HP (Hewlett-Packard) C2M71UA-ABA User Manual

User Guide

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel is a trademark of Intel Corporation in the U.S. and other countries. Windows is a U.S. registered trademark of Microsoft Corporation. SD Logo is a trademark of its proprietor.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: November 2012

Document Part Number: 682638-001

Product notice

This guide describes features that are common to most models. Some features may not be available on your computer.

Software terms

By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a refund subject to the refund policy of your place of purchase.

For any further information or to request a full refund of the computer, please contact your local point of sale (the seller).

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not

place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to come into contact with the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950).

iii

iv Safety warning notice

Table of contents

1 Starting right ................................................................................................................................................... 1

Best practices ....................................................................................................................................... 1

Fun things to do .................................................................................................................................... 2

More HP resources .............................................................................................................................. 3

2 Getting to know your computer ..................................................................................................................... 4

Finding your hardware and software information ................................................................................. 4

Locating hardware ............................................................................................................... 4

Locating software ................................................................................................................. 4

Right side ............................................................................................................................................. 5

Left side ................................................................................................................................................ 7

Display .................................................................................................................................................. 9

Top ..................................................................................................................................................... 10

TouchPad .......................................................................................................................... 10

Lights ................................................................................................................................. 11

Buttons, speakers, and antennas ...................................................................................... 13

Keys ................................................................................................................................... 15

Bottom ................................................................................................................................................ 16

Labels ................................................................................................................................................. 17

3 Connecting to a network .............................................................................................................................. 19

Connecting to a wireless network ....................................................................................................... 19

Using the wireless controls ................................................................................................ 19

Using the wireless button .................................................................................. 20

Using operating system controls ....................................................................... 21

Using a WLAN ................................................................................................................... 21

Using an Internet service provider .................................................................... 21

Setting up a WLAN ............................................................................................ 22

Configuring a wireless router ............................................................................ 22

Protecting your WLAN ....................................................................................... 22

Connecting to a WLAN ...................................................................................... 23

Using Bluetooth wireless devices ...................................................................................... 23

Connecting to a wired network ........................................................................................................... 24

Connecting to a local area network (LAN) ......................................................................... 24

4 Enjoying entertainment features ................................................................................................................. 25

Using the webcam .............................................................................................................................. 26

Sharing media and data between devices ......................................................................................... 26

Finding more information ................................................................................................... 26

Using sMedio 360 Suite ..................................................................................................... 27

Accessing sMedio 360 Suite ............................................................................. 27

Using sMedio 360 TrueSync .............................................................................................. 27

Accessing sMedio 360 TrueSync ...................................................................... 27

Using sMedio 360 TrueLink+ ............................................................................................. 28

Determining your Android phone OS version .................................................... 28

Downloading the sMedio 360 TrueLink+ app on your phone ............................ 28

Sharing media from your phone to your computer ............................................ 28

Using audio ........................................................................................................................................ 29

Connecting speakers ......................................................................................................... 29

Connecting headphones .................................................................................................... 29

Connecting a microphone .................................................................................................. 29

Using Beats Audio ............................................................................................................. 29

Accessing Beats Audio Control Panel ............................................................... 29

Enabling and disabling Beats Audio .................................................................. 29

Checking the sound ........................................................................................................... 30

Using video ......................................................................................................................................... 30

Connecting an HDMI device .............................................................................................. 31

Configuring HDMI audio settings ...................................................................... 31

Connecting a Thunderbolt DisplayPort device ................................................................... 32

Using Intel Wireless Display and Wireless Music (select models only) ............................. 33

Managing your audio and video files .................................................................................................. 33

5 Navigating using touch gestures, pointing devices and the keyboard ................................................... 34

Using the TouchPad ........................................................................................................................... 35

Using TouchPad gestures .................................................................................................................. 36

Tapping .............................................................................................................................. 36

Scrolling ............................................................................................................................. 37

Pinching/stretching ............................................................................................................ 37

Rotating (select models only) ............................................................................................ 38

2-finger click (select models only) ...................................................................................... 38

Flicking (select models only) .............................................................................................. 39

Edge swipes ...................................................................................................................... 39

Right-edge swipe .............................................................................................. 39

Top-edge swipe ................................................................................................. 40

Left-edge swipe ................................................................................................. 40

Using touch screen gestures .............................................................................................................. 41

One-finger slide ................................................................................................................. 41

Tapping .............................................................................................................................. 42

Scrolling ............................................................................................................................. 42

Pinching/stretching ............................................................................................................ 43

Rotating (select models only) ............................................................................................ 43

Edge swipes ...................................................................................................................... 44

Right-edge swipe .............................................................................................. 44

Left-edge swipe ................................................................................................. 44

Top-edge swipe and bottom-edge swipe .......................................................... 45

Keyboard backlight ............................................................................................................................. 46

Using the keyboard and mouse .......................................................................................................... 47

Using the keys ................................................................................................................... 47

Using the action keys ........................................................................................ 47

Using Windows 8 shortcut keys ........................................................................ 49

Using the hot keys ............................................................................................. 50

6 Managing power ............................................................................................................................................ 51

Initiating Sleep and Hibernation ......................................................................................................... 52

Intel Rapid Start Technology (select models only) ............................................................ 52

Initiating and exiting Sleep ................................................................................................. 52

Enabling and exiting user-initiated Hibernation ................................................................. 53

Setting password protection on wakeup ............................................................................ 53

Using the power meter and power settings ........................................................................................ 54

Selecting a power plan ....................................................................................................................... 55

Running on battery power .................................................................................................................. 56

Factory-sealed battery ....................................................................................................... 56

Finding battery information ................................................................................................ 56

