QuickSpecs

HP Elite Dragonfly Notebook PC

Overview

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 1

HP Elite Dragonfly Notebook PC

Left

Internal Microphones

Glass Clickpad

IR Camera LEDs

WWAN SIM (Nano)

Webcam and IR Camera

Nano Security Lock Slot (Lock sold separately)

Privacy Camera Shutter

Power Button

Webcam LED

10.

USB 3.1 Gen 1 Charging Port

NOTE: All units have a SIM card slot and icon but units that do not support WWAN are shipped with a non-removable SIM slot plug

Page 2

QuickSpecs

HP Elite Dragonfly Notebook PC

Overview

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 2

Right

HDMI port (Cable not included)

USB Type-C™ with Thunderbolt™

Audio Combo Jack

Touch Fingerprint Sensor

USB Type-C™ with Thunderbolt™

Page 3

QuickSpecs

HP Elite Dragonfly Notebook PC

Overview

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 3

AT A GLANCE

• Precision Machined CNC Mg Unibody with Narrow borders, a chassis that is .63 inches (1.61 cm) thin and with a starting

weight of 2.2 lbs. (1 Kg)1

• A 360° convertible notebook with 4 usage modes

• Integrated HP Privacy Camera, with a physical shutter to protect from malicious surveillance

• Choice of 8th Generation Intel® Core™ i7, i5 and i3 processors

• Display choices include 33.78 cm (13.3") diagonal IPS FHD touch screen or UHD HDR-400 touch screen. Brightness

choices up to 1000 Nits. Get added protection in open or public places with the optional HP Sure View Gen3 integrated privacy screen2

• Ultimate connectivity with 4G/LTE WWAN, WLAN, USB Type-C™, USB Type-A, HDMI and Thunderbolt™ Docking

• Engage teams, clients, and vendors with the crystal-clear audio by Bang & Olufsen and the high-performance HP

Premium Collaboration Keyboard

• The updated optional HP Rechargeable Active Pen G3

• Never forget your password with your choice of simple authentication methods, including the IR camera for face

recognition and Touch Fingerprint Sensor for Windows Hello

• Choice of solid state drives up to 2 TB

• DDR3 Memory up to 16 GB

• Up to TBD hours of battery life

• Preinstalled with Windows 10 versions or FreeDOS

• Undergoes 19 MIL-STD 810g tests

1. Starting weight less than 1kg is only available in certain configurations.

2. Touch-enabled display and Sure View privacy panel will lower actual brightness.

3. Recharges your battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging time may vary +/-10% due to System tolerance.

4. MIL-STD-810G testing is conducted on all HP EliteBook products. Testing is not intended to demonstrate fitness of U.S. Department of Defense (DoD) contract requirements or for military use. Test results are not a guarantee of future performance under these test conditions. Accidental damage requires an optional HP Accidental Damage Protection Care Pack

NOTE: See important legal disclosures for all listed specs in their respective features sections.

Page 4

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 4

PRODUCT NAME

HP Elite Dragonfly Notebook PC

OPERATING SYSTEM

Preinstalled

Windows 10 Pro 64

Windows 10 Pro 64 (National Academic License)

Windows 10 Home 64

Windows 10 Home Single Language 64 Windows 10 Pro (Windows 10 Enterprise available with a Volume Licensing Agreement)

FreeDOS

1. Not all features are available in all editions or versions of Windows. Systems may require upgraded and/or separately purchased hardware, drivers, software or BIOS update to take full advantage of Windows functionality. Windows 10 is automatically updated, which is always enabled. ISP fees may apply and additional requirements may apply over time for updates. See http://www.windows.com/.

2. Some devices for academic use will automatically be updated to Windows 10 Pro Education with the Windows 10 Anniversary Update. Features vary; see https://aka.ms/ProEducation for Windows 10 Pro Education feature information.

PROCESSORS

Intel® Core™ i7-8665U processor with Intel® UHD Graphics 620 (1.9 GHz base frequency, up to 4.8 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores) supports Intel® vPro™ Technology

3,4,5,6,7

Intel® Core™ i7-8565U processor with Intel® UHD Graphics 620 (1.8 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores)

3,4,5

Intel® Core™ i5-8365U processor with Intel® UHD Graphics 620 Graphics (1.6 GHz base frequency, up to 4.1 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores) supports Intel® vPro™ Technology

3,4,5,6,7

Intel® Core™ i5-8265U processor with Intel® UHD Graphics 620 (1.6 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 6 MB L3 cache, 4 cores)

3,4,5

Intel® Core™ i3-8145U processor with Intel® UHD Graphics 620 (2.1 GHz base frequency, up to 3.9 GHz with Intel® Turbo Boost Technology, 4 MB L3 cache, 2 cores)

3,4,5

Processor Family

8th Generation Intel® Core™ i7 processor (i7-8665U, i7-8565U)

8th Generation Intel® Core™ i5 processor (i5-8365U, i5-8265U)

8th Generation Intel® Core™ i3 processor (i3-8145U)

3. Multicore is designed to improve performance of certain software products. Not all customers or software applications will necessarily benefit from use of this technology. Performance and clock frequency will vary depending on application workload and your hardware and software configurations. Intel’s numbering, branding and/or naming is not a measurement of higher performance.

4. Processor speed denotes maximum performance mode; processors will run at lower speeds in battery optimization mode.

5. Intel® Turbo Boost performance varies depending on hardware, software and overall system configuration. See

http://www.intel.com/technology/turboboost for more information.

6. Some functionality of vPro, such as Intel Active management technology and Intel Virtualization technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for Intel vPro techno logy is dependent on 3rd party software providers. Compatibility with future "virtual appliances" is yet to be determined.

7. For full Intel® vPro™ functionality, Windows, a vPro supported processor, vPro enabled chipset, vPro enabled WLAN card

and discrete TPM 2.0 are required.

8. In accordance with Microsoft’s support policy, HP does not support the Windows 8 or Windows 7 operating system on products configured with Intel and AMD 7th generation and forward processors or provide any Windows 8 or Windows 7 drivers on http://www.support.hp.com.

