HP OBXT1500 Service Manual
HP Notebook PC
Reference Guide
Notice
This manual and any examples contained herein are provided “as is” and are subject to
change without notice. Hewlett-Packard Company makes no warranty of any kind with
regard to this manual, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard Co. shall not be
liable for any errors or for incidental or consequential damages in connection with the
furnishing, performance, or use of this manual or the examples herein.
Consumer transactions in Australia and the United Kingdom: The above disclaimers and
limitations shall not apply to Consumer transactions in Australia and the United Kingdom
and shall not affect the statutory rights of Consumers.
© Copyright Hewlett-Packard Company 2000–2001. All rights reserved. Reproduction,
adaptation, or translation of this manual is prohibited without prior written permission of
Hewlett-Packard Company, except as allowed under the copyright laws.
The programs that control this product are copyrighted and all rights are reserved.
Reproduction, adaptation, or translation of those programs without prior written
permission of Hewlett-Packard Co. is also prohibited.
Portions of the programs that control this product may also be copyrighted by Microsoft
Corporation, SystemSoft Corp., Insyde Software Corporation, S3 Graphics Incorporated,
and Adobe Systems Incorporated. See the individual programs for additional copyright
notices.
This product incorporates copyright protection technology that is protected by method
claims of certain U.S. patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation and is intended for home and
other limited viewing uses only unless otherwise authorized by Macrovision Corporation.
Reverse engineering or disassembly is prohibited.
Microsoft®, MS-DOS®, and Windows® are U.S. registered trademarks of Microsoft
Corporation. Pentium® and the Intel Inside logo are U.S. registered trademarks and
Celeron™ and SpeedStep™ are U.S. trademarks of Intel Corporation. Adobe® and
Acrobat® are trademarks of Adobe Systems Incorporated.
Hewlett-Packard Company
HP Notebook Customer Care
1000 NE Circle Blvd., MS 425E
Corvallis, OR 97330
2 Reference Guide
CAUTION
Important Safety Information
To reduce the risk of fire, use only No. 26 AWG or larger telecommunications line
cord to connect a modem to the telephone wall jack.
When using your computer with a telephone connection, always follow basic safety
precautions to reduce the risk of fire, electric shock, and injury to persons:
• Do not use this product with a telephone connection near water (for example, near a
bathtub, sink, swimming pool, or in a wet basement).
• Avoid using a telephone connection (other than a cordless type) during an electrical
storm. There may be a remote risk of electric shock from lighting.
• Do not use a telephone connection of any type to report a gas leak while in the
vicinity of the leak.
• Use only the power cord and batteries indicated in this manual. Do not dispose of
batteries in a fire. They may explode. Check with local codes for possible special
disposal instructions.
HP Software Product License Agreement
Your HP product contains software programs. CAREFULLY READ THIS LICENSE
AGREEMENT BEFORE PROCEEDING TO OPERATE THIS EQUIPMENT. RIGHTS
IN THE SOFTWARE ARE OFFERED ONLY ON THE CONDITION THAT THE
CUSTOMER AGREES TO ALL TERMS AND CONDITIONS OF THE LICENSE
AGREEMENT. PROCEEDING TO OPERATE THE EQUIPMENT INDICATES
YOUR ACCEPTANCE OF THESE TERMS AND CONDITIONS. IF YOU DO NOT
AGREE WITH THE TERMS OF THE LICENSE AGREEMENT, YOU MUST NOW
EITHER REMOVE THE SOFTWARE FROM YOUR HARD DISK DRIVE AND
DESTROY THE MASTER DISKETTES, OR RETURN THE COMPLETE HP
PRODUCT AND SOFTWARE FOR A FULL REFUND. PROCEEDING WITH
CONFIGURATION SIGNIFIES YOUR ACCEPTANCE OF THE LICENSE TERMS.
UNLESS OTHERWISE STATED BELOW, THIS HP SOFTWARE LICENSE
AGREEMENT SHALL GOVERN THE USE OF ALL SOFTWARE THAT IS
PROVIDED TO YOU AS PART OF THE HP PRODUCT AND SHALL SUPERSEDE
ANY OTHER SOFTWARE WARRANTY STATEMENT THAT MAY BE INCLUDED
IN THIS HP PRODUCT OR MAY BE FOUND ONLINE.
Operating system and software applications by Microsoft are licensed to you under the
Microsoft License Agreement contained in the Microsoft documentation or displayed on
your screen when Microsoft Software Products are launched.
