Honeywell Silent knight 5895XL Installation And Operation Manual

5895XL

Intelligent Power Module

Installation and Operation Guide

Document 151142-L8 Rev: L
08/09/2017 ECN: 17-0387

Fire Alarm & Emergency Communication System Limitations

While a life safety system may lower insurance rates, it is not a substitute for life and property
insurance!

An automatic fire alarm system—typically made up of smoke
detectors, heat detectors, manual pull sta tions, audible warni ng
devices, and a fire alarm control pane l (FACP) with remote noti­fication capability—can provide early warning of a developing
fire. Such a system, however, does not assure protection
against property damage or loss of life resulting from a fire.

An emergency communication system—typically made up of
an automatic fire alarm system (as described above) and a life
safety communication system that may include an autonomous
control unit (ACU), local operating console (LOC), voice com­munication, and other various inter-operable communication
methods—can broadcast a mass notification message. Such a
system, however, does not assure protection against property
damage or loss of life resulting from a fire or life safety event.

The Manufacturer recommends that smoke and/or heat
detectors be located throughout a protected premi ses fol lowing
the recommendations of the current edition of t he National Fire
Protection Association Standard 72 (NFPA 72), manufacturer's
recommendations, State and local codes, and the
recommendations contained in the Guide for Proper Use of
System Smoke Detectors, which is made available at no charge
to all installing dealers. Thi s document can be found at http://
www.systemsensor.com/appguides/. A study by the Federal
Emergency Management Agency (an agency of the United
States government) indicated that smoke detectors may not go
off in as many as 35% of all fires. While fire alarm systems are
designed to provide early warning against fire, they do not
guarantee warning or protection against fire. A fire alarm
system may not provide timely or adequate warning, or simply
may not function, for a variety of reasons:

Smoke detectors may not sense fire where smoke cannot
reach the detectors such as in chimneys, in or behind walls, on
roofs, or on the other side of closed doors. Smoke detectors
also may not sense a fire on another level or floor of a buil din g.
A second-fl oor detector , fo r example, may not sens e a first-floor
or basement fire.

Particles of combustion or “smoke” from a developing fire
may not reach the sensing chambers of smoke detectors
because:

• Barriers such as closed or partially closed doors, walls,
chimneys, even wet or humid areas may inhibit particle or
smoke flow.

• Smoke particles may become “cold,” stratify, and not reach
the ceiling or upper walls where detectors are located.

• Smoke particles may be blown away from detectors by air
outlets, such as air conditioning vents.

• Smoke particles may be drawn into air returns before reach­ing the detector.

The amount of “smoke” present may be insufficient to alarm
smoke detectors. Smoke detectors are designed to alarm at
various levels of smoke density. If such density levels are not
created by a developing fire at the location of detectors, the
detectors will not go into alarm.

Smoke detectors, even when working properly, have sensing
limitations. Detectors that have photoele ctronic sensing cham­bers tend to detect smoldering fires better than flaming fires,
which have little visible smoke. Detectors that have ionizing­type sensing chambers tend to detect fast-flaming fires better
than smoldering fires. Because fires develop in different ways
and are often unpredictable in their growth, neither type of
detector is necessarily best and a given type of detector may
not provide adequate warning of a fire.

Smoke detectors cannot be expected to provide adequate
warning of fires caused by arson, children playing with matches
(especially in bedrooms), smoking in bed, and violent explo-

sions (caused by escaping gas, improper storage of flammable
materials, etc.).

Heat detectors do not sense particles of combustion and alar m
only when heat on their sensors increases at a predetermined
rate or reaches a predetermined level. Rate-of-rise heat detec­tors may be subject to reduced sensitivity over time. For this
reason, the rate-of-rise feature of each detector should be
tested at least once per year by a qualified fire protection spe­cialist. Heat detectors are designed to protect property, not life.

IMPORTANT! Smoke detectors must be install ed in the same
room as the control panel and in rooms used by the system for
the connection of alarm transmission wiring, communications,
signaling, and/or power . If det ectors are not so locat ed, a devel­oping fire may damage the alarm system, compromising its
ability to report a fire.

Audible warning devices such as bells, horns, strobes,
speakers and displays may not alert people if these devices

are located on the other side of closed or partly open doors or
are located on another floor of a building. Any warning device
may fail to alert people with a disability or those who have
recently consumed drugs, alcohol, or medication. Please note
that:

• An emergency communication system may take priority ove r
a fire alarm system in the event of a life safety emergency.

• Voice messaging systems must be designed to meet intelli­gibility requirements as defined by NFPA, local codes, and
Authorities Having Jurisdiction (AHJ).

• Language and instructional requirements must be clearly
disseminated on any local displays.

• Strobes can, under certain circumstances, cause seizures in
people with conditions such as epilepsy.

• Studies have shown that certain people, even when they
hear a fire alarm signal, do not respond to or comprehend
the meaning of the signal. Audible devices, such as horns
and bells, can have different tonal patt erns and frequenci es.
It is the property owner's responsibility to conduct fire drills
and other training exercises to make people aware of fire
alarm signals and instruct them on the proper reaction to
alarm signals.

• In rare instances, the sounding of a warning device can
cause temporary or permanent hearing loss.

A life safety system will not operate without any electrical
power. If AC power fails, the system will operate from standby
batteries only for a specified time and only if the batteries have
been properly maintained and replaced regularly.

Equipment used in the system may not be technically com­patible with the control panel. It is essential to use only equip­ment listed for service with your control panel.

Te lepho ne line s

needed to transmit alarm signals from a prem­ises to a central monitoring station may be out of service or
temporarily disabled. For added protection against telephone
line failure, backup radio transmission systems are recom­mended.

The most common cause of life safety system malfunction is
inadequate maintenance. To keep the entire life safety system
in excellent working order , ongoi ng maintenance is re quired per
the manufacturer's recommendations, and UL and NFPA stan­dards. At a minimum, the requirements of NFPA 72 shall be fol­lowed. Environments with large amounts of dust, dirt, or high air
velocity require more frequent maintenance. A maintenance
agreement should be arranged through the local manufac­turer's representative. Maintenance should be scheduled
monthly or as required by National and/or local fire codes and
should be performed by authorized professional life safety sys­tem installers only. Adequate written records of all inspections

2

Installation Precautions

Adherence to the following will aid in problem-free installation with long-term reliability:

WARNING - Several different sources of power can be
connected to the fire alarm control panel. Disconnect all

sources of power before servicing. Control unit and associated
equipment may be damaged by removing and/or inserting
cards, modules, or interconnecting cables while the unit is
energized. Do not attempt to install, service, or operat e this
unit until manuals are read and understood.

CAUTION - System Re-acceptance Test after Software
Changes: To ensure proper system operation, this product

must be tested in accordance with NFPA 72 after any pro­gramming operation or change in site-specific software. Re­acceptance testing is required after any change, addition or
deletion of system components, or after any modification,
repair or adjustment to system hardware or wiring. All compo­nents, circuits, system operations, or software functions
known to be affected by a change must be 100% tested. In
addition, to ensure that other operations are not inadvertently
affected, at least 10% of initiating devices that are not directly
affected by the change, up to a maximum of 50 devices, must
also be tested and proper system operation verified.

This system meets NFP A requirements for operation at 0-49º
C/32-120º F and at a relative humidity. However, the useful
life of the system's standby batteries and the electronic com­ponents may be adversely affected by extreme temperature
ranges and humidity. Therefore, it is recommended that this
system and its peripherals be installed in an environment with
a normal room temperature of 15-27º C/60-80º F.

Verify that wire sizes are adequate for all initia ting and indi­cating device loops. Most devices cannot tol erate more than a
10% I.R. drop from the specified device voltage.

Like all solid state electronic devices, this system may
operate erratically or can be damaged when subjected to light­ning induced transients. Although no system is completely
immune from lightning transients and interference, proper
grounding will reduce susceptibility. Overhead or outside
aerial wiring is not recommended, due to an increased sus­ceptibility to nearby lightning strikes. Consult with the Techni­cal Services Department if any problems are anticipated or
encountered.

Disconnect AC power and batteries prior to removing or
inserting circuit boards. Failure to do so can damage circui ts.

Remove all electronic assemblies prior to any drilling, filing,
reaming, or punching of the enclosure. When possible, make
all cable entries from the sides or rear. Before making modifi­cations, verify that they will not interfere with battery, trans­former, or print ed circuit board location.

Do not tighten screw terminals more than 9 in-lbs. Over­tightening may damage threads, resulting in reduced terminal
contact pressure and difficulty with screw terminal removal.

This system contains static-sensitive components.
Always ground yourself with a proper wrist strap before han-

dling any circuits so that static charges are removed from the
body. Use static suppressive packaging to protect electronic
assemblies removed from the unit.

Follow the instructions in the installation, operating, and
programming manuals. These instructions must be followed to
avoid damage to the control panel and associated equipment .
FACP operation and reliability depend upon proper installa­tion.

Precau-D1-9-2005

3

Documentation Feedback

Your feedback helps us keep our documentation up-to-date and accurate. If you have a question or encounter a problem not covered
in this manual, contact Silent Knight Technical Support at 800-446-6444.

Please give the following information:

• Product name and version number (if applicable)

• Printed manual

• Topic Title

• Page number (for printed manual)

• Brief description of content you think should be improved or corrected

• Your suggestion for how to correct/improve documentation

To order parts, contact Silent Knight Sales at 800-328-0103.

4 5895XL Manual - P/N 151142-L8:L 08/09/2017

Content

............................................................................................................................................................................................. 1

1.1: Maximum Number of SBUS Modules ..............................................................................................................................................................2

1.2: Agency Requirements........................................................................................................................................................................................4

2.1: Inventory............................................................................................................................................................................................................6

2.2: Environmental Specifications............................................................................................................................................................................6

2.3: Software Downloads..........................................................................................................................................................................................6

2.4: 5895XL Board and Terminal Strip Description.................................................................................................................................................7

2.5: Earth Fault Resistance .......................................................................................................................................................................................8

2.6: Calculating Current Draw and Standby Battery ................................................................................................................................................9

2.6.1: Worksheet Requirements........................................................................................................................................................................9

Maximum Battery Standby Load..............................................................................................................................................................9

2.6.2: Current Draw Worksheet.......... ... ...........................................................................................................................................................9

2.6.3: Current Draw Worksheet for SD SLC Devices....................................................................................................................................12

2.7: Wiring Specifications.......................................................................................................................................................................................15

2.7.1: Length Limitations....... ...................................................... .......................... .........................................................................................15

2.7.2: Calculating Wiring distance for SBUS modules ................................... ............................. ..................................................................15

2.7.3: Wire Routing ......................................................... ...............................................................................................................................17

3.1: AC Power.........................................................................................................................................................................................................18

3.2: Battery Connection..........................................................................................................................................................................................18

3.3: Connecting the 5895XL to the FACP..............................................................................................................................................................19

3.3.1: Setting the Device ID............................................................................................................................................................................21

3.4: Connecting SBUS Modules to the 5895XL.....................................................................................................................................................21

3.5: Flexputs™ I/O Circuits....................................................................................................................................................................................22

3.5.1: Conventional Notification Appliance...................................................................................................................................................22

3.5.2: Releasing Operations................................ ............................................................................................................................................23

Class B Notification Wiring ...................................................................................................................................................................23

Class A Notification Wiring ..... ........................... ........................... .......................... ...............

