OfficeJet Pro 1150Cse

HP Parts Reference Guide™

www.hp.com/go/hpparts

Chassis Parts

Actuator

C5300-40027 Push rod - Power switch actuator shaft (with button)

NO LONGER SUPPLIED

Bezel

C5300-60112 Control panel bezel (Overlay) - Snaps on top of the control panel assembly

NO LONGER SUPPLIED

Door

C5300-40014 Pen cartridge door - Access door for changing the printer ink cartridges (Mounts on left end of the scanner)

NO LONGER SUPPLIED

Fan

3160-1039 Tubeaxial fan - 12VDC, 250mA, 3.0 watts, 35dB, 2750RPM - Housing dimensions 92mm x 92mm x 25.5mm - Mounting

hole center spacing 82.5mm - Plastic housing, fixed wire leads with connector NO LONGER SUPPLIED

Filter

C5300-80003 Fan filter

NO LONGER SUPPLIED

Finger Guard

C5300-00022 Fan finger guard - Mounts on the back side of the fan and fan gasket

C5364-69006 New Part for C5300-00022

Gasket

C1676-40159 Fan mounting gasket - Holds the fan, fan filter, and spacer in place on the internal chassis

NO LONGER SUPPLIED

Panel

C5300-40020 Front panel (n-shaped plastic)

NO LONGER SUPPLIED

C5300-40022 Left side panel

NO LONGER SUPPLIED

C5300-40023 Right side panel

NO LONGER SUPPLIED

C5364-40316 Rear panel

NO LONGER SUPPLIED

Rod

C5300-40036 Actuator rod - Vertical rod with cam - Actuates power swith on power supply board

NO LONGER SUPPLIED

Spacer

C5300-40017 Fan spacer - Retains the fan filter and fan in the gasket

NO LONGER SUPPLIED

Tray

C5300-60007 Input/output paper tray assembly - Holds 150 sheets

NO LONGER SUPPLIED

Wing

C4531-40016 Left wing - Holds printed document after being ejected - Part of the input/output paper tray assembly

NO LONGER SUPPLIED

C4531-40017 Right wing - Holds printed document after being ejected - Part of the input/output paper tray assembly

C5364-60339 New Part for C4531-40017

Electronic Accessories

Cable (Interface)

5063-1256 IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 2.0m

(6.6ft) long

5063-1257 IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m

(9.8ft) long

OfficeJet Pro 1150Cse

HP Parts Reference Guide™

www.hp.com/go/hpparts

Electronic Accessories

Cable (Interface)

C2950A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 2.0m

(6.6ft) long

5063-1256 New Part for C2950A

C2951A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m

(9.8ft) long

C2990A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) (type A) to 36 pin (M) Centronics (type B) - 1.8m (6ft) long

NO LONGER SUPPLIED

C2991A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) (type A) to 36 pin (M) Centronics (type B) - 3.0m (10ft) long

NO LONGER SUPPLIED

C3801-80073 Centronics parallel interface cable - 25 pin (M) with thumbscrews to 36 pin Centronics (M) - 2m (6.6ft) long

C6680-80003 New Part for C3801-80073

OfficeJet Electronics

Cable

C5300-60010 Ribbon cable - 10 pin (F) edge connectors on each end - 60.2cm (23.7 inches) long

NO LONGER SUPPLIED

C5300-60012 Cable assembly - Has 9 pin (F) connectors - 6.1cm (2.4 inches) long

Control Panel

C5300-60009 Control panel assembly - Mounts to the front panel - Does NOT include the bezel or ribbon cable - Available for trade

sales in Europe - Available for authorized service centers only in USA NO LONGER SUPPLIED

OfficeJet

C5300-69107 Replacement OfficeJet pro 1150C (not available in Europe) - Does NOT include the control panel bezel

NO LONGER SUPPLIED

PC Board

C5300-69100 Main logic board

NO LONGER SUPPLIED

Power Cord

8120-1369 Power cord (Mint Gray) - 17 AWG, 2.0m (6.6ft) long - Has straight (F) receptacle (For 240V in Australia, New Zealand,

and China)

8120-1378 Power cord (Jade Gray) - 18 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (For 120V in USA, Canada, Latin