Page 5

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 5

CHIPSET

Integrated with processor

GRAPHICS

Integrated

Intel® UHD Graphics 620

Supports

Support HD Decode, DX12, HDMI 1.4b

8. HD content required to view HD images.

DISPLAY

Touch

33.8 cm (13.3") diagonal FHD IPS eDP + PSR BrightView WLED-backlit Ultraslim direct bonded touch screen with Corning® Gorilla® Glass 5, 400 nits, 72% NTSC (1920 x 1080)

8,9,10

33.8 cm (13.3") diagonal FHD IPS eDP + PSR BrightView WLED-backlit Ultraslim direct bonded touch screen with Corning® Gorilla® Glass 5 and HP Sure View Integrated Privacy Screen, 1000 nits, 72% NTSC (1920 x 1080)

8,9,10, 11,47

33.8 cm (13.3") diagonal 4K IPS eDP + PSR BrightView WLED-backlit Ultraslim direct bonded touch screen with Corning® Gorilla® Glass 5, 550 nits, 69% NTSC (3840 x 2160)

8,9,10

Displays support

Supports dual display through the dock

Display Size (Diagonal)

13.3", 33.8cm (13.3")

8. HD content required to view HD images.

9. Sold separately or as an optional feature.

10. Resolutions are dependent upon monitor capability, and resolution and color depth settings.

11. HP Sure View integrated privacy screen is an optional feature that must be configured at purchase and is designed to function in landscape orientation.

47. Touch-enabled display and Sure View privacy panel will lower actual brightness.

Page 6

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 6

STORAGE AND DRIVES

Primary M.2 Storage

128 GB SATA-3 SS TLC12

256 GB PCIe® NVMe™ SS Value

256 GB PCIe® Gen3x4 NVMe™ SS TLC

256 GB SATA TLC SED OPAL 212

256 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 16 GB Intel® Optane™ memory H10

12,13,14

512 GB PCIe® NVMe™ SS Value

512 GB PCIe® Gen3x4 NVMe™ SS TLC

512 GB SATA TLC SED OPAL 2

512 GB SATA-3 SS TLC FIPS-140-2

512 GB Intel® PCIe® NVMe™ QLC M.2 SSD with 32 GB Intel® Optane™ memory H10

12, 13,14

1 TB PCIe® Gen3x4 NVMe™ SS TLC

2 TB PCIe® Gen3x4 NVMe™ SS TLC

12. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows

10) is reserved for system recovery software.

13. Intel® Optane™ memory system acceleration does not replace or increase the DRAM in your system. Requires 8th Gen or higher Intel® Core™ processor, BIOS version with Intel® Optane™ supported, Windows 10 64-bit, and an Intel® Rapid Storage Technology (Intel® RST) driver.

14. Intel® Optane™ memory H10 only for Intel® PCIe® NVMe™ QLC M.2 SSD.

MEMORY

Maximum Memory

16 GB LPDDR3-2133 SDRAM

Memory

8 GB LPDDR3-2133 SDRAM 16 GB LPDDR3-2133 SDRAM

Memory Slots

Memory soldered down Supports Dual Channel Memory System runs at: 2133

Page 7

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 7

NETWORKING/COMMUNICATIONS

WLAN

Intel® AX200 Wi-Fi 6 (2x2) and Bluetooth® 5 Combo, vPro™

15,47

Intel® AX200 Wi-Fi 6 (2x2) and Bluetooth® 5 Combo, non-vPro™15

WWAN

Intel® XMM™ 7360 LTE-Advanced Cat 9

Intel® XMM™ 7560 LTE-Advanced Pro Cat 1617

Miracast

Native Miracast Support18

Ethernet

No Direct Ethernet Support - Ethernet via HP accessories

15. Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices.

16. WWAN module is an optional feature, requires factory configuration and requires separately purchased service contract. Check with service provider for coverage and availability in your area. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.

17. Gigabit class Category 16 4G LTE module is optional and must be configured at the factory. Module designed for up to 1 Gbps download speeds as carriers deploy 5 carrier aggregation and 100Mhz channel bandwidth, requires activation and separately purchased service contract. Backwards compatible to HSPA 3G technologies. Check with service provider for coverage and availability in your area. Connection, upload and download speeds will vary due to network, location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.

18. Miracast is a wireless technology your PC can use to project your screen to TVs, projectors, and streaming.

47. For full Intel® vPro™ functionality, Windows, a vPro supported processor, vPro enabled c hipset, vPro enabled WLAN card and discrete TPM 2.0 are required.

AUDIO/MULTIMEDIA

Audio

Bang & Olufsen 4 Premium Stereo Speakers; 1609 x 2pcs, 1338 x 2pcs Microphones (Multi Array including World-Facing 3rd Mic) 4 Discrete Amplifiers

Camera

Hybrid HD RGB 720p + IR Camera

8,19

Webcam

IR Camera Camera Privacy Shutter

Sensors

Accelerometer Magnetometer Gyroscope Ambient light sensor

Page 8

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 8

Hall Sensor

8. HD content required to view HD images.

19. Internet access required.

KEYBOARDS/POINTING DEVICES/BUTTONS & FUNCTION KEYS

Keyboard

HP Premium Collaboration Keyboard Backlit, Spill-resistant, with HP Dura Keys

Pointing Device

Glass Clickpad Microsoft Precision Touchpad Default Gestures Support

Function Keys

F1 - Display Switching F2 - Sure View (blank if not supported) F3 - Brightness Down F4 - Brightness up F5 - Audio Mute F6 - Volume Down F7 - Volume Up F8 - Mic Mute F9 - Kybd Backlight F10 - NumLock F11 - Wireless F12 - Calendar > Share/Present > Pick Up/Accept/ Answer/Hold > Hang Up/Decline/ Reject > Delete > FN key lock

Hidden Function Keys:

Fn+R = Break Fn+S = Sys Rq Fn+C = Scroll Lock Fn+E = Insert Fn+W = Pause

Page 9

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 9

SOFTWARE AND SECURITY

Preinstalled Software

BIOS

HP BIOSphere Gen5

HP Drive Lock & Automatic Drive Lock

BIOS Update via Network Master Boot Record Security Power On Authentication Secure Erase

Absolute Persistence Module

Pre-boot Authentication

Software

HP Connection Optimizer HP Image Assistant HP Hotkey Support HP JumpStart HP Support Assistant

HP Noise Cancellation Software Buy Office (sold separately)

Manageability Features

HP Driver Packs

HP System Software Manager (SSM) HP BIOS Config Utility (BCU) HP Client Catalog HP Manageability Integration Kit Gen326

Client Security Software

HP Client Security Manager Gen5

HP Fingerprint Sensor

HP Power On Authentication Windows Defender29

Security Management

Pre-boot Authentication TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified) USB enable/disable (via BIOS) Power-on password (via BIOS) Setup password (via BIOS) Support for chassis padlocks and cable lock devices HP Sure Click

Page 10

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 10

HP Sure Start Gen5

HP Sure Run Gen2

HP Sure Recover Gen2

HP Sure Sense

HP Sure Admin

20. HP BIOSphere Gen5 is available on select HP Pro and Elite PCs. See product specifications for details. Features may vary depending on the platform and configurations.