Conserving battery power .................................................................................................. 56

Identifying low battery levels .............................................................................................. 57

Resolving a low battery level ............................................................................................. 57

Resolving a low battery level when external power is available ........................ 57

Resolving a low battery level when no power source is available ..................... 57

Resolving a low battery level when the computer cannot exit Hibernation ....... 57

Running on external AC power .......................................................................................................... 58

Troubleshooting power problems ...................................................................................... 59

HP CoolSense (select models only) ................................................................................................... 60

Refreshing your software content with Intel Smart Connect Technology (select models only) .......... 61

vii

Shutting down (turning off) the computer ........................................................................................... 62

7 Managing and sharing information ............................................................................................................. 63

Using a USB device ........................................................................................................................... 63

Connecting a USB device .................................................................................................. 64

Removing a USB device .................................................................................................... 65

Connecting a powered USB device ................................................................................... 65

Inserting and removing a digital storage card .................................................................................... 66

8 Maintaining your computer .......................................................................................................................... 67

Improving performance ...................................................................................................................... 67

Using HP 3D DriveGuard (select models only) .................................................................. 67

Using Disk Defragmenter ................................................................................................... 67

Using Disk Cleanup ........................................................................................................... 68

Updating programs and drivers .......................................................................................................... 69

Cleaning your computer ..................................................................................................................... 70

Cleaning the display, sides, and cover .............................................................................. 70

Cleaning the TouchPad and keyboard .............................................................................. 70

Traveling with or shipping your computer ........................................................................................... 71

9 Securing your computer and information .................................................................................................. 72

Using passwords ................................................................................................................................ 72

Setting Windows passwords .............................................................................................. 73

Setting Setup Utility (BIOS) passwords ............................................................................. 73

TPM Embedded Security device (select models only) ....................................................................... 74

Using Internet security software ......................................................................................................... 74

Using antivirus software ..................................................................................................... 75

Using firewall software ....................................................................................................... 75

Installing software updates ................................................................................................................. 75

Installing Windows updates ............................................................................................... 75

Installing HP and third-party software updates .................................................................. 76

Securing your wireless network .......................................................................................................... 76

Backing up your software applications and information ..................................................................... 76

Using an optional security cable lock ................................................................................................. 76

10 Using Setup Utility (BIOS) and System Diagnostics ............................................................................... 77

Starting Setup Utility (BIOS) ............................................................................................................... 77

Updating the BIOS ............................................................................................................................. 77

Determining the BIOS version ........................................................................................... 77

Downloading a BIOS update ............................................................................................. 78

viii

Using System Diagnostics .................................................................................................................. 79

11 Backing up, restoring, and recovering ..................................................................................................... 80

Creating recovery media and backups ............................................................................................... 81

Creating HP Recovery media ............................................................................................ 82

Restore and recovery ......................................................................................................................... 83

Using Windows Refresh for quick and easy recovery ....................................................... 84

Remove everything and reinstall Windows ........................................................................ 84

Recovering using HP Recovery Manager .......................................................................... 85

What you need to know ..................................................................................... 85

Using the HP Recovery partition to recover a minimized image (select

models only) ...................................................................................................... 86

Using HP Recovery media to recover ............................................................... 86

Changing the computer boot order ................................................................... 87

Removing the HP Recovery partition ................................................................................. 87

12 Specifications .............................................................................................................................................. 88

Input power ......................................................................................................................................... 88

Operating environment ....................................................................................................................... 89

13 Electrostatic Discharge .............................................................................................................................. 90

Index ................................................................................................................................................................... 91

1 Starting right

This computer is a powerful tool designed to enhance your work and entertainment. Read this chapter to learn about best practices after setup, fun things to do with your computer, and where to find additional HP resources.

Best practices

To get the most out of your smart investment, after you set up and register the computer, we recommend the following steps:

Take a minute to browse the printed Windows 8 Basics guide to explore the new Windows® 8

●

features.

TIP: To quickly return to the computer Start screen from an open app or the Windows desktop,

press the Windows logo key

return you to the previous screen.

If you haven’t already done so, connect to a wired or wireless network. See details in

●

to a network on page 19.

Become familiar with the computer hardware and software. For information, see

●

your computer on page 4 and Enjoying entertainment features on page 25.

Update or purchase antivirus software. Learn more at

●

Back up your hard drive by creating recovery discs or a recovery flash drive. See

●

restoring, and recovering on page 80.

on your keyboard. Pressing the Windows logo key again will

Using antivirus software on page 75.

Connecting

Getting to know

Backing up,

Best practices 1

Fun things to do

You know that you can watch a YouTube video on the computer. But did you know that you can

●

also connect your computer to a TV or gaming console? For more information, see

on page 30.

You know that you can listen to music on the computer. But did you know that you can also

●

stream live radio to the computer and listen to music or talk radio from all over the world? See

Using audio on page 29.

You know that you can create a powerful presentation with Microsoft applications. But did you

●

know you can also connect to a projector to share your ideas with a group? See

HDMI device on page 31 or Connecting a Thunderbolt DisplayPort device on page 32.

Experience music the way the artist intended, with deep controlled base and clear, pure sound.

●

Using Beats Audio on page 29.

See

Use the TouchPad, touch screen, and the new Windows 8 touch gestures for smooth control of

●

images and pages of text. See

gestures on page 41.

Using video

Connecting an

Using TouchPad gestures on page 36 and Using touch screen

2 Chapter 1 Starting right

More HP resources

You have already used Setup Instructions to turn on the computer and locate this guide. To locate product details, how-to information, and more, use this table.

