HP Elite Slice G2 QuickSpecs

QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

Overview

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 1
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
1.
HP Center of Room Control
2.
HP Elite Slice G2 MTR Audio Ready*
3.
HP Video Ingest Module
*Audio equipment or speakers are required and sold separately.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Overview
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 2
Slice G2 Audio Ready Platform
Left side view
1.
USB Type-C™ 3.1 Gen 1 USB port
2.
Audio-out (headphone/audio-in microphone)
Back connectors
1.
Power button
5.
2 USB Type A 3.1 ports
2.
Power connector
6.
Dual-Mode DisplayPort™ (DP++)
3.
RJ-45 (network) jack
7.
HDMI port
4.
USB Type-C™ 3.1 Gen 1 USB port (60 W input, DisplayPort™ Alternate mode)
8.
UltraSlim cable lock slot
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

Features

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 3
At A Glance
Teams Rooms/Skype Rooms systems conferencing solution built on Windows IoT 64 Enterprise
Designed for small, medium, and large conference rooms with 3
rd
party A/V accessories
Center of Room Control Display provides easy management of the meeting to start/add people/share
contact/end meeting functions without a separate PC
Video Ingest Module so that meeting attendees in the room can easily share content thru an HDMI port in the
module
HP Sure Start 3.0 with Dynamic Protection
HP Cable and Port Cover adapter secures the ports, prevents tampering, and provides cable management
New Optional HP USB Type-C Extension cable (5m) from the platform to the Center of Room Control. It is included
with select platforms only. See product sku details for the details. Option kit available in certain countries
Windows 10 IoT 64 Enterprise to have a dedicated OS to run the conferencing software
UEFI BIOS developed and engineered by HP
Intel® Q170 chipset supporting Intel® Peripheral Control Hub for 7th Gen Core™ Processors, featuring integrated
Intel® HD Graphics 630 and Intel® vPro Technology
Intel® Ethernet Connection I219LM GbE LOM integrated network connection
DDR4-2400 (up to 32GB) Synchronous Dynamic Random-Access Memory (SDRAM)
Intel® Ethernet Connection I219LM GbE LOM integrated network connection (recommended)
Dual-independent monitor support via HDMI and digital DisplayPort™ video interfaces
Dual HDMI ports supported with the HP DisplayPort to HDMI True 4K Adapter
Supports Intel® AC Wireless with vPro™ Technology
Conexant CX7501 audio codec
High efficiency energy saving power supply
Low halogen
Protected by HP Services, including limited warranties up to 3-3-3 (terms and conditions vary by country; certain
restrictions and exclusions apply); Care Packs available with up to 5 years Next Business Day Onsite Hardware Support
VESA Plate (Optional)
NOTE: See important legal disclosures for all listed specs in their respective features sections.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 4
OPERATING SYSTEMS AND TYPOLOGY REQUIREMENTS
Preinstalled
Windows 10 IoT 64 Enterprise CBB
1
1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com
Microsoft Teams Rooms/Skype Room Systems IT Topology Pre-Requisites (setup must be one of the these three):
1. Online Deployment (o365) - Skype for Business Online with Exchange Online. *Active Directory Online
2. On Premise Deployment - Skype for Business Server 2015 On-Premises with Exchange 2013 SP1+ or later On-Prem.
*Active Directory On-Prem
3. Hybrid Deployment - Skype For Business 2015 On-Premise with Exchange Online/ Skype for Business 2015 Online with Exchange 2013 SP1+ On-Prem. *Active Directory On-Prem
Note1: Microsoft Teams Rooms/Skype Room Systems does not support Lync Server 2013 Note2: Preparation of the environment to enable Teams Rooms/SRS
• Microsoft Teams Rooms/Skype Room Systems needs to be assigned a "User account" in Active Directory, Exchange, and Skype for Business. The account is used to access its meeting calendar and establish Skype for Business connectivity. People can book this account by scheduling a meeting with it. Microsoft Teams Rooms/Skype Room Systems will be able to join that meeting and provide various features to the meeting attendees. Without a user account, none of these features will work. The user account & infrastructure must be correctly configured to allow Microsoft Teams Rooms/Skype Room Systems to validate the user account and reach appropriate Microsoft services. For more information on configuration & licenses required: https://docs.microsoft.com/en-
us/microsoftteams/room-systems/requirements
