QuickSpecs

Overview

HP EliteBook 8540p Notebook PC

Volume mute button with LED indicator

Volume down button with LED indicator

Volume up button with LED indicator

Calculator button

Kensington Lock slot

RJ-11/modem port

RJ-45/Ethernet port

(2) USB 3.0 ports

Full numeric keypad

10.

Upgrade Bay (optical drive, 2nd hard drive)

11.

Integrated Smart Card Reader

12.

Optional HP Fingerprint Sensor

13.

Pointstick

14.

Pointstick buttons (3)

15.

Touchpad with scroll zone

16.

Touchpad buttons (3)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

17.

Hard drive activity / HP 3D DriveGuard LED indicator

18.

Battery charging LED indicator

19.

Power/standby LED indicator

20.

Wireless on/off LED indicator

21.

Power button with LED indicator

22.

HP QuickLook 3 button with LED indicator

23.

HP QuickWeb button with LED indicator

24.

Wireless on/off button with LED indicator

25.

Touchpad on/off button

26.

Ambient Light Sensor

27.

WWAN antennas

28.

Dual-microphone array

29.

Three WLAN antennas

30.

Optional 2 MP Webcam

31.

HP NightLight with on/off button

Page 1

QuickSpecs

Overview

HP EliteBook 8540p Notebook PC

(2) USB 2.0 ports

DisplayPort

eSATA port

USB 2.0 port

1394a port

Stereo microphone in

Stereo headphone/line out

ExpressCard/54 slot

Wireless on/off LED indicator

10.

Power/standby LED indicator

11.

Battery charging LED indicator

12.

Hard drive activity / HP 3D DriveGuard LED

13.

Integrated stereo speakers

14.

Media Card Reader

15.

Display release latch

16.

Business Card slot

17.

VGA connector (external monitor/projector)

18.

Power connector

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 2

QuickSpecs

Overview

HP EliteBook 8540p Notebook PC

Bottom View

SIM slot for WWAN (select models) – inside battery bay

Battery release latch

Battery bay

Docking connector

Secondary battery connector

Memory module compartment

Hard drive bay

WWAN module compartment

Bluetooth module compartment

At A Glance

Genuine Windows 7 versions, Genuine Windows Vista versions, Genuine Windows XP Professional available through downgrade rights from Windows 7 Professional, or FreeDOS Industrial, business rugged construction features a full magnesium alloy chassis, magnesium/aluminum display enclosure, metal alloy hinges, brushed aluminum with platinum finish; designed to meet the military standard Mil-Std810G for vibration, dust, humidity, altitude, and high and low temperature operation* NVIDIA NVS 5100M graphics with 1 GB dedicated memory Intel® Core™ i7 or Core i5 processor with Intel Turbo Boost Technology Widescreen 15.6-inch diagonal 16:9 LED-backlit HD, HD+, or FHD display with Ambient Light Sensor and optional HP Privacy Filter DisplayPort for external monitors, eSATA port for external storage, two USB 3.0 ports for faster transfer speeds to USB 3.0 peripherals and compatibility with USB 2.0 peripherals, three USB 2.0 ports Upgrade Bay for easy optical drive upgrade or optional second hard drive for RAID 1 Mirroring or RAID 0 Striping Choice of standard 8-cell primary battery or HP Long Life battery, plus optional external batteries - HP Ultra-Capacity Battery, HP Extended Life Battery Flexible wireless connectivity options:

Integrated HP un2420 EV-DO/HSPA Mobile Broadband Module provides worldwide Gobi mobile Internet technology with GPS Integrated Intel Centrino® Ultimate-N / Advanced-N 6000 Series 802.11 a/b/g/n wireless LAN module

Bluetooth® v2.1 Choice of 7200 rpm user-removable hard drive up to 500 GB with HP 3D DriveGuard protection, or 160/256 GB Solid State Drive HP SkyRoom 90-day trial version for professional quality visual collaboration built on HP Video and Image processing engines for hi-fi audio, hi-def video, and hi-performance 3D application sharing HP Power Assistant to conserve power, increase battery run-time, monitor power needs, report workforce power consumption

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 3

QuickSpecs

HP EliteBook 8540p Notebook PC

Overview

Enhanced security features including integrated Smart Card Reader, HP ProtectTools, Computrace LoJack Pro ready, HP SpareKey, HP Disk Sanitizer, TPM 1.2 ;** optional HP Fingerprint Sensor, and optional HP Privacy Filter Touch-sensitive controls for HP QuickLook 3 (instant access to email, calendar, contacts and tasks), HP QuickWeb, wireless on/off, touchpad on/off, mute, volume down, volume up, and calculator Optional 2 MP Webcam with Business Card Reader Software HP Night Light Dual pointing devices (touchpad with scroll zone and pointstick) ExpressCard/54 slot, Media Card Reader

* Testing was not intended to demonstrate fitness for DOD contracts requirements or for military use. Test results are not a guarantee of future performance under these test conditions. ** TPM module disabled where not permitted by law (for example, Russia and China).

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 4

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Processors

Operating System

Intel Quad-Core Processor

Intel Core i7-820QM Processor (1.73 GHz, 8 MB L3 cache) Up to 3.06 GHz with Intel Turbo Boost Technology

Intel Core i7-720QM Processor (1.60 GHz, 6 MB L3 cache) Up to 2.8 GHz with Intel Turbo Boost Technology

Intel Dual-Core Processors

Intel Core i7-620M Processor (2.66 GHz, 4 MB L3 cache) Up to 3.33 GHz with Intel Turbo Boost Technology

Intel Core i5-540M Processor (2.53 GHz, 3 MB L3 cache) Up to 3.06 GHz with Intel Turbo Boost Technology

Intel Core i5-520M Processor (2.4 GHz, 3 MB L3 cache) Up to 2.93 GHz with Intel Turbo Boost Technology

* Intel's numbering is not a measurement of higher performance.

NOTE:

Processor speed denotes maximum performance mode; processors will run at lower

speeds in battery optimization mode.

Preinstalled

Supported

Certified

* System may require upgraded and/or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See:

http://www.microsoft.com/windows/windows-7/

Genuine Windows 7 Professional Edition 32 Genuine Windows 7 Professional Edition 64 Genuine Windows XP Professional available through downgrade rights from Windows 7 Professional Genuine Windows 7 Home Premium Edition 32 Genuine Windows 7 Home Premium Edition 64 Genuine Windows Vista Business 32 Genuine Windows Vista Home Basic 32 FreeDOS

Genuine Windows Vista Enterprise 32 Genuine Windows Vista Enterprise 64 Genuine Windows XP Professional 64

SuSE Linux Enterprise Desktop 11

for details.

* *

*†

* *

** **

Chipset

** Certain Windows Vista product features require advanced or additional hardware. See:

http://www.microsoft.com/windowsvista/getready/hardwarereqs.mspx http://www.microsoft.com/windowsvista/getready/capable.mspx

Upgrade Advisor can help you determine which features of Windows Vista will run on your computer. To download the tool, visit:

† Windows XP Professional is preinstalled on this system and includes end user rights and media for Windows 7 Professional. You may only use one version at a time. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data.

Mobile Intel QM57 Express Chipset

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

http://www.windowsvista.com/upgradeadvisor

and

for details. Windows Vista

Page 5

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Intel Core i5 with vPro/Core i7 with vPro technology capable

Graphics

Display

Intel Core i5 with vPro and Core i7 with vPro technology is a selectable feature that is available on units configured with an Intel Centrino® Ultimate-N/Advanced-N 6000 series WLAN module and a preinstalled Windows operating system. It provides advances in remote manageability, security, energy efficient performance, and wireless connectivity. Intel Active Management Technology (AMT) offers built-in manageability and proactive security for networked notebook PCs, even when they are powered off* or when the operating system is inoperable. It can help identify threats before they reach the network, isolate infected systems, and update PCs regardless of their power state.

*Requires a Windows operating system, network hardware and software, connection with a power source, and a direct (non-VPN) corporate network connection which is either cable or wireless LAN.

