Hotpoint-ariston 7OFK 898ES CX User Manual [ru]

7OFK 897EJ X RU/HA 7OFKQ 897EC RU/HA 7OFK 898E CX RU/HA 7OFK 898ES CX RU/HA

English

Operating Instructions

OVEN

Contents

Operating Instructions,1 Warnings,2 Assistance,3 Description of the appliance,4 Description of the appliance,5 Installation,6 Start-up and use,8 Modes,9 Precautions and tips,12 Maintenance and care,12 Troubleshooting,14

Русскии

Руководство по эксплуатации

ДУХОВОЙ ШКАФ

Содержание

Руководство по эксплуатации,1 Предупреждения,2 Сервисное обслуживание,3 Описание изделия,4 Описание изделия,5 Установка,15 Включение и эксплуатация,17 Программы,18 Предосторожности и рекомендации,22 Техническое обслуживание и уход,22 Неисправности и методы их устранения,24

Warnings

Предупреждения

WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.

Never use steam cleaners or pressure cleaners on the appliance.

WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock.

! When you place the rack inside, make sure that the stop is directed upwards and in the back of the cavity.

ВНИМАНИЕ: Данное изделие и его доступные комплектующие сильно нагреваются в процессе эксплуатации. Будьте осторожны и не касайтесь нагревательных элементов. Не разрешайте детям младше 8 лет приближаться к изделию без контроля. Данное изделие может быть использовано детьми старше 8 лет и лицами с ограниченными физическими, сенсорными или умственными способностями или без опыта и знания о правилах использования изделия при условии надлежащего контроля или обучения безопасному использованию изделия с учетом соответствующих рисков. Не разрешайте детям играть с изделием. Не разрешайте детям осуществлять чистку и уход за изделием без контроля взрослых.

Не используйте абразивные вещества или режущие металлические скребки для чистки стеклянной дверцы духового шкафа, так как они могут поцарапать поверхность, что может привести к разбиванию стекла.

Никогда не используйте паровые чистящие агрегаты или агрегаты под высоким давлением для чистки изделия.

ВНИМАНИЕ: Проверьте, чтобы изделие было выключено, перед заменой лампочки во избежание возможных ударов током.

! При установке решетки проверить, чтобы фиксатор был повернут вверх с задней стороны выемки.

Assistance

Warning:

The appliance is tted with an automatic diagnostic system which detects any

malfunctions. Malfunctions are signalled through messages of the following type: “F—” followed by numbers. Call for technical assistance in the event of a malfunction.

Before calling for Assistance:

• Check whether you can x the problem yourself.

• Restart the programme to check whether the malfunction has disappeared.

• If it has not, contact the Authorised Technical Assistance Service.

! Never use the services of an unauthorised technician.

Сервисное обслуживание

Внимание: Изделие оснащено системой автоматической диагностики, позволяющей выявить возможные неисправности. Неисправности показываются на дисплее посредством следующих сообщений: “F—” с последующими цифрами. В этом случае необходимо вызвать техника из центра сервисного обслуживания.

Перед тем как обратиться в Центр Технического обслуживания:

• Проверьте, можно ли устранить неисправность самостоятельно;

• Вновь запустите программу для проверки исправности машины;

• В противном случае обратитесь в уполномоченный Центр Технического обслуживания.

Please have the following information to hand:

• The type of problem encountered.

• The message shown on the TEMPERATURE display.

• The appliance model (Mod.).

• The serial number (S/N). The latter two pieces of information can be found on the data plate located on the appliance.

! Никогда не обращайтесь к неуполномоченным техникам.

При обращении в Центр Технического Обслуживания необходимо сообщить:

• Тип неисправности;

• сообщение, показываемое на дисплее ТЕМПЕРАТУРЫ

• Модель изделия (Мод.)

• Номер тех. паспорта (серийный №)

Эти данные вы найдете на паспортной табличке, расположенной на изделии.