Resource Contents

Setup Instructions

Windows 8 Basics guide ● Overview of using and navigating with Windows® 8

Help and Support

To access Help and Support, from the Start screen, type h, and then select Help and Support. For U.S. support, go to worldwide support, go to

country/us/en/wwcontact_us.html.

Safety & Comfort Guide

To access this guide, select the HP Support Assistant app from the Start screen, select My computer, and then select User guides, or go to

http://www.hp.com/ergo.

Worldwide support web page

To get support in your language, go to

http://welcome.hp.com/country/us/en/ wwcontact_us.html.

Regulatory, Safety and Environmental Notices

To access this guide, select the HP Support Assistant app from the Start screen, select My computer, and then select User guides.

http://www.hp.com/go/contactHP. For

http://welcome.hp.com/

Overview of computer setup and features

●

A broad range of how-to information and troubleshooting tips

●

● Proper workstation setup

● Guidelines for posture and work habits that increase your

comfort and decrease your risk of injury

Electrical and mechanical safety information

●

● Online chat with an HP technician

● Email support

Support telephone numbers

●

HP service center locations

●

Important regulatory notices

●

Limited Warranty*

To access this warranty, select the HP Support

Assistant app, select My computer, and then select Warranty and services, or go to

go/orderdocuments.

*You can find the expressly provided HP Limited Warranty applicable to your product located with the user guides on your computer and/or on the CD/DVD provided in the box. In some countries/regions, HP may provide a printed HP Limited Warranty in the box. For countries/regions where the warranty is not provided in printed format, you may request a printed copy from

●

● Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy

● Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

When you request a printed copy of your warranty, please include your product number, warranty period (found on your service label), name, and postal address.

IMPORTANT: Do NOT return your HP product to the addresses above. For U.S. support, go to

contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.

http://www.hp.com/go/orderdocuments or write to:

North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, USA

http://www.hp.com/

● Specific warranty information about this computer

http://www.hp.com/go/

More HP resources 3

2 Getting to know your computer

Finding your hardware and software information

Locating hardware

To find out what hardware is installed on your computer:

1. From the Start screen, type c, and then select Control Panel.

2. Select System and Security, and then in the System area, select Device Manager.

A list displays all the devices installed in your computer.

Locating software

To find out what software is installed on your computer, from the Start screen, right-click using

▲

the mouse or swipe from the top of the TouchPad to display the Apps, and then select the All apps icon.

4 Chapter 2 Getting to know your computer

Right side

Component Description

(1)

(2)

(3)

Digital Media Card Reader Supports the following digital card formats:

● Secure Digital (SD) Memory Card

● Secure Digital High Capacity (SDHC) Memory Card

● Secure Digital Extended Capacity (SDxC) Memory

Card

● MultiMediaCard (MMC)

Audio-out (headphone) jack/ Audio-in (microphone) jack

USB 2.0 charging port Connects an optional USB device. This port can also

Connects an optional device such as a headset, power stereo speakers, headphones, earbuds, television audio, or a headset microphone.

WARNING! To reduce the risk of personal injury, adjust

the volume before putting on headphones, earbuds, or a headset. For additional safety information, refer to the Regulatory, Safety, and Environmental Notices. To access this guide, from the Start screen, select the HP Support

Assistant app, select My computer, and then select User guides.

NOTE: When a device is connected to the jack, the

computer speakers are disabled.

charge select models of cell phones and MP3 players, even when the computer is off.

(4) AC adapter light

NOTE: A USB charging port (also referred to as a USB

powered port) allows you to charge connected USB devices. Some USB devices require power and require you to use a powered port.

NOTE: For details about different types of USB ports, see

Using a USB device on page 63.

White: The AC adapter is connected and the battery is

●

charged.

● Amber: The AC adapter is connected and the battery

is charging.

Off: The computer is using battery power.

●

Right side 5

Component Description

(5)

(6)

Power connector Connects an AC adapter.

Security cable slot Attaches an optional security cable to the computer.

NOTE: The security cable is designed to act as a

deterrent, but it may not prevent the computer from being mishandled or stolen.

6 Chapter 2 Getting to know your computer

Left side

Component Description

(1) RJ-45 (network) jack lights (2)

(2)

(3)

(4)

(5)

RJ-45 (network) jack Connects a network cable.

HDMI port Connects an optional video or audio device, such as a

Thunderbolt DisplayPort Connects an optional high-resolution display device or a

USB 3.0 ports (2) Connect optional USB 3.0 devices and provide enhanced

White: The computer is connected to a network.

●

● Amber: The computer is connected to a network and

activity is occurring on the network.

high-definition television, any compatible digital or audio component, or a high-speed HDMI device.

high-performance data device.

NOTE: Thunderbolt is new technology. Install all the

latest drivers for your Thunderbolt device before connecting the device to the Thunderbolt DisplayPort. Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To determine whether your device is Thunderbolt Certified for Windows, see

https://thunderbolttechnology.net/products.

USB power performance.

NOTE: The USB 3.0 port is also compatible with USB 1.0

and USB 2.0 devices.

Left side 7

Component Description

(6)

(7)

Hard drive light

Power light ● White: The computer is on.

Blinking white: The hard drive is being accessed.

●

● Amber: HP 3D DriveGuard has temporarily parked the

hard drive.

NOTE: For information about HP 3D DriveGuard,

see Using HP 3D DriveGuard (select models only)

on page 67.

Blinking white: The computer is in the Sleep state,

●

which is an energy-saving mode. The computer shuts off power to the display and other unneeded components.

Off: The computer is off or in Hibernation. Hibernation

●

is an energy-saving mode that uses the least amount of power.