NOTE:

Some functionality of Intel Core i5 with vPro/Core i7 with vPro technology, such as Intel Active Management technology and Intel Virtualization technology, requires additional 3rd party software in order to run. Availability of future "virtual appliances" applications for Intel Core i5 with vPro/Core i7 with vPro technology is dependent on 3rd party software providers. Compatibility with future "virtual appliances" is yet to be determined.

NVIDIA NVS 5100M graphics with 1 GB dedicated DDR3 video memory Microsoft DirectX 10.1 (Shader Model 4.1)

Internal

External

15.6-inch diagonal 16:9 LED-backlit HD anti-glare (1366 x 768 resolution)

15.6-inch diagonal 16:9 LED-backlit HD+ anti-glare (1600 x 900 resolution)

15.6-inch diagonal 16:9 LED-backlit FHD anti-glare (1920 x 1080 resolution) Ambient Light Sensor Optional HP Privacy Filter

Up to 32-bit per pixel color depth

DisplayPort

at 60 Hz, and full HD (1920 x 1080) monitors, 24-bit color depth at 120 Hz

VGA

port supports resolutions up to 2048 x 1536 at 75 Hz, and lower

resolutions at up to 100 Hz

DVI-D

Docking Station (sold separately) supports resolutions up to 1600 x 1200 at both full and reduced blanking, and 1920 x 1200 at reduced blanking

NOTE:

resolution and color depth settings.

supports resolutions up to 2560 x 1600, 30-bit color depth

(single link) video signal available through DVI port in optional HP

Resolutions are dependent upon monitor capability, and

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 6

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Memory

Communications

Standard

Maximum

Dual-channel

* With some processors, memory bus runs at a maximum of 1066 MHz.

NOTE:

Due to the non-industry standard nature of some third-party memory modules, we recommend HP branded memory to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Full availability of 4 GB or more of memory requires a Windows 64-bit operating system or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

Integrated Intel Gigabit Network Connection (10/100/1000 NIC)

56K V.92 modem

* The term "10/100/1000" or "Gigabit" Ethernet indicates compliance with IEEE standard 802.3ab for Gigabit Ethernet, and does not connote actual operating speed of 1 Gb/s. For high-speed transmission, connection to a Gigabit Ethernet server and network infrastructure is required.

** Designed for downloads from 56K modem compliant sources. Maximum achievable download transmission rates currently do not reach 56 KB/s, and will vary with line conditions. Modem availability is subject to country regulatory approval.

DDR3 PC3-10600 SDRAM (1333 MHz) Two or four SODIMM slots supporting dual-channel memory 2048 MB and 4096 MB SODIMMs

NOTE:

Four memory slots only on models with quad-core processor.

Upgradeable to 16384 MB with (4) 4096 MB SODIMMs

Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory channels.

Wireless Devices

Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest industry standards. Wireless LAN is factory configurable or available as an option to be added later. Mobile Broadband (WWAN) requires a Windows operating system and is available in select countries as a standard, factory configurable feature or as an option to be added later. Integrated Bluetooth is also available (factory configurable only) and can be combined with any of the supported wireless LAN and wireless WAN options.

HP un2420 EVDO/HSPA Mobile Broadband Module

All 802.11 integrated wireless LAN options

Intel Centrino UltimateN 6300 (3x3)

Intel Centrino Advanced-N 6200 (2x2)

Integrated mobile broadband module with Gobi global mobile Internet technology that provides connectivity to both CDMA (EVDO) and UMTS (HSPA) networks. It also provides GPS functionality for various mapping applications and security applications such as Computrace LoJack Pro Premium for HP ProtectTools.

NOTE:

Separately purchased mobile network operator service is required.

Two 850/900/1575/1800/1900/2100 MHz antennas integrated in the top of the display panel support current and future WWAN technologies.

Wi-Fi Certified Cisco Compatible Extensions support Wired Equivalent Privacy (WEP) support up to 128-bit keys Wi-Fi Protected Access (WPA) and WPA2 support

802.1x authentication support, including EAP-TLS, EAP-TTLS, PEAPGTC, PEAP-MSCHAPv2, and LEAP Advanced Encryption Standard (AES) support Three antennas integrated in the display enclosure

Integrated support for 802.11a, b, g, and n 3 transmit, 3 receive antennas Up to 450 mbps data rate

Integrated support for 802.11a, b, g, and n 2 transmit, 2 receive antennas Up to 300 mbps data rate

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 7

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Keyboard

Touch-sensitive controls

HP Integrated Module with Bluetooth Wireless Technology

* In countries where 802.11n is not allowed, this capability is not enabled (802.11a/b/g only).

The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of damage to sensitive components underneath. The 101/102-key compatible keyboard features an industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and International key layouts are available. Includes a full numeric keypad, hotkeys for instant access to power conservation, brightness, and other features. It has 19.05 x

19.05 mm key pitch (center-to-center spacing) and 2.5 mm stroke.

HP DuraKeys is a clear coating applied over the notebook keyboard that helps protect the finish and the printed characters on the keys. HP DuraFinish helps protect the finish on the keyboard deck, graphics, and icons from normal wear and tear.

Touch-sensitive controls provide easy access to the following features: HP QuickLook 3, HP QuickWeb, wireless on/off, touchpad on/off, volume mute, volume down, volume up, and calculator button.

Bluetooth Specification v2.1 compliant Works with a wide range of Bluetooth devices

Dual Pointing devices

Expansion card slots

Internal Storage

Touchpad with scroll zone, three pick buttons Pointstick with three additional pointstick buttons

ExpressCard/54 slot

Integrated Smart Card Reader

Secure Digital slot

* Memory Stick Duo Adapters are required and sold separately. Inserting a Memory Stick Duo Card directly into your notebook could damage the memory card and/or notebook.

Hard Drives

NOTE:

These hard drives are customer removable and will withstand multiple insertion/removal

cycles. Up to 10 GB is reserved for the system recovery software.

HP 3D DriveGuard

(Windows only)

Solid State Drives

Supports ExpressCard/54

Compatible with ISO 7816 compliant Smart Cards PC/SC interface support

Supports SD (Secure Digital), MMC (MultiMedia Card), Memory Stick, Memory Stick Pro, Memory Stick Duo*, xD-Picture card

250/320/500 GB 7200 rpm SMART SATA II

The hard drive is mounted directly to the notebook frame, reducing the transmission of shock to the hard drive. Uses three-axis digital motion detection with intelligent sensitivity to help protect the hard drive during normal use from shock and vibration. The digital accelerometer temporarily halts all data transfer and parks the hard drive when abrupt motion is detected.

160 GB Solid State Drive 256 GB Solid State Drive

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 8

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Upgrade Bay

Interfaces

Fixed 12.7 mm SATA optical drive

Second hard drive

ExpressCard/54 slot

External monitor

Media Card Reader

1394a

Stereo microphone in

Stereo headphone/line out

Power connector

RJ-11/modem

RJ-45/Ethernet

USB 2.0

USB 3.0

eSATA

Docking connector

Secondary battery connector

Blu-ray R/RE DVD+/-RW SuperMulti DL Drive Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive DVD+/-RW SuperMulti DL LightScribe Drive DVD-ROM Drive

500 GB 7200 rpm SMART SATA II Hard Drive

One

Two – (1) DisplayPort, (1) VGA

One

Three

Two (for USB 2.0 and USB 3.0 peripherals)

One

Audio/Visual

High definition audio Integrated stereo speakers Integrated dual-microphone array Touch-sensitive controls for volume up, volume down, and mute Stereo headphone/line out Stereo microphone/line in

Optional 2 MP webcam with Business Card Reader software

Supports videoconferencing and still image capture Large image sensor for excellent color matching and good low light sensitivity Up to 30 frames/sec AutoMacro focus lens Video capture at VGA, 1.3 Mpixel, and 2 Mpixel resolutions 16-bit true color (camera sensors output YCrCb format among others)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 9

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Software

Preinstalled software with Windows operating system

Additional software available from the web

* 60 day trial period for McAfee Total Protection for Small Business software. Internet access required to receive updates. First update included. Subscription required for updates thereafter.