21. HP Drive Lock & Automatic Drive Lock is not supported on NVMe drives

22. For the methods outlined in the National Institute of Standards and Technology Special Publication 800-88 "Clear" sanitation method. HP Secure Erase does not support platforms with Intel® Optane™.

23. Absolute agent is shipped turned off, and will be activated when customers activate a purchased subscription. Subscriptions can be purchased for terms ranging multiple years. Service is limited, check with Absolute for availability outside the U.S. The Absolute Recovery Guarantee is a limited warranty. Certain conditions apply. For full details visit:

http://www.absolute.com/company/legal/agreements/ computrace-agreement. Data Delete is an optional service provided

by Absolute Software. If utilized, the Recovery Guarantee is null and void. In order to use the Data Delete service, customers must first sign a Pre-Authorization Agreement and either obtain a PIN or purchase one or more RSA SecurID tokens from Absolute Software.

24. HP Support Assistant requires Windows and Internet access.

25. HP Driver Packs not preinstalled, however available for download at http://www.hp.com/go/clientmanagement.

26. HP Manageability Integration Kit can be downloaded from http://www.hp.com/go/clientmanagement.

27. HP Client Security Manager Gen5 requires Windows and is available on the select HP Pro and Elite PCs. See product specifications for details.

28. HP Fingerprint Sensor sold separately or as an optional feature.

29. Windows Defender Opt in and internet connection required for updates.

30. HP Sure Click is available on most HP PCs and supports Microsoft® Internet Explorer and Chromium™. Supported attachments include Microsoft Office (Word, Excel, PowerPoint) and PDF files in read only mode, when Microsoft Office or Adobe Acrobat are installed.

31. HP Sure Start Gen5 is available on select HP PCs with Intel processors. See product specifications for availability.

32. HP Sure Run Gen2: See product specifications for availability.

33. HP Sure Recover Gen2: See product specifications for availability. Requires an open, wired network connection. Not available on platforms with multiple internal storage drives. You must back up important files, data, photos, videos, etc. before using HP Sure Recover to avoid loss of data. HP Sure Recover (Gen1) does not support platforms with Intel® Optane™.

34. HP Sure Sense requires Windows 10. See product specifications for availability. On units with WWAN shipping to China, HP Sure Sense is only available via Softpaq download.

Page 11

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 11

POWER

Power Supply

HP Smart 65 W USB Type-C™ adapter

Supports HP Fast Charging (Up to 50% in 30 minutes)

Primary Battery

HP Long Life 2-cell, 38 Wh Li-ion polymer

HP Long Life 4-cell, 56.2 Wh Li-ion polymer37

Power Cord

Duckhead power cord (C5NS), 1.0m, Sticker, Premium Black

Power Cord C5 Sticker, Premium 1.0m

Battery life

TBD

Battery Weight

56Whr: Starting at 0.48 lb/.22 Kg 38Whr: Starting at 0.35 lb/.16 Kg

35. Availability may vary by country.

36. Recharges the battery up to 50% within 30 minutes when the system is off or in standby mode. Power adapter with a minimum capacity of 65 watts is required. After charging has reached 50% capacity, charging will return to normal. Charging time may vary +/-10% due to System tolerance.

37. Battery is internal and not replaceable by customer. Serviceable by warranty.

38. Windows 10 MM14 battery life will vary depending on various factors including product model, configuration, loaded applications, features, use, wireless functionality, and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See http://www.bapco.com for additional details.

WEIGHTS & DIMENSIONS

Product Weight

Starting at 2.2 lb (Does not include power adapter)

Starting at 0.99 kg (Does not include power adapter)39

Product Dimensions (w x d x h)

11.98 x 7.78 x 0.63 in

30.43 x 19.75 x 1.61 cm

39. Weight will vary by configuration.

Page 12

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 12

PORTS/SLOTS

Ports

2 Thunderbolt™ (USB Type-C™ connector, support Power Delivery 3.0) 1 USB 3.1 Gen 1 (Charging) 1 HDMI 1.4

1 External Nano SIM slot for WWAN

1 Headphone/Microphone Combo

40. HDMI cable sold separately.

41. SIM slot is not user accessible without WWAN configuration.

SERVICE AND SUPPORT

HP Services offers 1-year limited warranties and 90 day software limited warranty options depending on country. Batteries have a default one year limited warranty except for Long Life batteries which will have same 1-year or 3-year limited warranty as the platform. Refer to http://www.hp.com/support/batterywarranty/ for additional battery information. Onsite service and extended coverage is also available. HP Care Pack Services are optional extended service contracts that go beyond the standard limited warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at: http://www.hp.com/go/cpc.42

42. HP Care Packs are sold separately. Service levels and response times for HP Care Packs may vary depending on your geographic location. Service starts on date of hardware purchase. Restrictions and limitations apply. For details, visit

http://www.hp.com/go/cpc. HP services are governed by the applicable HP terms and conditions of service provided or

indicated to Customer at the time of purchase. Customer may have additional statutory rights according to applicable local laws, and such rights are not in any way affected by the HP terms and conditions of service or the HP Limited Warranty provided with your HP Product.

COMPATIBILITY

HP USB-C Travel Dock

T0K29AA

HP Slim Wireless Keyboard and Mouse

T6L04AA

65W USB-C Power Adapter

1HE08AA

HP External Portable USB3.0 HDD

K6A93AA

HP Keyed Cable lock

T0Y14AA

CERTIFICATION AND COMPLIANCE

ENERGY STAR® certified EPEAT® 2019 Gold in U.S.

Low halogen

TCO 8.0 Certified

43. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit

http://www.epeat.net for more information.

44. External power supplies, power cords, cables and peripherals are not Low Halogen. Service parts obtained after purchase may not be Low Halogen.

