User Guide

Page 2

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel is a trademark of Intel Corporation in the U.S. and other countries. Windows is a U.S. registered trademark of Microsoft Corporation. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: November 2013

Document Part Number: 741488-001

Product notice

This guide describes features that are common to most models. Some features may not be available on your computer.

Not all features are available in all editions of Windows. This computer may require upgraded and/or separately purchased hardware, drivers and/or software to take full advantage of Windows functionality.

http://www.microsoft.com for details.

See

To obtain the latest information in this guide, contact support. For U.S. support, go

http://www.hp.com/go/contactHP.

For worldwide support, go to

http://welcome.hp.com/country/us/en/ wwcontact_us.html.

Software terms

By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a refund subject to the refund policy of your place of purchase.

For any further information or to request a full refund of the computer, please contact your local point of sale (the seller).

Page 3

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

Page 4

iv Safety warning notice

Page 5

Table of contents

1 Starting right ................................................................................................................................................... 1

Visit the HP Apps Store ........................................................................................................................ 1

Best practices ....................................................................................................................................... 1

Fun things to do .................................................................................................................................... 2

More HP resources .............................................................................................................................. 3

2 Getting to know your computer ..................................................................................................................... 5

Finding your hardware and software information ................................................................................. 5

Locating hardware ............................................................................................................... 5

Locating software ................................................................................................................. 5

Tablet edge components ...................................................................................................................... 6

Display .................................................................................................................................................. 9

Keyboard base ................................................................................................................................... 11

Top ..................................................................................................................................... 11

TouchPad .......................................................................................................................... 12

Lights ................................................................................................................................. 13

Keys ................................................................................................................................... 14

Right side ........................................................................................................................... 15

Left side ............................................................................................................................. 16

Releasing the tablet from the keyboard base .................................................................... 17

Changing your tablet's settings .......................................................................................................... 17

Changing your tablet's view ............................................................................................... 17

Turning your tablet's autorotate lock on or off ................................................... 17

Adjusting your tablet's screen brightness .......................................................... 18

Locating system information ............................................................................................................... 18

3 Connecting to a network .............................................................................................................................. 19

Connecting to a wireless network ....................................................................................................... 19

Using the wireless controls ................................................................................................ 19

Using the wireless button .................................................................................. 19

Using operating system controls ....................................................................... 19

Sharing data and drives and accessing software .............................................................. 20

Using a WLAN ................................................................................................................... 21

Using an Internet service provider .................................................................... 21

Setting up a WLAN ............................................................................................ 21

Configuring a wireless router ............................................................................ 22

Page 6

Protecting your WLAN ....................................................................................... 22

Connecting to a WLAN ...................................................................................... 22

Using Bluetooth wireless devices (select models only) ..................................................... 23

4 Enjoying entertainment features ................................................................................................................. 24

Multimedia features ............................................................................................................................ 25

Using the webcams ............................................................................................................................ 28

Using audio ........................................................................................................................................ 28

Connecting speakers ......................................................................................................... 29

Connecting headphones and microphones ....................................................................... 29

Using Beats Audio ............................................................................................................. 29

Accessing Beats Audio Control Panel ............................................................... 29

Enabling and disabling Beats Audio .................................................................. 30

Testing your audio features ............................................................................................... 30

Using video ......................................................................................................................................... 30

Connecting video devices using an HDMI cable ............................................................... 31

Setting up HDMI audio ...................................................................................... 31

Discovering and connecting to Miracast-compatible wireless displays (select models only) ............. 32

5 Navigating the screen ................................................................................................................................... 33

Using the TouchPad and gestures ..................................................................................................... 33

Tapping .............................................................................................................................. 34

Scrolling ............................................................................................................................. 35

2-finger pinch/zoom ........................................................................................................... 35

2-finger click ....................................................................................................................... 36

Rotating (select models only) ............................................................................................ 37

Flicking (select models only) .............................................................................................. 38

Edge swipes ...................................................................................................................... 38

Right-edge swipe .............................................................................................. 38

Left-edge swipe ................................................................................................. 39

Top-edge swipe ................................................................................................. 39

Using the touch screen ....................................................................................................................... 40

Using touch screen gestures ............................................................................................. 40

One-finger slide ................................................................................................. 40

Tapping ............................................................................................................. 41

Scrolling ............................................................................................................ 42

2-finger pinch/zoom ........................................................................................... 42

Rotating (select models only) ............................................................................ 43

Edge swipes ...................................................................................................... 43

Right-edge swipe .............................................................................. 43

Left-edge swipe ................................................................................ 44

Page 7

Top-edge swipe and bottom-edge swipe .......................................... 44

Using the on-screen keyboard ........................................................................................................... 45

Using the keyboard and mouse .......................................................................................................... 45

Using the keys ................................................................................................................... 45

Using the action keys ........................................................................................ 45

Using Windows shortcut keys ........................................................................... 47

Using the hot keys ............................................................................................. 47

6 Managing power ............................................................................................................................................ 48

Initiating Sleep and Hibernation ......................................................................................................... 48

Manually initiating and exiting Sleep .................................................................................. 48

Manually initiating and exiting Hibernation (select models only) ....................................... 49

Setting password protection on wakeup ............................................................................ 49

Using the power meter and power settings ........................................................................................ 49

Running on battery power .................................................................................................................. 49

Factory-sealed battery ....................................................................................................... 50

Conserving battery power .................................................................................................. 50

Identifying low battery levels .............................................................................................. 50

Resolving a low battery level ............................................................................................. 51

Resolving a low battery level when external power is available ........................ 51

Resolving a low battery level when no power source is available ..................... 51

Resolving a low battery level when the computer cannot exit Hibernation ....... 51

Running on external AC power .......................................................................................................... 51

Troubleshooting power problems ...................................................................................... 52

Shutting down (turning off) the computer ........................................................................................... 53

7 Maintaining your computer .......................................................................................................................... 54

Improving performance ...................................................................................................................... 54

Handling drives .................................................................................................................. 54

Using Disk Defragmenter ................................................................................................... 54

Using Disk Cleanup ........................................................................................................... 55

Updating programs and drivers .......................................................................................................... 55

Cleaning your computer ..................................................................................................................... 55

Cleaning procedures .......................................................................................................... 56

Cleaning the display (All-in-Ones or Notebooks) .............................................. 56

Cleaning the sides or cover ............................................................................... 56

Cleaning the TouchPad, keyboard, or mouse ................................................... 56

Traveling with or shipping your computer ........................................................................................... 57

vii

Page 8

8 Securing your computer and information .................................................................................................. 58

Using passwords ................................................................................................................................ 58

Setting Windows passwords .............................................................................................. 59

Setting Setup Utility (BIOS) passwords ............................................................................. 59

Using Internet security software ......................................................................................................... 60

Using antivirus software ..................................................................................................... 60

Using firewall software ....................................................................................................... 60

Installing software updates ................................................................................................................. 60

Installing critical security updates ...................................................................................... 61

Installing HP and third-party software updates .................................................................. 61

Securing your wireless network .......................................................................................................... 61

Backing up your software applications and information ..................................................................... 61

9 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI) ...................................................... 62

Starting Setup Utility (BIOS) ............................................................................................................... 62

Updating the BIOS ............................................................................................................................. 62

Determining the BIOS version ........................................................................................... 62

Downloading a BIOS update ............................................................................................. 63

Using HP PC Hardware Diagnostics (UEFI) ...................................................................................... 64

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ............................... 64

10 Backing up, restoring, and recovering ..................................................................................................... 65

Creating recovery media and backups ............................................................................................... 65

Creating HP Recovery media ............................................................................................ 65

Restore and recovery ......................................................................................................................... 66

Recovering using HP Recovery Manager .......................................................................... 67

What you need to know ..................................................................................... 67

Using the HP Recovery partition (select models only) ...................................... 67

Using HP Recovery media to recover ............................................................... 68

Changing the computer boot order ................................................................... 68

Removing the HP Recovery partition ................................................................................. 68

11 Specifications .............................................................................................................................................. 69

Input power ......................................................................................................................................... 69

Operating environment ....................................................................................................................... 69

12 Electrostatic Discharge .............................................................................................................................. 70

Index ................................................................................................................................................................... 71

viii

Page 9

1 Starting right

This computer is a powerful tool designed to enhance your work and entertainment. Read this chapter to learn about best practices after you set up your computer, fun things to do with your computer, and where to find additional HP resources.

Visit the HP Apps Store

To download apps to the Start screen, visit the HP Apps Store. The HP Apps Store offers a wide choice of popular games, entertainment and music apps, productivity apps, and apps exclusive to HP. The selection is updated regularly and includes regional content and country-specific offers. Be sure to check the HP Apps Store frequently for new and updated features.

IMPORTANT: You must be connected to the Internet to access the HP Apps Store.

To view and download an app:

1. From the Start screen, select the Store app.

2. Select HP Picks to view all the available apps.

3. Select the app you want to download, and then follow the on-screen instructions. When the

download is complete, the app appears on the All apps screen.

Best practices

To get the most out of your smart investment, after you set up and register the computer, we recommend the following steps:

● If you haven’t already done so, connect to a wired or wireless network. See details in

to a network.

Take a minute to browse the printed Windows Basics guide to explore the new Windows®

●

features.

Become familiar with the computer hardware and software. For more information, see

●

know your computer and Enjoying entertainment features for information.

Update or purchase antivirus software. Learn more at

●

Back up your hard drive by creating recovery discs or a recovery flash drive. See

●

restoring, and recovering.

Connecting

Getting to

Using antivirus software.

Backing up,

Visit the HP Apps Store 1

Page 10

Fun things to do

You know that you can watch a YouTube video on the computer. But did you know that you can

●

also connect your computer to a TV or gaming console? For more information, see

video devices using an HDMI cable.

You know that you can listen to music on the computer. But did you know that you can also

●

stream live radio to the computer and listen to music or talk radio from all over the world? See

Using audio.

● Experience music the way the artist intended, with deep controlled bass and clear, pure sound.

Using Beats Audio.

See

Use the TouchPad and the new Windows touch gestures for smooth control of images and

●

pages of text. See

Connecting

Using the TouchPad and gestures and Using the touch screen.

2 Chapter 1 Starting right

Page 11

More HP resources

You have already used Setup poster to turn on the computer and locate this guide. To locate resources that provide product details, how-to information, and more, use this table.

Resource Contents

Setup poster

Windows Basics guide

Help and Support

To access Help and Support, from the Start screen, type help, and then from the Search window, select Help and Support. For U.S. support, go to

http://www.hp.com/go/contactHP. For worldwide

support, go to

wwcontact_us.html.

Worldwide support

To get support in your language, go to

http://welcome.hp.com/country/us/en/ wwcontact_us.html.

HP SmartFriend

To get more information on HP SmartFriend, go to

http://www.hpremoteservices.com.

Safety & Comfort Guide

To access this guide:

1. From the Start screen, type support, and then

select the HP Support Assistant app.

2. Select My computer, and then select User

guides.

– or –

Go to

http://welcome.hp.com/country/us/en/

http://www.hp.com/ergo.

Overview of computer setup and features

●

Overview of using Windows®

●

● A broad range of how-to information and troubleshooting tips

● Online chat with an HP technician

Email support

●

Support telephone numbers

●

● HP service center locations

Subscription service that provides specially trained HP

●

technicians 24/7 to diagnose and resolve your software, hardware, accessories, and network problems quickly.