HP Recovery Manager (available with Windows 7 or Vista only) HP Support Assistant (available with Windows 7 or Vista only) HP ProtectTools Security Manager HP QuickLaunch Buttons Software HP QuickLook 3 HP QuickWeb HP Power Assistant HP Connection Manager HP Wireless Assistant Microsoft Office Professional 2007 60-day Convertible Trial McAfee Total Protection PDF Complete SE Roxio Creator Business 10 (select models) InterVideo WinDVD (select models) Synaptics Touchpad Driver HP Webcam Software WinZip 12

HP SoftPaq Download Manager HP Client Manager Software HP Client Management Solutions Java Card Security for HP ProtectTools

HP Recovery Manager

Security

Models shipped with Windows 7 or Windows Vista include HP Recovery Manager. HP Recovery Manager enables fast recovery of the factory preinstalled image if the system becomes corrupted or if important system files are accidentally deleted. Up to 15 GB of the hard drive is reserved for the system recovery software.

Standard Features

Optional Features

HP ProtectTools Security Manager Enhanced Pre-Boot Security HP SpareKey One-Step Logon Setup Password DriveLock Password TPM 1.2 Embedded Security Chip TPM Enhanced DriveLock HP Disk Sanitizer Kensington Lock slot Support for Computrace** LoJack Pro for HP ProtectTools

HP Fingerprint Sensor

HP Privacy Filter

Computrace** LoJack Pro Premium for HP ProtectTools with GPS Tracking

Enhanced sensor scans the fingerprint to uniquely identify and authenticate a person.

Narrows viewing area so that screen data is visible only to persons directly in front of the monitor.

Subscription based security solution providing the ability to track, initiate physical recovery, conduct asset management, and perform remote data delete by utilizing GPS technology. GPS functionality requires HP un2420 EV-DO/HSPA Mobile Broadband Module.

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 10

QuickSpecs

Standard Features

* TPM module disabled where use is restricted by law; for example, Russia and China. ** The Computrace agent is shipped turned off, and must be activated by customers when they purchase a subscription with terms ranging from one to five years. For more information on HP security solutions refer to:

HP EliteBook 8540p Notebook PC

http://www.hp.com/go/security

HP ProtectTools Security Manager

Power Supply

HP ProtectTools Security Manager is the security platform for business notebooks and desktops. The HP ProtectTools Security Manager is an extensible client security console that delivers enhanced security capabilities through add-on software modules. The following modules are available on the hard drive (also downloadable from the web) and can be configured in Software Setup:

Credential Manager for HP ProtectTools Device Access Manager for HP ProtectTools Drive Encryption for HP ProtectTools File Sanitizer for HP ProtectTools Privacy Manager for HP ProtectTools (Chat & Sign) Embedded Security for HP ProtectTools Computrace LoJack Pro for HP ProtectTools

External 120-watt Smart AC adapter External 90-watt Smart AC adapter

Recommended AC Adapter

Intel dual-core processor

90W

Power cord included is 6-foot (1.8 meter). Total length including external AC adapter is 12 feet (3.66 meter). HP Fast Charge

*HP Fast Charge recharges your battery up to 90% within 90 minutes when the system is off. HP Fast Charge does not apply to the HP Ultra-Capacity Battery.

Intel quad-core processor

120W

Battery

Primary battery

Optional secondary battery

HP 8-cell 73 WHr Li-Ion Primary Battery

HP Long Life 8-cell 68 WHr Li-Ion Primary Battery

HP Extended Life Battery (8-cell 52 WHr)

HP Ultra-Capacity Battery (12-cell 95 WHr)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 11

QuickSpecs

Standard Features

HP EliteBook 8540p Notebook PC

Battery Life

System Standby Time

Power Conservation

Primary battery only

Primary battery and optional HP Extended Life Battery

Primary battery and optional HP UltraCapacity Battery

NOTE:

Battery life will vary depending on the product model, configuration, loaded applications, features, use, wireless functionality and power management settings. The maximum capacity of the battery will naturally decrease with time and usage. See MobileMark07 battery benchmark

www.bapco.com/products/mobilemark2007

* This configuration not tested for battery life.

Up to 2 weeks

Supports enhanced Intel SpeedStep technology (allows Battery Optimized Mode, Maximum Performance Mode, or Automatic mode)

NVIDIA PowerMizer 7.0 technology

Hibernation

Standby

ACPI compliance

HP 8-cell 73 WHr Primary

Up to 5 hours 30 minutes

* *

for additional details.

HP Long Life 8-cell 68 WHr Primary

Docking and Stands

Service and Support

HP Docking Station HP Advanced Docking Station HP USB 2.0 Docking Station HP Essential USB 2.0 Port Replicator HP Dual-Monitor Stand HP Monitor Stand HP Basic Adjustable Stand HP Adjustable Notebook Stand

HP Services offers limited 3-year, 1-year and 90-day warranty options depending on country; 1-year limited warranty on primary battery. On-site service and warranty upgrades are also available. HP Care Pack Services extend service contracts beyond the standard warranties. To choose the right level of service for your HP product, use the HP Care Pack Services Lookup Tool at:

http://www.hp.com/go/lookuptool

available at:

NOTE:

details.

http://h20000.www2.hp.com/bizsupport/TechSupport/ProductRoot.jsp

http://www.hp.com/hps/carepack

Certain restrictions and exclusions apply. Consult the HP Customer Support Center for

. Additional HP Care Pack Services information by product is

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 12

QuickSpecs

Options

HP EliteBook 8540p Notebook PC

Memory

Storage

Expansion Solutions

HP 2 GB (DDR3 1333 MHz) SODIMM

HP 4 GB (DDR3 1333 MHz) SODIMM

HP Upgrade Bay SATA DVD+/-RW SuperMulti DL LightScribe Drive

HP 250GB Pocket Media Drive

HP External USB Drive CD/DVD R/RW

HP Upgrade Bay SATA 500 GB 7200 rpm Hard Drive

HP Primary SATA 500 GB 7200 rpm Hard Drive

HP Primary SATA 320 GB 7200 rpm Hard Drive

HP Docking Station

HP Advanced Docking Station

HP USB 2.0 Docking Station

HP Essential USB 2.0 Port Replicator

HP Dual Hinge Notebook Stand

HP Display & Notebook Stand

HP Adjustable Display Stand

HP Adjustable Dual Display Stand

AT912AA

AT913AA

AK869AA

FE477AA

FS943AA

AU097AA

AU098AA

AS282AA

VB043AA

NZ222AA

FQ834AA

AQ731AA

AW661AA

AW662AA

AW663AA

AW664AA

Communications

Power

HP un2420 EVDO/HSPA Mobile Broadband Module

HP 230W Smart Adapter

90W Smart AC/Auto/Air Combo Adapter

150W Smart AC Adapter

HP Smart 65W Travel AC Adapter

90W Smart AC Adapter

HP 8500/8700 Series 8-Cell Battery

HP Extended Life Battery

HP Ultra-Capacity Battery

TBD

AT895AA

AJ652AA

AL192AA

AU155AA

ED495AA

KU533AA

AJ259AA

AT486AA

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 13

QuickSpecs

Options

HP EliteBook 8540p Notebook PC

Carrying Cases

HP Deluxe Nylon Backpack

HP Deluxe Roller Case

HP Basic Backpack

HP Basic Messenger

HP Basic Carrying Case

HP Professional Series Carrying Case

HP Professional Series Backpack

HP Professional Series Messenger

HP Professional Series Designer Tote

HP Professional Series Slip Case

HP Elite Series Designer Tote

HP Elite Leather Top Load Case

HP Elite Leather Messenger

HP Executive Top Load Case

HP Executive Messenger

HP Elite Top Load Case

HP Elite Slim Top Load Case

HP Professional Slim Top Load Case

HP Value Nylon Case

HP Universal Nylon Case

HP 16.1 Slip Case with Integrated Fan

HP 16.1 Quick Case with Integrated Fan

RR317AA

GD405AA

AM863AA

AP355AA

AJ078AA

AT886AA

AT887AA

AT888AA

AT889AA

AT890AA

AT891AA

AX675AA

AX676AA

AX677AA

AX678AA

AX679AA

AX680AA

AY530AA

RR314AA

RR315AA

AY463AA

AY466AA

Security

Input/Output Devices

HP/Kensington MicroSaver Cable Lock

HP Compaq Notebook Cable Lock

HP Privacy Filter for 15.6-inch Display

HP ExpressCard Smart Card Reader with Java Card

HP PS/2 Keyboard & Mouse Bundle

HP USB Keyboard & Mouse Bundle

HP USB Optical Travel Mouse

HP Wireless Mouse

Desktop Mouse

HP BT Headset

HP Mobile Audio Speakers

HP Mobile Productivity Bundle

HP Mobile Bluetooth Presenter Mouse

HP Notebook Companion Projector

HP DreamColor Advanced Profiling Solution

HP Premium Autofocus Webcam

Premium Digital Headset

PC766A

AY475AA

AU103AA

AJ451AA

RC464AA

RC465AA

RH304AA

AR085AA

DA700AV

AR084AA

FS944AA

AQ729AA

GK872AA

AX325AA

TBD

KQ245AA

KJ270AA

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 14

QuickSpecs

Memory

HP EliteBook 8540p Notebook PC

DDR3 PC3-10600 SDRAM (1333 MHz) Two or four SODIMM slots supporting dual-channel memory SODIMM sizes supported: 2048 MB and 4096 MB