3.5.3: Conventional Initiation Circuits ...........................................................................................................................................................24

Class B Inputs........................................................................................................................................................................................24

Class A Inputs.........................................................................................................................................................................................24

3.5.4: Installing 2-Wire Smoke Detectors ........................................................................... ...........................................................................25

3.5.5: Installing 4-Wire Smoke Detectors ........................................................................... ...........................................................................26

3.5.6: Auxiliary Power Configuration ............................................................................................................................................................27

Door Holder Power.................................................................................................................................................................................27

Constant Power...................................................... ........................... ........................... ...........................................................................27

Resettable Power.....................................................................................................................................................................................27

Sounder Sync Power...............................................................................................................................................................................27

3.6: Conventional Relay Installation ......................................................................................................................................................................28

A.7: Notification Appliances ..................................................................................................................................................................................30

A.8: Two-Wire Smoke Detectors............................................................................................................................................................................38

A.9: Four-Wire Smoke Detectors/Devices (UL Listed)..........................................................................................................................................40

A.10: Door Holders (UL Listed).............................................................................................................................................................................42

A.11: Relays (UL Listed)................................. ........................... .......................... ..................................................................................................42

A.12: Compatible 520Hz Signaling Speakers ........................................................................................................................................................43

A.13: Compatible 520Hz Low Frequency Bases....................................................................................................................................................43

Honeywell Fire Product Warranty and Return Policy
Manufacturer Warranties and Limitation of Liability

...............................................................23

5895XL Manual - P/N 151142-L8:L 08/09/2017 1

Overview Maximum Number of SBUS Modules

Section 1: Overview

The Model 5895XL Intelligent Power Module provides additional power and circuits to the 5700, 6700, 5808, 6808, 5820XL, 5820XL­EVS, 6820, or 6820EVS FACPs. The 5895XL can power all compatible modules, including SLC devices (via a Model 5815XL or 6815
SLC Expander), remote annunciators (Model 6860, 6855 & 5860); notification appliances, auxiliary power modules, and all other com­patible modules.

NOTE: The 5700, 6700, 5808 and 6808 do not use the 5815XL or 6815 SLC expanders.

The 5895XL has six Flexputs™ and two programmable relays. Outputs are rated 3.0 A (6.0 A total for each 5895XL). Relays are Form
C rated at 2.5 A @ 24 VDC. Outputs and relays are fully programmable.

The 5895XL is optically isolated, providing ground loop isolation and transient protection. It functions as an SBUS repeater which con­ditions the RS-485 signal and allows the module to drive up to 6,000 feet of additional SBUS wiring.

The 5895XL is housed in a metal cabinet that is identical in size to the 5820XL FACP cabinet. This cabinet is large enough to house two
17 AH batteries. Like the 5820XL or 6820 cabinets, the 5895XL cabinet provides mounting studs for two SLC Expander modules.

The 5895XL communicates to the main FACP via the SBUS. Each 5895XL provides an additional 6,000 feet of SBUS wiring length to
the main panel. As the drawings on the next pages illustrate, this allows you to distribu te modules, SLC devices, and outpu ts throughout
an extremely large facility.

As well as expanding the wiring length capabilities, the 5895XL also expands power capabilities by an additional 6.0 A of current.

1.1 Maximum Number of SBUS Modules

The chart below shows the maximum number of compatible modules that can be used in the FA CP installation. Modules can be distrib­uted among the main panel SBUS and each additional 5895XL SBUS in virtually any combination.

Module or Device Maximum Number

5895XL Intelligent Power Module

5860/6855 Remote Annunciator

6860 Remote Annunciator 16 per 6820/EVS installation
5815XL SLC Expander
6815 SLC Expander 63 per 6820/EVS installation
5824 Serial/Parallel Modules
Outputs 6 per 5820XL, 6820/EVS or 5895XL

Conventional Relays 2 per 5820XL, 6820/EVS or 5895XL

8 per 5700, 6700, 5808, 6808, or 5820XL/ECS installation
16 per 6820/6820EVS installation
8 per 6700 installation
12 per 6808 or 5820XL/EVS installation
16 per 6820/EVS installation

3 per 5820XL/EVS installation
63 per 6820/EVS installation

2 per 5700, 5808, 5820XL/EVS installation
4 per 6700, 6808, 6820/EVS installation

2 5895XL Manual - P/N 151142-L8:L 08/09/2017

Maximum Number of SBUS Modules Overview

Figure 1.1 Example 5895XL Installation Overview

5895XL Manual - P/N 151142-L8:L 08/09/2017 3

Overview Agency Requirements

Figure 1.2 Example 5895XL Installation Overview (Details Added)

1.2 Agency Requirements

The 5895XL has the same requirements as the main control panel. These requirements are listed in the FACP Installation Manual.

Model Number FACP Installation Manual

5820XL/EVS LS10061-001SK-E
6820/EVS LS10144-001SK-E
5700 151295
6700 LS10148-001SK-E
5808 151274-L8
6808 LS10146-001SK-E

4 5895XL Manual - P/N 151142-L8:L 08/09/2017

Before You Begin Installing Inventory

Section 2: Before You Begin Installing

2.1 Inventory

The Model 5895XL ships with the following hardware:

• A cabinet with all hardware assembled

• Two keys for the front door

• Ten 4.7K ohm end-of-line resistors

NOTE: For UL installations 4.7k end-of-line resistor (ordered separately) must be used.

• A battery cable for batteries wired in series

2.2 Environmental Specifications

It is important to protect the 5895XL control panel from water. To prevent water damage, the following precautions should be FOL­LOWED when installing the units:

• Do not mount directly on exterior walls, especially masonry walls (condensation)

• Do not mount directly on exterior walls below grade (condensation)

• Protect from plumbing leaks

• Protect from splash caused by sprinkler system inspection ports

• Do not mount in areas with humidity-generating equipment (such as dryers, production machinery)
When selecting a location to mount the 5895XL, the unit should be mounted where it will NOT be exposed to temperatures outside the

range of 0°C-49°C (32°F-120°F) or humidity outside the range of 10%-93% at 30°C (86°F) non-condensing.

2.3 Software Downloads

In order to supply the latest features and functionality in fire alarm and life safety technology to our customers, we make frequent
upgrades to the embedded software in our products. To ensure that you are installing and programming the latest features, we strongly
recommend that you download the most current version of software for each product prior to commissioning any system. Contact Hon­eywell Silent Knight Technical Support with any questions about software and the appropriate version for a specific application. Soft­ware updates can be found at www.silentknight.com

6 5895XL Manual - P/N 151142-L8:L 08/09/2017

5895XL Board and Terminal Strip Description Before You Begin Installing

2.4 5895XL Board and Terminal Strip Description

Figure 2.3 shows the 5895XL circuit board including location of terminals, the DIP switch for setting module ID, and the LED.

Figure 2.3 The 5895XL Board Layout

Table 2.1 : Terminal Strip Description and Electrical Ratings

Terminal # and Label Description

1 L AC input (hot) 120/240 VAC,

2 G Earth ground N/A N/A
3 N AC input (neutral) 120/240 VAC,

4 X I/O 6* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
5O 100 mA Initiation Circuits
6 X I/O 5* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
7 O 100 mA Initiation Circuits
8 X I/O 4* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
9O 100 mA

10 X I/O 3* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
11 O 100 mA Initiation Circuits
12 X I/O 2* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
13 O 100 mA Initiation Circuits

Voltage Current

50/60 Hz

50/60 Hz

Rating

2.7 A

1.4 A

2.7 A

1.4 A

Initiation Circuits

5895XL Manual - P/N 151142-L8:L 08/09/2017 7

Before You Begin Installing Earth Fault Resistance

Table 2.1 : Terminal Strip Description and Electrical Ratings

Terminal # and Label Description

14 X I/O 1* Flexput™ Circuit 24 VDC 3.0 A Notification Circuits
15 O 100 mA Initiation Circuits
16 B SBUS OUT SBUS communication 5 VDC 100 mA
17 A
18 + SBUS power 24 VDC 1.0 A
19 ­20 B SBUS IN Used for Class A installations
21 A
22 +
23 ­24 N.C. RELAY 2 General Purpose Relay 2 24 VDC 2.5 A
25 C
26 N.O.
27 N.C. RELAY 1 General Purpose Relay 1 24 VDC 2.5 A
28 C
29 N.O.
30 B SBUS IN/
31 A

32 + MAIN 5895XL SBUS power (from
33 -

OUT

5895XL communication with main
panel or to controlling 5895XL if
daisy-chained

5820XL)

Voltage Current

5 VDC 100 mA

24 VDC 10 mA

Rating

* Regulated/special application when used for releasing.

2.5 Earth Fault Resistance

Table 2.2 lists the earth fault resistance detection for each applicable terminal on the FACP.

Function

Flexput™
Notification
Circuits

SBUS
Communication

SBUS Power 18 + 0 0 - -

Used for Class A
Installations

Terminal

Number

10 X I/O 3 - - 0 0
11 O 0 0 - ­12 X I/O 2 - - 0 0
13 O 0 0 - ­14 X I/O 1 - - 0 0
15 O 0 0 - ­16 B SBUS OUT - - 0 0
17 A - - 0 0

19 - - - 0 0
20 B SBUS IN - - 0 0
21 A - - 0 0
22 + 0 0 - ­23 - - - 0 0

Table 2.2 : Earth Fault Resistance Values by Terminal

Terminal Label Low Biased High Biased

(Values in kohms) High

Trip

4 X I/O 6 - - 0 0
5O 00-­6 X I/O 5 - - 0 0
7O 00-­8 X I/O 4 - - 0 0
9O 00--

High

Restore

Low
Trip

Low

Restore

8 5895XL Manual - P/N 151142-L8:L 08/09/2017

Calculating Current Draw and Standby Battery Before You Begin Installing

2.6 Calculating Current Draw and Standby Battery

This section is for helping you determine the current draw and standby battery needs for your installation.

2.6.1 Worksheet Requirements

The following steps must be taken when determining 5895XL current draw and standby battery requirements.

 Filling in the Current Draw Worksheet, Table 2.4 (Section 2.6.2)

1. For the 5895XL, the worst case current draw is listed for the panel, addressable devices, and SLC expanders. Fill in the number of
addressable devices and expanders that will be used in the system and comp ute the current draw requirements for alarm and
standby. Record this information in Table 2.4 at Line A.

2. Add up the current draw for all auxiliary devices and record in the table at Line B.

3. Add up all notification appliance loads and record in the table at Line C.

4. For notification appliances and auxiliary devices not mentioned in the manual, refer to the device manual for the current ratings.

5. Make sure that the total alarm current you calculated, including current for the panel itself, does not exceed 6.0 A. This is the
maximum alarm current allowable.

6. Complete the remaining instructions in Table 2.4 for determining battery size requirements.

Maximum Battery Standby Load

Table2.3 shows the maximum battery standby load for the 5895XL based on 24 and 60 hours of standby. The standby load calculations
of line G in the Current Draw Calculation Worksheet (Table 2.4) must be less than the number shown in Table 2.3 for the battery size
used and standby hours required.

Table 2.3 : Maximum Battery Standby Load

Rechargeable

Battery Size

7 AH 270 mA 105 mA
12 AH 475 mA 190 mA
17 AH 685 mA 270 mA
33 AH 1370 mA 540 mA

* Required for NFPA 72 Auxiliary Protected Fire Alarm systems for Fire Alarm Service (City Box) and Remote

Station Protected Fire Alarm systems (Polarity Reversal) and Digital Alarm Communicator/Transmitter (DACT).