Reference Guide 3
For a PC supplied with a Microsoft operating system: When you start the PC and accept
the Microsoft End-user License Agreement (“EULA”), your license rights are valid only
if a Certificate of Authenticity (“COA”) label corresponding to your Microsoft operating
system is provided with your PC. The COA label can usually be found on the bottom of
the computer. If the COA label does not correspond to your Microsoft operating system
or is missing, contact your HP reseller for details.
Other non-HP Software and Operating Systems are covered by the appropriate vendor
license. The following License Terms govern the use of the HP software:
USE. Customer may use the software on any one HP product. Customer may not network
the software or otherwise use it on more than one HP product. Customer may not reverse
assemble or decompile the software unless authorized by law.
COPIES AND ADAPTATIONS. Customer may make copies or adaptations of the
software a) for archival purposes or (b) when copying or adaptation is an essential step in
the use of the software with an HP product so long as the copies and adaptations are used
in no other manner.
OWNERSHIP. Customer agrees that he/she does not have any title or ownership of the
software, other than ownership of the physical media. Customer acknowledges and
agrees that the software is copyrighted and protected under the copyright laws. Customer
acknowledges and agrees that the software may have been developed by a third party
software supplier named in the copyright notices included with the software, who shall be
authorized to hold the Customer responsible for any copyright infringement or violation
of this Agreement.
PRODUCT RECOVERY CD-ROM. If your HP product was shipped with a product
recovery CD-ROM or DVD: (i) The product recovery CD-ROM or DVD and/or support
utility software may only be used for restoring the hard disk of the HP product with
which the product recovery CD-ROM or DVD was originally provided. (ii) The use of
any operating system software by Microsoft contained in any such product recovery CDROM or DVD shall be governed by the Microsoft License Agreement.
TRANSFER OF RIGHTS IN SOFTWARE. Customer may transfer rights in the software
to a third party only as part of the transfer of all rights and only if Customer obtains the
prior agreement of the third party to be bound by the terms of this License Agreement.
Upon such a transfer, Customer agrees that his/her rights in the software are terminated
and that he/she will either destroy his/her copies and adaptations or deliver them to the
third party.
SUBLICENSING AND DISTRIBUTION. Customer may not lease, sublicense the
software or distribute copies or adaptations of the software to the public in physical
media or by telecommunication without the prior written consent of Hewlett-Packard.
TERMINATION. Hewlett-Packard may terminate this software license for failure to
comply with any of these terms provided Hewlett-Packard has requested Customer to
cure the failure and Customer has failed to do so within thirty (30) days of such notice.
UPDATES AND UPGRADES. Customer agrees that the software does not include
updates and upgrades which may be available from Hewlett-Packard under a separate
support agreement.
4 Reference Guide
EXPORT CLAUSE. Customer agrees not to export or re-export the software or any copy
or adaptation in violation of the U.S. Export Administration regulations or other
applicable regulation.
U.S. GOVERNMENT RESTRICTED RIGHTS. Use, duplication, or disclosure is subject
to HP standard commercial license terms and for non-DOD Departments and Agencies of
the U.S. Government, the restrictions set forth in FAR 52.227-19(c)(1-2) (June 1987)
Hewlett-Packard Company, 3000 Hanover Street, Palo Alto, CA 94304 U.S.A. Copyright
(c) 2000 Hewlett-Packard Company. All Rights Reserved. Customer further agrees that
Software is delivered and licensed as “Commercial computer software” as defined in
DFARS 252-227-7014 (June 1995) or as a “commercial item” as defined in FAR
2.101(a), or as “Restricted computer software” as defined in FAR 52.227-19 (or any
equivalent agency regulation or contract clause), whichever is applicable. The Customer
agrees that it has only those rights provided for such Software by the applicable FAR or
DFARS clause or the HP standard software agreement for the product involved.
Support Policy for Support Pack of Operating Systems. HP provides end user support for
HP PCs that use Microsoft Operating Systems, including its latest service packs. This
support will be available within 30 days of the software being released.
Edition History
Edition 1 ........................................... October 2001
Edition 2 ............................................ March 2002
This manual is printed on recycled paper.