● Proper workstation setup

Guidelines for posture and work habits that increase your

●

comfort and decrease your risk of injury

● Electrical and mechanical safety information

Regulatory, Safety and Environmental Notices

To access this guide:

1. From the Start screen, type support, and then

select the HP Support Assistant app.

Important regulatory notices, including proper battery disposal

●

information

More HP resources 3

Page 12

Resource Contents

Limited Warranty*

To access this guide:

1. From the Start screen, type support, and then

select the HP Support Assistant app.

2. Select My computer, and then select Warranty

and services.

– or –

http://www.hp.com/go/orderdocuments.

Go to

*You can find the expressly provided HP Limited Warranty applicable to your product located with the user guides on your computer and/or on the CD or DVD provided in the box. In some countries or regions, HP may provide a printed HP Limited Warranty in the box. For some countries or regions where the warranty is not provided in printed format, you may request a printed copy from

● North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, USA

Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy

●

Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

●

When you request a printed copy of your warranty, please include your product number, warranty period (found on your service label), name, and postal address.

IMPORTANT: Do NOT return your HP product to the addresses above. For U.S. support, go to

contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.

http://www.hp.com/go/orderdocuments or write to:

Specific warranty information about this computer

●

http://www.hp.com/go/

4 Chapter 1 Starting right

Page 13

2 Getting to know your computer

Finding your hardware and software information

Locating hardware

To find out what hardware is installed on your computer:

1. From the Start screen, type control panel, and then select Control Panel.

2. Select System and Security, select System, and then click Device Manager in the left column.

A list displays all the devices installed on your computer.

To find out information about system hardware components and the system BIOS version number, press fn+esc.

Locating software

To find out what software is installed on your computer:

Mode Steps

1. From the Start screen, right-click, and then click All apps.

– or –

From the Start screen, click the down arrow in the lower-left corner of the screen.

1. Swipe to the left on the TouchPad or the touch screen until the arrow appears, and then tap the arrow in

the lower-left corner of the Start screen.

Finding your hardware and software information 5

Page 14

Tablet edge components

Components Description

(1)

Power button ● When the computer is off, press the button to turn on

the tablet.

When the computer is on, press the button briefly to

●

initiate Sleep.

● When the computer is in the Sleep state, press the

button briefly to exit Sleep.

CAUTION: Pressing and holding down the power button

will result in the loss of unsaved information.

If the computer has stopped responding and Windows® shutdown procedures are ineffective, press and hold the power button down for at least 5 seconds to turn off the tablet.

To learn more about your power settings, see your power options.

Swipe from the right edge of the TouchPad or

touch screen to display the charms, tap Search, and then tap the search box. In the search box, type power, select Settings, and then select Power options.

– or –

From the Start screen, type power, select

(2) Alignment post connectors (2) Align and attach the tablet to the keyboard base.

6 Chapter 2 Getting to know your computer

Power and sleep settings, and then select Power and sleep from the list of applications.

Page 15

Components Description

(3) microSD memory card reader Supports micro SD cards.

To insert a card:

Remove the tablet from the keyboard base. Hold the card label-side up, with connectors facing the slot, insert the card into the slot, and then push in on the card until it is firmly seated.

To remove a card:

Press in on the card it until it pops out.

(4)

(5) Docking port/power connector Connects the tablet to the keyboard base and connects an

(6)

(7) Volume button Controls speaker volume on the tablet.

Audio-out (headphone)/Audio-in (microphone) combo jack

Power connector Connects an AC adapter.

Connects optional powered stereo speakers, headphones, earbuds, a headset, or a television audio cable. Also connects an optional headset microphone. This jack does not support optional microphone-only devices.

WARNING! To reduce the risk of personal injury, adjust

the volume before using headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices. To access this guide, from the Start screen, type support, select the

HP Support Assistant app.

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

NOTE: Be sure that the device cable has a 4-conductor

connector that supports both audio-out (headphone) and audio-in (microphone).

AC adapter.

To increase speaker volume, press the + edge of the

●

button.

To decrease speaker volume, press the – edge of the

●

button.

Tablet edge components 7

Page 16

Components Description

(8) Webcam (rear) Records video, captures still photographs, and allows

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country or region. To access this guide, from the Start screen, type support, and then select the HP Support Assistant app.

video conferences and online chat by means of streaming video.

Swipe from the right edge of the TouchPad or

touch screen to display the charms, tap Search, and then tap the search box. type camera, and then select Camera from the list of applications.

– or –

From the Start screen, type control panel,

and then select Camera from the list of applications.

8 Chapter 2 Getting to know your computer

Page 17

Display

Component Description

(1) WLAN antennas (2)* Send and receive wireless signals to communicate with

(2) Webcam (front) Records video, captures still photographs, and allows you

(3) Webcam light (front) On: The webcam is in use.

(4) Ambient light sensor Automatically adjusts the display brightness based on the

(5) Internal microphone Records sound.

(6) Speakers (2) Produce sound.

wireless local area networks (WLANs).

to video conference and chat online using streaming video.

Swipe from the right edge of the TouchPad or

touch screen to display the charms, tap Search, and then tap the search box. type control panel, and then select Camera from the list of applications.

– or –

From the Start screen, type control panel,

and then select Camera from the list of applications.

lighting conditions in your environment.

Display 9

Page 18

Component Description

(7)

Windows button Returns you to the Start screen from an open app or the

Windows desktop.

NOTE: Pressing the Windows key again will return you to

the previous screen.

10 Chapter 2 Getting to know your computer

Page 19

Keyboard base

Top

Component Description

(1) Alignment posts Align and attach the tablet to the keyboard base.

(2) Docking connector Connects the tablet to the keyboard base.

(3) Release latch Releases the tablet. To release the tablet, slide the release latch

to the left.

Keyboard base 11

Page 20

TouchPad

Component Description

(1) TouchPad zone Reads your finger gesture to move the pointer or activate

(2) Left TouchPad button Functions like the left button of an external mouse.

items on the screen.

(3) Right TouchPad button Functions like the right button on an external mouse.

12 Chapter 2 Getting to know your computer

Page 21

Lights

Component Description

(1) Caps lock light

(2)

Mute light ● Amber: Computer sound is off.

White: Caps lock is on.

●

Off: Caps lock is off.

●

Off: Computer sound is on.

●

Keyboard base 13

Page 22

Keys

Component Description

(1) esc key Displays system information when pressed in combination with the

(2) fn key Executes frequently used system functions when pressed in

(3)

(4) Action keys Execute frequently used system functions.

Windows key Returns you to the Start screen from an open app or the Windows

fn key (select models only).

combination with the b key or the esc key (select models only).

desktop.

NOTE: Pressing the Windows key again will return you to the

previous screen.

NOTE: Action keys do not display or function on the on-screen

keyboard of the tablet.

14 Chapter 2 Getting to know your computer

Page 23

Right side

Component Description

(1)

(2)

(3)

(4) AC adapter light ● On: The AC adapter is connected and the battery is charged.

(5)

Memory card reader Reads optional memory cards that store, manage, share, or

access information.

To insert a card:

Hold the card label-side up, with connectors facing the slot, insert the card into the slot, and then push in on the card until it is firmly seated.

To remove a card:

Press in on the card it until it pops out.

HDMI port Connects an optional video or audio device, such as a high-

USB 3.0 port Connects optional USB devices, such as a keyboard, mouse,

Power connector Connects an AC adapter.

definition television, any compatible digital or audio component, or a high-speed HDMI device.

external drive, printer, scanner or USB hub.

Off: The computer is using battery power.

●

Keyboard base 15

Page 24

Left side

Component Description

(1)

(2)

USB 2.0 port Connects optional USB devices, such as a keyboard, mouse,

Audio-out (headphone)/Audio-in (microphone) combo jack

external drive, printer, scanner or USB hub.

WARNING! To reduce the risk of personal injury, adjust the

volume before using headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices. To access this guide, from the Start screen, type support, select the HP Support Assistant app.

NOTE: When a device is connected to the jack, the computer

speakers are disabled.

NOTE: Be sure that the device cable has a 4-conductor

connector that supports both audio-out (headphone) and audioin (microphone).

16 Chapter 2 Getting to know your computer

Page 25

Releasing the tablet from the keyboard base

To release the tablet from the keyboard base, follow these steps:

1. Slide the release latch on the keyboard base to the left (1).

2. Lift and remove the tablet (2).

Changing your tablet's settings

You can change view and screen brightness.

Changing your tablet's view

Your tablet's orientation, or view, changes automatically from landscape to portrait view, or from portrait to landscape view.

To change the view of your tablet from landscape view to portrait view:

Hold the tablet horizontally, and then turn it 90 degrees to the right (in a clockwise direction).

▲

To change the view of your tablet from portrait view to landscape view:

Hold the tablet vertically, and then turn it 90 degrees to the left (in a counter-clockwise direction).

▲

Turning your tablet's autorotate lock on or off

Autorotate automatically changes the orientation of the tablet screen depending on which way you are holding the tablet. You can lock the screen orientation in place so that it does not automatically rotate.

Changing your tablet's settings 17

Page 26

To turn your tablet's autorotate lock on or off:

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, and then tap

Settings.

2. Tap the Screen icon at the bottom right. Tap the autorotate lock icon to lock your current tablet

screen in place and to prevent rotation. The icon displays a lock symbol when autorotate lock is active. To turn off the autorotate lock, tap the autorotate lock icon again.

Adjusting your tablet's screen brightness

To adjust the screen brightness:

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, and then tap

Settings.

2. Tap the Screen icon at the bottom right. A vertical slider displays that controls the screen

brightness.

NOTE: From the Windows desktop, you can also tap the Power Meter icon in the notification area

at the far right of the taskbar, tap Adjust screen brightness, and then move the slider next to Screen brightness at the bottom of the screen.

Locating system information

Important system information is located on the bottom edge of the tablet or on the keyboard base. You may need the information when travelling internationally or when you contact support:

Serial number

●

Product number

●

Warranty period

●

● Regulatory and wireless certification information

Using Windows, briefly press the fn+esc key combination (select models only) to display the System Information screen, which provides the product name and serial number of your computer, as well as information about the memory, processor, BIOS, and keyboard.

18 Chapter 2 Getting to know your computer

Page 27

3 Connecting to a network

Your computer can travel with you wherever you go. But even at home, you can explore the globe and access information from millions of websites using your computer and a wired or wireless network connection. This chapter will help you get connected to that world.

Connecting to a wireless network

Wireless technology transfers data across radio waves instead of wires. Your computer may be equipped with one or more of the following wireless devices:

Wireless local area network (WLAN) device—Connects the computer to wireless local area

●

networks (commonly referred to as Wi-Fi networks, wireless LANs, or WLANs) in corporate offices, your home, and public places such as airports, restaurants, coffee shops, hotels, and universities. In a WLAN, the mobile wireless device in your computer communicates with a wireless router or a wireless access point.

Bluetooth device (select models only)—Creates a personal area network (PAN) to connect to

●

other Bluetooth-enabled devices such as computers, phones, printers, headsets, speakers, and cameras. In a PAN, each device communicates directly with other devices, and devices must be relatively close together—typically within 10 meters (approximately 33 feet) of each other.

For more information about wireless technology, see the information and website links provided in Help and Support. From the Start screen, type help, and then select Help and Support.

Using the wireless controls

You can control the wireless devices in your computer using these features:

Wireless button, wireless switch, or wireless key (referred to in this chapter as the wireless

●

button) (select models only)

Operating system controls

●

Using the wireless button

The computer has a wireless button and one or more wireless devices, depending on the model. All of the wireless devices on your computer are enabled at the factory.