FACETS

Page 13

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 13

SYSTEM UNIT

Stand-Alone Power Requirements (AC Power)

Nominal Operating Voltage

AC 15V (Type-C) Average Operating Power

Win10

Integrated Graphics

Yes, Intel

Max Operating Power

UMA<45 W

Temperature

Operating

32° to 95° F (0° to 35° C) (not writing optical)

Non-operating

41° to 95° F (5° to 35° C) (writing optical)

Relative Humidity

Operating

32° to 95° F (0° to 35° C) (not writing optical)

Non-operating

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

Shock

Operating

40 G, 2 ms, half-sine

Non-operating

240 G, 2 ms, half-sine

Random Vibration

Operating

0.75 grms

Non-operating

1.50 grms

Altitude (unpressurized)

Operating

-50 to 10,000 ft (-15.24 to 3,048 m)

Non-operating

-50 to 40,000 ft (-15.24 to 12,192 m)

Planned Industry Standard Certifications

Yes

CSA

Yes

FCC Compliance

Yes

ENERGY STAR®

Yes45

EPEAT®

EPEAT® 2019 Gold in U.S.46

ICES

Yes

Australia

Yes

NZ A-Tick Compliance

Yes

CCC

Yes

Japan VCCI Compliance

Yes

BSMI

Yes

CE Marking Compliance

Yes

BNCI or BELUS

Yes

CIT

Yes

GOST

Yes

Saudi Arabian Compliance (ICCP)

Yes

SABS

Yes

45. Configurations of the HP Elite Dragonfly Notebook PC that are ENERGY STAR® certified are identified as HP Elite Dragonfly Notebook PC ENERGY STAR on HP websites and on http://www.energystar.gov.

46. Based on US EPEAT® registration according to IEEE 1680.1-2018 EPEAT®. Status varies by country. Visit

http://www.epeat.net for more information.

Page 14

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 14

DISPLAYS

Panel LCD 13.3 inch diagonal FHD (1920 x 1080) BrightView WLED UWVA 72% NTSC 400 nits eDP 1.4+PSR2 bent LP NWBZ

Outline Dimensions (W x H)

299.06 x 176.54 mm (max) (FPC folding included)

Active Area

293.76 x 165.24 mm (typ.)

Weight

175 g (max)

Diagonal Size

13.3 inch

Thickness

2.0mm / 3.8mm (PCB) (max)

Interface

eDP 1.4

Surface Treatment

BrightView

Touch Enabled

Yes

Contrast Ratio

1500:1 (typ.)

Refresh Rate

60 Hz

Brightness

400nits

Pixel Resolution

1920 x 1080 (FHD)

Format of LCD Pixel Arrangement

RGB Stripe

Backlight

LED

Color Gamut Coverage

72% of NTSC (sRGB 100%) (typ.)

Color Depth

8 bit

Viewing Angle

UWVA 85/85/85/85

Panel LCD 13.3 inch diagonal UHD (3840 x 2160) BrightView WLED UWVA HDR-400 sRGB 95% NTSC cg 550 nits eDP 1.4+PSR2 bent NWBZ

Outline Dimensions (W x H)

299.06 x 176.54 mm (max) (FPC folding included)

Active Area

293.76 x 165.24 mm (typ.)

Weight

200 g (max)

Diagonal Size

13.3 inch

Thickness

2.0mm / 3.8mm (PCB) (max)

Interface

eDP 1.4

Surface Treatment

BrightView

Touch Enabled

Yes

Contrast Ratio

1400:1 (typ.) 1000:1 (HDR off) (min)

Refresh Rate

60 Hz

Brightness

550 nits

Pixel Resolution

3840 x 2160 (UHD)

Format of LCD Pixel Arrangement

RGB Stripe

Page 15

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 15

Backlight

LED

Color Gamut Coverage

sRGB 95% (min)

Color Depth

8 bits + 2 FRC

Viewing Angle

UWVA 85/85/85/85

Panel LCD 13.3 inch diagonal FHD (1920 x 1080) BrightView WLED UWVA 72% NTSC 1000 nits eDP 1.4+PSR2 bent Privacy NWBZ

Outline Dimensions (W x H)

277.748 x 193.2 mm (max)

Active Area

272.448 x 191.632 mm (typ.)

Weight

190 g (max)

Diagonal Size

13.3 inch

Thickness

3.9 mm (max)

Interface

eDP 1.4 + PSR2 (4 lane)

Surface Treatment

Bright-view (BV)

Touch Enabled

Yes

Contrast Ratio

2000:1 (typ.)

Refresh Rate

60 Hz

Brightness*

1000 nits

Pixel Resolution

1920 x 1080 (FHD)

Format of LCD Pixel Arrangement

RGB

Backlight

LED

Color Gamut Coverage

72% of NTSC

Color Depth

8 bits

Viewing Angle

UWVA 85/85/85/85

*Touch-enabled display and Sure View privacy panel will lower actual brightness.

Page 16

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 16

STORAGE

SSD 128 GB 2280 M2 SATA-3 TLC

Form Factor

M.2 2280

Capacity

128 GB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

ATA-8, SATA 3.0

Maximum Sequential Read

Around 540 ~ 560 MB/s

Maximum Sequential Write

Around 500 ~ 530 MB/s

Logical Blocks

250,069,680

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

DIPM; TRIM; DEVSLP

SSD 1 TB 2280 PCIe-3x4 NVMe Three Layer Cell single-sided

Form Factor

M.2 2280

Capacity

1 TB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X4

Maximum Sequential Read

Up To 2800 MB/s

Maximum Sequential Write

Up To 1600 MB/s

Logical Blocks

2,000,409,264

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security (Option); TRIM; L1.2

SSD 256 GB 2280 M2 PCIe-3x4 SS NVMe TLC

Form Factor

M.2 2280

Capacity

256 GB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X4

Maximum Sequential Read

2580 MB/s～ 2600 MB/s

Maximum Sequential Write

900 MB/s～ 1000 MB/s

Page 17

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 17

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security (Option); TRIM; L1.2

SSD 256 GB 2280 M2 SATA-3 Self Encrypted OPAL2 Three Layer Cell

Form Factor

M.2 2280

Capacity

256 GB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

ATA-8, SATA 3.0

Maximum Sequential Read

530 MB/s～ 560 MB/s

Maximum Sequential Write

500 MB/s～ 530 MB/s

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; TCG OPAL 2.0; DIPM; TRIM; DEVSLP