NOTE:

Four memory slots only on models with quad-core processor.

Standard Memory

Optional Memory Upgrades

2048 MB (2048 MB x 1) 4096 MB (4096 MB x 1) 4096 MB (2048 MB x 2) 8192 MB (4096 MB x 2) 8192 MB (2048 MB x 4) 12288 MB (4096 MB x 2 + 2048 MB x 2) 16384 MB (4096 MB x 4)

Support for up to 16384 MB** of memory with the installation of optional DDR3 SDRAM memory kits. All memory slots are user-accessible. Please refer to the Hardware and Software Guide for installation procedures. Maximized dual-channel performance requires SODIMMs of the same size and speed in both memory channels.

Up to

2048 MB 2048 MB 4096 MB 4096 MB 4096 MB 2048 MB 8192 MB 4096 MB

8192 MB 12288 MB 16384 MB

** **

Slot 1 Slot 2 Slot 3 Slot 4

2048 MB 2048 MB 2048 MB 2048 MB 4096 MB 2048 MB 4096 MB 2048 MB 4096 MB 4096 MB 4096 MB 4096 MB

* With some processors, memory bus runs at a maximum of 1066 MHz. ** Requires quad-core processor configuration with four memory slots.

Channel A Channel B

Empty

Empty 2048 MB 4096 MB

Memory Upgrades

NOTE:

This chart does not represent all possible memory configurations. Due to the nonindustry standard nature of some third-party memory modules, we strongly recommend using only HP- branded memory modules to ensure compatibility. If you mix memory speeds, the system will perform at the lower memory speed. Full availability of 4 GB or more of memory requires a Windows 64-bit operating system or Linux. With Windows 32-bit operating systems, the amount of usable memory is dependent upon your configuration, so that above 3 GB all memory may not be available due to system resource requirements.

HP 2 GB (DDR3 1333 MHz) SODIMM

HP 4 GB (DDR3 1333 MHz) SODIMM

AT912AA

AT913AA

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 15

QuickSpecs

Storage

Upgrade Bay Drive Support

HP EliteBook 8540p Notebook PC

Blu-ray R/RE DVD+/-RW SuperMulti DL Drive

Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive

DVD+/-RW SuperMulti DL LightScribe Drive

DVD-ROM Drive

500 GB 7200 rpm SMART SATA II Hard Drive

Internal Storage Device

Hard Drives

500 GB 7200 rpm SMART SATA II Hard Drive

320 GB 7200 rpm SMART SATA II Hard Drive

250 GB 7200 rpm SMART SATA II Hard Drive

Solid State Drive

256 GB Solid State Drive

160 GB Solid State Drive

Quantity Supported

One

Quantity Supported

One

Drive Bay

Upgrade Bay

Drive Bay

Dedicated hard drive bay

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 16

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

System Unit

Dimensions

Weight

NOTE:

varies by configuration and components. Weight includes hard drive, optical drive, and wireless.

Stand-Alone Power Requirements

Power)

Temperature

Relative Humidity

Shock

Random Vibration

Altitude

(unpressurized)

Industry Standard Certifications

* Configurations of the HP EliteBook 8540p that are ENERGY STAR qualified are identified as HP EliteBook 8540p ENERGY STAR on HP websites and on

(HxWxD)

Height varies depending upon where on the notebook the measurement is made. Weight

(AC

1.28 in (at front) x 14.7 in x 9.9 in

32.4 mm (at front) x 373.5 mm x 251.5 mm

Starting at 6.37 lb (2.89 kg)

Nominal Operating Voltage

Average Operating Power

Max Operating Power

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

CSA

FCC Compliance

ENERGY STAR®

EPEAT

ICES

Australia / NZ A-Tick Compliance

CCC

Japan VCCI Compliance

KCC

BSMI

CE Marking Compliance

BNCI or BELUS

CIT

GOST

Saudi Arabian Compliance (ICCP)

SABS

UKRSERTCOMPUTER

18.5 V

27.0 W

< 90 W or < 120 W

32° to 95° F (0° to 35° C) (not writing optical)

41° to 95° F (5° to 35° C) (writing optical)

–4° to 140° F (–20° to 60° C)

10% to 90%, non-condensing

5% to 95%, 101.6° F (38.7° C) maximum wet bulb temperature

125 G, 2 ms, half-sine

200 G, 2 ms, half-sine

0.75 grms

1.50 grms

–50 to 10,000 ft (–15.24 to 3,048 m)

–50 to 40,000 ft (–15.24 to 12,192 m)

Yes

Select models

Registered TBD in United States

Yes

www.energystar.gov

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 17

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

HP 120W Smart AC Adapter

** EPEAT TBD Registered in U.S. EPEAT registration varies by country. See registration status by country.

NOTE:

For accessibility information on HP products, please visit:

Weight

Dimensions

Input

Output

Environmental Design

EMI and Safety Certifications

1.52 lb (0.69 kg) (adapter)

0.29 lb (0.13 kg) (power cord)

6.65 x 2.56 x 1.50 in (16.9 x 6.5 x 3.8 cm)

Operating Input Voltage

Operating Input Current

Operating Frequency Range

Efficiency

Output power

DC Output Voltage

Operating Temperature

Non-operating (storage) Temperature

Altitude

Humidity

Storage Humidity

CE Mark: full compliance with LVD and EMC directives Worldwide safety standards: IEC60950, EN60950, UL60950, Class2, SELV Agency approvals: C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE, S-Mark, Australian Electric Permit, PSB, eK, BSMI, BNCI, KONCAR, GS, GOST, SASO, SABS, UKRSERTCOMPUTER; MTBF- over 200,000 hours at 25°C ambient condition.

100 to 240 VAC

PFC Version:

2.20 A at 90 VAC

1.10 A at 180 VAC

Non-PFC Version:

2.5 A at 110 VAC

1.25 A at 180 VAC

47 to 63 Hz AC

83% minimum at 115 VAC

120 W

18.5 V

32° to 104° F (0° to 35° C)

-4° to 149° F (-20° to 65° C)

0 to 10,000 ft (0 to 3,048 m)

20% to 80%

10% to 90%

http://www.hp.com/accessibility

www.epeat.net

for

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 18

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

HP 90W Smart AC Adapter

Dimensions

Weight

Input

Output

Connector

Environmental Design

EMI and Safety Certifications

5.00 x 1.97 x 1.1 in (12.7 x 5.0 x 2.9 cm)

0.82 lb (370 g)

100 to 240 VAC

Input Efficiency

Input frequency range

Input AC current

Output power

DC output

Hold-up time

Output current limit

3 pin/grounded, mates with interchangeable cords

Operating temperature

Non-operating (storage) temperature

Altitude

Humidity

Storage Humidity

CE Mark - full compliance with LVD and EMC directives; Worldwide safety standards - IEC60950, EN60950, UL60950, Class1, SELV; Agency approvals - C-UL-US, NORDICS, DENAN, EN55022 Class B, FCC Class B, CISPR22 Class B, CCC, NOM-1 NYCE; MTBF- over 200,000 hours at 25°C ambient condition.