NOTE: For select models, the Intel® Rapid Start

Technology feature is enabled at the factory. Rapid Start Technology allows your computer to resume quickly from inactivity. For more information, see

Rapid Start Technology (select models only) on page 52.

Intel

8 Chapter 2 Getting to know your computer

Display

Component Description

(1) Internal display switch Turns off the display and initiates Sleep if the display is closed

(2) Internal microphones (2) Record sound.

(3) Webcam light On: The webcam is in use.

(4) Webcam Records video, captures still photographs, and provides access

while the power is on.

NOTE: The internal display switch is not visible from the

outside of the computer.

to video conferences and online chat by means of streaming video.

To use the webcam, from the Start screen type c, and then select CyberLink YouCam.

Display 9

Top

TouchPad

Component Description

(1) TouchPad on/off button Turns the TouchPad on or off.

(2) TouchPad light ● On: The TouchPad is off.

Off: The TouchPad is on.

●

(3) TouchPad zone Moves the on-screen pointer and selects or activates items

(4) Left TouchPad button Functions like the left button on an external mouse.

(5) Right TouchPad button Functions like the right button on an external mouse.

on the screen.

NOTE: The TouchPad also supports gestures. For more

information, see

Using TouchPad gestures on page 36.

10 Chapter 2 Getting to know your computer

Lights

Component Description

(1)

(2)

(3)

(4)

Power light

Keyboard backlight light Identifies the keyboard backlight action key.

Mute light ● Amber: Computer sound is off.

Wireless light ● White: An integrated wireless device, such as a

White: The computer is on.

●

● Blinking white: The computer is in the Sleep state,

which is an energy-saving mode. The computer shuts off power to the display and other unneeded components.

● Off: The computer is off or in Hibernation. Hibernation

is an energy-saving mode that uses the least amount of power to preserve your work.

NOTE: For select models, the Intel® Rapid Start

Technology feature is enabled at the factory. Rapid Start Technology allows your computer to resume quickly from inactivity. For more information, see

Rapid Start Technology (select models only) on page 52.

Off: Computer sound is on.

●

wireless local area network (WLAN) device and/or a Bluetooth® device, is on.

Intel

● Amber: All wireless devices are off.

Top 11

Component Description

(5) Caps lock light On: Caps lock is on, which switches the keys to all capital

(6) TouchPad light

letters.

On: The TouchPad is off.

●

● Off: The TouchPad is on.

12 Chapter 2 Getting to know your computer

Buttons, speakers, and antennas

Component Description

(1)

Power button

When the computer is off, press the button to turn on

●

the computer.

● When the computer is in the Sleep state, press the

button briefly to exit Sleep.

When the computer is in Hibernation, press the button

●

briefly to exit Hibernation.

CAUTION: Pressing and holding down the power button

will result in the loss of unsaved information.

If the computer has stopped responding and Windows® shutdown procedures are ineffective, press and hold the power button down for at least 5 seconds to turn off the computer.

NOTE: For select models, the Intel® Rapid Start

Technology feature is enabled at the factory. Rapid Start Technology allows your computer to resume quickly from inactivity. For more information, see

Technology (select models only) on page 52.

To learn more about your power settings, follow these steps or see

Managing power on page 51.

1. From the Start screen, type p.

2. In the search box, type power.

Intel Rapid Start

3. Select Settings, and then select Power options.

(2) WLAN antennas (2)* Send and receive wireless signals to communicate with

wireless local area networks (WLANs).

Top 13

Component Description

(3) Speakers (2) Produce sound.

*The antennas are not visible from the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country or region. To access this guide, select the HP Support Assistant app from the Start screen, select My computer, and then select User guides.

14 Chapter 2 Getting to know your computer

Keys

Component Description

(1) esc key Displays system information when pressed in combination

(2) fn key Executes frequently used system functions when pressed

(3)

(4) Action keys Execute frequently used system functions.

(5)

Windows logo key Returns you to the Start screen from an open app or the

Windows application key Displays options for a selected object.

with the fn key.

in combination with the b key or the esc key.

Windows desktop.

NOTE: Pressing the Windows logo key again will return

you to the previous screen.

Top 15

Bottom

Components Description

(1) Speakers (2) Produce sound.

(2) Vent Enables airflow to cool internal components.

NOTE: The computer fan starts up automatically to

cool internal components and prevent overheating. It is normal for the internal fan to cycle on and off during routine operation.

16 Chapter 2 Getting to know your computer

Labels

The labels affixed to the computer provide information you may need when you troubleshoot system problems or travel internationally with the computer. The labels are located on the bottom of your computer or in other easily accessible locations.

●

Service label—Provides important information, including the following:

NOTE: Your label may look slightly different from the illustration in this section.

Component

(1) Serial number

(2) Product name

(3) Model description (select models only)

(4) Warranty period

(5) Product number

Have this information available when you contact support.

Regulatory label—Provides regulatory information about the computer.

●

Labels 17

Wireless certification label or labels—Provide information about optional wireless devices and

●

the approval markings of some of the countries or regions in which the devices have been approved for use. If your computer model includes one or more wireless devices, one or more certification labels are included with your computer. You may need this information when traveling internationally.

Additional country wireless labels are included below for the Ukraine, Indonesia, and Singapore.

Ukraine

Indonesia

Singapore

18 Chapter 2 Getting to know your computer

3 Connecting to a network

Your computer can travel with you wherever you go. But even at home, you can explore the globe and access information from millions of websites using your computer and a wired or wireless network connection. This chapter will help you get connected to that world.

