QuickSpecs

Overview

HP ProLiant ML570 Generation 3

SCSI Model

1. Four Memory Boards

2. Ten PCI slots

3. Four Intel Xeon Processors

4. Four Hot Plug Fans

5. USB (on front)

6. Front Panel LEDs - Diagnostic Lighting

7. High Speed IDE Slimline DVD Drive

SCSI Model

SAS Model

8. 5.25-inch Removable Media Bay (optional)

9. 1.44-MB Diskette Drive (optional)

10. Front Bezel

11. Ultra320 Hot Plug Drive Bays (8+2 Standard) or Hot Plug Drive SFF SAS Bays (18 Standard)

12. Two Hot Plug Fans

SAS Model

1. Front Panel LEDs - Diagnostic Lighting

2. Rack handles

3. High Speed IDE Slimline DVD Drive

4. 5.25-inch Removable Media Bay (optional)

What's New

Support for Dual-core 64-bit Intel® Xeon™ Processors Maximum 64 GB of memory with 4 GB dual-rank DIMMs

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

5. 1.44-MB Diskette Drive (optional)

6. Ultra320 Hot Plug Drive Bays (8+2 Standard) or Hot Plug Drive SFF SAS Bays (18 Standard)

Page 1

QuickSpecs

HP ProLiant ML570 Generation 3

Overview

At A Glance

The HP ProLiant ML570 G3 server is the industry's first 4 processor expansion server that offers not only exceptional performance, but increased reliability with hot-plug RAID memory, powerful management capabilities, and unmatched internal expansion.

With expansion capabilities featuring up to 64GB max memory, support for up to 10×1" hot-plug Ultra 320 SCSI hard drives or 18 Small Form Factor (SFF) SAS drives, and up to 10 PCI I/O slots, the ProLiant ML570 G3 is a truly expandable and reliable server for a data center or remote enterprise environment. The ML570 G3 now supports Intel's new Xeon dual core processor technology providing performance gains for multi-threaded applications, for example database, financial services, and supply-chain management.

Processors:

Intel Xeon Processors 7040 (3.00 GHz/2x2MB), 3.33 GHz/8MB, 3.00 GHz/8MB, 7020 (2.66 GHz/2x1MB), 2.83 GHz/4MB, 3.66 GHz/1MB or 3.16 GHz/1MB 667 MHz dual independent front-side bus Intel E8500 chipset

Memory:

1 GB (2 x 512 MB) standard, 2 GB (4 x 512 MB) standard on 2P models Maximum 64 GB of 2-way interleaved PC2-3200R Registered ECC SDRAM Memory with Advanced ECC capabilities Advanced Memory Protection now including Hot-plug RAID Memory

Storage Controller:

SCSI models: Integrated Dual Channel Ultra320 SCSI Adapter SAS Models: HP Smart Array P600/256 BBWC Controller

The existing embedded SCSI controller can be used for a tape drive in the removable media bay or external storage connect

Internal Drive Support:

Ultra320 compatible SCSI Drive Cage standard (standard duplex backplane 8 + 2) in SCSI models SFF SAS Drive Cage standard (18 drives) in SAS models Internal mass storage capacity up to 3.00TB (8 x 300GB + 2 x 300GB U320 hot plug drives) or 2.628TB (18 x 146GB hot plug SFF SAS drives)

Network Controller:

Embedded NC7782 PCI-X Gigabit Server Adapter

Expansion Slots:

10 Total: (4) 64-bit/100 MHz PCI-X slots, hot-plug: (2) full length; (2) half length; (2) 64-bit/133MHz PCI-X slots, hot-plug; (4) PCI-Express x4 slots

USB Ports:

3 Total: (1) front; (2) rear accessible ports

Redundancy:

Optional hot plug redundant power supplies and cooling fans On 2P models, hot plug redundant fans and power supplies standard

Management:

Integrated Lights-Out industry leading remote management with new support for two-factor authentication, schema-free Microsoft Active Directory integration, Power Regulator p-state reporting, USB key virtual media and VLAN on the shared network port Integrated Remote Console and Automatic Server Recovery-2 (ASR-2)

Form Factor:

Denser form factor - 6U rack and tower models

Deployment/Serviceability:

Industry-standard PCI Hot Plug with Push Button Functionality New Quick Find Diagnostic Display provides location of degraded component Tool-free, spring loaded snap-on slide rails designed to accommodate both round and square hole racks

Warranty:

Protected by HP Services and a worldwide network of resellers and service providers. Three-year Next Business Day, on-site limited global warranty. Certain restrictions and exclusions apply. Pre-Failure Notification on processors, memory, and SCSI/SAS hard drives. SATA hard drives have a one-year warranty.

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 2

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

Processor

One of the following depending on Model

Cache Memory

One of the following depending on Model

Dual-core Intel Xeon Processor at 3.00 GHz\2x2MB

Intel Xeon Processor at 3.33 GHz\8MB

Intel Xeon Processor at 3.00 GHz\8MB

Dual-core Intel Xeon Processor at 2.66 GHz\2x1MB

Intel Xeon Processor at 2.83 GHz\4MB

Intel Xeon Processor at 3.66 GHz\1MB

Intel Xeon Processor at 3.16 GHz\1MB

NOTE:

processor as standard.

8MB Integrated Level 3 cache (per processor)

NOTE:

4MB Integrated Level 3 cache

NOTE:

2x2MB Integrated Level 2 cache

NOTE:

2x1MB Integrated Level 2 cache

NOTE:

1MB Integrated Level 2 cache

NOTE:

2P models ship standard with two processors while all other models ship with one

Available with 3.33 GHz, 3.00 GHz models only.

2.83 GHz Model only.

Dual-core 3.00 GHz Model only.

Dual-core 2.66 GHz Model only.

3.66 GHz, 3.16 GHz Models only.

Upgradeability

Chipset

Memory Protection

Memory

Upgradeable to quad processing

Intel E8500 chipset

NOTE:

http://www.intel.com/products/server/chipsets/

Advanced ECC

Hot-Plug RAID Memory

Hot-Plug Mirrored Memory

Online Spare Memory

Type

Standard

(2P models)

Standard

(base models)

Maximum

NOTE:

URL:

http://h18000.www1.hp.com/products/servers/technology/memoryprotection.html

For more information regarding Intel chipsets, please see the following URL:

PC2-3200R MHz Registered ECC SDRAM DIMM Memory

2048 MB (4 x 512 MB)

1024 MB (2 x 512 MB)

64 GB

For more information regarding Advanced Memory Protection, please see the following

Network Controller

Embedded NC7782 PCI-X Gigabit Server Adapter

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 3

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

Expansion

Slots

NOTE:

All PCI-X slots can only accept universal keyed PCI cards running at 3.3 volts.

NOTE:

x8 PCI-Express cards are supported in all PCI-Express slots but will run at x4 speeds.

Slot

Number

NOTES:

*Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number. **Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest bus).

Bus Speed

64-bit/100MHz

PCI-X

64-bit/100MHz

PCI-X

64-bit/100MHz

PCI-X

64-bit/100MHz

PCI-X

PCI Express x4

64-bit/133MHz

PCI-X

64-bit/133MHz

PCI-X

Bus Number

7 1 no

7 2 no

3 1 no

3 2 no

11 1 no

14 1 no

17 1 no

20 1 no

27 1

24 1

Device

Number

Hot Plug

yes

PCI Voltage

3.3 Volt

N/A

3.3 Volt

Notes

Supported

RILOE slot

Recommended

Smart Array

P600

Controller slot

Storage Controllers

One of the following depending on Model

Storage

Maximum Internal Storage Type

Integrated Dual Channel Ultra320 SCSI Adapter

HP Smart Array P600/256 BBWC Controller (standard in SAS models)

NOTE:

for tape drive in removable media bay or external storage support.

Diskette Drives

Optical Drive

Hard Drives

Hot Plug SCSI

Hot Plug SAS

For SAS/SATA drives and integrated Dual Channel Ultra320 SCSI Adapter can be used

1.44 MB Slimline Drive (optional)

8x/24x IDE (ATAPI) Slimline DVD-ROM Drive

None

3.0TB

2.628TB

8 x 300GB + 2 x 300GB Ultra320

18 x 146GB SFF SAS

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 4

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

Interfaces

Graphics

Form Factor

Product Demo

Parallel

Serial

Pointing Device (Mouse)

Graphics

Keyboard

iLO

USB Ports

Network RJ-45

External SCSI

Integrated ATI RAGE XL Video Controller with 8MB Video Memory

Tower or Rack (6U)

To view the Product Demo, please see the following URL, then click on "PRODUCT TOUR":

http://h18004.www1.hp.com/products/servers/proliantml570/index.html

3 Total: 1 front; 2 rear

NOTE:

regarding USB support:

http://h18004.www1.hp.com/products/servers/platforms/usbsupport.html

Please see the following URL for additional information

ProLiant Foundation Pack Software

Essentials

HP Systems Insight Manager

HP Systems Insight Manager (HP SIM) provides a unified, secure and extensible environment to centrally manage servers, storage and other infrastructure devices across multiple operating system platforms.

Through a single management view, HP SIM provides core management services that include device discovery and identification, event views, health monitoring, inventory data collection, software version control and reporting. HP SIM is built on industry standards and is extensible with value-added ProLiant Essentials, Integrity Essentials and Storage Essentials software to meet individual management needs. For more details on HP SIM visit

HP SIM provides organizations with the following benefits:

Simplifies and consolidates infrastructure lifecycle management using task and query based functionality Provides the foundation for infrastructure automation and virtualization Enables IT management based on business processes not hardware platforms Lowers infrastructure maintenance cost and frees resources for innovation Maximizes resource utilization with virtualization technologies Provides a central point of integration between infrastructure and Enterprise management tools such as HP OpenView

http://www.hp.com/go/hpsim

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 5

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

SmartStart

Insight Management Agents

Subscriber's Choice

SmartStart is a tool that simplifies server setup, providing a rapid way to deploy reliable and consistent server configurations. For more information, please visit the SmartStart Web site at

http://www.hp.com/servers/smartstart

SmartStart version supported (minimum): SmartStart 7.20.

Insight Management Agents should be installed on all HP servers to present system instrumentation, health and configuration information into HP Systems Insight Manager and the HP System Management Homepage. The HP System Management Homepage aggregates systems data from Insight Management Agents and other HP management tools, providing a consolidated browser-based interface for managing individual servers, Insight Management Agents and The HP System Management Homepage are included on ProLiant Support Packs, and can also be installed using the server profiles provided with the ProLiant Essentials Rapid Deployment Pack. For additional information about the Management Agents and the HP System Management Homepage please visit the management Web site at

http://www.hp.com/servers/manage

Subscriber's Choice Driver and Support Alerts/Notifications is a webbased email subscription service that provides automatic delivery of software and driver change notifications for ProLiant products. Sign up at

http://www.hp.com/go/subscriberschoice

and customize your profile to receive various new alerts as they become available, on a weekly or monthly basis.

ROMPaq software, and configuration utilities

Survey Utility and diagnostics utilities

Optional Essentials Value Packs

, support

ProLiant

The latest software, drivers, and firmware fully optimized and tested for your ProLiant server and options available in SmartStart or downloadable from Software and Drivers download pages, linked from the SmartStart website at

The most advanced configuration analysis, reporting and troubleshooting utilities used by HP and at your fingertips, available in SmartStart.

Optional software offerings that selectively extend the functionality of an Adaptive Infrastructure to address specific business problems and needs:

Rapid Deployment Pack (RDP) is an automated deployment and provisioning solution for all ProLiant servers. RDP includes the ProLiant Integration Module featuring ProLiant server preconfigured events for OS installation, and optimized software drivers, firmware and management agents. Every RDP disc includes 10-node trial licenses for evaluation purposes. RDP requires a license for each server deployed and is available for purchase with HP servers. For more information, visit:

http://www.hp.com/servers/rdp

Workload Management Pack - provides easier management of complex environments, improving overall server utilization and enabling Windows® 2000 customers for the first time to confidently Performance Management Pack - a performance management solution that identifies and explains hardware performance bottlenecks on ProLiant servers and attached options enabling users to better utilize their valuable resources. Intelligent Networking Pack - detects and analyzes network bottlenecks or broken network linkages and steers traffic to the

http://www.hp.com/servers/smartstart

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 6

QuickSpecs

Standard Features

Optional Remote Management Packs

HP ProLiant ML570 Generation 3

optimum route based on network conditions, plus it provides an extra layer of protection. The virus throttle feature of the solution slows the propagation of fast spreading virus. Vulnerability and Patch Management Pack - identifies and remediates software security vulnerabilities due to missing patches as well operating system configurations that can be exploited by viruses, worms, and other blended threats Virtual Machine Management Pack - provides central management and control of virtual machines from Microsoft and VMware. Integrated approach provides the ability to manage both physical and virtual resources from a single management console. Server Migration Pack - The Server Migration Pack automates the manual processes required for migrating servers between physical or virtual platforms (P2V, V2P, and V2V).