• A Microsoft Teams Rooms/Skype Room Systems client appliance PC with all required software installed
• For additional information on configuration& supported topologies: https://docs.microsoft.com/en-
us/microsoftteams/room-systems/room-systems
PROCESSOR
7th Generation Intel® Core™ processors
1,2
Intel® Core™ i7-7700T with Intel® HD Graphics 630 Up to 3.8 GHz Max. Turbo Frequency (2.9 GHz base frequency) 8 MB cache, 4 cores, 8 threads
3,4,5
supports Intel® vPro Technology
Intel® Core™ i5-7500T with Intel® HD Graphics 630, Up to 3.3 GHz Max. Turbo Frequency (2.7 GHz base frequency) 6 MB cache, 4 cores, 4 threads
3,4,5
supports Intel® vPro™ Technology
1. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.
2. I5 CPU recommended for Single Display Conference Room, i7 CPU recommended for Dual Display Conference Room.
3. Intel® Turbo Boost technology requires a PC with a processor with Intel Turbo Boost capability. Intel Turbo Boost performance varies depending on hardware, software and overall system configuration. See www.intel.com/technology/turboboost for more information.
4. Some functionality of this technology, such as Intel Active management technology and Intel Virtualization technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro technology is dependent on 3rd party software providers. Compatibility of this generation of Intel vPro technology-based hardware with future "virtual appliances" is yet to be determined.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 5
CHIPSET
Intel® Q170
MEMORY
Both slots are customer accessible / upgradeable, Supports Dual Channel Memory
Type
Maximum
# of Slots
DDR4-2400 (Transfer rates up to 2433 MT/s)
32 GB capacity
2 DIMM
Configurations
8 GB DDR4-2400 SODIMM (2x4GB) (Dual Channel)
6
16 GB DDR4-2400 SODIMM (2x8GB) (Dual Channel)
6. 8 GB DDR4-2400 SDRAM: up to 32 GB thru option kit(s).
GRAPHICS
Integrated
Intel® HD Graphics 630 with GT2 support6
6. HD content required to view HD images.
STORAGE / DRIVES
PCIe® NVMe™ TLC M.2 SSD7
128GB PCIe NVMe M.2 Solid State Drive
7. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.
SLOTS
Integrated
1 M.2 2230 PCIe for WLAN
1 M.2 2280 PCIe for NVMe SSD
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 6
NETWORKING
LAN
Wired Intel
i219LM GbE LOM
WWAN (optional and must be configured at purchase)
8
Intel® Dual Band Wireless-AC 8260 802.11ac 2x2 +Bluetooth 4.2 vPro ™
Intel® Dual Band Wireless-AC 7265 802.11ac 2x2 +Bluetooth® 4.2 (Non-vPro)
8. Wireless cards are optional or add-on features and requires separately purchased wireless access point and internet service. Availability of public wireless access points limited. The specifications for the 802.11ac WLAN are draft specifications and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ac WLAN devices.
AUDIO / MULTIMEDIA
Conexant CX7501
1x Universal re-task able audio jack
KEYBOARD AND POINTING DEVICES (OPTIONAL)
Keyboards
9
HP Business Slim USB Keyboard
10
HP Wired Desktop 320K Keyboard
Mice9
HP USB 1000 dpi Laser Mouse
HP Mouse
HP USB Optical Mouse HP Wired Desktop 320M Mouse
9. Keyboards and mice are sold separately or as an optional feature.
10. USB Business Slim Wired Keyboard.
DISPLAY
Center of Room Control
11,12
11. Dimensions: Width (X) 301.75mm or 11.88 in; Height(Y) 219.75mm or 8.65 in; Depth (Z) 80.8mm or 3.17 in; Weight: 1040 grams or 2.3 lbs
12. 12.3" (31.2 cm) diagonal FHD LCD touch screen (1920 x 1280)
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 7
PORTS
External I/O Ports
1 Universal audio jack (with re-tasking) connector
1 USB Type-C™ (USB 3.1 Gen 1, 15W output) connector
1 USB Type-A (USB 3.1, charging) connector
1 USB Type-A (USB 3.1, S4/S5 wake) connector
1 USB Type-C™ (Alternate Mode DP, USB 3.1 Gen 1, 15W output, 60W input) connector
1 DisplayPort™ connector
1 HDMI connector (optional HP DisplayPort™)
1 RJ-45 connector
1 DC-in 7.4mm barrel
Internal I/O Ports
1. M.2 nVME
1 SATA
MODULES
Included
HP Cable and Port cover
HP Center of Room Control
11,12
HP Video Ingest Module
Optional
HP USB Type-C Extension Cable (5 m)
VESA Mount
Wireless Display Module13
11. Dimensions: Width (X) 301.75mm or 11.88 in; Height(Y) 219.75mm or 8.65 in; Depth (Z) 80.8mm or 3.17 in; Weight: 1040 grams or 2.3 lbs 12. 12.3" (31.2 cm) diagonal FHD LCD touch screen (1920 x 1280)
13. Only can be purchased as an optional feature at time of sale
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 8
SOFTWARE COMPONENTS AND APPLICATIONS WITH WINDOWS
Software
Microsoft Team Rooms/Skype Rooms Systems
Absolute Persistence Module
14
HP Connection Optimizer
14. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:
http://www.absolute.com/company/legal/agreements/computrace-agreement. Data Delete is an optional service provided by
Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.
MANAGEABILITY FEATURES
Intel® vPro™ Technology
SECURITY MANAGEMENT
TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified)
HP Sure Start 3.0*
*NOTE: Available on HP Elite products equipped with Intel® 7th generation processors.
POWER SUPPLY
90W AC adapter
15
Up to 85% efficient
15. All power supplies are not available in every region.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 9
DIMENSIONS AND WEIGHT (CONFIGURED WITH 1 SSD DRIVE )
Chassis (H x W x D)
6.5 x 6.5 x 1.4 in (165 x 165 x 35 mm)
Chassis (H x W x D) with Video Ingest
6.5 x 6.5 x 2.39 in (165 x 165 x 61 mm)
Chassis with Optional Video Ingest and Optional Vesa Plate
6.5 x 6.5 x 2.68 in (165 x 165 x 68 mm)
System Weight (without optional devices)
2.31 lb / 1.57 kg
PACKAGING DIMENSIONS AND WEIGHT
Dimensions
12 x 23.5 x 8.4 in (30.5 x 59.9 x 21.5 mm)
Weight
16.9 lb / 7.6 kg
COLOR
Sparkle black color
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 10
HP CENTER OF ROOM CONTROL
Functionality
See full Room Calendar for scheduled calls
Initiate ad-hoc calls, dial out, or invite participants
Toggle Skype views with Gallery, content, maximize 2x LDF for conferencing
Volume control & Mute on CoRC & Collab buttons
Fully replace the phone in the conference room
Tool-less Type-C cable installation with stand cover module
Display
12.3diagonal screen
Type-C interface
Dual orientation
1440 x 960 resolution
3:2 aspect ratio
10-point touch capable
Orientations
25 degrees horizontal
48 degrees horizontal
Sensor
Pyro-electric IR-Detectors
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 11
HP VIDEO INGEST MODULE
Functionality
1080 Resolution support
60Hz refresh
1 x HDMI 1.4 input port
Works in MTR with Present option (button)
Display input to local display and meeting
PORT COVER
Functionality
Tamper-proofing of cables from the back of Slice
Extends Power, 2 USB Type-A, RJ45, DisplayPort, and HDMI cables for connections under the table
Clean single condensed cable for single group of cables extended from Slice
Separate Type-C cable for easy movement of Center of Room Control display on the table
Cover to hide back connections to Slice
Cable Lengths:
Cable Type
Length
Power, 2 USB Type-A, HDMI, DisplayPort, RJ45
1.0m
Type-C
1.5m
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 12
WIRELESS DISPLAY MODULE
Functionality
Only supported with HDMI connector
1080p HD resolution
Only supported on table top
Transmitter and Receiver paired at the factory
Pair button included in case needed later
Light status included to show paired devices
60Ghz band is used – signal is blocked by walls and confined to conference room
Wireless Display Module is not support in all countries
HP USB TYPE-C EXTENSION CABLE (5 m) – Optional
Functionality
Gives more space between the Slice G2 Audio Ready platform and the Center of Room Control
Designed for small, medium and large rooms
Durable and flexible material
Supports Power and data transfer
Cable connectors clearly marked for proper installation
16.4’ (5m) length
Includes 7 plastic clips for secure cable installation
Cannot be installed with Port Cover
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Features
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 13
SERVICE AND SUPPORT
On-site Warranty: Protected by an HP standard three-year (3-3-3) or one-year (1-1-1) limited warranty (varies by region). Certain restrictions and exclusions apply. Limited warranty delivers next business day service for parts and labor and includes Complimentary Limited Technical Support. One-year onsite and labor are not available in all countries. Service offers terms up to 5 years by choosing an optional HP Care Pack. To choose the right level of service for your HP product, visit HP Care Pack Central: http://www.hp.com/go/cpc
NOTE 1: Terms and conditions may vary by country. Certain restrictions and exclusions apply. Other warranty variations may be offered in your region. NOTE 2: On-site service may be provided pursuant to a service contract between HP and an authorized HP third-party provider, and is not available in certain countries. Global service response times are based on commercially reasonable best effort and may vary by country.
NOTE 3: Technical support applies only to HP-configured and third-party HP qualified hardware and software.
COUNTRY OF ORIGIN
China
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