83% min at 115 VAC

47 to 63 Hz

1.5 A at 90 VAC, 0.75 A at 180 VAC PFC Version

2.4 A at 90 VAC, 1.2 A at 180 VAC NON PFC Version

90W

19.0V

5 msec at 115 VAC input

<11A, Over voltage protection- 29V max automatic shutdown

32° to 104° F (0° to 40° C)

-4° to 149° F (-20° to 65° C)

0 to 10,000 ft (0 to 3,048 m)

20% to 80%

10% to 90%

Optional HP UltraCapacity Battery

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge

(H x W x L)

1.3 x 6.0 x 10.6 in (3.33 x 15.25 x 26.88 cm)

1.77 lb (0.803 kg)

12-cell Lithium-Ion

Watt-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

Smart Adapter

System ON

When pressed, LEDs light indicating level of charge remaining on battery

95 Wh

32° to 113° F (0° to 45° C)

14° to 140° F (-10° to 60° C)

-4° to 140° F (-20° to 60° C)

3 to 4 hours

4 to 5 hours (depending on system power consumption)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 19

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

Optional HP Extended Life Battery

HP 8-Cell 73 Wh Lithium-Ion Primary battery

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

Fuel Gauge

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

(H x W x L)

(HxWxL)

1.0 x 3.9 x 8.7 in (2.5 x 10.0 x 22.0 cm)

1.00 lb (0.455 kg)

8-cell Lithium-Ion

Watt-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF mode or Standby

System ON

HP Fast Charge Technology

When pressed, LEDs light indicating level of charge remaining on battery

0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)

0.980 lb (0.445 kg)

8-cell Lithium-Ion

Watt-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF mode or Standby

System ON

HP Fast Charge Technology

52 Wh

32° to 113° F (0° to 45° C)

14° to 140° F (-10° to 60° C)

-4° to 140° F (-20° to 60° C)

3 hours

3 to 5 hours (depending on system power consumption)

Charges the battery up to 90% within 90 minutes when system is OFF

73 Wh

32° to 113° F (0° to 45° C)

14° to 140° F (-10° to 60° C)

-4° to 140° F (-20° to 60° C)

2.5 hours

3 to 5 hours (depending on system power consumption)

Charges the battery up to 90% within 1.5 hours when system is OFF

HP Long Life 8-Cell 68 Wh Primary battery

Displays

Dimensions

Weight

Cells/Type

Energy

Temperature

Battery Re-Charge Time

(HxWxL)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

0.8 x 1.9 x 10.6 in (2.0 x 4.8 x 27.0 cm)

0.930 lb (0.420 kg)

8-cell Lithium-Ion

Watt-hour Capacity

Operating (Charging)

Operating (Discharging)

Non-operating

System in OFF mode or Standby

System ON

68 Wh

32° to 113° F (0° to 45° C)

14° to 140° F (-10° to 60° C)

-4° to 140° F (-20° to 60° C)

2.5 hours

3 to 5 hours (depending on system power consumption)

Page 20

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

15.6-inch LED HD (1366 x 768) anti-glare

15.6-inch LED HD+ (1600 x 900) anti-glare

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

(W x H)

14.15 x 8.25 in (35.9 x 21.0 cm)

15.6 in (39.6cm)

Anti-glare

300:1 (min)

60 Hz

200 nit (typical)

Pitch

Format

Configuration

LED

101 ppi

±30° Horizontal, ±10° Vertical (minimum) 30/30/20/10 (Left/Right/Down/Up) (minimum) or 45/45/35/25 (Left/Right/Down/Up) (typical)

14.15 x 8.25 in (35.9 x 20.9 cm)

15.6 in (39.6cm)

Anti-glare

300:1 (min)

60 Hz

200 nits (typ)

Pitch

Format

Configuration

LED

118 ppi

30/30/20/10 (Left/Right/Down/Up) (minimum) or 45/45/35/25 (Left/Right/Down/Up) (typical)

0.252 mm

1366 x 768

RGB Stripe

0.2151mm

1600 x 900

RGB Strip

15.6-inch LED FHD (1920 x 1080) anti-glare

Internal Storage

Dimensions

Diagonal Size

Surface Treatment

Contrast Ratio

Refresh Rate

Brightness

Pixel Resolution

Backlight

PPI

Viewing Angle

(W x H)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

14.15 x 8.25 in (35.9 x 20.9 cm)

15.6 in (39.6 cm)

Anti-glare

300:1 (min)

60 Hz

220 nits (Typ)

Pitch

Format

Configuration

LED

142 ppi

60/60/50/50 (Left/Right/Down/Up) (minimum) or 70/70/60/60 (Left/Right/Down/Up) (typical)

0.179mm x 0.179mm

1920 x 1080

RGB Strip

Page 21

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

500 GB 7200 rpm SATA Hard Drive

320 GB 7200 rpm SATA Hard Drive

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

0.25 lbs (115g)

500 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Synchronous

(maximum)

Single Track

Average

Maximum

7200 rpm

976,773,168

32° to 140° F (0° to 60° C) [case temp]

ATA Security

0.25 lbs (115g)

250 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Synchronous

(maximum)

Single Track

Average

Maximum

7200 rpm

625,142,448

32° to 140° F (0° to 60° C) [case temp]

ATA Security

100 MB/s (Drive Capability)

1.5 ms

11 ms

22 ms

100 MB/s (Drive Capability)

1.5 ms

11 ms

22 ms

250 GB 7200 rpm SATA Hard Drive

Drive Weight

Capacity

Height

Width

Interface

Transfer Rate

Seek Time

(typical reads, including settling)

Rotational Speed

Logical Blocks

Operating Temperature

Features

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

0.25 lbs (115g)

250 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

ATA-8, SATA 2.6, 3.0 Gb/s, NCQ

Synchronous

(maximum)

Single Track

Average

Maximum

7200 rpm

488,397,168

32° to 140° F (0° to 60° C) [case temp]

ATA Security

100 MB/s (Drive Capability)

1.5 ms

11 ms

22 ms

Page 22

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

256 GB

2.5-Inch SATA Solid State Drive

160 GB

2.5-inch SATA Solid State Drive

Weight

Capacity

Height

Width

Interface

Performance

Logical Blocks

Operating Temperature

Features

Weight

Capacity

Height

Width

Interface

Performance

Logical Blocks

Operating Temperature

Features

80.1 Grams

256 GB

0.37 in (9.5 mm)

2.75 in (70 mm)

SATA

Maximum Sequential Read

220 MB/s 200 MB/s

500,118,192

32° to 158°F (0° to 70°C) [case temp]

ATA Security; ATA-7;SATA 2.6; DIPM

78 Grams

160 GB

0.275 in (7 mm)

2.75 in (70 mm)

SATA

Maximum Sequential Read

250 MB/s

312,581,808

32° to 158°F (0° to 70°C) [case temp]

ATA Security; ATA-7 ;SATA 2.6; DIPM

Maximum Sequential Write

70 MB/s

Optical Drives

DVD-ROM Drive

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(read)

Transport

(read)

(write)

Random

24X CD-ROM

8X-DVD

UDMA Mode 5

Gen 1 SATA

CD-DA, CD+(E)G, CD-MIDI, CD-TEXT, CD-ROM, CD-ROM XA, MIXED MODE CD, CD-I, CD-I Bridge (Photo-CD, Video CD), Multisession CD (Photo-CD, CD-EXTRA, Portfolio, CD-R, CD-RW), CD-R, CD-RW, DVD-ROM (DVD-5, DVD-9, DVD-10, DVD-18), DVD-R, DVD-RW, DVD+R, DVD+RW, DVD-RAM

None

8.5 GB

Tray Loading

< 110 ms CD (typical)

< 110 ms DVD (typical)

Up to 3,600 KB/s

Up to 10,800 KB/s

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 23

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

DVD+/-RW SuperMulti DL LightScribe Drive

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(read)

Max Media Capacity

(write)

Transport

(read)

(write)

