HP Compaq 6720t User Manual
HP Compaq 6720t Mobile Thin Client
End-User Reference Guide
© Copyright 2008 Hewlett-Packard
Development Company, L.P.
Windows is a U.S. registered trademark of
Microsoft Corporation.
The information contained herein is subject
to change without notice. The only
warranties for HP products and services are
set forth in the express warranty statements
accompanying such products and services.
Nothing herein should be construed as
constituting an additional warranty. HP shall
not be liable for technical or editorial errors
or omissions contained herein.
Second Edition: March 2008
First Edition: January 2008
Document Part Number: 466204-002
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not
place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a
hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft
surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact
the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the
AC adapter comply with the user-accessible surface temperature limits defined by the International
Standard for Safety of Information Technology Equipment (IEC 60950).
iii
iv Safety warning notice
Product notice
This user guide describes features that are common to most models. Some features may not be
available on your computer.
v
vi Product notice
Table of contents
1 Notebook tour
Identifying the hardware ....................................................................................................................... 1
Top components .................................................................................................................. 1
Pointing devices .................................................................................................. 1
Lights ................................................................................................................... 2
Buttons and switches .......................................................................................... 3
Keys .................................................................................................................... 4
Front components ................................................................................................................ 5
Right-side components ........................................................................................................ 5
Left-side components .......................................................................................................... 5
Rear components ................................................................................................................ 6
Bottom components ............................................................................................................. 6
Wireless antennae ............................................................................................................... 7
Identifying the labels ............................................................................................................................. 8
2 Enhanced Write Filter
Using the Enhanced Write Filter ........................................................................................................... 9
3 Pointing devices
Using pointing devices ....................................................................................................................... 10
Setting pointing device preferences ................................................................................... 10
Connecting an external mouse .......................................................................................... 10
Using the keyboard ............................................................................................................................ 11
Using hotkeys .................................................................................................................... 11
Using the keypads .............................................................................................................................. 13
Using the embedded numeric keypad ............................................................................... 13
Using an optional external numeric keypad ....................................................................... 14
4 Power
Power control and light locations ........................................................................................................ 15
Displaying system information (fn+esc) ............................................................ 11
Initiating Standby (fn+f3) ................................................................................... 12
Switching the screen image (fn+f4) ................................................................... 12
Viewing battery charge information (fn+f8) ....................................................... 12
Decreasing screen brightness (fn+f9) ............................................................... 12
Increasing screen brightness (fn+f10) ............................................................... 12
Enabling and disabling the embedded numeric keypad .................................... 13
Switching key functions on the embedded numeric keypad ............................. 14
vii
Shutting down the computer ............................................................................................................... 16
Setting power options ......................................................................................................................... 17
Using power-saving states ................................................................................................. 17
Initiating and exiting Standby ............................................................................ 17
Using the battery meter ..................................................................................................... 18
Using battery power ........................................................................................................................... 18
Displaying the remaining battery charge ........................................................................... 19
Inserting or removing the battery ....................................................................................... 19
Charging a battery ............................................................................................................. 20
Managing low battery levels .............................................................................................. 21
Identifying low battery levels ............................................................................. 21
Resolving a low battery level ............................................................................. 21
Resolving a low battery level when external power is available ....... 21
Resolving a low battery level when a charged battery is
available ........................................................................................... 21
Resolving a low battery level when no power source is
available ........................................................................................... 21
Conserving battery power .................................................................................................. 21
Storing a battery ................................................................................................................ 22
Disposing of a used battery ............................................................................................... 22
Using external AC power .................................................................................................................... 22
Connecting the AC adapter ............................................................................................... 23
5 Multimedia
Using multimedia hardware ................................................................................................................ 24
Using multimedia software ................................................................................................................. 26
6 Wireless
About integrated wireless devices ...................................................................................................... 28
Using wireless controls ....................................................................................................................... 28
Using WLAN ....................................................................................................................................... 28
Using the audio features .................................................................................................... 24
Using the audio-in (microphone) jack ................................................................ 25
Using the audio-out (headphone) jack .............................................................. 25
Adjusting the volume ......................................................................................... 25
Using the video features .................................................................................................... 26
