QuickSpecs

Overview

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 G5 Model (tower)

HP ProLiant ML370 G5 Model (tower)HP ProLiant ML370 G5 Model (tower)

Front View:

Front View:Front View:

System Insight Display (SID)

Media Bay Spacer (Tower)/Video Connector (Rack)

DVD-ROM Drive

Removable Media Bays

Front Bezel (Tower Model Only)

Hard Drive Bays 1-8 (Serial-attached SCSI (SAS) drives supported - SFF)

Hard Drive Bays 9-16 - Optional Drive Cage (Serialattached SCSI (SAS) drives supported - SFF)

Integrated RAID Controller Slot

(2) PCI-X 64 Bit/133MHz Slot

10.

(6) PCI-Express x4 Slot

11.

(8) PC2-5300 Fully Buffered DIMM Slots per memory card

- Standard

12.

(8) PC2-5300 Fully Buffered DIMM Slots per memory card

- Optional

13.

Dual-Core Intel Xeon processor - Optional

14.

Dual-Core Intel Xeon processor - Standard (2 processors standard on all Performance Models)

15.

(3) Hot Plug Redundant Fans - Standard

16.

(3) Hot Plug Redundant Fans - Optional

Rear View:

Rear View:Rear View:

Keyboard connector

Mouse connector

USB connectors

Integrated Lights-Out 2 (iLO 2) management connector

Video connector

Serial connector

NIC 2 connector

PCI expansion slots

Hot-plug power supply (primary bay)

10.

Hot-plug power supply blank (redundant bay)

11.

NIC 1 connector

12.

T-15 Torx screwdriver

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 1

QuickSpecs

Overview

Front View:

Front View:Front View:

System Insight Display (SID)

Video Connector

DVD/CD-ROM Drive

Removable Media Bays

Hard Drive Bays 1-8 (Serial-attached SCSI (SAS) drives supported - SFF)

Hard Drive Bays 9-16 - Optional Drive Cage (Serialattached SCSI (SAS) drives supported - SFF)

Rack Handles

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 G5 Model (Rack)

HP ProLiant ML370 G5 Model (Rack)HP ProLiant ML370 G5 Model (Rack)

Rear View:

Rear View:Rear View:

Keyboard connector

Mouse connector

USB connectors

Integrated Lights-Out 2 (iLO 2) management connector

Video connector

Serial connector

NIC 2 connector

PCI expansion slots

Hot-plug power supply (primary bay)

10.

Hot-plug power supply blank (redundant bay)

11.

NIC 1 connector

12.

T-15 Torx screwdriver

What's New

What's NewWhat's New

Support for:

HP 500GB 6G SAS 7.2K SFF DP MDL HDD HP 500GB 3G SATA 7.2K 2.5in MDL HDD HP 160GB 3G SATA 7.2K 2.5in MDL HDD

At A Glance

At A GlanceAt A Glance

The flagship ML370 G5 provides industry-leading management, performance and availability in a dual processor expansion server engineered to excel in a variety of environments - from corporate work groups in growing businesses to critical remote sites requiring continuous accessibility and uptime.

Processors:

Processors:Processors:

Quad-core Intel® Xeon® 5400 sequence processors with 12MB Level 2 cache (6MB per die) for blazing performance Servers support up to 2 processors (2 processors standard on all Performance models)

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 2

QuickSpecs

Overview

Preconfigured Performance models save valuable deployment time at a discounted bundle price Intel® 5000P chipset

Memory:

Memory:Memory:

Maximum 64 GB of PC2-5300 Fully Buffered DIMMs (DDR2-667) running at 667MHz of 4:1 interleaved memory with Advanced ECC capabilities including Online Spare and Mirrored Memory (8 FB DIMMs per memory card; up to 2 supported)

NOTE:

Memory DIMMs in systems with the Front Side Bus (FSB) running at 1333 MHz will run at 667 MHz and in

NOTE:NOTE: systems with a FSB running at 1066 MHz or 667 MHz the memory DIMMs will run at 533 MHz.