Technical Specifications - Graphics

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 14
GRAPHICS
Intel® HD Graphics 630 (integrated)
DisplayPort™ 1.2
Multimode capable; supports HDCP, DisplayPort™Audio (2 streams), HBR2 link rates and Multi-Stream Technology for a maximum of 3 displays (including the integrated panel)
Memory
The BIOS has options for selecting the dedicated memory size of 128MB, 256MB or 512MB
Additional memory is allocated for graphics as needed using Intel's Dynamic Video Memory Technology (DVMT), to provide an optimal balance between graphics and system memory use.
Maximum Graphics Memory
Microsoft Windows 7
Windows 8.1
Windows 10
Up to 1.7GB
Up to 1.8GB
>4 GB
Note: the actual amount of maximum graphics memory can be less than the amounts listed above depending upon your computer’s configuration.
Maximum Color Depth
32 bits/pixel
Graphics/Video API Support
6th Generation Core™ processors:
Next Generation Intel® Clear Video Technology HD Support is a collection of video
playback and enhancement features that improve the end user's viewing experience
o Encode/transcode HD content o Playback of high definition content including Blu-ray Disc o Superior image quality with sharper, more colorful images
DirectX Video Acceleration (DXVA) support for accelerating video processing
o Full AVC/VC1/MPEG2/HEVC HW Decode
Advanced Scheduler 2.0, 1.0
Windows 7, Windows 8.1, Windows 10, Linux OS Support
DirectX 12.1
OpenGL 4.4
Open CL 1.2 (Intel® HD Graphics 510)
Open CL 1.2/2.0 (Intel® HD Graphics 530)
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Graphics
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 15
Supported Display Resolutions and Refresh Rates
Note: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP. For
All in One platforms, resolutions higher than the integrated panel resolution are not supported on the integrated panel.
Resolution
Refresh Rate
DisplayPort™ 1.2
HDMI
Standard
640 x 480
60, 75, 85
X
X
VESA DMT, CVT 0.31M3
720 x 400
70
X
X
IBM VGA
800 x 600
60, 75, 85
X
X
VESA DMT, CVT0.48M3
1024 x 768
60, 75, 85
X
X
VESA DMT, CVT 0.79M3
1152 x 864
60, 75, 85
X
X
VESA DMT, CVT 0.83MA
1280 x 720
60, 75, 85
X
X
VESA DMT, CVT 0.92M9, CEA-770.3
1280 x 768
60, 60RB, 75, 85
X
X
VESA DMT, CVT 0.98M9/0.98M9-R
1280 x 800
60, 75, 85
X
X
VESA DMT
1280 x 960
60, 75, 85
X
X
VESA DMT
1280 x 1024
60, 75, 85
X
X
VESA DMT, CVT 1.31M4
1366 x 768
60, 60RB
X
X
VESA DMT
1440 x 900
60, 60RB
X
X
VESA DMT
1600 x 900
60, 60RB, 75, 85
X
X
VESA DMT
1680 x 1050
60, 60RB, 75
X
X
VESA DMT, CVT 1.76MA/1.76MA-R
1920 x 1080
60
X
X
VESA DMT, CVT 2.07M9, SMPTE 274M
1920 x 1200
60, 60RB, 75, 85
X
X
DMT, CVT 2.30MA/2.30MA-R
1600 x 1200
60, 75, 85
X
X
VESA DMT, 1.92M3
1920 x 1440
60, 75, 85
X
X
VESA DMT, CVT 2.76M3
2048 x 1536
60,75
X
X
CVT 3.15M3
2560 x 1440
59.951
X
X
CVT 3.69M9-R
2560 x 1600
60, 60RB
X
X
VESA DMT, CVT 4.10MA/4.10MA-R
3440 x 1440
60
X
X
VESA DMT, CVT 0.31M3
3440 x 1440
75, 85
X
VESA DMT, CVT 0.31M3
3840 x 2160
24
X
X
CVT-RBv1/v2 (8.29M9-R), SMPTE 274M
3840 x 2160
25
X
X
CVT-RBv1/v2 (8.29M9-R), SMPTE 274M
3840 x 2160
30
X
X
CVT-RBv1/v2 (8.29M9-R), SMPTE 274M
3840 x 2160
50
X
CVT-RBv1/v2 (8.29M9-R), SMPTE 274M
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Graphics
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 16
3840 x 2160
60
X
CVT-RBv1/v2 (8.29M9-R), SMPTE 274M
4096 x 2160
24
X
X
CVT-RBv1/v2 (8.85M-R), SMPTE 274M
4096 x 2160
25
X
X
CVT-RBv1/v2 (8.85M-R), SMPTE 274M
4096 x 2160
30
X
X
CVT-RBv1/v2 (8.85M-R), SMPTE 274M
4096 x 2160
50
X
CVT-RBv1/v2 (8.85M-R), SMPTE 274M
4096 x 2160
60
X
CVT-RBv1/v2 (8.85M-R), SMPTE 274M
1920 x 1080
60
X
X
VESA (SMPTE 274M)
1920 x 1080
50
X
X
SMPTE 274M
1920 x 1080
30
X
X
SMPTE 274M
1920 x 1080
24
X
X
SMPTE 274M
1280 x 720
60
X
X
VESA (CEA-770.3)
1280 x 720
50
X
X
SMPTE 296M
720 x 480
60
X
X
MHL (CEA-770.2)
720 x 576
50
X
X
ITU-R BT.1358
640 x 480
60
X
X
CEA (VESA DMT)
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