SSD 2 TB 2280 PCIe-3x4 NVMe Three Layer Cell single-sided

Form Factor

M.2 2280

Capacity

2 TB

NAND Type

TLC Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X4

Maximum Sequential Read

Up To 3000 MB/s

Maximum Sequential Write

Up To 2100 MB/s

Logical Blocks

3,907,029,168

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; TCG OPAL 2.0; DIPM; TRIM; DEVSLP

SSD 512 GB 2280 M2 PCIe-3x4 SS NVMe TLC

Form Factor

M.2 2280

Capacity

512 GB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X4

Page 18

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 18

Maximum Sequential Read

2800 MB/s～ 2900 MB/s

Maximum Sequential Write

1000 MB/s～ 1800 MB/s

Logical Blocks

1,000,215,215

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security (Option); TRIM; L1.2

SSD 512 GB 2280 PCIe-3x4 NVMe Self Encrypted OPAL2 Three Layer Cell

Form Factor

M.2 2280

Capacity

512 GB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X4

Maximum Sequential Read

2800 MB/s～ 2900 MB/s

Maximum Sequential Write

1000 MB/s～ 1800 MB/s

Logical Blocks

1,000,215,215

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security (Option); TCG Opal 2.0; TRIM; L1.2

SSD 512 GB 2280 PCIe NVMe Value

Form Factor

M.2 2280

Capacity

512 GB

NAND Type

QLC/TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe

Maximum Sequential Read

Up To 1700 MB/s

Maximum Sequential Write

Up To 1500 MB/s

Logical Blocks

1,000,215,215

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security; TRIM; L1.2

SSD 256 GB 2280 PCIe NVMe Value

Form Factor

M.2 2280

Capacity

256 GB

NAND Type

TLC

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Page 19

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 19

Interface

PCIe NVMe

Maximum Sequential Read

Up To 1700 MB/s

Maximum Sequential Write

Up to 1300 MB/s

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security, TRIM; L1.2

512 GB 2280 PCIe-3x2x2 NVMe+SSD 32 GB 3D Xpoint

Form Factor

M.2 2280

Capacity

512 GB

NAND Type

QLC+3D Xpoint

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X2X2

Maximum Sequential Read

Up To 2400 MB/s

Maximum Sequential Write

Up To 1300 MB/s

Logical Blocks

1,000,215,215

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security, TRIM; L1.2

256 GB 2280 PCIe-3x2x2 NVMe+SSD 16 GB 3D Xpoint

Form Factor

M.2 2280

Capacity

256 GB

NAND Type

QLC+3D Xpoint

Height

0.09 in (2.3 mm)

Width

0.87 in (22 mm)

Weight

0.02 lb (10 g)

Interface

PCIe NVMe Gen3X2X2

Maximum Sequential Read

Up To 1450 MB/s

Maximum Sequential Write

Up To 500 MB/s

Logical Blocks

500,118,192

Operating Temperature

32° to 158°F (0° to 70°C) [ambient temp]

Features

ATA Security, TRIM; L1.2

1. For storage drives, GB = 1 billion bytes. TB = 1 trillion bytes. Actual formatted capacity is less. Up to 30 GB (for Windows 10) is reserved for system recovery software.

Page 20

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 20

NETWORKING/COMMUNICATIONS

Intel® Wi-Fi 64 AX200 and Bluetooth® 5.0 802.11ax (2 x 2) (Supporting gigabit file transfer speeds) vPro™1*

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v

Frequency Band

•802.11b/g/n/ax

2.402 – 2.482 GHz

•802.11a/n/ac/ax

4.9 – 4.95 GHz (Japan)

5.15 – 5.25 GHz

5.25 – 5.35 GHz

5.47 – 5.725 GHz

5.825 – 5.850 GHz

Data Rates

•802.11b: 1, 2, 5.5, 11 Mbps

•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &

160MHz)

• 802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz & 160MHz)

Modulation

Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM , 1024QAM

Security2

•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only

•AES-CCMP: 128 bit in hardware

•802.1x authentication

•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

•WPA2 certification

•IEEE 802.11i

•WAPI

Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

• 802.11b: +18.5dBm minimum

• 802.11g: +17.5dBm minimum

• 802.11a: +18.5dBm minimum

Page 21

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 21

• 802.11n HT20(2.4GHz): +15.5dBm minimum

• 802.11n HT40(2.4GHz): +14.5dBm minimum

• 802.11n HT20(5GHz): +15.5dBm minimum

• 802.11n HT40(5GHz): +14.5dBm minimum

• 802.11ac VHT80(5GHz): +11.5dBm minimum

• 802.11ac VHT160(5GHz): +11.5dBm minimum

• 802.11ax HT40(2.4GHz): +10dBm minimum

• 802.11ax VHT160(5GHz): +10dBm minimum

Power Consumption

• Transmit mode 2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI and PCI Express compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

•802.11b, 1Mbps: -93.5dBm maximum

•802.11b, 11Mbps: -84dBm maximum

• 802.11a/g, 6Mbps: -86dBm maximum

• 802.11a/g, 54Mbps: -72dBm maximum

• 802.11n, MCS07: -67dBm maximum

• 802.11n, MCS15: -64dBm maximum

• 802.11ac, MCS0: -84dBm maximum

• 802.11ac, MCS9: -59dBm maximum

•802.11ax, MCS11(HT40): -59dBm maximum

•802.11ax, MCS11(VHT160): -58.5dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

1. Type 2230: 2.3 x 22.0 x 30.0 mm

2. Type 1216: 1.67 x 12.0 x 16.0 mm

Weight

1. Type 2230: 2.8 g

2. Type 126: 1.3 g

Operating Voltage

3.3 v +/- 9%

Temperature

Operating Non-operating

14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)

Humidity

Operating Non-operating

10% to 90% (non-condensing) 5% to 95% (non-condensing)

Altitude

Operating Non-operating

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF LED OFF – Radio ON

Page 22

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 22

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology Bluetooth Specification

4.0/4.1/4.2/5.0/5.1 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)

Signaling Data Rate

Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps

1. Actual throughput may vary.

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 9.5 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Bluetooth Software Supported

Microsoft Windows Bluetooth Software

Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

BT4.1-ESR 5/6/7 Compliance LE Link Layer Ping LE Dual Mode LE Link Layer LE Low Duty Cycle Directed Advertising LE L2CAP Connection Oriented Channels Train Nudging & Interlaced Scan BT4.2 ESR08 Compliance LE Secure Connection- Basic/Full LE Privacy 1.2 –Link Layer Privacy LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

1. Wireless access point and Internet service is required. Availability of public wireless access point is limited.

2. Check latest software/driver release for updates on supported security features.

Page 23

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 23

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

4. Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported. *For full Intel® vPro™ functionality, Windows, a vPro supported processor, vPro enabled chipset, vPro enabled WLAN card and discrete TPM 2.0 are required. See http://Intel.com/vpro.