Reference Guide 5
Contents
Getting Started with Your HP Notebook .....................................................................11
Taking Inventory.........................................................................................................12
What’s in the box? ................................................................................................12
To buy accessories ................................................................................................13
To find more information...................................................................................... 13
Identifying Parts of the Notebook............................................................................... 14
Front view .............................................................................................................14
Back view.............................................................................................................. 15
Bottom view..........................................................................................................16
Status lights........................................................................................................... 17
Multimedia buttons and status panel (selected models)........................................ 19
Setting Up Your Notebook .........................................................................................20
Step 1: Install the battery.......................................................................................20
Step 2: Connect AC power....................................................................................22
Step 3: Connect a phone line.................................................................................23
Step 4: Turn on the notebook................................................................................24
Step 5: Set up Windows ........................................................................................24
Step 6: Register your notebook .............................................................................25
To connect to the Internet......................................................................................25
Basic Operation ..............................................................................................................27
Operating Your Notebook...........................................................................................28
To turn the notebook on and off............................................................................28
To reset the notebook............................................................................................29
To change the boot device.....................................................................................30
To use the touch pad .............................................................................................30
To use the Fn hot keys ..........................................................................................32
To use the One-Touch buttons ..............................................................................33
To use the Windows and Applications keys..........................................................34
To use the embedded keypad ................................................................................34
To use the Alt GR key...........................................................................................35
To adjust the display .............................................................................................35
To adjust the volume.............................................................................................36
To mute the notebook............................................................................................37
To optimize video performance ............................................................................37
Securing Your Notebook ............................................................................................38
To set up password protection...............................................................................38
To lock your computer.......................................................................................... 39
To attach a security cable......................................................................................39
To protect against viruses......................................................................................40
Working in Comfort with a Notebook PC.................................................................. 41
Taking Care of Your Notebook ..................................................................................43
To protect your hard disk drive............................................................................. 43
Reference Guide 7
To maintain your notebook ...................................................................................43
To safeguard your data.......................................................................................... 44
To extend the life of the display............................................................................ 44
To clean your notebook.........................................................................................44
Batteries and Power Management ................................................................................45
Managing Power Consumption...................................................................................46
How the notebook manages power automatically................................................. 46
To manage power manually.................................................................................. 48
Using Battery Power...................................................................................................49
To check battery status.......................................................................................... 49
To respond to a low-battery warning ....................................................................50
To recharge the battery..........................................................................................50
To replace the battery............................................................................................50
To get the most from your batteries ......................................................................51
To maximize processor speed ...............................................................................52
Modem and Network Connections................................................................................ 53
Using the Modem........................................................................................................54
To connect the modem.......................................................................................... 54
To connect to the Internet......................................................................................56
To disconnect from the Internet ............................................................................56
To dial in to a network ..........................................................................................57
To change your modem settings............................................................................57
To send and receive e-mail....................................................................................58
To send and receive faxes .....................................................................................59
Connecting to a LAN..................................................................................................60
To connect to a LAN............................................................................................. 60
Making Wireless Network Connections (selected models) ........................................61
To prepare for wireless LAN connections.............................................................61
To turn wireless LAN communication on and off.................................................62
Making Wireless Bluetooth Connections (selected models).......................................64
To turn Bluetooth communication on and off.......................................................64
To prepare for Bluetooth connections...................................................................65
To work with Bluetooth devices ...........................................................................65
Add-On Devices ..............................................................................................................67
Using Plug-In Modules...............................................................................................68
To replace a plug-in module..................................................................................68
To insert or remove a CD or DVD........................................................................ 70
To play audio CDs ................................................................................................72
To use the status panel (selected models)..............................................................73
To play DVD movies ............................................................................................74
To create or copy CDs...........................................................................................75
Connecting PC Cards.................................................................................................. 76
To insert or remove a PC Card.............................................................................. 76
8 Reference Guide
Connecting SD Cards and MMC Cards...................................................................... 78
To insert or remove an SD Card or MMC Card.................................................... 78
Connecting External Devices......................................................................................80
To identify connectors for external devices ..........................................................80