NOTE: 33AH max battery size for FM (Factory Mutual) installations

2.6.2 Current Draw Worksheet

For *each 5895XL in the installation, use Table 2.4 to determine current requirements during alarm battery standby operation when SK
SLC devices are installed.

For each device use this formula: This column X This column = Current per number of devices.
5895XL Intelligent Power Module

(Current draw from battery)
Additional 5895XL

(Daisy-chained to this module)
Addressable SLC Detectors

SK-PHOTO Standby/Alarm: .30 mA
SK-PHOTO-T mA mA
SK-HEAT mA mA
SK-HEAT-HT mA mA
SK-ACCLIMATE mA mA
SK-HEAT-ROR mA mA
SK-DUCT
SK-BEAM (without integral test) SLC Standby/Alarm:

2

(includes PhotoR) mA mA

6

Table 2.4 Current Draw Worksheet for SK SLC Devices

Device # of Devices Current per Device

Max. Load for 24 hrs. Standby,

5 mins. Alarm

1* Standby 40 mA 40 mA

Alarm:

(7 max.) Standby 10 mA mA

Alarm: 10 mA mA

*Max. Load for 60 hrs. Standby,

5 mins. Alarm

Standby

Current

160 mA 160 mA

1

mA mA

2 mA

Aux. Pwr Standby:

Alarm: 8.5 mA mA

2 mA mA

Alarm

Current

5895XL Manual - P/N 151142-L8:L 08/09/2017 9

Before You Begin Installing Calculating Current Draw and Standby Battery

Table 2.4 Current Draw Worksheet for SK SLC Devices

Device # of Devices Current per Device

SK-BEAM-T3(with integral test) SLC Standby/Alarm: 2 mA mA m A

Aux. Pwr Standby: 2 mA mA

Alarm: 8.5 mA mA

SK-FIRE-CO SLC Standby:

Alarm: 7.2 mA mA

Addressable SLC Module
SK-MONITOR Standby/Alarm:
SK-MINIMON mA mA
SK-PULL-SA mA mA
SK-PULL-DA mA mA
SK-MONITOR-2 Standby/Alarm:
SK-MONITOR-10 Standby/Alarm:
SK-CONTROL SLC Standby:

Alarm: .375 mA mA

Aux Pwr Standby:

Alarm: 7 mA mA

SK-CONTROL-6 SLC Standby:

Alarm: 2.25 mA mA

Aux Pwr Standby:

Alarm: 20 mA mA

SK-RELAY Standby/Alarm:
SK-RELAY-6 Standby/Alarm:
SK-RELAYMON-2 Standby:

Alarm: 24 mA mA

SK-ZONE Aux Pwr Standby 12 mA mA

Alarm 90 mA mA

SLC Standby/Alarm .27 mA mA mA

SK-ZONE-6 Aux Pwr Standby 50 mA mA

Alarm 270 mA mA

SLC Standby/Alarm 2 mA mA mA
SLC Modules
B200SR Sounder Base Aux Pwr Standby: .5 mA mA

Alarm: 35 mA mA

SLC Standby .3 mA mA
B200S Intelligent Sounder Base Aux Pwr Standby: 5 mA mA

Alarm: (high vol) 35 mA mA

SLC Standby .3 mA mA
B200SR-LF Low Frequency Sounder

Base
B200S-LF Low Frequency Sounder

Base

B224RB Relay Base Standby/Alarm: 0.5 mA mA mA
RTS151/151 KEY Alarm: 7.5 mA
RA100Z Alarm: 10 mA
SLC Isolator Devices
SK-ISO (Isolator Module) (100 max/loop) Standby/Alarm: .45 mA mA mA
B224BI Isolator Base Standby/Alarm: .5 mA mA mA
Accessories Modules

Aux Pwr Standby: 1 mA mA

Alarm: 125 mA mA

Aux Pwr Standby .55 mA mA

Alarm (high vol) 140 mA mA

SLC Standby .30 mA mA

.30 mA mA

.375 mA mA mA

.75 mA mA mA

3.5 mA mA mA

.375 mA mA

1.7 mA mA

2.25 mA mA

8 mA mA

.255 mA mA mA

1.45 mA mA mA

1.3 mA mA

Standby

Current

Alarm

Current

mA
mA

10 5895XL Manual - P/N 151142-L8:L 08/09/2017

Calculating Current Draw and Standby Battery Before You Begin Installing

Table 2.4 Current Draw Worksheet for SK SLC Devices

Device # of Devices Current per Device

6815 SLC Expander (63 max.) Standby/Alarm: 78 mA m A mA
6860 Remote LCD Annunciator (16 max.) Standby: 25 mA mA

Alarm: 50 mA mA
5860 Remote LCD Annunciator Standby: 20 mA m A

Alarm: 25 mA mA
6855 Remote LCD Annunciator Standby: 20 mA m A

Alarm: 25 mA mA
5824 Serial/Parallel I/O Module (4 max.) Standby/Alarm: 45 mA mA mA
5895XL Power Supply (16 max.) Standby/Alarm: 10 mA mA mA
5496 NAC Expander Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator

(with reset and silence switches)
5865-3 LED Annunciator Standby: 35 mA mA

5880 I/O Module Standby: 35 mA mA

5883 Relay Interface (32 max.) Standby: 0 mA mA

EVS-50W or EVS-125W Audio
Amplifier with/without EVS-CE4

EVS-INT50W Internal Amplifier (4 max.) Standby: 52 mA m A

EVS-VCM Voice Control Module (1 max.) Standby: 70 mA mA

EVS-SW24 Switch Expander (5 max.) Standby: 10 mA mA

EVS-RPU Remote Paging Unit (4 max.) Standby: 70 mA mA

EVS-LOC Local Operating Console
(includes 6860, RVM & SW-24)

EVS-100W 100W amplifier (4 max.) Standby/Alarm: 10 mA mA m A
EVS-100WBU backup daughter card (4 max.) Standby/Alarm: 10 mA mA mA
Total System Current
Network Cards
SK-NIC Network Interface Card (1 Max.) Standby/Alarm: 21 mA mA m A
SK-FML Fiber Optic Multi Mode (1 Max.) Standby/Alarm: 53 mA mA m A
SK-FSL Fiber Optic Single Mode (1 Max.) Standby/Alarm: 79 mA mA mA
Wireless Modules
WSK-WGI Wireless Gateway Max current using ext supply 40 mA mA mA

Auxiliary Devices
IPDACT-2 IP Communicator (1 max.) Standby: 93 mA mA

IPDACT-2UD IP Communicator (1 max.) Standby: 98 mA mA

CELL-MOD/CELL-CAB-SK Standby: 55 mA mA

4

(8 max.) Standby: 35 mA mA

Alarm: 145 mA mA

Alarm: 145 mA mA

Alarm: 200 mA mA

Alarm: 220 mA

(22 mA per relay)

(4 max.) Standby: 10 mA mA

Alarm: 10 mA mA

Alarm @ 25V: 275 mA mA

Alarm @ 70V: 310 mA

Alarm: 100 mA mA

Alarm: 25 mA mA

Alarm: 100 mA mA

(4 max.) Standby: 100 mA mA

Alarm: 150 mA mA

Max current SLC Power 24 mA mA mA

Refer to devices manual for current rating.

Alarm: 136 mA mA

Alarm: 155 mA mA

Alarm: 100 mA mA

Standby

Current

Alarm

Current

mA

mA

5895XL Manual - P/N 151142-L8:L 08/09/2017 11

Before You Begin Installing Calculating Current Draw and Standby Battery

Table 2.4 Current Draw Worksheet for SK SLC Devices

Device # of Devices Current per Device

Alarm/Standby: mA mA m A

Alarm/Standby: mA mA m A

Alarm/Standby: mA mA m A

Alarm/Standby: mA mA m A
Auxiliary Devices Current
Notification Appliance Circuits Refer to device manual for current rating.
5495/5499 Power Supply 24 VDC One input circuit: 15 mA

Both input circuits: 30 mA
Alarm: mA
Alarm: mA
Alarm: mA
Alarm: mA

Notification Appliances Current
Total current ratings of all devices in system (line A + line B + C) mA mA
Total current ratings converted to amperes (line D x .001): A A
Number of standby hours: H
Multiply lines E and F. Total standby AH AH
Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
Multiply lines E and H. Total alarm AH
Add lines G and I.

1. The FACP can only support 5 devices w/LED’s on. This current draw has been added to the panels alarm current.

2. The SK-DUCT housing contains a vacant mount for a SK-RELAY (sold separately). Current draw for the SK-RELAY is calculated by
increasing the SK-RELAY row of the calculation sheet by one for each SK-RELAY used with a SK-DUCT.

3. SK-BEAM-T draws a maximum of 500mA from Auxiliary power only when the test feature is used. this should be considered when
determining auxiliary power capacity but not calculated into current requirements for day to day operation.

4. If using door holders, you do not need to consider door holder current for alarm/battery standby, because power is removed during that
time. However, during normal operation, door holders draw current and must be included in the 6.0A total current that can be drawn
from the panel.

5. Use next size battery with capacity greater than required.

6. Total does not include isolator devices or accessory bases.

5

Total ampere hours
required

Standby

Current

AH

Alarm

Current

mA
mA
mA
mA
mA
mA
mA

AH

2.6.3 Current Draw Worksheet for SD SLC Devices

Use Table 2.5 to determine current requirements during alarm/battery standby operation when SD SLC devices are installed.

Table 2.5 Current Draw Worksheet for SD SLC Devices

Device # of Devices Current per Device

For each device use this formula: This column X This column = Current per number of devices.
5895XL Intelligent Power Module

(Current draw from battery)
Additional 5895XL

(Daisy-chained to this module)
Addressable SLC Devices

SD500-AIM Standby/Alarm: .55 mA
SD500-MIM mA mA
SD500-PS mA mA
SD500-ARM mA mA
SD505-HEAT mA mA
SD505-PHOTO mA mA

1* Standby 40 mA 40 mA

Alarm: 160

(7 max.) Standby 10 mA mA

Alarm: 10 mA mA

Standby

Current

mA 160 mA

1

12 5895XL Manual - P/N 151142-L8:L 08/09/2017

5

Alarm

Current

mA mA

Calculating Current Draw and Standby Battery Before You Begin Installing

Table 2.5 Current Draw Worksheet for SD SLC Devices

Device # of Devices Current per Device

Standby

Current

Alarm

Current

SD500-ANM Aux. Pwr Standby: 8 mA mA

Alarm: 60 mA mA

SLC Standby/Alarm: .55 mA mA mA

SD500-SDM SLC Standby/Alarm: .55 mA mA

Aux. Pwr Standby: 20 mA mA

Alarm: 106 mA mA
SLC Accessory Bases
SD505-6RB Standby/Alarm: .082 mA mA mA
SD505-6SB Aux. Pwr Standby: 1 mA mA

Alarm: 32 mA mA

SLC Standby/Alarm .082 mA mA mA

SD505-DUCTR Aux. Pwr Standby: 20 mA

Alarm: 62 mA

2
2

mA

mA

SLC Standby/Alarm: .5 mA mA mA
SD505-DTS-K None, included with SD505-DUCTR worst case.
SD505-DUCT None, included with detector current.
SLC Isolator Devices
SD500-LIM (100 max/loop) Standby/Alarm .092 mA mA mA
SD505-6IB
Accessories Modules
5815XL SLC Loop Expander (63 max.) Standby/Alarm: 55 mA mA mA
6860 Remote LCD Annunciator. (16 max.) Standby: 25 mA mA