Description of the appliance

12345

Описание изделия

Overall view

1 POSITION 1 2 POSITION 2 3 POSITION 3 4 POSITION 4 5 POSITION 5 6 GUIDES for the sliding racks 7 DRIPPING PAN 8 GRILL 9 Control panel

Общии вид

1 ПОЛОЖЕНИЕ 1 2 ПОЛОЖЕНИЕ 2 3 ПОЛОЖЕНИЕ 3 4 ПОЛОЖЕНИЕ 4 5 ПОЛОЖЕНИЕ 5 6 ВЫДВИЖНЫЕ НАПРАВЛЯЮЩИЕ уровней 7 ПРОТИВЕНЬ 8 РЕШЕТКА 9 Панель управления

9 6

Description of the appliance

141516

171213

Описание изделия

Control panel

1 SELECTOR knob 2 CONTROL PANEL POWER BUTTON 3 DISPLAY 4 THERMOSTAT / TIMER knob 5 START / STOP 6 MINUTE MINDER icon 7 TIMER icon 8 CONTROL PANEL LOCK icon 9 LIGHT icon

Display

10 TEMPERATURE and TIME numerical digits 11 DURATION icon 12 END OF COOKING icon 13 CLOCK icon 14 MINUTE MINDER icon 15 CONTROL PANEL LOCK indicator 16 Preheating /Residual heat indicator 17 MODE icons

Панель управления

1 Рукоятка ПРОГРАММЫ 2 ВКЛЮЧЕНИЕ КОНСОЛИ УПРАВЛЕНИЯ 3 ДИСПЛЕЙ 4 Рукоятка ТЕРМОСТАТА / НАСТРОЙКИ ПРОДОЛЖИТЕЛЬНОСТИ 5 ПУСК / ОСТАНОВКА

6 Символ ТАЙМЕР 7 Символ НАСТРОЙКА ВРЕМЕНИ 8 Символ БЛОКИРОВКА ДВЕРЦЫ / УПРАВЛЕНИЙ 9 Символ ОСВЕЩЕНИЕ

Дисплей

10 Цифровые значения ТЕМПЕРАТУРЫ и ВРЕМЕНИ 11 Символ ПРОДОЛЖИТЕЛЬНОСТЬ 12 Символ КОНЕЦ ПРИГОТОВЛЕНИЯ 13 Символ ЧАСЫ 14 Символ ТАЙМЕР 15 Индикатор БЛОКИРОВКИ КОНСОЛИ УПРАВЛЕНИЯ

16 Индикатор Нагрева / Остаточного тепла 17 Символы ПРОГРАММ

Installation

590 mm.

! Please keep this instruction booklet in a safe place for future reference. If the appliance is sold, given away or moved, please make sure the booklet is

also passed on to the new owners so that they may benet from the advice

contained within it.

! Please read this instruction manual carefully: it contains important information concerning the safe operation, installation and maintenance of the appliance.

Positioning

! Do not let children play with the packaging material; it should be disposed

of in accordance with local separated waste collection standards (see Precautions and tips).

! The appliance must be installed by a qualied professional in accordance

with the instructions provided. Incorrect installation may damage property or cause harm to people or animals.

Centring and xing

Secure the appliance to the cabinet:

• Open the oven door.

• Remove the 2 rubber plugs covering the xing holes on the perimeter

frame.

• Fix the oven to the cabinet using the 2 wood screws.

• Replace the rubber plugs.

Built-in appliances

Use an appropriate cabinet to ensure that the appliance operates properly:

! All parts which ensure the safe operation of the appliance must not be removable without the aid of a tool.

• The panels adjacent to the oven must be made of heat-resistant material.

• Cabinets with a veneer exterior must be assembled with glues which can withstand temperatures of up to 100°C.

• To install the oven under the counter (see diagram) or in a kitchen unit, the cabinet must have the following dimensions:

Electrical connection

Ovens equipped with a three-pole power supply cable are designed to operate with alternating current at the voltage and frequency indicated on the data plate located on the appliance (see below).