Integrated Lights-Out Advanced Pack - upgrades the Integrated Lights-Out processor to full virtual presence and control with graphical console and virtual media.

Industry Standard Compliance

Availability

NOTE:

Refer to Pack product QuickSpecs for more information.

NOTE:

URL:

Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs.

http://www.hp.com/servers/proliantessentials

For more information regarding ProLiant Essentials Software, please see the following

http://www.hp.com/servers/proliantessentials

ACPI 2.0 Compliant

PCI 2.2 Compliant

PXE Support

WOL Support

Physical Address Extension (PAE) Support

Microsoft® Logo certifications

Advanced Memory Protection Technology

server availability:

Advanced ECC Memory

ECC protection provides the ability to detect and correct single bit memory errors while Advanced ECC extends this coverage to include protection against multiple simultaneous errors on a DIMM. Advanced ECC detects and corrects up to 4 bit memory errors that occur within a single DRAM chip on a DIMM. Advanced ECC algorithms work in combination with industry standard ECC DIMMS.

Advanced Memory Protection Configurations

Online Spare Memory

Offers a higher level of memory protection than Advanced ECC alone. The system is configured with a spare bank of memory. If the number of single-bit correctable errors on a bank exceeds the pre-defined error threshold, the failing bank will fail over to the Online Spare bank without intervention or server interruption. The failed memory can then be replaced at the user's convenience during a scheduled maintenance window.

Hot Plug Mirrored Memory

Hot Plug Mirrored Memory is a fault-tolerant memory feature that provides a higher level of availability than Advanced ECC or Online Spare Memory because it protects against multibit errors and does not require any server downtime to replace failed DIMMs. Hot Plug Mirrored Memory requires that two memory boards be installed, one an exact mirror of the other, which run in parallel and provide protection against multi-bit memory errors. When configured for Hot Plug Mirrored Memory, the system writes to both memory boards, but

– delivers unsurpassed memory protection and

or the various ProLiant Essentials Value

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 7

QuickSpecs

Standard Features

reads from one. If a read error occurs, the system fails over to the redundant memory board. At that point the memory board containing the failed DIMMs can be hot replaced. Once the failed DIMMs are replaced and the memory board re-installed into the server, the system goes back to full mirrored status. All this occurs without bringing the server down.

Hot Plug RAID Memory

Hot Plug RAID Memory (RAID Memory) provides a similar level of memory protection as Mirrored Memory but obtains this protection using less total memory. For example, in a RAID Memory configuration, 25% of the installed memory is not available to the operating system. In a Mirrored Memory configuration, however, 50% of the installed memory is not available to the operating system. RAID Memory protects the server against uncorrectable memory errors that would otherwise result in a server failure.

NOTE:

All HP ProLiant ML570 G3 servers ship standard with a single memory board. Additional memory boards are optional (P/N 348107-B21).

NOTE:

Based Setup Utility (RBSU) and viewable through Systems Insight Manager and the Integrated Management Log (IML.).

HP ProLiant ML570 Generation 3

All Advanced Memory Protection modes require the use of additional memory cards.

All Advanced Memory Protection modes are user configurable through the ROM-

Remote Management

Intelligent Manageability

Integrated Lights Out (iLO) Standard Management:

Virtual Text Remote Console Virtual Power Button Control Dedicated & shared LAN Connectivity Browser and command line access Automatic IP Configuration via DHCP/DNS/WINS Industry Standard 128-bit Secure Sockets Layer (SSL) and Secure Shell Security IML and iLO Event Logging Support for 12 user accounts with customizable access privilege

Integrated Lights Out Advanced Pack (optional) Remote Graphical Console:

Microsoft Remote Desktop for Administrators integration Virtual media (floppy, CD, USB key, floppy images and ISO images) User access management via Directory Services Two-factor authentication

HP Systems Insight Manager SmartStart Redundant ROM Remote Flash ROM Management Agent Integrated Management Log Automatic Server Recovery (ASR) Dynamic Sector Repairing (with Smart Array Controllers) Drive Parameter Tracking (with Smart Array Controllers) Pre-Failure Warranty (covers processors, SCSI/SAS hard drives and memory)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 8

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

Security

Server Power Cords

Power-on password Hot plug keyboard password Diskette drive control Diskette boot control QuickLock, Network Server Mode Parallel and serial interface control Administrator's password Disk configuration lock Locking tower bezel door Lockable access hood

Tower Models

Rack Models

NOTE:

the Japan model also includes a local power cord. For HP ProLiant ML570 tower models, local power cord(s) are included. Please see the following power cord matrix for details:

http://www.hp.com/go/powercordmatrix

For HP ProLiant ML570 rack models, a C19 to C20 2.8m jumper cord ships standard and

-001US, -011AUS, -031UK, -041GR, -051FR, -291JPN, -371AP, 421EURO, -AA1PRC, all bins

-201 BRZL (only 2.66 GHz, 2.83 GHz, 3.66 GHz and 3.16 GHz) US, Europe, UK, Germany, France, Brazil, Japan, and Australia tower models ship with one local power cord. Asia Pacific tower model ships with Japan, UK, and Europe power cords. PRC tower model ships with Japan, UK, and Australian power cords.

-001US, -291JPN, -371AP, -421EURO, -AA1PRC US and Japan rack models ship with one local power cord and one C19 to C14 jumper cable. Asia Pacific, Europe and PRC rack models ship with one C19 to C14 jumper cable.

UPS and PDU Power Cord Matrix

Power Supply

System Fans

Required Cabling

Please see the UPS and PDU cable matrix that lists cable descriptions, requirements, and specifications for UPS and PDU units:

ftp://ftp.compaq.com/pub/products/servers/ProLiantstorage/power-protection/powercordmatrix.pdf

One 910W/1300W Hot Plug Power Supply ships standard on all Tower Models and on 1P Rack Models. Second power supply is needed for redundancy.

Two 910W/1300W Hot Plug Power Supplies ship standard with the 2P models.

Three fans ship standard with three additional option fans for redundancy

NOTE:

For required cabling information, refer to the Web site at

http://h18000.www1.hp.com/products/servers/ProLiantml570/

2P models ship standard with redundant fans.

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 9

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

OS Support

Rack Airflow Requirements

Microsoft Windows 2003 Server Microsoft Windows 2000 Server Red Hat Enterprise Linux SuSE Enterprise Linux Novell NetWare SCO OpenServer, UnixWare Sun Solaris Intel Platform Edition VMware Virtualization Software

NOTE:

OS Support Matrix at:

NOTE:

http://h18023.www1.hp.com/support/files/server/us/index.html

NOTE:

BladeSystem Server Linux matrix

http://h18004.www1.hp.com/products/servers/linux/hpLinuxcert.html

NOTE:

from HP please visit the OS product site at:

http://h18004.www1.hp.com/products/servers/software/OEM.html

NOTE:

VMware Server Support Matrix at:

http://h18004.www1.hp.com/products/servers/software/vmware/hpvmwarecert.html

Rack 10000 series Cabinets

The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted servers. The 10000 Series Racks provide enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.

For a more complete and up-to-date listing of supported OSs and versions, please visit our

http://www.hp.com/go/supportos

For a listing of the latest drivers available for the HP ProLiant ML570 G3, please see:

For more Linux OS support & certification information, please visit our the ProLiant &

For more complete and up-to-date information on how to buy server operating systems

For more information on HP's Certified and Supported ProLiant Servers, please visit the

Rack Kit

Telco Rack Support

CAUTION:

adequate airflow and to prevent damage to the equipment:

CAUTION:

This arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

NOTE:

CD provided with the server, or to the server documentation located in the Support section at the following URL:

HP ProLiant ML570 G3 rack models have universal sliding rails which provide tool-free support for square and round hole racks (including Compaq/HP 7000, 9000, 10000, HP/E series and H9 series) with an adjustment range from 23 ¾" to 36" depth. The snap-on cable management arm is now ambidextrous.

Support for all 2-post Telco racks requires an additional option kit from Rack Solutions. The Rack Solutions brackets can be purchased at:

If a third-party rack is used, observe the following additional requirements to ensure

Front and rear doors: you must allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation). Side:

The clearance between the installed rack component and the side panels of the

rack must be a minimum of 2.75 inches (7 cm).

Always use blanking panels to fill all remaining empty front panel U-spaces in the rack.

For additional information, refer to the Setup and Installation Guide or the Documentation

http://h18000.www1.hp.com/products/servers/ProLiantml570/index.html

If your 42U server rack includes closing front and rear doors,

http://www.racksolutions.com/hp

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 10

QuickSpecs

Standard Features

HP ProLiant ML570 Generation 3

HP Factory Express Capabilities

HP Enterprise Configurator

Service and Support

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to

The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.

http://www.hp.com/products/configurator

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of resellers and service providers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Additional support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements.

http://www.hp.com/go/factory-express

NOTE:

information regarding worldwide limited warranty and technical support is available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

HP Care Pack services include coverage for the HP branded hardware options qualified for the server, purchased at the same time or afterward, internal to the enclosure, as well as 22" and smaller external monitors and tower UPS options up to 3kVA; these items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included, standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.

HP services provide continuous care and support expertise with committed response designed to meet your IT and business needs.

To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions provides a range of support services designed to meet the varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Enhanced Care - Minimum recommended service support offer designed to ensure customers have access to expert assistance, whenever they need it.

Server Warranty includes 3 year Parts, 3 year Labor, 3-year on-site support. Additional

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years

Continuous Care - Recommended service delivering cost-effective support options designed to extend HP Services committed response and guaranteed fix times, designed to speed problem identification and resolution.

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 11

QuickSpecs

Standard Features

Total Care - Highest HP Support service level recommend to help increase IT performance and availability with comprehensive, integrated hardware and software services

Support Plus 24 - Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays

Deployment Services - HP Installation and Start Up services designed to take time, risk, and worry out of the deployment of ProLiant servers - and free customers IT support staff to focus on what they do best, their business.

Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays

HP ProLiant ML570 Generation 3

NOTE:

http://www.hp.com/services/proliantservices http://www.hp.com/go/proliant/carepack

For a complete listing of service offerings and information visit:

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 12

QuickSpecs

Models

SAS Models

ML570R03 X3.008MB,2GB (2P) SAS

391120-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

HP ProLiant ML570 Generation 3

(2) Intel Xeon Processors MP 3.00 GHz standard (up to four supported)

8MB Integrated Level 3 Cache

2048 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

HP Smart Array P600/256 BBWC Controller

NOTE:

SCSI Adapter can be used for tape drive in removable media bay or external storage support.

None ship standard

2.628TB maximum (with optional hard drives)

Two 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

For SAS/SATA drives and integrated Dual Channel Ultra320

ML570T03 X3.00-8MB, 1GB (1P) SAS

391113-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Intel Xeon Processors MP 3.00 GHz standard (up to four supported)

8MB Integrated Level 3 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

HP Smart Array P600/256 BBWC Controller

NOTE:

SCSI Adapter can be used for tape drive in removable media bay or external storage support.