Technical Specifications - Storage

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 17
STORAGE
128GB SATA 2.5" (Non-SED) Solid State Drive
Unformatted Capacity
128GB
Architecture
TLC NAND Flash
Interface
SATA 3.2 (6.0 Gb/s)
Form Factor
2.5 inch
Dimensions (W x D x H)
6.98 x 10.05 x 0.7 cm
Weight
31g
Bandwidth Performance
Sustained Sequential Read:
Up to 510 MB/s
Sustained Sequential Write:
Up to 330 MB/s Random Read:
Up to 38K IOPs
Random Write:
Up to 70K IOPs
Power
DC power requirement:
5 VDC 5%-100 mV ripple p-p
Total power consumption:
50mW (active); 20mW (idle)
Useful Drive Life
72TB written, up to 40GB/day for 5 years
Environmental (all conditions, non-condensing)
Operating Temperature:
32° to 158° F (0° to 70° C)
Relative Humidity:
5% to 95%
Shock:
1,500 G/0.5 ms
NOTE: For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 18
128 GB M.2 2280 PCIe NVMe SSD
Drive Weight
< 10g
Capacity
128GB
Height
2.38mm
Length
80mm
Width
22mm
Interface
PCIE Gen3
Performance
Up to Random Read/Write = 60K/50K IOPS
Maximum Sequential Read
Up to 1400MB/s
Maximum Sequential Write
Up to 395MB/s
Logical Blocks
250,069,680
Operating Temperature
0° to 70°C (32° to 158°F) [ambient temp]
Features
APST; ASPM L1.2; NVME spec 1.2
NOTE:For hard drives and solid state drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 36 GB (for Windows
10) of system disk is reserved for the system recovery software.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 19
NETWORKING
Intel 8260 802.11a/b/g/n/ac (2x2) WiFi® and Bluetooth® 4.2 Combo vPro
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac
Interoperability
Wi-Fi® certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
802.11a/n
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, and
80MHz)
Modulation
Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through CCX4 and CCX
Lite
WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum
802.11g : +14dBm minimum
802.11a : +14dBm minimum
802.11n HT20(2.4GHz) : +13dBm minimum
802.11n HT40(2.4GHz) : +13dBm minimum
802.11n HT20(5GHz) : +12dBm minimum
802.11n HT40(5GHz) : +12dBm minimum
802.11ac 80MHz(5GHz) : +11dBm minimum
Power Consumption
Transmit mode2.0 W
Receive mode1.6 W
Idle mode (PSP)180 mW (WLAN Associated)
Idle mode50 mW (WLAN unassociated)
Connected Standby 10mW
Radio disabled8 mW
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 20
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -93.5dBm maximum
802.11b, 11Mbps : -84dBm maximum
802.11a/g, 6Mbps : -86dBm maximum
802.11a/g, 54Mbps : -72dBm maximum
802.11n, MCS07 : -67dBm maximum
802.11n, MCS15 : -64dBm maximum
802.11ac, MCS0 : -84dBm maximum
802.11ac, MCS9 : -59dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth® communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm
Weight
Type 2230 : 2.8g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
HP Integrated Module with Bluetooth® 4.0/4.1/4.2 Wireless Technology
Bluetooth® Specification
4.0/4.1/4.2 Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
Legacy : 0~79 (1 MHz/CH) BLE : 0~39 (2 MHz/CH)
Data Rates and Throughput
Legacy : 3 Mbps data rate; throughput up to 2.17 Mbps BLE : 1 Mbps data rate; throughput up to 0.2 Mbps Legacy : Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy : Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 4 dBm for BR and EDR.
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Electrical Interface
USB 2.0 compliant
Bluetooth® Software Supported Link Typology
Microsoft Windows Bluetooth® Software
Power Management
Microsoft Windows ACPI, and USB Bus Support
Certifications
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark
Bluetooth® Profiles Supported
BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 21
LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
Intel 7265 802.11ac 2x2 DualBand Combo PCIe x1 Card
Wireless LAN Standards
IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac
Interoperability
Wi-Fi certified
Frequency Band
802.11b/g/n
2.402 – 2.482 GHz
Note: The FCC has declared as of January 1, 2015 products that utilize passive scanning on channel 12/13 and are capable of transmitting must fully comply with requirements of 15.247 or otherwise disable those channels.
802.11a/n
4.9 – 4.95 GHz (Japan)
5.15 – 5.25 GHz
5.25 – 5.35 GHz
5.47 – 5.725 GHz
5.825 – 5.850 GHz
Note: Indonesia no support this band)
Data Rates
802.11b: 1, 2, 5.5, 11 Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)
802.11ac : MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz,
and 80MHz)
Modulation