Because the wireless devices are enabled at the factory, you can use the wireless button to turn on or turn off the wireless devices simultaneously.

Using operating system controls

The Network and Sharing Center allows you to set up a connection or network, connect to a network, and diagnose and repair network problems.

To use operating system controls:

Connecting to a wireless network 19

Page 28

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap

Search, and then tap the search box.

2. Type control panel in the search box, and then select Control Panel.

3. Select Network and Internet, and then select Network and Sharing Center.

1. From the Start screen, type control panel, and then select Control Panel.

2. Select Network and Internet, and then select Network and Sharing Center.

For more information, from the Start screen, type help, and then select Help and Support.

Sharing data and drives and accessing software

When your computer is part of a network, you are not limited to using only the information that is stored in your computer. Network computers can exchange software and data with each other.

NOTE: When a disc like a DVD movie or game is copy-protected, it cannot be shared.

To share folders or content on the same network:

1. From the Windows desktop, open File Explorer.

2. From This PC, click a folder with content you want to share. Select Share from the navigation

bar at the top of the window, and then click Specific people.

3. Type a name in the File Sharing box, and then click Add.

4. Click Share and then follow the on-screen instructions.

To share drives on the same network:

1. From the Windows desktop, right-click the network status icon in the notification area, at the far

right of the taskbar.

2. Select Open Network and Sharing Center.

3. Under View your active networks, select an active network.

4. Select Change advanced sharing settings to set sharing options for privacy, network

discovery, file and printer sharing or other network options.

20 Chapter 3 Connecting to a network

Page 29

Using a WLAN

With a WLAN device, you can access a wireless local area network (WLAN), which is composed of other computers and accessories that are linked by a wireless router or a wireless access point.

NOTE: The terms wireless router and wireless access point are often used interchangeably.

● A large-scale WLAN, such as a corporate or public WLAN, typically uses wireless access points

that can accommodate a large number of computers and accessories and can separate critical network functions.

A home or small office WLAN typically uses a wireless router, which allows several wireless and

●

wired computers to share an Internet connection, a printer, and files without requiring additional pieces of hardware or software.

To use the WLAN device in your computer, you must connect to a WLAN infrastructure (provided through a service provider or a public or corporate network).

Using an Internet service provider

When you are setting up Internet access in your home, you must establish an account with an Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP. The ISP will help set up the modem, install a network cable to connect your wireless router to the modem, and test the Internet service.

NOTE: Your ISP will give you a user ID and a password to use for Internet access. Record this

information and store it in a safe place.

Setting up a WLAN

To set up a WLAN and connect to the Internet, you need the following equipment:

A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from

●

an Internet service provider

A wireless router (2) (purchased separately)

●

A wireless computer (3)

●

NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type

of modem you have.

The illustration below shows an example of a wireless network installation that is connected to the Internet.

As your network grows, additional wireless and wired computers can be connected to the network to access the Internet.

For help in setting up your WLAN, see the information provided by your router manufacturer or your ISP.

Connecting to a wireless network 21

Page 30

Configuring a wireless router

For help in setting up a WLAN, see the information provided by your router manufacturer or your ISP.

NOTE: It is recommended that you initially connect your new wireless computer to the router by

using the network cable provided with the router. When the computer successfully connects to the Internet, disconnect the cable, and access the Internet through your wireless network.

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always enable security features to protect your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and airports may not provide any security. If you are concerned about the security of your computer when connected to a hotspot, limit your network activities to email that is not confidential and basic Internet surfing.

Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected signals. Take the following precautions to protect your WLAN:

Use a firewall.

●

A firewall checks information and requests that are sent to your network, and discards any suspicious items. Firewalls are available in both software and hardware. Some networks use a combination of both types.

Use wireless encryption.

●

Wireless encryption uses security settings to encrypt and decrypt data that is transmitted over the network. For more information, from the Start screen, type help, and then select Help and

Support.

Connecting to a WLAN

To connect to the WLAN, follow these steps:

1. Be sure that the WLAN device is on.

2. From the Start screen, point to the far-right upper or lower corner of the screen to display the

charms.

3. Select Settings, and then click the network status icon.

4. Select your WLAN from the list.

5. Click Connect.

If the WLAN is a security-enabled WLAN, you are prompted to enter a security code. Type the code, and then click Sign in to complete the connection.

NOTE: If no WLANs are listed, you may be out of range of a wireless router or access point.

NOTE: If you do not see the WLAN you want to connect to, from the Windows desktop, right-

click the network status icon, and then select Open Network and Sharing Center. Click Set up a new connection or network. A list of options is revealed, allowing you to manually search for

and connect to a network or to create a new network connection.

6. Follow the on-screen instructions to complete the connection.

After the connection is made, place the mouse pointer over the network status icon in the notification area, at the far right of the taskbar, to verify the name and status of the connection.

22 Chapter 3 Connecting to a network

Page 31

NOTE: The functional range (how far your wireless signals travel) depends on WLAN

implementation, router manufacturer, and interference from other electronic devices or structural barriers such as walls and floors.

Using Bluetooth wireless devices (select models only)

A Bluetooth device provides short-range wireless communications that replace the physical cable connections that traditionally link electronic devices such as the following:

Computers (desktop, notebook, PDA)

●

Phones (cellular, cordless, smart phone)

●

Imaging devices (printer, camera)

●

Audio devices (headset, speakers)

●

Mouse

●

Bluetooth devices provide peer-to-peer capability that allows you to set up a PAN of Bluetooth devices. For information about configuring and using Bluetooth devices, see the Bluetooth software Help.

Connecting to a wireless network 23

Page 32

4 Enjoying entertainment features

Use your HP computer as an entertainment hub to socialize via the webcam, enjoy and manage your music, and download and watch movies. Or, to make your computer an even more powerful entertainment center, connect external devices like a monitor, projector, or TV, or speakers and headphones.

24 Chapter 4 Enjoying entertainment features

Page 33

Multimedia features

Here are some of the entertainment features on your computer.

Component Description

(1)

Audio-out (headphone)/Audio-in (microphone) combo jack

WARNING! To reduce the risk of personal injury,

adjust the volume before using headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices. To access this guide, from the Start screen, type support, and then select the

HP Support Assistant app.

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

NOTE: Be sure that the device cable has a 4-

conductor connector that supports both audio-out (headphone) and audio-in (microphone).

Multimedia features 25

Page 34

Component Description

(2) Volume button Controls speaker volume.

To increase speaker volume, press the + edge

●

of the button.

To decrease speaker volume, press the – edge

●

of the button.

(3) Webcam (rear) Records video, captures still photographs, allows you

to video conference and chat online using streaming video.

Swipe from the right edge of the TouchPad

or touch screen to display the charms, tap Search, and then tap the search box. type camera, and then select Camera from the list of applications.

– or –

From the Start screen, type camera, and

then select Camera from the list of applications.

26 Chapter 4 Enjoying entertainment features

Page 35

Component Description

(1) Webcam (front) Records video, captures still photographs, allows you

to video conference and chat online using streaming video.

Swipe from the right edge of the

TouchPad or touch screen to display the charms, tap Search, and then tap the search box. type camera, and then select Camera from the list of applications.

– or –

From the Start screen, type camera, and

then select Camera from the list of applications.

(2) Webcam light On: The webcam is in use.

(3) Ambient light sensor Automatically adjusts the display brightness based

(4) Internal microphone Records sound.

(5) Speakers (2) Produce sound.

(6)

(7)

(8)

USB 3.0 port Connects an optional USB device, such as a

HDMI port Connects an optional video or audio device, such as

Memory card reader Reads optional memory cards that store, manage,

on the lighting conditions in your environment.

keyboard, mouse, external drive, printer, scanner or USB hub.

a high-definition television, any compatible digital or audio component, or a high-speed HDMI device.

share, or access information.

To insert a card:

Hold the card label-side up, with connectors facing the slot, insert the card into the slot, and then push in on the card until it is firmly seated.

To remove a card:

Press in on the card it until it pops out.

Multimedia features 27

Page 36

Component Description

(9)

(10)

Audio-out (headphone)/Audio-in (microphone) combo jack

USB 2.0 port Connects an optional USB device, such as a

Using the webcams

Your computer has two integrated webcams, a powerful social networking tool that allows you to communicate up close with friends and colleagues, whether they are next door or on the other side of the world. With the webcams, you can stream video with your instant messaging software, capture and share video, and take photos.

WARNING! To reduce the risk of personal injury,

HP Support Assistant app.

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

NOTE: Be sure that the device cable has a 4-

conductor connector that supports both audio-out (headphone) and audio-in (microphone).

keyboard, mouse, external drive, printer, scanner or USB hub.

To start the webcams, follow these steps:

Mode Steps

For details about using the webcams, go to Help and Support. From the Start screen, type help, and then select Help and Support.

Using audio

On your computer, you can play music CDs (with an optional external optical drive), download and listen to music, stream audio content from the web (including radio), record audio, or mix audio and video to create multimedia. To enhance your listening enjoyment, attach external audio devices such as speakers or headphones.

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap Search, and

then tap the search box.

2. Type camera, and then select Camera from the list of applications.

1. From the Start screen, type camera, and then select Camera from the list of applications.

28 Chapter 4 Enjoying entertainment features

Page 37

Connecting speakers

You can attach wired speakers to your computer by connecting them to a USB port or to the audioout (headphone) jack on your computer or on a docking station.

To connect wireless speakers to your computer, follow the device manufacturer's instructions. To connect high-definition speakers to the computer, see speakers, lower the volume setting.

Connecting headphones and microphones

You can connect wired headphones or headsets to the audio-out (headphone)/audio-in (microphone) combo jack on your computer. Many headsets with integrated microphones are commercially available.

To connect wireless headphones to your computer, follow the device manufacturer's instructions.

WARNING! To reduce the risk of personal injury, lower the volume setting before putting on

headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices. To access this guide, from the Start screen, type support, and then select

the HP Support Assistant app.

Using Beats Audio

Beats Audio is an enhanced audio feature that provides a deep, controlled bass while maintaining a clear sound. You can experience Beats Audio through the computer's internal speakers, through external speakers connected to a USB port, or through Beats Audio headphones connected to the headphone jack.

Setting up HDMI audio. Before connecting

Accessing Beats Audio Control Panel

Use Beats Audio Control Panel to view and manually control audio and bass settings.

To open Beats Audio Control Panel, follow these steps:

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap Search,

and then tap the search box.

2. Type control panel, select Control Panel, select Hardware and Sound, and then select

Beats Audio Control Panel.

From the Start screen, type control panel, select Control Panel, select Hardware and Sound, and then select Beats Audio Control Panel.

Using audio 29

Page 38

Enabling and disabling Beats Audio

To enable or disable Beats Audio, follow these steps:

Mode Steps

1. Swipe from the right edge of the TouchPad or touch screen to display the charms, tap Search,

and then tap the search box.

2. Type control panel, select Control Panel, select Hardware and Sound, and then select

Beats Audio Control Panel.

3. Follow the on-screen instructions.

1. From the Start screen, type control panel, select Control Panel, select Hardware and

Sound, and then select Beats Audio Control Panel.

2. Follow the on-screen instructions.

Testing your audio features

To check the audio function on your computer, follow these steps:

1. From the Start screen, type control panel, and then select Control Panel.

2. Select Hardware and Sound, and then select Sound.

3. When the Sound window opens, select the Sounds tab. Under Program Events, select any

sound event, such as a beep or alarm, and then click Test.

