MP4 Digital Signage Player 4200
Quick Reference Guide
19 pgs568.97 Kb0
Table of contents
Loading...

HP MP4 Digital Signage Player 4200, MP9 Digital Signage Player 9000 Quick Reference Guide

Download
HP Digital Signage Player MP4 and MP9 Microsoft® Windows Embedded Standard 7
Quick Reference Guide
© Copyright 2014 Hewlett-Packard Development Company, L.P.
Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
First Edition: March 2014
Document Part Number: 722929-002
About this guide
This document uses the following styles to distinguish elements of command line text:
Style Definition
<variable>
[optional parameters]
“literal value”
Variables or placeholders are enclosed in angle brackets and italicized. For example, replace <pathname> with the appropriate path, such as C:\Windows\System. When typing the actual value for the variable, omit the brackets.
Optional parameters are enclosed in square brackets. When specifying the parameters, omit the brackets.
Command line text that appears inside quotation marks should be typed exactly as shown, including the quotation marks.
iii
iv About this guide
Table of contents
1 Introduction ....................................................................................................................................................... 1
Finding more information ...................................................................................................................... 1
Finding image updates and add-ons .................................................................................................... 1
Finding utilities in the Windows Control Panel ..................................................................................... 1
2 Getting started .................................................................................................................................................. 2
Write filters ........................................................................................................................................... 2
Enhanced Write Filter .......................................................................................................... 2
Using the Enhanced Write Filter command line utility ......................................... 2
Using the Enhanced Write Filter GUI .................................................................. 3
Using the Enhanced Write Filter status utility ...................................................... 3
File-Based Write Filter ......................................................................................................... 4
Using the File-Based Write Filter command line utility ........................................ 4
Using the File-Based Write Filter GUI ................................................................. 4
Using the File-Based Write Filter status utility ..................................................... 4
Local drives .......................................................................................................................................... 5
Configuring logon settings .................................................................................................................... 6
Configuring the system date and time settings .................................................................................... 6
3 Software ............................................................................................................................................................ 7
Microsoft Remote Desktop Protocol ..................................................................................................... 7
4 Administration tools ........................................................................................................................................... 8
HP Digital Signage Player Imaging Utility ............................................................................................ 8
HP RAMDisk Manager ......................................................................................................................... 8
HP ThinState ........................................................................................................................................ 9
HP Velocity ........................................................................................................................................... 9
Microsoft System Center Configuration Manager ................................................................................ 9
5 Operating System Technical Information .......................................................................................................... 8
Windows Embedded 7 P SKU components ....................................................................................... 10
Codecs ............................................................................................................................................... 10
Write Filters ........................................................................................................................................ 11
Application Versions Included ............................................................................................................ 11
Windows Embedded Device Manager 2011 Client Service Pack, v 1.0.600.0 .................................. 12
Drivers ................................................................................................................................................ 12
v
Index ................................................................................................................................................................... 13
vi

1 Introduction

This guide is intended for administrators of For HP MP4, MP9 Digital Signage Player models that are based on the Windows assumed that you are using the latest WES 7E or WES 7P image provided by HP and that you will be logged on to WES as an administrator when making configurations or accessing administration utilities.
®
Embedded Standard (WES) 7E and WES 7P operating systems. It is

Finding more information

The information in this guide provides a basic overview of features specific to HP Digital Signage Players. See the following table to locate information not covered in this guide.
Resource Contents
Windows Help and Support
On the Windows desktop, click Start > Help and Support.
HP support website
http://www.hp.com/support
Microsoft support website
http://support.microsoft.com
A broad range of how-to information and troubleshooting tips about Windows operating system usage
Documentation for HP software not covered in detail in this guide
TIP: If your search results cannot locate the software you
are looking for, search for your Digital Signage Player model instead and see the Manuals page.
Documentation for Microsoft software not covered in detail in this guide

Finding image updates and add-ons

HP provides periodic updates and add-ons for digital signage player images. Check the HP support
http://www.hp.com/support for updates and add-ons that apply to your image version. Select
site at the country/region from the map, then select Drivers & Software. Type the digital signage player model in the field and click Search.