Storage Controller:

Storage Controller:Storage Controller:

Base Models: HP Smart Array P400/256MB Controller Performance Models: HP Smart Array P400/512MB BBWC Controller Entry Models: HP Smart Array E200/64MB Controller

Internal Drive Support:

Internal Drive Support:Internal Drive Support:

Up to (16) hot-plug Serial-attached SCSI (SAS) drives supported (8) drive bays in standard configurations Optional 8-bay drive cage available for maximum storage support (2nd drive bay cage will require additional SAS controller) Two open half-height media bays; supports full height or half height internal tape drive

Network Controller:

Network Controller:Network Controller:

Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine, including support for Accelerated iSCSI through an optional Licensing Kit

Expansion Slots:

Expansion Slots:Expansion Slots:

Nine total expansion slots Eight available: (6) PCI-Express x4 and (2) PCI-X 64-Bit/133MHz

USB Ports:

USB Ports:USB Ports:

USB 2.0 support Six total ports: (2) ports up front; (2) ports in back; (2) ports internal (one standard connection and one USB tape connection)

Redundancy:

Redundancy:Redundancy:

Optional Hot plug redundant power supplies and cooling fans Hot plug redundant fans and power supplies included on all Performance models

Infrastructure Management

Infrastructure ManagementInfrastructure Management

Convenient slide-out Systems Insight Display for quick and easy front view server diagnostics, along with status LEDs, Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU) HP ProLiant Onboard Administrator (powered by the HP Integrated Lights-Out 2 management processor) for simplified server setup, health monitoring and recovery, power and thermal control, and lights-out remote administration. HP Insight Control a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, control and optimize your IT infrastructure through a single, simple management console. Insight Control supports both Windows and Linux-based central management servers. HP Insight Dynamics for ProLiant, a product option, is an integrated command center that enables IT Staff personnel to continuously analyze and optimize a converged infrastructure, while automating and reducing the cost of common data center tasks by as much as 40 percent. This ultimately enables them to dynamically keep pace with the organization's changing business requirements.

Form Factor:

Form Factor:Form Factor:

5U tower and rack models available (front VGA connection on rack models)

Operating Systems and Virtualization Software Support for ProLiant Servers

Operating Systems and Virtualization Software Support for ProLiant ServersOperating Systems and Virtualization Software Support for ProLiant Servers

Supports Windows, RHEL, SLES, OEL, Solaris, VMware, and Citrix

Deployment/Serviceability:

Deployment/Serviceability:Deployment/Serviceability:

System Insight Display on the front bezel for quick and easy server diagnostics Quick Deploy Rail System includes sliding universal rails, an ambidextrous cable management arm and quick release levers Tool-less access to all system components for easy in-rack serviceability

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 3

QuickSpecs

Overview

Customer Self Repair (CSR): HP products are designed with many CSR parts to minimize repair time and allow for greater flexibility in performing defective parts replacement

Warranty:

Warranty:Warranty:

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE:

NOTE: NOTE: Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:

http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response.

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 4

QuickSpecs

Standard Features

NOTE:

For a brief, printer friendly data sheet that describes this product and informs you of the essential capabilities and

NOTE:NOTE: specifications, please visit: NOTE:

NOTE:

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory

NOTE:NOTE: Integrated Models" section.

Processor

ProcessorProcessor

One of the following depending on Model

http://h71028.www7.hp.com/ERC/downloads/4AA0-6361ENW.pdf

Quad-Core Processors

Quad-Core ProcessorsQuad-Core Processors Quad-Core Intel® Xeon® Processor X5470 (3.33 GHz, 120 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor X5450 (3.00 GHz, 120 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5450 (3.00 GHz, 80 Watts, 1333 FSB)

NOTE:

NOTE: NOTE:

Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5420 (2.50 GHz, 80 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5410 (2.33 GHz, 80 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor X5365 (3.00 GHz, 120 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor X5355 (2.66 GHz, 120 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5345 (2.33 GHz, 80 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5335 (2.00 GHz, 80 Watts, 1333 FSB) Quad-Core Intel® Xeon® Processor E5320 (1.86 GHz, 80 Watts, 1066 FSB) Quad-Core Intel® Xeon® Processor E5310 (1.60 GHz, 80 Watts, 1066 FSB) Dual-Core Processors