You should hear sound through the speakers or through connected headphones.

To check the recording functions on your computer, follow these steps:

1. From the Start screen, type sound, and then select Sound Receiver.

2. Click Start Recording and speak into the microphone.

3. Save the file to your desktop.

4. Open a multimedia program and play the recording.

To confirm or change the audio settings on your computer:

1. From the Start screen, type control panel, and then select Control Panel.

2. Select Hardware and Sound, and then select Sound.

Using video

Your computer is a powerful video device that enables you to watch streaming video from your favorite websites and download video and movies to watch on your computer when you are not connected to a network.

To enhance your viewing enjoyment, use one of the video ports on the computer to connect an external monitor, projector, or TV. Most computers have a video graphics array (VGA) port, which connects analog video devices. Your computer has a high-definition multimedia interface (HDMI) port, which allows you to connect a high-definition monitor or TV.

IMPORTANT: Be sure that the external device is connected to the correct port on the computer,

using the correct cable. Check the device manufacturer's instructions.

30 Chapter 4 Enjoying entertainment features

Page 39

Connecting video devices using an HDMI cable

NOTE: To connect an HDMI device to your computer, you need an HDMI cable, sold separately.

To see the computer screen image on a high-definition TV or monitor, connect the high-definition device according to the following instructions.

1. Connect one end of the HDMI cable to the HDMI port on the computer.

2. Connect the other end of the cable to the high-definition TV or monitor.

3. Press f4 to alternate the computer screen image between 4 display states:

PC screen only: View the screen image on the computer only.

●

Duplicate: View the screen image simultaneously on both the computer and the external

●

device.

Extend: View the screen image extended across both the computer and the external

●

device.

Second screen only: View the screen image on the external device only.

●

Each time you press f4, the display state changes.

NOTE: For best results, especially if you choose the “Extend” option, adjust the screen

resolution of the external device, as follows. From the Start screen, type control panel, and then select Control Panel from the list of applications. Select Appearance and

Personalization. Under Display, select Adjust screen resolution.

Setting up HDMI audio

HDMI is the only video interface that supports high-definition video and audio. After you connect an HDMI TV to the computer, you can then turn on HDMI audio by following these steps:

1. From the Windows desktop, right-click the Speakers icon in the notification area, at the far right

of the taskbar, and then select Playback devices.

2. On the Playback tab, select the name of the digital output device.

3. Click Set Default, and then click OK.

Using video 31

Page 40

To return the audio stream to the computer speakers:

1. From the Windows desktop, right-click the Speakers icon in the notification area, at the far right

of the taskbar, and then click Playback devices.

2. On the Playback tab, click Speakers.

3. Click Set Default, and then click OK.

Discovering and connecting to Miracast-compatible wireless displays (select models only)

To discover and connect to Miracast-compatible wireless displays without leaving your current apps, follow the steps below.

Mode Steps

Swipe from the right edge of the Start screen to display the charms, tap Devices, tap Project, and then follow the on-screen instructions.

Point to the upper-right or lower-right corner of the Start screen to display the charms, click Devices, click Project, and then follow the on-screen instructions.

32 Chapter 4 Enjoying entertainment features

Page 41

5 Navigating the screen

You can navigate the computer screen in several ways:

Touch gestures

●

Keyboard and mouse

●

Touch gestures can be used on your computer TouchPad or on a touch screen.

NOTE: An external USB mouse (purchased separately) can be connected to one of the USB ports

on the computer.

Review the Windows Basics guide included with your computer. The guide provides information on common tasks using the TouchPad, touch screen, or the keyboard.

You computer has special action keys and hot key functions on the keyboard to perform routine tasks.

Using the TouchPad and gestures

The TouchPad allows you to navigate the computer screen and control the pointer by using simple finger movements. You can customize the touch gestures by changing settings, button configurations, click speed, and pointer options. You can also view demonstrations of TouchPad gestures.

From the Start screen, type control panel, select Control Panel, and then select Hardware and

Sound. Under Devices and Printers, select Mouse.

TIP: Use the left and right buttons on the TouchPad as you would use the corresponding buttons on

an external mouse.

NOTE: TouchPad gestures are not supported in all apps.

Using the TouchPad and gestures 33

Page 42

Tapping

To make an on-screen selection, use the tap function on the TouchPad.

●

Point to an item on the screen, and then tap one finger on the TouchPad zone to make a selection. Double-tap an item to open it.

34 Chapter 5 Navigating the screen

Page 43

Scrolling

Scrolling is useful for moving up, down, or sideways on a page or image.

●

Place two fingers slightly apart on the TouchPad zone and then drag them up, down, left, or right.

2-finger pinch/zoom

2-finger pinch/zoomallows you to zoom in or out on images or text.

Zoom out by placing two fingers apart on the TouchPad zone and then moving your fingers

●

together.

Zoom in by placing two fingers together on the TouchPad zone and then moving your fingers

●

apart.

Using the TouchPad and gestures 35

Page 44

2-finger click

2-finger click allows you to make menu selections for an object on the screen.

NOTE: Using 2-finger click is the same action as using right-click with the mouse.

Place two fingers on the TouchPad zone and press down to open the options menu for the

●

selected object.

36 Chapter 5 Navigating the screen

Page 45

Rotating (select models only)

Rotating allows you to turn items such as photos.

Point to an object, then anchor the forefinger of your left hand in the TouchPad zone. Using your

●

right hand, slide your forefinger in a sweeping motion from 12 o’clock to 3 o’clock. To reverse the rotation, move your forefinger from 3 o’clock to 12 o’clock.

NOTE: Rotate is intended for specific apps where you can manipulate an object or image. Rotate

may not be functional for all apps.

Using the TouchPad and gestures 37

Page 46

Flicking (select models only)

Flicking allows you to navigate through screens or quickly scroll through documents.

Place three fingers on the TouchPad zone and flick your fingers in a light, quick motion up,

●

down, left or right.

Edge swipes

Edge swipes allow you to perform tasks such as changing settings and finding or using apps.

Right-edge swipe

The right-edge swipe reveals the charms, which let you search, share, start apps, access devices, or change settings.

Swipe your finger gently from the right edge to reveal the charms.

●

38 Chapter 5 Navigating the screen

Page 47

Left-edge swipe

The left-edge swipe accesses your recently opened apps so that you can switch between them quickly.

Swipe your finger gently from the left edge of the TouchPad to switch between them quickly.

●

Top-edge swipe

The top-edge swipe displays app command options that allow you to customize apps.

IMPORTANT: When an app is open, the top-edge gesture varies depending on the app.

Gently swipe your gently from the top edge to reveal the app command options.

●

Using the TouchPad and gestures 39

Page 48

Using the touch screen

A touch screen computer allows you to control items on the screen directly with your fingers.

TIP: On touch screen computers, you can perform the gestures on the screen or on the TouchPad.

You can also perform on-screen actions with the keyboard and mouse.

Using touch screen gestures

One-finger slide

The one-finger slide is mostly used to pan or scroll through lists and pages, but you can use it for other interactions, too, such as moving an object.

To scroll across the screen, lightly slide one finger across the screen in the direction you want to

●

move.

NOTE: When many apps are revealed on the Start screen, you can slide your finger to move

the screen left or right.

To drag, press and hold an object, and then drag the object to move it.

●

40 Chapter 5 Navigating the screen

Page 49

Tapping

To make an on-screen selection, use the tap function.

● Use one finger to tap an object on the screen to make a selection. Double-tap an item to open it.

Using the touch screen 41

Page 50

Scrolling

Scrolling is useful for moving the pointer up, down, left, or right on a page or image.

● Place two fingers on the screen and then drag them in an up, down, left, or right motion.

2-finger pinch/zoom

2-finger pinch/zoom allows you to zoom out or in on images or text.

Zoom out by placing two fingers apart on the display and then move your fingers together.

●

Zoom in by placing two fingers together on the display and then move your fingers apart.

●

42 Chapter 5 Navigating the screen

Page 51

Rotating (select models only)

Rotating allows you to turn items such as photos.

● Anchor the forefinger of your left hand on the object you want to rotate. Using your right hand,

slide your forefinger around in a sweeping motion from 12 o’clock to 3 o’clock. To reverse the rotation, move your forefinger from 3 o’clock to 12 o’clock.

NOTE: Rotate is intended for specific apps where you can manipulate an object or image. Rotate

may not be functional for all apps.

Edge swipes

With edge swipes you can perform tasks such as changing settings and finding or using apps.

Right-edge swipe

The right-edge swipe reveals the charms, which let you search, share, start apps, access devices, or change settings.

Gently swipe your finger inward from the right edge of the display onto the screen to reveal the

●

charms.

Using the touch screen 43

Page 52

Left-edge swipe

The left-edge swipe reveals your open apps so that you can switch to them quickly.

Gently swipe your finger inward from the left edge of the display to switch between apps.

●

Without lifting your finger, swipe back toward the left edge to reveal all open apps.

Top-edge swipe and bottom-edge swipe

The top-edge swipe or bottom-edge swipe displays app command options that allow you to customize apps.

IMPORTANT: When an app is open, the top-edge gesture varies depending on the app.

Gently swipe your finger from the top edge or the bottom edge to reveal the app command

▲

options.

44 Chapter 5 Navigating the screen

Page 53

Using the on-screen keyboard

You may want to enter data into a data field. This may be required when you set up a wireless network configuration or a weather reporting location, or when you access user accounts on Internet sites. The computer has an on-screen keyboard that is displayed when you need to enter such information into data fields.

1. To display the keyboard, tap in the first data field. Tap the small keyboard icon that is displayed.

– or –

From the Windows desktop, tap the keyboard icon right side of the notification area.

2. Tap each character, continuing until you have spelled out the name or word that you are

entering into the data field.

NOTE: Action keys do not display or function on the on-screen keyboard.

NOTE: Suggested words may be displayed at the top of the keyboard. If an appropriate word

is displayed, tap it to select it.

3. Tap enter on the keyboard.

Using the keyboard and mouse

The keyboard and mouse allow you to type, select items, scroll and to perform the same functions as you do using touch gestures. The keyboard base also allows you to use action keys and hot keys to perform specific functions.

TIP: The Windows key on the keyboard base and tablet allow you to quickly return to the

Start screen from an open app or the Windows desktop. Pressing the Windows key again will return you to the previous screen.

NOTE: Depending on the country or region, your keyboard may have different keys and keyboard

functions than those discussed in this section.

Using the keys

Your computer has different ways to quickly access information or perform functions with certain keys and key combinations.

Using the action keys

An action key on the keyboard base performs an assigned function. The icon on each of the f1 through f4 and f6 through f12 keys illustrates the assigned function for that key.

IMPORTANT: Action keys only function on the keyboard base. They do not display or function on

the on-screen keyboard of the tablet.

To use an action key function, press and hold the key.

The keyboard base action key feature is enabled at the factory. You can disable this feature in Setup Utility (BIOS). See instructions on opening Setup Utility (BIOS), and then follow the instructions at the bottom of the screen.

Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI) for

Using the on-screen keyboard 45

Page 54

To activate the assigned function after you have disabled the action key feature on the keyboard base, you must press the fn key in combination with the appropriate action key.

CAUTION: Use extreme care when making changes in Setup Utility. Errors can prevent the

computer from operating properly.