None ship standard

2.628TB maximum (with optional hard drives)

One 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower

For SAS/SATA drives and integrated Dual Channel Ultra320

(6U)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 13

QuickSpecs

Models

SCSI Models

ML570R03 X7040 2GB (2P)

399364-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

HP ProLiant ML570 Generation 3

(2) Dual-core 64-bit Intel Xeon Processors 3.00 GHz standard (up to four supported)

2 x 2MB Integrated Level 2 Cache

2048 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum (with optional hard drives)

Two 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

ML570T03 X7040 1GB (1P)

399363-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Dual-core 64-bit Intel Xeon Processors 3.00 GHz standard (up to four supported)

2 x 2MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum (with optional hard drives)

One 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower (6U)

Four memory boards would be required to configure up to 64 GB

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 14

QuickSpecs

Models

HP ProLiant ML570 Generation 3

ML570R03 X7020 1GB (1P)

399366-xx1

ML570T03 X7020 1GB (1P)

399365-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Dual-core 64-bit Intel Xeon Processors 2.66 GHz standard (up to four supported)

2 x 1MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum (with optional hard drives)

One 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

(1) Dual-core 64-bit Intel Xeon Processors 2.66 GHz standard (up to four supported)

2 x 1MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum (with optional hard drives)

One 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower (6U)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 15

QuickSpecs

Models

HP ProLiant ML570 Generation 3

ML570R03 X3.33-8MB, 2GB (2P)

348140-xx1

ML570R03 X3.00-8MB, 2GB (2P)

348138-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(2) Intel Xeon Processors MP 3.33 GHz standard (up to four supported)

8MB Integrated Level 3 Cache

2048 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum (with optional hard drives)

Two 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

(2) Intel Xeon Processors MP 3.00 GHz standard (up to four supported)

8MB Integrated Level 3 Cache

2048 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum (with optional hard drives)

Two 910W/1300W Power Supplies standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 16

QuickSpecs

Models

HP ProLiant ML570 Generation 3

ML570R03 X2.83-4MB, 1GB (1P)

348135-xx1

ML570R03 X3.66-1MB, 1GB (1P)

385943-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Intel Xeon Processor MP 2.83 GHz standard (up to four supported)

4MB Integrated Level 3 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

(1) Intel Xeon Processor MP 3.66 GHz standard (up to four supported)

1MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 464

GB using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 17

QuickSpecs

Models

HP ProLiant ML570 Generation 3

ML570R03 X3.16-1MB, 1GB (1P)

375367-xx1

ML570T03 X3.33-8MB, 1GB (1P)

348139-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Intel Xeon Processor MP 3.16 GHz standard (up to four supported)

1MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Rack (6U)

(1) Intel Xeon Processor MP 3.33 GHz standard (up to four supported)

8MB Integrated Level 3 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower (6U)

Four memory boards would be required to configure up to 64 GB

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 18

QuickSpecs

Models

HP ProLiant ML570 Generation 3

ML570T03 X3.00-8MB, 1GB (1P)

348137-xx1

ML570T03 X2.83-4MB, 1GB (1P)

348134-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Intel Xeon Processor MP 3.00 GHz standard (up to four supported)

8MB Integrated Level 3 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower

(6U)

(1) Intel Xeon Processor MP 2.83 GHz standard (up to four supported)

4MB Integrated Level 3 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower

(6U)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 19

QuickSpecs

Models

HP ProLiant ML570 Generation 3

ML570T03 X3.66-1MB, 1GB (1P)

385942-xx1

ML570T03 X3.16-1MB, 1GB (1P)

375366-xx1

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

Processor

Cache Memory

Memory

Network Controller

Storage Controller

Hard Drive

Internal Storage

Power Supplies

Optical Drive

Diskette Drive

Form Factor

(1) Intel Xeon Processor MP 3.66 GHz standard (up to four supported)

1MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower (6U)

(1) Intel Xeon Processor MP 3.16 GHz standard (up to four supported)

1MB Integrated Level 2 Cache

1024 MB PC2-3200R registered ECC SDRAM (Standard) to 64 GB (Maximum) (2 x 1 interleaved memory and Advanced Memory Protection Technology)

NOTE:

Four memory boards would be required to configure up to 64 GB

using 4 GB DIMMs.

Embedded NC7782 PCI-X Gigabit Server Adapter

Integrated Dual Channel Ultra320 SCSI Adapter

None ship standard

3.00TB maximum

One 910W/1300W Power Supply standard (second power supply for redundancy)

IDE Slimline DVD-ROM Drive

Optional

Tower (6U)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 20

QuickSpecs

Models

HP ProLiant ML570 Generation 3

Country Code Key

XX=00

XX=01

XX=03

XX=04

XX=05

XX=20

XX=29

XX=37

XX=42

XX=AA

TOWER MODELS

U.S. English U.S. English

Australia

Germany

France

Brazil

NOTE:

3.16 GHz, 3.33 GHz, 3.66 GHz, and 2.83 GHz speeds only.

Japan Japan

APD APD

Europe Europe

PRC PRC

Valid for X7020, 3.0 GHz,

RACK MODELS

N/A

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 21

QuickSpecs

HP ProLiant ML570 Generation 3

Configuration Information - Factory Integrated Models (North America only)

NOTE:

For Configure to Order requirements within EMEA region, please consult local Sales Contact.

NOTE:

HP does not allow factory integration of options into standard models listed above.

Configure-to-order servers must start with a CTO Chassis.

NOTE: NOTE: NOTE:

configurations are ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for additional information.

This product offering does not support HP Factory Express Server Configuration Level 1.

FIO indicates that this option only available as a Factory Installable Option.

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid

Step 1: Base Configuration (choose one of the following configurable models)

Models

HP ProLiant ML570 G3 Tower Chassis, NA

Factory Integrated Model ships with:

Embedded NC7782 PCI-X Gigabit Server Adapter

Ultra320 Controller (integrated on system board)

Ten Standard I/O Expansion slots

Tower models ship with one Hot Plug Power Supply and one local power cord.

Three Hot Plug Fans

Ultra320 Duplex Drive Cage (can be Simplex configured)

Integrated Lights-Out (iLO) Standard Management

Keyboard and Mouse

Tower (6U)

HP ProLiant ML570 G3 Rack Chassis, NA

Factory Integrated Model ships with:

Embedded NC7782 PCI-X Gigabit Server Adapter

Ultra320 Controller (integrated on system board)

Ten Standard I/O Expansion slots

Rack models ship with one Hot Plug Power Supply, and local power cord(s)

Three Hot Plug Fans

Ultra320 Duplex Drive Cage (can be Simplex configured)

Integrated Lights-Out (iLO) Standard Management

Rack (6U)

ML570T03 SAS Tower Chassis, NA

Factory Integrated Model ships with:

Embedded NC7782 PCI-X Gigabit Server Adapter

Ten Standard I/O Expansion slots

Tower models ship with one Hot Plug Power Supply and one local power cord

Three Hot Plug Fans

SFF SAS Drive Cage

Integrated Lights-Out (iLO) Standard Management

Keyboard and Mouse

Tower (6U)

ML570R03 SAS Rack Chassis, NA

Factory Integrated Model ships with:

Embedded NC7782 PCI-X Gigabit Server Adapter

Ten Standard I/O Expansion slots

379933-405

379934-405

391224-405

391225-405

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 22

QuickSpecs

HP ProLiant ML570 Generation 3

Configuration Information - Factory Integrated Models (North America only)

Rack models ship with one Hot Plug Power Supply, and local power cord(s)

Three Hot Plug Fans

SFF SAS Drive Cage

Integrated Lights-Out (iLO) Standard Management

Rack (6U)

Step 1A: If SAS Model, Choose SAS Starter Kit or Controller (only one of the following)

SAS Controller

SAS Starter Kit

HP Smart Array P600 Controller

NOTE:

This is a required selection if one of the two following SAS Starter Kits is not selected. If choosing this part number, SFF SAS hard drives must still be selected under Step 4.

SAS Starter Kit - 36GB

NOTE:

Includes HP Smart Array P600/256 BBWC Controller and (2) 36GB SFF SAS Universal Hard Drives.

SAS Starter Kit - 72GB

NOTE:

Includes HP Smart Array P600/256 BBWC Controller and (2) 72GB SFF SAS Universal Hard Drives.

337972-B21

396221-B21

396220-B21

Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)

Processors

Base Memory

Optical Drive

X3.00-2x2MB 570 G3 FIO

X2.66-2x1MB 570 G3 FIO

X3.33-8MB 570 G3 FIO

X3.00-8MB 570 G3 FIO

X2.83-4MB 570 G3 FIO

X3.66-1MB 570 G3 FIO

X3.16-1MB 570 G3 FIO

NOTE:

Up to 3 additional xxxxxx-B21 processors for each HP ProLiant ML570 server may be ordered. If selecting a Performance Pack option (404476-001, 380927-001 or 380928-001), a second processor (399889-B21, 348111-B21 or 348110-B21) is included and should not be ordered.

8 GB (2 x 4 GB 2RANK) PC2-3200R 400MHz DDR2 with Advanced ECC and online spare memory capabilities

4 GB (2 x 2 GB 2RANK) PC2-3200R 400MHz DDR2 with Advanced ECC and online spare memory capabilities

4 GB (2 x 2 GB 1RANK) PC2-3200R 400MHz DDR2 with Advanced ECC and online spare memory capabilities

2 GB (2 x 1 GB 1RANK) PC2-3200R 400MHz DDR2 with Advanced ECC and online spare memory capabilities

1 GB (2 x 512 MB 1RANK) PC2-3200R 400MHz DDR2 with Advanced ECC and online spare memory capabilities

Slimline CD-RW/DVD-ROM 24X Combo Drive Option Kit (Servers)

Slimline DVD-ROM Drive (8X/24X) Option Kit (Servers)

399889-L21

399888-L21

348111-L21

348110-L21

348109-L21

385903-L21

375369-L21

348106-B21

375004-B21

343057-B21

343056-B21

343055-B21

331903-B21

264007-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 23

QuickSpecs

HP ProLiant ML570 Generation 3

Configuration Information - Factory Integrated Models (North America only)

Step 3: Choose Additional Factory Integratable Options

The HP ProLiant ML570 G3 performance packs are necessary to configure a HP ProLiant ML570 G3 High Performance Model. HP ProLiant ML570 G3 High Performance models include the latest performance technologies and enterprise class availability features pre-installed for convenience and value. In addition to the standard features listed in Step 1, the High Performance Model includes the following:

Second Intel Xeon Processor Redundant Power Supplies and Fans

ML570G3 X7040 Rack Optimized Pack (US)

ML570G3 X3.33GHz/667-8MB Rack Optimized Pack (US)

ML570G3 X3.00GHz/667-8MB Rack Optimized Pack (US)

Step 4: Choose Additional Options for Factory Integration

NOTE:

For additional options, please refer to the "Options" section below.

404476-001

390927-001

390928-001

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 24

QuickSpecs

Options

NOTE:

Some options may not be factory configurable. Please contact your local sales representative for additional

information.

HP ProLiant ML570 G3 Unique Options

ProLiant Tower to Rack Conversion Kit

ProLiant Rack to Tower Conversion Kit

HP ProLiant ML570 Generation 3

348112-B21

348113-B21

Processor

Dual-Core Intel Xeon 7040 (3.00GHz-2x2MB) Processor Option Kit

NOTE:

This processor option kit (PN 399889-B21) supports the HP ProLiant ML570 G3 and the HP ProLiant DL580 G3.

Dual-Core Intel Xeon 7020 (2.66GHz-2x1MB) Processor Option Kit

NOTE:

This processor option kit (PN 399888-B21) supports the HP ProLiant ML570 G3 and the HP ProLiant DL580 G3.

Intel Xeon MP X3.33 GHz-8MB Processor Option Kit

NOTE:

ML570 G3 and the HP ProLiant DL580 G3.

Intel Xeon MP X3.00 GHz-8MB Processor Option Kit

NOTE:

ML570 G3 and the HP ProLiant DL580 G3.

Intel Xeon MP X2.83 GHz-4MB Processor Option Kit

NOTE:

ML570 G3 and the HP ProLiant DL580 G3.

Intel Xeon MP X3.66 GHz-1MB Processor Option Kit

NOTE:

ML570 G3 and the HP ProLiant DL580 G3.

Intel Xeon MP X3.16 GHz-1MB Processor Option Kit

NOTE:

ML570 G3 and the HP ProLiant DL580 G3.

NOTE:

supported.

