 29Monday, April 22, 2013

3 29Monday, April 22, 2013

3 29Monday, April 22, 2013

5

U19F

+VCC_CORE

A26

VCC[1]

A29

VCC[2]

A31

VCC[3]

C129

C116

22U/6.3VS_6

22U/6.3VS_6

D D

C105

C103

C109
22U/6.3VS_6

C119
22U/6.3VS_6

C118
22U/6.3VS_6

C134
22U/6.3VS_6

C C

B B

A A

22U/6.3VS_6

22U/6.3VS_6

C135

C132

22U/6.3VS_6

22U/6.3VS_6

C104

C122

22U/6.3VS_6

22U/6.3VS_6

C164 2.2U/6.3VS_4
C153 2.2U/6.3VS_4
C162 2.2U/6.3VS_4

C163 2.2U/6.3VS_4
C149 2.2U/6.3VS_4
C192 2.2U/6.3VS_4
C150 2.2U/6.3VS_4
C189 2.2U/6.3VS_4
C165 2.2U/6.3VS_4
C191 2.2U/6.3VS_4

5

A34

VCC[4]

A35

VCC[5]

A38

VCC[6]

A39

VCC[7]

A42

VCC[8]

C26

VCC[9]

C27

VCC[10]

C32

VCC[11]

C34

VCC[12]

C37

VCC[13]

C39

VCC[14]

C42

VCC[15]

D27

VCC[16]

D32

VCC[17]

D34

VCC[18]

D37

VCC[19]

D39

VCC[20]

D42

VCC[21]

E26

VCC[22]

E28

VCC[23]

E32

VCC[24]

E34

VCC[25]

E37

VCC[26]

E38

VCC[27]

F25

VCC[28]

F26

VCC[29]

F28

VCC[30]

F32

VCC[31]

F34

VCC[32]

F37

VCC[33]

F38

VCC[34]

F42

VCC[35]

G42

VCC[36]

H25

VCC[37]

H26

VCC[38]

H28

VCC[39]

H29

VCC[40]

H32

VCC[41]

H34

VCC[42]

H35

VCC[43]

H37

VCC[44]

H38

VCC[45]

H40

VCC[46]

J25

VCC[47]

J26

VCC[48]

J28

VCC[49]

J29

VCC[50]

J32

VCC[51]

J34

VCC[52]

J35

VCC[53]

J37

VCC[54]

J38

VCC[55]

J40

VCC[56]

J42

VCC[57]

K26

VCC[58]

K27

VCC[59]

K29

VCC[60]

K32

VCC[61]

K34

VCC[62]

K35

VCC[63]

K37

VCC[64]

K39

VCC[66]

K42

VCC[67]

L25

VCC[68]

L28

VCC[69]

L33

VCC[70]

L36

VCC[71]

L40

VCC[72]

N26

VCC[73]

N30

VCC[74]

N34

VCC[75]

N38

VCC[76]

IC,IVB_2CBGA,0P7

H_CPU_SVIDALRT#
VR_SVID_DATA

VR_SVID_CLK

POWER

CORE SUPPLY

R close to CPU

R176 43_4

4

VCCIO[1]
VCCIO[3]
VCCIO[4]
VCCIO[5]
VCCIO[6]
VCCIO[7]
VCCIO[8]

VCCIO[9]
VCCIO[10]
VCCIO[11]
VCCIO[12]
VCCIO[13]
VCCIO[14]
VCCIO[15]
VCCIO[16]
VCCIO[17]
VCCIO[18]
VCCIO[19]
VCCIO[20]
VCCIO[21]
VCCIO[22]
VCCIO[23]
VCCIO[24]
VCCIO[25]
VCCIO[26]
VCCIO[27]
VCCIO[28]
VCCIO[29]

VCCIO[30]
VCCIO[31]
VCCIO[32]

PEG IO AND DDR IO

VCCIO[33]
VCCIO[34]
VCCIO[35]
VCCIO[36]
VCCIO[37]
VCCIO[38]
VCCIO[39]
VCCIO[40]
VCCIO[41]
VCCIO[42]
VCCIO[43]
VCCIO[44]
VCCIO[45]
VCCIO[46]
VCCIO[47]
VCCIO[48]
VCCIO[49]

VCCIO50

VCCIO51

VCCIO_SEL

VCCPQE[1]
VCCPQE[2]

RAILS

VIDALERT#

VIDSCLK

VIDSOUT

VCC_SENSE
VSS_SENSE

VCCIO_SENSE

VSS_SENSE_VCCIO

SENSE LINES SVID QUIET

4

IVB:8.5A

AF46
AG48
AG50
AG51
AJ17
AJ21
AJ25
AJ43
AJ47
AK50
AK51
AL14
AL15
AL16
AL20
AL22
AL26
AL45
AL48
AM16
AM17
AM21
AM43
AM47
AN20
AN42
AN45
AN48

AA14
AA15
AB17
AB20
AC13
AD16
AD18
AD21
AE14
AE15
AF16
AF18
AF20
AG15
AG16
AG17
AG20
AG21
AJ14
AJ15

W16
W17

BC22

AM25
AN22

A44
B43
C44

100- ±1% pull-up to VCC near processor.

F43
G43

AN16
AN17

R149 75/F_4

R148 130/F_4

R403 *1K/F_2

H_CPU_SVIDALRT#
VR_SVID_CLK
VR_SVID_DATA

VCCP_SENSE

VSSP_SENSE

+1.05V
VR_SVID_ALERT# 27
VR_SVID_DATA 27

+1.05V
VR_SVID_CLK 27

C173
1U/6.3V_2

C166
22U/6.3VS_6

C167
22U/6.3VS_6

C221
22U/6.3VS_6

C76
1U/6.3V_2

R130 100/F_2

R129 100/F_2
R390 10/F_4

R393 10/F_4

+1.05V

C71
1U/6.3V_2

C97
22U/6.3VS_6

C99
22U/6.3VS_6

C102
22U/6.3VS_6

C67 1U/6.3V_2
C74 1U/6.3V_2
C81 1U/6.3V_2
C93 1U/6.3V_2
C87 1U/6.3V_2
C64 1U/6.3V_2
C100 1U/6.3V_2
C210 1U/6.3V_2
C175 1U/6.3V_2
C86 1U/6.3V_2
C176 1U/6.3V_2
C98 1U/6.3V_2
C211 1U/6.3V_2

H_VTTVID1 25

+1.05V

+VCC_CORE

VCC_SENSE 27
VSS_SENSE 27

+1.05V

VCCP_SENSE 25
VSSP_SENSE 25

3

+VCC_GFX

C174
1U/6.3V_2

C101
22U/6.3VS_6

+1.5V_CPU

C246

22U/6.3VS_6

C321

22U/6.3VS_6

C248

22U/6.3VS_6

C294

1U/6.3V_2

C296

1U/6.3V_2

C295

1U/6.3V_2C190 2.2U/6.3VS_4

22U/6.3VS_6

22U/6.3VS_6

22U/6.3VS_6

TP17

+VCC_GFX

VCC_AXG_SENSE27
VSS_AXG_SENSE27

TP19

1U/6.3V_2

1U/6.3V_2

1U/6.3V_2

C271

C272

C247

C293

C297

C292

IVB: 1.5A

C335

C339

1U/6.3V_2

1U/6.3V_2

+VCCSA

C66

10U/6.3V_6

C63

10U/6.3V_6

IVB: 6A

10U/6.3V_6

330uFx1, 10uFx4

Zo impedance: 27.4ohm

Zo impedance: 27.4ohm

Q28
AON7410

4

C332
*470P/50V_4

1
3

5 2

MAIND

CPU VDDQ

3

C58

1U/6.3V_2

C341
10U/6.3V_6

+1.5V_CPU+1.5VSUS

C291

C65

10U/6.3V_6

R351
220_8

3

1

R22610/F_4

R19910/F_4

2

Q23

2N7002K

U19G

AA46

VAXG[1]

AB47

VAXG[2]

AB50

VAXG[3]

AB51

VAXG[4]

AB52

VAXG[5]

AB53

VAXG[6]

AB55

VAXG[7]

AB56

VAXG[8]

AB58

VAXG[9]

AB59

VAXG[10]

AC61

VAXG[11]

AD47

VAXG[12]

AD48

VAXG[13]

AD50

VAXG[14]

AD51

VAXG[15]

AD52

VAXG[16]

AD53

VAXG[17]

AD55

VAXG[18]

AD56

VAXG[19]

AD58

VAXG[20]

AD59

VAXG[21]

AE46

VAXG[22]

N45

VAXG[23]

P47

VAXG[24]

P48

VAXG[25]

P50

VAXG[26]

P51

VAXG[27]

P52

VAXG[28]

P53

VAXG[29]

P55

VAXG[30]

P56

VAXG[31]

P61

VAXG[32]

T48

VAXG[33]

T58

VAXG[34]

T59

VAXG[35]

T61

VAXG[36]

U46

VAXG[37]

V47

VAXG[38]

V48

VAXG[39]

V50

VAXG[40]

V51

VAXG[41]

V52

VAXG[42]

V53

VAXG[43]

V55

VAXG[44]

V56

VAXG[45]

V58

VAXG[46]

V59

VAXG[47]

W50

VAXG[48]

W51

VAXG[49]

W52

VAXG[50]

W53

VAXG[51]

W55

VAXG[52]

W56

VAXG[53]

W61

VAXG[54]

Y48

VAXG[55]

Y61

VAXG[56]

F45

VAXG_SENSE

G45

VSSAXG_SENSE

BB3

VCCPLL[1]

BC1

VCCPLL[2]

BC4

VCCPLL[3]

L17

VCCSA[1]

L21

VCCSA[2]

N16

VCCSA[3]

N20

VCCSA[4]

N22

VCCSA[5]

P17

VCCSA[6]

P20

VCCSA[7]

R16

VCCSA[8]

R18

VCCSA[9]

R21

VCCSA[10]

U15

VCCSA[11]

V16

VCCSA[12]

V17

VCCSA[13]

V18

VCCSA[14]

V21

VCCSA[15]

W20

VCCSA[16]

IC,IVB_2CBGA,0P7

MAIN_ONG 2,29

POWER

VREF

DDR3 - 1.5V RAILS

GRAPHICS

SENSE

LINES

1.8V RAIL

SA RAIL

VCCSA VID

SMDDR_VREF_DQ0_M3

2

SM_VREF

SA_DIMM_VREFDQ
SB_DIMM_VREFDQ

VDDQ[10]
VDDQ[11]
VDDQ[12]
VDDQ[13]
VDDQ[14]
VDDQ[15]
VDDQ[16]
VDDQ[17]
VDDQ[18]
VDDQ[19]
VDDQ[20]
VDDQ[21]
VDDQ[22]
VDDQ[23]
VDDQ[24]
VDDQ[25]
VDDQ[26]

VCCDQ[1]
VCCDQ[2]

QUIET RAILS

VDDQ_SENSE

VSS_SENSE_VDDQ

VCCSA_SENSE

SENSE LINES

VCCSA_VID[0]
VCCSA_VID[1]

lines

2

VDDQ[1]
VDDQ[2]
VDDQ[3]
VDDQ[4]
VDDQ[5]
VDDQ[6]
VDDQ[7]
VDDQ[8]
VDDQ[9]

R404
*1K/F_2

+VDDR_REF_CPU +1.5V_CPU

AY43

BE7

SMDDR_VREF_DQ0_M3

BG7

20mils width

0.1U/10V_2

AJ28
AJ33
AJ36
AJ40
AL30
AL34
AL38
AL42
AM33
AM36
AM40
AN30
AN34
AN38
AR26
AR28
AR30
AR32
AR34
AR36
AR40
AV41
AW26
BA40
BB28
BG33

C337
10U/6.3V_6

C353
10U/6.3V_6

CPU center

CRB: 1uf*1

+1.5V_CPU

AM28
AN26

BC43
BA43

U10

D48
D49

SMDDR_VREF_DQ0_M3 12

R177 *100/F_4

VCCSA_SEL0
VCCSA_SEL

C336
1U/6.3V_2

C357

IVB: 5A

C352
10U/6.3V_6

C351
10U/6.3V_6

+VCCSA

VCCUSA_SENSE 26

Zo:55 ohm

R128 1K/F_2
R127 1K/F_2

1

CAD Note: +VDDR_REF_CPU should
have 10 mil trace width

R402
1K/F_2

1

R391
1K/F_2

+VDDR_REF_CPU and DDR_VTTREF must use 10mils width

C349
10U/6.3V_6

C342
10U/6.3V_6

TP31
TP30

VCCSA_SEL0 26
VCCSA_SEL 26

R153
*0_4

R163

100K_4 NTC

NB5

NB5

NB5

3

Q26
2N7002K

2

C328
470P/50V_4

+1.5V_CPU

C350
10U/6.3V_6

C338
10U/6.3V_6

C344 0.1U/10V_2

C345 0.1U/10V_2

C343 0.1U/10V_2

C340 0.1U/10V_2

+3VPCU

THER_GPU THER_CPU

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

DDR_VTTREF 12,24

R372 3.3K/F_4

+1.5VSUS+1.5V_CPU

IO Thrm Protect

For 65 degree, 1.8v limit, (SW)

R164

16.5K/F_4

1 2

R154

3.3K/F_4

For 75 degree, 1.2v limit, (HW)

R139
0_4

1 2

R132
100K_4 NTC

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

IVB 3/4 (POWER)

IVB 3/4 (POWER)

IVB 3/4 (POWER)

1

C139

0.1U/10V_2

C138

0.1U/10V_2

04

MAIND 29

THRM_MOINTOR 21

THRM_MOINTOR1 21

4 29Monday, April 22, 2013

4 29Monday, April 22, 2013

4 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

U19H

A13

VSS[1]

A17

VSS[2]

A21

VSS[3]

A25

VSS[4]

A28

VSS[5]

A33

D D

C C

B B

A A

A37
A40
A45
A49
A53

A9

AA1
AA13
AA50
AA51
AA52
AA53
AA55
AA56

AA8
AB16
AB18
AB21
AB48
AB61
AC10
AC14
AC46

AC6
AD17
AD20

AD4
AD61
AE13

AE8

AF1
AF17
AF21
AF47
AF48
AF50
AF51
AF52
AF53
AF55
AF56
AF58
AF59
AG10
AG14
AG18
AG47
AG52
AG61

AG7

AH4
AH58
AJ13
AJ16
AJ20
AJ22
AJ26
AJ30
AJ34
AJ38
AJ42
AJ45
AJ48

AJ7

AK1
AK52
AL10
AL13
AL17
AL21
AL25
AL28
AL33
AL36
AL40
AL43
AL47
AL61

AM13
AM20
AM22
AM26
AM30
AM34

IC,IVB_2CBGA,0P7

VSS[6]
VSS[7]
VSS[8]
VSS[9]
VSS[10]
VSS[11]
VSS[12]
VSS[13]
VSS[14]
VSS[15]
VSS[16]
VSS[17]
VSS[18]
VSS[19]
VSS[20]
VSS[21]
VSS[22]
VSS[23]
VSS[24]
VSS[25]
VSS[26]
VSS[27]
VSS[28]
VSS[29]
VSS[30]
VSS[31]
VSS[32]
VSS[33]
VSS[34]
VSS[35]
VSS[36]
VSS[37]
VSS[38]
VSS[39]
VSS[40]
VSS[41]
VSS[42]
VSS[43]
VSS[44]
VSS[45]
VSS[46]
VSS[47]
VSS[48]
VSS[49]
VSS[50]
VSS[51]
VSS[52]
VSS[53]
VSS[54]
VSS[55]
VSS[56]
VSS[57]
VSS[58]
VSS[59]
VSS[60]
VSS[61]
VSS[62]
VSS[63]
VSS[64]
VSS[65]
VSS[66]
VSS[67]
VSS[68]
VSS[69]
VSS[70]
VSS[71]
VSS[72]
VSS[73]
VSS[74]
VSS[75]
VSS[76]
VSS[77]
VSS[78]
VSS[79]
VSS[80]
VSS[81]
VSS[82]
VSS[83]
VSS[84]
VSS[85]
VSS[86]
VSS[87]
VSS[88]
VSS[89]
VSS[90]

VSS

VSS[91]
VSS[92]
VSS[93]
VSS[94]
VSS[95]
VSS[96]
VSS[97]
VSS[98]

VSS[99]
VSS[100]
VSS[101]
VSS[102]
VSS[103]
VSS[104]
VSS[105]
VSS[106]
VSS[107]
VSS[108]
VSS[109]
VSS[110]
VSS[111]
VSS[112]
VSS[113]
VSS[114]
VSS[115]
VSS[116]
VSS[117]
VSS[118]
VSS[119]
VSS[120]
VSS[121]
VSS[122]
VSS[123]
VSS[124]
VSS[125]
VSS[126]
VSS[127]
VSS[128]
VSS[129]
VSS[130]
VSS[131]
VSS[132]
VSS[133]
VSS[134]
VSS[135]
VSS[136]
VSS[137]
VSS[138]
VSS[139]
VSS[140]
VSS[141]
VSS[142]
VSS[143]
VSS[144]
VSS[145]
VSS[146]
VSS[147]
VSS[148]
VSS[149]
VSS[150]
VSS[151]
VSS[152]
VSS[153]
VSS[154]
VSS[155]
VSS[156]
VSS[157]
VSS[158]
VSS[159]
VSS[160]
VSS[161]
VSS[162]
VSS[163]
VSS[164]
VSS[165]
VSS[166]
VSS[167]
VSS[168]
VSS[169]
VSS[170]
VSS[171]
VSS[172]
VSS[173]
VSS[174]
VSS[175]
VSS[176]
VSS[177]
VSS[178]
VSS[179]
VSS[180]

AM38
AM4
AM42
AM45
AM48
AM58
AN1
AN21
AN25
AN28
AN33
AN36
AN40
AN43
AN47
AN50
AN54
AP10
AP51
AP55
AP7
AR13
AR17
AR21
AR41
AR48
AR61
AR7
AT14
AT19
AT36
AT4
AT45
AT52
AT58
AU1
AU11
AU28
AU32
AU51
AU7
AV17
AV21
AV22
AV34
AV40
AV48
AV55
AW13
AW43
AW61
AW7
AY14
AY19
AY30
AY36
AY4
AY41
AY45
AY49
AY55
AY58
AY9
BA1
BA11
BA17
BA21
BA26
BA32
BA48
BA51
BB53
BC13
BC5
BC57
BD12
BD16
BD19
BD23
BD27
BD32
BD36
BD40
BD44
BD48
BD52
BD56
BD8
BE5
BG13

U19I

BG17
BG21
BG24
BG28
BG37
BG41
BG45
BG49
BG53

BG9
C29
C35
C40
D10
D14
D18
D22
D26
D29
D35

D4
D40
D43
D46
D50
D54
D58

D6
E25
E29

E3
E35
E40

F13
F15
F19
F29
F35
F40
F55

G51

G6
G61
H10
H14
H17
H21

H4
H53
H58

J1
J49
J55

K11
K21
K51

K8
L16
L20
L22
L26
L30
L34
L38
L43
L48
L61

M11
M15

IC,IVB_2CBGA,0P7

VSS[181]
VSS[182]
VSS[183]
VSS[184]
VSS[185]
VSS[186]
VSS[187]
VSS[188]
VSS[189]
VSS[190]
VSS[191]
VSS[192]
VSS[193]
VSS[194]
VSS[195]
VSS[196]
VSS[197]
VSS[198]
VSS[199]
VSS[200]
VSS[201]
VSS[202]
VSS[203]
VSS[204]
VSS[205]
VSS[206]
VSS[207]
VSS[208]
VSS[209]
VSS[210]
VSS[211]
VSS[212]
VSS[213]
VSS[214]
VSS[215]
VSS[216]
VSS[217]
VSS[218]
VSS[219]
VSS[220]
VSS[221]
VSS[222]
VSS[223]
VSS[224]
VSS[225]
VSS[226]
VSS[227]
VSS[228]
VSS[229]
VSS[230]
VSS[231]
VSS[232]
VSS[233]
VSS[234]
VSS[235]
VSS[236]
VSS[237]
VSS[238]
VSS[239]
VSS[240]
VSS[241]
VSS[242]
VSS[243]
VSS[244]
VSS[245]
VSS[246]
VSS[247]
VSS[248]
VSS[249]

M4

VSS[250]

M58

VSS[251]

M6

VSS[252]

N1

VSS[253]

N17

VSS[254]

N21

VSS[255]

N25

VSS[256]

N28

VSS[257]

N33

VSS[258]

N36

VSS[259]

N40

VSS[260]

N43

VSS[261]

N47

VSS[262]

N48

VSS[263]

N51

VSS[264]

N52

VSS[265]

N56

VSS[266]

N61

VSS[267]

P14

VSS[268]

P16

VSS[269]

P18

VSS_NCTF_1
VSS_NCTF_2
VSS_NCTF_3
VSS_NCTF_4
VSS_NCTF_5
VSS_NCTF_6
VSS_NCTF_7
VSS_NCTF_8

VSS_NCTF_9
VSS_NCTF_10
VSS_NCTF_11

NCTF

VSS_NCTF_12
VSS_NCTF_13
VSS_NCTF_14

VSS[270]
VSS[271]
VSS[272]
VSS[273]
VSS[274]
VSS[275]
VSS[276]
VSS[277]
VSS[278]
VSS[279]
VSS[280]
VSS[281]
VSS[282]
VSS[283]
VSS[284]
VSS[285]
VSS[286]
VSS[287]
VSS[288]
VSS[289]
VSS[290]
VSS[291]
VSS[292]
VSS[293]
VSS[294]
VSS[295]
VSS[296]
VSS[297]
VSS[298]
VSS[299]
VSS[300]

P21
P58
P59
P9
R17
R20
R4
R46
T1
T47
T50
T51
T52
T53
T55
T56
U13
U8
V20
V61
W13
W15
W18
W21
W46
W8
Y4
Y47
Y58
Y59

A5
A57
BC61
BD3
BD59
BE4
BE58
BG5
BG57
C3
C58
D59
E1
E61

CDPTR

VSS

Processor Strapping

CFG2
(PCIe Static x16 Lane Numbering Reversal.)

CFG4
(DP Presence Strap)

CFG7
(PEG Defer Training)

CFG2

TP18

+VCC_CORE

TP24
TP28

TP22
TP23

CFG3
CFG4
CFG5
CFG6
CFG7

R144*49.9/F_4
R183*49.9/F_4

CFG[6:5] (PCIE Port Bifurcation Straps)

11: (Default) x16 - Device 1 functions 1 and 2 disabled
10: x8, x8 - Device 1 function 1 enabled ; function 2 disabled
01: Reserved - (Device 1 function 1 disabled ; function 2 enabled)
00: x8,x4,x4 - Device 1 functions 1 and 2 enabled

The CFG signals have a default value of '1' if not terminated on the board.