Dual-Core Processors

Dual-Core ProcessorsDual-Core Processors Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333 FSB) Dual-Core Intel® Xeon® Processor L5240 (3.00 GHz, 40 Watts, 1333 FSB) Dual-Core Intel® Xeon® Processor X5160 (3.0 GHz, 80 Watts, 1333 FSB) Dual-Core Intel® Xeon® Processor X5150 (2.67 GHz, 65 Watts, 1333 FSB) Dual-Core Intel® Xeon® Processor X5140 (2.33 GHz, 65 Watts, 1333 FSB) Dual-Core Intel® Xeon® Processor X5130 (2.0 GHz, 65 Watts, 1333 FSB) Dual-Core Intel® Xeon® Processor X5120 (1.86 GHz, 65 Watts, 1066 FSB) Dual-Core Intel® Xeon® Processor X5110 (1.6 GHz, 65 Watts, 1066 FSB)

NOTE:

NOTE: NOTE: NOTE:

NOTE:

Please contact your regional sales support to determine Quad-Core upgradeability. Some of the

NOTE:NOTE: earlier shipping models may not support upgrades to 5400/5400 Quad-Core processors. 5100 DualCore models are not upgradeable to the 5200 Dual-Core processors.

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

Available via Configure-to-order only. See Factory Integrated Models section for more details.

Up to 2 processors supported. Performance configurations include two processors.

Cache Memory

Cache MemoryCache Memory

One of the following depending on Model

4 MB (2 x 2 MB) Level 2 cache (5000 series) 4 MB (1 x 4 MB) Level 2 cache (5100 series) 6 MB (1x 6 MB) Level 2 cache (5200 series) 8 MB (2 x 4 MB) Level 2 cache (5300 series) 12 MB (2 x 6 MB) Level 2 cache (5400 series)

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 5

QuickSpecs

Standard Features

Chipset

ChipsetChipset

Memory Protection

Memory ProtectionMemory Protection

Memory

MemoryMemory

One of the following depending on Model

Intel® 5000P Chipset

NOTE:

For more information regarding Intel chipsets, please see the following URL:

NOTE:NOTE:

http://www.intel.com/products/server/chipsets/

Advanced ECC, Online Spare and Mirroring

NOTE:

Mirroring requires optional 2nd memory card.

NOTE:NOTE:

Type

Standard

(Entry Models)

Standard

(Base Models)

Standard

(Performance Models)

Maximum

NOTE:

NOTE: NOTE: MHz and in systems with a FSB running at 1066 MHz or 667 MHz the memory DIMMs will run at 533 MHz.

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

PC2-5300 Fully Buffered DIMMs (DDR2-667) running at 533 MHz with 4:1 interleaving

NOTE:

4-way interleaving requires optional 2nd memory card.

NOTE:NOTE:

1 GB (2 x 512 MB)

2 GB (2 x 1 GB)

4 GB (4 x 1 GB)

64 GB (16 x 4 GB with 2 memory cards)

Memory DIMMs in systems with the Front Side Bus (FSB) running at 1333 MHz will run at 667

Network Controller

Network ControllerNetwork Controller

Expansion Slots

Expansion SlotsExpansion Slots

Two embedded NC373i Multifunction Gigabit Network Adapters with TCP/IP Offload Engine, including support for Accelerated iSCSI through an optional Licensing Kit

Expansion

ExpansionExpansion

Slot #

Slot #Slot #

Technology

TechnologyTechnology

PCIe

PCI-X

(133MHz, 3.3

Volt)

PCI-X

(133MHz, 3.3

Volt) PCIe

PCIe

Width

WidthWidth

x4 x8

64-bit

x4 x8

Connector

ConnectorConnector

applicable

Width

WidthWidth

Not

Bus

BusBus

Number

NumberNumber

Form Factor

Form FactorForm Factor

Full length,

full height slot

Full length,

full height slot

Full length,

full height slot

Full length,

full height slot

Full length,

full height slot

Notes

NotesNotes

Reserved for

integrated

RAID

controller

Shared bus

with slot 3

Shared bus

with slot 2

Optional x8 if

PCIE

expander is

installed in

slot 4

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 6

QuickSpecs

Standard Features

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number. ** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID by bus (starting with the lowest bus).