Fitting the power supply cable

550 mm.

min.

45 mm.

560 mm.

575-585 mm.

570 mm.

595 mm.

20 mm.

550 mm.

20,5 mm.

22,5 mm.*

! The appliance must not come into contact with electrical parts once it has been installed. The indications for consumption given on the data plate have been calculated for this type of installation.

Ventilation

To ensure adequate ventilation, the back panel of the cabinet must be removed. It is advisable to install the oven so that it rests on two strips of

wood, or on a completely at surface with an opening of at least 45 x 560

mm (see diagrams).

Connecting the supply cable to the mains

Install a standardised plug corresponding to the load indicated on the data plate (see table).

45 mm.

560 mm.

The appliance must be directly connected to the mains using an omnipolar switch with a minimum contact opening of 3 mm installed between the appliance and the mains. The switch must be suitable for the charge indicated and must comply with current electrical regulations (the earthing wire must not be interrupted by the switch). The supply cable must be positioned so that it does not come into contact with temperatures higher than 50°C at any point (the back panel of the oven, for example).

1. Open the terminal board by inserting a screwdriver into the side tabs of the cover. Use the screwdriver as a lever by pushing it down to open the cover (see diagram).

2. Install the power supply cable by loosening the cable clamp screw and the three wire contact screws

L-N- . Connect the wires to the corresponding terminals: the Blue wire to the terminal marked (N), the Brown wire to the terminal marked (L) and the Yellow/Green wire to the

terminal marked (see diagram).

3. Secure the cable by fastening the clamp screw.

4. Close the cover of the terminal board.

! The installer must ensure that the correct electrical connection has been performed and that it is fully compliant with safety regulations.

Before connecting the appliance to the power supply, make sure that

• The appliance is earthed and the plug is compliant with the law.

• The socket can withstand the maximum power of the appliance, which is indicated on the data plate.

• The voltage is in the range between the values indicated on the data plate.

• The socket is compatible with the plug of the appliance. If the socket is incompatible with the plug, ask an authorised technician to replace it. Do not use extension cords or multiple sockets.

! Once the appliance has been installed, the power supply cable and the electrical socket must be easily accessible.

! The cable must not be bent or compressed.

! The cable must be checked regularly and replaced by authorised technicians

only (see Assistance).

! The manufacturer declines any liability should these safety measures not be observed.

APPLIANCE SPECIFICATIONS

width 43.5 cm

Dimensions*

Volume*

Dimensions**

Volume**

Electrical connections

ENERGY LABEL

Without removable guide rails

* Only for models with drawn rails. ** Only for models with wire rails.

height 32,4 cm depth 41.5 cm

59 l

width 45.5 cm height 32,4 cm depth 41.5 cm

62 l

voltage: 220 - 240 V~ 50/60 Hz or 50 Hz (see data plate) maximum power absorbed 2800 W

Directive 2002/40/EC on the label of electric ovens. Standard EN 50304

Declared energy consumption for Forced convection Class – heating mode: ECO.

This appliance conforms to the following European Economic Community directives:

- 2006/95/EEC dated 12/12/06 (Low Voltage) and subsequent amendments

- 2004/108/EEC dated 03/05/89 (Electromagnetic Compatibility) and subsequent amendments

- 93/68/EEC dated 22/07/93 and subsequent amendments.

- 2012/19/EEC and subsequent amendments. 1275/2008 standby/off mode.

Start-up and use

WARNING! The oven is provided with a stop system to extract the racks and prevent them from coming out of the oven (1). As shown in the drawing, to extract them completely, simply lift the racks, holding them on the front part, and pull (2).

Setting the minute minder

! The minute minder may still be set whether the oven is switched on or off. It does not switch the oven on or off.