Random

24X CD-ROM

8X DVD

24X CD-R

16X CD-RW

8X DVD+R

8X DVD+RW

8X DVD-R

6X DVD-RW

4X - DVD+R Dual Layer

4X - DVD-R Dual Layer

5X DVD-RAM

UDMA Mode 5

Gen 1 SATA

CD-R, CD-RW, DVD+R, DVD+RW, DVD-R, DVD-RW, DVD-RAM, LightScribe

8.5 GB

Tray Loading

< 150ms CD (typical)

< 160 ms DVD (typical)

Up to 3,600 KB/s

Up to 10,800 KB/s

Up to 3,600 KB/s

Up to 2,400 KB/s

Up to 10,800 KB/s

Up to 8100KB/s

Up to 5,400 KB/s

Up to 6,750 KB/s

Blu-ray R/RE DVD+/RW SuperMulti DL Drive

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Random

24X CD-ROM

8X DVD-ROM

8X CD-R

8X CD-RW

8X DVD+R

4X DVD+RW

8X DVD-R

4X DVD-RW

2.4X DVD+R(9)

5X DVD-RAM

1X BD-ROM

1X BD-R

1X BD-RE

UDMA Mode 5

Gen 1 SATA

<140 ms CD-ROM (typical)

<160 ms DVD-ROM (typical)

<300 ms BD-ROM (typical)

Up to 3,600 KB/s

Up to 10,800 KB/s

Up to 1,200 KB/s

Up to 10,800 KB/s

Up to 5,400 KB/s

Up to 10,800 KB/s

Up to 5,400 KB/s

Up to 2,700 KB/s

Up to 6,750 KB/s

Up to 4,500 KB/s

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 24

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive

Supported Media

Max Media Capacity

(read)

Max Media Capacity

(write)

Transport

Access Times

Max Data Transfer Rate

Transfer Mode

Interface

Supported Media

Max Media Capacity

(read)

Max Media Capacity

(write)

Transport

(read)

(write)

(read)

(write)

CD-R, CD-RW, DVD+R, DVD+R(9), DVD+RW, DVD-R, DVD-R(9), DVD-RW, DVD-RAM, BD-R, BD-RE

50.0 GB

Tray Loading

Random

24X CD-ROM

8X DVD-ROM

16X CD-R

10X CD-RW

8X DVD+R

8X DVD+RW

8X DVD-R

6X DVD-RW

4X - DVD+R Dual Layer

4X - DVD-R Dual Layer

5X DVD-RAM

4X BD-ROM

UDMA Mode 5

Gen 1 SATA

CD-R, CD-RW, DVD+R, DVD+R(9), DVD+RW, DVD-R, DVD-R(9), DVD-RW, DVD-RAM, LightScribe

50.0 GB

8.5 GB

Tray Loading

<190 ms CD-ROM (typical)

< 190ms DVD-ROM (typical)

<230 ms BD-ROM (typical)

Up to 3600 KB/s

Up to 10800 KB/s

Up to 1,200 KB/s

Up to 1500 KB/s

Up to 10800 KB/s

Up to 10,800 KB/s

Up to 10800 KB/s

Up to 8,100 KB/s

Up to 5400 KB/s

Up to 6750 KB/s

Up to 18,000 KB/s

Security

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 25

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

HP Fingerprint Sensor

(optional)

Audio

Hardware

Mobile Voltage Operation

Operating Temperature

Current Consumption @ 3.3V

High-Rate Image Capture

ESD Resistance

Detection Matrix

Implementation

Touch-Sensitive Volume Controls

Full Duplex

Microphone In

Headphone/Line Out

Integrated Microphone

3.0V-3.6V Single Supply

32° - 158°F (0° - 70°C)

Less than 70 mA peak imaging and scrolling Less than 25 mA hardware finger detection Advanced Power Management

Up to 240 image frames /sec

IEC 61000-4-2 Level 4 (±15KV)

192 x 16 Pixels

9.7 mm x 0.81 mm 500 ppi High-Resolution Images

IDT 92HD75B High Definition CODEC

Volume up, volume down, and mute

Yes

Stereo

Yes, dual-microphone array when equipped with optional webcam

Audio Output Quality

Integrated Stereo Speakers

Communications

Frequency Response

Signal to Noise Ratio

Total Harmonic Distortion

Noise Floor

Play/Record Sampling Rate

(s)

DAC

ADC

Power Rating

Impedance

20 Hz - 20 kHz

>85 dB

0.01%

-110 dB

8 kHz - 48kHz

16, 20 or 24-bit

16 or 20-bit

2 Watts

4 Ohms

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 26

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

Integrated Intel Gigabit Network Connection

(10/100/1000 NIC)

82577LM

Ethernet Features

Power Management

Performance Features

Manageability

Interface

NIC Device Driver Name

10 Mbit/s operation (10BASE-T; IEEE 802.3i; IEEE 802.3 clauses 13-

14) 100 Mbit/s operation (100BASE-TX; IEEE 802.3u; IEEE 802.3 clauses 21-30) 1000 Mbit/s operation (1000BASE-T; IEEE 802.3z and 802.3ab; IEEE

802.3 clauses 34-42) Auto-Negotiation (Automatic Speed Selection) Full Duplex Operation at all Speeds, Half Duplex operation at 10 and 100 Mbit/s IEEE 802.1p QoS (Quality of Service) Support IEEE 802.3x Flow Control (IEEE 802.3 clauses 31-32; configurable)

ACPI compliant – multiple power modes Situation-sensitive features reduce power consumption

TCP/IP/UDP Checksum Offload (configurable)

Wake-on-LAN from standby and hibernation (Magic Packet and Microsoft Wake-Up Frame); Wake-on-LAN from off (Magic Packet only) PXE 2.1 Remote Boot Statistics Gathering (SNMP MIB II, Ethernet-like MIB, Ethernet MIB (802.3x, clause 30)) Comprehensive diagnostic and configuration software suite Intel Advanced Management Technology 6.0 (iAMT)

PCI Express x1 based, SMBUS dedicated connection with Intel® 5 Series Chipset

Intel 82577 Gigabit Network Connection

V.92 56K Data/Fax Modem

Form Factor

Power Management Support

Approvals/ Certifications

Data Mode Capabilities

MDC 1.5 Daughtercard

APM Revision 1.2, ACPI

UL, CSA, NEMKO, CCIB, Industry Canada, FCC Part 68, CTR21, FCC Part 15 Class B, Canadian ICES-003 Class B, C.I.S.P.R.22, Australian ACA, CE Mark, Other Countries

V.92 data

V.8bis

V.80

V44, V.42bis, MNP5 (Compression)

V.42 (LAPM, MNP2-4) (Error Correction)

Optional symbol rates:

2800, 3429 Asymmetric Symbol rates

Synchronous primary channel data signaling rates:

3600, 31200 Automatic rate re-negotiation V.34 V.32bis V.32 V.23 V.22bis V.22 V.21 Bell 212A Bell 103J

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 27

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

HP un2420 EV-DO/HSPA Mobile Broadband Module

Fax Mode Capabilities

Command Set

Technology/Operating Bands

Wireless Protocol Standards

Wireless Parametric Standards

Maximum Data Rates

GPS

GPS Bands

Maximum Output Power

Maximum Power Consumption

Power Consumption, Sleep Mode

Power Management

Antenna Type

Form Factor

Weight

Dimensions

Width x Thickness)

Voltage, Operating

Temperature, Operating

TIA/EIA/IS-98-D)

(Length x

(from

TIA/EIA-578-B (Class 1) T.30, T.4 (Group 3) V.17 V.29 V.27ter V.21 Channel 2

V.250 (Partial) TIA-602 Identification: +GMI, +GMM, +GMR Port control: +IPR, +ICF, +IFC, +ILRR Modulation: +MS, +MR, +MA Error control: +ES, +ER, +EB, +ESR, +ETBM Data compression: +DS, +DR V.251

GSM/GPRS/EDGE: 850MHz(Cell), 900MHz(EGSM), 1800MHz(DCS), 1900MHz (PCS) UMTS/WCDMA with receive diversity: 2100MHz (UTRA FDD Band I), 1900MHz (UTRA FDD Band II), 900Mhz (UTRA FDD Band VIII), 850MHz (UTRA FDD Band V) 1xEVDO/1xRTT with receive diversity: 850MHz (Band Class0-Cell), 1900MHz (Band Class1-PCS)