This processor option kit (PN 348111-B21) supports the HP ProLiant

This processor option kit (PN 348110-B21) supports the HP ProLiant

This processor option kit (PN 348109-B21) supports the HP ProLiant

This processor option kit (PN 385903-B21) supports the HP ProLiant

This processor option kit (PN 375369-B21) supports the HP ProLiant

Processor mixing of different frequencies and cache sizes is not

399889-B21

399888-B21

348111-B21

348110-B21

348109-B21

385903-B21

375369-B21

ProLiant Essentials Value Pack Software

ProLiant Essentials Intelligent Networking Pack

ProLiant Essentials Intelligent Networking Pack - Windows Edition, Single Server License

NOTE:

For use with a single server. Contains one license with a unique license activation key and documentation.

NOTE:

For additional ProLiant Intelligent Networking Pack License Kits please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12062_div/12062_div.HTML

ProLiant Essentials Intelligent Networking Pack - Linux Edition, Single Server License

NOTE:

please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12327_div/12327_div.HTML

ProLiant Essentials Performance Management Pack

ProLiant Essentials Performance Management Pack, Single-Server License

NOTE:

activation key, HP Management CD and documentation.

NOTE:

http://www.hp.com/products/pmp

NOTE:

please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11925_div/11925_div.HTML

For additional ProLiant Intelligent Networking Pack - Linux License Kits

For use with a single server. Contains one license with a unique license

The most recent version of the software can always be downloaded at

For additional ProLiant Performance Management Pack License Kits

436225-B21

436229-B21

306696-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 25

QuickSpecs

Options

ProLiant Essentials Rapid Deployment Pack Windows Edition Release

Rapid Deployment Pack, Single-Server License

NOTE:

This license allows 1 server to be deployed and managed via RDP.

Rapid Deployment Pack, Single-Server License (Japan)

NOTE:

This license allows 1 server to be deployed and managed via RDP.

ProLiant Essentials Rapid Deployment Pack - Physical Media Kit

ProLiant Essentials Rapid Deployment Pack Flatpack - single-server license

NOTE:

For additional ProLiant Essentials Rapid Deployment Pack License Kits please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11053_div/11053_div.HTML

ProLiant Essentials Workload Management Pack

ProLiant Essentials Workload Management Pack, Single Server License

NOTE:

For additional ProLiant Workload Management Pack License Kits please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11452_div/11452_div.HTML

ProLiant Essentials Virtualization Management Software

ProLiant Essentials Virtual Machine Management Pack, Single-Server License

NOTE:

For use with a single server. Contains one license with a unique license activation key and documentation.

ProLiant Essentials Server Migration Pack, Single-Migration License

NOTE:

activation key and documentation.

NOTE:

virtual machine. Or this license can be used to migrate a virtual machine from one virtualization layer i.e. VMware GSX to a different virtualization layer such as VMware ESX or Microsoft Virtual Server 2005.

ProLiant Essentials Server Migration Pack - Physical to ProLiant Edition, SingleMigration License

HP ProLiant Essentials Server Migration Pack - Physical to ProLiant Edition. 1 Year Unlimited Migration License

NOTE:

For additional ProLiant Essentials Virtualization Management Software License Kits please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12328_div/12328_div.HTML

ProLiant Essentials Vulnerability and Patch Management Pack

ProLiant Essentials Vulnerability and Patch Management Pack, Single-Server License

NOTE:

For use with a single server. Contains one license with a unique license activation key and documentation.

NOTE:

For additional ProLiant Vulnerability and Patch Management Pack License Kits, please see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12111_div/12111_div.HTML

NOTE:

Flexible and volume quantity license kits are available for ProLiant Essentials Value Packs. Refer to the various ProLiant Essentials Value Pack product QuickSpecs for more information.

NOTE:

For more information regarding ProLiant Essentials Software, please see the following URL:

HP ProLiant ML570 Generation 3

Contains one license, enabling 1 server migration, with a unique license

This license allows 1 server to be migrated from a physical server to a

http://www.hp.com/servers/proliantessentials

267196-B21

267196-291

434559-B21

434560-B21

303284-B21

435661-B21

435663-B21

412978-B21

412982-B21

371645-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 26

QuickSpecs

Options

HP ProLiant ML570 Generation 3

Remote Management

Memory

Optical Drives

(DIMMs)

Integrated Lights-Out Advanced Pack

Integrated Lights-Out Advanced Pack, 1 server

Featuring:

servers in the data centers and remote sites.

NOTE:

see the QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/12326_div/12326_div.HTML

8 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 4096 MB) Dual Rank

4 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 2048 MB) Dual Rank

4 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 2048 MB) Single Rank

2 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 1024 MB)

1 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 512 MB)

Hot-plug Memory Expansion Board

NOTE:

using 2 GB DIMMs.

Slimline DVD-ROM Drive (8X/24X) Option Kit (Servers)

NOTE:

Slimline CD-RW/DVD-ROM Combo Drive Option Kit

NOTE: This drive is supported in the DVD-ROM bay and floppy bay

HP DVD+R/RW 8X Slim

Slimline CD-ROM Drive 24X

Sophisticated virtual administration features for ultimate control of

For additional Integrated Light-Out Advanced Pack License Kits please

Four memory boards would be required to configure 48 GB of memory

This drive is supported in the removable media bay.

263825-B21

348106-B21

375004-B21

343057-B21

343056-B21

343055-B21

348107-B21

264007-B21

331903-B21

383975-B21

356963-B21

Diskette Drive

SAS Drive Cage

Hard Drives

Slimline Floppy Diskette Drive Option Kit

ML570G3 SAS Drive Cage Option Kit

Ultra320 SCSI – Universal Hot Plug

HP 300GB U320 10K Universal HDD

HP 146GB U320 10K Universal HDD

HP 72GB U320 10K Universal HDD

HP 300GB U320 15K Universal HDD

HP 146GB U320 15K Universal HDD

HP 72GB U320 15K Universal HDD

HP 36GB U320 15K Universal HDD

NOTE:

speeds.

NOTE:

as capacity, height, width, interface, transfer rate, seek time, physical configuration, and operating temperature:

http://h18000.www1.hp.com/products/quickspecs/11531_div/11531_div.HTML

(Worldwide)

Serial Attached SCSI (SAS) SFF Hot Plug

All U320 Universal Hard Drives are backward compatible to U2 or U3

Please see the Hard Drive QuickSpecs for Technical Specifications such

390164-B21

378101-B21

350964-B22

286716-B22

286714-B22

411089-B22

347708-B22

286778-B22

286776-B22

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 27

QuickSpecs

Options

HP ProLiant ML570 Generation 3

Storage Controllers

HP 146GB 3G SAS 10K SFF SP HDD

HP 72GB 3G SAS 10K SFF SP HDD

HP 72GB 3G SAS 15K SFF SP HDD

HP 36GB 3G SAS 10K SFF SP HDD

HP 36GB 3G SAS 15K SFF SP HDD

NOTE:

Please see the SAS Hard Drive QuickSpecs for Technical Specifications such as capacity, height, width, interface, transfer rate, seek time, physical configuration, and operating temperature:

http://h18000.www1.hp.com/products/quickspecs/12244_div12244_div.HTML

(Worldwide)

SATA Hot Plug

HP 120GB 1.5G SATA 5.4K SFF HDD

HP 60GB 1.5G SATA 5.4K SFF HDD

NOTE:

QuickSpecs for Technical Specifications such as capacity, height, width, interface, transfer rate, seek time, physical configuration, and operating temperature:

http://h18000.www1.hp.com/products/quickspecs/11940_div/11940_div.HTML

(Worldwide)

SAS Controllers

Smart Array P600 Controller

HP Smart Array P600/256 BBWC Controller

NOTE:

Option Kit.

512MB DDR BBWC Upgrade

NOTE:

including Technical Specifications:

http://h18000.www1.hp.com/products/quickspecs/12247_div/12247_div.HTML

(Smart Array P600 Controller)

SAS HBA

HP 8 Internal Port SAS HBA with RAID

NOTE:

http://h18004.www1.hp.com/products/quickspecs/12617_div/12617_div.html

(SC44Ge HBA)

http://h18004.www1.hp.com/products/quickspecs/12332_div/12332_div.html

(8 Internal Port SAS HBA)

SCSI Controllers

Smart Array 6402/128 Controller

Smart Array 6404/256 Controller

Smart Array 641 Controller

Smart Array 642 Controller

128-MB BBWC (Battery-Backed Write Cache) Enabler

NOTE:

Array 642 Controller.

Ultra320 Expansion Module for SA-6402

64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2

NOTE:

additional information:

http://h18000.www1.hp.com/products/quickspecs/11587_div/11587_div.HTML

(Smart Array 6400 Series)

SATA drives have a 1-year warranty. Please see the SATA Hard Drive

Included in SAS Server Models. Only needed with SAS Drive Cage

Please see the following Controller QuickSpecs for additional information

Please see the HBA QuickSpecs for additional information:

This 128MB BBWC supports the Smart Array 641 Controller and Smart

Please see the following QuickSpecs for Technical Specifications and

431958-B21

375861-B21

431935-B21

375859-B21

431933-B21

431786-B21

379306-B21

337972-B21

372538-B21

347786-B21

273915-B21

273914-B21

291966-B21

291967-B21

351580-B21

273911-B21

374654-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 28

QuickSpecs

Options

http://h18000.www1.hp.com/products/quickspecs/12067_div/12067_div.HTML

(Smart Array 641)

http://h18000.www1.hp.com/products/quickspecs/12069_div/12069_div.HTML

(Smart Array 642)

http://h18000.www1.hp.com/products/quickspecs/11943_div/11943_div.HTML

(Single Channel U320 SCSI G2 HBA)

HP ProLiant ML570 Generation 3

Communications

Redundant Options

HP NC110T PCI Express Gigabit Server Adapter

HP NC310F PCI-X 1000SX Gigabit Server Adapter

HP NC340T PCI-X 4-port 1000T Gigabit Server Adapter

HP NC360T PCI Express Dual Port Gigabit Server Adapter

HP NC373F PCI Express Multifunction Gigabit Server Adapter

HP NC373T PCI Express Multifunction Gigabit Server Adapter

HP NC510F PCIe 10 Gigabit Server Adapter

NOTE:

NC510F adapter.

HP NC510C PCIe 10 Gigabit Server Adapter

NOTE:

NC510C adapter.

HP NC7771 PCI-X 1000T Gigabit Server Adapter

Hot-plug Redundant Fan Kit

NOTE:

910W (low line), 1300W (high line) Hot Plug Redundant Power Supply US

910W (low line), 1300W (high line) Hot Plug Redundant Power Supply AUST

910W (low line), 1300W (high line) Hot Plug Redundant Power Supply EURO

910W (low line), 1300W (high line) Hot Plug Redundant Power Supply UK

910W (low line), 1300W (high line) Hot Plug Redundant Power Supply JPN2

910W (low line), 1300W (high line) Hot Plug Redundant Power Supply

NOTE:

A minimum of 1 gigabyte (1 GB) of server memory is required per each

Includes three fans. Included in 2P models.

Includes C14 to C19 IEC cable.

434905-B21

368169-B21

391661-B21

412648-B21

394793-B21

394791-B21

414126-B21

414129-B21

290563-B21

348108-B21

348114-001

348114-011

348114-021

348114-031

348114-291

348114-B21

Management Options

Remote Insight Lights-Out Edition II (NA, LA)

Remote Insight Lights-Out Edition II (EMEA)

Remote Insight Lights-Out Edition II (APD, Japan)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

227251-001

227251-021

227251-371

Page 29

QuickSpecs

Options

HP ProLiant ML570 Generation 3

Tape Drives

NOTE:

For complete listing of tape drive offerings see

http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html

For recommended tape drive offerings for this ProLiant server see the following:

USB Tape Drives

HP StorageWorks DAT 72 USB Internal Tape Drive (Carbonite)

Ultrium Tape Drives

HP StorageWorks Ultrium 232 Internal Tape Drive (Carbonite)

HP StorageWorks Ultrium 460 Internal Tape Drive (Carbon)

HP StorageWorks Ultrium 448 Internal Tape Drive (Carbonite)

HP StorageWorks Ultrium 920 SCSI Internal Tape Drive

HP StorageWorks Ultrium 960 Internal Tape Drive (Carbonite)

NOTE:

additional options such as controllers, media, and other related items:

http://h18006.www1.hp.com/products/quickspecs/11739_div/11739_div.html

(Worldwide)

http://h18006.www1.hp.com/products/quickspecs/12128_div/12128_div.html

(Worldwide)

For an up-to-date listing of the latest O/S and software support details for HP Ultrium tape drives, please visit:

DAT Drives

HP StorageWorks DAT 72 SCSI Internal Tape Drive (Carbon)

NOTE:

other options:

http://h18000.www1.hp.com/products/quickspecs/11883_div/11883_div.HTML

(Worldwide) For an up-to-date listing of the latest O/S and software support details for HP DAT drives, please visit:

Rack-Mount Tape Drive Enclosures

HP StorageWorks 1U SCSI Rack-Mount kit

NOTE:

is compatible with multiple Single-Ended and LVD SCSI tape drives including the DAT 24, DAT 40, DAT 72, DLT VS80, DLT VS160, Ultrium 215, Ultrium 232, Ultrium 448 and Ultrium 920 tape drives.