Direct Sequence Spread Spectrum BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Security1
IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g
mode only
AES-CCMP: 128 bit in hardware
802.1x authentication
WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.
WPA2 certification
IEEE 802.11i
Cisco Certified Extensions, all versions through CCX4 and CCX
Lite
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 22
WAPI
Network Architecture Models
Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)
Roaming
IEEE 802.11 compliant roaming between access points
Output Power2
802.11b : +16dBm minimum
802.11g : +14dBm minimum
802.11a : +14dBm minimum
802.11n HT20(2.4GHz) : +13dBm minimum
802.11n HT40(2.4GHz) : +13dBm minimum
802.11n HT20(5GHz) : +12dBm minimum
802.11n HT40(5GHz) : +12dBm minimum
802.11ac 80MHz(5GHz) : +11dBm minimum
Power Consumption
Transmit: 2.0 W (max) Receive: 1.6 W (max) Idle mode (PSP): 180 mW (WLAN Associated) Idle mode: 60 mW (WLAN unassociated) Radio disabled: 30 mW
Power Management
ACPI and PCI Express compliant power management
802.11 compliant power saving mode
Receiver Sensitivity3
802.11b, 1Mbps : -94dBm maximum
802.11b, 11Mbps : -86dBm maximum
802.11g, 6Mbps : -88dBm maximum
802.11g, 54Mbps : -74dBm maximum
802.11a, 6Mbps : -86dBm maximum
802.11a, 54Mbps : -72dBm maximum
802.11n, MCS07 : -69dBm maximum
802.11n, MCS15 : -66dBm maximum
802.11ac, 1SS, MCS-0 : -86dBm maximum
802.11ac, 1SS, MCS-9 : -61dBm maximum
802.11ac, 2SS, MCS-0 : -83dBm maximum
802.11ac, 2SS, MCS-9 : -58dBm maximum
Antenna type
High efficiency antenna with spatial diversity, mounted in the display enclosure Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth® communications
Form Factor
PCI-Express M.2 MiniCard
Dimensions
Type 2230 : 2.3 x 22.0 x 30.0 mm Or Type 1630 : 2.3 x 16.0 x 30.0 mm
Weight
Type 2230 : 2.8g Or Type 1630 : 2g
Operating Voltage
3.3v +/- 9%
Temperature
Operating Non-operating
14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)
Humidity
Operating Non-operating
10% to 90% (non-condensing) 5% to 95% (non-condensing)
Altitude
Operating Non-operating
0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)
LED Activity
LED Amber – Radio OFF; LED White – Radio ON
1. Check latest software/driver release for updates on supported security features.
2. Maximum output power may vary by country according to local regulations.
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 23
3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a
packet error rate of 10% for 802.11a/g (OFDM modulation).
HP Integrated Module with Bluetooth® 4.0+EDR Wireless Technology
Bluetooth® Specification
4.0+EDR Compliant
Frequency Band
2402 to 2480 MHz
Number of Available Channels
79 (1 MHz) available channels
Data Rates and Throughput
3 Mbps data rate; throughput up to 2.17 Mbps
Synchronous Connection Oriented links up to 3, 64 kbps, voice channels
Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or 1306.9 kbps symmetric
Transmit Power
The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of +4 dBm for BR and EDR.
Receiver Sensitivity
Modulation
0.01% BER
0.001% BER
GFSK
-80 dBm
-70 dBm
π/4-DQPSK
-80 dBm
-70 dBm
8DPSK
-80 dBm
-70 dBm
Power Consumption
Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW
Range
Up to 33 ft (10 m)
Electrical Interface
USB 2.0 compliant
Bluetooth® Software Supported Link Topology
Microsoft Windows Bluetooth® Software
Electrical Interface Bluetooth® Software Supported Security
Point to Point, Multipoint Pico Nets up to 7 slaves
Full support of Bluetooth® Security Provisions
Power Management Power Management Certifications
Microsoft Windows ACPI, and USB Bus Support
Self-configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff
Security
All necessary regulatory approvals for supported countries, including:
Certifications Bluetooth® Profiles Supported
FCC (47 CFR) Part 15C, Section 15.247 & 15.249
Power Management Certifications
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
Certifications Bluetooth® Profiles Supported
UL, CSA, and CE Mark
Serial Port Profile (SPP)1 Service Discovery Application Profile (SDAP) Dial-Up Networking (DUN)
1,2
Generic Object Exchange Profile (GOEP)
1,2
Object Push Profile (OPP)
1,2
File Transfer Profile (FTP) Synchronization Profile (SYNC) Hard Copy Cable Replacement (HCRP)
1,2
Personal Area Networking Profile (PAN)
1,2
Human Interface Device Profile (HID)
1,2
FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications - Storage
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 24
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