Storage Controller

Storage ControllerStorage Controller

One of the following depending on Model

Base Models

Base ModelsBase Models

Performance Models

Performance ModelsPerformance Models Entry Models

Entry Models

Entry ModelsEntry Models

PCIe

x4 x8

HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5) Available upgrades:

Available upgrades:

Available upgrades:Available upgrades: battery-backed write cache (BBWC) RAID 0/1/1+0/5/6.

HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6) HP Smart Array E200/64MB Controller (RAID 0/1/1+0)

Available upgrades:

Available upgrades:Available upgrades: for battery-backed write cache (BBWC).

512MB memory BBWC module for, or battery for

128MB memory module for RAID 0/1/1+0/5, battery

Full length,

full height slot

Full length,

full height slot

Full length,

full height slot

Full length,

full height slot

Optional x8 if

PCIE

expander is

installed in

slot 6

Optional x8 if

PCIE

expander is

installed in

slot 8

Storage

StorageStorage

Maximum Internal

Maximum InternalMaximum Internal Storage

Storage

StorageStorage

Diskette Drive Optical Drive

One of the following depending on Model

Hard Drives

Hot Plug SAS

Hot Plug SATA

DA - 12478 Worldwide — Version 49 — November 19, 2009

None standard DVD-ROM Drive (Performance Models) 48x IDE CD-ROM Drive (Base and Entry Models)

NOTE:

NOTE: NOTE: Drive.

None standard

4.0TB

8.0TB

All units after 11/12/2007 will come standard with a DVD-ROM

8 x 500GB with standard 8-bay hot plug Serialattached SCSI (SAS) drive cage

16 x 500GB with optional 2nd SAS drive cage 16 x 500GB

Page 7

QuickSpecs

Standard Features

Intelligent Manageability

Intelligent ManageabilityIntelligent Manageability

Interfaces

InterfacesInterfaces

HP Systems Insight Manager SmartStart Management Agent Redundant ROM Remote Flash ROM ROM-Based Setup Utility (RBSU) Integrated Management Log Automatic Server Recovery (ASR) Dynamic Sector Repairing (with Smart Array controller) Drive Parameter Tracking (with Smart Array controller) Hot Spare Boot

NOTE:

Upon the event of a failed processor in a multi-processing environment, the system will

NOTE:NOTE: automatically reboot and attempt to use the remaining good processor.

Pre-Failure Warranty (covers processors, SAS hard drives and memory)

Serial Pointing Device (Mouse) VGA Keyboard Network RJ-45 iLO 2 remote

management port USB 2.0 Ports

Dedicated USB 2.0 Port

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

1 (2nd serial and parallel port available via option Kit) 1 1 (+1 front VGA on rack models) 1 2 1

5 (2 on the rear, 2 on the front, 1 internal)

NOTE:

NOTE: NOTE: USB support:

http://h18004.www1.hp.com/products/servers/platforms/usb-support.html

1 (available for DAT USB tape connectivity)

NOTE:

NOTE:NOTE: Internal Tape Drives

Please see the following URL for additional information regarding

Internal USB ports are optimal for the attachment of HP DAT USB

Graphics

GraphicsGraphics

Form Factor

Form FactorForm Factor

HP Insight management

HP Insight managementHP Insight management software

software

softwaresoftware

Integrated ATI ES1000, 32 MB video standard

16 bit color: maximum resolution of 1600 x 1200 32 bit color: maximum resolution of 1280 x 1024

NOTE:

Maximum resolution available via iLO 2 remote console is 1280 x 1024.

NOTE:NOTE:

Tower and Rack (5U) models available

HP Insight Foundation

DA - 12478 Worldwide — Version 49 — November 19, 2009

Managing the growing number of servers can be complex and expensive for your organization. IT managers need to address changing business needs with tools that meet the challenges of managing today's complex Datacenters.