Alarm: 50 mA mA
5860 Remote LCD Annunciator. Standby: 20 mA mA

Alarm: 25 mA mA
6855 Remote LCD Annunciator Standby: 20 mA mA

Alarm: 25 mA mA
5824 Serial/Parallel Printer Interface (4 max.) Standby/Alarm: 45 mA mA mA
5895XL Power Supply (16 max.) Standby/Alarm: 10 mA mA m A
5496 NAC Expander Standby/Alarm: 10 mA mA mA
5865-4 LED Annunciator Module

(with reset and silence switches)

(8 max.) Standby: 35 mA mA

Alarm: 145 mA mA
5865-3 LED Annunciator Module Standby: 35 mA mA

Alarm: 145 mA mA
5880 LED I/O Module Standby: 35 mA mA

Alarm: 200 mA mA
5883 Relay Interface (32 max.) Standby: 0 mA mA

Alarm: 220 mA

mA

(22 mA per relay)
EVS-50W or EVS-125W Audio Amplifier

with/without EVS-CE4

(4 max.) Standby: 10 mA mA

Alarm: 10 mA mA
EVS-INT50W Internal Amplifier (4 max.) Standby: 52 mA mA

Alarm @ 25V: 275 mA mA

Alarm @ 70V: 310 mA

mA

EVS-VCM Voice Control Module (1max.) Standby: 70 mA mA

Alarm: 100 mA mA
EVS-SW24 Switch Expander (5 max.) Standby: 10 mA mA

Alarm: 25 mA mA

5895XL Manual - P/N 151142-L8:L 08/09/2017 13

Before You Begin Installing Calculating Current Draw and Standby Battery

Table 2.5 Current Draw Worksheet for SD SLC Devices

Device # of Devices Current per Device

EVS-RPU Remote Paging Unit (4 max.) Standby: 70 mA mA

Alarm: 100 mA mA
EVS-LOC Remote Command Unit

(includes 6860, RVM & SW-24)
EVS-100W 100W Amplifier (4 max.) Standby/Alarm: 10 mA mA mA

EVS-100WBU backup daughter card (4 max.) Standby/Alarm: 10 mA mA mA

A Total System Current

Network Cards
SK-NIC Network Interface Card (1 Max.) Standby/Alarm: 21 mA mA mA
SK-FML Fiber Optic Multi Mode (1 Max.) Standby/Alarm: 53 mA mA mA
SK-FSL Fiber Optic Single Mode (1 Max.) Standby/Alarm: 79 mA mA mA
Auxiliary Devices
IPDACT-2 IP Communicator (1 max.) Standby: 93 mA mA

IPDACT-2UD IP Communicator (1 max.) Standby: 98 mA mA

CELL-MOD/CELL-CAB-SK Standby: 55 mA mA

B Auxiliary Devices Current

Notification Appliance Circuits Refer to device manual for current rating.
5495/5499 Power Supply 24 VDC One input circuit: 15 mA

C Notification Appliances Current
D Total current ratings of all devices in system (line A + line B + C) mA mA
E Total current ratings converted to amperes (line D x .001): A A
F Number of standby hours: H
G Multiply lines E and F. Total standby AH AH
H Alarm sounding period in hours. (For example, 5 minutes = .0833 hours) H
I Multiply lines E and H. Total alarm AH
J Add lines G and I.

1. The FACP can only support 5 devices w/LED’s on. This current draw has been added to the panels alarm current.

2. If using 24 VDC aux power only. No standby or alarm current for battery calculation if using 24 VAC, 120 VAC or 240 VAC.

3. If using door holders, you do not need to consider door holder current for alarm/battery standby, because power is removed during that
time. However, during normal operation, door holders draw current and must be included in the 6.0A total current that can be drawn
from the panel.

4. Use next size battery with capacity greater than required.

5. Total does not include isolator devices or accessory bases.

3

4

Total ampere hours

(4 max.) Standby: 100 mA mA

Alarm: 150 mA mA

Refer to devices manual for current rating.

Alarm: 136 mA mA

Alarm: 155 mA mA

Alarm: 100 mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA
Alarm/Standby: mA mA mA

Both input circuits: 30 mA
Alarm: mA
Alarm: mA
Alarm: mA
Alarm: mA

required

Standby

Current

Alarm

Current

mA
mA
mA
mA
mA
mA
mA

AH

AH

* Use a separate worksheet for each 5895XL.

14 5895XL Manual - P/N 151142-L8:L 08/09/2017

Wiring Specifications Before You Begin Installing

2.7 Wiring Specifications

2.7.1 Length Limitations

This section contains information on calculating SBUS wire distances and the types of wiring configurations (Class A and B).

2.7.2 Calculating Wiring distance for SBUS modules

The following instructions will guide you in determining the type of wire and the maximum wiring distance that can be used with SBUS
accessory modules.

To calculate the wire gauge that must be used to con nect SBUS modules to the panel, it is necessary to calculate the total worst case cur­rent draw for all modules on a single 4-conductor bus. The total worst case curr ent draw is calc ulated by adding the individual worst case
currents for each module. The individual worst case values are shown in the table below.

NOTE: Total worst case current draw on a single SBUS cannot exceed 1 amp. If a large number of accessory modules are required, and the
worst case current draw will exceed the 1 amp limit, then the current draw must be distributed using 5895XL Power Expanders. Each 5895XL
Power Expander provides an additional SBUS, with an additional 1 amp of SBUS current. Wiring distance calculations are done separately for
each 5895XL, and separately for the panel itself.

Model Number Worst Case Current Draw

6860, 5860, 6855 Fire Annunciator .120 amps
5815XL SLC Loop Expander .150 amps
6815 SLC Loop Expander .078 amps
5824 Serial/Parallel Printer Interface Module .040 amps
5880 LED I/O Module .250 amps
5865 LED Annunciator .200 amps
5895XL Intelligent Power Supply .010 amps
5496 Intelligent Power Supply .010 amps
EVS-50W .010 amps
EVS-125W .010 amps
EVS-100W .010 amps
EVS-100W with EVS-100WBU .010 amps
EVS-VCM / EVS-VCM with EVS-SW24* ** .080 amps / .105 amps
EVS-LOC / EVS-LOC with EVS-SW24* ** .080 amps / .105 amps
SK-NIC Network Interface Card .021 amps
CELL-MOD/CELL-CAB-SK .145 amps
SK-F485C Fiber Converter .125 amps

* All devices must use the same SBUS and VBUS.
** When doing wire calculations, use .080 amps per device with .105 amps for the last device.
After calculating the total worst case current draw, Table 2.6 specifies the maximum distance the modules can be located from the panel

on a single wire run. The table insures 6.0 volts of line drop maximum. In general, the wire length is li mited by resistan ce, but for heavier
wire gauges, capacitance is the limiting factor .

5895XL Manual - P/N 151142-L8:L 08/09/2017 15

Before You Begin Installing Wiring Specifications

These cases are marked in the chart with an asterisk (*). Maximum length can never be more than 6,000 feet, regardless of gauge used.
(The formula used to generate this chart is shown in the note below).

Table 2.6 Wire Distances Per Wire Gauge

Wiring Distance: SBUS Modules to Panel

Total Worst Case

Current Draw (amps)

0.100 1852 ft. 4688 ft. * 6000 ft. * 6000 ft.

0.200 926 ft. 2344 ft. 3731 ft. 5906 ft.

0.300 617 ft. 1563 ft. 2488 ft. 3937 ft.

0.400 463 ft. 1172 ft. 1866 ft. 2953 ft.

0.500 370 ft. 938 ft. 1493 ft. 2362 ft.

0.600 309 ft. 781 ft. 1244 ft. 1969 ft.

0.700 265 ft. 670 ft. 1066 ft. 1687 ft.

0.800 231 ft. 586 ft. 933 ft. 1476 ft.

0.900 206 ft. 521 ft. 829 ft. 1312 ft.

1.000 (Max) 185 ft. 469 ft. 746 ft. 1181 ft.

NOTE: The following formulas were used to generate the wire distance chart:

Maximum Resistance (Ohms) = 6.0 Volts

22 Gauge 18 Gauge 16 Gauge 14 Gauge

Total Worst Case Current Draw (amps)

Maximum Wire Length (Feet) =
(6000 feet maximum)

where: Rpu = Ohms per 1000 feet for various Wire Gauges (see table below)

Maximum Resistance (Ohms) * 500
Rpu

Table 2.7 Typical Wire Resistance Per 1000 ft.

Wire Gauge Ohms per 1000 feet (Rpu)

22 16.2
18 6.4
16 4.02
14 2.54

Wiring Distance calculation example:



Suppose a system is configured with the following SBUS modules:
2 - Module 5860 Fire Annunciator
1 - 5895XL Intelligent Power Expander
1 - 5865 LED Fire Annunciator
1 - 5824 Parallel/Serial Interface
The total worst case current is calculated as follows:

5860 Current Draw = 2 x .100 amps = .200 amps
5895XL Current Draw = 1 x .010 amps = .010 amps
5865 Current Draw = 1 x .200 amps = .200 amps
5824 Current Draw = 1 x .040 amps = .040 amps
Total Worst Case Current Draw = .450 amps

Using this value, and referring to the Wiring Distance table, it can be found that the available options are:
370 feet maximum using 22 Gauge wire
938 feet maximum using 18 Gauge wire
1493 feet maximum using 16 Gauge wire
2362 feet maximum using 14 Gauge wire

16 5895XL Manual - P/N 151142-L8:L 08/09/2017

Wiring Specifications Before You Begin Installing

5895XL Board

2.7.3 Wire Routing

You must follow power-limited wiring techniques, which includes maintaining one-quarter inch spacing between power-limited and
non-power-limited circuits and separating high and low voltage circuits.

Figure 2.4 Wire Routing Example

5895XL Manual - P/N 151142-L8:L 08/09/2017 17

Hardware Installation AC Power

To 120 VAC

Power Source

Green

White

Black

Section 3: Hardware Installation

5895XL installation involves the following steps:

• AC power (Section 3.1) and backup battery connection (Section 3.2).

• Physical connection to the FACP or to the controlling 5895XL (see Section 3.3).

• Setting an ID for the 5895XL (Section 3.3.1).

• Physical connection of SBUS modules that will be powered by this 5895XL (Section 3.4).

• Physical connection of any outputs (conventional relays, notification appliances, auxiliary power modules, and so on) that will be
powered by this 5895XL. See Section 3.5.1 for notification appliance wiring information. Refer to the FACP Installation Manual,
for software configuration information and other information about installing outputs.

Model Number FACP Installation Manual

5820XL/EVS LS10061-001SK-E

6820/EVS LS10144-001SK-E

5700 151295
6700 LS10148-001SK-E
5808 151274-L8
6808 LS10146-001SK-E

3.1 AC Power

At installation, connect the AC termin als to 120 VAC source as shown in Figure 3.5. It may be necessary for a professional electrician to
make this connection.

The AC terminals are rated as 120 VAC, 50 or 60 Hz, 2.7 A.