Finding utilities in the Windows Control Panel

To find many of the utilities listed in this guide, you need to view the Control Panel as large icons or small icons, not as categories. You can also configure the Control Panel item in the Start menu to display as a menu for quick access to all utilities.
Finding more information 1

2 Getting started

Write filters

●
Local drives
●
Configuring logon settings
●
Configuring the system date and time settings
●
Write filters
Write filters provide a secure environment and can extend the life of your Digital Signage Players by protecting it from unauthorized and excessive writes to the storage device. Write data is intercepted by the write filter and cached in the RAM drive, and as a result, lost after the next reboot. There are two different types of write filters available:
Enhanced Write Filter (EWF)—Protects the entire storage device from writes
●
File-Based Write Filter (FBWF)—Allows you to specify files or folders to be excluded from
●
interception by the write filter
Only one write filter can be selected and active at one time. To save permanent configurations to the storage device, the write filter must be temporarily disabled.
CAUTION: Ensure that the write filter is enabled after committing necessary configurations to the
thin client flash drive. During normal operation of the thin client, the write filter must be enabled. Also ensure that Page File is not enabled on thin clients with flash memory storage. Failure to follow these required actions can void the warranty of the flash storage device. In the event of damage to the flash storage device due to operation with a disabled write filter or enabled Page File, the damage will not be covered by HP warranty.

Enhanced Write Filter

Using the Enhanced Write Filter command line utility
The EWF command line utility enables you to issue a set of commands to the EWF driver, report the status of each protected volume overlay, and report the format of the overall EWF configurations.
To use the EWF command line utility, follow these steps:
1. Select Start > Run.
2. Type CMD and click OK.
3. Enter ewfmgr c: <commands> at the prompt.
The following table describes the supported commands for the EWF utility.
Command Description
-all
Displays information about all protected volumes and performs a command, such as disable, enable, and commit, on each volume, if specified.
-commit
2 Chapter 2 Getting started
Commits all current cached data to the specified volume after the next reboot.
Command Description
-disable
-enable
-commitanddisable
Disables the write filter on the specified volume after the next reboot.
Enables the write filter on the specified volume after the next reboot.
Commits all current cached data and disables the write filter on the specified volume after the next reboot.
Using the Enhanced Write Filter GUI
To access the EWF GUI, follow these steps:
Click Start > Control Panel > HP Write Filter Configuration.
▲
The EWF interface includes the following buttons:
Enable/Disable EWF—Enables or disables the EWF on the specified volume.
●
Overlay Configuration—Displays the overlay information and is a combination of the information
●
supplied when executing ewfmgr.exe c: -Description and ewfmgr.exe c: -Gauge from the command line.
Clear Boot Command—Clears any boot commands that were entered via the command line.
●
Commit Data to Volume—Commits all current cached data to the specified volume after the next
●
reboot.
Using the Enhanced Write Filter status utility
The EWF status utility creates an icon in the notification area of the taskbar that shows the status of the filter. You can right-click the icon to display and execute the available options.
The EWF status icon displays the following states:
Red lock—EWF is disabled.
●
Green lock—EWF is enabled.
●
Yellow lock—EWF state will change on next boot.
●
You can change the status of EWF by right-clicking the icon and selecting the desired EWF state.
If you use the command line to modify the EWF, right-click the icon to refresh the status icon display (click anywhere on the screen to close the context menu). The status icon display is refreshed automatically when you make modifications through the HP Write Filter Configuration utility.
NOTE: Because the ewfmgr.exe utility and the EWF status service execute separate code, status
changes by ewfmgr.exe are not automatically reflected by the EWF status icon.
Write filters 3