HP provides management solutions that are designed to simplify a server's installation, configuration and maintenance throughout the entire server

Page 8

QuickSpecs

Standard Features

ProLiant Onboard Administrator

HP Insight Control

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

lifecycle. This provides the customer with higher levels of operational efficiency and highly reliable systems:

The foundation pack includes:

HP SmartStart HP Management HP ProLiant Firmware Maintenance

SmartStart version supported (minimum): SmartStart 7.51

http://www.hp.com/servers/smartstart

HP ProLiant Onboard Administrator (powered by the HP Integrated LightsOut 2 management processor) simplifies server setup, health monitoring, power and thermal control, and lights-out remote administration of ProLiant ML, DL, and BL servers. HP ProLiant Onboard Administrator functions without additional software, and can be accessed from any location via a web browser. It works hand-in-hand with HP Systems Insight Manager, Insight Control suites, and the Insight Dynamics for ProLiant helping customers unlock the value of the ProLiant platform and deliver the highest possible quality of IT service to the business. See

www.hp.com/go/ProLiantOA

HP Insight Control, a product option, delivers essential infrastructure management that can help save time and money by making it easy to deploy, migrate, monitor, remote control, and optimize your IT infrastructure through a single, simple management console.

www.hp.com/go/foundation

HP Insight Dynamics for ProLiant

Two versions of Insight Control are available, to serve environments requiring either a Linux-based or a Windows-based central management server: HP Insight Control for Linux, and HP Insight Control. See

www.hp.com/go/insightcontrol

HP Insight Control includes one year of 24 x 7 HP Software Technical Support and Update Service ensuring rapid access to HP support staff and proactive delivery of software updates. For more information about this service, please visit:

HP Insight Dynamics for ProLiant, a product option, is an integrated command center that enables IT Staff personnel to continuously analyze and optimize a converged infrastructure, while automating and reducing the cost of common data center tasks by as much as 40 percent. As a powerfully integrated by design toolkit to accelerate complex technology projects and simplify daily operations that ultimately enable IT Staff personnel to dynamically keep pace with the organizations changing business requirements. It enables them to plan capacity and power continuously, balance across physical and virtual resources, and ensure cost-effective high availability. It also enables IT organizations to provision infrastructure consistently and automatically from pools of shared resources using a selfservice portal. Resources provisioned can range from a single virtual machine to complex multi-tier environments and their associated physical and virtual resource requirements. In addition to the previous functional benefits, it also provides a cost-effective disaster recovery for physical and virtual environments that works with HP StorageWorks Continuous Access

http://www.hp.com/services/insight

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 9

QuickSpecs

Standard Features

Industry Standard

Industry StandardIndustry Standard Compliance

Compliance

ComplianceCompliance

Security

SecuritySecurity

ACPI 1.0b Compliant PCI 2.2 Compliant WOL Support Microsoft® Logo certifications PXE Support

Power-on password Keyboard password Diskette drive control Diskette boot control QuickLock, Network Server Mode Parallel and serial interface control Administrator's password

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

software for both the Enterprise Virtual Array and the XP storage array allowing application environments to be reactivated in minutes with the touch of a button to a remote location.

NOTE:

For more information, visit:

NOTE:NOTE:

http://www.hp.com/go/insightdynamics

Server Power Cords

Server Power CordsServer Power Cords

Power Supply

Power SupplyPower Supply

UPS and PDU Power

UPS and PDU PowerUPS and PDU Power Cord Matrix

Cord Matrix

Cord MatrixCord Matrix

System Fans

System FansSystem Fans

Required Cabling

Required CablingRequired Cabling

110V NEMA -6ft. (1.83m) cord included in the United States; localized cables included with geographic specific models in other world regions. IEC 6 ft. (1.83m) cords also included with rack models. Localized cables included with geographic specific models in other world regions.

NOTE:

NOTE: NOTE: local power cord, they can check the power cord matrix for the appropriate country specific sku. Please see the following power cord matrix:

800 Watt-CE Mark Compliant Hot Plug Power Supply (1000 Watt high line) Optional second Power Supply provides redundant capability

NOTE:

NOTE: NOTE: requirements.

Please see the UPS and PDU cable matrix's on the HP Power Protection and Management page. Under Power Cords, click on the "HP Power Cord Matrix" link. That link will list cable descriptions, requirements, and specifications for UPS and PDU units. Please see the following link:

www.hp.com/products/powercords

Three hot-plug fans standard. Redundant fan kit includes three additional fans.