1 0

Normal Operation(Default) Lane Reversed

Disable; No physical DP attached to eDP

PEG train immediately following
xxRESETB de assertion

Enable; An ext DP device is connected to eDP

PEG wait for BIOS training

U19E

B50

CFG[0]

C51

CFG[1]

B54

CFG[2]

D53

CFG[3]

A51

CFG[4]

C53

CFG[5]

C55

CFG[6]

H49

CFG[7]

A55

CFG[8]

H51

CFG[9]

K49

CFG[10]

K53

CFG[11]

F53

CFG[12]

G53

CFG[13]

L51

CFG[14]

F51

CFG[15]

D52

CFG[16]

L53

CFG[17]

H43

VCC_VAL_SENSE

K43

VSS_VAL_SENSE

H45

VAXG_VAL_SENSE

K45

VSSAXG_VAL_SENSE

F48

VCC_DIE_SENSE

G48

RSVD47

H48

RSVD6

K48

RSVD7

BA19

RSVD8

AV19

RSVD9

AT21

RSVD10

BB21

RSVD11

BB19

RSVD12

AY21

RSVD13

BA22

RSVD14

AY22

RSVD15

AU19

RSVD16

AU21

RSVD17

BD21

RSVD18

BD22

RSVD19

BD25

RSVD20

BD26

RSVD21

BG22

RSVD22

BE22

RSVD23

BG26

RSVD24

BE26

RSVD25

BF23

RSVD26

BE24

RSVD27

IC,IVB_2CBGA,0P7

RESERVED

BCLK_ITP

BCLK_ITP#

RSVD30
RSVD31
RSVD32
RSVD33

RSVD34
RSVD35
RSVD36
RSVD37
RSVD38

RSVD39
RSVD40

RSVD41
RSVD42
RSVD43
RSVD44

RSVD45

DC_TEST_A4
DC_TEST_C4
DC_TEST_D3

DC_TEST_D1
DC_TEST_A58
DC_TEST_A59
DC_TEST_C59
DC_TEST_A61
DC_TEST_C61
DC_TEST_D61

DC_TEST_BD61
DC_TEST_BE61

DC_TEST_BE59
DC_TEST_BG61
DC_TEST_BG59
DC_TEST_BG58

DC_TEST_BG4
DC_TEST_BG3
DC_TEST_BE3
DC_TEST_BG1
DC_TEST_BE1
DC_TEST_BD1

CFG2
CFG4
CFG7

N59
N58

N42
L42
L45
L47

M13
M14
U14
W14
P13

AT49
K24

AH2
AG13
AM14
AM15

N50

A4
C4
D3
D1
A58
A59
C59
A61
C61
D61
BD61
BE61
BE59
BG61
BG59
BG58
BG4
BG3
BE3
BG1
BE1
BD1

CFG5

R186 1K/F_2

CFG6

R184 *1K/F_2

R185 *1K/F_2
R187 1K/F_2
R145 *1K/F_2

05

TP45

TP47
TP46

TP48
TP49

TP50
TP51

TP52

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

IVB 4/4 (RSV,GND)

IVB 4/4 (RSV,GND)

NB5

NB5

5

4

3

2

NB5

IVB 4/4 (RSV,GND)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

1A

1A

1A

5 29Monday, April 22, 2013

5 29Monday, April 22, 2013

5 29Monday, April 22, 2013

5

4

3

2

1

Cougar Point/Panther Point (DMI,FDI,PM)

U11C
HM77

DMI_RXN02
DMI_RXN12
DMI_RXN22
DMI_RXN32

DMI_RXP02

+1.05V

DMI_RXP12
DMI_RXP22
DMI_RXP32

DMI_TXN02
DMI_TXN12
DMI_TXN22
DMI_TXN32

DMI_TXP02
DMI_TXP12
DMI_TXP22
DMI_TXP32

R158 49.9/F_4
R191 750/F_4

DMI_COMP
DMI_RBIAS

D D

PV 3/27: R286/267/138 Change to shortpad

for DS3

SUSACK#_EC21

C C

XDP_DBRST#2

IMVP_PWRGD

EC_PWROK21

for DS3

SUSWARN#_EC21

R286 *0_4/S

C306 *1U/6.3V_2

PM_DRAM_PWRGD2

RSMRST#21

R267 *0_4/S

DNBSWON#21

R138 *0_4/S

for DS3

B B

SUS_PWR_ACK

XDP_DBRST#

EC_PWROK

EC_PWROK

RSMRST#

SUSWARN#

DNBSWON#

AC_PRESENT_R

PM_BATLOW#

PM_RI#

BC24

DMI0RXN

BE20

DMI1RXN

BG18

DMI2RXN

BG20

DMI3RXN

BE24

DMI0RXP

BC20

DMI1RXP

BJ18

DMI2RXP

BJ20

DMI3RXP

AW24

DMI0TXN

AW20

DMI1TXN

BB18

DMI2TXN

AV18

DMI3TXN

AY24

DMI0TXP

AY20

DMI1TXP

AY18

DMI2TXP

AU18

DMI3TXP

BJ24

DMI_ZCOMP

BG25

DMI_IRCOMP

BH21

DMI2RBIAS

C12

SUSACK#

K3

SYS_RESET#

P12

SYS_PWROK

L22

PWROK

L10

APWROK

B13

DRAMPWROK

C21

RSMRST#

(+3VS5)

K16

SUSWARN#/SUSPWRDNACK/GPIO30

E20

PWRBTN#

(DSW)

H20

ACPRESENT / GPIO31

(+3VS5)

E10

BATLOW# / GPIO72

A10

RI#

DMI

FDI

CLKRUN# / GPIO32

SUS_STAT# / GPIO61

SUSCLK / GPIO62

SLP_S5# / GPIO63

System Power Management

SLP_LAN# / GPIO29

FDI_FSYNC0
FDI_FSYNC1
FDI_LSYNC0
FDI_LSYNC1

DSWVRMEN

FDI_RXN0
FDI_RXN1
FDI_RXN2
FDI_RXN3
FDI_RXN4
FDI_RXN5
FDI_RXN6
FDI_RXN7

FDI_RXP0
FDI_RXP1
FDI_RXP2
FDI_RXP3
FDI_RXP4
FDI_RXP5
FDI_RXP6
FDI_RXP7

FDI_INT

DPWROK

WAKE#

(+3V)

(+3VS5)

(+3VS5)

(+3VS5)

SLP_S4#

SLP_S3#

SLP_A#

SLP_SUS#

PMSYNCH

(+3VS5)

BJ14
AY14
BE14
BH13
BC12
BJ12
BG10
BG9

BG14
BB14
BF14
BG13
BE12
BG12
BJ10
BH9

AW16
AV12
BC10
AV14
BB10

A18

DSWVREN

E22

DPWROK RSMRST#

B9

PCIE_WAKE#

N3

CLKRUN#

G8

SUS_SATA#

N14

PCH_SUSCLK_L

D10

H4

F4

G10

G16

AP14

K14

SLP_LAN#

SLP_SUS#

R123 *0_4/S
R122 *0_4

R166 *0_4/S

FDI_TXN0 2
FDI_TXN1 2
FDI_TXN2 2
FDI_TXN3 2
FDI_TXN4 2
FDI_TXN5 2
FDI_TXN6 2
FDI_TXN7 2

FDI_TXP0 2
FDI_TXP1 2
FDI_TXP2 2
FDI_TXP3 2
FDI_TXP4 2
FDI_TXP5 2
FDI_TXP6 2
FDI_TXP7 2

FDI_INT 2
FDI_FSYNC0 2
FDI_FSYNC1 2
FDI_LSYNC0 2
FDI_LSYNC1 2

DPWROK_EC

PCIE_WAKE# 18,19,21

CLKRUN# 20,21

TP29

SUSC# 21

SUSB# 21

for DS3

SLP_SUS#_EC

PM_SYNC 2

PV 3/27: R166 Change to shortpad

DPWROK_EC 21

PV 3/27: R123 Change to shortpad

PCH_SUSCLK 21

PCH_LVDS_BLON14

PCH_DISP_ON14

PCH_DPST_PWM14

+3V

for DS3

SLP_SUS#_EC 21AC_PRESENT_EC21

Cougar Point/Panther Point (LVDS,DDI)

U11D
HM77

J47

R45 2.2K_2
R46 2.2K_2

R37 2.37K/F_4

TP5
TP1

CTRL_CLK
CTRL_DATA

LVD_IBG

TP7
TP6

TP34
TP37
TP38

TP4
TP39
TP33

TP8

DAC_IREF

R39
1K/F_2

M45

AF37
AF36

AE48
AE47

AK39
AK40

AN48
AM47
AK47

AJ48

AN47
AM49
AK49

AJ47

AF40
AF39

AH45
AH47

AF49
AF45

AH43
AH49

AF47
AF43

N48

M40

M47
M49

P45
T40

K47
T45

P39

P49
T49

T39

T43
T42

L_BKLTEN
L_VDD_EN

L_BKLTCTL
L_DDC_CLK

L_DDC_DATA
L_CTRL_CLK

L_CTRL_DATA
LVD_IBG

LVD_VBG
LVD_VREFH

LVD_VREFL

LVDSA_CLK#
LVDSA_CLK

LVDSA_DATA#0
LVDSA_DATA#1
LVDSA_DATA#2
LVDSA_DATA#3

LVDSA_DATA0
LVDSA_DATA1
LVDSA_DATA2
LVDSA_DATA3

LVDSB_CLK#
LVDSB_CLK

LVDSB_DATA#0
LVDSB_DATA#1
LVDSB_DATA#2
LVDSB_DATA#3

LVDSB_DATA0
LVDSB_DATA1
LVDSB_DATA2
LVDSB_DATA3

CRT_BLUE
CRT_GREEN
CRT_RED

CRT_DDC_CLK
CRT_DDC_DATA

CRT_HSYNC
CRT_VSYNC

DAC_IREF
CRT_IRTN

LVDS

CRT

SDVO_TVCLKINN
SDVO_TVCLKINP

SDVO_STALLN
SDVO_STALLP

SDVO_CTRLCLK

SDVO_CTRLDATA

DDPC_CTRLCLK

DDPC_CTRLDATA

Digital Display Interface

DDPD_CTRLCLK

DDPD_CTRLDATA

SDVO_INTN
SDVO_INTP

DDPB_AUXN
DDPB_AUXP

DDPB_HPD

DDPB_0N
DDPB_0P
DDPB_1N
DDPB_1P
DDPB_2N
DDPB_2P
DDPB_3N
DDPB_3P

DDPC_AUXN
DDPC_AUXP

DDPC_HPD

DDPC_0N

DDPC_0P

DDPC_1N

DDPC_1P

DDPC_2N

DDPC_2P

DDPC_3N

DDPC_3P

DDPD_AUXN
DDPD_AUXP

DDPD_HPD

DDPD_0N

DDPD_0P

DDPD_1N

DDPD_1P

DDPD_2N

DDPD_2P

DDPD_3N

DDPD_3P

AP43
AP45

AM42
AM40

AP39
AP40

P38
M39

AT49
AT47
AT40

AV42
AV40
AV45
AV46
AU48
AU47
AV47
AV49

P46
P42

AP47
AP49
AT38

AY47
AY49
AY43
AY45
BA47
BA48
BB47
BB49

M43
M36

AT45
AT43
BH41

BB43
BB45
BF44
BE44
BF42
BE42
BJ42
BG42

HDMI_SCLK
HDMI_SDATA

HDMI_HPD
IN_D2#

IN_D2
IN_D1#
IN_D1
IN_D0#
IN_D0
IN_CLK#
IN_CLK

+3V_RTC7,10

06

HDMI_SCLK 17

HDMI_SDATA 17

HDMI_HPD 17
IN_D2# 17

IN_D2 17
IN_D1# 17
IN_D1 17
IN_D0# 17
IN_D0 17
IN_CLK# 17
IN_CLK 17

+3V2,7,8,9,10,12,13,14,15,16,17,18,19,20,21,25,27,29

+3VS59,10,18,19,20,23,25,29

+1.05V2,4,7,8,10,20,21,25,27

+3VPCU4,7,15,17,18,19,21,22,23

INT. HDMI

PCH Pull-high/low(CLG)

PM_RI#
PM_BATLOW#
PCIE_WAKE#
SLP_LAN#
SUSWARN#
SUS_PWR_ACK

AC_PRESENT_R

A A

CLKRUN#
XDP_DBRST#

RSMRST#
IMVP_PWRGD

for DS3

R296 10K/F_2
R257 8.2K_2
R295 10K/F_2
R211 *10K/F_2
R268 *10K/F_2
R273 *10K/F_2

R141 10K/F_2

R331 8.2K_2
R336 1K/F_2
R335 *1K/F_2
R126 10K/F_2
R326 *100K/F_2

+3V_DEEP_SUS

+3VS5

+3V

INTEL DG

5

INTEL DG

for DS3

PV 3/27: R133 Change to shortpad

SLP_SUS_ON21

R133 *0_4/S

C125
*10P/25V_2

C197
1U/6.3V_2

4

R136
100K/F_2

R193 *0_6

U9

5

IN

4

IN

3

ON/OFF

IC(5P) G5243AT11U

OUT
GND

System PWR_OK(CLG)

IMVP_PWRGD
EC_PWROK

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

PCH 1/6 (DMI/FDI/VIDEO)

PCH 1/6 (DMI/FDI/VIDEO)

PCH 1/6 (DMI/FDI/VIDEO)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

R254
100K/F_2

IMVP_PWRGD 21,27

6 29Monday, April 22, 2013

6 29Monday, April 22, 2013

6 29Monday, April 22, 2013

1A

1A

1A

OUT
GND

1
2

+5V_DEEP_SUS

C195

0.1U/10V_2

+3V_RTC

R202 330K_4

DSWVREN

On Die DSW VR Enable
High = Enable (Default)

Low = Disable

NB5

NB5

2

NB5

C196
1U/6.3V_2

+5VS5

R140
*100K/F_2

R194 *0_4

U10

5

IN

4

IN

3

ON/OFF

IC(5P) G5243AT11U

+3V_DEEP_SUS+3VS5

1
2

C207

0.1U/10V_2

SLP_SUS_ON

3

5

Cougar Point/Panther Point (HDA,JTAG,SATA)

RTC_X1
RTC_X2
RTC_RST#
SRTC_RST#

R150 1M_2

D D

+3V_RTC

ACZ_SPKR16

ACZ_SDIN016

for DS3

+3V_DEEP_SUS

C C

SIO_EXT_SCI#21

R110 10K/F_2

SM_INTRUDER#
PCH_INVRMEN

ACZ_BCLK
ACZ_SYNC
ACZ_SPKR
ACZ_RST#

ACZ_SDOUT

SIO_EXT_SCI#

PCH_SPI_CS0#

PCH_SPI_SI
PCH_SPI_SO

A20
C20
D20
G22
K22
C17

N34
L34
T10
K34

E34
G34
C34
A34

A36

C36

GPIO33BIOS_WP#

N32

Y14

U11A
HM77

RTCX1
RTCX2
RTCRST#
SRTCRST#
INTRUDER#
INTVRMEN

HDA_BCLK
HDA_SYNC
SPKR
HDA_RST#

HDA_SDIN0
HDA_SDIN1
HDA_SDIN2
HDA_SDIN3

HDA_SDO

(+3V)

HDA_DOCK_EN# / GPIO33

(+3VS5)

HDA_DOCK_RST# / GPIO13

J3

JTAG_TCK

H7

JTAG_TMS

K5

JTAG_TDI

H1

JTAG_TDO

T3

SPI_CLK
SPI_CS0#

T1

SPI_CS1#

V4

SPI_MOSI

U3

SPI_MISO

JTAG

ph

B B

PCH Strap Table

Pin Name Strap description Sampled Configuration

SPKR
GNT3# / GPIO55 Top-Block Swap Override

No reboot mode setting PWROK

PWROK

INTVRMEN Integrated 1.05V VRM enable ALWAYS Should be always pull-up
HDA_DOCK_EN#/GPIO33
GNT1# / GPIO51

GPIO19

Different from
Calpella

GNT2# / GPIO53
NV_ALE

NV_CLE

A A

HDA_SYNC On-Die PLL VR Voltage Select RSMRST

Flash Descriptor Security

Only for Interposer

Boot BIOS Selection 1 [bit-1]
Boot BIOS Selection 0 [bit-0]
ESI strap (Server only)

Intel Anti-Theft HDD protection

Only for Interposer

DMI Termination voltage weak pull-down 20kohm

PWROK
PWROK
PWROK
PWROK
PWROK 0 = Disable (Internal pull-down 20kohm)

PWROK

HDA_SDO PWROKFlash Descriptor Security
GPIO8

GPIO28

Different from
Calpella

Integrated Clock Chip Enable Should be pull-down (weak pull-up 20K)RSMRST#
On-die PLL Voltage Regulator RSMRST#

SPI_MOSI iTPM function Disable APWROK

5

4

FWH0 / LAD0
FWH1 / LAD1
FWH2 / LAD2
FWH3 / LAD3

LPC

FWH4 / LFRAME#

LDRQ0#

LDRQ1# / GPIO23

RTCIHDA

SPI

(+3V)

SERIRQ

SATA0RXN
SATA0RXP
SATA0TXN

SATA0TXP

SATA1RXN
SATA1RXP

SATA 6G

SATA1TXN

SATA1TXP

SATA2RXN
SATA2RXP
SATA2TXN

SATA2TXP

SATA3RXN
SATA3RXP
SATA3TXN

SATA3TXP

SATA4RXN
SATA4RXP
SATA4TXN

SATA

SATA4TXP

SATA5RXN
SATA5RXP
SATA5TXN

SATA5TXP

SATAICOMPO

SATAICOMPI

SATA3RCOMPO

SATA3COMPI

SATA3RBIAS

SATALED#

(+3V)

SATA0GP / GPIO21

(+3V)

SATA1GP / GPIO19

0 = Default (weak pull-down 20K)

1 = Setting to No-Reboot mode

0 = "top-block swap" mode

1 = Default (weak pull-up 20K)

0 = Override

1 = Default (weak pull-up 20K)

GNT0#GNT1#

11
00

Should not be pull-down
(weak pull-up 20K)

0 = Support by 1.8V (weak pull-down)
1 = Support by 1.5V

0 = Override

1 = Default (weak pull-up 20K)

0 = Disable

1 = Enable (Default)
0 = Default (weak pull-down 20K)

1 = Enable

4

C38
A38
B37
C37

D36
E36

K36
V5

AM3
AM1
AP7
AP5

AM10
AM8
AP11
AP10

AD7
AD5
AH5
AH4

AB8
AB10
AF3
AF1

Y7
Y5
AD3
AD1

Y3
Y1
AB3
AB1

Y11
Y10

AB12
AB13

AH1

P3
V14
P1

Boot Location

SERIRQ

SATA_RXN1
SATA_RXP1
SATA_TXN1
SATA_TXP1

SATA_RXN0
SATA_RXP0
SATA_TXN0
SATA_TXP0

SATA_COMP

SATA3_COMP

SATA3_RBIASPCH_SPI_CLK

SATA0GP

SPI

LPC

3

LAD0 18,20,21
LAD1 18,20,21
LAD2 18,20,21
LAD3 18,20,21

LFRAME# 18,20,21

R357 8.2K_2

+3V
SERIRQ 20,21

SATA_RXN1 14
SATA_RXP1 14
SATA_TXN1 14
SATA_TXP1 14

mSATA (SATA 6Gb/s)

Base HDD

SATA_RXN0 15,17
SATA_RXP0 15,17
SATA_TXN0 15,17
SATA_TXP0 15,17

R361 37.4/F_4

R360 49.9/F_4 R92 33_2

R362 750/F_4

R327 10K/F_2
R344 10K/F_2

R328 *10K/F_2

+1.05V

+3V

SATA0GP 14

for SI 2/21: add SATA0GP

+3V

DG recommended that SATA AC coupling capacitors should be
close to the connector (<100 mils) for optimal signal quality.

+5VPCU

RTC Power trace width 20mils.

R79 2.2K_2

R83

4.7K/F_2

R85
15K

VCCRTC_1

VCCRTC_3

Q2
MMBT3904-7-F

2

13

+3V_RTC_0

2

RTC Clock 32.768KHz

C159 10P/25V_4

C158 10P/25V_4

PV 3/26: Change C158/C159 to 10P & 0402

RTC Circuitry(RTC)

RTC Power trace width 20mils.