File-Based Write Filter

Using the File-Based Write Filter command line utility
The FBWF command line utility enables you to issue a set of commands to the FBWF driver, report the status of each protected overlay, and report the format of the overall FBWF configurations.
To use the FBWF command line utility, follow these steps:
1. Select Start > Run.
2. Type CMD and click OK.
3. Enter fbwfmgr c: <commands> at the prompt.
The following table describes the supported commands for the FBWF utility.
Command Description
/disable
/enable
/displayconfig
/overlaydetail
/addexclusion
/removeexclusion
/setthreshold
Using the File-Based Write Filter GUI
To access the FBWF GUI, follow these steps:
Click Start > Control Panel > HP Write Filter Configuration.
▲
The FBWF interface includes the following buttons:
Enable/Disable Write Filter—Enables/disables the FBWF so that data written to the protected
●
media is cached or not.
Disables the write filter on the next restart.
Enables the write filter on the next restart.
Displays all current configuration information for the write filter including filter state, protected volumes list, cache compression state, overlay cache threshold, cache pre­allocation status, and write-through paths.
Displays detail on the current overlay contents for all protected volumes including file and folder contents and memory used.
Adds a write through path to the exclusion list.
Removes a write through path from the exclusion list.
Sets the overlay threshold value.
Enable/Disable Cache Compression—Enables/disables cache compression.
●
Enable/Disable Cache Pre-allocation—Enables/disables cache pre-allocation.
●
Set Cache Threshold—Sets the amount of RAM in MB that the FBWF cache can use.
●
Using the File-Based Write Filter status utility
The FBWF status utility creates an icon in the notification area of the taskbar that shows the status of the FBWF. You can right-click the icon to display and execute the available options.
The FBWF status icon displays the following states:
4 Chapter 2 Getting started
Red lock—FBWF is disabled.
●
Green lock—FBWF is enabled.
●
Yellow lock—FBWF state will change on next boot.
●
You can change the status of FBWF by right-clicking the icon and selecting the desired FBWF state.
If you use the command line to modify the FBWF, right-click the icon to refresh the status icon display (click anywhere on the screen to close the context menu). The status icon display is refreshed automatically when you make modifications through the HP Write Filter Configuration utility.
NOTE: Because the fbwfmgr.exe utility and the FBWF status service execute separate code, status
changes made by fbwfmgr.exe are not automatically reflected by the FBWF status icon.

Local drives

IMPORTANT: The write filter must be disabled for any configurations to be made permanent. See Write filters on page 2 for more information.
The following local drives are configured on the Digital Signage Player by default:
Drive C (storage device)—This is where the operating system and software are installed. Writes
●
to this drive can be limited or restricted entirely by using a write filter.
CAUTION: HP recommends that you do not allow the available free space on the storage
device to drop below 10% of the flash size. If the available free space on the storage device drops below 15 MB, the Digital Signage Player can become unstable.
Drive Z (RAM drive)—This is a virtual drive that is created from the system's physical RAM. This
●
drive will look and behave like a standard fixed disk drive, but it is created at system startup and destroyed at system shutdown. Therefore, HP recommends that you do not store information or data on this virtual disk drive.
You can use the HP RAMDisk Manager utility to configure the size of Drive Z. For more information, see
HP RAMDisk Manager on page 8.
Local drives 5

Configuring logon settings

IMPORTANT: The write filter must be disabled for any configurations to be made permanent. See Write filters on page 2 for more information.
For a user account, the factory-default user name and password are both User.
●
For an administrator account, the factory-default user name and password are both
●
Administrator.
For security purposes, HP recommends that you change the passwords from their default
●
values. An administrator can change passwords by pressing Ctrl+Alt+Del and then clicking Change a password.
NOTE: You cannot change the password while logged on as a user.
Passwords are case sensitive.
●
Alternatively, the Digital Signage Player can be configured to log on to a specific user account automatically. To configure automatic logon:
1. Click Start > Control Panel > HP Logon Manager.
2. In the Windows Logon Configuration dialog box, check the Enable Autologon box, type the
account credentials and domain name, and then click OK.
The configured account will be logged on to automatically during system startup.
TIP: To log on as a different user or as an administrator when automatic logon is enabled, simply
log off the current account to return to the Windows logon screen.

Configuring the system date and time settings

IMPORTANT: The write filter must be disabled for any configurations to be made permanent. See Write filters on page 2 for more information.
You can use the Date and Time utility in the Control Panel to set the system date and time manually or to configure the system to synchronize the date and time with an Internet server periodically.
TIP: You can also access this utility by clicking the clock in the Windows notification area and then
clicking Change time and date settings or by right-clicking the clock and selecting Adjust date/time from the menu.
If you want to configure the system to synchronize the date and time with an Internet server, you will also need to enable the Windows Time service, which is disabled by default. To do this, follow these steps:
1. Click Start > Control Panel > Administrative Tools.
2. Double-click Services.
3. Double-click the Windows Time service to access its settings. You can start the service manually
and configure it start up automatically in the future.
6 Chapter 2 Getting started