Using the external monitor port ......................................................................... 26
Opening preinstalled multimedia software ......................................................................... 26
Using multimedia software ................................................................................................. 27
Preventing playback disruptions ........................................................................................ 27
Observing the copyright warning ....................................................................................... 27
Using the wireless button .................................................................................................. 28
Using operating system controls ........................................................................................ 28
Setting up a WLAN ............................................................................................................ 29
Connecting to a WLAN ...................................................................................................... 30
Using wireless security features ........................................................................................ 30
Identifying a WLAN device ................................................................................................. 30
7 Modem and LAN
viii
Using a modem .................................................................................................................................. 31
Connecting a modem cable ............................................................................................... 31
Connecting a country-specific modem cable adapter ........................................................ 32
Selecting a location setting ................................................................................................ 33
Connecting to a local area network .................................................................................................... 34
8 Security
Protecting the computer ..................................................................................................................... 36
Using passwords ................................................................................................................................ 37
Setting passwords in Windows .......................................................................................... 37
Using a power-on password .............................................................................................. 37
Installing a security cable ................................................................................................................... 39
9 Connecting hardware
Using a USB device ........................................................................................................................... 40
Connecting a USB device .................................................................................................. 40
Removing a USB device .................................................................................................... 41
Using the docking connector .............................................................................................................. 41
Using PC Cards .................................................................................................................................. 41
Inserting and removing a PC Card .................................................................................... 41
Viewing the current location selection ............................................................... 33
Solving travel connection problems .................................................................. 33
Managing a power-on password ....................................................................... 38
Entering a power-on password ......................................................................... 38
Requiring a power-on password at restart ........................................................ 38
10 Hardware upgrades
Identifying installed drives .................................................................................................................. 44
Handling drives ................................................................................................................................... 44
Using optical drives (select models only) ........................................................................................... 45
Inserting an optical disc (CD or DVD) ................................................................................ 46
Removing an optical disc (CD or DVD) ............................................................................. 47
When the disc tray opens .................................................................................. 47
When the disc tray does not open ..................................................................... 48
Appendix A Routine care
Cleaning the display ........................................................................................................................... 49
Cleaning the keyboard ....................................................................................................................... 49
Traveling and shipping ....................................................................................................................... 49
Index ................................................................................................................................................................... 51
ix
x
1 Notebook tour
Identifying the hardware
Components included with the computer may vary by region and model. The illustrations in this chapter
identify the standard features on most computer models.
Top components
Pointing devices
Component Description
(1) TouchPad* Moves the pointer and selects or activates items on the
screen.
(2) Left TouchPad button* Functions like the left button on an external mouse.
(3) TouchPad scroll zone Scrolls up or down.
(4) Right TouchPad button* Functions like the right button on an external mouse.
*This table describes factory settings. To view or change pointing device preferences, select Start > Control Panel > Printers
and Other Hardware > Mouse.
Identifying the hardware 1
Lights
Component Description
(1) Power lights* (2)
(2)
(3) Caps lock light On: Caps lock is on.
(4) Num lock light On: Num lock is on.
(5) Volume mute light On: Computer sound is turned off.
(6) Battery light
Wireless lights† (2)
On: The computer is on.
●
Blinking: The computer is in Standby.
●
Off: The computer is off.
●
Blue: An integrated wireless device, such as a
●
wireless local area network (WLAN) device, is on.
Off: All wireless devices are off.
●
Amber: A battery is charging.
●
Blue: A battery is close to full charge capacity.
●
Blinking amber: A battery that is the only available
●
power source has reached a low battery level.
When the battery reaches a critical battery level, the
battery light begins blinking rapidly.
Off: If the computer is plugged into an external
●
power source, the light turns off when all batteries
2 Chapter 1 Notebook tour
Component Description
(7) Drive light Blinking: The flash drive or optional optical drive is being
*The 2 power lights display the same information. The light on the power button is visible only when the computer is open. The
power light on the front of the computer is visible whether the computer is open or closed.
†
The 2 wireless lights display the same information. The light on the wireless button is visible only when the computer is open.
The wireless light on the front of the computer is visible whether the computer is open or closed.
Buttons and switches
in the computer are fully charged. If the computer is
not plugged into an external power source, the light
stays off until the battery reaches a low battery
level.
accessed.
Component Description
(1) Power button
(2) Internal display switch Turns off the display if the display is closed while the
(3) Wireless button Turns the wireless feature on or off, but does not
When the computer is off, press the button to turn
●
on the computer.
When the computer is in Standby, press the button
●
briefly to exit Standby.
If the computer has stopped responding and Windows®
shutdown procedures are ineffective, press and hold the
power button for at least 5 seconds to turn off the
computer.
To learn more about your power settings, right-click the
Power Meter icon in the notification area, and then click
Adjust Power Properties.
power is on.
establish a wireless connection.
NOTE: A wireless network must be set up in order to
establish a wireless connection.
Identifying the hardware 3
Keys
Component Description
(4) Volume mute button Mutes and restores computer sound.
(5) Volume down button Decreases speaker sound.
(6) Volume up button Increases speaker sound.
Component Description
(1) esc key Displays system information when pressed in
combination with the fn key.
(2) fn key Executes frequently used system functions when
(3) Windows logo key Displays the Windows Start menu.