+3V_RTC_0

R54 1K/F_2

12

CN1
RTC_CONN

for SI 2/21: Change RTC conn

ACZ_RST#_AUDIO16

ACZ_SDOUT_AUDIO16

BIT_CLK_AUDIO16

C96

*10P/25V_2

ACZ_SYNC_AUDIO16

R102 33_2

Circuit

R249 *1K/F_2

+3V

R40 10K/F_2

+3V

+3V_RTC

R201 330K_4

GPIO33

[Need external pull-down for LPC BIOS]
Default weak pull-up on GNT0/1#

USE GPIO PIN

R323 2.2K_2

+3V

for DS3

+3V_DEEP_SUS

R91 *1K/F_2

R90 *1K/F_2

+3V_DEEP_SUS

3

ACZ_SPKR

PCI_GNT3# 8

PCH_INVRMEN

ACZ_SDOUT

ACZ_SDOUT

R84 1K/F_2

GPIO33_EC 21

NV_CLE 9
H_SNB_IVB# 2

ACZ_SYNC

Vender
EON

AMIC 4MB AKE39F-0800 (A25LQ32AM-F/Q)
Socket

Size

P/N

4MB

AKE39ZN0Q02 (EN25Q32B-104HIP)
AKE39FP0Z02 (MX25L3206EM2I-12G)MX

4MB

DFHS08FS023(91960-0084L-8P-SOCKET)

PCH_SPI_CS0# PCH_SPI_CS0#_R
PCH_SPI_CLK

+3V 2,6,8,9,10,12,13,14,15,16,17,18,19,20,21,25,27,29
+5V 10,14,15,16,17,18,29
+1.8V 10,25
+1.05V 2,4,6,8,10,20,21,25,27
+3VS5 6,9,10,18,19,20,23,25,29
+3VPCU 4,15,17,18,19,21,22,23
+3V_RTC 6,10

2

+3V

12

+3VPCU

+3V_RTC_1

D3
BAT54C

HDA Bus(CLG)

R106 33_2

R117 33_2

R98 10K/F_2

+5V

R101

1M_2

PCH_SPI1_CLK_R
PCH_SPI1_SI_RPCH_SPI_SI
PCH_SPI1_SO_RPCH_SPI_SO

C313
22P/25V_2

NB5

NB5

NB5

BIOS_WP#

R82 3.3K_2

1

RTC_X1

1

C83

R179
10M_4

RTC_X2

30mils

+3V_RTC

2

R195

20K_2

R198
20K_2

C141
*1U/6.3V_2

Q4
2N7002K

3

10P/25V_2

R197 *0_6

ACZ_SYNCACZ_SYNC_R1

C199
1U/6.3V_2

C202
1U/6.3V_2

SRTC_RST#RTC_RST#

SRTC_RST#

Y3

32.768KHz

ACZ_RST#
ACZ_SDOUT
ACZ_BCLK

PCH SPI ROM(CLG)

U3

1

CE#

6

SCK

5

SI

2

SO

3

WP#

EN25Q32B-104HIP

AKE39ZN0800

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

8

VDD

7

R81 3.3K_2

HOLD#

4

VSS

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PCH 2/6 (SATA/HDA/SPI)

PCH 2/6 (SATA/HDA/SPI)

PCH 2/6 (SATA/HDA/SPI)

C57

0.1U/10V_2R324 1K/F_2

1

07

RTC_RST#

+3V

7 29Monday, April 22, 2013

7 29Monday, April 22, 2013

7 29Monday, April 22, 2013

1A

1A

1A

5

PCI/USBOC# Pull-up(CLG)

1

USB_OC6#

2

USB_OC0#

3

PCH_AOCS#
USB_OC5#USB_OC2#

56

R33 0_2

*BLM15AG121SS1

R462

R43 22_2

R77 22_2

R80 22_2

C54
18P/25V_2

EMI(near PCH)

R165 2.2K_2
R213 2.2K_2

+3V

PCI_PIRQA#

R47 8.2K_2

PCI_PIRQB#

R60 8.2K_2

PCI_PIRQC#

R61 8.2K_2

PCI_PIRQD#

R62 8.2K_2

MPC_PWR_CTRL#
ACC_LED#
BT_COMBO_EN#

D D

SI modify on 4/2

for DS3

USB_OC4#
USB_OC1#

USB_OC3#

USB3.0

C C

SI 2/20: R33 stuff

B B

CLK_PCI_TPM20

CLK_33M_DEBUG18

CLK_33M_KBC21

GPIO3
GPIO52
GPIO54

PIRQH#17,21

R51 10K/F_2
R59 10K/F_2
R41 10K/F_2

R44 10K/F_2
R49 10K/F_2
R58 10K/F_2

+3V_DEEP_SUS

RP1

10

9
8
7 4

10K_10P8R_6

USB30_RX1-19

USB30_RX1+19

USB30_TX1-19

USB30_TX1+19

BT_COMBO_EN#18

PCI_GNT3#7

PIRQH#

BOARD_ID39

R50 8.2K_2

+3V

R32 *0_2

CLK_PCI_FB

C53

18P/25V_2

SMBus/Pull-up(CLG)

SI modify on 4/2

SMB_ME1_CLK
SMB_ME1_DAT

A A

PLTRST#(CLG)

R313

PCI_PLTRST#

*0_4/S

PLTRST#

R358
100K/F_2

PLTRST# 2,18,19,20,21

5

Cougar Point-M/Panther Point (PCI,USB,NVRAM)

U11E
HM77

BG26

TP1

BJ26

TP2

BH25

TP3

BJ16

TP4

BG16

TP5

AH38

TP6

AH37

TP7

AK43

TP8

AK45

TP9

C18

TP10

N30

TP11

H3

TP12

AH12

TP13

AM4

TP14

AM5

TP15

Y13

TP16

K24

TP17

L24

TP18

AB46

TP19

AB45

TP20

PCI_PIRQA#
PCI_PIRQB#
PCI_PIRQC#
PCI_PIRQD#

BT_COMBO_EN#

GPIO52
GPIO54

ACC_LED#
PCI_GNT3#

MPC_PWR_CTRL#

GPIO3

PIRQH#_R

PCI_PLTRST#

CLK_PCI_TPM_R

CLK_PCI_FB_R

CLK_PCI_LPC_R

CLK_PCI_EC_R

M20

AY16

BG46

BE28

BC30

BE32
BJ32

BC28

BE30
BF32

BG32

AV26
BB26

AU28

AY30

AU26

AY26
AV28

AW30

B21

K40
K38
H38
G38

C46
C44
E40

D47
E42
F46

G42
G40
C42
D44

K10

C6

H49
H43
J48
K42
H40

TP21
TP22
TP23
TP24

USB3Rn1
USB3Rn2
USB3Rn3
USB3Rn4
USB3Rp1
USB3Rp2
USB3Rp3
USB3Rp4
USB3Tn1
USB3Tn2
USB3Tn3
USB3Tn4
USB3Tp1
USB3Tp2
USB3Tp3
USB3Tp4

PIRQA#
PIRQB#
PIRQC#
PIRQD#

REQ1# / GPIO50
REQ2# / GPIO52
REQ3# / GPIO54

GNT1# / GPIO51
GNT2# / GPIO53
GNT3# / GPIO55

PIRQE# / GPIO2
PIRQF# / GPIO3
PIRQG# / GPIO4
PIRQH# / GPIO5

PME#
PLTRST#

CLKOUT_PCI0
CLKOUT_PCI1
CLKOUT_PCI2
CLKOUT_PCI3
CLKOUT_PCI4

RSVD

(+3V)
(+3V)
(+3V)

(+3V)
(+3V)
(+3V)

(+3V)
(+3V)
(+3V)
(+3V)

PCI

(+3VS5)
(+3VS5)
(+3VS5)
(+3VS5)
(+3VS5)
(+3VS5)
(+3VS5)
(+3VS5)

SMBus/Pull-up(CLG)

+3V_DEEP_SUS

SMB_RUN_DAT12,18

SMB_RUN_CLK12,18

MBCLK22,12,15,21

MBDATA22,12,15,21

R353 4.7K/F_2

+3V

SMB_RUN_DAT

R352 4.7K/F_2

+3V

SMB_RUN_CLK SMB_PCH_CLK

Q13

4 3

1

*2N7002DW

Q24

4 3

1

2N7002DW

USB

4

RSVD1
RSVD2
RSVD3
RSVD4

RSVD5
RSVD6

RSVD7
RSVD8

RSVD9
RSVD10
RSVD11
RSVD12
RSVD13
RSVD14
RSVD15
RSVD16
RSVD17
RSVD18
RSVD19
RSVD20
RSVD21
RSVD22

RSVD23
RSVD24

RSVD25
RSVD26

RSVD27
RSVD28

RSVD29

USBP0N
USBP0P
USBP1N
USBP1P
USBP2N
USBP2P
USBP3N
USBP3P
USBP4N
USBP4P
USBP5N
USBP5P
USBP6N
USBP6P
USBP7N
USBP7P
USBP8N
USBP8P
USBP9N
USBP9P

USBP10N
USBP10P
USBP11N
USBP11P
USBP12N
USBP12P
USBP13N
USBP13P

USBRBIAS#

USBRBIAS

OC0# / GPIO59
OC1# / GPIO40
OC2# / GPIO41
OC3# / GPIO42
OC4# / GPIO43

OC5# / GPIO9
OC6# / GPIO10
OC7# / GPIO14

+3V

5

2
6

+3V

5

SMB_PCH_DAT

2
6

4

AY7
AV7
AU3
BG4

AT10
BC8

AU2
AT4
AT3
AT1
AY3
AT5
AV3
AV1
BB1
BA3
BB5
BB3
BB7
BE8
BD4
BF6

AV5
AV10

AT8
AY5

BA2
AT12

BF3

C24
A24
C25
B25
C26
A26
K28
H28
E28
D28
C28
A28
C29
B29
N28
M28
L30
K30
G30
E30
C30
A30
L32
K32
G32
E32
C32
A32

C33

B33

A14
K20
B17
C16
L16
A16
D14
C14

SMB_ME1_CLK

SMB_ME1_DAT

PCIE_RXN3_WLAN18
PCIE_RXP3_WLAN18

WLAN

Cardreader

PCIE_TXN3_WLAN18
PCIE_TXP3_WLAN18

PCIE_RXN2_CARD19
PCIE_RXP2_CARD19

PCIE_TXN2_CARD19
PCIE_TXP2_CARD19

MPC_PWR_CTRL#

ACC_LED#

12/13 Add for EMI

for SI 2/21: Change USB net name

USB-_COMBO 17
USB+_COMBO 17

USB-_SENSOR 13

USB+_SENSOR 13
USB-_CAMERA 13
USB+_CAMERA 13
USB-_CR 17
USB+_CR 17

USB2.0/USB3.0 COMBO 1st

USB2.0(M/B-1)

Sensor HUB
Camera

(USBP2)

USB2.0 Cardreader

for SI 2/21: Change USB net name

USB_BIAS

USB_OC0#
USB_OC1#
USB_OC2#
USB_OC3#
USB_OC4#
USB_OC5#
USB_OC6#
PCH_AOCS#

USB-_TP 17

USB+_TP 17

USB-_LEFT 17
USB+_LEFT 17
USB-_WLAN 18
USB+_WLAN 18
USB-_TS 15
USB+_TS 15

R100

22.6/F_4

(USBP8)

TP

(USBP9)

USB2.0

(USBP10)

WLAN

Touch Screen

10/25:modify for 14/15 co-lay

CLK_REQ/Strap Pin(CLG)

CLK_PCIE_REQ1#
PCIE_CLKREQ_CR#

PCIE_CLKREQ_WLAN#
CLK_PCIE_REQ3#
CLK_PCIE_REQ4#

CLK_PEGB_REQ#
CLK_PEGA_REQ#

CLK_BUF_BCLK_N
CLK_BUF_BCLK_P

CLK_BUF_PCIE_3GPLL#
CLK_BUF_PCIE_3GPLL
CLK_BUF_DREFCLK#
CLK_BUF_DREFCLK
CLK_BUF_DREFSSCLK#
CLK_BUF_DREFSSCLK
CLK_PCH_14M

CLOCK TERMINATION for FCIM

R332 10K/F_2
R347 10K/F_2

for DS3for DS3

R340 10K/F_2
R293 10K/F_2
R235 10K/F_2

Intel DG request

R307 10K/F_2
R325 10K/F_2

R137 10K/F_2 R303 2.2K_2
R131 10K/F_2

R239 10K/F_2
R248 10K/F_2
R142 10K/F_2
R143 10K/F_2
R341 10K/F_2
R342 10K/F_2
R69 10K/F_2

C110 0.1U/10V_2
C108 0.1U/10V_2

C95 0.1U/10V_2
C88 0.1U/10V_2

MPC Switch Control

MPC_PWR_CTRL#

R48 *1K/F_2

EC2 680P/16V_2

(USBP0)

(USBP1)

(USBP3)

Cardreader

(USBP11)

+3V

+3V_DEEP_SUS

3

Cougar Point-M/Panther Point (PCI-E,SMBUS,CLK)

PCIE_TXN3_C
PCIE_TXP3_C

PCIE_TXN2_CR_C
PCIE_TXP2_CR_C

Low = MPC ON
High = MPC OFF (Default)

CLK_PCIE_WLANN
CLK_PCIE_WLANP

WLAN

PCIE_CLKREQ_WLAN#

CLK_PCIE_REQ1#

CLK_PCIE_CRN
CLK_PCIE_CRP

PCIE_CLKREQ_CR#

CLK_PCIE_REQ3#

CLK_PCIE_REQ4#

BOARD_ID09

CLK_PEGB_REQ#

BOARD_ID19

BOARD_ID29

PCIE Clock

WLAN

Cardreader

3

PCIE_CLKREQ_WLAN#18

CLK_PCIE_WLANN18
CLK_PCIE_WLANP18

CLK_PCIE_CRN19
CLK_PCIE_CRP19

PCIE_CLKREQ_CR#19

U11B
HM77

BG34

PERN1

BJ34

PERP1

AV32

PETN1

AU32

PETP1

BE34

PERN2

BF34

PERP2

BB32

PETN2

AY32

PETP2

BG36

PERN3

BJ36

PERP3

AV34

PETN3

AU34

PETP3

BF36

PERN4

BE36

PERP4

AY34

PETN4

BB34

PETP4

BG37

PERN5

BH37

PERP5

AY36

PETN5

BB36

PETP5

BJ38

PERN6

BG38

PERP6

AU36

PETN6

AV36

PETP6

BG40

PERN7

BJ40

PERP7

AY40

PETN7

BB40

PETP7

BE38

PERN8

BC38

PERP8

AW38

PETN8

AY38

PETP8

Y40

CLKOUT_PCIE0N

Y39

CLKOUT_PCIE0P

J2

PCIECLKRQ0# / GPIO73

(+3VS5)

AB49

CLKOUT_PCIE1N

AB47

CLKOUT_PCIE1P

M1

PCIECLKRQ1# / GPIO18

(+3V)

AA48

CLKOUT_PCIE2N

AA47

CLKOUT_PCIE2P

V10

PCIECLKRQ2# / GPIO20

(+3V)

Y37

CLKOUT_PCIE3N

Y36

CLKOUT_PCIE3P

A8

PCIECLKRQ3# / GPIO25

(+3VS5)

Y43

CLKOUT_PCIE4N

Y45

CLKOUT_PCIE4P

L12

PCIECLKRQ4# / GPIO26

(+3VS5)

V45

CLKOUT_PCIE5N

V46

CLKOUT_PCIE5P

L14

PCIECLKRQ5# / GPIO44

(+3VS5)

AB42

CLKOUT_PEG_B_N

AB40

CLKOUT_PEG_B_P

E6

PEG_B_CLKRQ# / GPIO56

(+3VS5)

V40

CLKOUT_PCIE6N

V42

CLKOUT_PCIE6P

T13

PCIECLKRQ6# / GPIO45

(+3VS5)

V38

CLKOUT_PCIE7N

V37

CLKOUT_PCIE7P

K12

PCIECLKRQ7# / GPIO46

(+3VS5)

AK14

CLKOUT_ITPXDP_N

AK13

CLKOUT_ITPXDP_P

SMBUSController

SML1ALERT# / PCHHOT# / GPIO74

PCI-E*

CLOCKS

CLK_PCIE_WLANN
CLK_PCIE_WLANP

PCIE_CLKREQ_WLAN#

CLK_PCIE_CRN
CLK_PCIE_CRP

PCIE_CLKREQ_CR#

2

(+3VS5)

E12

SMBALERT# / GPIO11

SML0ALERT# / GPIO60

SML1CLK / GPIO58

SML1DATA / GPIO75

Link

PEG_A_CLKRQ# / GPIO47

CLKOUT_PEG_A_N
CLKOUT_PEG_A_P

CLKOUT_DMI_N
CLKOUT_DMI_P

CLKOUT_DP_N
CLKOUT_DP_P

CLKIN_DMI_N
CLKIN_DMI_P

CLKIN_GND1_N
CLKIN_GND1_P

CLKIN_DOT_96N
CLKIN_DOT_96P

CLKIN_SATA_N
CLKIN_SATA_P

REFCLK14IN

CLKIN_PCILOOPBACK

XTAL25_OUT

XCLK_RCOMP

CLKOUTFLEX0 / GPIO64
CLKOUTFLEX1 / GPIO65
CLKOUTFLEX2 / GPIO66
CLKOUTFLEX3 / GPIO67

FLEX CLOCKS

SMBCLK

SMBDATA

(+3VS5)

SML0CLK

SML0DATA

(+3VS5)
(+3VS5)

(+3VS5)

CL_CLK1

CL_DATA1

CL_RST1#

(+3VS5)

XTAL25_IN

(+3V)
(+3V)

(+3V)
(+3V)

SMBALERT#

H14

SMB_PCH_CLK

C9

SMB_PCH_DAT

A12

DRAMRST_CNTRL_PCH

C8

SMB_ME0_CLK

G12

SMB_ME0_DAT

C13

FPR_OFF

E14

SMB_ME1_CLK

M16

SMB_ME1_DAT

M7

T11

P10

M10

CLK_PEGA_REQ#

AB37
AB38

AV22
AU22

AM12
AM13

BF18

CLK_BUF_PCIE_3GPLL#

BE18

CLK_BUF_PCIE_3GPLL

BJ30

CLK_BUF_BCLK_N

BG30

CLK_BUF_BCLK_P

G24

CLK_BUF_DREFCLK#

E24

CLK_BUF_DREFCLK

AK7

CLK_BUF_DREFSSCLK#

AK5

CLK_BUF_DREFSSCLK

K45

CLK_PCH_14M

H45

CLK_PCI_FB

V47

XTAL25_IN

V49

XTAL25_OUT

Y47

XCLK_RCOMP

K43
F47
H47
K49

PV-1 4/22: C30/31 Change to 10P

for DS3

+3V2,6,7,9,10,12,13,14,15,16,17,18,19,20,21,25,27,29

+3VS56,9,10,18,19,20,23,25,29

2

1

DRAMRST_CNTRL_PCH 2

TP16

CLK_CPU_BCLKN 2
CLK_CPU_BCLKP 2

CLK_DPLL_SSCLKN 2
CLK_DPLL_SSCLKP 2

PV-1 4/15: Change Y2 footprint

R34 90.9/F_4

XTAL25_IN
XTAL25_OUT

+3V_DEEP_SUS

PV modify on 5/24

R229 10K/F_2
R275 2.2K_2
R274 2.2K_2

R228 2.2K_2
R212 10K/F_2

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

+1.05V

TP36

C30 10P/25V_2

23

R35

Y2

1M_2

25MHZ +-10PPM

4 1

C31 10P/25V_2

TP35

SMBus/Pull-up(CLG)

SMBALERT#
SMB_PCH_CLK
SMB_PCH_DAT
SMB_ME0_CLK
SMB_ME0_DAT
FPR_OFF

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PCH 3/6 (PCIE/USB/CLK)

PCH 3/6 (PCIE/USB/CLK)

PCH 3/6 (PCIE/USB/CLK)

1

08

8 29Monday, April 22, 2013

8 29Monday, April 22, 2013

8 29Monday, April 22, 2013

1A

1A

1A

5

Cougar Point/Panther Point (GPIO,VSS_NCTF,RSVD)

Cougar Point/Panther Point (GPIO,VSS_NCTF,RSVD)

Cougar Point/Panther Point (GPIO,VSS_NCTF,RSVD)Cougar Point/Panther Point (GPIO,VSS_NCTF,RSVD)

PCI_SERR#21

SIO_EXT_SMI#21

D D

RF_OFF18

Vibrator _Out#15,21

for DS3

for SI 2/20: change net from "DEVSLP1" to "SATA2GP"

C C

CHIP_DOCK_DET#17

GPIO27_EC21

+3V

SATA2GP21

BT_OFF18

R337 10K/F_2

2011 12 01 : Modify net from DGPU_PRSNT# to DGPU_PRSNT

OPTIMUS POWER control pin
DGPU_PWROK GPIO17
DGPU_HOLD_RST#
DGPU_PWR_EN

B B

GPIO24
GPIO36

PCI_SERR#

R73 *0_4

R238 *0_4

SIO_EXT_SMI#
BOARD_ID4
BOARD_ID5
BT_OFF
LAN_DISABLE#_R
RF_OFF

ODD_PRSNT#_R

Vibrator _Out#_R
BIOS_REC

CHIP_DOCK_DET#

GPIO27

GPIO34

SATA2GP

FDI_OVRVLTG
MFG_MODE
DGPU_PRSNT
TEST_SET_UP
SATA5GP
SV_DET

U11F
HM77

T7

BMBUSY# / GPIO0

(+3V)

A42

TACH1 / GPIO1

(+3V)

H36

TACH2 / GPIO6

(+3V)

E38

TACH3 / GPIO7

(+3V)

C10

GPIO8

(+3VS5)

C4

LAN_PHY_PWR_CTRL / GPIO12

(+3VS5)

G2

GPIO15

(+3VS5)

U2

SATA4GP / GPIO16

(+3V)

D40

TACH0 / GPIO17

(+3V)

T5

SCLOCK / GPIO22

(+3V)

E8

GPIO24

(+3VS5)

E16

GPIO27

(DSW)

P8

GPIO28

(+3VS5)

K1

STP_PCI# / GPIO34

(+3V)

K4

GPIO35

(+3V)

V8

SATA2GP / GPIO36

(+3V)

M5

SATA3GP / GPIO37

(+3V)

N2

SLOAD / GPIO38

(+3V)

M3

SDATAOUT0 / GPIO39

(+3V)

V13

SDATAOUT1 / GPIO48

(+3V)

V3

SATA5GP / GPIO49 / TEMP_ALERT#

(+3V)

D6

GPIO57

(+3VS5)

A4

VSS_NCTF_1

A44

VSS_NCTF_2

A45

VSS_NCTF_3

A46

VSS_NCTF_4

A5

VSS_NCTF_5

A6

VSS_NCTF_6

B3

VSS_NCTF_7

B47

VSS_NCTF_8

BD1

VSS_NCTF_9

BD49

VSS_NCTF_10

BE1

VSS_NCTF_11

BE49

VSS_NCTF_12

BF1

VSS_NCTF_13

BF49

VSS_NCTF_14

4

C40

PECI

B41
C41
A40

P4
AU16
P5
AY11
AY10
T14
AY1

AH8
AK11
AH10
AK10

P37

BG2
BG48
BH3
BH47
BJ4
BJ44
BJ45
BJ46
BJ5
BJ6
C2
C48
D1
D49
E1
E49
F1
F49

GPIO68

GPIO69

GPIO70

EC_RCIN#

PCH_THRMTRIP#

NV_CLE

TACH4 / GPIO68

(+3V)

TACH5 / GPIO69

(+3V)

TACH6 / GPIO70

(+3V)

TACH7 / GPIO71

(+3V)

A20GATE

RCIN#

PROCPWRGD

NCTF

THRMTRIP#

INIT3_3V#

CPU/MISC

TS_VSS1
TS_VSS2
TS_VSS3
TS_VSS4

VSS_NCTF_15
VSS_NCTF_16
VSS_NCTF_17
VSS_NCTF_18
VSS_NCTF_19
VSS_NCTF_20
VSS_NCTF_21
VSS_NCTF_22
VSS_NCTF_23
VSS_NCTF_24
VSS_NCTF_25
VSS_NCTF_26
VSS_NCTF_27
VSS_NCTF_28
VSS_NCTF_29
VSS_NCTF_30
VSS_NCTF_31
VSS_NCTF_32

DF_TVS

NC_1

GPIO

R38 10K/F_2

R36 1.5K/F_4
R28 *1.5K/F_4

FPR_LOCK#

R312 390_4

NV_CLE 7

3

2

1

09

+3V

+3V

TP32

EC_A20GATE 21

EC_RCIN# 21
H_PWRGOOD 2
PM_THRMTRIP# 2,21

GPIO Pull-up/Pull-down(CLG)

MFG-TEST

MFG_MODE

R330 10K/F_2

Bios swap GPIO.