3 Software

Microsoft Remote Desktop Protocol

Make Microsoft Remote Desktop Protocol (RDP) available on the network using Microsoft Terminal Services on a Windows server. Use the Remote Desktop Connection (RDC) utility to establish a connection to a Windows terminal server or to access remote applications using Microsoft RDP.
To open the RDC utility:
Click Start > All Programs > Accessories > Remote Desktop Connection.
▲
NOTE: If a Windows server is used, a Terminal Services Client Access Licenses (TSCAL) server
must also reside somewhere on the network. A Client Access License (CAL) permits a client to use the services provided by the Windows server. The server grants temporary licenses (on an individual device basis) that are good for 90 days. Beyond that, TSCALs must be purchased and installed on the TSCAL server. A client cannot make a connection without a temporary or permanent license.
Microsoft Remote Desktop Protocol 7

4 Administration tools

HP Digital Signage Player Imaging Utility

●

HP RAMDisk Manager

●
HP ThinState
●
HP Velocity
●
Microsoft System Center Configuration Manager
●
HP Digital Signage Player Imaging Utility
The HP Digital Signage Player includes a utility in each SoftPaq that contains an original factory image for an HP Digital Signage Player. Use this utility to restore the original factory image to the Digital Signage Player.
This utility allows you to choose one of the following options:
Create a bootable flash image on a storage device
●
Unbundle the image to a directory for use in a custom deployment scenario or PXE image
●
See the release notes included in the SoftPaq for instructions.
HP RAMDisk Manager
HP RAMDisk Manager allows you to configure the size of the RAM drive (Drive Z).
To open HP RAMDisk Manager:
Click Start > Control Panel > HP RAMDisk Manager.
▲
By default, the size of the RAM drive is set to the optimal setting of 128 MB. The maximum size that can be set is 768 MB. The minimum is 16 MB. Temporarily increase the size to install software that requires more than 128 MB.
8 Chapter 4 Administration tools

HP ThinState

HP ThinState can be used to capture an HP Digital Signage Player image that can then be deployed to another HP Digital Signage Player of identical model and hardware.
NOTE: HP ThinState now uses ibrpe.exe for imaging. Any storage devices previously created
containing ibr.exe can no longer be used.
To perform an HP ThinState capture:
1. On the Digital Signage Player you are capturing the image from, make sure the first boot device
in the BIOS is set to USB.
2. Disable the write filter.
3. Insert a storage device that is greater in size than the onboard storage device.
4. Click Start > Control Panel > HP ThinState Capture.
5. Follow the on-screen instructions.
6. The HP ThinState Capture tool opens a blue screen. Follow the on-screen instructions.
Use the storage device to deploy the captured image to another HP Digital Signage Player of the exact same model and hardware.
NOTE: With HP ThinState Capture, you might be able to capture the image from a larger flash and
deploy it to a smaller flash, depending on the size of the captured image.
To perform an HP ThinState deployment:
1. On the Digital Signage Player you are deploying the image to, make sure the first boot device in
the BIOS is set to USB.
2. Insert the storage device that contains the captured image, and then restart the computer.
3. Follow the on-screen instructions.
After you remove the storage device and cycle power to the system, the image will unbundle. Do not interrupt or cycle power to the unit during this process.

HP Velocity

HP Velocity is a quality of service (QoS) system that dramatically improves the user experience for real-time, networked applications by reducing packet loss on IP-based networks used to carry the application traffic. The HP Velocity client-side component is preinstalled on HP Digital Signage Players running WES 7 and works in conjunction with a server-side component.
TIP: For more information, go to http://www.hp.com/go/velocity and see the HP Velocity
documentation.

Microsoft System Center Configuration Manager

Microsoft System Center Configuration Manager (SCCM) helps maintain corporate compliance and control while enabling users to use the devices and applications they need. It provides key management capabilities for application delivery, desktop virtualization, device management, and security, which makes it possible to enable productivity amidst device proliferation.
TIP: For more information, see the white paper
Managing HP Thin Clients with SCCM 2012 SP1
HP ThinState 9
.

5 Operating System Technical Information

This section describes the components and settings included in the Windows® Embedded Standard 7 on the HP MP9 and MP4 Digital Signage Players.