Icon Key Description

f1 Opens Help and Support, which provides tutorials, information about the Windows

f2 Decreases the screen brightness incrementally as long as you hold down the key.

f3 Increases the screen brightness incrementally as long as you hold down the key.

f4 Switches the screen image between display devices connected to the system. For

f6 Plays the previous track of an audio CD or the previous section of a DVD or a BD.

f7 Begins, pauses, or resumes playback of an audio CD, a DVD, or a BD.

f8 Plays the next track of an audio CD or the next section of a DVD or a BD.

f9 Decreases speaker volume incrementally as long as you hold down the key.

operating system and your computer, answers to questions, and updates to your computer.

Help and Support also provides automated troubleshooting tools and access to support.

example, if a monitor is connected to the computer, pressing this key alternates the screen image from the computer display to the monitor display to a simultaneous display on both the computer and the monitor.

f10 Increases speaker volume incrementally as long as you hold down the key.

f11 Mutes or restores speaker sound.

f12 Turns the wireless feature on or off.

46 Chapter 5 Navigating the screen

NOTE: A wireless network must be set up before a wireless connection is possible.

Page 55

Using Windows shortcut keys

Windows provides shortcuts to perform actions quickly. Press the Windows key alone or in

combination with a specific key to perform a designated action.

For commonly used shortcuts, use the Windows Basics guide.

Using the hot keys

A hot key is a combination of the fn key and the esc key or the b key.

To use a hot key:

Briefly press the fn key, and then briefly press the second key of the combination.

▲

Using the keyboard and mouse 47

Page 56

6 Managing power

Your computer can operate on either battery power or external power. When the computer is running on battery power only and an AC power source is not available to charge the battery, it is important to monitor and conserve the battery charge. Your computer supports an optimal power plan to manage how your computer uses and conserves power so that computer performance is balanced with power conservation.

Initiating Sleep and Hibernation

Windows has two power-saving states, Sleep and Hibernation.

Sleep—The Sleep state is automatically initiated after a period of inactivity when running on

●

battery power or on external power. Your work is saved to memory, allowing you to resume your work very quickly. You can also initiate Sleep manually. For more information, see

initiating and exiting Sleep.

● Hibernation—The Hibernation state is automatically initiated if the battery reaches a critical level.

In the Hibernation state, your work is saved to a hibernation file and the computer powers down.

NOTE: You can manually initiate Hibernation. See Manually initiating and exiting Sleep and

Manually initiating and exiting Hibernation (select models only).

Manually

CAUTION: To reduce the risk of possible audio and video degradation, loss of audio or video

playback functionality, or loss of information, do not initiate Sleep while reading from or writing to a disc or an external media card.

NOTE: You cannot initiate any type of networking connection or perform any computer functions

while the computer is in the Sleep state or in Hibernation.

Manually initiating and exiting Sleep

You can initiate Sleep in any of the following ways:

● Close the display.

From the Start screen, point to the upper-right or lower-right corner of the screen to reveal the

●

charms. Click Settings, click the Power icon, and then click Sleep.

To exit Sleep:

● Briefly press the power button.

If the display is closed, and the tablet is connected to the keyboard base, open the display.

●

Press a key on the keyboard.

●

● Tap or swipe the TouchPad.

When the computer exits Sleep, the power lights turn on and the computer returns to the screen where you stopped working.

NOTE: If you have set a password to be required on wakeup, you must enter your Windows

password before the computer will return to the screen.

48 Chapter 6 Managing power

Page 57

Manually initiating and exiting Hibernation (select models only)

You can enable user-initiated Hibernation and change other power settings and timeouts using Power Options.

1. From the Start screen, type power options, and then select Power Options.

2. In the left pane, click Choose what the power button does.

3. Click Change Settings that are currently unavailable.

4. In the When I press the power button area, select Hibernate.

5. Click Save changes.

When the computer exits Hibernation, the power lights turn on and your work returns to the screen.

NOTE: If you have set a password to be required on wakeup, you must enter your Windows

password before your work will return to the screen.

Setting password protection on wakeup

To set the computer to prompt for a password when the computer exits Sleep or Hibernation, follow these steps:

1. From the Start screen, type power options, and then select Power Options.

2. In the left pane, click Require a password on wakeup.

3. Click Change Settings that are currently unavailable.

4. Click Require a password (recommended).

NOTE: If you need to create a user account password or change your current user account

password, click Create or change your user account password, and then follow the on- screen instructions. If you do not need to create or change a user account password, go to step

5. Click Save changes.

Using the power meter and power settings

The power meter is located on the Windows desktop. The power meter allows you to quickly access power settings and view the remaining battery charge.

To reveal the percentage of remaining battery charge and the current power plan, on the

●

Windows desktop, point over the power meter icon.

To use Power Options, click the power meter icon and select an item from the list. From the

●

Start screen, you can also type power options, and then select Power Options.

Different power meter icons indicate whether the computer is running on battery or external power. The icon also reveals a message if the battery has reached a low or critical battery level.

Running on battery power

When a charged battery is in the tablet and the tablet is not plugged into external power, the tablet runs on battery power. If the tablet has a charged battery installed and the AC adapter is disconnected from the tablet, the tablet automatically switches to battery power and the display brightness decreases to conserve battery life. The battery in the tablet slowly discharges when the

Using the power meter and power settings 49

Page 58

tablet is off and unplugged from external power. When the tablet is attached to the keyboard base, the system is powered by the keyboard base’s battery until the battery reaches a critical level in the keyboard base. At that time, the system switches to the tablet’s battery.

Computer battery life varies, depending on power management settings, programs running on the computer, display brightness, external devices connected to the tablet, and other factors.

NOTE: On select computer models, there is a secondary battery in the keyboard base. When the

tablet is attached to the keyboard base, the system is powered by the keyboard base's battery.

Factory-sealed battery

Your computer has one or two internal, rechargeable batteries that can be replaced only by an authorized service provider. To monitor the status of your battery, or if the battery is no longer holding a charge, run Battery Check in Help and Support. To access battery information, from the Start screen, type support, select the HP Support Assistant app, and then select Battery and performance. If Battery Check indicates that your battery should be replaced, contact support.

Do not attempt to remove or replace the factory-sealed batteries. Removing or replacing the battery could affect your warranty coverage. If the battery is no longer holding a charge, contact support.

When a battery has reached the end of its useful life, do not dispose of the battery in general household waste. Follow the local laws and regulations in your area for battery disposal.

Conserving battery power

Tips for conserving battery power and maximizing battery life:

Lower the brightness on the display.

●

Select the Power saver setting in Power Options.

●

Turn off wireless devices when you are not using them.

●

Disconnect unused external devices that are not plugged into an external power source, such as

●

an external hard drive connected to a USB port.

Stop, disable, or remove any external media cards that you are not using.

●

Before you leave your work, initiate Sleep or shut down the computer.

●

Identifying low battery levels

When a battery that is the sole power source for the computer reaches a low or critical battery level, the following behavior occurs:

The battery light (select models only) indicates a low or critical battery level.

●

– or –

The power meter icon on the Windows desktop shows a low or critical battery notification.

●

NOTE: For additional information about the power meter, see Using the power meter and

power settings.

The computer takes the following actions for a critical battery level:

If Hibernation is disabled and the computer is on or in the Sleep state, the computer remains

●

briefly in the Sleep state, and then shuts down and loses any unsaved information.

If Hibernation is enabled and the computer is on or in the Sleep state, the computer initiates

●

Hibernation.

50 Chapter 6 Managing power

Page 59

Resolving a low battery level

Resolving a low battery level when external power is available

Connect an AC adapter.

●

Connect the keyboard base to the tablet.

●

Connect an optional power adapter purchased as an accessory from HP.

●

Resolving a low battery level when no power source is available

Save your work and shut down the computer.

Resolving a low battery level when the computer cannot exit Hibernation

When the computer lacks sufficient power to exit Hibernation, follow these steps:

1. Connect the AC adapter to the computer and to external power.

2. Exit Hibernation by pressing the power button.

Running on external AC power

For information on connecting to AC power, refer to the Setup Instructions poster provided in the computer box.

The computer does not use battery power when the computer is connected to AC external power with an approved AC adapter or an optional docking/expansion device.

WARNING! To reduce potential safety issues, use only the AC adapter provided with the computer,

a replacement AC adapter provided by HP, or a compatible AC adapter purchased from HP.

Connect the computer to external AC power under any of the following conditions:

WARNING! Do not charge the computer battery while you are onboard aircraft.

When charging or calibrating a battery

●

When installing or modifying system software

●

When writing information to a disc (select models only)

●

● When running Disk Defragmenter on computers with internal hard drives

When performing a backup or recovery

●

When you connect the computer to external AC power:

The battery begins to charge.

●

The display brightness increases.

●

The power meter icon on the Windows desktop changes appearance.

●

When you disconnect external AC power, the following events occur:

The computer switches to battery power.

●

The display brightness automatically decreases to save battery life.

●

The power meter icon on the Windows desktop changes appearance.

●

Running on external AC power 51

Page 60

Troubleshooting power problems

Test the AC adapter if the computer exhibits any of the following symptoms when it is connected to AC power:

The computer does not turn on.

●

● The display does not turn on.

The power lights are off.

●

To test the AC adapter:

1. Shut down the computer.

2. Connect the AC adapter to the computer, and then plug it into an AC outlet.

3. Turn on the computer.

If the power lights turn on, the AC adapter is working properly.

●

● If the power lights remain off, check the connection from the AC adapter to the computer

and the connection from the AC adapter to the AC outlet to be sure that the connections are secure.

If the connections are secure and the power lights remain off, the AC adapter is not

●

functioning and should be replaced.

Contact support for information on obtaining a replacement AC power adapter.

52 Chapter 6 Managing power

Page 61

Shutting down (turning off) the computer

CAUTION: Unsaved information is lost when the computer shuts down. Be sure to save your work

before shutting down the computer.

The Shut down command closes all open programs, including the operating system, and then turns off the display and computer.

Shut down the computer under any of the following conditions:

When you are connecting an external hardware device that does not connect to a USB or video

●

port

When the computer will be unused and disconnected from external power for an extended

●

period

Although you can turn off the computer with the power button, the recommended procedure is to use the Windows Shut down command:

NOTE: If the computer is in the Sleep state or in Hibernation, you must first exit Sleep or

Hibernation before shutdown is possible by briefly pressing the power button.

1. Save your work and close all open programs.

2. From the Start screen, point to the upper-right or lower-right corner of the screen to reveal the

charms.

3. Click Settings, click the Power icon, and then click Shut down.

– or –

Right-click the Start button in the lower-left corner of the screen, select Shut down, and then select Shut down.

If the computer is unresponsive and you are unable to use the preceding shutdown procedures, try the following emergency procedures in the sequence provided:

To shut down the unresponsive tablet:

Press both the Windows key and the power button at the same time.

▲

To shut down the unresponsive tablet when it is connected to the keyboard base:

● Press ctrl+alt+delete, click the Power icon, and then select Shut Down.

Press and hold the power button for at least 5 seconds.

●

Disconnect the computer from external power.

●

Shutting down (turning off) the computer 53

Page 62

7 Maintaining your computer

It is important to perform regular maintenance to keep your computer in optimal condition. This chapter provides information about improving the performance of your computer by running tools such as Disk Defragmenter and Disk Cleanup. It also provides information about updating your programs and drivers, instructions for cleaning your computer, and tips for traveling with your computer.

Improving performance

Everyone wants a fast computer and you can drastically improve the performance of your computer by performing regular maintenance tasks with tools such as Disk Defragmenter and Disk Cleanup. Also, as your computer gets older, you might consider installing larger drives and adding more memory.