America, Korea, Taiwan, Thailand, Spain, Brazil, and Vietnam) 8120-6329 Power cord (Dove Gray) - 17 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (For 240V in South Africa and India) 8120-6330 Power cord (Dove Gray) - 2.3m (7.5ft) long - Has straight (F) receptacle (For 220V in Denmark) 8120-6331 Power cord (Dove Gray) - 2.3m (7.5ft) long - Has straight (F) receptacle (For 220V in Switzerland) 8120-6809 Power cord (Dove Gray) - 2.3m (7.5ft) long - Has straight (F) receptacle (For 240V operation in the United Kingdom,

Hong Kong, Singapore, Malaysia) 8120-6811 Power cord (Flint Gray) - 17 AWG, 2.3m (7.5ft) long - Has straight (F) receptacle (For 220V in Europe, Saudi Arabia,

South Africa, India, and Korea) 8120-6870 Power cord (Dove Gray) - 2.0m (6.6ft) long - Has straight (F) receptacle (For 220V in Argentina) 8120-6978 Power cord (Dove Gray) - 18 AWG, 2.0m (6.6ft) long - Has straight (F) receptacle (For 220V in Chile)

Power Supply

C5300-60001 Power supply PC board

NO LONGER SUPPLIED

Other Accessories

CD-ROM (Support)

C6659-10101 Service manual, technical support solutions guide and user's guide CD-ROM for print/scan/copy 370/380, OfficeJet

500/520/570/580/590/600/610/630/635/700/710/720/725, fax 910/920, OfficeJet Pro 1150/1170/1175, color copier

140/150

NO LONGER SUPPLIED

OfficeJet Pro 1150Cse

HP Parts Reference Guide™

www.hp.com/go/hpparts

Other Accessories

Cartridge

51641A Tri-color ink print cartridge - Prints approximately 360 pages based on 13.5% total density (4.5% for each color) on a 8

inch by 10 inch print area (for USA) 51641AA Tri-color ink print cartridge - Prints approximately 360 pages based on 13.5% total density (4.5% for each color) on a 8

inch by 10 inch print area (for Asia/Pacific) 51641AC Tri-color ink print cartridge - Prints approximately 360 pages based on 13.5% total density (4.5% for each color) on a 8

inch by 10 inch print area (for canada) 51641AE Tri-color ink print cartridge - Prints approximately 360 pages based on 13.5% total density (4.5% for each color) on a 8

inch by 10 inch print area (for europe) 51641AL Tri-color ink print cartridge - Prints approximately 360 pages based on 13.5% total density (4.5% for each color) on a 8

inch by 10 inch print area (for latin america) 51645A Black print cartridge (High capacity) - Prints approximately 840 pages based on 5% density on a 8 inch by 10 inch print

area (for USA) 51645AA Black print cartridge (High capacity) - Prints approximately 840 pages based on 5% density on a 8 inch by 10 inch print

area (for Asia/Pacific) 51645AC Black print cartridge (high capacity) - Prints approximately 840 pages based on 5% density on a 8 inch by 10 inch print

area (for Canada) 51645AE Black print cartridge (high capacity) - Prints approximately 840 pages based on 5% density on a 8 inch by 10 inch print

area (for Europe) 51645AL Black print cartridge (high capacity) - Prints approximately 840 pages based on 5% density on a 8 inch by 10 inch print

area (for Latin America) 51645G Black print cartridge (economy) - Prints approximately 415 pages based on 5% density on a 8 inch by 10 inch print area

(for USA) 51645GA Black print cartridge (economy) - Prints approximately 415 pages based on 5% density on a 8 inch by 10 inch print area

(for Asia/Pacific) 51645GC Black print cartridge (economy) - Prints approximately 415 pages based on 5% density on a 8 inch by 10 inch print area

(for Canada) 51645GE Black print cartridge (economy) - Prints approximately 415 pages based on 5% density on a 8 inch by 10 inch print area

(for Europe) 51645GL Black print cartridge (economy) - Prints approximately 415 pages based on 5% density on a 8 inch by 10 inch print area

(for Latin America) C6613AN Black print cartridges (High capacity) - (2 pack of 51645A) each prints approximately 840 pages based on 5% density on

a 8 inch (20.3cm) by 10 inch (25.4cm) print area (for USA)

NO LONGER SUPPLIED

Manual

C5300-90004 OfficeJet Pro 1150C user's guide (English)

NO LONGER SUPPLIED

Tape

0460-2555 Scanner ESD tape - 1/2 inch wide by 72 yards long - Adhesive backed polyester film - Used to cover the scanner

aperture after scanner bezel is removed - Keeps dust out of scanner

NO LONGER SUPPLIED

Paper and Other Media

Film (Transparency)