Figure 3.5 AC Power Connection

3.2 Battery Connection

The 5895XL battery charge capacity is 7.0 to 33.0 AH. Use 12V batteries of the same AH rating. Determine the correct AH ra ting as pe r
your current load calculation (see Section Table 2.4 or Table 2.5).

NOTE: When your backup batteries requirements use backup batteries that are to large to fit into the 5895XL cabinet. The AB-33 cabinet
holds batteries up to the 33 AH size. (Refer to FACP Installation Manual for AB-33 installation instructions.

* 33AH max battery size for FM (Factory Mutual) installations

18 5895XL Manual - P/N 151142-L8:L 08/09/2017

Connecting the 5895XL to the FACP Hardware Installation

Red

To Panel

Black

12V Battery

12V Battery

Battery Jumper

(P/N 140694)

Shipped With 5895XL

Replace batteries every 5 years.

(FACP SBUS)

5895XL
Terminals 30-33 are used only for connection
5895XL to the FACP or to the controlling 5895XL.
Use 5895XL Terminals 16-19 to connect other
SBUS modules (SLC expanders, annunciators,

5895XL Board
(5895XL-1)

5895XL Board
(5895XL-2)

To next 5895XL

and other SBUS

modules.

Wire batteries in series to produce a 24-volt equivalent. Do not parallel batteries to increase the AH rating.

3.3 Connecting the 5895XL to the FACP

1. Connect the 5895XL to the appropriate SBUS. The 5895XL can be connected directly to the FACP or can be daisy-chained to
another 5895XL. Figure 3.7 and Figure 3.8 show both connections.

2. Use on-board DIP switch to assign an ID#. (See Section 3.3.1) Figure 2.3 shows the location of the DIP switches on the 5895XL
board.

3. Configure the 5895XL module by adding it to the system (through JumpStart or manually). You can also assign a name to the
module. These procedures are described in the FACP Installation Manual.

Figure 3.6 Battery Connection

5895XL Manual - P/N 151142-L8:L 08/09/2017 19

Figure 3.7 Class B 5895XL Connection to FACP

Hardware Installation Connecting the 5895XL to the FACP

See Figure 3.10 for SBUS Module Connections

See Figure 3.10 for

SBUS Module

Connections

Figure 3.8 Class A 5895XL Connection to FACP

20 5895XL Manual - P/N 151142-L8:L 08/09/2017

Connecting SBUS Modules to the 5895XL Hardware Installation

3.3.1 Setting the Device ID

board to set the module ID#. Figure 2.3 shows the location of the DIP switch on the board.

Figure 3.9 Possible Module Addresses

3.4 Connecting SBUS Modules to the 5895XL

1. Connect SBUS modules to the 5895XL as shown in Figure 3.10 or Figure 3.11.

2. All SBUS modules must have an ID. Use the DIP switches on the module board to assign an ID number (1-31) to the module. This
number identifies the module to the 5895XL and must be unique.

5895XL Manual - P/N 151142-L8:L 08/09/2017 21

Hardware Installation Flexputs™ I/O Circuits

3. Software configuration steps vary for each SBUS module. For more information, refer to the FACP installation manual in the
section that discusses the type of module you are installing.

3.5 Flexputs

The six Flexput™ circuits are an innovative and versatile feature of the 5895XL panel. They can be used as: Class A or B notification
circuits, Class A or B initiation circuits (either 2 or 4 wire detectors), or as auxiliary power (resettable, continuous, or door holder).

This section of the manual explains how to install conventional notification appliances and initiating devices to be used with the
5895XL.

™

I/O Circuits

Figure 3.10 SBUS Class A Connection to 5895XL

Figure 3.11 SBUS Class B Wiring to 5895XL

3.5.1 Conventional Notification Appliance

This sub-section of the manual explains how to install conventional notification appliances for Class A and Class B configurations.

22 5895XL Manual - P/N 151142-L8:L 08/09/2017

Flexputs™ I/O Circuits Hardware Installation

alarm polarity shown.

UL Listed EOL

4.7 k

Supervised
Power Limited

Notification Wiring

Regulated

3.5.2 Releasing Operations

Approved releasing solenoids are list in Table 3.8. Do not mix cross alarming zones with smoke verification zones. There must be at
least two automatic detection devices in each protected space. Spacing must be reduced to 0.7 times the linear spacing in accordance
with NFPA 72.

Table 3.8 Approved Releasing Solenoids

Manufacturer Part Number Rating Current Freq

Asco T8210A107 24 VDC 3A max 0 Hz

8210G207 24 VDC 3A max 0 Hz

Class B Notification Wiring

You must use an appliance from the list of compatible appliances in Appendix A.
To install a Class B notification appliance circuit:

1. Wire Class B Notification appliances as shown in Figure 3.12.

2. Configure the circuit through programming.

Figure 3.12 Class B Notification Appliance Circuit Wiring

Class A Notification Wiring

You must use an appliance from the list of compatible appliances in the Appendix A at the back of this manual.
To install a Class A notification appliance circuit:

1. Wire the Class A notification appliances as shown in Figure 3.13.

5895XL Manual - P/N 151142-L8:L 08/09/2017 23

Hardware Installation Flexputs™ I/O Circuits

Regulated

UL Listed EOL

4.7 k

2. Configure the circuit for Class A in programming.

Figure 3.13 Class A Notification Appliance Circuit Configuration

NOTE: In programming any point that uses multiple I/O circuits are always referred to as the lowest I/O circuit number used. For example,

Figure 3.13 uses both I/O circuit 5 and 6, so in programming it would be referred to as point 5.

3.5.3 Conventional Initiation Circuits

This section of the manual explains how to install conventional initiating devices for Class A (Style D) or Class B (Style B) configura­tions.

Class B Inputs

You can connect conventional Class B switches, such as waterflow switches and pull stations, directly to the I/O circuits of the 5895XL
panel.

To install a Class B switch:

1. Wire the Class B switch as shown in Figure 3.14.

2. Configure the circuit through programming (see FACP Installation Manual).

Figure 3.14 Class B Input Switches

Class A Inputs

You can connect conventional Class A switches, such as waterflow switches and pull stations, directly to the I/O circuits of the 5895XL
panel.

24 5895XL Manual - P/N 151142-L8:L 08/09/2017

Flexputs™ I/O Circuits Hardware Installation

Note:
I/O circuit 5 and 6

used as an example.
Any I/O point pairing
could be used.

Note:
I/O circuit 5

used as an example.
Any I/O circuit
could be used.

UL Listed EOL

4.7 k

To install a Class A switch:

1. Wire the Class A switch as shown in Figure 3.15.

2. Configure the circuit through programming.

Figure 3.15 Class A initiating Switches

NOTE: In programming any point that uses multiple I/O circuits are always referred to as the lowest I/O circuit number used. For example,

Figure 3.15 uses both I/O circuit 5 and 6, so in programming it would be referred to as point 5.

3.5.4 Installing 2-Wire Smoke Detectors

Any compatible U.L. listed two-wire smoke detector can be used with the 5895XL panel (see Appendix A for list of compatible smoke
detectors). Figure 3.16 and Figure 3.17 illustrate how to connect a UL listed 2-wire detector to the control panel.



Class B Installation

To install a Class B two-wire smoke detector, wire as shown in Figure 3.16.

5895XL Manual - P/N 151142-L8:L 08/09/2017 25

Figure 3.16 Two-Wire Class B Smoke Detector

Hardware Installation Flexputs™ I/O Circuits

Note:
I/O circuit 5 and 6

used as an example.
Any I/O point pairing
could be used.

Air Products

PAM-2

Model 160150

Supervision

Module

UL Listed
EOL 4.7K

ESL 449CT

Note:
I/O circuit 5 and 6

used as an example.
Any I/O point pairing
could be used.



2-Wire Class A Smoke Detector Installation

To install a Class A two-wire smoke detector, wire as shown in Figure 3.17.

Figure 3.17 Two-Wire Class A Smoke Detector Connections

NOTE: In programming any point that uses multiple I/O circuits are always referred to as the lowest I/O circuit number used. For example,

Figure 3.17 uses both I/O circuit 5 and 6, so in programming it would be referred to as point 5.

3.5.5 Installing 4-Wire Smoke Detectors

Any compatible U.L. listed four-wire smoke detector can be used with the 5895XL panel (see Appendix A for list of compatible smoke
detectors). Figure 3.18 and Figure 3.19 illustrate how to connect a UL listed four-wire detector to the control panel.



Installing a Class B 4-Wire Smoke Detector

“Class B 4-Wire Smoke Detector Connections” on page 26 illustrates how to install a 4-wire Class B smoke detector.
Conventions used for wiring 4-wire Class B loops:

1. Up to three Class B 4-wire smoke detector loops can be connected to the control panel at once.

2. Each Class B loop input is paired with a unique power source as shown in Figure 3.18.

3. Each loop gets smoke power from the even numbered I/O circuit and the contact input is connected to the odd numbered I/O circuit.

Figure 3.18 Class B 4-Wire Smoke Detector Connections

26 5895XL Manual - P/N 151142-L8:L 08/09/2017

NOTE: In programming any point that uses multiple I/O circuits are always referred to as the lowest I/O circuit number used. For example,
Figure 3.18 uses both I/O circuit 5 and 6, so in programming it would be referred to as point 5.

Conventional Relay Installation Hardware Installation

Air Products

PAM-2

Model 160150

Supervision

Module

Air Products

PAM-2

Model 160150

Supervision

Module



Installing 4-Wire Class A Smoke Detectors

Figure 3.19 illustrates how to install 4-wire Class A detectors.
Conventions used for wiring 4-wire Class A loops:

1. Up to two Class A 4-wire loops can be connected to the control panel at once.

2. Smoke power is supplied to each Class A loop as shown in Figure 3.19.

3.5.6 Auxiliary Power Configuration

3.6 Conventional Relay Installation

Figure 3.19 Class A 4-Wire Smoke Detector Connections

NOTE: In programming any point that uses multiple I/O circuits are always referred to as the lowest I/O circuit number used. For example,

Figure 3.19 uses I/O circuits 1, 2, 3 together and 4, 5, 6 together. In programming (1, 2, 3) would be referred to as point 1, and (4, 5, 6) would be
referred to as point 4.

Circuits 1-6 on the control panel can be used as auxiliary power circuits. The four types of auxiliary power avai lable are:

• Door Holder

• Constant

• Resettable Power

• Sounder Sync Power

Auxiliary power circuits are power limited. Each circuit can source up to 3A (total curr ent for all circuits must not exceed 6A).
To install an auxiliary power circuit:

1. Wire the circuit(s) that will be used for auxiliary power.

2. Configure the auxiliary power output through programming.

Door Holder Power

Door holder power is intended for fire door applications. When there are no fire system alarms in the system and the panel has AC
power, door holder circuits have 24 volt power present at their terminals. Any fire system alarm will cause power to disconnect. Power
will be re-applied when the fire system is reset. If AC power is not present, the auxiliary door holder power will be disconnected to con­serve the battery backup. When AC power is restored, power is immediately restored to the door holder circuits.

Constant Power

Use constant power for applications that require a constant auxiliary power source. Power is always present at Constant circuits.

Resettable Power

Resettable power is typically used to power beam detectors, flame detectors and conventional 4-wire smoke detectors. For circuits
selected as Resettable, 24-volt power is always present at the terminals unle ss a syst em reset occurs. If a system reset occurs, power is
disconnected from the terminals for 30 seconds, then re-applied.