Handling drives

Observe these precautions when handling drives:

Before removing or installing a drive, shut down the computer. If you are unsure whether the

●

computer is off, in the Sleep state, or in Hibernation, turn the computer on, and then shut it down.

Before handling a drive, discharge static electricity by touching the unpainted metal surface of

●

the drive.

Do not touch the connector pins on a removable drive or on the computer.

●

Do not use excessive force when inserting a drive into a drive bay.

●

When the battery is the only source of power, be sure that the battery is sufficiently charged

●

before writing to media.

If a drive must be mailed, place the drive in a bubble-pack mailer or other suitable protective

●

packaging and label the package “FRAGILE.”

● Avoid exposing a drive to magnetic fields. Security devices with magnetic fields include airport

walk-through devices and security wands. Airport conveyer belts and similar security devices that check carry-on baggage use X-rays instead of magnetism and do not damage drives.

● Remove media from a drive before removing the drive from the drive bay, or traveling with,

shipping, or storing a drive.

Do not type on the keyboard or move the computer while an optical drive is writing to a disc. The

●

write process is sensitive to vibration.

Before you move a computer that is connected to an external hard drive, initiate Sleep and allow

●

the screen to clear, or properly disconnect the external hard drive.

Using Disk Defragmenter

As you use your computer over time, the files on the hard drive become fragmented. A fragmented drive means data on your drive is not contiguous (sequential) and, because of this, the hard drive works harder to locate files, thus slowing down the computer. Disk Defragmenter consolidates (or

54 Chapter 7 Maintaining your computer

Page 63

physically reorganizes) the fragmented files and folders on the hard drive so that the system can run more efficiently.

NOTE: It is not necessary to run Disk Defragmenter on solid-state drives.

After you start Disk Defragmenter, it works without supervision. However, depending on the size of your hard drive and the number of fragmented files, Disk Defragmenter may take more than an hour to complete.

HP recommends defragmenting your hard drive at least once a month. You may set Disk Defragmenter to run on a monthly schedule, but you can defragment your computer manually at any time.

To run Disk Defragmenter:

1. Connect the computer to AC power.

2. From the Start screen, type d, and then type disk.

3. Follow the on-screen instructions.

For additional information, access the Disk Defragmenter software Help.

Using Disk Cleanup

Disk Cleanup searches the hard drive for unnecessary files that you can safely delete to free up disk space and help the computer run more efficiently.

To run Disk Cleanup:

1. From the Start screen, type disk, and then select Uninstall apps to free up disk space.

2. Follow the on-screen instructions.

Updating programs and drivers

HP recommends that you update your programs and drivers on a regular basis to the latest versions. Updates can resolve issues and bring new features and options to your computer. Technology is always changing, and updating programs and drivers allows your computer to run the latest technology available. For example, older graphics components might not work well with the most recent gaming software. Without the latest driver, you would not be getting the most out of your equipment.

http://www.hp.com/support to download the latest versions of HP programs and drivers. In

Go to addition, register to receive automatic update notifications when they become available.

Cleaning your computer

Use the following products to safely clean your computer:

Dimethyl benzyl ammonium chloride 0.3 percent maximum concentration (For example:

●

Disposable wipes, which come in a variety of brands.)

Alcohol-free glass-cleaning fluid

●

Water with mild soap solution

●

Dry microfiber cleaning cloth or a chamois (static-free cloth without oil)

●

Static-free cloth wipes

●

Updating programs and drivers 55

Page 64

CAUTION: Avoid strong cleaning solvents that can permanently damage your computer. If you are

not sure that a cleaning product is safe for your computer, check the product contents to make sure that ingredients such as alcohol, acetone, ammonium chloride, methylene chloride, and hydrocarbons are not included in the product.

Fibrous materials, such as paper towels, can scratch the computer. Over time, dirt particles and cleaning agents can get trapped in the scratches.

Cleaning procedures

Follow the procedures in this section to safely clean your computer.

WARNING! To prevent electric shock or damage to components, do not attempt to clean your

computer while it is turned on.

Turn off the computer.

Disconnect AC power.

Disconnect all powered external devices.

CAUTION: To prevent damage to internal components, do not spray cleaning agents or liquids

directly on any computer surface. Liquids dripped on the surface can permanently damage internal components.

Cleaning the display (All-in-Ones or Notebooks)

Gently wipe the display using a soft, lint-free cloth moistened with an alcohol-free glass cleaner. Be sure that the display is dry before closing the display.

Cleaning the sides or cover

To clean the sides or cover, use a soft microfiber cloth or chamois moistened with one of the cleaning solutions listed previously or use an acceptable disposable wipe.

NOTE: When cleaning the cover of the computer, use a circular motion to aid in removing dirt and

debris.

Cleaning the TouchPad, keyboard, or mouse

WARNING! To reduce the risk of electric shock or damage to internal components, do not use a

vacuum cleaner attachment to clean the keyboard. A vacuum cleaner can deposit household debris on the keyboard surface.

CAUTION: To prevent damage to internal components, do not allow liquids to drip between the

keys.

To clean the TouchPad, keyboard, or mouse, use a soft microfiber cloth or a chamois moistened

●

with one of the cleaning solutions listed previously or use an acceptable disposable wipe.

To prevent keys from sticking and to remove dust, lint, and particles from the keyboard, use a

●

can of compressed air with a straw extension.

56 Chapter 7 Maintaining your computer

Page 65

Traveling with or shipping your computer

If you have to travel with or ship your computer, here are some tips to keep in mind to keep your equipment safe.

● Prepare the computer for traveling or shipping:

◦ Attach the tablet to the keyboard base to protect the tablet screen.

Back up your information to an external drive.

◦

Remove all discs and all external media cards, such as memory cards, from the computer.

◦

◦ Turn off and then disconnect all external devices.

Shut down the computer.

◦

Take along a backup of your information. Keep the backup separate from the computer.

●

When traveling by air, carry the computer as hand luggage; do not check it in with the rest of

●

your luggage.

CAUTION: Avoid exposing a drive to magnetic fields. Security devices with magnetic fields

include airport walk-through devices and security wands. Airport conveyer belts and similar security devices that check carry-on baggage use X-rays instead of magnetism and do not damage drives.

If you plan to use the computer during a flight, listen for the in-flight announcement that tells you

●

when you are allowed to use your computer. In-flight computer use is at the discretion of the airline.

If you are shipping the computer or a drive, use suitable protective packaging and label the

●

package “FRAGILE.”

If the computer has a wireless device installed, the use of these devices may be restricted in

●

some environments. Such restrictions may apply aboard aircraft, in hospitals, near explosives, and in hazardous locations. If you are uncertain of the policy that applies to the use of a particular device, ask for authorization to use your computer before you turn it on.

If you are traveling internationally, follow these suggestions:

●

Check the computer-related customs regulations for each country or region on your

◦

itinerary.

◦ Check the power cord and adapter requirements for each location in which you plan to use

the computer. Voltage, frequency, and plug configurations vary.

WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not

attempt to power the computer with a voltage converter kit sold for appliances.

Traveling with or shipping your computer 57

Page 66

8 Securing your computer and

information

Tablet security is essential for protecting the confidentiality, integrity, and availability of your information. Standard security solutions provided by the Windows operating system, HP applications, the non-Windows Setup Utility (BIOS), and other third-party software can help protect your computer from a variety of risks, such as viruses, worms, and other types of malicious code.

IMPORTANT: Some security features listed in this chapter may not be available on your computer.

Tablet risk Security feature

Unauthorized use of the computer Power-on password

Computer viruses Antivirus software

Unauthorized access to data Firewall software

Unauthorized access to Setup Utility (BIOS) settings and other system identification information

Ongoing or future threats to the computer Software updates

Unauthorized access to a Windows user account User password

Using passwords

A password is a group of characters that you choose to secure your computer information and to protect online transactions. Several types of passwords can be set. For example, when you set up your computer for the first time, you were asked to create a user password to secure your computer. Additional passwords can be set in Windows or in the HP Setup Utility (BIOS) that is preinstalled on your computer.

You may find it helpful to use the same password for a Setup Utility (BIOS) feature and for a Windows security feature.

Use the following tips for creating and saving passwords:

To reduce the risk of being locked out of the computer, record each password and store it in a

●

secure place away from the computer. Do not store passwords in a file on the computer.

When creating passwords, follow requirements set by the program.

●

Change your passwords at least every three months.

●

Administrator password

An ideal password is long and has letters, punctuation, symbols, and numbers.

●

● Before you send your computer for service, back up your files, delete confidential files, and then

remove all password settings.

For additional information about Windows passwords, such as screen-saver passwords, from the Start screen, type hp support assistant, and then select the HP Support Assistant app.

58 Chapter 8 Securing your computer and information

Page 67

Setting Windows passwords

Password Function

User password Protects access to a Windows user account.

Administrator password Protects administrator-level access to computer contents.

Setting Setup Utility (BIOS) passwords

Password Function

NOTE: This password cannot be used to access Setup

Utility (BIOS) contents.

Administrator password

Power-on password

Must be entered each time you access Setup Utility

●

(BIOS).

If you forget your administrator password, you cannot

●

access Setup Utility (BIOS).

NOTE: The administrator password can be used in place of

the power-on password.

NOTE: Your administrator password is not interchangeable

with an administrator password set in Windows, nor is it revealed as it is set, entered, changed, or deleted.

NOTE: If you enter the power-on password at the first

password check, you must enter the administrator password to access Setup Utility (BIOS).

Must be entered each time you turn on or restart the

●

computer.

If you forget your power-on password, you cannot turn

●

on or restart the computer.

NOTE: The administrator password can be used in place of

the power-on password.

NOTE: A power-on password is not revealed as it is set,

entered, changed, or deleted.

To set, change, or delete an administrator or power-on password in Setup Utility (BIOS):

1. To start Setup Utility (BIOS), turn on or restart the computer, quickly press esc, and then press f10.

2. Use the arrow keys to select Security, and then follow the on-screen instructions.

Your changes take effect when the computer restarts.

Using passwords 59

Page 68

Using Internet security software

When you use your computer to access email, a network, or the Internet, you potentially expose your computer to computer viruses, spyware, and other online threats. To help protect your computer, Internet security software that includes antivirus and firewall features may be preinstalled on your computer as a trial offer. To provide ongoing protection against newly discovered viruses and other security risks, security software must be kept up to date. It is strongly recommended that you upgrade the security software trial offer or purchase the software of your choice in order to fully protect your computer.

Using antivirus software

Computer viruses can disable programs, utilities, or the operating system, or cause them to function abnormally. Antivirus software can detect most viruses, destroy them, and in most cases, repair any damage they have caused.

To provide ongoing protection against newly discovered viruses, antivirus software must be kept up to date.

An antivirus program may be preinstalled on your computer. It is strongly recommended that you use the antivirus program of your choice in order to fully protect your computer.

For more information about computer viruses, from the Start screen, type hp support assistant, and then select the HP Support Assistant app.

Using firewall software

Firewalls are designed to prevent unauthorized access to a system or network. A firewall can be software you install on your computer and/or network, or it can be a combination of both hardware and software.

There are two types of firewalls to consider:

● Host-based firewalls—Software that protects only the computer it is installed on.

● Network-based firewalls—Installed between your DSL or cable modem and your home network

to protect all the computers on the network.

When a firewall is installed on a system, all data sent to and from the system is monitored and compared with a set of user-defined security criteria. Any data that does not meet those criteria is blocked.