To connect a printer or other parallel device.........................................................82
To connect an external keyboard or mouse...........................................................82
To connect a USB device......................................................................................82
To connect a USB floppy disk drive..................................................................... 83
To connect an audio device................................................................................... 83
To use an external monitor.................................................................................... 84
To use a TV set as a monitor................................................................................. 85
To connect an infrared device (selected models).................................................. 87
To use the port replicator ......................................................................................88
To connect an IEEE 1394 device ..........................................................................89
Installing Additional RAM .........................................................................................90
To install a RAM expansion module.....................................................................90
To remove a RAM expansion module ..................................................................91
To replace the system RAM module.....................................................................92
Replacing the Hard Disk Drive................................................................................... 95
To replace the hard disk drive............................................................................... 95
To replace the hard disk drive holder.................................................................... 96
To prepare a new hard disk drive.......................................................................... 96
Troubleshooting and Maintenance................................................................................97
Troubleshooting Techniques.......................................................................................98
Getting Assistance for Your Notebook....................................................................... 99
To get help from HP Instant Support ....................................................................99
Audio problems..................................................................................................... 99
CD and DVD problems.......................................................................................100
Display problems ................................................................................................101
Floppy disk drive problems................................................................................. 103
Hard disk drive problems.................................................................................... 103
Heat problems .....................................................................................................104
Infrared Problems................................................................................................ 104
Keyboard and pointing device problems.............................................................104
LAN problems.....................................................................................................106
Memory problems ...............................................................................................106
Modem problems ................................................................................................107
One-Touch button problems................................................................................110
Parallel and USB problems .................................................................................111
PC card (PCMCIA) problems .............................................................................112
Performance problems ........................................................................................113
Power and battery problems................................................................................114
Printing problems................................................................................................ 115
Startup Problems................................................................................................. 116
Standby and resume problems.............................................................................117
Wireless Problems............................................................................................... 117
Reference Guide 9
Testing the Hardware................................................................................................ 119
To run the e–Diagtools diagnostic test................................................................119
Configuring the Notebook ........................................................................................121
To run the BIOS configuration utility................................................................. 121
Reinstalling and Updating Software ......................................................................... 124
To recover the factory installation of your hard disk ..........................................124
To replace damaged Recovery CDs or DVDs .....................................................125
To update the notebook BIOS............................................................................. 126
To update Windows drivers ................................................................................126
HP Support and Service............................................................................................... 127
Getting Assistance for Your Notebook..................................................................... 128
To get help from the web ....................................................................................128
To contact HP for support or service...................................................................129
To receive repair service ..................................................................................... 131
To prepare your notebook for shipment..............................................................132
Hewlett-Packard Limited Warranty Statement .........................................................133
Reference Information .................................................................................................135
Hardware Specifications........................................................................................... 136
Modem Reference Information................................................................................. 139
Modem Reference (Ambit) .................................................................................139
Safety Information ....................................................................................................144
Power cords......................................................................................................... 144
Ergonomics .........................................................................................................145
Battery safety ......................................................................................................145
Laser safety .........................................................................................................146
LED safety ..........................................................................................................146
Exposure to radio frequency radiation ................................................................147
Regulatory Information.............................................................................................148
U.S.A...................................................................................................................148
Canada.................................................................................................................149
European Union ..................................................................................................149
International ........................................................................................................151
Index .............................................................................................................................. 153
10 Reference Guide
Getting Started with Your HP Notebook
Reference Guide 11
Getting Started with Your HP Notebook
Taking Inventory
Taking Inventory
Congratulations! Your HP notebook computer sets a new standard in personal computing.
Although compact and easy to carry, your notebook is made with the quality and
attention to detail that are the hallmark of Hewlett-Packard.
Your notebook has several features that make it convenient to use:
• The power button provides convenient options for starting and stopping the notebook.
• The notebook includes a variety of connectors—USB, parallel, TV out, and IEEE
1394—that enable you to use it with a wide range of printers, drives, audio
equipment, and other external devices.
In addition, most connectors are on or near the back of the notebook, keeping cables
away from your working area.
• Selected models feature convenient dedicated volume controls and a mute button
(with indicator) that lets you cut off all sound quickly when needed.
This manual shows how to set up and operate your notebook, as well as what to do if you
run into trouble.
What’s in the box?
Your notebook is shipped with these items:
• Battery (installed).
• Plug-in drive module: CD, DVD, CD-RW, or DVD/CD-RW combo.
• Weight-saving module for the notebook’s drive module bay, to reduce travel weight.
• AC adapter and power cord.
• Quick Start sheet.
• Startup Guide.
• Recovery CDs or DVDs, for restoring Windows and all software included with your
notebook.
• Microsoft Windows manual.
• Phone cord.
• USB-serial adapter.
In addition, your notebook includes a variety of preinstalled software. (The exact
software installed depends on your particular notebook model.)