Intel® Wi-Fi 61 AX200 and Bluetooth 5.0 (802.11ax 2 x 2, non-vPro, supporting gigabit file transfer speeds) nonvPro

Wireless LAN Standards

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n IEEE 802.11ac IEEE 802.11ax IEEE 802.11d IEEE 802.11e IEEE 802.11h IEEE 802.11i IEEE 802.11k IEEE 802.11r IEEE 802.11v

Frequency Band

•802.11b/g/n/ax

2.402 – 2.482 GHz

•802.11a/n/ac/ax

4.9 – 4.95 GHz (Japan)

5.15 – 5.25 GHz

5.25 – 5.35 GHz

5.47 – 5.725 GHz

5.825 – 5.850 GHz

Data Rates

•802.11b: 1, 2, 5.5, 11 Mbps

•802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

•802.11n: MCS 0 ~ MCS 15, (20MHz, and 40MHz)

•802.11ac: MCS0 ~ MCS9, (1SS, and 2SS) (20MHz, 40MHz, 80MHz &

160MHz)

• 802.11ax: MCS0 ~ MCS11, (1SS and 2SS) (20MHz, 40MHz, 80MHz &

160MHz)

Modulation

Direct Sequence Spread Spectrum OFDM, BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM, 1024QAM

Security2

•IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only

•AES-CCMP: 128 bit in hardware

Page 24

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 24

•802.1x authentication

•WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES.

•WPA2 certification

•IEEE 802.11i

•WAPI

Network Architecture Models

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

Roaming

IEEE 802.11 compliant roaming between access points

Output Power

• 802.11b: +18.5dBm minimum

• 802.11g: +17.5dBm minimum

• 802.11a: +18.5dBm minimum

• 802.11n HT20(2.4GHz): +15.5dBm minimum

• 802.11n HT40(2.4GHz): +14.5dBm minimum

• 802.11n HT20(5GHz): +15.5dBm minimum

• 802.11n HT40(5GHz): +14.5dBm minimum

• 802.11ac VHT80(5GHz): +11.5dBm minimum

• 802.11ac VHT160(5GHz): +11.5dBm minimum

• 802.11ax HT40(2.4GHz): +10dBm minimum

• 802.11ax VHT160(5GHz): +10dBm minimum

Power Consumption

• Transmit mode 2.0 W

• Receive mode 1.6 W

• Idle mode (PSP) 180 mW (WLAN Associated)

• Idle mode 50 mW (WLAN unassociated)

• Connected Standby 10mW

• Radio disabled 8 mW

Power Management

ACPI compliant power management

802.11 compliant power saving mode

Receiver Sensitivity3

•802.11b, 1Mbps: -93.5dBm maximum

•802.11b, 11Mbps: -84dBm maximum

• 802.11a/g, 6Mbps: -86dBm maximum

• 802.11a/g, 54Mbps: -72dBm maximum

• 802.11n, MCS07: -67dBm maximum

• 802.11n, MCS15: -64dBm maximum

• 802.11ac, MCS0: -84dBm maximum

• 802.11ac, MCS9: -59dBm maximum

•802.11ax, MCS11(HT40): -59dBm maximum

•802.11ax, MCS11(VHT160): -58.5dBm maximum

Antenna type

High efficiency antenna with spatial diversity, mounted in the display enclosure

Two embedded dual band 2.4/5 GHz antennas are provided to the card to support WLAN MIMO communications and Bluetooth communications

Form Factor

PCI-Express M.2 MiniCard

Dimensions

1. Type 2230: 2.3 x 22.0 x 30.0 mm

2. Type 1216: 1.67 x 12.0 x 16.0 mm

Weight

1. Type 2230: 2.8 g

2. Type 126: 1.3 g

Page 25

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 25

Operating Voltage

3.3v +/- 9%

Temperature

Operating Non-operating

14° to 158° F (–10° to 70° C) –40° to 176° F (–40° to 80° C)

Humidity

Operating Non-operating

10% to 90% (non-condensing) 5% to 95% (non-condensing)

Altitude

Operating Non-operating

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

LED Activity

LED Amber – Radio OFF LED OFF – Radio ON

HP Integrated Module with Bluetooth 4.0/4.1/4.2/5.0/5.1 Wireless Technology Bluetooth Specification

4.0/4.1/4.2/5.0/5.1 Compliant

Frequency Band

2402 to 2480 MHz

Number of Available Channels

Legacy: 0~79 (1 MHz/CH) BLE: 0~39 (2 MHz/CH)

Signaling Data Rate

Legacy: 3 Mbps signaling data rate1 2.17 Mbps BLE: 1 Mbps signaling data rate1 0.2 Mbps

1. Actual throughput may vary.

Legacy: Synchronous Connection Oriented links up to 3, 64 kbps, voice channels Legacy: Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric (3-DH5) or 864 kbps symmetric (3-EV5)

Transmit Power

The Bluetooth component shall operate as a Class II Bluetooth device with a maximum transmit power of + 9.5 dBm for BR and EDR.

Power Consumption

Peak (Tx) 330 mW Peak (Rx) 230 mW Selective Suspend 17 mW

Bluetooth Software Supported

Microsoft Windows Bluetooth Software

Power Management

Microsoft Windows ACPI, and USB Bus Support

Certifications

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

Power Management Certifications

ETS 300 328, ETS 300 826 Low Voltage Directive IEC950 UL, CSA, and CE Mark

Bluetooth Profiles Supported

Page 26

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 26

LE Privacy 1.2 –Extended Scanner Filter Policies LE Data Packet Length Extension FAX Profile (FAX) Basic Imaging Profile (BIP)2 Headset Profile (HSP) Hands Free Profile (HFP) Advanced Audio Distribution Profile (A2DP)

1. Wireless access point and internet service required and sold separately. Availability of public wireless access points limited. Wi-Fi 6 is backwards compatible with prior 802.11 specs. The specifications for Wi-Fi 6 (802.11ax) are draft and are not final. If the final specifications differ from the draft specifications, it may affect the ability of the notebook to communicate with other 802.11ax devices. Only available in countries where 802.11ax is supported.