For external storage cabling information, refer to the Web site at:

HP ProLiant ML370 a C13 to C14 2.8M jumper cord ships standard. If customers require a

http://www.hp.com/go/powercordmatrix

Please see the "Power Specifications" section later in this document for low line and high line

www.hp.com/servers/ml370

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 10

QuickSpecs

Standard Features

Operating Systems and

Operating Systems andOperating Systems and Virtualization Software

Virtualization Software

Virtualization SoftwareVirtualization Software Support for ProLiant

Support for ProLiant

Support for ProLiantSupport for ProLiant Servers

Servers

ServersServers

Rack Airflow

Rack AirflowRack Airflow Requirements

Requirements

RequirementsRequirements

Microsoft Windows Server Microsoft Windows Server Hyper V Red Hat Enterprise Linux (RHEL) SUSE Linux Enterprise Server (SLES) Oracle Enterprise Linux (OEL) Solaris VMware Citrix for XenServer

NOTE:

For more information on HP's Certified and Supported ProLiant Servers for OS and Virtualization

NOTE:NOTE: Software and latest listing of software drivers available for your server, please visit our Support Matrix at:

http://www.hp.com/go/ossupport http://www.hp.com/support/ML370G5

Rack 10000 G2 series Cabinets

Rack 10000 G2 series CabinetsRack 10000 G2 series Cabinets The increasing power of new high-performance processor technology requires increased cooling efficiency for rack-mounted servers. The 10000 G2 Series Racks provide enhanced airflow for maximum cooling, allowing these racks to be fully loaded with servers using the latest processors.

CAUTION:

CAUTION:CAUTION: adequate airflow and to prevent damage to the equipment:

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

and our driver download page

If a third-party rack is used, observe the following additional requirements to ensure

Rack Kit

Rack KitRack Kit

Telco Rack Support

Telco Rack SupportTelco Rack Support

Front and rear doors: allow 830 square inches (5,350 sq cm) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation). Side:

The clearance between the installed rack component and the side panels of the rack must be

a minimum of 2.75 inches (7 cm).

CAUTION:

CAUTION: CAUTION: arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

NOTE:

NOTE:NOTE: provided with the server, or to the server documentation located in the Support section at the following URL:

Quick deploy rail system provides tool-free support for racks with square or round mounting holes (including Compaq/HP 7000, 9000, 10000 G2 and HP series), with an adjustment range of 24" - 36". The ambidextrous cable management arm can be mounted on either the left or right side for improved cable management.

Support for all 2-post Telco racks requires the use of the standard rack kit and an additional option kit from Rack Solutions at:

Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This

For additional information, refer to the Setup and Installation Guide or the Documentation CD

www.hp.com/servers/ml370-g5

If your 42U server rack includes closing front and rear doors, you must

http://www.racksolutions.com/hp/

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 11

QuickSpecs

Standard Features

Factory Express Portfolio

Factory Express PortfolioFactory Express Portfolio for Servers and Storage

for Servers and Storage

for Servers and Storagefor Servers and Storage

HP Enterprise

HP EnterpriseHP Enterprise Configurator

Configurator

ConfiguratorConfigurator

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to:

The HP eCo-Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

http://www.hp.com/go/factory-express

http://www.hp.com/products/configurator

Service and Support

Service and SupportService and Support

HP Care Pack services provide total care and support expertise with committed response designed to meet your IT and business needs.

HP Care Pack services include coverage for the HP branded hardware options qualified for the server and purchased at the same time or afterward that are internal to the enclosure. This also includes the 22" and smaller external monitors and tower UPS options up to 3kVA. These items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included, and standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.

To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions, provides a range of support services designed to meet the varying needs of your business. Whether an SMB, or large global corporation, HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Recommended Service

Recommended ServiceRecommended Service

Support

SupportSupport Deployment Service

Deployment Service

Deployment ServiceDeployment Service

Enhanced Service

Enhanced Service Enhanced Service

Support

SupportSupport

Refer to the information on "Installation & Start-Up" for service on ProLiant server and Microsoft or Linux O/S per the Customer Description and/or Data Sheet; to be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.