PCI_SERR#

R320 10K/F_2
R350 *0_4

for DS3

RF_OFF

Intel ME Crypto Transport Layer
Security (TLS) cipher suite

Low = Disable (Default)
High = Enable

SV_SET_UP
High = Strong (Default)

R338 1K/F_2

TEST_SET_UP SV_DET

R345 10K/F_2

+3V

for SI 2/21: reserve R430

+3V

+3V_DEEP_SUS

BIOS RECOVERY High = Disable (Default)

+3V

R339 100K/F_2

BT_OFF
LAN_DISABLE#_R

CHIP_DOCK_DET#

SIO_EXT_SMI#
BT_OFF
EC_A20GATE
EC_RCIN#
SATA5GP
GPIO70
FPR_LOCK#
ODD_PRSNT#_R
Vibrator _Out#_R
SATA2GP

SATA2GP
Vibrator _Out#_R

GPIO27

BIOS_REC

Low = Enable

TEST DETECT
Low = Default

R297 10K/F_2
R309 10K/F_2

R230 10K/F_2

R31 10K/F_2
R298 *10K/F_2
R250 10K/F_2
R251 10K/F_2
R346 10K/F_2
R27 1.5K/F_4
R29 1.5K/F_4
R348 10K/F_2
R72 10K/F_2
R322 10K/F_2

R430 *10K/F_2
R71 *10K/F_2

R217 10K/F_2
R216 *10K/F_2

R343 10K/F_2

for DS3

+3V_DEEP_SUS

+3V

+3VS5

+3V

Chief River BOARD ID SETTING

BOARD_ID0

BOARD_ID1

BOARD_ID2

BOARD_ID3

BOARD_ID4

BOARD_ID5

DGPU_PRSNT

SG
Ra
Rb

BOARD_ID0
BOARD_ID1
BOARD_ID2
BOARD_ID3

R210 *10K/F_2

R329 *10K/F_2

R227 *10K/F_2

R30 *10K/F_2

R66 *10K/F_2

R63 *10K/F_2

R334 *10K/F_2

UMA
Rb
Ra

for DS3

R349 100K/F_2

+3V_DEEP_SUS

+3V_DEEP_SUS

+3V_DEEP_SUS

+3V

SATA2GP/GPIO36 Reserved only

FDI TERMINATION
VOLTAGE OVERRIDE

RaRb

NB5

NB5

3

2

NB5

FDI_OVRVLTG

Reserved only

+3V2,6,7,8,10,12,13,14,15,16,17,18,19,20,21,25,27,29

+3VS56,10,18,19,20,23,25,29

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

PCH 4/6 (GPIO/MISC)

PCH 4/6 (GPIO/MISC)

PCH 4/6 (GPIO/MISC)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

9 29Monday, April 22, 2013

9 29Monday, April 22, 2013

9 29Monday, April 22, 2013

1A

1A

1A

BOARD_ID08
BOARD_ID18
BOARD_ID28

BOARD_ID4

BOARD_ID5

0

0

0

0

0

0 0

14": 0
15": 1

0

0

0

0

0

1

0

0

0

Model

U62 UMA

U62 DIS

A A

14"

15.6"

BOARD_ID1BOARD_ID2BOARD_ID3

BOARD_ID0

0

0

0

0

0

0

0

0

0 0 0

UMA: 0
DIS: 1

00000

1

0

0

0

BOARD_ID38

R209 10K/F_2

R354 10K/F_2

R236 10K/F_2

R42 10K/F_2

R65 10K/F_2

R64 10K/F_2

R333 10K/F_2

Stuff
NC

5

4

5

4

3

2

1

Cougar Point/Panther Point (POWER)

U11J

HM77

AD49

VCCACLK

+VCCSST

BH23

AL29

AL24

AA19
AA21
AA24
AA26
AA27
AA29
AA31
AC26
AC27
AC29
AC31
AD29
AD31

W21
W23
W24
W26
W29
W31
W33

BD47

BF47

AF17
AF33
AF34

AG34

AG33

T16

V12

T38

N16

Y49

V16

T17
V19

BJ8

A22

VCCDSW3_3

DCPSUSBYP

VCC3_3[5]

VCCAPLLDMI2
VCCIO[14]

DCPSUS[3]

VCCASW[1]
VCCASW[2]
VCCASW[3]
VCCASW[4]
VCCASW[5]
VCCASW[6]
VCCASW[7]
VCCASW[8]
VCCASW[9]
VCCASW[10]
VCCASW[11]
VCCASW[12]
VCCASW[13]
VCCASW[14]
VCCASW[15]
VCCASW[16]
VCCASW[17]
VCCASW[18]
VCCASW[19]
VCCASW[20]

DCPRTC

VCCVRM[4]

VCCADPLLA
VCCADPLLB

VCCIO[7]
VCCDIFFCLKN[1]
VCCDIFFCLKN[2]
VCCDIFFCLKN[3]

VCCSSC

DCPSST

DCPSUS[1]
DCPSUS[2]

V_PROC_IO

VCCRTC

R363 *0_4/S

+3VS5

D D

+1.05V

C C

+1.05V

C204

1U/6.3V_2

R88 *0_4/S

+1.05V

B B

+1.05V

+1.05V

V_PROC_IO=2mA
(10mils)

A A

VCCRTC<1mA
(10mils)

C78

1U/6.3V_2

R157 *0_4/S

C151

1U/6.3V_2

+3V_RTC

+VCCDSW3_3

C310

0.1U/10V_2

+1.05V

VCCASW:803mA (40mils)

C136
1U/6.3V_2

C283

4.7U/6.3V_6

C170
1U/6.3V_2

5

C184
1U/6.3V_2

C26
22U/6.3VS_8

+VCCAFDI_VRM

160mA (20mils)

+1.05V_VCCA_A_DPL

65mA (10mils)

+1.05V_VCCA_B_DPL

8mA (10mils)

+VCCDIFFCLKN

55mA (10mils)

+V1.05V_SSCVCC

95mA (10mils)

C311

0.1U/10V_2

C278

0.1U/10V_2

C169

0.1U/10V_2

+3V2,6,7,8,9,12,13,14,15,16,17,18,19,20,21,25,27,29
+5V7,14,15,16,17,18,29

+1.8V25

+1.05V2,4,6,7,8,20,21,25,27

+3VS56,9,18,19,20,23,25,29
+5VS56,23,24,25,26,27,29

3mA (10mils)

+3V_SUS_CLKF33

+VCCSUS1

C206
*1U/6.3V_2

C156
1U/6.3V_2

C25
22U/6.3VS_8

C112

0.1U/10V_2

+VCCRTCEXT

C270

0.1U/10V_2

C168

0.1U/10V_2

POWER

C217

0.1U/10V_2

+1.5V_CPU

3

+1.05V

R190 10_4

D7 RB500V-40

+3V

(Mobile 1.5V)

R189 *0_4/S

+1.05V

+1.05V

+1.05V

L5
10uH/100MA_8

L4
10uH/100MA_8

+3V

VCCCore:1.73 A (100mils)

C157
1U/6.3V_2

C215
10U/6.3VS_6

for DS3

+5V_DEEP_SUS
+3V_DEEP_SUS

+1.05V

VCCIO:3.799 A (140mils)

C133
1U/6.3V_2

C229
10U/6.3VS_6

C117
1U/6.3V_2

178m A (20mils)

+VCCAFDI_VRM

+1.05V_VCCA_A_DPL

+1.05V_VCCA_B_DPL

20mA (10mils)

+3V_SUS_CLKF33

20mA (10mils)

160mA (15mils)

N26

VCCIO[29]

P26

VCCIO[30]

P28

VCCIO[31]

T27

VCCIO[32]

T29

VCCIO[33]

VCCIO[34]

DCPSUS[4]

V5REF

VCC3_3[1]
VCC3_3[8]
VCC3_3[4]

VCC3_3[2]

VCCIO[5]

VCCIO[12]
VCCIO[13]

VCCIO[6]

VCCVRM[1]

VCCIO[2]
VCCIO[3]
VCCIO[4]

T23
T24
V23
V24
P24

T26

M26

AN23
AN24

P34

N20
N22
P20
P22

AA16
W16
T34

AJ2

AF13

AH13
AH14

AF14
AK1

AF11

AC16
AC17
AD17

1.01A (60mils)

T21

V21

T19

P32

70mA

30mA

+5V_PCH_VCC5REFSUS

+VCCA_USBSUS

for DS3

+5V_PCH_VCC5REF

119mA (15mils)

266mA (20mils)

+3V

C137

0.1U/10V_2

350mA

+VCCAFDI_VRM

+1.05V

10mA (10mils)

C219

0.1U/10V_2

VCCSUS3_3[7]
VCCSUS3_3[8]
VCCSUS3_3[9]

VCCSUS3_3[10]

VCCSUS3_3[6]

V5REF_SUS

VCCSUS3_3[1]

VCCSUS3_3[2]
VCCSUS3_3[3]
VCCSUS3_3[4]
VCCSUS3_3[5]

Clock and Miscellaneous

PCI/GPIO/LPCMISC

VCCAPLLSATA

SATA USB

VCCASW[22]

VCCASW[23]

CPURTC

VCCASW[21]

VCCSUSHDA

HDA

+3V_RTC6,7

+1.5VSUS2,4,12,24

+1.5V_CPU2,4,14,16,18

4

+1.05V

C212
1U/6.3V_2

C142

0.1U/10V_2

C213

0.1U/10V_2

+1.05V

C205 *1U/6.3V_2

+3V_DEEP_SUS

1mA (10mils)

for DS3

+3V_DEEP_SUS

C220
1U/6.3V_2

+3V

C62

0.1U/10V_2

+3V

C303

0.1U/10V_2

C194
1U/6.3V_2

C200
1U/6.3V_2

C152
1U/6.3V_2

for DS3

+3V_DEEP_SUS

C218
*1U/6.3V_2

for DS3

+3V_DEEP_SUS

VCCSUS3_3:65mA(15mils)

VCC5REFSUS=1mA

+1.05V

+1.05V

Cougar Point/Panther Point (POWER)

C124
1U/6.3V_2

C120
1U/6.3V_2

+1.05V

C188
1U/6.3V_2

C147
1U/6.3V_2

C145

0.1U/10V_2

+VCCAFDI_VRM

Close to Y49

AA23
AC23
AD21
AD23

AF21

AF23
AG21
AG23
AG24
AG26
AG27
AG29

AJ23

AJ26

AJ27

AJ29

AJ31

AN19

BJ22

AN16
AN17

AN21
AN26
AN27
AP21
AP23
AP24
AP26

AT24

AN33
AN34

BH29

AP16

AP17

AU20

C35 1U/6.3V_2

C34 1U/6.3V_2

L2
10uH/100MA_8

C41
1U/6.3V_2

U11G
HM77

VCCCORE[1]
VCCCORE[2]
VCCCORE[3]
VCCCORE[4]
VCCCORE[5]
VCCCORE[6]
VCCCORE[7]
VCCCORE[8]
VCCCORE[9]
VCCCORE[10]
VCCCORE[11]
VCCCORE[12]
VCCCORE[13]
VCCCORE[14]
VCCCORE[15]
VCCCORE[16]
VCCCORE[17]

VCCIO[28]

VCCAPLLEXP

VCCIO[15]
VCCIO[16]

VCCIO[17]
VCCIO[18]
VCCIO[19]
VCCIO[20]
VCCIO[21]
VCCIO[22]
VCCIO[23]
VCCIO[24]

VCCIO[25]
VCCIO[26]

VCC3_3[3]

VCCVRM[2]

BG6

VccAFDIPLL

VCCIO[27]

VCCDMI[2]

C27 1U/6.3V_2
C22 10U/6.3VS_6

POWER

CRTLVDS

VCC CORE

DMI

VCCIO

DFT / SPI HVCMOS

FDI

C208
1U/6.3V_2

Close to AT16 Close to AP16

2

C214
1U/6.3V_2

VCCADAC

VSSADAC

VCCALVDS

VSSALVDS

VCCTX_LVDS[1]
VCCTX_LVDS[2]
VCCTX_LVDS[3]
VCCTX_LVDS[4]

VCC3_3[6]

VCC3_3[7]

VCCVRM[3]

VCCDMI[1]

VCCCLKDMI

VCCDFTERM[1]

VCCDFTERM[2]

VCCDFTERM[3]

VCCDFTERM[4]

VCCSPI

NB5

NB5

NB5

U48

U47

AK36
AK37

AM37
AM38
AP36
AP37

SG & UMA : Ra
DIS : Rb

V33

V34

AT16

+VCCAFDI_VRM

AT20

AB36

AG16

AG17

AJ16

AJ17

V1

+5V_PCH_VCC5REF

V5REF= 1mA

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

6.3mA (10mils)

10

C37 *0.1U/10V_2

1mA (10mils)

60mA (10mils)

C171
1U/6.3V_2

C226
1U/6.3V_2

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

PCH 5/6 (POWER)

PCH 5/6 (POWER)

PCH 5/6 (POWER)

+3V

L3

*0.1uH/250mA_8

C39 *0.01U/16V_4

C61

0.1U/10V_2

42mA (10mils)

C144
1U/6.3V_2

+1.05V

C201
*10U/6.3V_6

2 mA (10mils)

C60

0.1U/10V_2

10mA (10mils)

C312
1U/6.3V_2

R220 10_4
D8 RB500V-40

1

+1.05V

10 29Monday, April 22, 2013

10 29Monday, April 22, 2013

10 29Monday, April 22, 2013

+3V

+5V
+3V

+1.8V+VCC_TX_LVDS

+3V

+3V

1A

1A

1A

5

4

3

2

1

Cougar Point/Panther Point (GND)

U11I
HM77

AY4

VSS[159]

AY42

VSS[160]

AY46

VSS[161]

AY8

VSS[162]

B11

VSS[163]

B15

BB12
BB16
BB20
BB22
BB24
BB28
BB30
BB38

BB46
BC14
BC18

BC22
BC26
BC32
BC34
BC36
BC40
BC42
BC48
BD46

BE22
BE26
BE40

BF10
BF12
BF16
BF20
BF22
BF24
BF26
BF28

BF30
BF38
BF40

BG17
BG21
BG33
BG44

BH11
BH15
BH17
BH19

BH27
BH31
BH33
BH35
BH39
BH43

B19
B23
B27
B31
B35
B39

BB4

BC2

BD5

BD3

BF8

BG8

H10

BH7
D12

D16
D18
D22
D24
D26
D30
D32
D34
D38
D42

E18
E26
G18
G20
G26
G28
G36
G48
H12
H18
H22
H24
H26
H30
H32
H34

VSS[164]
VSS[165]
VSS[166]
VSS[167]
VSS[168]
VSS[169]
VSS[170]

B7

VSS[171]

F45

VSS[172]
VSS[173]
VSS[174]
VSS[175]
VSS[176]
VSS[177]
VSS[178]
VSS[179]
VSS[180]
VSS[181]
VSS[182]
VSS[183]
VSS[184]
VSS[185]
VSS[186]
VSS[187]
VSS[188]
VSS[189]
VSS[190]
VSS[191]
VSS[192]
VSS[193]
VSS[194]
VSS[195]
VSS[196]
VSS[197]
VSS[198]
VSS[199]
VSS[200]
VSS[201]
VSS[202]
VSS[203]
VSS[204]
VSS[205]
VSS[206]
VSS[207]
VSS[208]
VSS[209]
VSS[210]
VSS[211]
VSS[212]
VSS[213]
VSS[214]
VSS[215]
VSS[216]
VSS[217]
VSS[218]
VSS[219]
VSS[220]
VSS[221]
VSS[222]
VSS[223]
VSS[224]
VSS[225]
VSS[226]
VSS[227]
VSS[228]

D3

VSS[229]
VSS[230]
VSS[231]
VSS[232]
VSS[233]
VSS[234]
VSS[235]
VSS[236]
VSS[237]
VSS[238]
VSS[239]
VSS[240]

D8

VSS[241]
VSS[242]
VSS[243]
VSS[244]
VSS[245]
VSS[246]
VSS[247]
VSS[248]
VSS[249]
VSS[250]
VSS[251]
VSS[252]
VSS[253]
VSS[254]
VSS[255]
VSS[256]
VSS[257]

F3

VSS[258]

D D

C C

B B

A A

5

VSS[259]
VSS[260]
VSS[261]
VSS[262]
VSS[263]
VSS[264]
VSS[265]
VSS[266]
VSS[267]
VSS[268]
VSS[269]
VSS[270]
VSS[271]
VSS[272]
VSS[273]
VSS[274]
VSS[275]
VSS[276]
VSS[277]
VSS[278]
VSS[279]
VSS[280]
VSS[281]
VSS[282]
VSS[283]
VSS[284]
VSS[285]
VSS[286]
VSS[287]
VSS[288]
VSS[289]
VSS[290]
VSS[291]
VSS[292]
VSS[293]
VSS[294]
VSS[295]
VSS[296]
VSS[297]
VSS[298]
VSS[299]
VSS[300]
VSS[301]
VSS[302]
VSS[303]
VSS[304]
VSS[305]
VSS[306]
VSS[307]
VSS[308]
VSS[309]
VSS[310]
VSS[311]
VSS[312]
VSS[313]
VSS[314]
VSS[315]
VSS[316]
VSS[317]
VSS[318]
VSS[319]
VSS[320]
VSS[321]
VSS[322]
VSS[323]
VSS[324]
VSS[325]
VSS[328]
VSS[329]
VSS[330]
VSS[331]
VSS[333]
VSS[334]
VSS[335]
VSS[337]
VSS[338]
VSS[340]
VSS[342]
VSS[343]
VSS[344]
VSS[345]
VSS[346]
VSS[347]
VSS[348]
VSS[349]
VSS[350]
VSS[351]
VSS[352]

4

H46
K18
K26
K39
K46
K7
L18
L2
L20
L26
L28
L36
L48
M12
P16
M18
M22
M24
M30
M32
M34
M38
M4
M42
M46
M8
N18
P30
N47
P11
P18
T33
P40
P43
P47
P7
R2
R48
T12
T31
T37
T4
W34
T46
T47
T8
V11
V17
V26
V27
V29
V31
V36
V39
V43
V7
W17
W19
W2
W27
W48
Y12
Y38
Y4
Y42
Y46
Y8
BG29
N24
AJ3
AD47
B43
BE10
BG41
G14
H16
T36
BG22
BG24
C22
AP13
M14
AP3
AP1
BE16
BC16
BG28
BJ28

Cougar Point/Panther Point (GND)

U11H
HM77

H5

VSS[0]

AA17

VSS[1]

AA2

VSS[2]

AA3

VSS[3]

AA33

VSS[4]

AA34

VSS[5]

AB11

VSS[6]

AB14

VSS[7]

AB39

VSS[8]

AB4

VSS[9]

AB43

VSS[10]

AB5

VSS[11]

AB7

VSS[12]

AC19

VSS[13]

AC2

VSS[14]

AC21

VSS[15]

AC24

VSS[16]

AC33

VSS[17]

AC34

VSS[18]

AC48

VSS[19]

AD10

VSS[20]

AD11

VSS[21]

AD12

VSS[22]

AD13

VSS[23]

AD19

VSS[24]

AD24

VSS[25]

AD26

VSS[26]

AD27

VSS[27]

AD33

VSS[28]

AD34

VSS[29]

AD36

VSS[30]

AD37

VSS[31]

AD38

VSS[32]

AD39

VSS[33]

AD4

VSS[34]

AD40

VSS[35]

AD42

VSS[36]

AD43

VSS[37]

AD45

VSS[38]

AD46

VSS[39]

AD8

VSS[40]

AE2

VSS[41]

AE3

VSS[42]

AF10

VSS[43]

AF12

VSS[44]

AD14

VSS[45]

AD16

VSS[46]

AF16

VSS[47]

AF19

VSS[48]

AF24

VSS[49]

AF26

VSS[50]

AF27

VSS[51]

AF29

VSS[52]

AF31

VSS[53]

AF38

VSS[54]

AF4

VSS[55]

AF42

VSS[56]

AF46

VSS[57]

AF5

VSS[58]

AF7

VSS[59]

AF8

VSS[60]

AG19

VSS[61]

AG2

VSS[62]

AG31

VSS[63]

AG48

VSS[64]

AH11

VSS[65]

AH3

VSS[66]

AH36

VSS[67]

AH39

VSS[68]

AH40

VSS[69]

AH42

VSS[70]

AH46

VSS[71]

AH7

VSS[72]

AJ19

VSS[73]

AJ21

VSS[74]

AJ24

VSS[75]

AJ33

VSS[76]

AJ34

VSS[77]

AK12

VSS[78]

AK3

VSS[79]

3

VSS[80]
VSS[81]
VSS[82]
VSS[83]
VSS[84]
VSS[85]
VSS[86]
VSS[87]
VSS[88]
VSS[89]
VSS[90]
VSS[91]
VSS[92]
VSS[93]
VSS[94]
VSS[95]
VSS[96]
VSS[97]
VSS[98]

VSS[99]
VSS[100]
VSS[101]
VSS[102]
VSS[103]
VSS[104]
VSS[105]
VSS[106]
VSS[107]
VSS[108]
VSS[109]
VSS[110]
VSS[111]
VSS[112]
VSS[113]
VSS[114]
VSS[115]
VSS[116]
VSS[117]
VSS[118]
VSS[119]
VSS[120]
VSS[121]
VSS[122]
VSS[123]
VSS[124]
VSS[125]
VSS[126]
VSS[127]
VSS[128]
VSS[129]
VSS[130]
VSS[131]
VSS[132]
VSS[133]
VSS[134]
VSS[135]
VSS[136]
VSS[137]
VSS[138]
VSS[139]
VSS[140]
VSS[141]
VSS[142]
VSS[143]
VSS[144]
VSS[145]
VSS[146]
VSS[147]
VSS[148]
VSS[149]
VSS[150]
VSS[151]
VSS[152]
VSS[153]
VSS[154]
VSS[155]
VSS[156]
VSS[157]
VSS[158]

AK38
AK4
AK42
AK46
AK8
AL16
AL17
AL19
AL2
AL21
AL23
AL26
AL27
AL31
AL33
AL34
AL48
AM11
AM14
AM36
AM39
AM43
AM45
AM46
AM7
AN2
AN29
AN3
AN31
AP12
AP19
AP28
AP30
AP32
AP38
AP4
AP42
AP46
AP8
AR2
AR48
AT11
AT13
AT18
AT22
AT26
AT28
AT30
AT32
AT34
AT39
AT42
AT46
AT7
AU24
AU30
AV16
AV20
AV24
AV30
AV38
AV4
AV43
AV8
AW14
AW18
AW2
AW22
AW26
AW28
AW32
AW34
AW36
AW40
AW48
AV11
AY12
AY22
AY28

2

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

PCH 6/6 (GND)

PCH 6/6 (GND)

NB5

NB5

NB5

PCH 6/6 (GND)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

11

11 29Monday, April 22, 2013

11 29Monday, April 22, 2013

11 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

M_A_A[15:0]3

D D

M_A_BS#03
M_A_BS#13
M_A_BS#23
M_A_CS#03
M_A_CS#13
M_A_CLKP03
M_A_CLKN03
M_A_CLKP13
M_A_CLKN13
M_A_CKE03
M_A_CKE13
M_A_CAS#3
M_A_RAS#3

R409 10K/F_2
R408 10K/F_2

C C

M_A_WE#3

SMB_RUN_CLK8,18
SMB_RUN_DAT8,18

M_A_ODT03
M_A_ODT13

M_A_DQSP[7:0]3

M_A_DQSN[7:0]3

CPU Bracket

B B

M_A_A0
M_A_A1
M_A_A2
M_A_A3
M_A_A4
M_A_A5
M_A_A6
M_A_A7
M_A_A8
M_A_A9
M_A_A10
M_A_A11
M_A_A12
M_A_A13
M_A_A14
M_A_A15

DIMM0_SA0
DIMM0_SA1
SMB_RUN_CLK
SMB_RUN_DAT

M_A_DQSP0
M_A_DQSP1
M_A_DQSP2
M_A_DQSP3
M_A_DQSP4
M_A_DQSP5
M_A_DQSP6
M_A_DQSP7
M_A_DQSN0
M_A_DQSN1
M_A_DQSN2
M_A_DQSN3
M_A_DQSN4
M_A_DQSN5
M_A_DQSN6
M_A_DQSN7

JDIM1A

98

A0

97

A1

96

A2

95

A3

92

A4

91

A5

90

A6

86

A7

89

A8

85

A9

107

A10/AP

84

A11

83

A12/BC#

119

A13

80

A14

78

A15

109

BA0

108

BA1

79

BA2

114

S0#

121

S1#

101

CK0

103

CK0#

102

CK1

104

CK1#

73

CKE0

74

CKE1

115

CAS#

110

RAS#

113

WE#

197

SA0

201

SA1

202

SCL

200

SDA

116

ODT0

120

ODT1

11

DM0

28

DM1

46

DM2

63

DM3

136

DM4

153

DM5

170

DM6

187

DM7

12

DQS0

29

DQS1

47

DQS2

64

DQS3

137

DQS4

154

DQS5

171

DQS6

188

DQS7

10

DQS#0

27

DQS#1

45

DQS#2

62

DQS#3

135

DQS#4

152

DQS#5

169

DQS#6

186

DQS#7

DDR3-DIMM0_H=4.0_STD

ddr-ddrsk-20401-tp4b-204p-ldv

DGMK4000324

IC SOCKET DDR3 SODIMM(204P,H4.0,STD)