2. Check latest software/driver release for updates on supported security features.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CKK modulation) and a packet error rate of 10% for 802.11a/g (OFDM modulation).

Intel® XMM™ 7360 LTEAdvanced CAT9

Technology/Operating bands

FDD LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 1400 (Band 11), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 17 lower), 850 (Band 18 lower), 850 (Band 19 upper), 800 (Band 20), 1400 (Band 21), 850 (Band 26), 700 (Band 28), 700 (Band 29 RX only), 2300 (Band 30), 1700/2100 (Band 66). TDD LTE: 2600 (Band 38), 1900 (Band 39), 2400 (Band 40), 2500 (Band 41). HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz

Wireless protocol standards

3GPP Release 11 LTE Specification CAT.9, DL 60MHz BW throughput up to 450Mbps; UL 20MHz throughput up to 50Mbps WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification

GPS

Standalone, A-GPS (MS-A, MS-B)

GPS bands

1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz, Beidou 1561.098 MHz

Maximum data rates

LTE: 450 Mbps (Download), 50 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)

Maximum output power

LTE: 23 dBm HSPA+: 23.5 dBm

Maximum power consumption

LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average)

Form Factor

M.2, 3042-S3 Key B

Weight

5.8 g

Dimensions (Length x Width x Thickness)

42 x 30 x 2.3 mm

1. Mobile Broadband is an optional feature. Connection requires wireless data service contract, network support, and is not available in all areas. Contact service provider to determine the coverage area and availability. Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all products or in all countries.

Page 27

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 27

Intel® XMM™ 7560 LTEAdvanced Pro DL CAT16

Technology/Operating bands

FDD LTE: 2100 (Band 1), 1900 (Band 2), 1800 (Band 3), 1700/2100 (Band 4), 850 (Band 5), 2600 (Band 7), 900 (Band 8), 700 (Band 12 lower), 700 (Band 13 upper), 700 (Band 14 upper), 700 (Band 17 lower), 850 (Band 18 lower), 850 (Band 19 upper), 800 (Band 20), 1900 (Band 25), 850 (Band 26), 700 (Band 28), 700 (Band 29 RX only), 2300 (Band 30), 1700/2100 (Band 66). TDD LTE: 2600 (Band 38), 1900 (Band 39), 2400 (Band 40), 2500 (Band 41), 3500 (Band 42), 5200 (Band 46 RX only) HSPA+: 2100 (Band 1), 1900 (Band 2), 1700/2100 (Band 4), 850 (Band 5), 900 (Band 8) MHz

Wireless protocol standards

3GPP Release 12 LTE Specification DL-CAT.16, DL 100MHz BW throughput up to 978Mbps; UL-CAT.7 20MHz throughput up to 75Mbps WCDMA R99, 3GPP Release 5, 6, 7 and 8 UMTS Specification

GPS

Standalone, A-GPS (MS-A, MS-B)

GPS bands

1575.42 MHz ± 1.023 MHz, GLONASS 1596-1607MHz, Beidou 1561.098 MHz

Maximum data rates

LTE: 978 Mbps (Download), 75 Mbps (Upload) DC-HSPA+: 42 Mbps (Download), 5.76 Mbps (Upload) HSPA+: 21Mbps (Download), 5.76 Mbps (Upload)

Maximum output power

LTE: 23 dBm in all band except B41 LTE B41 HPUE = 26dBm HSPA+: 23.5 dBm

Maximum power consumption

LTE: 1,200 mA (peak); 900 mA (average) HSPA+: 1,100 mA (peak); 800 mA (average)

Form Factor

M.2, 3042-S3 Key B

Weight

6 g

Dimensions (Length x Width x Thickness)

42 x 30 x 2.3 mm

1. Gigabit class Category 16 4G LTE module is optional and must be configured at the factory. Module designed for up to 1 Gbps download speeds as carriers deploy 5 carrier aggregation and 100Mhz channel bandwidth, requires activation and separately purchased service contract. Backwards compatible to HSPA 3G technologies. Check with service provider for coverage and availability in your area. Connection, upload and download speeds will vary due to network, location, environment, network conditions, and other factors. 4G LTE not available on all products, in all regions.

Page 28

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 28

POWER

AC Adapter 65 Watt nPFC Slim USB type C Straight

1.8 m

Dimensions

88.0 x 53.5 x 21.0 mm

Weight

220 g +/- 10 g

Input

100 to 240 VAC

Input Efficiency

Average Efficiency of 25%, 50%, 75%, 100% load condition with 115Vac/230Vac Spec: 5V: 81.5% 9V: 86.7% 12V: 88.0% 15V: 89.0% 20V: 89.0%

Input frequency range

48 ~ 63 Hz

Input AC current

Max. 1.7 A at 90 Vac

Output

Output power

5V/15W 9V/27W 12V/60W 15V/65W 20V/65W

DC output

5V / 9V / 12V / 15V / 20V

Hold-up time

5ms at 115 Vac input

Output current limit

<8.0A

Connector

USB Type-C

Environmental Design

Operating temperature

32°F to 95°F (0° to 35°C)

Non-operating (storage) temperature

-4°F to 185°F (-20°to 85°C)

Altitude

0 to 16,400 ft (0 to 5000m)

Humidity

20% to 95%

Storage Humidity

10% to 95%

EMI and Safety Certifications

CE Mark - full compliance with LVD and EMC directives Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE. MTBF - over 200,000 hours at 25°C ambient condition.