Connecting to a wireless network

Wireless technology transfers data across radio waves instead of wires. Your computer may be equipped with one or more of the following wireless devices:

Wireless local area network (WLAN) device—Connects the computer to wireless local area

●

networks (commonly referred to as Wi-Fi networks, wireless LANs, or WLANs) in corporate offices, your home, and public places such as airports, restaurants, coffee shops, hotels, and universities. In a WLAN, the mobile wireless device in your computer communicates with a wireless router or a wireless access point.

● Bluetooth device—Creates a personal area network (PAN) to connect to other Bluetooth-

enabled devices such as computers, phones, printers, headsets, speakers, and cameras. In a PAN, each device communicates directly with other devices, and devices must be relatively close together—typically within 10 meters (approximately 33 feet) of each other.

For more information about wireless technology, see the information and website links provided in Help and Support. From the Start screen, type h, and then select Help and Support.

Using the wireless controls

You can control the wireless devices in your computer using these features:

Wireless button, wireless switch, or wireless key (referred to in this chapter as the wireless

●

button)

Operating system controls

●

Connecting to a wireless network 19

Using the wireless button

The computer has a wireless button, one or more wireless devices, and one or two wireless lights, depending on the model. All of the wireless devices on your computer are enabled at the factory, so the wireless light is on (white) when you turn on the computer.

The wireless light indicates the overall power state of your wireless devices, not the status of individual devices. If the wireless light is white, at least one wireless device is on. If the wireless light is off, all wireless devices are off.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

Because the wireless devices are enabled at the factory, you can use the wireless button to turn on or turn off the wireless devices simultaneously.

20 Chapter 3 Connecting to a network

Using operating system controls

The Network and Sharing Center allows you to set up a connection or network, connect to a network, manage wireless networks, and diagnose and repair network problems.

To use operating system controls:

1. From the Start screen, type n, and then select Settings.

2. Type network and sharing in the search box, and then select Network and Sharing

Center.

For more information, from the Start screen, type h, and then select Help and Support.

Using a WLAN

With a WLAN device, you can access a wireless local area network (WLAN), which is composed of other computers and accessories that are linked by a wireless router or a wireless access point.

NOTE: The terms wireless router and wireless access point are often used interchangeably.

A large-scale WLAN, such as a corporate or public WLAN, typically uses wireless access points

●

that can accommodate a large number of computers and accessories and can separate critical network functions.

A home or small office WLAN typically uses a wireless router, which allows several wireless and

●

wired computers to share an Internet connection, a printer, and files without requiring additional pieces of hardware or software.

To use the WLAN device in your computer, you must connect to a WLAN infrastructure (provided through a service provider or a public or corporate network).

Using an Internet service provider

When you are setting up Internet access in your home, you must establish an account with an Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP. The ISP will help set up the modem, install a network cable to connect your wireless router to the modem, and test the Internet service.

NOTE: Your ISP will give you a user ID and a password to use for Internet access. Record this

information and store it in a safe place.

Connecting to a wireless network 21

Setting up a WLAN

To set up a WLAN and connect to the Internet, you need the following equipment:

A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from

●

an Internet service provider

A wireless router (2) (purchased separately)

●

A wireless computer (3)

●

NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type

of modem you have.

The illustration below shows an example of a wireless network installation that is connected to the Internet.

As your network grows, additional wireless and wired computers can be connected to the network to access the Internet.

For help in setting up your WLAN, see the information provided by your router manufacturer or your ISP.

Configuring a wireless router

For help in setting up a WLAN, see the information provided by your router manufacturer or your ISP.

NOTE: It is recommended that you initially connect your new wireless computer to the router by

using the network cable provided with the router. When the computer successfully connects to the Internet, disconnect the cable, and access the Internet through your wireless network.

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always enable security features to protect your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and airports may not provide any security. If you are concerned about the security of your computer when connected to a hotspot, limit your network activities to email that is not confidential and basic Internet surfing.

Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected signals. Take the following precautions to protect your WLAN:

Use a firewall.

●

A firewall checks both data and requests for data that are sent to your network, and discards any suspicious items. Firewalls are available in both software and hardware. Some networks use a combination of both types.

● Use wireless encryption.

22 Chapter 3 Connecting to a network

Wireless encryption uses security settings to encrypt and decrypt data that is transmitted over the network. For more information, from the Start screen, type h, and then select Help and

Support.

Connecting to a WLAN

To connect to the WLAN, follow these steps:

1. Be sure that the WLAN device is on. If the device is on, the wireless light is white. If the wireless

light is off, press the wireless button.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

2. From the Windows desktop, tap or click the network status icon in the notification area, at the far

right of the taskbar.

3. Select your WLAN from the list.

4. Click Connect.

If the WLAN is a security-enabled WLAN, you are prompted to enter a security code. Type the code, and then click OK to complete the connection.

NOTE: If no WLANs are listed, you may be out of range of a wireless router or access point.

NOTE: If you do not see the WLAN you want to connect to, from the Windows desktop, right-

click the network status icon, and then select Open Network and Sharing Center. Click Set up a new connection or network. A list of options is displayed, allowing you to manually search

for and connect to a network or to create a new network connection.

After the connection is made, place the mouse pointer over the network status icon in the notification area, at the far right of the taskbar, to verify the name and status of the connection.

NOTE: The functional range (how far your wireless signals travel) depends on WLAN

implementation, router manufacturer, and interference from other electronic devices or structural barriers such as walls and floors.

Using Bluetooth wireless devices

A Bluetooth device provides short-range wireless communications that replace the physical cable connections that traditionally link electronic devices such as the following:

Computers (desktop, notebook, PDA)

●

● Phones (cellular, cordless, smart phone)

Imaging devices (printer, camera)

●

Audio devices (headset, speakers)

●

Mouse

●

Bluetooth devices provide peer-to-peer capability that allows you to set up a personal area network (PAN) of Bluetooth devices. For information about configuring and using Bluetooth devices, see the Bluetooth software Help.