When the set time has elapsed, the timer emits a buzzer that will automatically stop after 30 seconds or when any active button on the control panel is pressed. To adjust the timer proceed as follows:

1. Press the icon.

2. Adjust the time as desired by turning the TIMER knob towards and .

! The rst time you use your appliance, heat the empty oven with its door closed

at its maximum temperature for at least half an hour. Make sure that the room is well ventilated before switching the oven off and opening the oven door. The appliance may emit a slightly unpleasant odour caused by protective substances used during the manufacturing process burning away.

! To make the setting process easier, keep the knob in position: this will increase the scrolling speed of the numbers on the display.

! Each setting will automatically be stored in the appliance memory after 10 seconds.

! The touch controls cannot be activated if the user is wearing gloves.

Some models are equipped with a system of hinges which allows the door to close slowly, without the user having to follow the movement through with his/ her hand. To use the system correctly, before closing the door:

• Open the door fully.

• Do not force the closing movement manually.

! In order to optimise the cooking performance, when starting the selected function, product settings will be applied that could cause a delayed start of the fan and heating elements.

Control panel lock

! The control panel can be locked while the oven is off, once cooking has

started or nished and during programming.

To lock the oven controls, press and hold the icon for at least 2 seconds. A buzzer sounds and the display shows the key symbol “n—O”. The icon, when lit, indicate lock function activation. To deactivate the lock, press and hold the icon again for at least 2 seconds.

Setting the clock

! The clock can only be set when the oven is switched off. If the oven is

in standby mode, pressing the icon once will display the current time setting. Press it again to set the time.

3. Once you have reached the desired value, press the icon again.

The lit symbol will remind you that the minute minder is on. The DISPLAY will show the countdown.

To cancel the minute minder, press the icon and use the knob to set the time to 00:00. Press button again.

The icon will switch off to indicate that the minute minder has been disabled.

Starting the oven

1. Switch the control panel on by pressing the icon. The appliance buzzer sounds three times (ascending) and all buttons light up in sequence.

2. Select the desired cooking mode by turning the SELECTOR knob. The display shows:

- the temperature associated with the mode, if programming manually;

- “Auto” and the duration alternately, if programming is automatic.

3. Press the icon to begin cooking.

4. The oven will begin its preheating phase, the preheating indicators will light up as the temperature rises.

5. When the preheating process has nished, a buzzer sounds and all the

preheating indicator lights show that this stage has been completed: the food can then be placed in the oven.

6. During cooking it is always possible to:

- modify the temperature by turning the THERMOSTAT knob (manual

modes only);

- set the duration of a cooking mode (see Cooking Modes);

- press the icon to stop cooking. In this case the appliance stores the

temperature modied previously in its memory (manual modes only);

- switch off the oven by pressing the icon for 3 seconds.

7. If a blackout occurs while the oven is already in operation, an automatic

system within the appliance will reactivate the cooking mode from the point at which it was interrupted, provided that the temperature has not dropped below a certain level. Programmed cooking modes which have not yet started will not be restored and must be reprogrammed (for example: a cooking mode has been programmed to start at 20:30. At 19:30 a blackout occurs. When the power supply is restored, the mode will have to be reprogrammed).

After connection to the power supply network or after a blackout, the

icon and the digits on the display will ash for 10 seconds.

To set the clock:

1. Press the icon.

2. Turn the TIMER knob towards and to adjust the hour value.

3. Once you have reached the correct hour value, press the icon.

4. Repeat the above process to set the minutes.

If a blackout occurs, it will be necessary to reset the clock. If the icon

ashes on the display, this indicates that the clock has not been set correctly.

! The oven will begin its preheating phase after 2 seconds from selecting the desired cycle.

! There is no preheating stage for the GRILL mode.

! Never put objects directly on the bottom of the oven; this will prevent the

enamel coating from being damaged.

! Always place cookware on the rack(s) provided.

! The oven will begin its preheating phase after 2 seconds from selecting

the desired cycle.