C3832A Premium InkJet transparency film - A4 size (21.0cm x 29.7cm) - 20 sheets per package C3835A Premium InkJet transparency film - A4 size (21.0cm x 29.7cm) - 50 sheets per package C6053A Premium InkJet rapid-dry tranparencies - A4 size (21.0cm x 29.7cm) - 50 sheets per package

NO LONGER SUPPLIED C3828A Premium InkJet transparency film - A size (8.5 x 11-inches) - 20 sheets per package C3834A Premium InkJet transparency film - A size (8.5 x 11-inches) - 50 sheets per package C6051A Premium InkJet rapid-dry tranparencies - A size (8.5 x 11-inches) - 50 sheets per package

NO LONGER SUPPLIED

OfficeJet Pro 1150Cse

HP Parts Reference Guide™

www.hp.com/go/hpparts

Paper and Other Media

Greeting Card Kit

C6587AN Printable Expressions all occasions card kit - Includes 20 greeting cards and envelopes, and a CD-ROM with 24 original

pieces of art

NO LONGER SUPPLIED

Iron-On Transfers

C6049A Iron-on T-shirt transfers - A size (8.5 x 11-inches) - 10 sheets per package

Paper (Glossy)

C3831A Premium glossy InkJet paper - A4 size (21.0cm x 29.7cm) - 10 sheets per package C3837A Premium glossy InkJet paper - A4 size (21.0cm x 29.7cm) - 50 sheets per package C3833A Premium glossy InkJet paper - A size (8.5 x 11-inches) - 10 sheets per package C3836A Premium glossy InkJet paper - A size (8.5 x 11-inches) - 50 sheets per package C6817A Professional glossy InkJet brochure and flyer paper - Glossy on both sides - A size (8.5 x 11-inches) - 50 sheets per box

Paper (InkJet)

51634Z InkJet non-glossy LX paper - A4 size (21.0cm x 29.7cm) - 200 sheets per package C1825A Bright white InkJet paper - A4 size (21.0cm x 29.7cm) - 500 sheets per package C1853A Premium InkJet heavyweight paper - A4 size (21.0cm x 29.7cm) - Coated on both sides - 100 sheets per package C5977A Bright white InkJet paper - A4 size (21.0cm x 29.7cm) - 200 sheets per package C5977B Bright white InkJet paper - A4 size (21.0cm x 29.7cm) - 250 sheets per package 51634Y InkJet non-glossy LX paper - A size (8.5 x 11-inches) - 200 sheets per package C1824A Bright white InkJet paper - A size (8.5 x 11-inches) - 500 sheets per package C5973A Premium glossy paper - A size (8.5 x 11-inches) - 25 sheets per package

NO LONGER SUPPLIED C5976A Bright white InkJet paper - A size (8.5 x 11-inches) - 200 sheets per package C5976B Bright white InkJet paper - A size (8.5 x 11-inches) - 250 sheets per package

Paper (Matte)

C6955A Professional and flyer paper (Matte) - A size (8.5 x 11-inches) - 50 sheets

Paper (Photo)

C6040A Premium glossy photo paper - A4 size (21.0cm x 29.7cm) - 15 sheets per package (Europe, Brazil, and Argentina) C6043A Premium glossy photo paper - A4 size (21.0cm x 29.7cm) - 15 sheets per package (Japan) C6039A Premium glossy photo paper (Fast dry time) - A size (8.5 x 11-inches) - 15 sheets per package

Stickers

C6822A Round re-stickable InkJet stickers - HP bright white 6.35cm (2.5in) round stickers with 3M 'Post-it' adhesive - A size (8.5

x 11-inches) - 10 sheets per package with nine stickers per sheet C6823A Square re-stickable InkJet stickers - HP bright white 6.35cm (2.5in) square stickers with 3M 'Post-it' adhesive - A size

(8.5 x 11-inches) - 10 sheets per package with nine stickers per sheet

Print Mech Assembly Parts

Belt

C2145-40058 Drive belt - For the print mechanism carriage assembly

NO LONGER SUPPLIED

Cable

C2145-60032 Carriage assembly flex cable - Overall length is 46.7cm (18.4 inches)

NO LONGER SUPPLIED

Clamp

C2145-40047 Flex cable clamp

NO LONGER SUPPLIED