Connecting to a wireless network 23

Connecting to a wired network

There are 2 kinds of wired connections: local area network (LAN) and modem connection. A LAN connection uses a network cable and is much faster than a modem connection, which uses a telephone cable. Both cables are sold separately.

WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not plug a

modem cable or telephone cable into an RJ-45 (network) jack.

Connecting to a local area network (LAN)

Use a LAN connection if you want to connect the computer directly to a router in your home (instead of working wirelessly), or if you want to connect to an existing network at your office.

Connecting to a LAN requires an 8-pin, RJ-45 (network) cable.

To connect the network cable, follow these steps:

1. Plug the network cable into the network jack (1) on the computer.

2. Plug the other end of the network cable into a network wall jack (2) or router.

NOTE: If the network cable contains noise suppression circuitry (3), which prevents

interference from TV and radio reception, orient the circuitry end of the cable toward the computer.

24 Chapter 3 Connecting to a network

4 Enjoying entertainment features

Use your HP computer as an entertainment hub to socialize via the webcam, enjoy and manage your music, and download and watch movies. Or, to make your computer an even more powerful entertainment center, connect external devices like a monitor, projector, or TV, or speakers and headphones.

Using the webcam

Your computer has an integrated webcam, a powerful social networking tool that allows you to communicate up close with friends and colleagues, next door or on the other side of the world. With the webcam, you can stream video with your instant messaging software, capture and share video, and take still photos.

To start the webcam, from the Start screen, type c, and then select CyberLink YouCam from

▲

the list of applications.

For details about using the webcam, refer to the help for the app.

Sharing media and data between devices

Using sMedio 360 software, you can wirelessly stream media and transfer data (sync 2-way or migrate 1-way) between devices on the same home group network. You can also stream and transfer media to and from your computer and your Android 4.0 smart phone.

sMedio 360 works in both Windows 8 and Windows 7, as well as other devices on the same home group network. The software includes the following three main apps:

sMedio 360 Suite enables you to wirelessly stream and share media between enabled

●

computers and mobile devices. The sMedio 360 Suite app is located from the Start screen.

sMedio 360 TrueSync enables you to migrate (1-way communication) or synchronize (2-way

●

communication) data between two computers on a wired or wireless home group network. This app is located on the Windows desktop and is also compatible with computers running Windows 7 operating systems.

sMedio 360 TrueLink+ enables you to transfer (copy) or stream (play) photos, videos, and

●

music from either your Android phone to your computer or vice versa.

Finding more information

For more information on using this software, click the Tutorials app in the sMedio 360 main screen located from the Start screen or on the Windows desktop. To explore all of the available features, click Learn More in the Tutorials app.

26 Chapter 4 Enjoying entertainment features

Using sMedio 360 Suite

To stream and share media from one device to another, your computers and mobile devices must be on the same home group network and media sharing must be enabled on all devices.

NOTE: For information on setting up a home group network, click the Tutorial app on the sMedio

screen.

To enable media sharing:

1. From the Start screen, point to the far-upper right or lower corner of the screen to show the

charms.

2. Select Settings, and then select the network status icon.

3. Right-click the network you are connected to, and then select Turn sharing on or off.

Accessing sMedio 360 Suite

From the Start screen, select the sMedio 360 Suite app.

▲

– or –

From the Start screen, type s, and then select sMedio 360 Suite for HP from the list of apps.

Using sMedio 360 TrueSync

To migrate and synchronize data between two computers, the computers must be on the same home group network.

For information on setting up a home group network, select the Tutorial app on the sMedio screen.

Accessing sMedio 360 TrueSync

1. From the Windows desktop, click the sMedio 360 TrueSync icon on the taskbar.

2. Follow the on-screen instructions to set up your folders that will be used for migrating and

synchronizing information.

TIP: You will also be guided through copying the software to additional computers and setting

them up for the synchronization relationship.

Sharing media and data between devices 27

Using sMedio 360 TrueLink+

Download the sMedio 360 TrueLink+ free app to your phone to wirelessly share, photos, videos, and music between your Android 4.0 smart phone and your computer. Your phone must be on the same home group network as your computer. For help in connecting the phone to your home group network, see the phone manufacturer's instructions.

NOTE: In order to share media from your phone to your computer, the media must be in a format

that is compatible with the other network devices.

Determining your Android phone OS version

To determine whether your Android phone is running the required 4.0 operating system:

Go to the Settings screen on your phone, and then tap About Phone.

▲

Downloading the sMedio 360 TrueLink+ app on your phone

You must install the sMedio 360 TrueLink+ app on your phone before you can begin wirelessly sharing media. This free app is located in the Google Play app store.

1. From the Start screen, select the sMedio 360 Suite app.

2. Click the Tutorials icon for instructions on downloading and using this app.

Sharing media from your phone to your computer

1. Be sure that your phone and computer are connected to the same home group network.

2. On your computer, select sMedio 360 Suite app from the Start screen, and then select Media

Receiver.

3. On your phone, open the sMedio TrueLink+ app, tap My Devices, and then tap My Mobile.

4. Swipe left or right to find your music, videos, and photos.

5. Open the media that you want to share.

6. Tap the arrow on the top of the phone screen, and then select a device to receive the media file.

7. In a few seconds, the media file will appear on the device you selected.

28 Chapter 4 Enjoying entertainment features

Using audio

On your computer, you can play music CDs, download and listen to music, stream audio content from the web (including radio), record audio, or mix audio and video to create multimedia. To enhance your listening enjoyment, attach external audio devices such as speakers or headphones.