(4) Windows applications key Displays a shortcut menu for items beneath the pointer.
(5) Embedded numeric keypad keys Can be used like the keys on an external numeric
(6) Function keys Execute frequently used system functions when pressed
pressed in combination with a function key or the esc
key.
keypad.
in combination with the fn key.
4 Chapter 1 Notebook tour
Front components
Component Description
(1) Display release latch Opens the computer.
Right-side components
Component Description
(1) Audio-out (headphone) jack Produces sound when connected to optional powered
(2) Audio-in (microphone) jack Connects an optional computer headset microphone,
(3) USB ports (2) Connect optional USB devices.
(4) Optical drive (select models only) Reads an optical disc.
Left-side components
stereo speakers, headphones, ear buds, a headset, or
television audio.
stereo array microphone, or monaural microphone.
Component Description
(1) Security cable slot Attaches an optional security cable to the computer.
Identifying the hardware 5
Component Description
(2) RJ-45 (network) jack Connects a network cable.
(3) RJ-11 (modem) jack Connects a modem cable.
(4) Vent Enables airflow to cool internal components.
(5) USB port Connects an optional USB device.
(6) PC Card slot Supports optional Type I and Type II 32-bit (CardBus) or
Rear components
NOTE: The security cable is designed to act as a
deterrent, but it may not prevent the computer from being
mishandled or stolen.
16-bit PC Cards.
Components Description
(1) Power connector Connects an AC adapter.
(2) External monitor port Connects an external VGA monitor or projector.
Bottom components
6 Chapter 1 Notebook tour
Component Description
(1) Battery bay Holds the battery.
(2) Battery release latches (2) Release the battery from the battery bay.
(3) Business card holder Holds a standard-size business card.
(4) Flash drive bay Holds the flash drive.
(5) Docking connector Connects to an optional docking device.
(6) Memory module compartment Contains the memory module slot.
(7) Vent Enables airflow to cool internal components.
(8) Accessory battery connector Connects an optional accessory battery.
Wireless antennae
Wireless antennae send and receive signals from one or more wireless devices. These antennae are
not visible from the outside of the computer.
NOTE: For optimal transmission, keep the areas immediately around the antennae free from
obstructions.
To see wireless regulatory notices, refer to the section of the Regulatory, Safety and Environmental
Notices that applies to your country or region. These notices are located in the printed Getting Started
guide.
Identifying the hardware 7
Identifying the labels
The labels affixed to the computer provide information you may need when you troubleshoot system
problems or travel internationally with the computer:
Service tag—Provides the product brand and series name, serial number (s/n), and product
●
number (p/n) of your computer. Have this information available when you contact technical support.
The service tag label is affixed to the bottom of the computer.
Regulatory label—Provides regulatory information about the computer. The regulatory label is
●
affixed to the bottom of the computer.
Modem approval label—Provides regulatory information about the modem and lists the agency
●
approval markings required by some of the countries in which the modem has been approved for
use. You may need this information when traveling internationally. The modem approval label is
affixed to the bottom of the computer.
Wireless certification label(s)—Provide information about wireless devices and the approval
●
markings of some of the countries in which the devices have been approved for use. If your
computer model includes one or more wireless devices, one or more certification labels are
included with your computer. You may need this information when traveling internationally.
Wireless certification labels are affixed inside the memory module compartment.
8 Chapter 1 Notebook tour
2 Enhanced Write Filter
Using the Enhanced Write Filter
The Enhanced Write Filter (EWF) provides a secure environment for your computer by protecting it from
undesired flash memory writes. In order to save changes to your system configuration settings, you
must commit your changes in the EWF. Otherwise, the new settings will be lost when the computer is
shut down or restarted.
For additional information on the EWF, see your network administrator.
Using the Enhanced Write Filter 9
3 Pointing devices
Using pointing devices
To move the pointer, slide your finger across the TouchPad surface in the direction you want the pointer
to go. Use the TouchPad buttons like the corresponding buttons on an external mouse. To scroll up and
down using the TouchPad vertical scroll zone, slide your finger up or down over the lines.
NOTE: If you are using the TouchPad to move the pointer, you must lift your finger off the TouchPad
before moving it to the scroll zone. Simply sliding your finger from the TouchPad to the scroll zone will
not activate the scrolling function.
Setting pointing device preferences
Use Mouse Properties in Windows to customize settings for pointing devices, such as button
configuration, click speed, and pointer options.
To access Mouse Properties, select Start > Control Panel > Printers and Other Hardware >
Mouse.
Connecting an external mouse
You can connect an external USB mouse to the computer using one of the USB ports on the computer.
A USB mouse can also be connected to the computer using the ports on an optional docking device.
10 Chapter 3 Pointing devices
Loading...