Sounder Sync Power

Sounder Sync Power continuously outputs the System Sensor synchronization pattern and is intended for use with B200S sounder bases.

5895XL relay circuits are installed in exactly the same way as the FACP relay circuits. Refer to the FACP Installation Manual for infor­mation on installing conventional relays.

5895XL Manual - P/N 151142-L8:L 08/09/2017 27

Compatible Devices Notification Appliances

Appendix A: Compatible Devices

A.1 Notification Appliances

For proper operation, you must use polarized devices with a Model 7628 4.7k ohm EOL resistor on each loop. All supervised notifica­tion appliances used with the 5895XL must be polarized.

NOTE: Not all devices can use the Sync feature, be sure to check below table to ensure the device you have chosen will work with this
feature. This control is UL listed for panel wide Synchronization.

Compatible Devices table below lists notification appliances compatible with the fire alarm control panel. Appliances
which can be synchronized indicate the type of sync available in the columns marked Audio and/or Visual

Manufacturer Model Audio Visual Type

Horn/Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Chimes/Strobe
Chimes/Strobe
Chimes/Strobe
Chimes/Strobe
Horn
Horn

Mini Horn
Mini Horn
Vibrating Bell
Vibrating Bell
Vibrating Chime
Horn
Horn
Horn

AMSECO

FCI

SH24W-153075
SAD24-153075
SAD24-75110
SL24W-75110
SL24C-3075110
SLB24-75
RSD24-153075
RSD24-75110
SH24W-75110
SH24W-3075110
SHB24-75
SCM24W-153075
SCM24W-75110
SCM24C-3075110
SCM24C-177
H24W
H24R
S2415-FC x Strobe

S241575-FC x Strobe
S2430-FC x Strobe
130-3117C

130-3147C
BLV-6
BLV-10
BLVCH
H12/24-FC
H12/24W-FC
H12/24K-FC

xx

x
x
x
x
x
x

x
xx
xx
xx
x
x
x
x
x
x

x
x
x
x
x
x
x
x

.

30 5895XL Manual - P/N 151142-L8:L 08/09/2017

Notification Appliances Compatible Devices

Manufacturer Model Audio Visual Type

HC12/24-FC x Horn
HC12/24W-FC x Horn
HC12/24K-FC x Horn
P2415-FC x x Horn/Strobe
P2415W-FC x x Horn/Strobe
P2415K-FC x x Horn/Strobe
P241575-FC x x Horn/Strobe
P241575W-FC x x Horn/Strobe
P241575F-FC x x Horn/Strobe
P241575K-FC x x Horn/Strobe
P2430-FC x x Horn/Strobe
P2430W-FC x x Horn/Strobe
P2430K-FC x x Horn/Strobe

FCI con’t

Federal
Signal

P2475-FC x x Horn/Strobe
P2475W-FC x x Horn/Strobe
P2475K-FC x x Horn/Strobe
P24110-FC x x Horn/Strobe
P24110W-FC x x Horn/Strobe
P24110K-FC x x Horn/Strobe
S2430W-FC x Strobe
S2430K-FC x Strobe
S2475-FC x Strobe
S2475W-FC x Strobe
S2475K-FC x Strobe
S24110-FC x Strobe
S24110W-FC x Strobe
S24110K-FC x Strobe
450 x Horn
VALS x x Horn/Strobe

5895XL Manual - P/N 151142-L8:L 08/09/2017 31

Compatible Devices Notification Appliances

Manufacturer Model Audio Visual Type

Gentex

GEC-24-15
GEC-24-30
GEC-24-60
GEC-24-75
GEC-24-177
GEC-24-110
GEC-24-15/75 x x Horn/Strobe
GX91
GX93
HG124 x Horn

HS24-15
HS24-30
HS24-60
HS24-75
HS24-110
HS24-1575
GCC24
GCCR24
GCS24
GCSR24
GECR-24
GES24-15
GES24-30
GES24-60
GES24-75
GES24-110
GES24-15/75
GES24-177
GES3-24
GESR-24
GEH-24
ST24-30
ST24-60
ST24-75
ST24-110
ST24-1575
WGEC24-75W
WGES24-75W
WGMS-24-X x x Horn/Strobe

xx
xx
xx
xx
xx
xx

x
x

xx
xx
xx
xx
xx
xx
xx

x

x

x
xx

x

x

x

x

x

x

x

x

x
x

x

x

x

x

x
xx

x

Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe

MiniHorn Steady Tone
MiniHorn Temporal Tone

Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Multi Candella Horn/Strobe Ceiling Mount
Multi Candella Horn/Strobe Ceiling Mount
Multi Candella Strobe Ceiling Mount
Multi Candella Strobe Ceiling Mount
Multi Candella Horn/Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Multi Candella Strobe
Multi Candella Strobe
Horn
Strobe
Strobe
Strobe
Strobe
Strobe
Weatherproof Horn/Strobe
Weatherproof Strobe

32 5895XL Manual - P/N 151142-L8:L 08/09/2017

Notification Appliances Compatible Devices

Manufacturer Model Audio Visual Type

System
Sensor

CHR
CHW
CHSR
CHSW
HR
HW
HRK
HWL x Horn WHT Wall 4x4
HRL x Horn Red Wall 4x4

HGRL x Horn Red Wall 2x4
HGWL x Horn WHT Wall 2x4
CHWL x Chime WHT Wall 4x4
CHRL x Chime Red Wall 4x4
CHSRL

CHSWL
CHSCRL
CHSCWL
P2R
P2R-P
PC2R
PC2R-P
P2RH
P2RH-P
PC2RH
PC2RH-P
P2W
P2W-P
PC2W
PC2W-P
P2WH
P2WH-P
PC2WH
PC2WH-P
P2RK
PC2RK
P2RHK
PC2RHK
P4R
PC4R
P4RH
P4W

x
x
xx
xx
xx

x

x

xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx

Chime
Chime
2-Wire Chime/Strobe
2-Wire Chime/Strobe
Horn
Horn
Horn

Chime/Strobe Red Wall 4x4
Chime/Strobe WHT Wall 4x4
Chime/Strobe Red Ceil 4x4
Chime/Strobe WHT Ceil 4x4
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe
2-Wire Horn/Strobe
2-Wire Horn/Strobe High Candela
2-Wire Horn/Strobe High Candela
4-Wire Horn/Strobe
4-Wire Horn/Strobe
4-Wire Horn/Strobe High Candela
4-Wire Horn/Strobe

5895XL Manual - P/N 151142-L8:L 08/09/2017 33

Compatible Devices Notification Appliances

Manufacturer Model Audio Visual Type

System
Sensor
(cont.)

PC4W
P4WH
PC4WH
P4RK
PC4RK
P4RHK
PC4RHK
PC4RH
P2RL, P2RL-P, P2RL-SP*
P2WL, P2WL-P, P2WL-SP*
PC2RL
PC2WL
P2GRL
P2GWL
P4RL
P4WL
PC4RL
PC4WL
SR
SR-P
SCR
SCR-P
SRH
SRH-P
SCRH
SCRH-P
SW
SW-P
SCW
SCW-P
SWH
SWH-P
SCWH

xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx
xx

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

4-Wire Horn/Strobe
4-Wire Horn/Strobe High Candela
4-Wire Horn/Strobe High Candela
4-Wire Horn/Strobe
4-Wire Horn/Strobe
4-Wire Horn/Strobe High Candela
4-Wire Horn/Strobe High Candela
4-Wire Horn/Strobe High Candela
Horn/Strobe 2W Red Wall 4x4
Horn/Strobe 2W WHT Wall 4x4
Horn/Strobe 2W Red Ceil 4x4
Horn/Strobe 2W WHT Ceil 4x4
Horn/Strobe 2W Red Wall 2x4
Horn/Strobe 2W WHT Wall 2x4
Horn/Strobe 4W Red Wall 4X4
Horn/Strobe 4W WHT Wall 4X4
Horn/Strobe 4W Red Ceil 4X4
Horn/Strobe 4W WHT Ceil 4X4
Strobe
Strobe
Strobe
Strobe
Strobe High Candela
Strobe High Candela
Strobe High Candela
Strobe High Candela
Strobe
Strobe
Strobe
Strobe
Strobe High Candela
Strobe High Candela
Strobe High Candela

34 5895XL Manual - P/N 151142-L8:L 08/09/2017

Notification Appliances Compatible Devices

Manufacturer Model Audio Visual Type

System
Sensor
(cont.)

SCWH-P
SRK
SCRK
SRHK
SCRHK
SRL, SRL-P, SRL-SP*
SWL, SWL-P, SWL-ALERT

SWL-CLR-ALERT*
SCRL

SCWL
SCWL-CLR-ALERT
SGRL
SGWL
P2RH-LF
P2WH-LF
HR-LF
HW-LF

x

x

x

x

x

x

x

x

x

x

x

x
xx
xx
x
x

Strobe High Candela
Strobe
Strobe
Strobe High Candela
Strobe High Candela
Strobe Red Wall 4x4
Strobe White Wall 4x4

Strobe Red Ceil 4x4
Strobe White Ceil 4x4
Strobe WHT Ceil CLR Lens 4x4
Strobe Red Wall 2x4
Strobe White Wall 2x4
2-Wire Low Frequency Sounder Strobe
2-Wire Low Frequency Sounder Strobe
Low Frequency Sounder
Low Frequency Sounder

* P=Plain, ALERT=Pad Printing ALERT, SP=Fuego

Horn
Horn
Horn Weatherproof
Horn Weatherproof
Multi-Tone Horn Strobe
Mutli-Tone Horn Strobe
Multi-Tone Horn Strobe
Multi-tone Horn
Multi-tone Horn
Horn/Strobe
Horn
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe Weatherproof
Horn/Strobe Weatherproof

Wheelock

AH-12
AH-24
AH-12WP
AH-24WP
AMT-241575W
AMT-24MCW
AMT-241575W-NYC
AMT-12/24
AMT-12/24 NYC
AS-121575W
NH-12/24
AS-241575W
AS-24MCC
AS-24MCCH
AS-24MCW
AS-24MCWH
ASWP-2475W
ASWP-2475C

x
x
x
x
xx

x
xx
x
x

x
xx
xx
xx
xx
xx
xx
xx
xx

5895XL Manual - P/N 151142-L8:L 08/09/2017 35

Compatible Devices Notification Appliances

Manufacturer Model Audio Visual Type

Horn/Strobe
Horn/Strobe
Chime
Chime
Chime/Strobe
Chime/Strobe
Chime/Strobe
Chime/Strobe
Chime/Strobe
Horn
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Mini Horn Strobe
MultitoneHorn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Multitone Horn Strobe
Horn
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe
Horn/Strobe

Wheelock
(cont.)