Connecting speakers

You can attach wired speakers to your computer by connecting them to a USB port or to the audioout (headphone) jack on your computer or on a docking station.

To connect wireless speakers to your computer, follow the device manufacturer's instructions. To connect high-definition speakers to the computer, see Before connecting speakers, lower the volume setting.

Connecting headphones

You can connect wired headphones to the headphone jack on your computer.

To connect wireless headphones to your computer, follow the device manufacturer's instructions.

WARNING! To reduce the risk of personal injury, lower the volume setting before putting on

headphones, earbuds, or a headset. For additional safety information, see the Regulatory, Safety and Environmental Notices. To access this guide, select the HP Support Assistant app from the Start

screen, select My computer, and then select User guides.

Configuring HDMI audio settings on page 31.

Connecting a microphone

To record audio, connect a microphone to the microphone jack on the computer. For best results when recording, speak directly into the microphone and record sound in a setting free of background noise.

Using Beats Audio

Beats Audio is an enhanced audio feature that provides a deep, controlled bass while maintaining a clear sound. You can experience Beats Audio through the computer's internal speakers, through external speakers connected to a USB port, or through Beats Audio headphones connected to the headphone jack.

Accessing Beats Audio Control Panel

Use Beats Audio Control Panel to view and manually control audio and bass settings.

▲ From the Start screen, type c, select Control Panel, select Hardware and Sound, and then

select Beats Audio Control Panel.

Enabling and disabling Beats Audio

To enable or disable Beats Audio, press the fn key in combination with the b key.

▲

Using audio 29

Checking the sound

To check the audio functions on your computer, follow these steps:

1. From the Start screen, type c, and then select Control Panel from the list of applications.

2. Select Hardware and Sound, and then select Sound.

3. When the Sound window opens, select the Sounds tab. Under Program Events, select any

sound event, such as a beep or alarm, and then select Test.

You should hear sound through the speakers or through connected headphones.

To check the recording functions on your computer, follow these steps:

1. From the Start screen, type s, and then select Sound Recorder.

2. Select Start Recording and speak into the microphone. Save the file to your desktop.

3. Open a multimedia program and play the recording.

To confirm or change the audio settings on your computer:

1. From the Start screen, type c, and then select Control Panel from the list of applications.

2. Select Hardware and Sound, and then select Sound.

Using video

Your computer is a powerful video device that enables you to watch streaming video from your favorite websites and download video and movies to watch on your computer without needing to connect to a network.

To enhance your viewing enjoyment, use one of the video ports on the computer to connect an external monitor, projector, or TV. Your computer has a high-definition multimedia interface (HDMI) port and a Thunderbolt DisplayPort.

IMPORTANT: Be sure that the external device is connected to the correct port on the computer,

using the correct cable. Check the device manufacturer's instructions.

30 Chapter 4 Enjoying entertainment features

Connecting an HDMI device

NOTE: To connect an HDMI device to your computer, you need an HDMI cable, sold separately.

To see the computer screen image on a high-definition TV or monitor, connect the high-definition device according to the following instructions.

1. Connect one end of the HDMI cable to the HDMI port on the computer.

2. Connect the other end of the cable to the high-definition TV or monitor.

3. Press f4 to alternate the computer screen image between 4 display states:

PC screen only: View the screen image on the computer only.

●

Duplicate: View the screen image simultaneously on both the computer and external

●

device.

Extend: View the screen image extended across both the computer and external device.

●

Second screen only: View the screen image on the external device only.

●

Each time you press f4, the display state changes.

NOTE: Adjust the screen resolution of the external device, especially if you choose the

“Extend” option. From the Start screen, type c, and then select Control Panel from the list of applications. Select Appearance and Personalization. Under Display, select Adjust screen

resolution.

Configuring HDMI audio settings

HDMI is the only video interface that supports high-definition video and audio. After you connect an HDMI TV to the computer, you can then turn on HDMI audio by following these steps:

1. From the Windows desktop, right-click the Speakers icon in the notification area, at the far right

of the taskbar, and then select Playback devices.

2. On the Playback tab, select the name of the digital output device.

3. Select Set Default, and then select OK.

Using video 31

To return the audio stream to the computer speakers:

1. From the Windows desktop, right-click the Speakers icon in the notification area, at the far right

of the taskbar, and then click Playback devices.

2. On the Playback tab, select Speakers and Headphones.

3. Select Set Default, and then select OK.

Connecting a Thunderbolt DisplayPort device

The Thunderbolt DisplayPort connects an optional high-resolution display device or a highperformance data device. This port delivers higher performance than the VGA external monitor port and improves digital connectivity.

NOTE: Thunderbolt is new technology. Install all the latest drivers for your Thunderbolt device

before connecting the device to the Thunderbolt Displayport. Thunderbolt cable and Thunderbolt device (sold separately) must be compatible with Windows. To determine whether your device is Thunderbolt Certified for Windows, see

1. Connect one end of the Thunderbolt DisplayPort cable to the Thunderbolt DisplayPort on the

computer.

https://thunderbolttechnology.net/products.

2. Connect the other end of the cable to the digital display device.

3. Press f4 to alternate the computer screen image between 4 display states:

PC screen only: View the screen image on the computer only.

●

Duplicate: View the screen image simultaneously on both the computer and external

●

device.

Extend: View the screen image extended across both the computer and external device.

●

Second screen only: View the screen image on the external device only.

●

Each time you press f4, the display state changes.

32 Chapter 4 Enjoying entertainment features

NOTE: Adjust the screen resolution of the external device, especially if you choose the

“Extend” option. From the Start screen, type c, and then select Control Panel from the list of applications. Select Appearance and Personalization. Under Display, select Adjust screen

resolution.