HP StorageWorks 1U USB Rack-Mount Kit

NOTE:

and is compatible with the DAT 24 USB, DAT 40 USB and DAT 72 USB tape drives.

HP StorageWorks 3U Rack-mount kit

NOTE:

tape drives and compatible with multiple LVD SCSI tape drives including DAT 40, DAT 72, DLT VS160, SDLT 320, SDLT 600, Ultrium 232, Ultrium 460, Ultrium 448, Ultrium 920 and Ultrium 960 tape drives.

NOTE:

information regarding these kits:

http://h18000.www1.hp.com/products/quickspecs/10854_div/10854_div.HTML

(Worldwide)

Please see the HP StorageWorks Ultrium Tape Drive QuickSpecs for

http://www.hp.com/go/connect

Please see the DAT Tape Drive QuickSpecs for controllers, media, and

http://www.hp.com/go/connect

The 1U Rack-Mount Kit can support up to (2) half-height tape drives and

The 1U USB Rack-Mount Kit can support up to (2) half-height tape drives

The 3U Rack-mount Kit can support up to (2) full-height or (4) half-height

Please see the Rack-Mount Tape Drive Kits QuickSpecs for additional

DW026A

DW064A

Q1518B

DW016A

EH841A

Q1538A

Q1522B

A7445B

A8007A

274338-B22

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 30

QuickSpecs

Options

HP ProLiant ML570 Generation 3

Tape Autoloaders

Tape Libraries

HP StorageWorks DAT Autoloader

HP StorageWorks DAT 72x10 tape autoloader

HP StorageWorks Tape 1/8 Autoloader

HP StorageWorks 1/8 Ultrium 920 G2 Tape Autoloader

HP StorageWorks 1/8 Ultrium 448 G2 Tape Autoloader

HP StorageWorks 1/8 Ultrium 232 G2 Tape Autoloader

HP StorageWorks 1/8 G2 Tape Autoloader Rack Kit

NOTE:

includes rails and rackmount instructions

NOTE:

http://www.hp.com/go/automation

complete solution; reference current compatibility information at

http://www.hp.com/go/ebs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 1 Ultrium 960 Drive Library HP StorageWorks MSL2024 1 Ultrium 960 4GB FC Drive Library HP StorageWorks MSL2024 1 Ultrium 920 Drive Library HP StorageWorks MSL2024 2 Ultrium 920 Drive Library HP StorageWorks MSL2024 1 Ultrium 448 Drive Library HP StorageWorks MSL2024 2 Ultrium 448 Drive Library

HP StorageWorks MSL4048 Tape Library

HP StorageWorks MSL4048 1 Ultrium 448 Drive Library HP StorageWorks MSL4048 2 Ultrium 448 Drive Library HP StorageWorks MSL4048 1 Ultrium 920 Drive Library HP StorageWorks MSL4048 2 Ultrium 920 Drive Library HP StorageWorks MSL4048 1 Ultrium 960 Drive Library HP StorageWorks MSL4048 1 Ultrium 960 4GB FC Drive Library HP StorageWorks MSL4048 2 Ultrium 960 Drive Library HP StorageWorks MSL4048 2 Ultrium 960 4GB FC Drive Library

HP StorageWorks MSL6000 Tape Library Ultrium 960 technology

HP StorageWorks MSL6030 1 Ultrium 960 Dr LVDS Library HP StorageWorks MSL6030 1 Ultrium 960 Dr FC Library HP StorageWorks MSL6030 2 Ultrium 960 Dr LVDS Library HP StorageWorks MSL6030 2 Ultrium 960 Dr FC Library

Ultrium 460 technology

HP StorageWorks MSL6030 1 Ultrium 460 Dr LVDS Library HP StorageWorks MSL6030 1 Ultrium 460 Dr FC Library HP StorageWorks MSL6030 2 Ultrium 460 Dr LVDS Library HP StorageWorks MSL6030 2 Ultrium 460 Dr FC Library

NOTE:

QuickSpecs at needed to create a complete solution; reference current compatibility information at

Required to install the 1/8 G2 Autoloaders in a standard 19-inch rack;

Please reference the 1/8 Tape Autoloader QuickSpecs at

for additional information needed to create a

Please reference the

http://www.hp.com/go/automation

http://www.hp.com/go/ebs

MSL2024, MSL4048, and

for additional information

MSL6000 Tape Library

AE313A

AH165A

AH164A

AH163A

AH166A

AG115A AG326B

AH169A

AH170A AG116A AG117A

AG320A AG321A

AH171A

AH172A AG322A AG324B AG323A AG325B

AD606B

AD608B

AD607B

AD609B

AD598B

AD600B

AD599B

AD601B

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 31

QuickSpecs

Options

HP ProLiant ML570 Generation 3

HP Data Protector Express Software

Cluster Options

HP DP Express Backup Server Upgrade for ProLiant Software

HP DP Express Package for Microsoft Small Business Server

NOTE:

Please see the HP Data Protector Express QuickSpecs for additional information regarding the purchase of HP Data Protector Express software:

http://h18000.www1.hp.com/products/quickspecs/12337_div/12337_div.html

(Worldwide)

NOTE:

To obtain a free licensed copy of HP Data Protector Express for ProLiant edition software, please visit the "Protect Your Data" link accessible from your ProLiant server's System Management Homepage (SMH) software (SmartStart

7.5 or later).

ProLiant Cluster Starter Kit

NOTE:

please see the following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11935_div/11935_div.html

(Worldwide)

HP HA/F200 for Entry SAN Cluster

NOTE:

SAN please see the following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11932_div/11932_div.html

(Worldwide)

ProLiant Cluster HA/F500 for the Enterprise SAN

NOTE:

Enterprise SAN please see the following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11933_div/11933_div.html

(Worldwide)

HP Serviceguard for Linux ProLiant Cluster A.11.16 for SUSE SLES 9 & 10 and Red Hat EL 3 & 4 (2 node license cluster kit)

HP Serviceguard for Linux A.11.16 for SUSE SLES 9 & 10 and Red Hat EL 3 & 4 (single license version)

HP Serviceguard for Linux and Red Hat Global File System - 1 year subscription

HP Serviceguard for Linux and Red Hat Global File System - 3 years subscription

NOTE:

License, please see the following QuickSpecs at:

http://h18000.www1.hp.com/products/quickspecs/11518_div/11518_div.html

(Worldwide)

NOTE:

Cluster for Oracle RAC please go to:

http://www.hp.com/solutions/highavailability/oracle

For additional information regarding the ProLiant Cluster Starter Kit

For additional information regarding the ProLiant Cluster for Entry Level

For additional information regarding the ProLiant Cluster HA/F500 for

For additional information regarding the HP Serviceguard for Linux

For configuration/certification options for the HP Parallel Database

BB117AP

BB118AA

364023-B22

364026-B22

364024-B21

305199-B26

307754-B26

T2798AA#001

T2798AA#003

HP StorageWorks Modular Smart Array 20

NOTE:

redundant power supplies.

HP StorageWorks Modular Smart Array 20 Starter Kit

NOTE:

redundant power supplies. Includes Smart Array 6402/128 Controller.

NOTE:

1.5Gb/s 3.5" Hot Plug Hard Drives.

Rack-mountable 12 (SATA) drive enclosure with U320 Host connectivity,

The Modular Smart Array Enclosure 20 Family supports the SATA

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

335921-B21

366172-B21

Page 32

QuickSpecs

Options

HP ProLiant ML570 Generation 3

HP StorageWorks Modular Smart Array 30

HP StorageWorks Modular Smart Array 50

HP StorageWorks Modular Smart Array 1000

HP StorageWorks Modular Smart Array 30 SB

NOTE:

Rack-mountable 14 drive enclosure with single bus, redundant power supplies

HP StorageWorks Modular Smart Array 30 DB

NOTE:

Rack-mountable 14 drive enclosure with dual bus, redundant power supplies

NOTE:

Ultra320 Hot Plug Hard Drives.

HP StorageWorks Modular Smart Array 50 Enclosure

NOTE:

options and configuration information at:

http://h18000.www1.hp.com/products/quickspecs/12245_div/12245_div.HTML

(Worldwide)

HP StorageWorks Modular Smart Array 1000

NOTE:

options and configuration information at:

http://h18000.www1.hp.com/products/quickspecs/11033_div/11033_div.HTML

(Worldwide)

The Modular Smart Array Enclosure 30 Family supports the Wide Ultra3,

Please see the Modular Smart Array 50 QuickSpecs for additional

Please see the Modular Smart Array 1000 QuickSpecs for additional

302969-B21

302970-B21

364430-B21

201723-B22

HP StorageWorks Modular Smart Array 1500

StorageWorks Options

Modular Smart Array 1500 Controller Shelf

NOTE:

additional options and configuration information at:

http://www.hp.com/go/MSA1500cs

NOTE:

Windows and Linux. For detailed compatibility information please see:

http://h18006.www1.hp.com/storage/saninfrastructure/hba.html

HP StorageWorks FC2142SR 4Gb PCI-e HBA

HP StorageWorks FC2242SR Dual Channel 4 Gb PCI-e HBA

HP StorageWorks FC1142SR 4Gb PCI-e HBA

HP StorageWorks FC1242SR Dual Channel 4 Gb PCI-e HBA

HP StorageWorks FC2143 4Gb PCI-X 2.0 -to-Fibre Channel HBA

HP StorageWorks FC2243 Dual Channel 4Gb PCI-X 2.0 HBA

HP StorageWorks FC1143 4Gb PCI-X 2.0 HBA

HP StorageWorks FC1243 Dual Channel 4Gb PCI-X 2.0 HBA

Please see the StorageWorks Modular SAN Array 1500 QuickSpecs for

The following is a list of all Fibre Channel Host Bus Adapters for

AA986A

A8002A

A8003A

AE311A

AE312A

AD167A

AD168A

AB429A

AE369A

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 33

QuickSpecs

Options

HP ProLiant ML570 Generation 3

HP Uninterruptible Power Systems - Tower

Uninterruptible Power Systems – Rack

HP, T1000 UPS NA

HP, T1000 UPS JPN

HP, T1000 UPS INTL

HP, T1500 UPS NA

HP, T1500 UPS JPN

HP, T1500 UPS INTL

HP, R/T 2200 UPS NA

HP, R/T 2200 UPS JPN

HP, R/T 2200 UPS INTL

HP, R1.5kVA UPS, 1U, NA

HP, R1.5kVA UPS, 1U, INTL

HP, R1.5kVA UPS, 1U, JPN/TW

HP R3000 VA UPS, 2U, DTC, INTL

NOTE:

Replaces non-RoHS compliant part numbers 192186-B31, 192186-B32, 192186-B33, 192186-AR1.

HP R3000 VA UPS, 2U, L5-30, NA

NOTE:

Replaces non-RoHS compliant part number 192186-001.

HP R3000 VA UPS, 2U, L6-20, NA

NOTE:

Replaces non-RoHS compliant part number 192186-002.

HP R3000 VA UPS, 2U, L6-20, JPN

NOTE:

Replaces non-RoHS compliant part number 192186-292.

HP R3000 VA UPS, 2U, L5-30, JPN

NOTE:

HP R5500 VA UPS, INTL

NOTE:

HP R5500 VA UPS, NA/JPN

NOTE:

Replaces non-RoHS compliant part number 192186-291.

Replaces non-RoHS compliant part number 326529-B31.