Installing software updates

HP, Windows, and third-party software installed on your computer should be regularly updated to correct security problems and improve software performance. For more information, see

programs and drivers.

Updating

60 Chapter 8 Securing your computer and information

Page 69

Installing critical security updates

CAUTION: Microsoft sends out alerts regarding critical updates. To protect the computer from

security breaches and computer viruses, install all critical updates from Microsoft as soon as you receive an alert.

You can choose whether updates are installed automatically. To change the settings, from the Start screen, type c, and then select Control Panel. Select System and Security, select Windows Update, select Change settings, and then follow the on-screen instructions.

Installing HP and third-party software updates

HP recommends that you regularly update the software and drivers that were originally installed on your computer. To download the latest versions, go to you can also register to receive automatic update notifications when they become available.

If you have installed third-party software after you purchased your computer, regularly update the software. Software companies provide software updates to their products to correct security problems and improve functionality of the software.

http://www.hp.com/support. At this location,

Securing your wireless network

When you set up your wireless network, always enable security features. For more information, see

Protecting your WLAN.

Backing up your software applications and information

Regularly back up your software applications and information to protect them from being permanently lost or damaged through a virus attack or a software or hardware failure. For more information, see

Backing up, restoring, and recovering.

Securing your wireless network 61

Page 70

9 Using Setup Utility (BIOS) and HP PC

Hardware Diagnostics (UEFI)

Setup Utility, or Basic Input/Output System (BIOS), controls communication between all the input and output devices on the system (such as disk drives, display, keyboard, mouse, and printer). Setup Utility (BIOS) includes settings for the types of devices installed, the startup sequence of the computer, and the amount of system and extended memory.

Starting Setup Utility (BIOS)

To start Setup Utility (BIOS), turn on or restart the computer, quickly press esc, and then press f10.

Information about how to navigate in Setup Utility (BIOS) is located at the bottom of the screen.

NOTE: Use extreme care when making changes in Setup Utility (BIOS). Errors can prevent the

computer from operating properly.

Updating the BIOS

Updated versions of the BIOS may be available on the HP website.

Most BIOS updates on the HP website are packaged in compressed files called SoftPaqs.

Some download packages contain a file named Readme.txt, which contains information regarding installing and troubleshooting the file.

Determining the BIOS version

To determine whether available BIOS updates contain later BIOS versions than those currently installed on the computer, you need to know the version of the system BIOS currently installed.

BIOS version information (also known as ROM date and System BIOS) can be revealed by pressing

fn+esc (if you are already in Windows) or by using Setup Utility (BIOS).

1. Start Setup Utility (BIOS) (see

2. Use the arrow keys to select Main, and then make note of the BIOS version number.

3. To exit Setup Utility (BIOS) without saving your changes, use the arrow keys to select Exit,

select Exit Discarding Changes, and then press enter.

4. Click Yes.

Starting Setup Utility (BIOS).

62 Chapter 9 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI)

Page 71

Downloading a BIOS update

CAUTION: To reduce the risk of damage to the computer or an unsuccessful installation, download

and install a BIOS update only when the computer is connected to reliable external power using the AC adapter. Do not download or install a BIOS update while the computer is running on battery power, docked in an optional docking device, or connected to an optional power source. During the download and installation, follow these instructions:

Do not disconnect power from the computer by unplugging the power cord from the AC outlet.

Do not shut down the computer or initiate Sleep.

Do not insert, remove, connect, or disconnect any device, cable, or cord.

1. From the Start screen, type support, and then select the HP Support Assistant app.

2. Click Updates and tune-ups, and then click Check for HP updates now.

3. Follow the on-screen instructions.

4. At the download area, follow these steps:

a. Identify the most recent BIOS update and compare it to the BIOS version currently installed

on your computer. If the update is more recent than your BIOS, make a note of the date, name, or other identifier. You may need this information to locate the update later, after it has been downloaded to your hard drive.

b. Follow the on-screen instructions to download your selection to the hard drive.

If the update is more recent than your BIOS, make a note of the path to the location on your hard drive where the BIOS update is downloaded. You will need to access this path when you are ready to install the update.

NOTE: If you connect your computer to a network, consult the network administrator before

installing any software updates, especially system BIOS updates.

BIOS installation procedures vary. Follow any instructions that are revealed on the screen after the download is complete. If no instructions are revealed, follow these steps:

1. From the Start screen, type file, and then select File Explorer.

2. Click your hard drive designation. The hard drive designation is typically Local Disk (C:)..

3. Using the hard drive path you recorded earlier, open the folder on your hard drive that contains

the update.

4. Double-click the file that has an .exe extension (for example, filename.exe).

The BIOS installation begins.

5. Complete the installation by following the on-screen instructions.

NOTE: After a message on the screen reports a successful installation, you can delete the

downloaded file from your hard drive.

Updating the BIOS 63

Page 72

Using HP PC Hardware Diagnostics (UEFI)

HP PC Hardware Diagnostics is a Unified Extensible Firmware Interface (UEFI) that allows you to run diagnostic tests to determine whether the computer hardware is functioning properly. The tool runs outside the operating system so that it can isolate hardware failures from issues that are caused by the operating system or other software components.

To start HP PC Hardware Diagnostics UEFI:

1. Turn on or restart the computer, quickly press esc, and then press f2.

The BIOS searches three places for the diagnostics tools in the following order:

a. Connected USB drive

NOTE: To download the HP PC Hardware Diagnostics (UEFI) tool to a USB drive, see

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device.

b. Hard drive

c. BIOS

2. When the diagnostic tool opens, click the type of diagnostic test you want to run, and then follow

the on-screen instructions.

NOTE: If you need to stop a diagnostic test, press esc.

Downloading HP PC Hardware Diagnostics (UEFI) to a USB device

NOTE: Instructions for downloading HP PC Hardware Diagnostics (UEFI) are provided in English

only.

1. Go to http://www.hp.com.

2. Click Support & Drivers, and then click the Drivers & Downloads tab.

3. Enter the product name in the text box, and then click Go.

4. Select your computer model, and then select your operating system.

5. In the Diagnostic section, click HP UEFI Support Environment.

– or –

Click Download, and then select Run.

64 Chapter 9 Using Setup Utility (BIOS) and HP PC Hardware Diagnostics (UEFI)

Page 73

10 Backing up, restoring, and recovering

This chapter provides information about the following processes:

Creating recovery media and backups

●

Restoring and recovering your system

●

Creating recovery media and backups

1. After you successfully set up the computer, create HP Recovery media. This step creates a

backup of the HP Recovery partition on the computer. The backup can be used to reinstall the original operating system in cases where the hard drive is corrupted or has been replaced.

HP Recovery media you create will provide the following recovery options:

System Recovery—Reinstalls the original operating system and the programs that were

●

installed at the factory.

Minimized Image Recovery—Reinstalls the operating system and all hardware-related

●

drivers and software, but not other software applications.

● Factory Reset—Restores the computer to its original factory state by deleting all

information from the hard drive and re-creating the partitions. Then it reinstalls the operating system and the software that was installed at the factory.

See

Creating HP Recovery media.

2. Use the Windows tools to create system restore points and create backups of personal

information. For more information and steps, see Help and Support. From the Start screen, type

help, and then select Help and Support.

Creating HP Recovery media

HP Recovery Manager is a software program that offers a way to create recovery media after you successfully set up the computer. HP Recovery media can be used to perform system recovery if the hard drive becomes corrupted. System recovery reinstalls the original operating system and the software programs installed at the factory, and then configures the settings for the programs. HP Recovery media can also be used to customize the system or restore the factory image if you replace the hard drive.

Only one set of HP Recovery media can be created. Handle these recovery tools carefully, and

●

keep them in a safe place.

HP Recovery Manager examines the computer and determines the required storage capacity for

●

the blank USB flash drive or the number of blank DVD discs that will be required.

To create recovery discs, your computer must have an optical drive with DVD writer capability,

●

and you must use only high-quality blank DVD-R, DVD+R, DVD-R DL, or DVD+R DL discs. Do not use rewritable discs such as CD±RW, DVD±RW, double-layer DVD±RW, or BD-RE (rewritable Blu-ray) discs; they are not compatible with HP Recovery Manager software. Or instead you can use a high-quality blank USB flash drive.

If your computer does not include an integrated optical drive with DVD writer capability, but you

●

would like to create DVD recovery media, you can use an external optical drive (purchased

Creating recovery media and backups 65

Page 74

separately) to create recovery discs, or you can obtain recovery discs from support. See the Worldwide Telephone Numbers booklet included with the computer. You can also find contact information from the HP website. Go to region, and follow the on-screen instructions. If you use an external optical drive, it must be connected directly to a USB port on the computer; the drive cannot be connected to a USB port on an external device, such as a USB hub.

Be sure that the computer is connected to AC power before you begin creating the recovery

●

media.

The creation process can take up to an hour or more. Do not interrupt the creation process.

●

If necessary, you can exit the program before you have finished creating all of the recovery

●

DVDs. HP Recovery Manager will finish burning the current DVD. The next time you start HP Recovery Manager, you will be prompted to continue, and the remaining discs will be burned.

To create HP Recovery media:

IMPORTANT: For tablets, connect to the keyboard dock before beginning these steps (select

models only).

1. From the Start screen, type recovery, and then select HP Recovery Manager.

2. Select Recovery Media Creation, and then follow the on-screen instructions.

http://www.hp.com/support, select your country or

If you ever need to recover the system, see

Restore and recovery

There are several options for recovering your system. Choose the method that best matches your situation and level of expertise:

Windows offers several options for restoring from backup, refreshing the computer, and resetting

●

the computer to its original state. For more information and steps, see Help and Support. From the Start screen, type help, and then select Help and Support.

If you need to correct a problem with a preinstalled application or driver, use the Drivers and

●

Applications Reinstall option of HP Recovery Manager to reinstall the individual application or driver.

From the Start screen, type recovery, select HP Recovery Manager, select Drivers and Applications Reinstall, and then follow the on-screen instructions.

● If you want to reset your computer using a minimized image, you can choose the HP Minimized

Image Recovery option from the HP Recovery partition (select models only) or HP Recovery media. Minimized Image Recovery installs only drivers and hardware-enabling applications. Other applications included in the image continue to be available for installation through the Drivers and Applications Reinstall option in HP Recovery Manager.

For more information, see

● If you want to recover the computer's original factory partitioning and content, you can choose

the System Recovery option from the HP Recovery partition (select models only) or use the HP Recovery media that you have created. For more information, see

Recovery Manager. If you have not already created recovery media, see Creating HP Recovery media.

Recovering using HP Recovery Manager.

Recovering using HP Recovery Manager

Recovering using HP

66 Chapter 10 Backing up, restoring, and recovering

Page 75

If you have replaced the hard drive, you can use the Factory Reset option of HP Recovery

●

media to restore the factory image to the replacement drive. For more information, see

Recovering using HP Recovery Manager.

If you wish to remove the recovery partition to reclaim hard drive space, HP Recovery Manager

●

offers the Remove Recovery Partition option.

For more information, see

Removing the HP Recovery partition.

Recovering using HP Recovery Manager

HP Recovery Manager software allows you to recover the computer to its original factory state by using the HP Recovery media that you created or by using the HP Recovery partition (select models only). If you have not already created recovery media, see

Using HP Recovery media, you can choose from one of the following recovery options:

System Recovery—Reinstalls the original operating system, and then configures the settings for

●

the programs that were installed at the factory.