GSM/GPRS/EDGE: Class B, Multi-slot operation, coding schemes CS1

- CS4 and MSC1 - MSC9. UMTS/WCDMA: Release 99 and Release 6 CDMA: 1xEVDO Release 0 and Release A, IS-95A, IS-95B, IS-2000

Meets or exceeds TIA/EIA IS-98-D

UMTS (HSPA) - 7.2 Mbps (Download ), 2.0Mbps (Upload) CDMA (EVDO Release A) - 3.1 Mbps (Download), 1.8Mbps (Upload)

Standalone GPS enabled

L1 - 1575.42 MHz

GSM/GPRS/EDGE: 32dBm (+/-1) WCDMA: 24dBm (+/-1) CDMA: 24dBm (+/-1)

2500mA (peak); 1000mA (average)

5 mA

USB selective suspend Integrated notebook wireless button

Dual high efficiency 5 band antennae with spatial diversity, mounted in the display enclosure

PCI-Express MiniCard, USB 2.0 interface

11.5 g

2.01 x 1.18 x 0.18 in (51 x 30 x 5 mm)

3.3v +/- 10%

-22° to 140° F (-30° to 60° C) (full RF performance)

-22° to 167° F (-30° to 75° C) (reduced RF performance)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 28

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

Intel Centrino UltimateN 6300

Temperature, Nonoperating, 96 hours

(from MIL-STD 202 Method 108)

Humidity, Nonoperating

Configuration Utilities

LED Activity

Wireless LAN Standards

Interoperability

Frequency Band

Antenna Structure

Data Rates

Modulation

Security

-40° to 185° F (-40° to 85° C)

85% relative humidity for 48 hours @ 185° F (85° C) (non-condensing)

HP Connection Manager

LED Off - Radio Off; Solid LED On - Radio On

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n

* In countries where 802.11n is not allowed, this capability is not enabled.

Wi-Fi certified (802.11bgn only) Cisco Compatible Extensions Program compliant (802.11bgn only) with Microsoft Windows Vista and XP

2.4 GHz and 5GHz

3 transmit; 3 receive (3x3)

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: many possible data rates, ranging from 6 Mbps to 450 Mbps, depending on the combination of Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n specification

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Authentication: WPA and WPA2, 802.1x (EAP_TLS, TTLS, PEAP, LEAP, EAP-FAST)

Authentication Protocols: PAP, CHAP, TLS, GTC, MS-CHAP, MSCHAPv2

Encryption: 64 and 128-bit WEP, AES-CCMP, CKIP, TKIP

Support for Cisco Security Features (proven compatibility with Cisco Aironet infrastructure products through the Cisco Compatible Extensions Program Version 4) with Microsoft Windows Vista and XP only.

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output Power

and OFDM)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

(for CCK

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between Access Points

17 dBm max

Page 29

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

Power Consumption

Power Management

Receiver Sensitivity454 Mbps: -76 dBm, 6 Mbps: -92 dBm

Antenna Connections

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

Check latest software/driver release for updates on supported security features.

1. Maximum output power may vary by country according to local regulations.

2. In Power Save Polling mode and on battery power.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation)

4. and a packet error rate of 10% for 802.11a/g (OFDM modulation). WLAN supplier's client utility is required for Cisco Compatible Extensions support with

5. Microsoft Windows XP. WLAN may also be compatible with certain third-party software supplicants. WLAN supplier IHV extensions required for Cisco Compatible Extensions support for Microsoft Windows Vista.

Transmit: 2.4 Watts (max, with three spatial streams) Receive: 1.4 Watts (max with three spatial streams) Idle mode3: 35 mW (average) Radio off: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

3 U.FL type connectors, 50 ohm nominal impedance

PCI-Express Half-MiniCard

0.0075 lb (3.4 g)

0.12 x 1.06 x 1.18 in (3.1 x 26.8 x 30.0 mm)

3.3V +/- 9%

Operating Non-operating

LED Off - Radio OFF; Solid LED On - Radio ON

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

10% to 90% (non-condensing) 5% to 90% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

Intel Centrino Advanced-N 6200

Wireless LAN Standards

Interoperability

Frequency Band

Antenna Structure

Data Rates

Modulation

Security

IEEE 802.11a IEEE 802.11b IEEE 802.11g IEEE 802.11n

* In countries where 802.11n is not allowed, this capability is not enabled.

Wi-Fi certified Cisco Compatible Extensions Program compliant with Microsoft Windows Vista and XP

2.4 GHz and 5GHz

2 transmit; 2 receive (2x2)

802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11b: 1, 2, 5.5, 11 Mbps

802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps

802.11n: 66 possible data rates, ranging from 6 Mbps to 300 Mbps, depending on the combination of Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n specification

Direct Sequence Spread Spectrum DBPSK, DQPSK, CCK, OFDM, BPSK, QPSK, 16-QAM, 64-QAM

Authentication: WPA and WPA2, 802.1x (EAP_TLS, TTLS, PEAP, LEAP, EAP-FAST)

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 30

QuickSpecs

Technical Specifications

Sub-channels

Media Access Protocol

Network Architecture Models

Roaming

Output Power

and OFDM)

Power Consumption

Power Management

Receiver Sensitivity454 Mbps: -76 dBm, 6 Mbps: -92 dBm

Antenna Connections

Form Factor

Weight

Dimensions

Operating Voltage

Temperature

Humidity

Altitude

LED Activity

Check latest software/driver release for updates on supported security features.

1. Maximum output power may vary by country according to local regulations.

2. In Power Save Polling mode and on battery power.

3. Receiver sensitivity is measured at a packet error rate of 8% for 802.11b (CCK modulation)

4. and a packet error rate of 10% for 802.11a/g (OFDM modulation). WLAN supplier's client utility is required for Cisco Compatible Extensions support with

(for CCK

HP EliteBook 8540p Notebook PC

Authentication Protocols: PAP, CHAP, TLS, GTC, MS-CHAP, MSCHAPv2

Encryption: 64 and 128-bit WEP, AES-CCMP, CKIP, TKIP

Multinational support with frequency bands and channels compliant to local regulations.

CSMA/CA (Collision Avoidance) with ACK

Ad-hoc (Peer to Peer) Infrastructure (Access Point Required)

IEEE 802.11 compliant roaming between 2.4GHz band Access Points

17 dBm max

Transmit: 2.3 Watts (max, with two spatial streams) Receive: 1 Watt (max with two spatial streams) Idle mode3: 35 mW (average) Radio off: 20 mW (max)

ACPI compliant power management

802.11 compliant power saving mode

2 U.FL type connectors, 50 ohm nominal impedance

PCI-Express Half-MiniCard

0.0075 lb (3.4 g)

0.12 x 1.06 x 1.18 in (3.1 x 26.8 x 30.0 mm)

3.3V +/- 9%

Operating Non-operating

LED Off - Radio OFF; Solid LED On - Radio ON

32° to 176° F (0° to 80° C)

-40° to 176° F (-40° to 80° C)

10% to 90% (non-condensing) 5% to 90% (non-condensing)

0 to 10,000 ft (3,048 m) 0 to 50,000 ft (15,240 m)

HP Integrated Module with Bluetooth 2.1 Wireless Technology

Bluetooth Specification

Dimensions

Frequency Band

Number of Available Channels

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

2.1 Compliant

1.18 x 0.26 x 0.13 in (30 x 6.5 x 3.25 mm)

2402 to 2480 MHz

79 (1 MHz) available channels

Page 31

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

Data Rates and Throughput

Transmit Power

Receiver Sensitivity

Power Consumption

Antenna

Range

Electrical Interface

Bluetooth Software Supported

Link Topology

Security

Power Management

Certifications

Temperature

Humidity

Altitude

Bluetooth Profiles Supported

3 Mbps data rate; throughput up to 2.17 Mbps

Synchronous Connection Oriented links up to 3, 64 kbps, voice channels

Asynchronous Connection Less links 2178.1 kbps/177.1 kbps asymmetric or 1306.9 kbps symmetric