Using Intel Wireless Display and Wireless Music (select models only)

Intel® Wireless Display and Wireless Music allow you to transmit your computer content wirelessly to your receive/display device, such as HDTV, monitor, projector, game console, Blu-ray player, or DVR, by using an optional wireless adapter (purchased separately). For details about using the wireless adapter, see the manufacturer's instructions.

To open Intel Wireless Display, from the Start screen, type w, and then select Intel WiDi.

▲

NOTE: Before using the wireless display feature, be sure that your wireless device is turned on.

Managing your audio and video files

CyberLink PowerDVD helps you manage and edit your photo and video collections.

To open CyberLink Power DVD, from the Start screen, type c, and then select CyberLink

▲

PowerDVD.

For more information about using CyberLink PowerDVD, see the PowerDVD software Help.

Managing your audio and video files 33

5 Navigating using touch gestures,

pointing devices and the keyboard

Your computer allows navigation using touch gestures (select models only) in addition to the keyboard and mouse. Touch gestures can be used on your computer TouchPad or on the touch screen.

NOTE: An external USB mouse (purchased separately) can be connected to one of the USB ports

on the computer.

Review the Windows 8 Basics guide included with your computer. The guide provides information on common tasks using the TouchPad, touch screen, or the keyboard.

Your computer also has special action keys and hot key functions on the keyboard to perform routine tasks.

34 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

Using the TouchPad

The TouchPad allows you to navigate the computer with simple finger movements.

You can customize the touch gestures by changing settings, button configurations, click speed, and pointer options. From the Start screen, type c to display the Apps list. Select Control Panel, and then select Hardware and Sound. Under Devices and Printers, select Mouse.

Turning the TouchPad off or on

To turn the TouchPad off or on, quickly double-tap the TouchPad on/off button.

The TouchPad light is off when the TouchPad is on.

The TouchPad supports a variety of gestures that let your fingers scroll, swipe, pinch, and rotate to manipulate items on the screen.

Using the TouchPad 35

Using TouchPad gestures

A TouchPad allows you to control the pointer on the screen using your fingers.

TIP: Use the left and right buttons on the TouchPad as you would use the corresponding buttons on

a external mouse.

NOTE: TouchPad gestures are not supported in all apps.

To view a demonstration of each gesture:

1. From the Start screen, type c to display the Apps list. Select Control Panel, and then select

Hardware and Sound.

2. Select Synaptics TouchPad.

3. Select a gesture to activate the demonstration.

To turn a gesture off or on:

1. From the Synaptics TouchPad screen, select or clear the check box next to the gesture that

you want to turn on or off.

2. Select Apply, and then select OK.

Tapping

To make an on-screen selection, use the tap function on the TouchPad.

Point to an item on the screen, and then tap one finger on the TouchPad zone to make a

●

selection. Double-tap an item to open it.

NOTE: Tap and hold your finger on the TouchPad to open a help screen that provides information

about the selected item.

36 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

Scrolling

Scrolling is useful for moving up, down, or sideways on a page or image.

● Place two fingers slightly apart on the TouchPad zone and then drag them up, down, left, or

right.

Pinching/stretching

Pinching and stretching allow you to zoom in or out on images or text.

Zoom out by placing two fingers apart on the TouchPad zone and then moving your fingers

●

together.

● Zoom in by placing two fingers together on the TouchPad zone and then moving your fingers

apart.

Using TouchPad gestures 37

Rotating (select models only)

Rotating allows you to turn items such as photos.

● Point to an object, and then anchor the forefinger of your left hand in the TouchPad zone. Using

your right hand, slide your forefinger in a sweeping motion from 12 o’clock to 3 o’clock. To reverse the rotation, move your forefinger from 3 o’clock to 12 o’clock.

NOTE: Rotate is intended for specific apps where you can manipulate an object or image. Rotate

may not be functional for all apps.

2-finger click (select models only)

2-finger click allows you to make menu selections for an object on the screen.

● Place two fingers on the TouchPad zone and press down to open the options menu for the

selected object.

38 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

Flicking (select models only)

Flicking allows you to navigate through screens or quickly scroll through documents.

● Place three fingers on the TouchPad zone and flick your fingers in a light, quick motion up,

down, left or right.

Edge swipes

Edge swipes allow you to perform tasks such as changing settings and finding or using apps.

Right-edge swipe

The right-edge swipe reveals the charms, which let you search, share, start apps, access devices, or change settings.

Swipe your finger gently from the right edge to display the charms.

●

Using TouchPad gestures 39

Top-edge swipe

The top-edge swipe allows you to access All Apps available from the Start screen.

IMPORTANT: When an app is active, the top-edge gesture varies depending on the app.

Swipe your finger gently from the top edge to display available apps.

●

Left-edge swipe

The left-edge swipe accesses your recently opened apps so that you can switch between them quickly.

Swipe your finger gently from the left edge of the TouchPad to switch between them quickly.

●

40 Chapter 5 Navigating using touch gestures, pointing devices and the keyboard

Using touch screen gestures

A touch screen computer allows you to control items on the screen directly with your fingers.

TIP: On touch screen computers, you can perform the gestures on the screen or on the TouchPad.

You can also perform on-screen actions with the keyboard and mouse.

One-finger slide

The one-finger slide is most often used to pan or scroll through lists and pages, but you can use it for other interactions, too, such as moving an object.

To scroll across the screen, lightly slide one finger across the screen in the direction you want to

●

move.

NOTE: When many apps are displayed from the Start screen, you can slide your finger to

move the screen left or right.

To drag, press and hold an object, and then drag the object to move it.

●

Using touch screen gestures 41