12 Reference Guide
Getting Started with Your HP Notebook
Taking Inventory
To buy accessories
You can buy accessories for your notebook online. For the latest accessories and options,
visit the HP Notebook web site at www.hp.com/notebooks.
HP currently offers a wide variety of accessories, such as the following:
• Port replicator.
• External USB floppy disk drive.
• AC adapters.
• 8-cell LiIon enhanced battery.
• Additional RAM.
• Ethernet, modem, LAN, and wireless LAN cards.
To find more information
The following table lists other sources of information about your notebook and related
products.
Source Description and Location
Startup Guide
Online Reference
Guide
Online HP Notes
Microsoft Windows
manual
HP Notebook Web
Site
HP Business
Support Web Site
This printed manual introduces your HP notebook computer, and contains setup
instructions, basic operation guidelines, troubleshooting information, and warranty
information.
The Reference Guide is shipped on the notebook’s hard drive, and provides a
complete source for operating and maintaining the notebook. Click Start, All
Programs, HP Library, HP Notebook Reference Guide, or look on the Recovery CD
or DVD in \hp\Library.
For late-breaking information available after the manuals were completed, see the
HP Notes—click Start, All Programs, HP Library, HP Notes, or look on the Recovery
CD or DVD in \hp\Library.
This is shipped with your notebook and contains information about using the version
of Microsoft Windows shipped with your notebook.
www.hp.com/notebooks.
www.europe.hp.com/notebooks (European mirror).
www.hp.com/go/bizsupport.
Reference Guide 13
Getting Started with Your HP Notebook
Identifying Parts of the Notebook
Identifying Parts of the Notebook
Front view
1. One-Touch buttons (programmable).
2. Power button.
3. Keyboard status lights: Caps Lock, Num Lock,
CD or DVD drive activity.
4. Touch pad/scroll pad on-off button (with on-off
indicators on either side).
5. Left and right click buttons.
6. Touch pad.
7. Scroll pad.
14 Reference Guide
8. Volume controls (selected models).
9. Mute button and indicator light (selected models).
10. Removable DVD or DVD/CD-RW drive.
11. CD/DVD eject button.
12. Speaker (one on each side).
13. Latch.
14. Built-in microphone.
Getting Started with Your HP Notebook
Identifying Parts of the Notebook
Back view
15. AC adapter jack.
16. Parallel port (LPT1) (colored burgundy). Use this
port for a parallel printer or other parallel device.
17. External monitor (VGA) port (colored blue).
18. Universal serial bus (USB) ports (2).
19. S-video (TV out) port (colored yellow).
20. Reset switch.
21. Kensington lock slot (security connector).
22. LAN port and indicators.
23. Modem.
Reference Guide 15
24. IEEE 1394 connector.
25. SD-MMC Card slot.
26. PC Card slot (Type II).
27. PC Card eject button.
28. Hard disk drive.
29. Wireless on-off button and indicator light (selected
models).
30. External microphone jack (colored pink).
31. Headphones jack (colored green).
Getting Started with Your HP Notebook
Identifying Parts of the Notebook
Bottom view
32. Infrared port (selected models).
33. Battery.
34. CD/DVD drive latch.
35. RAM cover.
36. Battery latch.
37. Docking port.
38. Mini-PCI cover (no user-replaceable parts inside).
39. Hard disk drive retaining screws.
16 Reference Guide
Getting Started with Your HP Notebook
Identifying Parts of the Notebook
Status lights
The main status lights report power and battery status and drive activity.
1. Hard disk drive activity.
• On: the notebook is accessing the hard disk drive.
2. Power mode.
• Green: the notebook is on (even if the display is off).
• Amber: the notebook is on standby.
• Off: the notebook is off or in hibernation.
3. Battery charge status.
• Green: the AC adapter is connected and the battery is fully charged.
• Amber: the AC adapter is connected and the battery is charging.
• Red: the AC adapter is connected and the battery has a fault.
• Off: the AC adapter is not connected or the battery is missing.
Reference Guide 17
Getting Started with Your HP Notebook
Identifying Parts of the Notebook
The keyboard status lights, located above the keyboard, indicate the states of keyboard
locks and the CD player.
1. Caps Lock. Caps Lock is active.
2. Num Lock. Num Lock is active. (The Keypad Lock must also be on to use the
embedded keypad.)