DQ0
DQ1
DQ2
DQ3
DQ4
DQ5
DQ6
DQ7
DQ8

DQ9
DQ10
DQ11
DQ12
DQ13
DQ14
DQ15
DQ16
DQ17
DQ18
DQ19
DQ20
DQ21
DQ22
DQ23
DQ24
DQ25
DQ26
DQ27
DQ28
DQ29
DQ30
DQ31
DQ32
DQ33
DQ34
DQ35
DQ36
DQ37
DQ38
DQ39
DQ40
DQ41
DQ42
DQ43
DQ44
DQ45
DQ46

(204P)

PC2100 DDR3 SDRAM SO-DIMM

DQ47
DQ48
DQ49
DQ50
DQ51
DQ52
DQ53
DQ54
DQ55
DQ56
DQ57
DQ58
DQ59
DQ60
DQ61
DQ62
DQ63

EZIW

5

M_A_DQ0

7

M_A_DQ4

15

M_A_DQ7

17

M_A_DQ3

4

M_A_DQ1

6

M_A_DQ5

16

M_A_DQ2

18

M_A_DQ6

21

M_A_DQ13

23

M_A_DQ9

33

M_A_DQ14

35

M_A_DQ10

22

M_A_DQ12

24

M_A_DQ8

34

M_A_DQ11

36

M_A_DQ15

39

M_A_DQ21

41

M_A_DQ17

51

M_A_DQ19

53

M_A_DQ18

40

M_A_DQ20

42

M_A_DQ16

50

M_A_DQ23

52

M_A_DQ22

57

M_A_DQ25

59

M_A_DQ24

67

M_A_DQ30

69

M_A_DQ26

56

M_A_DQ28

58

M_A_DQ29

68

M_A_DQ31

70

M_A_DQ27

129

M_A_DQ36

131

M_A_DQ37

141

M_A_DQ34

143

M_A_DQ38

130

M_A_DQ32

132

M_A_DQ33

140

M_A_DQ35

142

M_A_DQ39

147

M_A_DQ41

149

M_A_DQ45

157

M_A_DQ47

159

M_A_DQ46

146

M_A_DQ40

148

M_A_DQ44

158

M_A_DQ42

160

M_A_DQ43

163

M_A_DQ49

165

M_A_DQ48

175

M_A_DQ54

177

M_A_DQ50

164

M_A_DQ53

166

M_A_DQ52

174

M_A_DQ55

176

M_A_DQ51

181

M_A_DQ61

183

M_A_DQ60

191

M_A_DQ59

193

M_A_DQ63

180

M_A_DQ56

182

M_A_DQ57

192

M_A_DQ62

194

M_A_DQ58

M_A_DQ[63:0] 3

+3V

DDR3_DRAMRST#2

SMDDR_VREF_DQ0_M34

SMDDR_VREF_DQ0_M3

R418 *0_6/S
R414 *0_6

+1.5VSUS

2.48A

+3V

R405 10K/F_2

PM_EXTTS#0

+SMDDR_VREF_DQ0SMDDR_VREF_DQ0_M1
+SMDDR_VREF_DIMM

JDIM1B

75

VDD1

76

VDD2

81

VDD3

82

VDD4

87

VDD5

88

VDD6

93

VDD7

94

VDD8

99

VDD9

100

VDD10

105

VDD11

106

VDD12

111

VDD13

112

VDD14

117

VDD15

118

VDD16

123

VDD17

124

VDD18

199

VDDSPD

77

NC1

122

NC2

125

NCTEST

198

EVENT#

30

RESET#

1

VREF_DQ

126

VREF_CA

2

VSS1

3

VSS2

8

VSS3

9

VSS4

13

VSS5

14

VSS6

19

VSS7

20

VSS8

25

VSS9

26

VSS10

31

VSS11

32

VSS12

37

VSS13

38

VSS14

43

VSS15

DDR3-DIMM0_H=4.0_STD

ddr-ddrsk-20401-tp4b-204p-ldv

DGMK4000326

IC SOCKET DDR3 SODIMM(204P,H4.0,STD)

VSS16
VSS17
VSS18
VSS19
VSS20
VSS21
VSS22
VSS23
VSS24
VSS25
VSS26
VSS27
VSS28
VSS29
VSS30
VSS31
VSS32
VSS33
VSS34
VSS35
VSS36
VSS37
VSS38
VSS39
VSS40
VSS41
VSS42
VSS43
VSS44
VSS45
VSS46
VSS47
VSS48
VSS49
VSS50
VSS51
VSS52

(204P)

PC2100 DDR3 SDRAM SO-DIMM

VTT1
VTT2

GND
GND

44
48
49
54
55
60
61
65
66
71
72
127
128
133
134
138
139
144
145
150
151
155
156
161
162
167
168
172
173
178
179
184
185
189
190
195
196

203
204

205
206

+0.75V_DDR_VTT

+1.5VSUS2,4,24

+0.75V_DDR_VTT24,29

+3V2,6,7,8,9,10,13,14,15,16,17,18,19,20,21,25,27,29

12

3

+1.5VSUS

R412
1K/F_2

SMDDR_VREF_DQ0_M1

R413
1K/F_2

DDR_VTTREF4,24

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

Local Thermal Sensor

U20

8

SCLK

7

SDA

6

ALERT#

4

OVERT#

*EMC1412-1-ACZL-TR

R406 *10K/F_2

+3V

MBCLK2
MBDATA2
PM_EXTTS#0

5

MBCLK22,8,15,21

MBDATA22,8,15,21

A A

VCC

DXP
DXN
GND

1
2
3
5

DDR_THERMDA

C358
*2200P/50V_4

DDR_THERMDC

Main:AL001412003 EMC1412-1-ACZL-TR(98h)

2nd:AL000431014 TMP431ADGKR(98h)

DDR3 Thermal Sensor

+3V

2

Q29
*METR3904-G

1 3

4

+1.5VSUS +0.75V_DDR_VTT

C347 1U/6.3V_2
C391 1U/6.3V_2
C388 1U/6.3V_2C359 *0.01U/16V_4
C389 1U/6.3V_2
C381 10U/6.3VS_6
C384 10U/6.3VS_6
C387 10U/6.3VS_6
C385 10U/6.3VS_6
C382 10U/6.3VS_6
C380 10U/6.3VS_6
C386 10U/6.3V_6
C346 10U/6.3V_6
C383 10U/6.3V_6
C506 10U/6.3V_6
C507 10U/6.3V_6

PV-1 4/17: add C506/507, C386

+SMDDR_VREF_DIMM

+SMDDR_VREF_DQ0



3

C366 1U/6.3V_2
C367 1U/6.3V_2
C362 1U/6.3V_2
C363 1U/6.3V_2
C379 10U/6.3VS_6
C390 *10U/6.3V_6

C369 0.1U/10V_2
C376 2.2U/6.3V_6

C368 0.1U/10V_2
C377 2.2U/6.3V_6

+3V

C364 0.1U/10V_2
C373 2.2U/6.3V_6

DDR_VTTREF

SMDDR_VREF_DQ0_M3

DRAMRST_CNTRL_DDR2

2

R417 *0_6

1

2

Q30
A03416

VREF DQ0 M1 SolutionPlace these Caps near So-Dimm0.

+1.5VSUS

R411
1K/F_2

1

+SMDDR_VREF_DIMM

R410

C372

1K/F_2

470P/50V_4

12 29Monday, April 22, 2013

12 29Monday, April 22, 2013

12 29Monday, April 22, 2013

R416 *0_6

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

DDR3 DIMM0-STD(4.0H)

DDR3 DIMM0-STD(4.0H)

DDR3 DIMM0-STD(4.0H)

1A

1A

1A

5

4

3

2

1

Camera \ ALS

USB-_CAMERA8

USB+_CAMERA8

D D

D_MIC

DIGITAL_D116

DIGITAL_CLK16

L6 FCM1608KF-301T02
L7 FCM1608KF-301T02

C32 *33P/50V_4
C49 *33P/50V_4
C38 100P/50V_4
C51 100P/50V_4

USB CAMERA

R70 0_4

2

R76 0_4

DIGITAL_D1
DIGITAL_CLK
DIGITAL_D1_R
DIGITAL_CLK_R

L8

1
43

*MCM2012B900GBE

DIGITAL_D1_R
DIGITAL_CLK_R

for SI 2/21: Change USB net name

USB-_CAMERA_C
USB+_CAMERA_C

+3V

CAMERA CONN.

USB+_CAMERA_C
USB-_CAMERA_C
DIGITAL_D1_R
DIGITAL_CLK_R

I2C1_SDA
I2C1_SCL

ALS_INT

C7 1000P/50V_4

CN2

10

10

9

9

8

8

7

7

6

6

5

5

4

4

3

3

2

2

1

1

Camera CONN

50208-01001-001-10p-l

G-sensor/E-compass

WR Address : 0x3C
RD Address : 0x3D

U1

C2

4.7U/25V_8

I2C1_SCL
I2C1_SDA

ACC_INT1
ACC_INT2
MAG_DRDY

C1

0.22U/10V_4

2

SCL

3

SDA

5

INT1

4

INT2

9

RSVD

6

C1

12

SETP

13

SETC

HP303DLHCTR

VDD_IO

RSVD
RSVD

RSVD

VDD

GND

13

+3V

1
14

8
10

11
7

C4

0.1U/10V_2

C5
10U/6.3V_6

C6

0.1U/10V_4

Sensor HUB

+3V

C C

R13 10K/F_2
R12 10K/F_2
R11 *10K/F_2
R10 10K/F_2
R8 10K/F_2
R9 *10K/F_2

SI 2/21: Change USB net name

Y1

USB+_SENSOR

41

(USBP1)

SI 2/26: Change Y1 footprint

PV-1 4/22: C10/C11 Change to 18P

B B

USB-_SENSOR8

USB+_SENSOR8

C10 18P/25V_2

12MHZ +20PPM

C11 18P/25V_2

+3V

R1 10K/F_2

C3 0.1U/10V_2

USB-_SENSOR

USB+_SENSOR

TP41
TP40

2 3

R55 20K_2

R7 *10K/F_2
R6 *10K/F_2
R5 10K/F_2
R4 *10K/F_2
R3 *10K/F_2
R2 10K/F_2

R105 1.3K/F_4

SWDIO
SWCLK

XTL_IN
XTL_OUT

+3V

C9

0.1U/10V_2

14

PA0-WKUP

15

PA1

16

PA2

17

PA3

20

PA4

21

PA5

22

PA6

23

PA7

41

PA8

42

PA9

43

PA10

44

PA11

45

PA12

46

PA13

49

PA14

50

PA15

29

PB10

30

PB11

33

PB12

5

PD0/OSC_IN

6

PD1/OSC_OUT

54

PD2

7

nRST

60

BOOT0

13

VDDA

12

VSSA

U5

PB0
PB1
PB2
PB3
PB4
PB5
PB6
PB7
PB8
PB9

PB13
PB14
PB15

I2C INTERFACE

PC0
PC1
PC2
PC3
PC4
PC5
PC6
PC7
PC8

PC9
PC10
PC11
PC12

PC13/TAMPER-RTC

PC14/OSC32_IN

PC15/OSC32_OUT

VBAT

VDD1
VDD2
VDD3
VDD4

VSS1
VSS2
VSS3
VSS4

26

ACC_INT1

27

ACC_INT2

28

GYRO_INT1

55

GYRO_INT2

56
57
58

I2C1_SCL

59
61
62

34
35
36

8
9
10
11
24
25
37
38
39
40
51
52
53
2
3
4

1
32

48
64
19

31
47
63
18

R57 2.2K_2

I2C1_SDA

R56 2.2K_2

MAG_DRDY
ALS_INT

R429 2.2K_2

SI 2/20: add R429 pull-up

C84

C69

0.1U/10V_2

0.1U/10V_2

+3V

C17

0.1U/10V_2

+3V

C45

0.1U/10V_2

Gyro

I2C1_SCL
I2C1_SDA

GYRO_INT1
GYRO_INT2

PV 3/26: change U2 footprint

Gyro (4x4)

U2

C42

0.01U/25V_4

2
3

7
6

14

SCL
SDA

INT
DRDY

RSVD

L3GD20TR

VDD_IO

VDD

SA0
RSVD
RSVD

RSVD
RSVD
RSVD
RSVD

GND

CS

+3V

1
16

4
5
15

8
9
10
11
12
13

C23

0.1U/10V_4

C8
10U/6.3V_6

C29

0.1U/10V_4

A A

5

STM32F103RBT6TR

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

Gyro/G-sensor/e-Compass

Gyro/G-sensor/e-Compass

NB5

NB5

4

3

2

NB5

Gyro/G-sensor/e-Compass

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

13 29Monday, April 22, 2013

13 29Monday, April 22, 2013

13 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

eDP Conn.

CN5

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

14

24

23

22

21

+3V

R78
100K/F_2

R395
100K/F_2

D4

U8

5

IN

4

IN

3

ON/OFF

IC(5P) G5243AT11U

C300
22P/50V_4

RB500V-40

R272 100K/F_2
C254 22P/25V_2

C82

D D

PCH_DISP_ON6

PCH_DPST_PWM6

Can't change to short

C C

EMU_LID21

PCH_LVDS_BLON6

1U/6.3V_2

R3961K/F_2

R124 0_4

R125 1K/F_2

R114
100K/F_2

OUT
GND

BLON_CON

+LCDVCC

1
2

L10

TI160808U600

+3VLCD_CON

C114 *10U/6.3V_6
C131 *0.01U/16V_4
C106 0.1U/10V_2

+3V

R1131K/F_2

PCH_DPST_PWMPCH_DPST_PWM_R

R3971K/F_2

eDP_AUXN_R
eDP_AUXP_R

For LVDS stuff
Ra=4.7k,Rb=4.7k,Rc un-stuff
For eDP reserve
Ra=100k,Rc=100k,Rb un-stuff

PCH_LVDS_BLON

R258 *100K/F_2
R232 *100K/F_2

INT_eDP_TXN12
INT_eDP_TXP12

INT_eDP_TXN02
INT_eDP_TXP02

INT_eDP_AUXP2

INT_eDP_AUXN2

+3VLCD_CON

PV 3/27: R394 Change to shortpad

+3V

+3V

DV1 eDP to LVDS for Control IC Power

EDP_HPD_L2

R398 *0_6

+VIN

C59

0.1U/50V_6

C203 0.1U/10V_2
C209 0.1U/10V_2

C222 0.1U/10V_2
C228 0.1U/10V_2

C233 0.1U/10V_2
C235 0.1U/10V_2

1 2

C115 *0.047U/10V_4

1 2

C130 *0.047U/10V_4

R394 *0_4/S

L9

*0_8/S

EDP_TXN1_R
EDP_TXP1_R

EDP_TXN0_R
EDP_TXP0_R

EDP_AUXP_R
EDP_AUXN_R

EDP_HPD_R

BLON_CON
PCH_DPST_PWM_R

+VIN_BLIGHT

50406-02071-001-20p-r

GS12401-1011-9H

+VIN_BLIGHT

+VIN_BLIGHT

C91 *4.7U/25V_8
C113 0.1U/50V_6
C128 0.01U/25V_4

Mini PCI-E Card 2- Full size
mSATA

B B

for SI 2/20: change pin/net from "44" to "51"

H=4.0

CN12

51

Presence Detection

49

DA/DSS

47

Vendor Specific

45

Vendor Specific

43

Reserved

41

+3.3 V

39

+3.3 V

37

GND

35

GND

33

SATA TX+

31

SATA TX-

29

GND

27

GND

25

SATA RX-

23

SATA RX+

21

GND

19

Reserved

17

Reserved

15

GND

13

Reserved

11

Reserved

9

GND

7

Reserved

5

Reserved

3

Reserved

1

Reserved

MINI SATA H=4.0

DFHS52FR133

minipci-mpcet-ssc10-ts10-52p

5

R420 *0_4

SATA_TXP1_C
SATA_TXN1_C

SATA_RXN1_C
SATA_RXP1_C

SATA0GP7

Place Cap close to
conn within 100mils

SATA_TXP17
SATA_TXN17

SATA_RXN17
SATA_RXP17

A A

C395 0.01U/16V_4
C394 0.01U/16V_4

C393 0.01U/16V_4
C392 0.01U/16V_4

+3.3V

GND

+1.5V
Reserved
Reserved
Reserved

GND
Reserved
Reserved

GND

SMB_DATA

SMB_CLK

+1.5V

GND

+3.3 V
Reserved
Reserved

GND

Reserved
Reserved
Reserved
Reserved
Reserved

+1.5V

GND

+3.3V

52
50
48
46
44
42
40
38
36
34
32
30
28
26
24
22
20
18

16
14
12
10
8
6
4
2

4

+1.5V_CPU

+3V

+3V

C398 4.7U/6.3V_6
C403 0.1U/10V_2
C401 0.1U/10V_2
C402 0.1U/10V_2
C396 *4.7U/6.3V_6
C400 4.7U/6.3V_6

R428 *0_8
R419 *0_8

DV1 msata to HDD Power

+5V

for SI 2/20: reserve R428

3

C399

0.01U/16V_4

C404
*0.1U/10V_2

+1.5V_CPU

C397
*4.7U/6.3V_6

+3V2,6,7,8,9,10,12,13,15,16,17,18,19,20,21,25,27,29

+3VPCU4,7,15,17,18,19,21,22,23

+5V7,10,15,16,17,18,29

+VIN

+VIN20,22,23,24,25,27,28,29

+5VS56,23,24,25,26,27,29

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

eDP / mSATA

eDP / mSATA

NB5

NB5

2

NB5

eDP / mSATA

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

14 29Monday, April 22, 2013

14 29Monday, April 22, 2013

14 29Monday, April 22, 2013

1A

1A

1A

A

Control Buttons

Power button

C56 *220P/50V_4

NBSWON1#21

50505-00441-001-4p-l

DFFC04FR070

POWER BTN CONN

4
3

2
1

CN8

B

VOL BTN CONN

Vibrator _Out#9,21

VOL_Down#21

VOL_UP#21

Vibrator _Out#
VOL_Down#

VOL_UP#

*220P/50V_4

+3V

C354

C356

*220P/50V_4

C

Touch screen

PV 3/26: change form "+3V" to "+3VPCU"

+5V

C348 0.1U/10V_2

CN10

1
2
3
4
5
6

C355

VOL BTN CONN

*220P/50V_4 CN9

C252
1U/10V_4

TS_ON21

TS_ON

+3V

R208 0_6

1

Vout

Vin

NC

3

R282
*100K/F_2

R280*0_2

R281*0_2

GND

EN

*G9191-330T1U

U13

SI 2/20: reserve R427 pull-up

+VCC_TS

5
4
2

D

+3V

R245 *0_6
R479 0_6

HOME_BUTTON_INT#21

Home_Button_LED17

USB+_TS8

USB-_TS8

MBDATA22,8,12,21
MBCLK22,8,12,21

+VCC_TS

+3VPCU

C224

1U/10V_4

for SI 2/21: Change USB net name

USB+_TS
USB-_TS

+3V

R283 0_4
R263 0_4

R427 *4.7K/F_2

USB+_TS_C
USB-_TS_C

Home_Button_LED

Home_Buttone Power

C263 *220P/50V_2
C234 0.1U/10V_2
C225 0.1U/10V_2

TS_ON
Home_Buttone Power

2

L15 *MCM2012B900GBE

E

+5V7,10,14,16,17,18,29
+3V2,6,7,8,9,10,12,13,14,16,17,18,19,20,21,25,27,29

1

USB+_TS_C

43

USB-_TS_C

15

1
2
3
4
5
6
7
8
9
10

TOUCH Screen

SATA_TXP0_C
SATA_TXN0_C

SATA_RXN0_C
SATA_RXP0_C

+3V

R374 *10K/F_2
R381 *0_4
R380 *0_4

+3V

R276 *0_4
R255 *0_4
R256 *0_4

U17

1

A+

2

A-

3

TDETB#

4

BO-

5

BO+

FAN

+5V

C365 10U/6.3VS_6
C378 0.1U/10V_4

FAN1

FAN1_PWM21

FAN1SIG21

R407 4.7K/F_2

+3V

1 1

FAN1_PWM

C360 *220P/50V_4

FAN1SIG

C361 *220P/50V_4

1
2
3
4

FAN1

DFFC04FR070

50505-00441-001-4p-l

SATA Re-driver

C274 1U/6.3V_2

+3V

SATA_TXP07,17
SATA_TXN07,17

SATA_RXN07,17

SATA_RXP07,17

C319 0.1U/10V_2
C261 0.1U/10V_4

HOST

C302 *0.01U/10V_4
C290 *0.01U/10V_4

C284 *0.01U/10V_4
C280 *0.01U/10V_4

2/22: change C280/284/290/302 footprint to 0402

Unstuff R230,R242 for support PI3EQX6741ST

R383 *0_4
R382 *0_4

R379 *6.2K/F_4

21

20

19

18

17NC16

VDD

B_EQ

A_EQ

AO+

T_DET_EN

HEAT_GND

VDD6EN7B_EM8A_EM9VDD

AO-

TDETA#

BI­BI+

*PI3EQX6741STZDE

10

R277 *0_4
R278 *0_4
R279 *0_4

15

SATA_TXP0_DC_L

14

SATA_TXN0_DC_L

13
12

SATA_RXN0_DC_L

11

SATA_RXP0_DC_L

2/22: R383/382 unstuff

DEVICE

SATA_TXP0_DC_L 17
SATA_TXN0_DC_L 17

SATA_RXN0_DC_L 17

SATA_RXP0_DC_L 17

2/22: R277 unstuff

stuff R263 for support PI3EQX6741ST

Change R255 from 6.2K to 0R for support PI3EQX6741ST

PV 3/27: R278/279 unstuff

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

Button/FAN/TS/SATA-driver

Button/FAN/TS/SATA-driver

NB5

NB5

A

B

C

D

NB5

Button/FAN/TS/SATA-driver

Date: Sheet of

Date: Sheet of

Date: Sheet of

E

15 29Monday, April 22, 2013

15 29Monday, April 22, 2013

15 29Monday, April 22, 2013

1A

1A

1A

A

for intel HSW ULT

L14

+3V

HCB1608KF-181T15_6

>20mils trace

+3V_DVDD-IO

C282

0.1U/10V_4

B

Close to Pin 7

C

>20mils trace

Place near Pin22 Place near Pin30

+3V_AVDD_2 +3V_AVDD

C262
1U/6.3V_2

Close to PIN22

CPVSS

C266

0.1U/10V_2

L120_6

D

C317
1U/6.3V_2

Close to PIN30

SI 2/25: no stuff for IDT recommend

AGND

C316

0.1U/10V_2

L13*0_6

+3V+3V

E

16

+3V2,6,7,8,9,10,12,13,14,15,17,18,19,20,21,25,27,29
+5V7,10,14,15,17,18,29

C288

>40mils trace

AnalogDigital

FCap1

CPVreg

28

29

CAP+

C276

CPVSS

C

PVDD1
PVDD2

PVSS1
PVSS2

PORTD_+L

PORTD_-L
PORTD_+R
PORTD_-R

PCBEEP
SENSE_A
PORTC_L
PORTC_R

VREFOUT_C

PORTB_L
PORTB_R

VREFOUT_B

CAP2

VREFFILT

AVDD1

ClassG Area

AVDD2

PORTA_L

PORTA_R

92HD95 40_QFN

4.7U/25V_8

>40mils trace

+5V_PVDD

C249

+3V_AVDD

C504

1000P/50V_4

C331
1U/6.3V_2

HPOUT_L 18

HPOUT_R 18

1U/6.3V_2

AGND

C327

1U/6.3V_2

31
38

34
35

32

L_SPK+

33

L_SPK-

37

R_SPK+

36

R_SPK-

12

AMP_BEEP

13

SENSE_A_1 SENSE_A

14

Close to codec

15
16

Close to codec

17

EXT_MIC_L1

18

EXT_MIC_R1

19

VREFOUT_C

21
20
22

+3V_AVDD

30

+3V_AVDD_2

23

HPOUT_L

24

HPOUT_R

Close to PIN31 Close to PIN38

R373 2.2K_2

AGND

AMP_BEEP AMP_BEEP_R2AMP_BEEP_L

Check layout
mount location

C257

0.1U/10V_2

R426

SI 2/20: add R426 pull-up

2.49K/F_4

R378 39.2K/F_4

PV-1 4/15: add C504 for IDT recommend

R388 0_4C325 2.2U/6.3V_8/S

C326
1U/6.3V_2

AGND AGND

trace >15mils trace
Space >35mils trace

C322

0.1U/10V_2

0.01U/16V_2

+3V_AVDD

C267

2.2U/6.3V_6

AGND

D

C330

AGND

C265

0.1U/10V_2

SI 2/25: add R465 for IDT recommend

R465 0_8/FM

C251
1U/6.3V_2

EXT_MIC_L

C250

0.1U/10V_2

SENSE_A 17

EXT_MIC_L 17

COMPONENT CHOICES ON FERRITES:

Ferrites are only necessary when required by EMI.
The selection of ferrite beads can have a large effect on

THD+N, causing failures versus the WLP requirements.
At this time, IDT has verified three ferrite beads that will
meet the WLP performance requirements:

Murata: BLM18BD601SN1
TDK: MMZ1608Y601BTA
Taiyo Yuden: LF BK 1608HM601-T

+3V_AVDD

R386
10K/F_2

3

Q27

1

AGND

C230

0.047U/10V_4

E

check value

R370 100K/F_2

R385
10K/F_2

U14

5
4

C241
1U/6.3V_2

TLV70233DBVR

HPA01198DBVR

NB5

NB5

NB5

C323

0.1U/10V_2

2N7002

PV 3/28: U14 pin1 change to +5V

1

Vout

Vin
BYP
GND2EN

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev

Custom

Custom

Custom

Date: Sheet of

Date: Sheet of

Date: Sheet of

C227

3

0.1U/10V_2

R242 10K/F_2

Vset=1.242V

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Azalia 92HD95 40_QFN

Azalia 92HD95 40_QFN

Azalia 92HD95 40_QFN

+5V

2

ACZ_SPKR 7

+5V

C231
1U/6.3V_2

+5V

1A

1A

16 29Monday, April 22, 2013

16 29Monday, April 22, 2013

16 29Monday, April 22, 2013

1A

>20mils trace

BIT_CLK_AUDIO7

ACZ_SDIN07

ACZ_SYNC_AUDIO7

ACZ_RST#_AUDIO7

DIGITAL_CLK13
DIGITAL_D113

+1.5V_CPU

2

1 3

TO Digital MIC

R222
*2.2K_2

Q14

*MMBT3904-7-F

21

Close to PIN9

C299

C298

0.1U/10V_2

1U/6.3V_2 C2534.7U/6.3V_6

Place near Pin6

R294 0_4

Place near Pin8

C264 10P/25V_2
R284 100/F_2
R290 0_4

C269 10P/25V_2

MUTE_LED_CNTL21

C320

2.2U/6.3V_6

CPVSS

+3V_DVDD

R224

SI 2/25:R224 change to 10K ohm,R223 no stuff IDT recommend

10K/F_2

PD#

R223
*10K/F_2

HD_BCLK

ACZ_SDOUT_AUDIO
HD_SDIN0

R31133_2

ACZ_SYNC_AUDIO

DMIC_CLK_R
DMIC0

PD#

C314

2.2U/6.3V_6

CPVSS

Speaker 4 ohm: 40mils

L_SPK+
L_SPK­R_SPK­R_SPK+

C243

C242

2200P/50V_4

2200P/50V_4

B

+3V_DVDD-IO
+3V_DVDD

C245

C244

2200P/50V_4

2200P/50V_4

U16

1

DVDD_LV

7

DVDD_IO

9

DVDD

6

HDA_BCLK

5

HDA_DOUT

8

HDA_DIN

10

HDA_SYNC

11

HDA_RST#

2

DMIC_CLK/GPIO1

3

DMIC0/GPIO2

4

DMIC1/GPIO0

39

EAPD

40

SPDIF/GPIO3

41

DAP

25

VPos

26

VNeg

R241

R234

3.3/F_4
R233

3.3/F_4

Close to Codec

R240

3.3/F_4

3.3/F_4

FCap2

27

CAP-

2.2U/6.3V_6

L_SPK+ 17
L_SPK- 17
R_SPK- 17
R_SPK+ 17

+3V_DVDD

+3V

L17

HCB1608KF-181T15_6

ACZ_SDOUT_AUDIO7

SI 2/25:C324/256/255 no stuff IDT recommend

C324 *1000P/50V_4

C256 *1000P/50V_4

C255 *1000P/50V_4

1 1

AGND

Close to CODEC

R15 *0_8/S

AGND

R14 *0_8/S

CPVSS

for intel HSW ULT

Q7
BA039040000
BA039040020

ACZ_RST#_AUDIO

VOLMUTE#21

ACZ_SDIN0

ACZ_SDOUT_AUDIO

ACZ_SYNC_AUDIO

BIT_CLK_AUDIO

FOR EMI

C287 *33P/25V_2

C273 *10P/25V_2

C304 *10P/25V_2

C275 *33P/25V_2

D6 MEK500V-40

A

5

FFC Conn

SENSE_A16
EXT_MIC_L16

Home_Button_LED#

LINEOUT_L_C18
LINEOUT_R_C18

UNDOCK_INT#_R

HDMI_SDATA6
HDMI_SCLK6

USB-_TP8
USB+_TP8

USB-_COMBO8
USB+_COMBO8

USB-_LEFT8
USB+_LEFT8

USB-_CR8
USB+_CR8

SI 2/25: add R463/Q31 for leakage

ECBASE_DATA21

ECBASE_CLK21

SI 2/25: C318 change 0.01u

C318 0.01U/10V_2

UNDOCK_INT#21

D D

PIRQH#8,21

PIRQH#

Touch PAD

USB2.0/USB3.0 COMBO 1st

USB2.0(M/B-1)

USB2.0(M/B-2)

USB2.0 Cardreader for Base

R359 0_2

(USBP8)

(USBP0)

(USBP9)

(USBP3)

for SI 2/21: Change USB net name

I2C for EC Base

PV 3/26: add Q32 for Home_LED

34

Home_Button_EC21

C C

Home_Button_LED15

5

2

Q32A
PJ4N3KDW

Home_Button_LED#

61

Q32B
PJ4N3KDW

4

SENSE_A
EXT_MIC_L
LINEOUT_L_C
LINEOUT_R_C
DOCK_IN_DET
HDMI_SDATA

HDMI_SCLK
USB-_TP

USB+_TP
USB-_COMBO

USB+_COMBO
USB-_LEFT

USB+_LEFT
USB-_CR

USB+_CR
HDMI_HPD_CON_R

ECBASE_DATA_R
ECBASE_CLK_R
BASE_EC_RESET
Dock_ECBASE_INT#
Home_Button_LED#

EC_BASE_EN

ECBASE_DATA

ECBASE_CLK

AGND
AGND
AGND
AGND

R463 0_2

Q31

4 3

1

2N7002DW

DFFC31FR007

FH35C-31S-0.3SHW(50)

1
31
2
30
3
29
4
28
5
27
6
26
7
25
8
24
9
23
10
22
11
21
12
20
13
19
14
18
15
17
16

CN6

fh35c-31s-0_3shw-31p-ldh

PV-1 4/15: change R463 2.2K to 0 ohm

5

2
6

3

+VAD

+5V

SATA_TXP07,15
SATA_TXN07,15

SATA_RXN07,15
SATA_RXP07,15

SI 2/27: add R466~R469 test PASS

PV 3/27: change Q31 pin

ECBASE_DATA_R

ECBASE_CLK_R

SATA_TXP0
SATA_TXN0
SATA_RXN0
SATA_RXP0

C193 *4.7U/25V_8
C172 0.1U/50V_6
C155 0.01U/25V_4

C126 *4.7U/25V_8R366 *0_2
C146 0.1U/50V_6
C177 0.01U/25V_4

R466 *0_4/S
R467 *0_4/S
R468 *0_4/S
R469 *0_4/S

+3VPCU

SATA_TXP0_DC
SATA_TXN0_DC
SATA_RXN0_DC
SATA_RXP0_DC

AD_ID21

AC_LED_ON21

MBATLED021

SATA_TXP0_DC_L15

SATA_TXN0_DC_L15
SATA_RXN0_DC_L15
SATA_RXP0_DC_L15

IN_CLK6

IN_CLK#6

IN_D0#6

IN_D1#6

IN_D2#6

USB30_TX1+_DC19

USB30_TX1-_DC19

USB30_RX1+_DC19

USB30_RX1-_DC19

L_SPK+16
L_SPK-16
R_SPK-16
R_SPK+16

C182 0.1U/10V_2
C181 1U/6.3V_2

2

+VAD

+VA
+5V

IN_D06

IN_D16

IN_D26

+3VPCU

IN_CLK#
IN_D0

IN_D0#
IN_D1

IN_D1#

IN_D2#

Wire Conn

C301 *0.01U/10V_2
C289 *0.01U/10V_2
C285 *0.01U/10V_2
C281 *0.01U/10V_2

C79 0.1U/10V_2
C73 0.1U/10V_2

C107 0.1U/10V_2
C94 0.1U/10V_2

C127 0.1U/10V_2
C123 0.1U/10V_2

C160 0.1U/10V_2
C154 0.1U/10V_2

USB30_TX1+_DC
USB30_TX1-_DC
USB30_RX1+_DC
USB30_RX1-_DC

L_SPK+
L_SPK­R_SPK­R_SPK+

SATA_TXP0_DCSATA_TXP0_DC_L
SATA_TXN0_DCSATA_TXN0_DC_L
SATA_RXN0_DCSATA_RXN0_DC_L
SATA_RXP0_DCSATA_RXP0_DC_L

C_TXC_HDMI+IN_CLK
C_TXC_HDMI-

C_TX0_HDMI+
C_TX0_HDMI-

C_TX1_HDMI+
C_TX1_HDMI-

C_TX2_HDMI+IN_D2
C_TX2_HDMI-

1

CN4

G_0

1
2
3
4
5
6
7
8
9
10

G_1
11
12
13
14
15
16
17
18

G_2
19
20
21
22
23
24
25
26
27
28
29
30

G_4

31
32
33
34
35
36
37
38
39
40

G_5

GS12407-11141-9F

17

Normal:High

Base Dock_Plug:Low

Base Dock_Plug Detect Schematic

B B

+3VPCU

R318
100K/F_2

DOCK_IN_DET

A A

3920_RST#21

2

3920_RST#

+3VPCU

61

5

R319
100K/F_2

Q21B
PJ4N3KDW

+3VPCU

2

R204
100K/F_2

61

Q18B
PJ4N3KDW

CHIP_DOCK_DET#

34

5

Q21A
PJ4N3KDW

To PCH

DOCK_DET_R 21

To EC

PV 3/26: add R477/R478
PV-1 4/15: R478/R477

R477 *0_2
R478 0_2

34

5

Q18A
PJ4N3KDW

C503

PV-1 4/15: add C503

*1U/6.3V_2

CHIP_DOCK_DET# 9

D9

21

*CH501H-40PT

BASE_EC_RESET
ECBASE_DATA

EC_BASE_ENDOCK_DET_R

EC_BASE_EN21

From EC

Normal:Low
Base Dock_Plug: High

4

EC Reset

From EC

Normal:Low
Base Dock_Plug: High

EC_BASE_EN BASE_EC_RESET_R

R237 10K/F_2

R231 10K/F_2

BASE_EC_KEY_R

From BASE EC IRQ

Slate_EC_Reset21

From Slate EC Reset

Dock_ECBASE_INT#

R291 0_2

2

Q16

MMBT3904T-7-F/SOT523

1 3

+3VPCU

R214
10K/F_2

2

Q17
MMBT3904T-7-F/SOT523

1 3

EC KEY Level Shift

3

To Slate EC

ECBASE_INT# 21

To Base EC Reset

BASE_EC_RESET

HDMI

HDMI_SCLK

HDMI_HPD6

HDMI_SDATA

+5VS56,23,24,25,26,27,29
+3VPCU4,7,15,18,19,21,22,23

2

Shark Chief river Platform Stuff

+3V+3V

R205
1M_2

Q11
MMBT3904-7-F

2

HDMI_HPD

+3V

R218 2.2K_2
R219 2.2K_2

1 3

R206
10K/F_2

EMI Solution

C_TX2_HDMI+
C_TX1_HDMI+
C_TX0_HDMI+
C_TXC_HDMI+

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

R155 *121/F_4
R135 *121/F_4
R116 *121/F_4
R94 *121/F_4

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

DOCKINGCON

DOCKINGCON

DOCKINGCON

12

R203 150K/F_4

1

HDMI_HPD_CON_RHDMI_HPD_CON_R_P

C_TX2_HDMI­C_TX1_HDMI­C_TX0_HDMI­C_TXC_HDMI-

17 29Monday, April 22, 2013

17 29Monday, April 22, 2013

17 29Monday, April 22, 2013

1A

1A

1A

A

+3V_WLAN_P

BT_OFF9

R103 *0_6

4 4

3 3

+5V

SI change for DS3 leakage issue!

EC_DEBUG21

CLK_33M_DEBUG8

PCIE_TXP3_WLAN8
PCIE_TXN3_WLAN8
PCIE_RXP3_WLAN8

PCIE_RXN3_WLAN8
CLK_PCIE_WLANP8
CLK_PCIE_WLANN8

PCIE_CLKREQ_WLAN#8

BT_COMBO_EN#8

1

Q6

2N7002E

INT_BT_OFF#

R104
10K/F_2

2

3

R108 *0_4

R156 *0_4/S
R168 *0_4

MINICAR_PME# LFRAME#

PLTRST#

REQ_WLAN#

28
48
51
49
47
45
19
17
33
31
25
23
13
11

43
37
35
29
27
21
15

minipci-mpcet-ssc10-ts10-52p

CN3

6

+1.5V
+1.5V
+1.5V
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
PETp0
PETn0
PERp0
PERn0
REFCLK+
REFCLK-

7

CLKREQ#

5

BT_CHCLK

3

BT_DATA

1

WAKE#
Reserved
Reserved
GND
GND
GND
GND
GND

MINI PCIE H=4.0

DFHS52FR133

H=4.0

+3.3V

+3.3V
+3.3Vaux
Reserved
Reserved

LED_WLAN#
LED_WPAN#

LED_WW AN#

USB_D+

USB_D-

SMB_DATA

SMB_CLK

PERST#

W_DISABLE#

Reserved
Reserved
Reserved
Reserved
Reserved

GND
GND
GND
GND
GND
GND
GND

PAD54PAD53HOLE55HOLE

56

ph

52
2
24
41
39
44
46
42
38
36
32
30
22
20
16
14
12
10
8
50
40
34
26
18
4
9

+3V_WLAN_P+1.5V_CPU

WLAN_LED#

B

PLTRST#
INT_RF_OFF#
LAD0
LAD1
LAD2
LAD3

C21

0.01U/16V_4

R174 4.7K/F_2
R173 *0_4/S

USB+_WLAN 8
USB-_WLAN 8
PLTRST# 2,8,19,20,21

LAD0 7,20,21
LAD1 7,20,21
LAD2 7,20,21
LAD3 7,20,21
LFRAME# 7,20,21

+1.5V_CPU +3V_WLAN_P

C80

0.1U/10V_2

+3V_WLAN_P

C161
10U/6.3VS_6

PV 3/27: R156/173 Change to shortpad

RF_LINK# 21

C

C89

0.1U/10V_2

C140

0.1U/10V_2

Mini Card
WLAN/BT(Option)

for SI 2/21: Change USB net name

R107 10K/F_2

Q5
2N7002E

3

2

SI change for DS3 leakage issue!

+3V_WLAN_P

1

RF_OFF 9

C28

C111

0.1U/10V_2

10U/6.3VS_6

For EMI Suggestion

CLK_33M_DEBUG

R89 *0_4

EC_AOCS#21

D

Q7

2

C68 *33P/25V_2

R152
10K/F_2

R151 200K_4

3

2N7002E

1

C148

0.1U/10V_2

Support Wake Function(Reserve)

PCIE_WAKE#6,19,21

E

+3VS5+3VPCU

1

2

3

Q12
ME2303T1

24mil

+3V_AOCS

+3V_WLAN_P

R196 *0_8

C216
*0.1U/10V_2

+3V_WLAN_P

2

13

Q15 *DDTC144EUA-7-F

MINICAR_PME#

+3V_WLAN_P

R221 10K/F_2

2

18

+3V

+5V_AMP

C258 1U/10V_6

Add 1uF caps for the
AC coupling. (IDT
recommend)

HPOUT_L

HPOUT_R

C259 1U/6.3V_8S

AGND

C279 1U/6.3V_8S

HPOUT_L16

2 2

HPOUT_R16

HPOUT_L_1

C260 1U/10V_8S

C268 1U/10V_8S

HPOUT_R_1

+5V_AMP

R431 4.7K_4

U18

1
2
3
4
5

LEFTINML­LEFTINP+
GND
RIGHTINP+
RIGHTINM-

SDA7SCL8GND9GND

SD#

6

20

VDD

TPA6130A2

10

SI 2/22: add R431 pull-up

TPA6130A2

HPA00836PWPR

AMP_CLK

1 1

A

AMP_DAT

C315 1U/10V_6

18

19

CPP

GND

AGND21AGND22AGND23AGND24AGND

17

CPM

AGND

16

CPVSS

HPLEFT

CPVSS

HPRIGHT

25

AGNDAGND

GND
VDD

AGND
AGND
AGND
AGND
AGND

HPA00929RTJR

B

15
14
13
12
11
30

29
28
27
26

C329 1U/10V_8

LINEOUT_L

LINEOUT_R

+5V_AMP

+3V

R252

*0_2

R364

*2K/F_4

R369
*0_2

R321

*2K/F_4

AGND

+5V_AMP

R368 0_2
R308 0_2

+5V_AMP

L16

BLM18PG181SN1D(180,1.5A)_6

R387 30.1/F_4

LINEOUT_L LINEOUT_L_C

C277
1U/10V_6

AGND

HPOUT_L LINEOUT_L_C

HPOUT_R LINEOUT_R_C

R384 30.1/F_4

R377 *0_2

R376 *0_2

+5V

C334
*1000P/50V_4

Stuff Res once No support AMP.

SMB_RUN_CLK 8,12
SMB_RUN_DAT 8,12

C

LINEOUT_R_CLINEOUT_R

C333
*1000P/50V_4

LINEOUT_R_C 17

LINEOUT_L_C 17

AGND

EC_PCIE_WAKE#21

+3V2,6,7,8,9,10,12,13,14,15,16,17,19,20,21,25,27,29

+3VPCU4,7,15,17,19,21,22,23

D

NB5

NB5

NB5

13

Q10 DDTC144EUA-7-F

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

MINICAR_PME#

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

WLAN

WLAN

WLAN

E

18 29Monday, April 22, 2013

18 29Monday, April 22, 2013

18 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

USB 3.0 Re-driver

OSx Transition Bit Amplitude

NC(default)

D D

0

1
EQx
NC(default)

0

1

DEx

OSx=NC

-3.5dB

NC

-6.0dB

0

-8.5dB

1

EN_RXD

1(default) Normal operating mode

0

CM

0(default)

C C

1

1000
870
1085

Equalization dB

0
7
15

OSx=0

-2.2dB

-5.2dB

-8.9dB

OSx=1

-4.4dB

-6.0dB

-7.6dB

DEVICE FUNCTION

Sleep mode

DEVICE FUNCTION
Normal operating mode
Compliance mode

*4.99K/F_2

R288

*4.99K/F_2

R269

*4.99K/F_2

R292

*4.99K/F_2

+3VS5

R317

*4.99K/F_2

R300

*4.99K/F_2

R314

*4.99K/F_2

R301

*4.99K/F_2

R316

*4.99K/F_2

R299

Ra Rb

*0_2

R315

*4.99K/F_2

R302

*4.99K/F_2

EQ1_1
EQ2_1
DE1_1
DE2_1
OS1_1
OS2_1

HOST DEVICE

USB30_TX1-8
USB30_TX1+8

USB30_RX1-8
USB30_RX1+8

+3VS5

C237 *0.1U/10V_2R266
C238 *0.1U/10V_2

C239 *0.1U/10V_2
C240 *0.1U/10V_2

C236 0.1U/10V_2
C307 0.1U/10V_2

USB30_RX1-_C
USB30_RX1+_C

USB3.0 re-driver IC

U15

8

RX1-

9

RX1+

11

TX2-

12

TX2+

1

VCC

13

VCC

2

EQ1_1

EQ1

17

EQ2_1

EQ2

3

DE1_1

DE1

16

DE2_1

DE2

4

OS1_1

OS1

15

OS2_1

OS2

*SN65LVPE502A

USB30_TX1­USB30_TX1+
USB30_RX1­USB30_RX1+

R470 *0_4/S
R471 *0_4/S
R472 *0_4/S
R473 *0_4/S

TX1-

TX1+
RX2-

RX2+

EN_RXD

GND
GND
GND
GND

NC1
NC2

CM

23

USB30_TX1-_DC_CUSB30_TX1-_C

22

USB30_TX1+_DC_CUSB30_TX1+_C

20

USB30_RX1-_DC_C

19

USB30_RX1+_DC_C

5
14
7

24
6

10
18
21

USB30_TX1-_DC
USB30_TX1+_DC
USB30_RX1-_DC
USB30_RX1+_DC

C308 *0.1U/10V_4
C309 *0.1U/10V_4

R474 *0_4
R475 *0_4

R289 *4.99K/F_2
R270 *0_2

R265 *4.99K/F_2
R287 *0_2
R260 *4.99K/F_2
R261 *4.99K/F_2

USB30_TX1-_DC
USB30_TX1+_DC

USB30_RX1-_DC
USB30_RX1+_DC

SI 3/2: add R474~R475

+3VS5

+3VS5

19

USB30_TX1-_DC 17
USB30_TX1+_DC 17

USB30_RX1-_DC 17
USB30_RX1+_DC 17

SI 3/1: add R470~R473 test PASS

CardReader

B B

PCIE Cardreader for Slate

C370 *10U/6.3V_6
C371 0.1U/10V_4

A A

5

PCIE_RXP2_CARD8
PCIE_RXN2_CARD8

PCIE_TXP2_CARD8
PCIE_TXN2_CARD8

CLK_PCIE_CRP8
CLK_PCIE_CRN8

PCIE_CLKREQ_CR#8

PLTRST#2,8,18,20,21

PCIE_WAKE#6,18,21

+3VPCU

LID_EC#21

+3V+3V

C375

0.1U/10V_2

4

PCIE_RXP2_CARD
PCIE_RXN2_CARD

PCIE_TXP2_CARD
PCIE_TXN2_CARD

CLK_PCIE_CRP
CLK_PCIE_CRN

PCIE_CLKREQ_CR#
PLTRST#
PCIE_WAKE#

C374
*220P/50V_2

USB FFC CONN

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

CN11

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

+3VS56,9,10,18,20,23,25,29

NB5

NB5

3

2

NB5

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

USB3.0 re-driver

USB3.0 re-driver

USB3.0 re-driver

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

19 29Monday, April 22, 2013

19 29Monday, April 22, 2013

19 29Monday, April 22, 2013

1A

1A

1A

5

EMI / Hole

+VA +PRWSRC +VIN +VAD +1.05V

D D

EC1
*0.1U/25V_4

EC6
*0.1U/25V_4

EC4
*0.1U/25V_4

EC7
*0.1U/25V_4

EC3
*0.1U/25V_4

EC5
*0.1U/25V_4

4

H1

o-jw7c-3

H4
o-jw7c-1

H8
o-jw7c-4

H11

o-jw7c-7

3

2

1

20

1

H5

h-tc236bc142d142pt

1

H9

h-tc236bc142d142pt

1

1

1

H6

h-tc236bc142d142pt

1

1

H7

h-tc236bc142d142pt

1

H10

H-TE413X295BC142D142P2

1

H3

*o-jw7c-5

H2

*o-jw7c-6

H14

*H-C91D91N

PV 3/27: add H14 for ICT

1

C C

1

1

TPM

+3V rail for SLB9656 +3VS5 rail for SLB9635

SI 2/25: add TPM function

+3V_TPM_PWR

B B

CLK_PCI_TPM

R459
*33_4

C500
*10P/50V_4

FOR EMI

CLKRUN#6,21

LAD07,18,21
LAD17,18,21
LAD27,18,21
LAD37,18,21

CLK_PCI_TPM8

LFRAME#7,18,21

PLTRST#2,8,18,19,21

SERIRQ7,21

install for SLB9635
No install for SLB9656

LAD0
LAD1
LAD2
LAD3
CLK_PCI_TPM

LFRAME#
PLTRST#
LPCPD#_TPM
SERIRQ

TPM_TESTB1

R460*0_4

TPM (1.2)