AC Adapter 65 Watt nPFC USB type C Straight 1.8 m C6NS

Dimensions

74 x 74 x 28.5 mm

Weight

unit: 245 g +/- 10 g

Input

100 to 240 VAC

Input Efficiency

81.5% min at 115 Vac/ 230Vac @ 5V/3A

86.7% min at 115 Vac/ 230Vac @ 9V/3A 88% min at 115 Vac/ 230Vac @ 10V/5A 88% min at 115 Vac/ 230Vac @ 12V/5A 89% min at 115 Vac/ 230Vac @ 15V/4.33A 89% min at 115 Vac/ 230Vac @ 20V/3.25A

Input frequency range

47 ~ 63 Hz

Input AC current

1.7 A at 90 VAC and maximum load

Output

Output power

65 W

DC output

5V/9V/10V/12V/15V/20V

Hold-up time

5ms at 115 Vac input

Page 29

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 29

Output current limit

<8.0A

Connector

Non-Standard C6

Environmental Design

Operating temperature

32°F to 95°F (0°to 35°C)

Non-operating (storage) temperature

-4°F to 185°F (-20° to 85°C)

Altitude

0 to 16,400 ft (0 to 5000m)

Humidity

5% to 95%

Storage Humidity

5% to 95%

Safety Certifications

HP 4-cell Long Life Li-Ion (56 WHr)

Dimensions (H x W x L)

5.25 x 85.00 x 274.00 mm

Weight

0.259 kg

Cells/Type

4cell Lithium-Ion Polymer cell / 446872

Energy Voltage

8.8 V / 7.7 V

Amp-hour capacity

7.3 Ah / 7.0 Ah

Watt-hour capacity

56 Wh

Temperature Operating (Charging)

32˚ to 113˚ F (0˚ to 45˚ C)

Operating (Discharging)

14˚ to 122˚ F (-10˚ to 60˚ C)

Optional Travel Battery Available

HP 2-cell Long Life Li-Ion (38 WHr)

Dimensions (H x W x L)

5.20 x 79.40 x 274.00

Weight

0.16 kg

Cells/Type

2cell Lithium-Ion Polymer cell / 4453C2

Energy

Voltage

8.8 V / 7.7 V

Amp-hour capacity

4.93 Ah / 4.68 Ah

Watt-hour capacity

38 Wh

Temperature Operating (Charging)

32˚ to 113˚ F (0˚ to 45˚ C)

Operating (Discharging)

14˚ to 122˚ F (-10˚ to 60˚ C)

Optional Travel Battery Available

Page 30

QuickSpecs

HP Elite Dragonfly Notebook PC

Technical Specifications

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 30

COUNTRY OF ORIGIN

China

Page 31

QuickSpecs

HP Elite Dragonfly Notebook PC

Options and Accessories (sold separately and availability may vary by country)

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 31

Type

Description

Part #

Cases

HP Executive 14.1 Slim Top load

6KD04AA

HP Executive 15.6 Top Load

6KD06AA

HP Executive 15.6 Backpack

6KD07AA

Docking

HP Thunderbolt Dock 120W G2

2UK37AA

HP Thunderbolt Dock w/Combo Cable G2 (Hook with 230W)

3TR87AA

HP Thunderbolt Dock w/Audio Module

3YE87AA

HP Audio Module (Hook base dock required)

3AQ21AA

HP Thunderbolt Dock 120W Cable

3XB94AA

HP Thunderbolt Dock Combo Cable

3XB96AA

HP USB-C Dock G4

3FF69AA

HP USB-C Universal Dock

1MK33AA

HP USB-C Universal Dock Non Flash

3DV65AA

HP USB-C Mini Dock

1PM64AA

HP USB-C Dock G5

5TW10AA

HP USB-C/A Universal Dock G2

5TW13AA

HP EliteDisplay E223d Docking monitor

5VT82AA

HP EliteDisplay E273d Docking monitor

5WN63AA

HP E244d Docking monitor

6PA50AA

HP E274d Docking monitor

6PA56AA

Input/Output

HP Slim Wireless Keyboard and Mouse

T6L04AA

HP Slim USB Keyboard and Mouse

T6T83AA

HP Wireless (Link-5) Keyboard

T6U20AA

HP USB Essential Keyboard and Mouse

H6L29AA

HP Conferencing Keyboard

K8P74AA

HP USB Collaboration Keyboard

Z9N38AA

HP Wireless Collaboration Keyboard

Z9N39AA

HP Comfort Grip Wireless Mouse

H2L63AA

HP X4000b Bluetooth Mouse

H3T50AA

HP 3-Button USB Laser Mouse

H4B81AA

HP USB Travel Mouse

G1K28AA

HP Ultra Mobile Wireless Mouse

H6F25AA

HP Slim Bluetooth Mouse

F3J92AA

HP Wireless Premium Mouse

1JR31AA

HP USB Premium Mouse

1JR32AA

HP Elite Presenter Mouse

2CE30AA

HP UC Speaker Phone

4VW02AA

HP USB-C to USB-A Hub

Z6A00AA

HP USB-C to DP

N9K78AA

HP USB-C to VGA

N9K76AA

HP USB-C to RJ45 Adapter

V7W66AA

Page 32

QuickSpecs

HP Elite Dragonfly Notebook PC

Options and Accessories (sold separately and availability may vary by country)

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 32

HP HDMI to DVI

F5A28AA

HP HDMI to VGA

H4F02AA

HP USB 3.0 to Gigabit Adapter

N7P47AA

HP Elite USB-C Hub

4WX89AA

HP USB-C to 4.5mm Adapter

4ST73AA

Power

HP 65W USB-C Power Adapter

1HE08AA

HP 65W USB-C Slim Power Adapter

3PN48AA

HP 65W USB-C Auto Adapter

5TQ76AA

HP USB-C Notebook Power Bank

2NA10AA

Security

HP Nano Keyed Cable Lock

1AJ39AA

HP Nano Dual-Head Keyed Cable Lock

1AJ41AA

HP Nano Keyed Cable Lock

1AJ39AA

HP Nano Dual-Head Keyed Cable Lock

1AJ41AA

HP Sure Key Cable Lock

6UW42AA

UCC

HP Stereo 3.5mm Headset

T1A66AA

HP Stereo USB Headset

T1A67AA

HP UC Wireless Mono Headset

W3K08AA

HP UC Wireless Duo Headset

W3K09AA

Page 33

QuickSpecs

HP Elite Dragonfly Notebook PC

Summary of Changes

c06442027 — DA 16518—Worldwide — Version 1 — October 22, 2019

Page 33

Date of change:

Version History:

Description of change:

V1 to V2

Copyright © 2019 HP Development Company, L.P. The only warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

Intel®, Core®, Optane®, Thunderbolt and Intel vPro™ are trademarks or registered trademarks of Intel Corporation or its

subsidiaries in the United States and other countries. Bluetooth is a trademark owned by its proprietor and used by HP Inc. under license. USB Type-C™ and USB-C™ are trademarks of USB Implementers Forum. ENERGY STAR is a registered trademark of the U.S. Environmental Protection Agency. All other trademarks are the property of their respective owners.