3. CD drive activity. The CD drive is active.
18 Reference Guide
Getting Started with Your HP Notebook
Identifying Parts of the Notebook
Multimedia buttons and status panel (selected models)
1. MP3 player launch button.
2. Previous track.
3. Next track.
4. Status panel button.
5. Status panel.
6. Play/Pause.
7. Stop.
8. Multimedia power switch and indicator light—turns the CD player on and off. Works
only when the notebook is off, on standby, or in hibernation.
Reference Guide 19
Getting Started with Your HP Notebook
Setting Up Your Notebook
Setting Up Your Notebook
WARNING
WARNING
Improper use of keyboards and other input devices has been associated with
ergonomic injury. For information about reducing your risk, see “Working in
Comfort” in the online HP Library, or visit our ergonomics web site,
www.hp.com/ergo. For a summary about working with a notebook computer, see
“Working in Comfort with a Notebook PC” on page 41.
If you are using your notebook as your primary computer, or using it for extended
periods, you should use it with a full-size keyboard, monitor, and mouse. This can
reduce the risk of ergonomic injury. See “Working in Comfort” in the online HP
Library.
When you set up your notebook for the first time, you’ll need to install and charge the
battery, connect the AC adapter and a phone line, turn on the notebook, run the Windows
setup program, and register the notebook.
Step 1: Install the battery
Do not mutilate or puncture batteries. Do not dispose of batteries in fire, or they
can burst or explode, releasing hazardous chemicals. Rechargeable batteries must
be recycled or disposed of properly.
Your notebook is shipped with the battery installed. If the battery has been removed,
install it as follows.
20 Reference Guide
Getting Started with Your HP Notebook
Setting Up Your Notebook
• Insert the front end of the battery into the battery compartment on the bottom of the
notebook, then press the back end in until the battery clicks into place.
To remove the battery
• Slide the battery’s release latch, then lift the battery out of its compartment.
Reference Guide 21
Getting Started with Your HP Notebook
Setting Up Your Notebook
Step 2: Connect AC power
CAUTION
Use only the HP AC adapter included with your notebook (or other approved 75watt adapter). Do not use a 60-watt adapter, such as HP F1454A or F1781A. Using
any other AC adapter could damage the notebook and may void your warranty—
see "Hewlett-Packard Limited Warranty Statement" on page 133.
• Plug in the AC adapter (its LED lights), then connect it to the AC adapter jack on the
back of the notebook. The notebook’s battery then starts charging.
While the battery is charging, you can continue with step 3.
22 Reference Guide
Getting Started with Your HP Notebook
Setting Up Your Notebook
Step 3: Connect a phone line
If your notebook does not include a built-in modem, you can skip this step. Also, if you
prefer, you can instead connect to a PC Card modem or an external modem.
1. Make sure the telephone line is an analog line. You must not use a digital line. (Many
office and some home lines are digital.)
2. Plug the telephone cord into the notebook’s modem jack, or the PC Card or external
modem. Make sure the cord clicks into place.
3. Plug the other end of the cord into a telephone jack. If the plug on the phone cord
doesn’t fit the jack, you may need to use an adapter.
For details about using the modem, see “Using the Modem” on page 54.
Reference Guide 23
Getting Started with Your HP Notebook
Setting Up Your Notebook
Step 4: Turn on the notebook
• Press the power button above the keyboard. The notebook then boots up, and
Windows starts automatically.
Note
Hint
Note
Your notebook comes with a factory-installed DVD, DVD/CD-RW, or similar drive.
Before you turn on your notebook for the first time, make sure this drive is in place.
This ensures that the system properly identifies the hardware already installed and loads
the appropriate software.
If your notebook does not turn on when operating on battery power, the battery may be
out of power. Plug in the AC adapter and press the power button again. Leave the AC
adapter plugged in for at least an hour.
Step 5: Set up Windows
Your notebook has Microsoft Windows XP preinstalled on its hard disk drive. The first
time you turn on your notebook, the Windows Setup program runs automatically so you
can customize your setup.
1. Follow the Setup program’s instructions as they appear on the screen.
2. If your notebook has a modem, check the modem’s country or region settings: click
Start, Control Panel, Printers and Other Hardware, Phone and Modem Options. On
the Dialing Rules tab, verify the settings for your location, or create a new location.
If you need the Windows XP Product ID code, you will find it on the bottom of the
notebook.