U22

26

LAD0

23

LAD1

20

LAD2

17

LAD3

21

LCLK

22

LFRAME#

16

LRESET#

28

LPCPD#

27

SERIRQ

9

TEST/BADD

15

CLKRUN#

1

NC

3

NC

12

NC

*SLB9656TT1.2

SLB9635 SLB9656

R458 Install No install

A A

R453
R454
R455 Install No install

Y6,R413

C501,C502

R412
R409
R457 No install Install

No install

Install

Install

No install

Install No install
Install
Install

5

No install
No install

Address

BADD
4EH/4F

HIGH

4

3

R453

*0_4

VDD
VDD
VDD

GND
GND
GND
GND

GPIO

GPIO2

TESTI

XTALI/32K IN

XTALO

VSB

PP

(default)

+3V

+3VS5

R454
*0_4

install for SLB9635
No install for SLB9656

R432*4.7K/F_4
R433*4.7K/F_4

+3V

R456*4.7K/F_4

+3V

R458*0_4

R461*0_4

No install for SLB9635
install for SLB9656

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

EMI/Hole/TPM

EMI/Hole/TPM

EMI/Hole/TPM

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

20 29Monday, April 22, 2013

20 29Monday, April 22, 2013

20 29Monday, April 22, 2013

1A

1A

1A

C498

0.1U/10V_4

R455*0_4

+3V

TPM_TESTB1

C499

0.1U/10V_4

C502
*18P/50V_4

2

LPCPD#_TPM

LPC_PP

TPM_TESTB1 PLTRST#

NB5

NB5

NB5

C496

0.1U/10V_4

10
19
24
5

4
11
18
25

6
2

7
8

13
14

LPC_PP

TPM_XIN
TPM_XOUT

C497

0.1U/10V_4

install for SLB9635
No install for SLB9656

H=2.54mm

R457 *10M_4

Y6

1 2

*32.768KHz

C501
*18P/50V_4

install for SLB9635
No install for SLB9656

1

EC_strap2

EC_HW_strap

SERIRQ
LFRAME#
LAD0
LAD1
LAD2
LAD3

CLKRUN#
SIO_EXT_SCI#

GATEA20
RCIN#
3920_RST#

SERIRQ7,20

LFRAME#7,18,20

LAD07,18,20
LAD17,18,20
LAD27,18,20
LAD37,18,20

A A

CLK_33M_KBC8

TP9

TP15
TP12
TP11
TP14

PLTRST#2,8,18,19,20

CLKRUN#6,20

SIO_EXT_SCI#7
EC_A20GATE9

EC_RCIN#9
3920_RST#17

for SI 2/21: add SATA0GP

SATA2GP9
Slate_EC_Reset17
EC_BASE_EN17
PIRQH#8,17

B B

Vibrator _Out#9,15

For EC on BASE

PV 3/26: add home_BUT_LED

C C

THRM_MOINTOR14

10/17:modify
by EC-Jerry

D D

TP10
TP13

UNDOCK_INT#17

MUTE_LED_CNTL16

ECBASE_CLK17

ECBASE_DATA17

SUSWARN#_EC6

SLP_SUS#_EC6

Home_Button_EC17

SYS_I21,22

SATA2GP
Slate_EC_Reset
EC_BASE_EN

R375 0_2

R182 0_2

ACIN22,29

VOL_Down#15

VOL_UP#15

RF_LINK#18

GPIO33_EC7

DPWROK_EC6

SUSON24

MAINON24,25,29

SLP_SUS_ON6

S5_ON23

R21*0_4/S

R24*0_4

THRM_ALERT_HW#1

MBATLED017

C19

0.1U/10V_2

1 2

THRM_MOINTOR
THRM_MOINTOR1

1

MUTE_LED_CNTL
ECBASE_CLK

ECBASE_DATA

BIOS_RD#
BIOS_WR#
BIOS_CS#

ACIN

VOL_Down#
VOL_UP#

D1 MEK500V-40

EC_PECI_R
Home_Button_EC Home_Button_EC

SUSON
MAINON

C13

4.7U/6.3V_6

C15

0.1U/10V_2

1 2

2

U7

3

SERIRQ

4

LFRAME

10

LAD0

8

LAD1

7

LAD2

5

LAD3

12

PCICLK

13

PCIRST/GPIO5

38

CLKRUN

20

SCI/GPIOE

1

GA20/GPIO0

2

KBRST/GPIO1

37

ECRST

55

KSI0/GPIO30

56

KSI1/GPIO31

57

KSI2/GPIO32

58

KSI3/GPIO33

59

KSI4/GPIO34

60

KSI5/GPIO35

61

KSI6/GPIO36

62

KSI7/GPIO37

39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
81
82

83
84
85
86
87
88

119
120
128

89

76
109
110
112
114
115
116
117
118

97

98

99
100
101
102
103
104
105
106
107
108

124

KB3940QF A1

KSO0/GPIO20
KSO1/GPIO21
KSO2/GPIO22
KSO3/GPIO23
KSO4/GPIO24
KSO5/GPIO25
KSO6/GPIO26
KSO7/GPIO27
KSO8/GPIO28
KSO9/GPIO29
KSO10/GPIO2A
KSO11/GPIO2B
KSO12/GPIO2C
KSO13/GPIO2D
KSO14/GPIO2E
KSO15/GPIO2F
KSO16/GPIO48
KSO17/GPIO49

PSCLK1/GPIO4A
PSDAT1/GPIO4B
PSCLK2/GPIO4C
PSDAT2/GPIO4D
PSCLK3/GPIO4E
PSDAT3/GPIO4F

RD
WR
SELMEM/SPICS
SELIO/GPIO50
SELIO2/GPIO43
D0/GPXD0
D1/GPXD1
D2/GPXD2
D3/GPXD3
D4/GPXD4
D5/GPXD5
D6/GPXD6
D7/GPXD7

A0/GPXA0
A1/GPXA1
A2/GPXA2
A3/GPXA3
A4/GPXA4
A5/GPXA5
A6/GPXA6
A7/GPXA7
A8/GPXA8
A9/GPXA9
A10/GPXA10
A11/GPXA11

V18R

FANPWM1/GPIO12
FANPWM2/GPIO13

FANFB1/GPIO14
FANFB2/GPIO15

CIR_RX/GPIO40

Need Change New PN

C92

0.1U/10V_2

1 2

2

VCC1
VCC2
VCC3
VCC4
VCC5
VCC6
AVCC

AD0/GPI38
AD1/GPI39
AD2/GPI3A
AD3/GPI3B

DA0/GPO3C
DA1/GPO3D
DA2/GPO3E
DA3/GPO3F

PWM1/GPIOE

PWM2/GPIO10

SCL1/GPIO44
SDA1/GPIO45
SCL2/GPIO46
SDA2/GPIO47

GPIO4
GPIO7

GPIO8
GPIOA

GPIOB
GPIOC

GPIOD
GPIO11
GPIO16
GPIO17
GPIO18

GPIO19

GPIO1A

GPIO41
GPIO42
GPIO52
GPIO53
GPIO54
GPIO55
GPIO56
GPIO57
GPIO58
GPIO59

XCLKO

XCLKI

GND1
GND2
GND3
GND4
GND5
AGND

+3VPCU

9
22
33
96
111
125
67

63

TEMP_MBAT

64

AD_TYPE

65

AD_AIR

66

SYS_I

68
70

HOME_BUTTON_SLEEP

71

BATSHIP

72

PCH_PCIE_WAKE#

21

DRAMRST_CNTRL_EC

23

GPIO27_EC

26

FAN1_PWM

27

HOME_BUTTON_INT#

28

FAN1SIG

29
77

MBCLK

78

MBDATA

79

MBCLK2

80

MBDATA2

6

SUSB#

14

HWPG

15

H_PROCHOT#_EC

16

SUSC#

17
18
19

NBSWON1#

25
30

R115 *0_4/S

31

ECBASE_INT#

32

SIO_EXT_SMI#

34

VRON

36

DOCK_DET_R

73

EC_PCIE_WAKE#

74

THRM_MOINTOR

75

GPIO42_EC

90

DNBSWON#

91
92
93

EC_PWROK

95

RSMRST#

121

VOLMUTE#

126

BIOS_SPI_CLK

127

LID_EC#

123

CRY2

122

CRY1

11
24
35
94
113
69

R134 0_6

3

C72 0.1U/10V_2
C47 0.1U/10V_2
C43 0.1U/10V_2
C24 0.1U/10V_2
C20 0.1U/10V_2
C185 0.1U/10V_2
C16 0.1U/10V_2
C48 0.1U/10V_2
C77 0.1U/10V_2

+3VPCU_EC

C143 0.1U/10V_2

SUSACK#_EC 6

C18 22P/25V_2

R19 *0_4/S

500mA

4.7U/6.3V_6

TEMP_MBAT 22
AD_AIR 22

SYS_I 21,22

SI 2/22: change PCI_SERR# pin from "89" to "68"

PCI_SERR# 9

TP42

BATSHIP 22

PCIE_WAKE# 6,18,19
DRAMRST_CNTRL_EC 2

GPIO27_EC 9

FAN1_PWM 15

HOME_BUTTON_INT# 15

FAN1SIG 15

TS_ON 15

MBCLK 22
MBDATA 22
MBCLK2 2,8,12,15
MBDATA2 2,8,12,15

SUSB# 6
HWPG 23,24,25,26

SUSC# 6

EC_AOCS# 18
NBSWON1# 15,21
EMU_LID 14
EC_DEBUG 18

ECBASE_INT# 17

SIO_EXT_SMI# 9
VRON 27

DOCK_DET_R 17

EC_PCIE_WAKE# 18
THRM_MOINTOR 4

DNBSWON# 6

TP2

AC_LED_ON 6

EC_PWROK 6
RSMRST# 6
VOLMUTE# 16

LID_EC# 19

AC_PRESENT_EC 6

4

C121

2/22:modify by EC-Jerry

GPIO13/GPIO41 for NVD GC6 function

for Battery charge/charge

for DDR Thermal IC

PV 3/27: change AC_LED_ON pin from "106" to "92"

L1
BLM15AG700SS1D(70,0.5A)

PV 3/27: R19/20/21 Change to shortpad

SI Add 0ohm on AGND for ENE request!

CRY2

3

R20 *0_4/S C46 0.1U/10V_2

R23
100K/F_2

1 2

4

+3VPCU+3VPCU_EC

L11
BLM18BA470SN1D

PV-1 4/15: C33 stuff 0.1u

BIOS_SPI_CLK_I

R17
33_2

C12
22P/25V_2

PCH_SUSCLK 6

5

1 3

3920_RST#

Q8
*METR3904-G

2

R120 4.7K/F_2

D2 MEK500V-40

R118 10K/F_2

R119 0_4 R171 10K/F_2

2 1

6

EC_PWROKOVT_DETC

THRM_ALERT_HW#1

Open Drain need pu high

R161 4.7K/F_2

R160 *0_4

2

Q19

13

*METR3904-G

+1.05V

IMVP_PWRGD 6,27

C232 220P/50V_2

PM_THRMTRIP# 2,9

Power Button Rest

C33

0.1U/10V_4

+3VPCU

PV-1 4/15: 󰇤 R482/483

PV 3/26: add R476 pull-up/R121 to +3VPCU
SI 2/20: add R421~R425 pull-up

HWPG

+3VPCU

C50 *10P/25V_2

Adapter select for EC

+3VPCU

+1.05V2,4,6,7,8,10,20,25,27
+3V2,6,7,8,9,10,12,13,14,15,16,17,18,19,20,25,27,29
+3VPCU4,7,15,17,18,19,22,23

5

C36

0.01U/16V_4

R86 10K/F_2
R109 4.7K/F_2
R99 4.7K/F_2
R95 10K/F_2
R169 4.7K/F_2
R170 4.7K/F_2
R175 10K/F_2
R25 4.7K/F_2
R26 4.7K/F_2
R97 10K/F_2
R415 4.7K/F_2
R421 4.7K/F_2
R422 4.7K/F_2
R476 4.7K/F_2
R121 4.7K/F_2
R482 *4.7K/F_2
R483 *4.7K/F_2

C52 0.1U/10V_2

R159 47K_4

R112 *10K/F_2

Hi ==> DIS/SG ( 90W )
Low ==>UMA ( 65W)

EC_PECI2

C40

0.047UF_4

NBSWON1#
MBCLK
MBDATA
EC_PCIE_WAKE#
ECBASE_CLK
ECBASE_DATA
EC_HW_strap
VOL_Down#
VOL_UP#
UNDOCK_INT#
LID_EC#
AC_LED_ON
MBATLED0

HOME_BUTTON_INT#

MBCLK2
MBDATA2

3920_RST#

C180 0.1U/10V_2

R67 *10_4

H_PECI (50ohm)
Route on microstrip only
Spacing >18 mils
Trace Length: 0.4~6.125 iches

CLK_33M_KBC

GPIO42_EC

R18 43_4

6

7

adapter Type check

+3V

+3VPCU

AD_TYPE

C178

0.1U/10V_2

H_PROCHOT#_EC

U4

1

MRDLY

2

GND

3

CD

G677L308A31U

Stuff while the EC no stuff

VCC

RESET#

MR#

6

5

4

BUTTON_ONKEY_R

3920_RST#

+3VPCU

for SI 2/20: R74 stuff

Reserve for ENE Hold time issue

R481 4.7K/F_2

+3VPCU

PV-1 4/15: add R481

EC_BASE_EN



SI 2/25: add R464 pull-down for IDT recommend

+3V

SI 2/20: R121 stuff

Vender
EON

AMIC 1MB AKE3GZP0801 (A25L080M-F)
Socket

BIOS_CS#

R111 10K/F_2

EC_PECI_R

BIOS_SPI_CLK_I
BIOS_WR#

BIOS_RD#

+3VPCU

NB5

NB5

NB5

R96 10K/F_2

7

2

R22
*10K/F_2

+3VPCU

C44

0.1U/10V_2

R74 *0_4/S

R6847K/F_4

+3VPCU

R75 10K/F_2

PV 3/27: R74 Change to shortpad

MUTE_LED_CNTL

R480 *4.7K/F_2
R16 *10K/F_2
R93 4.7K/F_2
R87 4.7K/F_2

R423 4.7K/F_2
R424 *4.7K/F_2
R425 4.7K/F_2

Size

P/N

1MB

AKE3GZN0Q01 (EON EN25Q80A-100HIP)
AKE3GFP0Z00 (MX25L8006EM2I-12G)MX

1MB

DFHS08FS023

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

8

+3VPCU

21

Change to 1SS355 as Current loss

D5
1SS355

2 1

R172 100/F_2

R180

12.1K/F_4

H_PROCHOT#

3

C14

Q1

*47P/50V_2

2N7002K

1

R53 *100K/F_2

Q3 DMG1012T-7(SOT523)

1

2

MBCLK2
MBDATA2
MBCLK
MBDATA
EC_strap2

SI modify on 4/12

SPI_3P

PROJECT : Wolverine

PROJECT : Wolverine

PROJECT : Wolverine

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

C75 *10P/25V_2
C70 *10P/25V_2
C90 *10P/25V_2

C85 *10P/25V_2
R181 *4.7K/F_2
R464 10K/F_2

HOME_BUTTON_INT#
GPIO33_EC
MBCLK2
MBDATA2

Vibrator _Out#
MUTE_LED_CNTL
TS_ON

U6

1

CE#

VDD

6

SCK

5

SI

2

SO

HOLD#

3

WP#

VSS

AKE3GZP0801

soic8-8-1_27

C179

100P/50V_2

H_PROCHOT# 2,27

3

8

7

SPI_7P

R52 10K/F_2

4

8

AD_ID 17

NBSWON1# 15,21

+3VPCU

21 29Monday, April 22, 2013

21 29Monday, April 22, 2013

21 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

28

Do Not add test pad on BATDIS_G signal

2

PR153

4.02K/F4

BQCMSRC

ACIN

BQVCC

2

*METR3904-G

1 3

+PRWSRC

PC103

0.1U/25V_4

3

CMSRC

4

ACDRV

5

ACPRES

20

VCC

8

SDA

9

SCL

PR88
*66.5K/F_4 PC73

3

PQ1
*2N7002K

1

modify on 2/26

PQ2

RC1206-R010

PR149
*0_2/S

PR150

CSIP

PC83

2

0.1U/25V_4

ACP

ACDET

6

*0.1U/10V_4

PR151
*0_2/S

CSIN

1

ACN

PU4

BQ24738

ILIM

10

PR57

*100K/F_4

+3VPCU

3

PR133

2K/F_4

21

REGN6V

PC104

PC53

1U/16V_4

16

0.1U/25V_4

7

PR49

100K/F_4

REGN

PHASE

LODRV

BATDRV

IOUT

BQIOUT

PC66

100P/50V_4

HIDRV

BTST

GND
GND
GND
GND
GND
GND

SRP
SRN

PR72
10/F_4

18

BQHIDRV

PR70

17

BQB_2

0_6

19

BQPHASE

15

BQLODRV

14
21
22
23
24
25

13

BQSRP

12

BQSRN

11

BQBATDRV

PC56

0.01U/50V_4

Place this cap
close to EC

D D

+3VPCU 4,7,15,17,18,19,21,23
BATT+

+PRWSRC 20

4

IDEA_G_1

G

PR51

220K_4

AD_AIR21

PC130

0.1U/10V_4

Place this cap
close to EC

6
7
8

3

65

Q2

2 1

4

+PRWSRC+VAD

PR30
1K_6

PQ3

Q1

MMDT2907A

PR47
220K_4

PR46
1M_4

C C

PQ7
EMB20P03V

S D

1 5
2
3

B B

A A

modify on 2/23

5

PR24
1M_4

+VAD

+VAD17,20,29

+PRWSRC

+VAD

PD2

P4SMAJ20A

2 1

Place this ZVS close to
Diode away +VIN

+VA+VA_AIR

PD3

21

MEW316-D3-G

PR22
75K/F_4

PR23

12.4K/F_4

+VAD

PR94
22_8

4

PQ16

QM3016D

4 3

1

PC158

*2200P/50V_4

BATDIS_G

REGN6V

PC81

0.47U/25V_6

ACDET=13.2V

+VAD

MIN. BATV=7.2V

+PRWSRC

+VA_AIR

PC157

0.022U/50V_6

PR155
2K/F_4

BQACDRV

PR100
100K/F_4

ACIN21,29

PR101
100K/F_4

PR61

MBDATA BQDATA

*0_4/S

PR55

MBCLK BQCLK

*0_4/S

PR87
430K/F_4

PR89

69.8K/F_4

PR42
*1M_4

PR41
*1M_4

PR21
*75K/F_4

PR20
*12.4K/F_4

PQ9

+BATCHG

TPCA8064-H

3

D

S

2

5

1

G

BATDIS_ID_DODBQBATDRV

Place this ZVS close to
Far-Far away +VIN

BQB_1

4

PD1

P4SMAJ20A

2 1

21

PD4 RB501V-40

PC68

0.047U/25V_4

PR58

0.1U/25V_4

0_4/P

PR50
0_4/P

0.1U/25V_4

SYS_I 21

REGN6V

PQ8

EMB20N03V

PC44

PC38

PC137
2200P/50V_4

PC43

0.1U/25V_4

2

+VIN

678

35241

678

35241

PL13
80/5A

PL12
80/5A

PC145

0.1U/25V_4

MBDATA21

MBCLK21

PC106

4.7U/25V_6

PQ10
EMB20N03V

PL9

4.7uH/5.5A(EM-47AM05V08)

PR77
*2.2_6

PC67
*2200P/50V_4

PC151

0.1U/25V_4

PC150

*100P/50V_4

PC126
2200P/50V_4

BQLR

CSOP

CSON

PR143
330_4

PD9

PDZ5.6B

NB5

NB5

NB5

PR142
330_4

PC149

*100P/50V_4

PD8

2 1

2 1

PDZ5.6B

PC128
1000P/50V_4

RC1206-R020

PR136

*0_2/S

PC127

0.1U/25V_4

PR137

21

PC147

PR138
*0_2/S

+BATCHG

BATSHIP21

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom
Date: Sheet of

Date: Sheet of

Date: Sheet of

2

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

BATT+

SMD
SMC

B_TEMP_MBAT

PC153

0.01U/25V_4

10U/25V_8

3

1

2013/1/14 update

PMPCR0-08MNBS2ZZ4H5

PR135
200K_4

PR141
1K/F_4

Place this cap

close to EC

PC146

10U/25V_8

PR140
470_8

PQ12
2N7002K

1

CN7

9

BAT+

8

BAT+

7

BAT+

6

SMD

5

SMC

4

TS

3

GND

2

GND

1

GND

+3VPCU

PC136

0.01U/25V_4

+BATCHG

PC138

0.1U/25V_4

22 29Monday, April 22, 2013

22 29Monday, April 22, 2013

22 29Monday, April 22, 2013

10

GND

11

GND

TEMP_MBAT 21

PD7
SX34

1A

1A

1A

5

DC/DC +3VS5/+5VS5

4

3

2

1

+3VS5 6,9,10,18,19,20,25,29
+5VS5 6,24,25,26,27,29

D D

PR66
10K/F_4

+3VS5

HWPG21,24,25,26

C C

B B

A A

Reserve for NB670 5V version.