Replaces non-RoHS compliant part number 326529-D71.

AF403A

AF404A

AF405A

AF406A

AF407A

AF408A

AF409A

AF410A

AF411A

AF419A

AF418A

AF421A

AF414A

AF422A

AF423A

AF424A

AF425A

AF416A

AF426A

HP Monitored Power Distribution Unit

(PDU)

HP Monitored Power Distribution Unit: Full Rack Version

HP 17.3 kVA S2324 Monitored PDU- dual input, 3U, 24A (NA/JPN)

NOTE:

Replaces non-RoHS compliant part number 370959-D71.

HP 8.3 kVA S1324 Monitored PDU- single input, 3U, 24A (NA/JPN)

NOTE:

Replaces non-RoHS compliant part number 370960-D71.

HP 16.6 kVA S2140 Monitored PDU- dual input, 1U, 40A (NA/JPN)

NOTE:

Replaces non-RoHS compliant part number 37061-D71.

HP 8.6 S1140 Monitored PDU- single input, 1U, 40A (NA/JPN)

NOTE:

Replaces non-RoHS compliant part number 370962-D71.

HP 22.1 kVA S2316 Monitored PDU- dual input, 3U, 16A (INTL)

NOTE:

Replaces non-RoHS compliant part number 370963-B31.

HP 11 kVA S1316 Monitored PDU- single input, 3U, 16A (INTL)

NOTE:

Replaces non-RoHS compliant part number 370964-B31.

HP 14.7 kVA S2132 Monitored PDU- dual input, 1U, 32A (INTL)

NOTE:

Replaces non-RoHS compliant part number 370965-B31.

HP 7.3kVA S1132 Monitored PDU- single input, 1U, 32A (INTL)

NOTE:

Replaces non-RoHS compliant part number 370966-B31.

HP Monitored Power Distribution Unit: Half Rack Version

HP 17.3 kVA S348 Monitored PDU- single input, 3-phase, 60A (NA/JPN)

HP 22 kVA S332 Monitored PDU- single input, 3-phase, 32A (INTL)

AF503A

AF504A

AF505A

AF506A

AF507A

AF508A

AF509A

AF510A

AF916A

AF917A

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 34

QuickSpecs

Options

HP ProLiant ML570 Generation 3

Modular PDUs 1U/0U

(Up to 32 outlets)

NOTE:

brackets shipped with the unit (optimized for 10000 and 9000 series racks).

1U/0U mounting

HP 4.9kVA S124 Monitored PDU- single input, 1U, 24A (NA/JPN)

HP 7.3kVA S132 Monitored PDU- single input, 1U, 32A (INTL)

NOTE:

Replaces non-RoHS compliant part number 370966-B31.

3.6kVA Model - mPDU, 16A, High (WW)

2.8 kVA Model - mPDU, 24A, Low (NA/JPN)

4.9kVA Model - mPDU, 24A, High (NA/JPN)

7.3kVA Model - mPDU, 32A, High (INT'L)

8.3kVA Model - mPDU, 40A, High (WW)

8.3kVA Model - mPDU, 40A, High (power cord attached) (NA/JPN)

9.2kVA Model - mPDU, 40A, High (power cord attached) (INTL)

8.3kVA Model - mPDU 40A, High (core only) (NA/JPN)

9.2kVA Model - mPDU 40 A, High (core only) (Int'l)

8.3kVA Model - mPDU 32A, High (core only) (Int'l)

4.9kVA Model - mPDU 24A, High (core only) (NA/JPN)

NOTE:

Modular PDUs) QuickSpecs for additional options including shorter jumper cables and country specific power cords:

http://h18000.www1.hp.com/products/quickspecs/11041_div/11041_div.HTML

(Worldwide)

Please see the following Modular Power Distribution Unit (Zero-U/1U

AF914A

AF915A

252663-B24

252663-D71

252663-D72

252663-B31

252663-B21

252663-D73

252663-B32

252663-D75

252663-B34

252663-B33

252663-D74

USB Options

Rack Conversion Kit

HP Rack 5000 Series

(

Graphite Metallic)

USB 2-Button Optical Scroll Mouse (Carbonite/Silver)

HP USB 04 Standard Keyboard

USB 2.0 4-port HUB

HP 1GB Drive Key II- USB 2.0 Flash Drive

HP 512MB DriveKey II- USB Flash Drive

ProLiant Tower to Rack Conversion Kit

ProLiant Rack to Tower Conversion Kit

HP 5642 Rack-Unassembled

NOTE:

Please see the HP Rack 5642 QuickSpecs for additional part numbers and Technical Specifications such as height, width, depth, weight, and color:

http://h18000.www1.hp.com/products/quickspecs/12074_div/12074_div.HTML

(Worldwide)

NOTE:

For additional information regarding Rack Cabinets, please see the following URL:

www.hp.com/go/rackandpower

DC172B

DT528A#xxx

DG954A

AG382AA

ED516AA

348112-B21

348113-B21

358254-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 35

QuickSpecs

Options

HP ProLiant ML570 Generation 3

HP Rack 10000 G2 Series

(Carbon/Graphite Metallic)

10642 G2 (42U) Rack Cabinet - Pallet

10642 G2 (42U) Rack Cabinet - Shock Pallet

10642 G2 (42U) Rack Cabinet - Crated

10642 G2 (42U) Rack Cabinet, with Extension - Shock Pallet

10636 G2 (36U) Rack Cabinet - Pallet

10636 G2 (36U) Rack Cabinet - Shock Pallet

10636 G2 (36U) Rack Cabinet - Crated

10636 G2 (36U) Rack Cabinet, with Extension - Shock Pallet

10622 G2 (22U) Rack Cabinet - Pallet

10622 G2 (22U) Rack Cabinet - Shock Pallet

10842 G2 (42U) 800mm Wide Rack Cabinet - Pallet

10842 G2 (42U) 800mm Wide Rack Cabinet - Shock Pallet

10647 G2 (47U) Rack Cabinet - Pallet

NOTE:

It is mandatory to use a shock pallet when shipping racks with equipment installed.

NOTE:

Please see the Rack 10000 G2 QuickSpecs for Technical Specifications such as height, width, depth, weight, and color:

http://h18000.www1.hp.com/products/quickspecs/12402_div/12402_div.HTML

(Worldwide)

NOTE:

For additional information regarding Rack Cabinets, please see the following URL:

http://www.hp.com/go/rackandpower

AF001A

AF002A

AF003A

AF004A

AF011A

AF012A

AF013A

AF014A

AF021A

AF022A

AF041A

AF042A

AF031A

HP Rack 10000 Series

(Graphite Metallic)

10642 (42U) Infrastructure Rack (Low Voltage)

10642 (42U) Infrastructure Rack (High Voltage)

HP Rack S10614 (14U) Rack Cabinet – Shock Pallet

HP Rack 10842 (42U, 800mm wide) – Pallet

HP Rack 10842 (42U, 800mm wide) – Shock Pallet

HP Rack 10647 (47U) – Pallet

HP Rack 10647 (47U) – Crated

HP Rack 10622 (22U) – Pallet

HP Rack 10622 (22U) – Shock Pallet

HP Rack 10622 (22U) – Crated

NOTE:

(shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels). xxxxxx-B23 (crated) used for air shipments of empty racks.

NOTE:

equipment installed. Not all HP equipment is qualified to be shipped in the Rack 10000 series

NOTE:

such as height, width, depth, weight, and color:

http://h18000.www1.hp.com/products/quickspecs/10995_div/10995_div.HTML

(Worldwide)

NOTE:

following URL:

xxxxxx-B21 (pallet) used to ship empty racks shipped on a truck. -B22

It is mandatory to use a shock pallet in order to ship racks with

Please see the Rack 10000 QuickSpecs for Technical Specifications

For additional information regarding Rack Cabinets, please see the

http://

www.hp.com/go/rackandpower

379006-001

379005-001

292302-B22

257415-B21

257415-B22

245160-B21

245160-B23

245163-B21

245163-B22

245163-B23

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 36

QuickSpecs

Options

HP ProLiant ML570 Generation 3

Keyboards and Monitors

TFT7210R Rack Mounted 17" Monitor

TFT7600 Rackmount Keyboard Monitor US

TFT7600 Rackmount Keyboard Monitor UK

TFT7600 Rackmount Keyboard Monitor GR

TFT7600 Rackmount Keyboard Monitor FR

TFT7600 Rackmount Keyboard Monitor IT

TFT7600 Rackmount Keyboard Monitor SP

TFT7600 Rackmount Keyboard Monitor DEN

TFT7600 Rackmount Keyboard Monitor NOR

TFT7600 Rackmount Keyboard Monitor SE/FI

TFT7600 Rackmount Keyboard Monitor SWI

TFT7600 Rackmount Keyboard Monitor PORT

TFT7600 Rackmount Keyboard Monitor BEL

TFT7600 Rackmount Keyboard Monitor JPN2

TFT7600 Rackmount Keyboard Monitor RUS

TFT7600 Rackmount Keyboard Monitor INTL

1U Rackmount Keyboard with USB, US

1U Rackmount Keyboard with USB, UK

1U Rackmount Keyboard with USB, GR

1U Rackmount Keyboard with USB, FR

1U Rackmount Keyboard with USB, ITL

1U Rackmount Keyboard with USB, SP

1U Rackmount Keyboard with USB, DEN

1U Rackmount Keyboard with USB, NOR

1U Rackmount Keyboard with USB, SE/FI

1U Rackmount Keyboard with USB, SWI

1U Rackmount Keyboard with USB, PORT

1U Rackmount Keyboard with USB, BEL

1U Rackmount Keyboard with USB, JPN2

1U Rackmount Keyboard with USB, RUS

1U Rackmount Keyboard with USB, INTL

NOTE:

following URL:

For additional information regarding Rack Options, please see the

http://www.hp.com/go/rackandpower

348373-B21

AG052A

AG053A

AG054A

AG055A

AG056A

AG057A

AG058A

AG059A

AG060A

AG061A

AG062A

AG063A

AG064A

AG065A

AG066A

AG072A

AG073A

AG074A

AG075A

AG076A

AG077A

AG078A

AG079A

AG080A

AG081A

AG082A

AG083A

AG084A

AG085A

AG086A

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 37

QuickSpecs

Options

HP ProLiant ML570 Generation 3

HP KVM Switch Options

2x1x16 IP Console Switch with Virtual Media

4x1x16 IP Console Switch with Virtual Media

2x16 Server Console Switch with Virtual Media

PS/2 Virtual Media Interface Adapter, 1 pack

NOTE:

Requires PS/2 and one USB port on server.

Server Console Switch (KVM), 0 x 1 x 8 port

Server Console Switch (KVM), 0 x 2 x 16 port

PS/2 Interface Adapter, 1 pack

PS/2 Interface Adapter, 8 pack

USB Interface Adapter, 1 pack

Serial Interface adapter - 1 Pack with power supply

NOTE:

Switches. Cat5e cables can be found at the following URL:

http://www.hp.com/go/kvm

HP 1x 4 Console Switch

PS2 Server Console Cable, 6 ft, 2 pack

USB Server Console Cable, 6 ft, 2 pack

NOTE:

servers, rack mount monitors, keyboards and all related options please see the following URL:

Cat5e cables are required to connect Interface Adapters to Console

For additional information regarding KVM switches, Serial Console

http://www.hp.com/go/kvm

AF601A

AF602A

AF600A

AF604A

336044-B21

336045-B21

262588-B21

262587-B21

336047-B21

373035-B21

AF611A

AF612A

AF613A

HP Serial Console Server Options

Service and Support Offerings

Pack Services)

(HP Care

HP 16 Port Serial Console Server (worldwide)

HP 48 Port Serial Console Server (worldwide)

Serial Adapter, RJ45-DB9 DCE Female, 1 Pack

Serial Adapter, RJ45-DB9 DCE Female, 8 Pack

NOTE:

Cat5e cables are required to connect Serial Adapters to Serial Console Servers. Additional Serial Adapters and Cat5e cables can be found at the following URL:

NOTE:

For additional information regarding KVM switches, Serial Console servers, rack mount monitors, keyboards and all related options please see the following URL:

Hardware Services On-site Service

4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic

4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic

6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic

Installation & Start-up Services

Hardware Installation, Electronic

Installation & Start-Up of a ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays, Electronic

http://www.hp.com/go/kvm

AF101A

AF102A

AF103A

AF110A

U4591E

U4592E

U4593E

U4601E

U4602E

Support Plus

Onsite HW support, 8am-9pm, M-F, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 8am-9pm, M-F 2hr response time excl. HP holidays, Electronic

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

U4603E

Page 38

QuickSpecs

Options

Support Plus 24

Onsite HW support 24x7, 4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic

Onsite HW support 24x7, 4hr response and SuSE Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic

Onsite HW support 24x7, 4hr response and Red Hat ES Linux SW Tech support offsite, onsite at HP's discretion, 24x7 2hr response time incl. HP holidays, Electronic

HP ProLiant ML570 Generation 3

U4604E

U6314E

U9237E

NOTE:

http://www.hp.com/services/carepack

For more information, customer/resellers can contact

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 39

QuickSpecs

HP ProLiant ML570 Generation 3

Memory

HP ProLiant ML570 G3 - 7040, 3.33 GHz and 3.00 GHz 1P Tower Models and all 7020, 2.83 GHz, 3.66 GHz, 3.16 GHz Models

NOTE: Memory configurations listed do not apply to "Factory Integrated Models".