Technical Specifications – I/O Devices

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 25
INPUT / OUTPUT DEVICES
HP Wired Desktop 320K Keyboard
Dimensions (H x L x W)
16.77 x 4.36 x 0.65 in (426.2 x 110.9 x 16.7 mm)
Weight
14.57 oz (413g)
Cable length
1800 mm
Keys
104, 105, 107, 109 layout (depending on country)
Operating voltage
5V
Power consumption
50mA - 100 mA
Interface
USB
Switch life
10M
Switch type
Plunger
Operating temperature
10°C to 50°C
Non-operating temperature
30°C to 65°C
Operating humidity
10°C to 90°C
Non-operating humidity
0°C to 90°C
Sustainability
Greater than 50% post-consumer recycled plastic content and low halogen PCBA
System required
Windows 10 (64 and 32 bit), (UWP) RS4 and above
Approvals
FCC ICES CULus CE GS EAC Ukraine India BIS KCC RCM BSMI VCCI
Kit contents
Keyboard, QSP, Warranty Card, Product Notice
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications – I/O Devices
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 26
HP USB Business Slim USB Keyboard
Physical characteristics
Keys
104, 105, 106, 107, 109 layout (depending upon country)
Dimensions (L x W x H)
171.97 x 68.35 x 8.27 in (436.8± 1.5 x 137.6± 1.0 x 21.0± 1.0 cm)
Weight
1.32 lb (0.6± 0.08 kg)
Electrical
Operating voltage
+ 4.4 – 5.25VDC
Power consumption
50-mA maximum (with 5 VDC power supplied and three LEDs ON)
System interface
USB Type A plug connector
ESD
Contact Discharge: 2,4,6,8KV
Air Discharge: 2,4, 8,10,12.5KV
EMI - RFI
Conforms to FCC rules for a Class B computing device
Microsoft® PC 99 - 2001
Functionally compliant
Mechanical
Keycaps
Low-profile design
Switch actuation
60±12.5g nominal peak force with tactile feedback
Switch life
10 million keystrokes (Life tester)
Switch type
Contamination-resistant switch membrane
Key-leveling mechanisms
For all double-wide and greater-length keys
Cable length
6 ft (1.8 m)
Microsoft PC 99 - 2001
Mechanically compliant
Environmental
Acoustics
43-dBA maximum sound pressure level
Operating temperature
50° to 122° F (10° to 50° C)
Non-operating temperature
-22° to 140° F (-30° to 60° C)
Operating humidity
10% to 90% (non-condensing at ambient)
Non-operating humidity
20% to 80% (non-condensing at ambient)
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications – I/O Devices
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 27
Operating shock
40 g, six surfaces
Non-operating shock
80 g, six surfaces
Operating vibration
2-g peak acceleration
Non-operating vibration
4-g peak acceleration
Drop (out of box)
26 in (66 cm) on carpet, six-drop sequence
Drop (in box)
30 in (76.2 cm) on concrete, 16-drop sequence
Approvals
UL, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, KC
Ergonomic compliance
ANSI HFS 100, ISO 9241-4, and TUVGS
Kit contents
Keyboard
Installation Guide
Warranty Card
Safety and Comfort Guide
HP Wired Desktop 320M Mouse
Dimensions (H x L x W)
4.08 x 2.49 x 1.39 in (103.8 x 63.4 x 35.5 mm)
Weight
2.67 oz (75.8 g)
Dots per inch (DPI)
1000
Tracking type
Optical Red Sensor
Connectivity
USB
Cable length
1800 mm
System requirements
Windows 10 (64 bit and 32 bit) (UWP) RS4 and above
Approvals
FCC ICES CULus CE GS EAC Ukraine India BIS KCC RCM BSMI VCCI
Sustainability
Low halogen PCBA.
Kit contents
Mouse, QSP, Warranty Card, Product Notice
HP USB Mouse
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
Technical Specifications – I/O Devices
Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 28
Dimensions (H x L x W)
2.5 x 4.5 x 1.5 in (63.5 x 114.3 x 38.1 mm) Weight
0.22 lb (99.79 g)
Color
Black
Connector
USB
Mechanical
Resolution
800 DPI sensitivity
Buttons
Two primary buttons and clickable scroll wheel
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