Minimized Image Recovery (select models only)—Reinstalls the operating system and all

●

hardware-related drivers and software, but not other software applications.

Factory Reset—Restores the computer to its original factory state by deleting all information

●

from the hard drive and re-creating the partitions. Then it reinstalls the operating system and the software that was installed at the factory.

The HP Recovery partition (select models only) allows System Recovery and Minimized Image Recovery.

What you need to know

HP Recovery Manager recovers only software that was installed at the factory. For software not

●

provided with this computer, you must either download the software from the manufacturer's website or reinstall the software from the media provided by the manufacturer.

Creating HP Recovery media.

Recovery through HP Recovery Manager should be used as a final attempt to correct computer

●

issues.

● HP Recovery media must be used if the computer hard drive fails. If you have not already

created recovery media, see

To use the Factory Reset option, you must use HP Recovery media. If you have not already

●

created recovery media, see

If the HP Recovery media does not work, you can obtain recovery media for your system from

●

support. See the Worldwide Telephone Numbers booklet included with the computer. You can also find contact information from the HP website. Go to country or region, and follow the on-screen instructions.

IMPORTANT: HP Recovery Manager does not automatically provide backups of your personal

data. Before beginning recovery, back up any personal data you wish to retain.

Creating HP Recovery media.

Using the HP Recovery partition (select models only)

The HP Recovery partition (select models only) allows you to perform a system recovery or minimized image recovery without the need for recovery discs or a recovery USB flash drive. This type of recovery can only be used if the hard drive is still working.

To start HP Recovery Manager from the HP Recovery partition:

http://www.hp.com/support, select your

Restore and recovery 67

Page 76

IMPORTANT: For tablets, connect to the keyboard dock before beginning these steps (select

models only).

1. Press f11 while the computer boots.

– or –

Press and hold f11 as you press the power button.

2. Choose your keyboard layout.

3. Select Troubleshoot from the boot options menu.

4. Select Recovery Manager, and then follow the on-screen instructions.

Using HP Recovery media to recover

You can use HP Recovery media to recover the original system. This method can be used if your system does not have an HP Recovery partition or if the hard drive is not working properly.

1. If possible, back up all personal files.

2. Insert the HP Recovery disc you created, and then restart the computer.

NOTE: If the computer does not automatically restart in HP Recovery Manager, change the

computer boot order. See

3. Follow the on-screen instructions.

Changing the computer boot order.

Changing the computer boot order

If computer does not restart in HP Recovery Manager, you can change the computer boot order, which is the order of devices listed in BIOS where the computer looks for startup information. You can change the selection for an optical drive or a USB flash drive.

To change the boot order:

1. Insert the HP Recovery media you created.

2. Restart the computer, quickly press esc, and then press f9 for boot options.

3. Select the optical drive or USB flash drive you want to boot from.

4. Follow the on-screen instructions.

Removing the HP Recovery partition

HP Recovery Manager software allows you to remove the HP Recovery partition to free up hard drive space.

IMPORTANT: After you remove the HP Recovery partition, you can no longer use the Windows

Refresh option, the Windows option to remove everything and reinstall Windows, or the HP Recovery Manager option. So before you remove the Recovery partition, create HP Recovery media; see

Creating HP Recovery media.

Follow these steps to remove the HP Recovery partition:

1. From the Start screen, type recovery, and then select HP Recovery Manager.

2. Select Remove Recovery Partition, and then follow the on-screen instructions.

68 Chapter 10 Backing up, restoring, and recovering

Page 77

11 Specifications

Input power

The power information in this section may be helpful if you plan to travel internationally with the computer.

The computer operates on DC power, which can be supplied by an AC or a DC power source. The AC power source must be rated at 100–240 V, 50–60 Hz. Although the computer can be powered from a standalone DC power source, it should be powered only with an AC adapter or a DC power source supplied and approved by HP for use with this computer.

The computer can operate on DC power within the following specifications. Operating voltage and current varies by platform.

Input power Rating

Operating voltage and current 19.5 V dc @ 2.31 A – 45 W

DC plug of external HP power supply

19.5 V dc @ 3.33 A – 65 W

NOTE: This product is designed for IT power systems in Norway with phase-to-phase voltage not

exceeding 240 V rms.

NOTE: The computer operating voltage and current can be found on the system regulatory label.

Operating environment

Factor Metric U.S.

Temperature

Operating 5°C to 35°C 41°F to 95°F

Nonoperating -20°C to 60°C -4°F to 140°F

Relative humidity (noncondensing)

Operating 10% to 90% 10% to 90%

Nonoperating 5% to 95% 5% to 95%

Maximum altitude (unpressurized)

Operating -15 m to 3,048 m -50 ft to 10,000 ft

Nonoperating -15 m to 12,192 m -50 ft to 40,000 ft

Input power 69

Page 78

12 Electrostatic Discharge

Electrostatic discharge is the release of static electricity when two objects come into contact—for example, the shock you receive when you walk across the carpet and touch a metal door knob.

A discharge of static electricity from fingers or other electrostatic conductors may damage electronic components. To prevent damage to the computer, damage to a drive, or loss of information, observe these precautions:

If removal or installation instructions direct you to unplug the computer, first be sure that it is

●

properly grounded, and then remove the cover.

Keep components in their electrostatic-safe containers until you are ready to install them.

●

Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.

●

Use nonmagnetic tools.

●

● Before handling components, discharge static electricity by touching an unpainted metal surface

of the component.

If you remove a component, place it in an electrostatic-safe container.

●

If you need more information about static electricity or assistance with component removal or installation, contact support.

70 Chapter 12 Electrostatic Discharge

Page 79

Index

Symbols/Numerics

2-finger click, TouchPad gesture

AC adapter light, identifying 15 AC adapter, testing 52 action keys

decrease screen brightness

46 Help and Support 46 identifying 14 increase screen brightness 46 next track or section 46 play, pause, resume 46 previous track or section 46 switch screen image 46 volume down 46 volume mute 46 volume up 46 wireless 46

airport security devices 54 alignment post connectors,

identifying 6 alignment posts, identifying 11 ambient light sensor, identifying

9, 27 antivirus software, using 60 audio functions, checking 30 audio-in (microphone) jacks 7,

16, 25, 28 audio-out (headphone) jacks 7,

16, 25, 28 autorotate lock 17

backing up, software and

information 61 backups 65 battery

conserving 50

low battery levels 50 battery information, finding 50 battery power 50 Beats Audio 29

Beats Audio Control Panel 29 Beats Audio hot key 30 BIOS

determining version 62 downloading an update 63

updating 62 Bluetooth device 19, 23 boot order, changing HP Recovery

Manager 68

buttons

left TouchPad 12

power 6

right TouchPad 12

Windows 10

caps lock light, identifying 13 caring for your computer 55 checking audio functions 30 cleaning your computer 55 components

display 9

left-side 16

right-side 15

top 11 configuring audio for HDMI 31 connecting to a WLAN 22 corporate WLAN connection 22 critical battery level 50 critical security updates,

installing 61

deleted files, restoring 66 Disk Cleanup software 55 Disk Defragmenter software 54 docking connector, identifying 11 docking port/power connector,

identifying 7

edge swipe gestures 43

left-edge swipe 44

right-edge swipe 43

top-edge swipe 44

electrostatic discharge 70 esc key, identifying 14 external AC power, using 51

firewall software 60 fn key, identifying 14, 47 fun things to do 2

HDMI port

connecting 31

identifying 15, 27 HDMI, configuring audio 31 headphones, connecting 29 Hibernation

exiting 49

initiated during critical battery

level 50

initiating 49 high-definition devices,

connecting 31

hot keys

description 47

using 47 HP and third-party software

updates, installing 61

HP PC Hardware Diagnostics

(UEFI), downloading 64

HP Recovery Manager

correcting boot problems 68

starting 67 HP Recovery media

creating 65

recovery 68 HP Recovery partition

recovery 67

removing 68

input power 69 internal microphone, identifying

internal microphones, identifying

Index 71

Page 80

Internet connection setup 21 Internet security software, using

jacks

audio-in (microphone) 7, 16,

25, 28

audio-out (headphone) 7, 16,

25, 28

keyboard hot keys, identifying 47 keys

action 14 esc 14 fn 14 Windows key 14

labels, serial number 18 left-edge swipe 44 lights

AC adapter 15 caps lock 13 mute 13 webcam 9, 27

low battery level 50

maintenance

Disk Cleanup 55 Disk Defragmenter 54

memory card reader, identifying

15, 27 microphone, connecting 29 microSD memory card reader,

identifying 7 minimized image

creating 67 recovery 67

mouse, external

setting preferences 33

mute light, identifying 13

on-screen keyboard 45 operating environment 69 original system recovery 67

passwords

Setup Utility (BIOS) 59

Windows 59 pinching touch screen gesture 42 pinching TouchPad gesture 35 ports

HDMI 15, 27, 31

USB 2.0 16, 28

USB 3.0 15, 27 power button, identifying 6 power connector, identifying 7,

15 power meter 49 power, battery 50 product name and number,

computer 18 public WLAN connection 22

recovery

discs 65, 68 HP Recovery Manager 67 media 68 options 65 starting 67 supported discs 65 system 67 USB flash drive 68 using HP Recovery media 66

recovery media

creating 65 creating using HP Recovery

Manager 66

recovery partition

removing 68 regulatory information 18 releasing the tablet 17 restore, Windows File History 66 right-edge swipe 43 rotating TouchPad gesture 37

scrolling TouchPad gesture 35 security, wireless 22 serial number 18 serial number, computer 18 setting password protection on

wakeup 49

setup of WLAN 21

Setup Utility (BIOS) passwords

59 Setup Utility (BIOS), using 62 shipping the computer 57 shutdown 53 Sleep

exiting 48 initiating 48

slots, memory card reader

memory card reader 15

software

Disk Cleanup 55

Disk Defragmenter 54 software updates, installing 60 speakers

connecting 29

identifying 9, 27 supported discs, recovery 65 system recovery 67 system restore point

creating 65

tablet release latch, identifying

11 tablet screen brightness 18 tablet settings, changing 17 tablet view, changing 17 tapping TouchPad gesture 34 testing an AC adapter 52 touch screen gestures 43, 44

edge swipe gestures 43, 44 one-finger slide 40 pinching 42 rotating 43 scrolling 42

tapping 41 touch screen, using 40 TouchPad

buttons 12

identifying 12 TouchPad gestures

2-finger click 36

pinching 35

rotating 37

scrolling 35

tapping 34

zooming 35 TouchPad zone, identifying 12 traveling with the computer 57

72 Index

Page 81

turning off the computer 53

unresponsive system 53 updating, programs and drivers

55 USB 2.0 port, identifying 16, 28 USB 3.0 port, identifying 15, 27 using external AC power 51 using passwords 58

video 30 volume button, identifying 7, 26

warranty period 18 webcam light, identifying 9, 27 webcam, identifying 8, 9, 26, 27,

28 Windows

File History 66 restoring files 66

system restore point 65 Windows button, identifying 10 Windows key, identifying 14 Windows passwords 59 Windows shortcut keys 47 Wireless Assistant software 19 wireless button 19 wireless certification information

wireless controls

button 19

operating system 19

Wireless Assistant software

wireless network (WLAN)

connecting 22

corporate WLAN connection

22 equipment needed 21 functional range 23 public WLAN connection 22 security 22 using 21

wireless network, securing 61 WLAN antennas, identifying 9 WLAN device 21

zooming touch screen gesture 42 zooming TouchPad gesture 35

Index 73