Windows Embedded 7 P SKU components

●

Codecs

●
Write Filters
●
Application Versions Included
●
Windows Embedded Device Manager 2011 Client Service Pack, v 1.0.600.0
●
Drivers
●
Windows Embedded 7 P SKU components
Anti-Malware \ Defender
●
Tablet / Touch
●
Photo Viewer
●
●
●
●
●
●
●
Codecs
●
●
●
●
●
●
DirectAccess
Branchcache
Enterprise Search Scopes
Applocker
Remote Media Streaming
Additional accessories such as Snipping Tool, Sticky Notes, etc
Microsoft AC3 Encoder
Microsoft DTV-DVD Video Decoder (MPEG-2, H.264)
Microsoft DTV-DVD Audio Decoder (MPEG-2, AAC)
MPEG Layer-3 Audio Codecs (MP3)
MPEG-4 Decoders
Windows Media Video Codecs (VC-1)
10 Chapter 5 Operating System Technical Information

Write Filters

Both the Enhanced Write Filter and File Based Filter are available, but disabled by default.
QFE’s Installed
KB2425227 KB2511250 KB2563894 KB2621440 KB2660465
KB2446710 KB2511455 KB2564958 KB2631813 KB2660649
KB2475792 KB2515325 KB2567053 KB2632503 KB2665364
KB2476490 KB2518869 KB2567680 KB2633171 KB2667402
KB2478662 KB2526967 KB2570791 KB2633873 KB2675157
KB2479628 KB2530548 KB2570814 KB2633952 KB2676562
KB2479943 KB2533623 KB2570947 KB2637530 KB2677070
KB2482017 KB2534366 KB2572077 KB2639417 KB2679255
KB2485376 KB2536275 KB2573437 KB2640148 KB2685939
KB2492386 KB2536276 KB2573449 KB2641653 KB2686831
KB2496898 KB2539566 KB2584146 KB2644615 KB2688338
KB2497640 KB2539635 KB2585542 KB2645895 KB2690533
KB2502285 KB2541014 KB2585853 KB2647516 KB2695962
KB2502664 KB2544521 KB2586448 KB2647518 KB2699988
KB2503658 KB2544893 KB2588516 KB2649672 KB2703157
KB2503665 KB2545698 KB2598845 KB2653956 KB2709162
KB2506212 KB2547666 KB2604115 KB2654269 KB2709630
KB2506223 KB2552343 KB2607576 KB2654428 KB2709981
KB2507618 KB2555917 KB2612905 KB2656356 KB2718704
KB2507938 KB2556532 KB2617657 KB2656373 KB947821
KB2508272 KB2559049 KB2618444 KB2656411 KB976902
KB2508429 KB2560656 KB2618451 KB2658846 KB976932
KB2509553 KB2562937 KB2620704 KB2659262 KB982861
KB2510531 KB2563227 KB2620712 KB2660075

Application Versions Included

PDF Complete, version 4.1.10
●
Windows Embedded Device Manager 2011 Client Service Pack, ver 1.0.600.0
●
Write Filters 11

Windows Embedded Device Manager 2011 Client Service Pack, v 1.0.600.0

Anti-Malware \ Defender
●
Tablet / Touch
●
Photo Viewer
●
DirectAccess
●
Branchcache
●
Enterprise Search Scopes
●
Applocker
●
Remote Media Streaming
●
Additional accessories such as Snipping Tool, Sticky Notes, etc
●

Drivers

To ensure you have the most up-to-date drivers, you can search for your product and download drivers for your digital signage player model.
To find the latest drivers go to
http://www8.hp.com/us/en/drivers.html and enter your product name.
12 Chapter 5 Operating System Technical Information

Index

A
add-ons 1 administration tools 8, 10
D
Drive C 5 Drive Z 5
E
Enhanced Write Filter 2
F
File-Based Write Filter 4 finding more information 1 finding utilities 1
H
help and support 1 HP Digital Signage Player Imaging
Utility 8, 10 HP RAMDisk Manager 8, 10 HP ThinState 9, 11 HP Velocity 9, 11
system date and time 6
V
virtualization software 7
W
websites
Citrix support 1 HP support 1 Microsoft support 1 VMware support 1
write filters 2
I
image capture and deployment
9, 11 image updates 1
L
local drives 5 logon
administrator 6 automatic 6 manual 6 user 6
M
Microsoft RDP 7 Microsoft System Center
Configuration Manager 9, 12
S
See
SCCM.
Center Configuration Manager
Microsoft System
Index 13
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