Standard Memory

1 GB PC2-3200R MHz Registered ECC SDRAM DIMM installed (2 x 512 MB SDRAM DIMM)

Standard Memory Plus Optional Memory

Up to 57 GB of memory is available with the optional installation of 4 GB DIMMs.

Standard Memory Replaced with Optional Memory

Up to 64 GB of memory is available with the removal of the standard 1024 MB of memory and the optional installation of 4 GB DIMMs.

Loads:

Single rank (SR) DIMM => 1 load Dual rank (DR) DIMM => 2 loads

DIMMs must be installed in pairs on board.

Each DIMM pair must be identical, e.g. both SR or both DR, and same capacity, technology and density. Each HP ProLiant ML570 G3 memory board supports 8 loads, thus valid maximum DIMM configurations per memory board for the HP ProLiant ML570 G3 are:

6 SR DIMMs = 6 loads, or

4 DR DIMMs = 8 loads, or

2 DR DIMMS + 4 SR DIMMs = 8 loads Advance Memory Protection support

Online Spare is supported with 1, 2, 3 or 4 boards

Each board can failover to its Online Spare Bank independent of the other memory boards. The minimum valid Online Spare configuration for a memory board requires at least one bank of dual-rank DIMMs or two banks of single-rank DIMMs. HP Recommends (for maximum memory usage efficiency):

If only single -rank DIMMs are used on a memory board, all DIMMs should be of the same size on that memory board. If only dual-rank DIMMs are used on a memory board, all DIMMs should be of the same size on that memory board. If a mixture of single- and dual-rank DIMMs are used on a memory board, the dual-rank DIMMs should be two times (2x) the size of any single-rank DIMM

Hot-Plug Mirrored Memory is supported with 2 or 4 boards

Memory boards within a mirrored pair must have the same amount of total memory. However, each board of the mirrored pair may have different DIMM configurations as long as they have equal total size. The amount of memory between mirrored pairs can be different in quadboard Mirrored Memory mode.

Hot-Plug RAID Memory is only supported with 4 boards

All four memory boards must have the same amount of total memory. However, each board may have different DIMM configurations as long as they have equal total size

NOTE: NOTE:

This chart does not represent all possible memory configurations.

Four memory boards would be required to configure up to 57GB or maximum memory using 4GB DIMMs.

Standard

Optional

Maximum

Standard

Optional

Maximum

Memory

1 2 3 4 5 6

1 GB 512 MB 512 MB 57 GB 64 GB

1 GB 57 GB 64 GB

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

512 MB 512 MB 4 GB 4 GB

4 GB 4 GB 4 GB 4 GB

7 8 9 10 11 12

Empty Empty Empty Empty Empty Empty

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

Empty Empty Empty Empty

Slot

Empty Empty Empty Empty

Page 40

QuickSpecs

Memory

HP ProLiant ML570 Generation 3

Memory

13 14 15 16 17 18

Empty Empty Empty Empty Empty Empty

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

19 20 21 22 23 24

Empty Empty Empty Empty Empty Empty

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

Standard

Optional

Maximum

Standard

Optional

Maximum

1 GB 57 GB 64 GB

Memory

1 GB 57 GB 64 GB

Following are memory options available from HP:

8 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 4 GB) Dual Rank

4 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 2 GB) Dual Rank

4 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 2 GB) Single Rank

2 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 1 GB)

1 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 512 MB)

Hot-plug Memory Expansion Board

HP ProLiant ML570 G3 - 7040, 3.33 GHz and 3.00 GHz 2P Rack Models

NOTE

: Memory configurations listed do not apply to "Factory Integrated Models".

Slot

Empty Empty Empty Empty

Slot

Empty Empty Empty Empty

348106-B21

375004-B21

343057-B21

343056-B21

343055-B21

348107-B21

Standard Memory

2 GB PC2-3200R MHz Registered ECC SDRAM DIMM installed (4 x 512 MB SDRAM DIMM)

Standard Memory Plus Optional Memory

Up to 58 GB of memory is available with the optional installation of 4 GB DIMMs.

Standard Memory Replaced with Optional Memory

Up to 64 GB of memory is available with the removal of the standard 2GB of memory and the optional installation of 4 GB DIMMs.

NOTE: NOTE:

This chart does not represent all possible memory configurations.

Four memory boards would be required to configure up to 58 GB or maximum memory using 4 GB DIMMs.

Standard

Optional

Maximum

Standard

Optional

Maximum

Memory

1 2 3 4 5 6

2 GB 512 MB 512 MB 512 MB 512 MB 58 GB 64 GB

2 GB 58 GB 64 GB

512 MB 512 MB 512 MB 512 MB 4 GB 4 GB

4 GB 4 GB 4 GB 4 GB

7 8 9 10 11 12

Empty Empty Empty Empty Empty Empty

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

Slot

Empty Empty

Slot

Empty Empty Empty Empty

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 41

QuickSpecs

Memory

HP ProLiant ML570 Generation 3

Memory

13 14 15 16 17 18

Empty Empty Empty Empty Empty Empty

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

19 20 21 22 23 24

Empty Empty Empty Empty Empty Empty

4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB 4 GB

Standard

Optional

Maximum

Standard

Optional

Maximum

2 GB 58 GB 64 GB

Memory

2 GB 58 GB 64 GB

Following are memory options available from HP:

8 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 4 GB) Dual Rank

4 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 2 GB) Dual Rank

4 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 2 GB) Single Rank

2 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 1 GB)

1 GB PC2-3200R Registered ECC SDRAM Memory Kit (2 x 512 MB)

Hot-plug Memory Expansion Board

Slot

Empty Empty Empty Empty

Slot

Empty Empty Empty Empty

348106-B21

375004-B21

343057-B21

343056-B21

343055-B21

348107-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 42

QuickSpecs

Storage

1-inch Drive Locations

0-7, 0-1

SFF SAS Drive Locations

Ten Ultra320 SCSI Drive Bays (8 on one channel, 2 on another)

1.44-MB Slimline Diskette Drive (optional)

8x/24x IDE Slimline DVD-ROM

One available removable media bay for storage. A half-height tape drive or a USB tape drive may be installed in the removable media bay.

HP ProLiant ML570 Generation 3

1-18

Eighteen SFF SAS Drive Bays

1.44-MB Slimline Diskette Drive (optional)

8x/24x IDE Slimline DVD-ROM

One available removable media bay for storage. A half-height tape drive or a USB tape drive may be installed in the removable media bay.

Drive Support

Hard Drives

Ultra320 Hot Pluggable Drives

300GB U320 10K 146GB U320 10K 72GB U320 10K 300GB U320 15K 146GB U320 15K 72GB U320 15K 36GB U320 15K

NOTE:

Smart Array Controller or U320 SCSI HBA to support U320 transfer rates.

All U320 Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives require an optional U320

Quantity Supported

Up to 10

Position Supported

0-7 and 0-1

Controller

Integrated Dual Channel Ultra320 SCSI Adapter Smart Array 6402/128 Controller Smart Array 6404/256 Controller Smart Array 641 Controller Smart Array 642 Controller

SFF SATA Hot Pluggable Drives

120GB 1.5G SATA 5.4K 60GB 1.5G SATA 5.4K

Quantity Supported

Up to 18

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Position Supported

1-18

Controller

HP Smart Array P600/256 BBWC Controller

Page 43

QuickSpecs

Storage

SFF SAS Hot Pluggable Drives

146GB 3G SAS 10K SP 72GB 3G SAS 10K SP 72GB 3G SAS 15K SP 36GB 3G SAS 10K SP 36GB 3G SAS 15K SP

NOTE:

upgraded SAS Drive Cage Option Kit.

External Storage

SAS Drives supported by the HP ProLiant ML570 G3 SAS Models only or with HP ProLiant ML570 G3 model

Modular Smart Array 30 Family

Modular Smart Array 50 Enclosure

Modular Smart Array 1000

Modular Smart Array 1500 cs

Quantity Supported

Up to 18

Quantity Supported

Up to 28

Up to 2

Please see the Modular Smart Array 1000 QuickSpecs below to determine configuration requirements

Please see the Modular Smart Array 1500 cs QuickSpecs below to determine configuration requirements

Position Supported

1-18

Position Supported

External

HP ProLiant ML570 Generation 3

Controller

HP Smart Array P600/256 BBWC Controller

Host Controller or Adapter

Smart Array 6402/128 Controller Smart Array 6404/256 Controller Smart Array 642 Controller

HP Smart Array P600/256 BBWC Controller

Please see the Modular Smart Array 1000 QuickSpecs for the latest list of supported HBAs:

http://www.hp.com/go/MSA1000

Please see the Modular Smart Array 1500 cs QuickSpecs for the latest list of supported HBAs:

http://www.hp.com/go/MSA1500cs

Maximum Storage Capacity

PCI-X slots & MSA30 enclosures)

Internal

External

Total

Maximum Storage Capacity SAS Models

enclosures)

Internal

External

Total

Tape Drives, Tape Autoloaders, & Tape Libraries

NOTE:

For an up-to-date listing of the latest O/S Support details for each of the Tape Drives listed below, please see the

– (ML570 10 Bay Hot Plug Ultra320 SCSI Drive Cage, 4 channel controller in 4 full-length

3.00TB ((10 x 300GB) Ultra320 SCSI Drives)

67.20TB hot plug SCSI storage (16 x (14 x 300GB Ultra320 SCSI Drives))

70.20TB

– (ML570 SFF SAS Drive Cage, 8 port SAS controller in 4 slots & MSA50

2.628TB ((18 x 146GB) SFF SAS Drives)

11.680TB hot plug SFF SAS storage (4 x (20 x 146GB SFF SAS Drives))

14.308TB

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 44

QuickSpecs

Storage

following:

http://h18000.www1.hp.com/products/quickspecs/Division/10233.html

NOTE:

For an up-to-date listing of the latest O/S Support details for each of the Tape Autoloaders and Tape Libraries listed below, please see the following:

http://h18000.www1.hp.com/products/quickspecs/Division/10809.html

NOTE:

For complete listing of tape drive offerings see

http://www.hp.com/products1/storage/compatibility/tapebackup/ISS/index.html

HP StorageWorks Tape Drives, Internal

DAT 24 USB DAT 40 USB DAT 72 USB

HP StorageWorks Tape Drives, External

DAT 24 USB DAT 40 USB DAT 72 USB

HP StorageWorks Tape Drives, Internal

Ultrium 232 Ultrium 448 Ultrium 920 DAT 40 DAT 72 DLT VS160

HP StorageWorks Tape Drives, Internal

Ultrium 460 Ultrium 960 SDLT 600

HP StorageWorks Tape Drives, External

Ultrium 232 Ultrium 448 Ultrium 460 Ultrium 920 Ultrium 960 DAT 40 DAT 72 DLT VS160 SDLT 600

HP StorageWorks Autoloaders, External

DAT 72x10 Autoloader 1/8 G2 Tape Autoloader

Position

Supported

B or C

External

B or C

External

Controller

USB 2.0 Port

64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2

(Worldwide)

HP ProLiant ML570 Generation 3

Controller Part

Number

N/A

374654-B21

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 45

QuickSpecs

Storage

HP ProLiant ML570 Generation 3

HP StorageWorks SCSI Rack-Mount Tape Drive Enclosures

1U Rack-Mount Kit 3U Rack-Mount Kit

HP StorageWorks USB Rack-Mount Tape Drive Enclosures

1U Rack-Mount Kit

HP StorageWorks Tape Libraries, External

MSL2024 (Ultrium 448, Ultrium 920 and 960based) MSL4048 (Ultrium 448, Ultrium 920 and 960based) MSL6000 (Ultrium 960 and 460-based) MSL6000 (SDLT 600based)

External

64-Bit/133-MHz Single Channel Ultra320 SCSI HBA G2

USB 2.0 Port

Please consult the EBS connectivity matrix at

http://www.hp.com/go/ebs

for detailed connectivity information.