ASWP-24MCWH
ASWP-24MCCH
CH-70
CH-90
CH70-241575W
CH70-24MCW
CH70-24MCWH
CH90-24MCC
CH90-24MCCH
HS-24
HS4-241575W
HS4-24MCW
HS4-24MCWH
HS4-24MCC
MIZ-24S
MT-121575W
MT-241575W
MT-24MCW
MTWP-2475W
MTWP-2475C
MTG-121575W
MTR-121575W
MTWPA-2475W
MTWPB-2475W
MTWPG-2475W
MTWPR-2475W
MTWPA-24MCCH
ZNH
NS-121575W
NS-241575W
NS-24MCW
NS-24MCC
NS-24MCCH
ZNS-MCW
ZNS-MCWH
ZNS-24MCC

xx
xx
x
x

x

x

x

x

x
x
xx
xx
xx
xx
xx

x
xx

x

x

x
xx
xx
xx
xx
xx
xx
xx
x
xx
xx
xx
xx
xx
xx
xx
xx

36 5895XL Manual - P/N 151142-L8:L 08/09/2017

Notification Appliances Compatible Devices

Manufacturer Model Audio Visual Type

Horn/Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Strobe
Multi-Cd Strobe
Multi-Cd Strobe
Multi-Cd Strobe
Multi-Cd Strobe
Strobe Weatherproof
Strobe Weatherproof
Strobe Weatherproof
Strobe Weatherproof
Strobe Weatherproof
Strobe Weatherproof
Strobe Weatherproof

Wheelock
(cont.)

ZNS-24MCCH
RSS-121575W
RSS-241575W
RSS-24MCC
RSS-24MCCR
RSS-24MCCH
RSS-24MCCHR
RSS-24MCW
RSS-24MCWH
RSSP-121575W
RSSP-241575W
RSSR-2415W
RSSR-2415C
RSSR-2475W
RSSR-2475C
RSSR-24110C
RSSA-24110W
RSSB-24110W
RSSG-24110W
RSSR-24110W
RSSA-24MCC
RSSB-24MCC
RSSG-24MCC
RSSR-24MCC
RSSWPA-2475W
RSSWPA-24MCCH
RSSWPG-24MCCH
RSSWPR-24MCCH
RSSWP-2475W
RSSWP-2475C
RSSWP-24MCWH

xx

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

x

5895XL Manual - P/N 151142-L8:L 08/09/2017 37

Compatible Devices Two-Wire Smoke Detectors

Manufacturer Model Audio Visual Type

Strobe
Strobe
Strobe
Motor Bell
Motor Bell
Motor Bell
Motor Bell
Mini-Horn
Multitone Horn
Multitone Horn
Strobe
Multitone Horn Strobe
Horn
Horn/Strobe
Horn/Strobe
Strobe
Strobe
Horn
Horn

Wheelock
(cont.)

ZRS-MCWH
ZRS-24MCC
ZRS-24MCCH
MB-G6-24
MB-G10-24
MB-G6-12
MB-G10-12
MIZ-24-R
MT-12/24-R
MT4-12/2z
ZRS-MCW
MTWPR-24MCCH
NH-12/24R
HSR
HSW
STR
STW
HNR
HNW

x

x

x
x
x
x
x
x
xx
xx

x
xx
x

x

x

x

x

x

x

A.2 Two-Wire Smoke Detectors

TableA.1 lists two-wire smoke detectors that are compatible with the panel. The table is organized by manufacturer. The columns show
the number of detectors per loop that can be used.

The maximum number of smoke detectors per zone is determined by both the current draw and the impedance of the smoke detector. If
too many smoke detectors are used on any zone, false alarms could occur .

Do not mix different models of detectors on any zone; false alarms could occur.

Do not mix detectors of different models unless the system is specifically intended to be installed in that configuration.

Control unit Smoke Reset Time must be programmed for a number greater than or equal to the maximum reset time of the smoke detec­tor.

Table A.1 lists two-wire smoke detectors that are compatible with the 5895XL panel. The table is organized by manufacturer. The col­umns show the number of detectors per loop that can be used.

Manufacturer

Apollo

(Base model name or number in

55000-350 (45681-200) 55000-350 45681-200 24 / loop
55000-250 (45681-200) 55000-250 45681-200 24 / loop

Table A.1 Compatible Two-Wire Smoke Detectors

Identifier

Operating Voltage Range

Model Name or Number

parentheses.)

5895XL

24H

18.5–27.4 VDC

Compatibility ID

Head Base

# per Loop

38 5895XL Manual - P/N 151142-L8:L 08/09/2017

Two-Wire Smoke Detectors Compatible Devices

Manufacturer

Detection Systems

ESL

Kidde-Fenwall

Falcon

Faraday

Model Name or Number

(Base model name or number in

parentheses.)

DS200 (MB200-2W) A A 30 / loop
DS200HD (MB200-2W) A A 30 / loop
DS230 N/A N/A 30 / loop
DS250 (MB2W or MB2WL) B A 30 / loop
DS250HD (MB2W or MB2WL) B A 30 / loop
DS250TH (MB2W or MB2WL) B A 30 / loop
DS282 B N/A 30 / loop
DS283 (MB2W or MB2WL) N/A N/A 30 / loop
DS283TH (MB2W or MB2WL) N/A N/A 30 / loop
425 (S10) 30 / loop
425C (S11) 30 / loop
425CR (S11) 30 / loop
425CRT (S11) 30 / loop
425CT (S11) S10 N/A 30 / loop
429C (S10A) N/A S10A 30 / loop
429CRT (S11A) N/A S11A 30 / loop
429CST (S11A) N/A S11A 30 / loop
429CT (S10A) N/A S10A 30 / loop
521BXT N/A S11A 30 / loop
521B N/A S11A 30 / loop
609U01-11 S10 S00 40 / loop
609U02-11 S10 S00/S03 40 / loop
611U (601U or 602U) S10 S00/S03 40 / loop
611UD (601U or 602U) S10 S00/S03 40 / loop
611UT (601U or 602U) S10 S00/S03 40 / loop
612U (601U or 602U) S10 S00/S03 40 / loop
612UD (601U or 602U) S10 S00/S03 40 / loop
711U (701E or 701U) N/A S10A 25 / loop
712U (701E or 701U) N/A S10A 25 / loop
713-5U (702E or 701U) N/A S10A 25 / loop
713-6U (702E or 701U) N/A S10A 25 / loop
721-U (S10A) N/A S10A 30 / loop
721-UT (S10A) N/A S10A 30 / loop
PSD 7156 (FE01A) (P56FE1) P56FE1 FE01A 30 / loop
PSD 7156 (FE51A) (P56FE1) P56FE1 FE51A 30 / loop
PSD 7155 (FE01A) (P55FE1) P55FE1 FE1A 30 / loop
PSD 7155 (FE51A) (P55FE1) P56FE1 FE1A 30 / loop
CPD 7051 (FE01A) (I51FE1) CPD 7051 FE51A 30 / loop
CPD 7051 (FE01A) CPD 7051 FE01A 30 / loop
CPD 7051 (FE51A) CPD 7051 FE51A 30 / loop
525 FDT1 N/A 17 / loop
525T FDT1 N/A 17 / loop
9374 30 / loop
9375 30 / loop
9376 30 / loop

Compatibility ID

Head Base

# per Loop

Table A.1 Compatible Two-Wire Smoke Detectors

5895XL Manual - P/N 151142-L8:L 08/09/2017 39

Compatible Devices Two-Wire Smoke Detectors

Manufacturer

Hochiki

System Sensor

System Sensor
(cont.)

Model Name or Number

(Base model name or number in

parentheses.)

Compatibility ID

Head Base

# per Loop

SIH-24F (HS-224D OR HSD-224) HD-3 HB-5 30 / loop
SLK-12 30 / loop
SLK-24F (HS-224D) HD-3 HB-5 30 / loop
SLK-24FH (HS-224D) HD-3 HB-5 30 / loop
SLR-24 V 30 / loop
SLR-835B-2 (HD-6) 30 / loop
1100T A N/A 30 / loop
1100TB A N/A 30 / loop
1151 (110LP) A A 30 / loop
1400 A N/A 20 / loop
1451 (B401B) A A 20 / loop
1800 A N/A 30 / loop
1851B (B101B) A A 30 / loop
1851DH (DH1851DC) A A 30 / loop
2100 A N/A 30 / loop
2100D A N/A 30 / loop
2100S A N/A 30 / loop
2100T A N/A 30 / loop
2100TB A N/A 30 / loop
2100TS A N/A 30 / loop
2151 (B110LP) A N/A 30 / loop
2300T A N/A 30 / loop
2300 A N/A 30 / loop
2300TB A N/A 30 / loop
2400 A N/A 30 / loop
2400 (DH400) A N/A 30 / loop
2400AIT A N/A 30 / loop
2400AT A N/A 30 / loop
2400TH A N/A 30 / loop
2451 (B401B) A N/A 30 / loop
2451DH (DH 400) A N/A 30 / loop
2451TH (B401B) A N/A 30 / loop
2800 A N/A 30 / loop
2800TH A N/A 30 / loop
2851B (B101B) A A 30 / loop
2851BTH (B101B) A A 30 / loop
2851DH A A 30 / loop
2851TH (B101B) A A 30 / loop

3

2W-B A N/A 30 / loop

i

3

2WT-B A N/A 30 / loop

i

Table A.1 Compatible Two-Wire Smoke Detectors

40 5895XL Manual - P/N 151142-L8:L 08/09/2017

Four-Wire Smoke Detectors/Devices (UL Listed) Compatible Devices

A.3 Four-Wire Smoke Detectors/Devices (UL Listed)

Table A.2 Compatible Four-Wire Smoke Detectors

Smoke Detector/Base Detector Type

Max Standby
Current (mA)

Alarm Current

Fenwal CPD-7021 (w/70-201000-005 Base) Ionization 0.10 *
Fenwal PSD-7125 Photoelectric 0.10 *
Fenwal PSD-7126 (w/70-201000-005 Base) Photoelectric 0.10 *
Fire-Lite BLP-12-4W Base * *
Gentex 824 Photoelectric 0.50 *
Gentex 824T Photoelectric 0.50 *
Gentex 824CP Photoelectric 0.50 *
Gentex 824CPT Photoelectric 0.50 *
Hochiki HSC-4R Base * *
Hochiki SPB-24 Projected Beam 0.25 *
System Sensor B112LP Base 0.12 36
System Sensor B114LP Base * *
System Sensor B404B Base * *
System Sensor DH100ACDC Photoelectric 0.15 0.70
System Sensor DH100ACDCLP Photoelectric 0.15 0.70
System Sensor DH100ACDCLWP Photoelectric 0.15 0.70
System Sensor DH400ACDCI Ionization Duct 25 95
System Sensor DH400ACDCP Photoelectric Duct 25 95
System Sensor 1112/24/D Ionization 0.05 50
System Sensor 1424 Ionization 0.10 41
System Sensor 1451 (w/B402B Base) Ionization 0.10 39
System Sensor 2112/24ATR Photoelectric 0.50 60/70
System Sensor 2112/24AITR Photoelectric 0.50 60/70
System Sensor 2112/24/D Photoelectric 0.05 50
System Sensor 2112/24R Photoelectric 0.50 60/70
System Sensor 2112/24TR Photoelectric 0.50 60/70
System Sensor 2112/24T/D Photoelectric w/135° Thermal 0.05 50
System Sensor 2112/24TSRB Photoelectric w/135° Thermal

15 45

Supervisory Relay
System Sensor 2312/24TB Photoelectric 0.12 50
System Sensor 2412 (12 volt) Photoelectric 0.12 77
System Sensor 2412AT (12 volt) Photoelectric 0.12 58
System Sensor 2412TH (12 volt) Photoelectric 0.12 77
System Sensor 2424 Photoelectric 0.10 41
System Sensor 2424TH Photoelectric 0.10 41
System Sensor 2451 Photoelectric 0.10 39
System Sensor 2451TH (with/B402B Base) Photoelectric 0.10 39
System Sensor 2W-MOD Loop Test/Maintenance Mod. 30 50
System Sensor 4W-B (12/24 Volt) Photoelectric I
System Sensor4WT-B (12/24 Volt) Photoelectric I
System Sensor 4WTA-B (12/24 Volt)
System Sensor 4WTR-B (12/24 Volt) I
System Sensor 4WTAR-B (12/24 Volt) I

I3 Photo w/ Therm Sounder

3

Photo w/ Therm/Relay .05 35

3

Photo w/

3
3

w/Therm .05 23

.05 23

.05 35

.05 50

Therm/Sounder/Relay
System Sensor 4WITAR-B (12/24 Volt) I

Photo w/ Isolated

.05 50

3

Therm/Sounder/Relay

3

System Sensor 2W-MOD2 I
System Sensor RRS-MOD I

Loop Test/Maintenance Mod. .05 *

3

Reversing Relay/Sync Module .05 *

(mA)

5895XL Manual - P/N 151142-L8:L 08/09/2017 41

Compatible Devices Door Holders (UL Listed)

Table A.2 Compatible Four-Wire Smoke Detectors

Smoke Detector/Base Detector Type

System Sensor 6424 Projected Beam 10 28.4
System Sensor Beam 1224(S) Projected Beam 17 38.5
* Contact manufacturer for current draws

A.4 Door Holders (UL Listed)

TableA.4 lists door holders that are compatible with the fire control panel.