24 Reference Guide
Getting Started with Your HP Notebook
Setting Up Your Notebook
Step 6: Register your notebook
Be sure to register your notebook. Registering is free and fast, and ensures you will
receive quicker, more personalized support. The information you provide during
registration allows us to provide you with better products and services.
Registering your notebook does the following:
• Records your ownership of the notebook with Hewlett-Packard and provides access to
service, support, and information.
• Records your ownership of the Windows XP operating system with Microsoft.
You can register while setting up Windows, or later in any of three ways: by modem, by
phone, or by fax.
By modem
If you decide not to register while setting up Windows, or if your notebook does not have
a built-in modem, you can register after you set up a PC card modem or an external
modem—or you can register by phone or fax.
By phone
You can register by calling your HP Customer Care Center. See “To contact HP for
support or service” on page 129 for the phone number.
By fax
If you have a printer connected to your notebook, you can print a registration form and
fax it to HP. Double-click the HP Notebook Registration icon on the desktop, and print
the registration form. You will find the fax number on the form.
To connect to the Internet
You can use the built-in modem, LAN port, or wireless LAN (if available on your
notebook), to connect to the Internet. For details, see “Using the Modem” on page 54,
“Connecting to a LAN” on page 60, or “Making Wireless Network Connections” on
page 61.
Reference Guide 25
Basic Operation
Reference Guide 27
Basic Operation
Operating Your Notebook
Operating Your Notebook
You can start and stop your notebook using its power button. However, at certain times
you may want to use other methods to start or stop the notebook—depending on power
considerations, types of active connections, and start-up time.
Note
Power mode To enter this mode To turn on again
On
Power mode status light is green.
Standby
Maintains current session in RAM.
Turns off the display and other components.
Saves significant power.
Restarts quickly.
Restores network connections.
Power mode status light is amber.
Hibernation
Saves current session to disk, then turns off.
Saves maximum power.
Restores network connections.
Power mode status light is off.
Turn off
Turns off without saving current session.
Saves maximum power.
At startup, resets everything, and starts a new
session.
Power mode status light is off.
This manual describes your notebook in its original factory configuration, with all
settings at their default values.
To turn the notebook on and off
Press the power button.
Click Start, Turn Off
Computer,
Stand By
–or–
press the power button
–or–
allow timeout.
Click Start, Turn Off
Computer, then press and
hold Shift and click
Hibernate
–or–
allow timeout.
Click Start, Turn Off
Computer, Turn Off
–or–
press and hold the power
button for four seconds (only
if the Start menu procedure
doesn’t work).
Press the power button to
quickly resume your
session.
Press the power button to
resume your session.
Press the power button to
start with a new session.
You can customize the way these power modes work, and the ways you can put the
notebook into them. See “Managing Power Consumption” on page 46.
28 Reference Guide
Basic Operation
Operating Your Notebook
To reset the notebook
Occasionally, you may find that Windows or the notebook has stopped responding, and
will not let you turn the notebook off. If this happens, try the following in the order listed.
• If possible, shut down Windows: press Ctrl+Alt+Del, then click Shut Down, Turn
Off.
–or, if this fails–
• Press and hold the power button for about four seconds, until the display turns off.
Press the power button again to restart.
–or, if this fails–
• Use a pen or straightened paper clip to press the reset switch on the back of the
notebook, then press the power button to restart.
Reference Guide 29
Basic Operation
Operating Your Notebook
To change the boot device
The notebook normally boots from its internal hard disk. You can also boot the notebook
from an external USB floppy disk drive (optional accessory), the CD/DVD drive, or a
local area network (LAN).
1. Click Start, Turn Off Computer, Restart.
2. When the HP logo appears, press Esc to display the Boot menu.
3. Use the arrow keys to select the boot device, and press Enter.
If you want to boot from a specific device whenever it is present, change the boot order
using the BIOS configuration utility—see “To run the BIOS configuration utility” on
page 121.
To use the touch pad
Your notebook includes a built-in touch pad, scroll pad, and click buttons.
1. Left click button—works like the left button on a standard mouse.
2. Right click button—works like the right button on a standard mouse.
3. Touch pad—pressure-sensitive pointing and clicking device.
4. Pad Lock button—turns the touch pad and scroll pad on and off.
5. Scroll pad—scrolls the contents of a window.
6. Pad Lock indicators (one on each side)—these light while the touch pad and scroll
pad are enabled.
30 Reference Guide