: 3-Year 4-Hour response 24x7 Same Business Day Coverage only

: 3-Year Support Plus 24 only

- simplify ProLiant solution implementation, maintenance, and management.

: Installation and Start up only

- optimize service level to increase IT performance and availability.

NOTE:

NOTE: NOTE:

http://www.hp.com/services/proliantservices http://www.hp.com/go/proliant/carepack

For a complete listing of service offerings and information visit:

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 12

QuickSpecs

Models

NOTE:

NOTE: NOTE: Integrated Models" section.

HP ML370 G5

HP ML370 G5HP ML370 G5 Performance Models

Performance Models

Performance ModelsPerformance Models

Tower Models:

Tower Models:Tower Models: Quad-Core:

Quad-Core:

Quad-Core:Quad-Core: ML370T05 X5450

ML370T05 X5450

ML370T05 X5450ML370T05 X5450 458341-xx1

Rack Models:

Rack Models:Rack Models: Quad-Core:

Quad-Core:

Quad-Core:Quad-Core: ML370R05 X5450

ML370R05 X5450

ML370R05 X5450ML370R05 X5450 458342-xx1

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information – Factory

Processor(s)

Processor(s)Processor(s)

Two of the following depending on Model

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory Network Controller

Network Controller

Network ControllerNetwork Controller Storage Controller

Storage Controller

Storage ControllerStorage Controller Hard Drive

Hard Drive

Hard DriveHard Drive Internal Storage

Internal Storage

Internal StorageInternal Storage

Optical Drive

Optical DriveOptical Drive Power Supply

Power Supply

Power SupplyPower Supply

Fans

FansFans Form Factor

Form Factor

Form FactorForm Factor

One of the following depending on Model

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

(2) Quad-Core Intel® Xeon® Processor X5450 (3.00 GHz, 120 Watts, 1333 FSB)

12MB (2 x 6 MB) Level 2 cache - 5400 Sequence 4 GB (4 x 1 GB); 2 memory cards (2 x 1 GB each card) Two embedded NC373i Multifunction Gigabit Sever Adapters HP Smart Array P400/512MB BBWC Controller (RAID 0/1/1+0/5/6) None ship standard SAS: 8.0TB maximum with 16 SFF drive option

SATA: 8.0TB maximum DVD-ROM Drive (diskette drive optional) (1) 800 Watt-CE Mark Compliant Hot Plug Power Supply (1000 Watt high

line) (3) hot-plug fans standard Tower

Rack (5U), (8.75-inch)

HP ML370 G5 Base

HP ML370 G5 BaseHP ML370 G5 Base Models

Models

ModelsModels

Tower Models:

Tower Models:Tower Models: Quad-Core:

Quad-Core:

Quad-Core:Quad-Core: ML370T05 E5440

ML370T05 E5440

ML370T05 E5440ML370T05 E5440 458343-xx1 ML370T05 E5430

ML370T05 E5430

ML370T05 E5430ML370T05 E5430 458345-xx1

Dual-Core:

Dual-Core:Dual-Core: ML370T05 X5260

ML370T05 X5260

ML370T05 X5260ML370T05 X5260 458425-xx1

Rack Models:

Rack Models:Rack Models: Quad-Core

Quad-Core

Quad-CoreQuad-Core ML370R05 E5440

ML370R05 E5440

ML370R05 E5440ML370R05 E5440 458344-xx1 ML370R05 E5430

ML370R05 E5430

ML370R05 E5430ML370R05 E5430 458346-xx1

Dual-Core:

Dual-Core:Dual-Core: ML370R05 X5260

ML370R05 X5260

ML370R05 X5260ML370R05 X5260 458426-xx1

Processor(s)

Processor(s)Processor(s)