-6 dBm to 4 dBm (Bluetooth Class II)

Better than -80 dBM at 0.1 % raw bit error rate

Peak (Tx) 264 mW

Peak (Rx) 231 mW

Sleep <1 mW

Internally integrated within module

Up 33 ft (10 m)

USB 2.0 compliant

Microsoft Windows Plug and Play compliant

Broadcom Bluetooth for Windows

Microsoft Windows Bluetooth Software

Point to Point, Multipoint Pico Nets up to 7 slaves

Full support of Bluetooth Security Provisions

Microsoft Windows ACPI, and USB Bus Support

Self configurable to optimize power conservation in all operating modes, including Standby, Hold, Park, and Sniff

All necessary regulatory approvals for supported countries, including:

FCC (47 CFR) Part 15C, Section 15.247 & 15.249

ETS 300 328, ETS 300 826

Low Voltage Directive IEC950

UL, CSA, and CE Mark

Operating

Non-operating

Operating

Non-operating

Operating

Non-operating

Serial Port Profile (SPP)

Service Discovery Applicaton Profile (SDAP)

Dial-Up Networking (DUN)

Generic Object Exchange Profile (GOEP)

Object Push Profile (OPP)

File Transfer Profile (FTP)

Synchronization Profile (SYNC)

Hard Copy Cable Replacement (HCRP)

Personal Area Networking Profile (PAN)

Human Interface Device Profile (HID)

FAX Profile (FAX)

Basic Imaging Profile (BIP)

Headset Profile (HSP)

Hands Free Profile (HFP)

Advanced Audio Distribution Profile (A2DP)

-4° to 158° F (-20° to 70° C)

-40° to 176° F (-40° to 80° C)

10% to 90%

5% to 95%

15,000 ft (4,572 m)

40,000 ft (12,192 m)

1,2

1,2,3

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 32

QuickSpecs

Technical Specifications

indicates the profile is supported by Microsoft Windows XP SP2

indicates the profile is part of Windows Vista

HP EliteBook 8540p Notebook PC

Environmental Data

Eco-Label Certifications

System Configuration

Energy Consumption

Normal Operation

Sleep (Energy Star low power mode)

Off

Heat Dissipation

Normal Operation

Sleep

Off

Declared Noise Emissions (in accordance with ISO 7779 and ISO 9296)

System Fan Off

Idle

Fixed Disk (random writes)

System fan is usually off except when charging the battery

Batteries

This product has received or is in the process of being certified to the following approvals and may be labeled with one or more of these marks:

US Energy Star IT ECO declaration EPEAT - Gold where HP registers commercial desktop products. See

http://www.epeat.net

The configuration used for the Energy Consumption and Declared Noise Emissions data for the Convertible Mini tower Desktop model is based on a "Typically Configured Notebook"

115 VAC 230 VAC 100 VAC

17.14 W 17.95 W 17.05 W

1.278 W 1.335 W

0.647 W 0.707 W 0.649 W

115 VAC 230 VAC 100 VAC

59 BTU/hr 61 BTU/hr 58 BTU/hr

4 BTU/hr 5 BTU/hr 4 BTU/hr

2 BTU/hr 2 BTU/hr 2 BTU/hr

* Heat dissipation is calculated based on the measured watts, assuming the service level is attained for one hour.

Sound Power

(LWAd, bels)

3.5

This battery(s) in this product comply with EU Directive 2006/66/EC

for registration status in your country.

1.28 W

Sound Pressure

(LpAm, decibels)

27.8

Batteries used in the product do not contain:

Mercury greater the 5ppm by weight Cadmium greater than 10ppm by weight

The battery type and chemistry used in the product is: CR2032 (coin cell), Li-ion 6-cell high capacity Lithium-Ion battery (optional 8 cell available)

Additional information

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

This product is in compliance with the Restrictions of Hazardous Substances (RoHS) directive - 2002/95/EC.

This HP product is designed to comply with the Waste Electrical and Electronic Equipment (WEEE) Directive - 2002/96/EC.

This product is in compliance with California Proposition 65 (State of

Page 33

QuickSpecs

Technical Specifications

HP EliteBook 8540p Notebook PC

California; Safe Drinking Water and Toxic Enforcement Act of 1986).

This product is in compliance with the IEEE 1680 (EPEAT) standard at the Gold level, see:

Plastics parts weighing over 25 grams used in the product are marked per ISO 11469 and ISO1043.

This product contains 0% post consumer recycled plastic (by wt.)

This product is greater than 90% recycle-able when properly disposed of at end of life.

Packaging Materials

External:

Paper 97 g

Internal:

Polyethylene low density solid 13 g Molded Pulp 100 g

Polyethylene low density 4 g The paper material is made from 80% recycled content. The Polyethylene low density solid is made from 100% recycled content. The Molded Pulp is made from 80% recycled content. The Polyethylene low density material is made from 100% recycled content.

www.epeat.net

Material Usage

HP follows these guidelines to decrease the environmental impact of product packaging:

Eliminate the use of heavy metals such as lead, chromium, mercury and cadmium in packaging materials. Eliminate the use of ozone-depleting substances (ODS) in packaging materials. Design packaging materials for ease of disassembly. Maximize the use of post-consumer recycled content materials in packaging materials. Use readily recyclable packaging materials such as paper and corrugated materials. Reduce size and weight of packages to improve transportation fuel efficiency. Plastic packaging materials are marked according to ISO 11469 and DIN 6120 standards.

This product does not contain any of the following substances in excess of regulatory limits (for reference of these limits please refer to the HP General Specification of the Environment: (

http://www.hp.com/hpinfo/globalcitizenship/environment/supplychain/

gen_specifications.html

Asbestos Certain Azo Colorants Certain Brominated Flame Retardants - may not be used as flame retardants in plastics Cadmium Chlorinated Hydrocarbons Chlorinated Paraffins Formaldehyde Halogenated Diphenyl Methanes

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 34

QuickSpecs

Technical Specifications

End-of-life Management and Recycling

HP EliteBook 8540p Notebook PC

Lead carbonates and sulfates Lead and Lead compounds Mercuric Oxide Batteries Nickel - finishes must not be used on the external surface designed to be frequently handled or carried by the user. Ozone Depleting Substances Polybrominated Biphenyls (PBBs) Polybrominated Biphenyl Ethers (PBBEs) Polybrominated Biphenyl Oxides (PBBOs) Polychlorinated Biphenyl (PCB) Polychlorinated Terphenyls (PCT) Polyvinyl Chloride (PVC) - except for wires and cables, and certain retail packaging has been voluntarily removed from most applications. Radioactive Substances Tributyl Tin (TBT), Triphenyl Tin (TPT), Tributyl Tin Oxide (TBTO)

Hewlett-Packard offers end-of-life HP product return and recycling programs in many geographic areas. To recycle your product, please go to:

http://www.hp.com/go/reuse-recycle

office. Products returned to HP will be recycled, recovered or disposed of in a responsible manner.

or contact your nearest HP sales

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: These instructions may be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.

Hewlett-Packard Corporate Environmental Information

All rights reserved. Microsoft, Windows, Windows 7, Windows Vista and Windows XP are registered trademarks or trademarks of Microsoft Corporation in the U.S. and/or other countries. Intel and Core are registered trademarks or trademarks of Intel Corporation in the U.S. and/or other countries. Bluetooth is a registered trademark of Bluetooth SIG, Inc., in the U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies.

For more information about HP's commitment to the environment: Global Citizenship Report

http://www.hp.com/hpinfo/globalcitizenship/gcreport/index.html

Environment website

http://www.hp.com/environment

Eco-label certifications

http://www.hp.com/hpinfo/globalcitizenship/environment/productdesign/ ecolabels.html

ISO 14001 certificates:

http://www.hp.com/hpinfo/globalcitizenship/environment/operations/ envmanagement.html

http://www.hp.com/go/recyclers

The information contained herein is subject to change without notice and is provided "as is" without warranty of any kind. The warranties for HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

DA - 13521 Worldwide QuickSpecs — Version 7 — 3.1.2010

Page 35

HP 8540p User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Options

Memory

Storage

Technical Specifications