Manufacturer Model Type

Edwards DH150A Floor Mount 96
Edwards DH154A Flush Mount 96
Edwards DH158A Surface Mount 96
Rixon Firemark FM-980 Floor Mount, single 68
Rixon Firemark FM-996 Surface Wiring 68
Rixon Firemark FM-998 Concealed Wiring 68

A.5 Relays (UL Listed)

Table A.5 lists relays compatible with the fire control panel.

Air Products & Controls, LTD MR-101/C

System Sensor A77-716B

Max Standby
Current (mA)

Table A.3 Compatible Door Holders

T able A.4 Compatible Relays

Manufacturer Model Current (mA)

15
MR-201/C
PAM-1
PAM-2
PAM-SD

PR-1
PR-2
PR-3
EOLR-1
R-10T
R-14T
R-20T
R-24T
R-10E
R-14E
R-20E
R-24E

35

15

15

15

20

15

30

30

30

23

23

40

40

23

23

40

40

Alarm Current

(mA)

Current

(mA)

42 5895XL Manual - P/N 151142-L8:L 08/09/2017

Compatible 520Hz Signaling Speakers Compatible Devices

A.6 Compatible 520Hz Signaling Speakers

Model Number Description

System Sensor Model Number Description

SPR Wall High-Fidelity Speaker, Red
SPW Wall High-Fidelity Speaker, White
SPCR Ceiling High-Fidelity Speaker, Red
SPCW Ceiling High-Fidelity Speaker, White
SPSR Wall High-Fidelity Speaker Strobe, Red
SPSRH Wall High-Fidelity Speaker Strobe, High Candela, Red
SPSW Wall High-Fidelity Speaker Strobe, White
SPSCR Ceiling High-Fidelity Speaker Strobe, Red
SPSCW Ceiling High-Fidelity Speaker Strobe, White
SPSCWH Ceiling High-Fidelity Speaker Strobe, High Candela, White
SPSCRH Ceiling High-Fidelity Speaker Strobe, High Candela, Red
SPSCW-CLR-ALERT Ceiling High-Fidelity Speaker Strobe, Clear Lens, ALERT, White
SPSCW-P Ceiling High-Fidelity Speaker Strobe, Plain, White
SPSCWH-P Ceiling High-Fidelity Speaker Strobe, High Candela, Plain, White
SPSR-P Wall High-Fidelity Speaker Strobe, Plain, Red
SPSRH-P Wall High-Fidelity Speaker Strobe, High Candela, Plain, Red
SPSCWH-P Ceiling High-Fidelity Speaker Strobe, High Candela, Plain, White
SPSW-ALERT Wall High-Fidelity Speaker Strobe, Amber Lens, ALERT, White
SPSW-CLR-ALERT Wall High-Fidelity Speaker Strobe, Clear Lens, ALERT, White
SPSW-P Wall High-Fidelity Speaker Strobe, Plain, Red
SPSWH Wall High-Fidelity Speaker Strobe, High Candela, White
SPSWH-P Wall High-Fidelity Speaker Strobe, High Candela, Plain, Red
SPCRL Ceiling High-Fidelity Speaker, Red
SPCWL Ceiling High-Fidelity Speaker, White
SPRL Wall High-Fidelity Speaker, Red
SPWL Wall High-Fidelity Speaker, White
SPSCRL Ceiling High-Fidelity Speaker Strobe, Red
SPSCWL Ceiling High-Fidelity Speaker Strobe, White
SPSRL Wall High-Fidelity Speaker Strobe, Red
SPSRL-SP Wall High-Fidelity Speaker Strobe, FUEGO
SPSWL Wall High-Fidelity Speaker Strobe, White
SPSCWL-P Ceiling High-Fidelity Speaker Strobe, Standard, White, Plain
SPSRL-P Wall High-Fidelity Speaker Strobe, Standard, Red, Plain
SPSWL-P Wall High-Fidelity Speaker Strobe, Standard, White, Plain
SPSCWL-CLR-ALERT Ceiling High-Fidelity Speaker Strobe, Clear Lens, Standard, White, ALERT
SPSWL-ALERT Wall High-Fidelity Speaker Strobe, Amber Lens, ALERT, White
SPSWL-CLR-ALERT Wall High-Fidelity Speaker Strobe, Clear Lens, Standard, White, ALERT

*F=FIRE, P=PLAIN, AL=ALERT, AG=AGENT, EV=EVAC, SP=FUEGO, PG=FOGO

A.7 Compatible 520Hz Low Frequency Bases

Model Number Description

B200S-LF Low Frequency Intelligent Sounder Base
B200SR-LF Low Frequency Intelligent Sounder Base

5895XL Manual - P/N 151142-L8:L 08/09/2017 43

Honeywell Fire Product Warranty and Return Policy

General Terms and Conditions

• All new fire products manufactured by Honeywell have a limited warranty period of 36 months from the
date of manufacture against defects in materials and workmanship. See limited warranty statement for
details.

• This limited warranty does not apply to those products that are damaged due to misuse, abuse, negligence,
exposure to adverse environmental conditions, or have been modified in any manner whatsoever.

Repair and RMA Procedure

• All products that are returned to Honeywell for credit or repair require a RMA (Return Authorization)
number. Call Customer Service at 800-328-0103 or 203-484-7161 between 8:00 A.M. and 5:00 P.M. EST,
Monday through Friday to obtain a return authorization number.

• Honeywell Technical Support is available at 800-446-6444 between 8:00 A.M. and 5:00 P.M. CST, Monday
through Friday.

• All returns for credit are subject to inspection and testing at the factory before actual determination is made
to allow credit.

• RMA number must be prominently displayed on the outside of the shipping box. See return address example
under Advanced Replacement Policy.

• Included with each return should be: a packing slip that has the RMA number, a content list, and a detailed
description of the problem.

• All products returned by Honeywell must be sent freight pre-paid. After the product is processed, Honeywell
will pay for shipping product back to customer via UPS ground.

• Return the Honeywell product circuit board only. Products that are returned in cabinets will be charged an
additional $50 to cover the extra shipping and handling costs over board only returns. Do not return
batteries. Honeywell has the authority to determine if a product is repairable. Products that are deemed un­repairable will be returned to the customer.

• Product that is returned that has a board date code more than 36 months from date of manufacture will be
repaired and the customer will be assessed the standard Honeywell repair charge for that model.

Advanced Replacement Policy

• Honeywell offers an option of advance replacement for fire product printed circuit boards that fail during the
first 6 months of the warranty period. These items must be returned with transportation charges prepaid and
must be accompanied by a return authorization.

• For advance replacement of a defective board, contact your local Honeywell distributor or call Honeywell at
800-328-0103 to obtain a RMA (Return Authorization) numb er and request advanced replacement.

• A new or refurbished board will be shipped to the customer. The customer will initially be billed for the
replacement board but a credit will be issued after the repairable board is received at Honeywell. All
returned products must comply with the guidelines described under “General Terms and Conditions” and
“Repair and RMA Procedure”.

• The defective board must be returned within 30 days of shipment of replacement board for customer to
receive credit. No credit will be issued if the returned board was damaged due to misuse or abuse.

• Repairs and returns should be sent to:
Honeywell Fire Systems
Attn: Repair Department / RA Number_______________________
12 Clintonville Road
Northford, CT 06472 USA

Manufacturer Warranties and Limitation of Liability

Manufacturer Warranties. Subject to the limitations set forth herein, Manufacturer warrants that the Products
manufactured by it in its Northford, Connecticut facility and sold by it to its authorized Distributors shall be free,
under normal use and service, from defects in material and workmanship for a period of thirty six months (36)
months from the date of manufacture (effective Jan. 1, 2009). The Products manufactured and sold by
Manufacturer are date stamped at the time of production. Manufacturer does not warrant Products that are not
manufactured by it in its Northford, Connecticut facility but assigns to its Distributor, to extent possible, any
warranty offered by the manufacturer of such product. This warranty shall be void if a Product is altered, service
repaired by anyone other than Manufacturer or its authorized Distributors. This warranty shall also be void if
there is a failure to maintain the Products and the systems in which they operate in proper working conditions.

MANUFACTURER MAKES NO FURTHER WARRANTIES, AND DISCLAIMS ANY AND ALL OTHER
WARRANTIES, EITHER EXPRESSED OR IMPLIED, WITH RESPECT TO THE
PRODUCTS,TRADEMARKS, PROGRAMS AND SERVICES RENDERED BY MANUFACTURER
INCLUDING WITHOUT LIMITATION, INFRINGEMENT, TITLE, MERCHANTABILITY, OR FITNESS
FOR ANY PARTICULAR PURPOSE. MANUFACTURER SHALL NOT BE LIABLE FOR ANY PERSONAL
INJURY OR DEATH WHICH MAY ARISE IN THE COURSE OF, OR AS A RESULT OF, PERSONAL,
COMMERCIAL OR INDUSTRIAL USES OF ITS PRODUCTS.

This document constitutes the only warranty made by Manufacturer with respect to its products and replaces all
previous warranties and is the only warranty made by Manufacturer. No increase or alteration, written or verbal,
of the obligation of this warranty is authorized. Manufacturer does not represent that its products will prevent any
loss by fire or otherwise.

Warranty Claims. Manufacturer shall replace or repair, at Manufacturer's discretion, each part returned by its
authorized Distributor and acknowledged by Manufacturer to be defective, provided that such part shall have
been returned to Manufacturer with all charges prepaid and the authorized Distributor has completed
Manufacturer's Return Material Authorization form. The replacement part shall come from Manufacturer's stock
and may be new or refurbished. THE FOREGOING IS DISTRIBUTOR'S SOLE AND EXCLUSIVE REMEDY
IN THE EVENT OF A WARRANTY CLAIM.

Warn-HL-08-2009.fm

Honeywell Silent Knight

12 Clintonville Road
Northford, CT 06472-1610

203.484.7161
www.silentknight.com

151142-L8 | L | 10/17
©2018 Honeywell International Inc.