One of the following depending on Model

Cache Memory

Cache MemoryCache Memory

One of the following depending on Model

Memory

MemoryMemory Network Controller

Network Controller

Network ControllerNetwork Controller Storage Controller

Storage Controller

Storage ControllerStorage Controller Hard Drive

Hard Drive

Hard DriveHard Drive Internal Storage

Internal Storage

Internal StorageInternal Storage

Optical Drive

Optical DriveOptical Drive

DVD-ROM standard after 11/12/07

Power Supply

Power SupplyPower Supply

Fans

FansFans Form Factor

Form Factor

Form FactorForm Factor

One of the following depending on Model

(1) Quad-Core Intel® Xeon® Processor E5440 (2.83 GHz, 80 Watts, 1333 FSB) (1) Quad-Core Intel® Xeon® Processor E5430 (2.66 GHz, 80 Watts, 1333 FSB) (1) Dual-Core Intel® Xeon® Processor X5260 (3.33 GHz, 80 Watts, 1333 FSB)

12MB (2 x 6MB) Level 2 cache - 5400 Sequence 6MB (1 x6MB) Level 2 cache - 5200 Sequence

2 GB (2 x 1 GB); 1 memory card Two embedded NC373i Multifunction Gigabit Sever Adapters HP Smart Array P400/256MB Controller (RAID 0/1/1+0/5) None ship standard SAS: 8.0TB maximum with 16 SFF drive option

SATA: 8.0TB maximum 48x CD-ROM Drive (diskette optional)

(1) 800 Watt-CE Mark Compliant Hot Plug Power Supply (1000 Watt high line)

(3) hot-plug fans standard Tower

Rack (5U), (8.75-inch)

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 13

QuickSpecs

Models

HP ML370 G5 Entry

HP ML370 G5 EntryHP ML370 G5 Entry Models

Models

ModelsModels

Tower Models:

Tower Models:Tower Models: Quad-Core:

Quad-Core:

Quad-Core:Quad-Core: ML370T05 E5410

ML370T05 E5410

ML370T05 E5410ML370T05 E5410 458347-xx1

Dual-Core:

Dual-Core:Dual-Core: Rack Models:

Rack Models:

Rack Models:Rack Models: Quad-Core:

Quad-Core:

Quad-Core:Quad-Core: ML370R05 E5410

ML370R05 E5410

ML370R05 E5410ML370R05 E5410 458348-xx1

Processor(s)

Processor(s)Processor(s)

One of the following depending on Model

Cache Memory

Cache MemoryCache Memory Memory

Memory

MemoryMemory Network Controller

Network Controller

Network ControllerNetwork Controller Storage Controller

Storage Controller

Storage ControllerStorage Controller Hard Drive

Hard Drive

Hard DriveHard Drive Internal Storage

Internal Storage

Internal StorageInternal Storage

Optical Drive

Optical DriveOptical Drive

DVD-ROM standard after 11/12/07

Power Supply

Power SupplyPower Supply

Fans

FansFans Form Factor

Form Factor

Form FactorForm Factor

One of the following depending on Model

HP ProLiant ML370 Generation 5 (G5)

HP ProLiant ML370 Generation 5 (G5)HP ProLiant ML370 Generation 5 (G5)

(1) Quad-Core Intel® Xeon® Processor E5410 (2.33 GHz, 80 Watts, 1333 FSB)

12MB (2 x 6MB) Level 2 cache - 5400 Sequence 1 GB (2 x 512 MB) Level 2 cache Two embedded NC373i Multifunction Gigabit Sever Adapters HP Smart Array E200/64MB Controller (RAID 0/1/1+0) None ship standard SAS: 8.0TB maximum with 16 SFF drive option

SATA: 8.0TB maximum 48x CD-ROM (diskette optional)

(1) 800 Watt-CE Mark Compliant Hot Plug Power Supply (1000 Watt high line)

(3) hot-plug fans standard Tower

Rack (5U), (8.75-inch)

Country Code Key

Country Code KeyCountry Code Key

XX=00 XX=01 XX=03 XX=04 XX=05 XX=20 XX=29 XX=37 XX=42 XX=AA

Tower Code Key

Tower Code KeyTower Code Key U.S. English U.S. English Australia UK Germany France Brazil Brazil Japan Japan APD APD Europe Europe PRC PRC

Rack Code Key

Rack Code KeyRack Code Key

N/A N/A N/A N/A

DA - 12478 Worldwide — Version 49 — November 19, 2009

Page 14

+ 31 hidden pages
