HP 8110i User Manual
HP SureStore
CD-Writer Plus
User’s Guide
for your internal drive
Hewlett-Packard Company, 800 S. Taft Ave., Loveland, CO 80537
C4392-90100
Copyright 1998. Hewlett-Packard Company. All rights reserved.
Hewlett-Packard is a registered trademark of the Hewlett-Packard Company. Microsoft and Windows are U.S. registered
trademarks of Microsoft Corporation. Pentium is a U.S. registered trademark of Intel Corp. Names of products mentioned
herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective
company.
Printed in USA.
ii
Table of Contents
Chapter 1: Installing CD-Writer Plus and Software
What’s in the Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Tools You’ll Need. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Installing a CD-Writer Plus in an Empty Drive Bay . . . . . . . . . . . . . . . 1-3
Replacing an Existing CD-ROM Drive With a CD-Writer Plus . . . . . . 1-20
Installing Software: Windows 95, Windows 98, or Windows NT 4.0. 1-34
Uninstalling the Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-34
If You Have Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-35
Chapter 2: Using Your CD-Writer Plus
Using CDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Identifying CD-Writer Plus’s Drive Letter . . . . . . . . . . . . . . . . . . . . . . . 2-4
Chapter 3: Problem Solving
Things to Try First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Common Symptoms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Solutions to Some Common Symptoms . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Chapter 4: Sharing Your CDs
Varying Formats. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Sharing CDs across Different Formats. . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
Chapter 5: Making Data CDs
Making Data CDs to Use on Your Own Computer. . . . . . . . . . . . . . . . 5-1
Making Data CDs to Use on Different Types of Computers . . . . . . . . . 5-6
Getting Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Chapter 6: Making Music CDs
Starting EasyCDCreator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Making a Music CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Modifying Your CD Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
Playing Music CDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Getting Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-10
Chapter 7: Making Inserts and Labels
How to Make a Jewel Case Insert or a Label . . . . . . . . . . . . . . . . . . . . . 7-2
Getting Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Chapter 8: Copying CDs
What Types of CDs Can I Copy?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-1
Starting CDCopier. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2
Making a Copy of a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-3
Getting Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5
iii
Chapter 9: HP Simple Trax
Welcome to HP Simple Trax . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-1
Protecting Files and Folders Immediately . . . . . . . . . . . . . . . . . . . . . . . 9-2
Creating a Protection List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3
Scheduling a Protection Session to Run Automatically . . . . . . . . . . . . 9-4
Retrieving Protected Files and Folders. . . . . . . . . . . . . . . . . . . . . . . . . . 9-6
Searching the HP Simple Trax Information Vault . . . . . . . . . . . . . . . . . 9-9
Reconstructing the HP Simple Trax Information Vault . . . . . . . . . . . 9-11
Importing CDs into HP Simple Trax . . . . . . . . . . . . . . . . . . . . . . . . . . 9-11
HP Simple Trax Control Panel Overview. . . . . . . . . . . . . . . . . . . . . . . 9-12
Chapter 10: HP Disaster Recovery
Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-1
Testing your Disaster Recovery Set . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-3
Recovering Your Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-4
HP Disaster Recovery Glossary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-8
iv
Appendix A: Technical Information
Minimum System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
What Affects System Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-2
Drive Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-3
Appendix B: Customer Support
Before You Call HP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
HP Customer Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-5
Returning a Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-8
v
Product Certifications
UL, cUL, TÜV, CE, C-Tick, meets or exceeds FCC Class B Requirements