374654-B21

N/A

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 46

QuickSpecs

Power Specifications

HP ProLiant ML570 Generation 3

Part Number

Spare Kit

Operational Input Voltage Range (Vrms)

Frequency Range (Nominal) (Hz)

Nominal Input Voltage (Vrms)

Max Rated Output Wattage Rating Nominal Input Current (A rms) Max Rated Input Wattage Rating (Watts) Max. Rated VA (Volt-Amp) Efficiency (%) Power Factor Leakage Current (mA) Maximum Inrush Current (A peak) Maximum Inrush Current duration (mS)

337867-001

364360-001

90 to 264

47 to 63 (50/60)

100 115 208 220 230 240

910 910 1300 1300 1300 1300

11.9 10.2 1163 1148 1566 1566 1548 1548 1186 1172 1598 1598 1579 1579

80 81 83 83 84 84

0.98 0.98 0.98 0.98 0.98 0.98

0.43 0.50 0.90 0.96 1.00 1.04

100 100 100 100 100 100

10 10 10 10 10 10

7.7 7.3 6.9 6.6

System Specifications

To determine power specifications for various system configurations, please use the online HP Power Calculator Tool referenced below.

Power cord requirements

NOTES:

Tower model comes with local power cord

Rack models come with PDU jumper cord and/or local power cord.

Option no. See chart below Spare no. See chart below

* - To review typical system power ratings use the Active Answers Power Calculator which is available via the online tool located at URL:

- Click on the Power Calculator for the server of interest. Example: ML570 G3

- There are certain Dual-core, lowline, max configurations that are not supported. All highline configurations are supported. Consult the Power Calculator to determine if your lowline configuration is supported.

http://h30099.www3.hp.com/configurator/calc/power%20calculator%20catalog.xls

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 47

QuickSpecs

Power Specifications

HP ProLiant ML570 Generation 3

Standard Tower Model Power Cords

Asia Pacific

Australia

Brazil

Europe

France

Germany

Japan

USA

PRC

Standard Rack Model Power Cords

Asia Pacific

Europe

Japan

PRC

USA

Optional Country Power Cords and Jumper Cords

Australia/New Zealand

Denmark/Switzerland

Europe

Italy

South Africa/India

Description

CEE 7-VII to IEC320-C19

JIS C8303 to IEC320-C19

BS1363 to IEC320-C19

AS/NZS 3112 to IEC320-C19

Nema 5-15P to IEC320-C19

CEE 7-VII to IEC320-C19

JIS C8303 to IEC320-C19

BS1363 to IEC320-C19

Nema 5-15P to IEC320-C19

AS/NZS 3112 to IEC320-C19

JIS C8303 to IEC320-C19

BS1363 to IEC320-C19

Description

IEC320-C14 to IEC320-C19

JIS C8303 to IEC320-C19

IEC320-C14 to IEC320-C19

Nema 5-15P to IEC320-C19

IEC320-C14 to IEC320-C19

Description

AS/NZS 3112 to IEC320-C19

IEC320-C19, Industrial

CEE 7-VII to IEC320-C19

IEC320-C19, Italy

IEC320-C19, SA

BS1363 to IEC320-C19

Nema 5-15P to IEC320-C19

Nema 6-20P to IEC320-C19

IEC320-C19, 20A, 250V, US

IEC320-C14 to IEC320-C19 Jumper (10A, IEC, 6ft/2.0m)

IEC320-C14 to IEC320-C19 Jumper (10A, IEC, 12ft/3.6m)

IEC320-C19 to IEC320-C20 Jumper (16A, IEC, 8ft/2.5m)

Option Power Cord Part Number

305340-011

305340-081

305340-021

305340-061

305340-AR1

305340-031

235603-001

235604-001

340653-001

313227-B21

313228-B21

295633-B22

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 48

QuickSpecs

Technical Specifications

HP ProLiant ML570 Generation 3

System Unit

Tower Dimensions

(HxWxD) (with feet/bezel)

Rack Dimensions

(HxWxD) (with bezel)

Maximum Weight

Input Requirements

(per power supply)

BTU Rating

SCSI Connectors

Power Supply Output Power

supply)

Temperature Range

Relative Humidity

condensing)

Maximum Wet Bulb Temperature

Acoustic Noise

(per power

(non-

20 x 11.1 x 28.8 in (50.8 x 28.2 x 73.2 cm)

11.1 x 19.0 x 28.0 in (28.2 x 48.3 x 71.1 cm)

137 lb (62.14 kg)

Range Input Voltage

Rated Input Frequency

Input Power

Rated Input Current

BTU/hr (max)

Two internal HD68 connectors (supporting Ultra320)

One external VHDCI connector (supporting Ultra320)

One SCSI knockout

Rated Steady-State Power

Maximum Peak Power

Operating

Non-operating

Shipping

Operating

Non-operating

101.7° F (38.7° C)

Listed are the declared A-WEIGHTED SOUND POWER (LWAd) and average bystander position A-WEIGHTED SOUND PRESSURE LEVEL (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74, 7th edition) and declared in accordance with ISO 9296 (ECMA 109).

100 to 127 VAC/200 to 240 VAC

47 to 63 Hz

1163W @ 110 VAC; 1598W @ 200 VAC

12A / 8A

5457 BTU/hr

910W/1300W

960W/1420W for 10 sec max

50° to 95° F (10° to 35° C)

-20° to 140° F (-29° to 60° C)

-22° to 122° F (-30° to 50° C)

10% to 70%

5% to 95%

Idle and Operating (Maximum configuration): LWAd = 7.5 Bels, Average Bystander LpAm = 56 dBA (Note 1)

NOTE:

The values listed apply to both the tower and 6U rack configurations. Maximum configuration tested included four Xeon MP processors, ten SCSI hard drives, two power supplies, and six inlet fans.

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 49

QuickSpecs

Technical Specifications

HP ProLiant ML570 Generation 3

Slimline CD-RW/DVDROM 8X/24X Combo Drive

(Multibay)

Disk

Block Size

Access Times

Diameter

Thickness

Track pitch

Data Transfer Rate

Cache Buffer

Start-up Time

Stop Time

Laser Parameters

Output Power

Operating Conditions

Dimensions

(typical)

Disk formats

Capacity

Mode 0

Mode 1

Mode 2

DVD

Random

Full-Stroke

12 cm, 8 cm (4.70 in, 3.15 in)

1.2 mm (0.05 in)

0.74 µm (3.15 x 10-7 in) DVD-ROM

1.6 µm (6.3 x 10-7 in) CD-ROM

Sustained

Burst

< 10 seconds

< 5 seconds (single); < 30 seconds (multisession)

Type

Wave Length

Divergence angle

0.14 mW

Temperature

Humidity

(HxWxD, maximum)

Weight

DVD (single and double layer), DVD-5, DVD9, DVD-10, DVD-R, CD-ROM Mode 1 & 2, CD-DA, CD-XA (mode 2, Form 1 & 2), CD-I (Mode 2, Form 1 & 2), CD-I ready, CD-Bridge, CD-R, Photo CD( single and multi-session)

4.7 GB (DVD-5), 8.5 GB (DVD-9), 9.4 GB (DVD-10), 550MB (Mode 1, 12 cm), 640 MB (Mode 2, 12 cm), 180 MB (8 cm)

2352 bytes

2352, 2340, 2336, 2048 bytes

2048 bytes

<110 ms CD <180 ms DVD

<200 ms CD <300 ms DVD

4463 - 10,800 KB/2 (8x CAV DVD mode), 150 KB/s (sustained 1x CD-ROM), 1552 - 3600 KB/s (24x CAV CD-ROM)

16.6 MB/s with DMA support

Semiconductor Laser GaAs

700 ± 25 nm

53.5° ± 1.5°

41° to 118° F (5° to 45° C)

5% to 90%

0.5 x 5.2 x 5.2 in (12.7 x 132.08 x 132.08 mm)

0.75 lb (0.34 kg)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 50

QuickSpecs

Technical Specifications

HP ProLiant ML570 Generation 3

Embedded NC7782 PCI-X Gigabit Server Adapter

Network Interface

Compatibility

Data Transfer Method

Network Transfer Rate

Connector

Cable Support

10Base-T/100Base-TX/1000Base-TX

IEEE 802.3 10Base-T IEEE 802.3ab 1000Base-T IEEE 802.3u 100Base-TX

64-bit bus-master PCI-X

10Base-T (Half-Duplex)

10Base-T (Full-Duplex)

100Base-TX (HalfDuplex)

100Base-TX (FullDuplex)

1000Base-TX (Half and Full-Duplex)

Two RJ-45

10Base-T

100Base-TX

1000Base-TX

10 Mb/s

20 Mb/s

100 Mb/s

200 Mb/s

2000 Mb/s

Categories 3, 4 or 5 UTP; up to 328 ft (100 m)

Category 5 or higher UTP; up to 328 ft (100 m)

Smart Array P600 Controller

(SAS models only)

Disk Drive and Enclosure Protocol Support

Architecture

SAS Connectors

Data Transfer Method

PCI Bus Speed

Memory Bus Speed

PCI

Simultaneous Drive Transfer Ports

Port Transfer Rate

Software upgradeable Firmware

Cache Memory

Logical Drives Supported

Maximum Capacity

Memory Addressing

RAID Support

3 Gbps SAS (Serial Attached SCSI)

1.5 Gbps SATA (Serial AT Attachment)

1.5 Gb SATA

1 internal SFF8484 & 1 external SFF8470 / internal SFF8484 shared x4 Wide SAS Ports 12 Gbps per x4 Wide SAS Port (4 x 3 Gbps)

64-bit wide, PCIX 133 MHz (1 GB/s maximum bandwidth)

PCIX-133 and 3.3 volt PCI compatibility only

DDR-266 and 72 bit wide bus

64-bit, 133-MHz PCI-X (1 GB/s maximum bandwidth)

PCI-X and 3.3 volt PCI compatibility only

2 x4 Wide SAS Ports

12 Gb/s per x4 Wide SAS Port (4 x 3 Gb/s)

Yes

256 MB Read/Write (512-MB module upgrade available); ECC protection, battery-backed, and removable

Up to 32 logical drives Up to 2.2 TB per logical drive

2.7 TB (38 x 72 GB) 64-bit, supporting servers memory greater than 4 GB

RAID 6 (Advanced Data Guarding) RAID 5 (Distributed Data Guarding) RAID 1+0 (Striping & Mirroring) RAID 0 (Striping)

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 51

QuickSpecs

Technical Specifications

HP ProLiant ML570 Generation 3

Upgradeable Firmware Disk Drive and

Enclosure Protocol Support

Integrated Dual Channel Ultra320 SCSI Adapter

The information contained herein is subject to change without notice.

Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation.

Drives Supported

Data Transfer Method

SCSI Channel Transfer Rate

Maximum Transfer Rate per PCI Bus (peak)

SCSI Termination

SCSI Connectors

4-MB flashable ROM

3 Gb SAS and 1.5 Gb SATA

Up to 15 SCSI devices per channel

64-bit PCI bus-master

320 MB/s per channel

400 MB/s

Active Termination

1 external (VHDCI), 2 internal (68-pin)

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.

DA - 12201 Worldwide QuickSpecs — Version 32 — 3.30.2007

Page 52

HP ML570 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Models

Configuration Information - Factory Integrated Models (North America only)

Options

Memory

Storage

Power Specifications

Technical Specifications
