TMX
Einbau-Anleitung • Installation instructions • Instructions de montage
Istruzioni per il montaggio • Instrucciones de instalación
n
TS = max. 140 °C (gas charge - MOP)
PS = max. 29 bar
P
= max. 32 bar
test
∆t
oh, stat
p
max. 70 °C (liquid charge - F)
TS = max. 100 °C
≈ 3.5 K
EN 378 !
o
a
b
a) R22, R23, R124, R134a, R227,
R236fa, R401A, R402A, R404A,
R407C, R410A, R507, R508B, ISC89
b) t
c) 4.5 - 10 =>
d) MOP: Gas Charge
/ t
0, max
0, min
F: Liquid Charge
d
c
EB-TMX-01 MU1H-1904GE23 R0106
q
TMX
P
0 → t0
6 mm, 1/4"
t
0h
∆t0h = t0h - t
∆t0h ≠ ok => w
r
0
s
s
a.)
b.)
2 Subject to change without notice • MU1H-1904GE23 R0106
t
j
a.) b.) c.)
d.) e.) f.)
OPEN
g.)
ZE-00020
h.) i.)
20 Nm
20 Nm
20 Nm
20 Nm
.) k.) l.)
2 x 360°
TMV-9-0004,
ZE-00017
Subject to change without notice • MU1H-1904GE23 R0106 3
0.2 Nm
CLOSE
25 Nm
u
R
max. 3 x
R
L
v
L
max. 3 x
L = min. 2 cm
R = min. 2 cm
≈ 0 °
<22 mm
<7/8"
≈ 120 °
>22 mm
>7/8"
4 Subject to change without notice • MU1H-1904GE23 R0106
w
∆t0h ≠ ok
a.) b.)
c.) d.)
∆t
↑
0h
∆t0h ↓
360° ≈ 0.3 bar
e.) f.)
TMV-9-0004,
ZE-00017
25 Nm
Subject to change without notice • MU1H-1904GE23 R0106 5
∆t0h ↑ => MOP ↓
↓ => MOP ↑
∆t
0h
∆t0h > 0
Q0 [kW]
R22 R23 R124 R134a R227
R236fa
R401A R404A R407C R410A R507 R508B ISC89
4.5 16.3 18.6 9.4 11.1 6.6 6.0 13.0 12.3 16.3 20.5 12.3 12.2 5.6
4.75
21.5 24.5 12.4 15.0 8.7 8.0 17.1 16.2 21.5 27.0 16.2 16.1 7.4
5 27.9 31.9 16.1 18.8 11.3 10.3 22.2 21.0 27.9 35.1 21.0 20.9 9.6
6 40.7 46.5 23.5 26.0 16.4 15.1 32.4 30.6 40.7 51.2 30.6 30.5 14.0
7 52.3 59.7 30.2 33.3 21.1 19.4 41.6 39.3 52.3 65.8 39.3 39.2 18.0
8 61.6 70.4 35.6 40.8 24.9 22.8 49.0 46.3 61.6 77.5 46.3 46.2 21.2
10 72.1 82.3 41.7 48.0 29.1 26.7 57.3 54.2 72.1 90.7 54.2 54.1 24.8
t0-10 °C -70 °C +10 °C -10 °C +10 °C +10 °C -10 °C -10 °C -10 °C -10 °C -10 °C -70 °C -40 °C
+25 °C -30 °C +50 °C +25 °C +50 °C +50 °C +25 °C +25 °C +25 °C +25 °C +25 °C -30 °C +25 °C
t
c
∆t
1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K 1 K
c2u
Automation and Control Solutions
Honeywell GmbH
Hardhofweg • 74821 Mosbach / Germany
Phone: +49 (0) 62 61 / 81-475
Manufactured for and on behalf of the
Environment and Combustion Controls
Division of Honeywell Technologies Sàrl,
Ecublens, Route du Bois 37, Switzerland
by its autorised representative Honeywell GmbH
Fax: +49 (0) 62 61 / 81-461
E-Mail: Cooling.Mosbach@honeywell.com
www.honeywell-cooling.com
6 Subject to change without notice • MU1H-1904GE23 R0106