After Market Options

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 29
AFTER MARKET OPTIONS
ITEM
Part Number
Memory
HP 4GB DDR4-2400 SODIMM
Z9H55AA
HP 8GB DDR4-2400 SODIMM
Z9H56AA
HP 16GB DDR4-2400 SODIMM
Z9H53AA
HP 16GB DDR4-2666 SODIMM
3TK84AA
HP 4GB DDR4-2666 SODIMM
3TK86AA
HP 8GB DDR4-2666 SODIMM
3TK88AA
Other
HP VESA Plate
X8U74AA
HP (Bulk) Elite Slice Sata Storage Drive Screws Kit
Z5U26AA
HP DisplayPort Cable Kit
VN567AA
HP USB Type-C Extension Cable (5m) (in certain countries)
9JH45AA
HP Desktop Mini 90W Power Supply Kit
L4R65AA
Pointing Devices
HP USB Mouse
QY777AA
HP 1000dpi Laser Mouse
QY778AT
HP Desktop Wired 320M Mouse
9VA80AA
Keyboards
HP USB Business Slim Keyboard
N3R87AA
HP Wireless Business Slim Keyboard and Mouse
N3R88AA
HP Desktop Wired 320K Keyboard
9SR37AA
QuickSpecs
HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms

Summary of Changes

Not all configuration components are available in all regions/countries.
c06133533 DA 15372 Worldwide Version 16 April 21, 2021
Page 30
Date of change:
Version History:
Description of change:
January 16, 2019
V1 to V2
Update
Audio codec corrected
April 5, 2019
V2 to V3
Update
AMO updated
May 15, 2019
V3 to V4
Update
Name changed to HP Elite Slice G2 - Audio Ready with Microsoft Teams Rooms
July 1, 2019
V4 to V5
Update
Operating Systems and Topology requirements section updated
July 18, 2019
V5 to V6
Update
Footnote general re-arrange At a glance updated CPU 7400T removed and 7700T added WLAN removed CoRC image updated
August 23, 2019
V6 to V7
Update
Software components and CoRC image updated
September 4, 2019
V7 to V8
Update
COrC image reduced
December 20, 2019
V8 to V9
Update
HP USB Type-C Extension Cable (5m) added
February 10, 2020
V9 to V10
Update
Supported Display Resolutions and Refresh Rates table
February 26, 2020
V10 to v11
Update
Pages 1 and 10 images updated
May 27, 2020
V11 to V12
Update
Intel® Dual Band Wireless-AC 7265 added and Dimensions and weight updated
June 15, 2020
V12 to V13
Removed
Active Health (black box flight recorder) from SECURITY MANAGEMENT section
July 15, 2020
V13to 14
Add
EPEAT statement and disclaimer updated
October 10, 2020
V14 to V15
Update
Energy Star/EPEAT references removed Cable Lengths added to Port Cover features HP Desktop Mini 90W Power Supply Kit added to AMO section
April 21, 2021
V15 to V16
Update
Storage section corrections / HP 320k Keyboard and mouse added to document
© Copyright 2021 HP Development Company, L.P. All rights reserved. The information contained herein is subject to change without notice. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Bluetooth is a trademark of its proprietor, used by HP, Inc. under license.
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®) in the
United States and other countries. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum Intel, Core and vPro are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries.
Loading...