HWPG NB670PG

+VIN

S5_ON21,23

+5VPCU

S5_ON21,23

+3VPCU

PC64

10U/6.3V_6

PR65
0_4/P

PR69

*665K/F_4

S5_ON NB670EN NB670VOUT

PR64

0_4/P

10U/6.3V_6

HWPG NB671PG

S5_ON NB671EN

PR76
0_4/P

PC74

PR79
0_4/P

PR123
0_4/P

NB670ENLDO

PR71
*330K/F_4

PC125

1U/6.3V_4

PU5

6

LDO

PR60

3

NC

*0_4

5

CLK

4

PGOOD

12

ENLDO

13

EN

PC57
*0.1U/10V_4

NB670

PU7

6

NC

PR78

3

NC

*0_4

5

NC

4

PGOOD

11

VCC

13

EN

PC124
*0.1U/10V_4 PR126

NB669

+VIN

AGND
PGND

BST

VCC

VOUT

VIN

SW
SW
SW
SW

VIN

AGND
PGND

BST

SW
SW
SW
SW

VOUT

FB

*665K/F_4

1

14
2

10

8
9
15
16

11

7

PR124

NB670BST

NB670SW

+5VALW

1

14
2

10

8
9
15
16

7

12

PC71
1U/6.3V_4

NB671SW

NB671VOUT

NB671FB

PR83

+5VS5

PC72
*0.1U/10V_4

PC50

0.1U/25V_4

NB670BST_S

0_6

PD5

*BAT54C

modify on 3/5

PC82

0.1U/25V_4

PR121

NB671BST_SNB671BST

0_6

PR125

*82K/F_4

*330K/F_4

PC47

4.7U/25V_6

PC108

0.1U/25V_4

+5VPCU

4.7U/25V_6

+VIN_3VS5

PC39

4.7U/25V_6

PC88

PC109

4.7U/25V_6

PC107

0.1U/25V_4

PC49

PR106
*2.2_6

PC123
*2200P/50V_4

+VIN_5VS5

PR81
*2.2_6

PC65
*2200P/50V_4

2200P/50V_4

PC96

+VIN

PL1
*0_8/S

PC32

0.1U/25V_4

PL10

4.7uH/5.5A

PR129
*0_2/S

+3.3VS5_S

+3.3 Volt +/- 5%
Countinue current:2A
Peak current:3A
OCP minimum:7.5A

+3VS5

PC92
22U/6.3V_8

PC89
22U/6.3V_8

co-layout with output POSCAP

PC93
22U/6.3V_8

delete PJP2 modify on 2/23

PC95
22U/6.3V_8

PC112

0.1U/10V_4

delete PC98 modify on 2/23

+VIN

PL7
*0_8/S

PC75

0.1U/25V_4

2200P/50V_4

PR130
*0_2/S

+5VS5_S

PL8

4.7uH/5.5A

+5 Volt +/- 5%
Countinue current:2A
Peak current:3A
OCP minimum:7.5A

+5VS5

PC90
22U/6.3V_8

PC91
22U/6.3V_8

delete PJP3 modify on 2/23

PC140
22U/6.3V_8

PC141
22U/6.3V_8

PC129

0.1U/10V_4

delete PC97 modify on 2/23

29

Reserve for NB670 5V version.

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

NB5

NB5

5

4

3

2

NB5

EC (KB3940QF)/ROM

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

23 29Monday, April 22, 2013

23 29Monday, April 22, 2013

23 29Monday, April 22, 2013

1A

1A

1A

1

2

3

4

5

31

678

678

modify on 4/17

+VIN_DDR

PC164

0.1U/25V_4

PQ17
EMB20N03V

PR170
*2.2_6

*2200P/50V_4

PC179

EC80
*22U/25V_8

PC171

4.7U/25V_8

EC181
*1000P/50V_4

PC172

4.7U/25V_8

PL16

0.82uH/13A(EM-82BM05V04)

Del PL15 on 4/17

PC165
2200P/50V_4

PR163
*0_2/S

+VIN+VIN_DDR

PC163

0.1U/25V_4

+1.35VSUS_S

12

+

+1.35V +/- 5%
Countinue current:6A
Peak current:10A
OCP minimum:12A

+1.5VSUS

PJP4
*POWER_JP/S

1 2

PC174

0.1U/10V_4

PC175
330U_2V_7343

+1.5VSUS 2,4,12

A A

( VTT/2A )

+0.75V_DDR_VTT

+0.75V_DDR_VTT12,29

PC170

10U/6.3V_6

PD10

B B

MAINON21,25,29

C C

RB501V-40

PR165

100K/F_4

21

PC178

0.1U/10V_4

( 3mA )

DDR_VTTREF4,12

SUSON21

HWPG21,23,25,26

PR162
*100/F_4

PC169
*0.1U/10V_4

PR169
0_4/P
PR166
0_4/P

PR168
120K/F_4

PR167
47K/F_4

PC166

0.22U/10V_4

51216S3

51216S5
51216PG

51216TRIP

51216MODE

+5VS5

PU9

VTT3VLDOIN

1

VTTSNS

4

VTTGND

7

GND

21

GND

5

VTTREF

17

S3

16

S5

20

PGOOD

18

TRIP

19

MODE

12

V5IN

TPS51216RUKR
PC173
1U/6.3V_4

VDDQSNS

DRVH

VBST

DRVL

PGND

VREF

REFIN

+1.5VSUS

2

PC177
*10U/6.3V_6

14

15

13

SW

11

10

9

+1.8VREF

6

8

51216VBST

51216SW

51216DRVL

PC167

0.1U/10V_4

51216REFIN

PC168

0.01U/25V_4

PR164

2.2_6

51216VDDQSNS

51216VBST_S

PR161
10K/F_4

PR160

51.1K/F_4

51216DRVH

PC176

0.1U/25V_4

PQ18

MDV1595SURH

Rds(on) 14m ohm

35241

35241

D D

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

NB5

NB5

1

2

3

4

NB5

EC (KB3940QF)/ROM

Date: Sheet of

Date: Sheet of

Date: Sheet of

5

24 29Monday, April 22, 2013

24 29Monday, April 22, 2013

24 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

30

CS

PGOOD
EN

PAD

PR114
*10/F_4

+3VS5

RT8240TON

5

11

VCC

RT8240BZ

GND12FB

RGND

7

RT8240RGND

PR92
10K/F_4

PU6

UGATE

TON

BOOST

6

RT8240FB

PR86

PHASE
LGATE

*0_4

3
4

2
1

PR117
*10/F_4

RT8240DH
8240BST

RT8240LX

RT8240DL

H_VTTVID1 4

PR84

2.2_6

PR116
0_4
PR115
0_4

8240BST1

PC77

0.1U/25V_4

+VIN_1.05V_VTT

G

4

PQ4

TPCA8A11-H

RDSon= 5m ohm

678

PQ20
EMB20N03V

35241

5

D

S

213

VCCP_SENSE 4
VSSP_SENSE 4

PC59

4.7U/25V_8

modify on 3/5

RT8240LX

PR32
*2.2_6

PC26
*2200P/50V_4

PC37

PC60

4.7U/25V_8

2200P/50V_4

0.82uH/13A(EM-82BM05V04)

+VIN

PL6
*0_8/S

PC61

0.1U/25V_4

PC70

0.1U/25V_4

+1.05V_VTT +/- 5%
Countinue current:10A
Peak current: 12A
OCP minimum: 14.5A

12

PC42
330U_2V_7343

+1.05V

+1.05V 2,4,6,7,8,10,20,21,27

PC69

0.1U/10V_4

PL4

600 mils

PR74
*0_2/S

+

D D

PR103
10_6

PC94

1U/6.3V_4

RT8240ILIM

RT8240EN

RT8240VCC

10

9
8

13

+5VS5

+3V

PR107

1.05V_VTT_PWRGD26

HWPG21,23,24,26

MAINON21,24,25,29

PD6

2 1

MEW316-D3-G

modify on 2/26

C C

10K/F_4

PR112
*0_4/S

PR113
0_4/P PC114

PR99

61.9K/F_4

RT8240HWPG_S2A

*0.1U/10V_4

modify on 3/28

VOUT

VADJ

+3VS5+5VS5

6

VIN

PC55
*4.7U/6.3V_6

5

PR3

R1

*127K/F_4

4

PR2

R2

*100K/F_4

+1.8V Volt +/- 5%

Countinue current:100mA

+1.8V

PC54

*4.7U/6.3V_6

B B

PC18
*1U/6.3V_4

PR13

MAINON21,24,25,29

*10K/F_4

PC12
*0.47U/6.3V_4

PU2

1

VBIAS

2

GND

3

EN

*G9183-12TP1U

Vout=0.8(1+R1/R2)

A A

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

NB5

NB5

5

4

3

2

NB5

EC (KB3940QF)/ROM

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

25 29Monday, April 22, 2013

25 29Monday, April 22, 2013

25 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

29

D D

modify on 4/17

VCC_TPS51461

EC79

C C

*22U/25V_8

EC180
*1000P/50V_4

HWPG21,23,24,25

PC9
1U/6.3V_4

PR1
0_6/P

PC8

2.2U/6.3V_4

51461VCC

15

16

17

18

Del PJP1 on 4/17

V5FILT

VCC_TPS51461

+5VS5

PC7
10U/6.3V_8

PC6
10U/6.3V_8

PC5

0.1U/10V_4

modify on 3/28

B B

22

VIN

23

VIN

24

VIN

19

PGND

20

PGND

21

PGND

1

GND

PC11

0.22U/6.3V_4

V5DRV

PGOOD

PU1

TPS51463RGER

VREF2COMP3SLEW4VOUT5MODE

51461REF

51461COMP

PC14

0.01U/16V_4

PR4

4.99K/F_4

PC15

3300P/50V_4

TPS51463RGER/AL051463000

For CPU ULV system agent
voltage slew rate of 0.5 -10 mV/µs

SEL0

SEL1

0

0

1

0

1

0

1 1

VCCSA_VID1

VCCSA_VID0

51461EN

13

EN

VID014VID1

BST

SW

SW

SW

SW

SW

6

PR35

*33K/F_4

modify on 3/6

PR14

12

0_6

11

10

9

8

7

+VCCSA

0.9V

0.85V

0.775V

0.75V

PC10

*0.1U/10V_4

PC13

*0.1U/10V_4

PC28

0.1U/25V_4

PR15
0_4/P

PR5
*0_4/S

PR6
*0_4/S

PR36
0_4/P

PC27

*0.1U/10V_4

0.47uH/17.5A(EM-47BM05V05)

PR48
*2.2_6

PC51
*2200P/50V_4

PR16
100/F_4

VCCUSA_SENSE 4

VCCSA_SEL 4

VCCSA_SEL0 4

1.05V_VTT_PWRGD 25

+VCCSA Volt +/- 5%
Countinue current:4A
Peak current:6A
OCP minimum:7A

PL2

PC84

PC85

PC87

PC86

22U/6.3V_8

22U/6.3V_8

22U/6.3V_8

51461FB

+VCCSA

PC63

PR85
*0_2/S

0.1U/10V_4

22U/6.3V_8

A A

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

NB5

NB5

5

4

3

2

NB5

EC (KB3940QF)/ROM

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

26 29Monday, April 22, 2013

26 29Monday, April 22, 2013

26 29Monday, April 22, 2013

1A

1A

1A

5

+5VS5

PR98
*0_4

D D

C C

SDIO

VR_SVID_ALERT#

SCLK

B B

A A

TRBSTA#

Using Kevin connection

TRBST#

for layout

VCC_AXG_SENSE4

VSS_AXG_SENSE4

+1.05V

PR54
*75/F_4

GFX_HWPG

VR_SVID_DATA4

VR_SVID_ALERT#4

VR_SVID_CLK4

+VIN_VCC_CORE

PR9
10/F_4

CSCOMP

PR26

1.21K/F_4

PR17

0_4

PC17
680P/50V_4

+3V

PR45
10K/F_4

IMVP_PWRGD6,21

+3V

PR82
10K/F_4

PR75
130/F_4

VSS_SENSE4

VCC_SENSE4

VRON21

+1.05V

GFX_HWPG

PR67
*75/F_4

5

PR62

54.9/F_4

H_PROCHOT#

PR80
0_4

PC45
*0.1U/10V_4

PC52

0.1U/10V_4

Using Kevin connection
for layout

GFX_HWPG

1K/F_4

6132AGND

PR43
0_4

PR33
0_4

6132AGND

DROOP

4

+5VS5

6132AGND

PR73 *0_4/S
PR68 *0_4/S

6132AGND

H_PROCHOT#2,21

PC48

0.01U/50V_4

PC16
4700P/25V_4

PC19

*1000P/50V_4

4

PR96
10/F_4

PR63 10K/F_4
PR59 95.3K/F_4

PC33
1000P/50V_4

PR37

1K/F_4

PR25

49.9/F_4

PR8

24.9K/F_4

CSREF

PC110

33P/50V_4

PR97

1K/F_4

PR110
0_4

PR109
0_4

PR91

2.2_6

PC80

2.2U/6.3V_6

VR_SVID_ALERT#

PC21

100P/50V_4

modify on 3/28

PR7

*0_4/S

6132AGND

VCC

6132EN

SDIO
SCLK

VBOOT
ROSC

6132VRMP
H_PROCHOT#
IMVP_PWRGD

VSN
VSP
DIFF

PR38

5.11K/F_4

modify on 3/28

PR10

24.3K/F_4

PC99

6132AGND

0.1U/10V_4
PR111

24.3K/F_4

PC111 10P/50V_4

PC117

PR118

4.3K/F_4
2200P/50V_4

PC105
1000P/50V_4

VSPA

DIFFA

VSNA

59

58

60

61

VSPA

VSNA

EPAD

1

VCC

2

VDDBP

3

VRDYA

4

EN

5

SDIO

6

ALERT#

7

SCLK

8

VBOOT

9

ROSC

10

VRMP

11

VRHOT#

12

VRDY

13

VSN

14

VSP

15

DIFF

FB

TRBST#

18

17

16

FB

COMP

TRBST#

PR39

9.09K/F_4

PC36

33P/50V_4

PC29

2200P/50V_4

PC30

0.1U/10V_4

6132AGND 6132AGND

FBA

TRBSTA#

57

56

FBA

DIFFA

TRBSTA#

NCP6132A

COMP

IOUT

ILIM

19

20

IMON

ILIM

IMONA

PR95

12.1K/F_4

IMONA

DROOPA

CSCOMPA

ILIMA

COMPA

54

52

55

53

51

ILIMA

IOUTA

COMPA

DROOPA

CSCOMPA

PU3

CSCOMP22CSP325CSREF24CSSUM

DROOP

23

21

CSREF

CSSUM

CSP3

DROOP

CSCOMP

PC31
1000P/50V_4

6132AGND

PC22 *1200P/50V_4

PC34 560P/50V_4

PR11

75K/F_4

PR19
220K_6 NTC

3

PC113

PC120
470P/50V_4

1200P/50V_4

PR108
165K/F_4

PR102

68.1K/F_6

6132AGND

PC101
1000P/50V_4

PC100

CSSUMA

CSP1A

CSREFA

TSENSEA

0.1U/10V_4

46

49

50

48

47

CSP2A

CSP1A

TSNSA

CSREFA

CSSUMA

CSP1

CSP2

27

26

28

CSP1

CSP2

TSENSE CSP2A

12

3

45

PWMA

44

BSTA

42

SWA

43

HGA

41

LGA

40

BST2

38

SW2

39

HG2

37

LG2

36

PVCC

35

PGND

34

LG1

32

HG1

33

SW1

31

BST1

DRVEN

TSNS

PWM

29

30

6132_PWM

PC35

0.1U/10V_4

CSREF 28

CSSUM

PR12

165K/F_4

Put close with VCORE
Phase 1 Inductor

PR119
75K/F_4

Place NTC close
with GT Inductor

SWN1A

CSREFA 28

+5VS5

6132AGND

modify on 3/28

6132_PWMA
BSTA

LG1
HG1
SW1
BST1

modify on 3/28

PR44

19.6K/F_4

6132AGND

+5VS5

+5VS5
+5VS5

12

SWN1A 28

PR90

19.6K/F_4

PR31

360K/F_6

PR158
220K_6 NTC

2.2U/6.3V_6

0.22U/25V_6

2

CSREFA

CSP1A SWN1A

PC78

0.22U/25V_6

PC62

PC46

CSREF

SWN1

modify on 3/28

PC23

0.01U/25V_4

SWN1 28

2

PR127
1K/F_4

PC102

0.033U/10V_4

modify on 3/28

SW1A 28
HG1A 28
LG1A 28

LG1 28
HG1 28
SW1 28

PR40

4.99K/F_4

PR105

6.49K/F_4

DROOPA

SWN1

PC121

1000P/50V_4

1

CSREFACSCOMPA

TSENSEA

12

PR134

PR144

100K_4 NTC

8.25K/F_4

Place NTC close with
V_GT hot spot

+5VS5

PR93

Rd

*0_4PR56

POP Rd

CSP1A

PR27

8.25K/F_4

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

NB5

NB5

NB5

Date: Sheet of

Date: Sheet of

Date: Sheet of

For discrete only
operation

TSENSE

12

PR28
100K_4 NTC

Place close with
VCORE hot spot

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

CPU Core1 (NCP6132B)

CPU Core1 (NCP6132B)

CPU Core1 (NCP6132B)

1

32

27 29Monday, April 22, 2013

27 29Monday, April 22, 2013

27 29Monday, April 22, 2013

1A

1A

1A

5

4

3

2

1

33

modify on 4/16

delete PL3 on 3/1

D D

PC41

4.7U/25V_8

PC40

4.7U/25V_8

PC25

0.1U/25V_4

PC24
2200P/50V_4

12

Add PQ47 on 3/6

5

D

G

PR34

HG127

SW127

LG127

1_6

PQ47

FDMS0308AS

4

S

PQ6

FDMS7698

213

5

D

G

4

S

213

PR29
*4.7_6

PC20
*1000P/50V_4

modify on 3/28

PL5

0.22uH/29A_7X7X1.8

modify on 3/28

PR52 *0_2/S

C C

PR53 *0_2/S

PC58

0.1U/25V_4

No POP for UMA

+VIN+VIN_VCC_CORE

12

+

PC4

15U 25V

12

+

PC1

* 22U 25V

delete PC2 on 2/26

delete PC79 on 3/1

PR18

CSREF 27

10/F_4

SWN1 27

12

+

PC3

*15U 25V

+VCC_CORE

12

+

PC76
560U_2V_7343

PC122

0.1U/10V_4

+VCC_CORE (8W)
Countinue current:12A

Iccmax:25A
Load Line : -2.9mV/A

B B

2

D1D1D1

PQ14

RJK03S3DPA

S2S2S2

765

LG1A27
SW1A27

A A

5

4

modify on 4/15

PC133

4.7U/25V_8

1

G1

9

S1/D2

G2

8

+VIN_VCC_GT +VIN

PC134

PC131

0.1U/25V_4

4.7U/25V_6

PR148
1_6

0.24uH/28A_7X7X3

PR159
*4.7_6

PC161
*1000P/50V_4

3

HG1A 27

PL14

PL11
*0_8/S

PC132
2200P/50V_4

PR157 *0_2/S
PR156 *0_2/S

PC139

0.1U/25V_4

PR104
10/F_4

+VCC_GFX
Countinue current:15A
Iccmax:25A
Load Line : -3.9mV/A

+VCC_GFX

12

+

CSREFA 27
SWN1A 27

PC159
560U_2V_7343

PC160

0.1U/10V_4

2

EC99
10U/6.3V_6

modify on 4/17

EC98
10U/6.3V_6

NB5

NB5

NB5

EC97
10U/6.3V_6

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
C

C

C

CPU Core2 (NCP5911)

CPU Core2 (NCP5911)

CPU Core2 (NCP5911)

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

1A

1A

1A

28 29Monday, April 22, 2013

28 29Monday, April 22, 2013

28 29Monday, April 22, 2013

5

4

3

2

1

34

PR145
*0_4/S

PC116
1U/35V_6

PC115

PR120
*0_4

PQ13

PR146
*0_4/S

+VAD

MAIND 4

ACIN 21,22

PR128
*750K/F_4

PR131
*100K/F_4

+5VS5

678

35241

*10U/6.3V_6

PC142

+5V

PC155

0.1U/10V_4

5.1A

+5V

PC148

0.1U/10V_4

2

3

1

PQ15
2N7002K

+VIN

0.47U/25V_6

DCAP

G5934VOUT

16

17

VOUT

D_CAP

15

G5934PG

PG

14

REG

DISC3

DISC2

21

MAIND

GND

+12VALW

13

7

6

G5934VSENSE

PC144

1U/16V_4

EMB20N03V

VSENSE

DRIVER1

DRIVER2

9

10

PC156
2200P/50V_4

+0.75V_DDR_VTT12,24

PR154
1M_4

PR152
1M_4

+VIN14,20,22,23,24,25,27,28
+3VS56,9,10,18,19,20,23,25
+5VS56,23,24,25,26,27

+12VALW

+3V2,6,7,8,9,10,12,13,14,15,16,17,18,19,20,21,25,27
+5V7,10,14,15,16,17,18

MAIN_ONG 2,4

PR122

D D

MAINON21,24,25

MAINON

PR147

PQ11

EMB20N03V

PC135
2200P/50V_4

*0_4/S

C C

PC154

0.1U/10V_4

5.2A

+3V

B B

PC143

0.1U/10V_4

+0.75V_DDR_VTT

+3VS5

678

35241

PC152
*10U/6.3V_6

22_6

+VAD

PC119

0.1U/25V_4

PR132
*0_4/S

PR139
*0_4/S

MAIND3.3V

1

ON1

2

ON2

3

ON3

4

ON4

5

G5934DISC1 G5934DISC2

DISC1

12

G5934VIN

20

VIN

DRIVER4

PC118

0.1U/25V_4

12

G5934CN

G5934CP

19

18

CP

CN

PU8

G5934RZ1U

DISC4

DRIVER3

8

11

G5934DISC4

+3V

A A

PROJECT : U62

PROJECT : U62

PROJECT : U62

Quanta Computer Inc.

Quanta Computer Inc.

Quanta Computer Inc.

Size Document Number Rev

Size Document Number Rev

Size Document Number Rev
Custom

Custom

Custom

EC (KB3940QF)/ROM

EC (KB3940QF)/ROM

NB5

NB5

5

4

3

2

NB5

EC (KB3940QF)/ROM

Date: Sheet of

Date: Sheet of

Date: Sheet of

1

29 29Monday, April 22, 2013

29 29Monday, April 22, 2013

29 29Monday, April 22, 2013

1A

1A

1A
