Honeywell HZ0360 User Manual

360° SURROUND HEATER™

Model HZ-0360 Series

The Honeywell trademark is used by Kaz USA Inc. under license from Honeywell International Inc.

Honeywell International Inc. makes no representation or warranties with respect to this product

IMPORTANT SAFETY
INSTRUCTIONS

WARNING – READ AND SAVE THESE SAFETY
INSTRUCTIONS BEFORE USING THIS HEATER.
IF YOU DO NOT UNDERSTAND THESE
INSTRUCTIONS OR PRODUCT LABELS
DO NOT USE THIS PRODUCT AND CALL
US AT [phone] FOR AN EXPLANATION.

Warning – Failure to follow any of these safety
instructions could result in fire, injury or death.

YOUR RESPONSIBILITIES

Electrical appliances may expose people to
hazards that can cause severe injury as well as
death. The use of electrical products may create
hazards that include, but are not limited to,
injury, fire, electrical shock and electrical system
damage. These instructions are intended to
provide you with the information you need to
use the product and to avoid such hazards.

1. Warning – Read all instructions before
using this heater.

2. Warning – This heater is hot when in use.
To avoid burns, do not let bare skin touch
hot surfaces. If, provided, use handle when
moving this heater. Keep combustible
materials, such as furniture, pillows,
bedding, papers, clothes, and curtains at
least 3 feet (0.9 m) from the front of the

heater and keep them away from the sides
and rear.

3. Warning – Extreme caution is necessary
when any heater is used by or near children,
pets or invalids, or whenever the heater is
left operating and unattended.

4. Warning – Always unplug heater when not
in use.

5. Warning – Do not operate any heater with a
damaged cord or plug or after the heater
malfunctions, has been dropped or
damaged in any manner.

6. Warning – Do not use outdoors.

7. Warning – This heater is not intended for

use in bathrooms, laundry areas and similar
indoor locations. Never locate heater where
it may fall into a bathtub or other water
container.

8. Warning – Do not run cord under carpeting.
Do not cover cord with throw rugs, runners,
or the like. Arrange cord away from traffic
area where it will not be tripped over.

9. Warning – This appliance has a polarized
plug (one blade is wider than the other).
To reduce the risk of shock, this plug is
intended to fit only one way in a polarized
outlet. If the plug does not fit securely in the
outlet, reverse the plug. If it still does not
fit, contact a qualified electrician.

DO NOT attempt to defeat this safety feature.

10. Warning – This heater draws 12.5 amps

during operation when in the high setting.
To prevent overloading a circuit, do not plug
the heater into a circuit that already has
other appliances working.

11. Warning – It is normal for the plug to feel
warm to the touch; however, a loose fit
between the AC outlet (receptacle) and plug
may cause overheating and distortion of the
plug. Contact a qualified electrician to
replace a loose or worn outlet.

HZ-0360_OM v7.0.qxd:HZ-2200-3200-3220_OM_Rev1 4/15/10 12:08 PM Page 1

12. Warning – To disconnect the heater, first
turn off the product, then grip the plug and
pull it from the wall outlet. Never pull by the
cord.

13. Warning – Do not insert or allow foreign
objects to enter any ventilation or exhaust
opening as this may cause an electric shock
or fire, or damage the heater.

14. Warning – To prevent a possible fire, do not
block air intakes or exhaust in any manner.
Do not use on soft surfaces, like a bed, or
where openings may become blocked.

15. Warning – A heater has hot and arcing or
sparking parts inside. Do not use it in the
areas where gasoline, paint or flammable
liquids are used or stored.

16. Warning – Use this heater only as described
in this manual. Any other use not
recommended by the manufacturer may
cause fire, electric shock, or injury to
persons.

17. Warning – Avoid the use of an extension
cord because the extension cord may
overheat and cause a risk of fire. However, if
you have to use an extension cord, the cord
shall be No. 14 AWG minimum size and
rated not less than 1875 watts. The
extension cord shall be a three wire cord
with a grounding-type cord and plug
connector.

18. Warning – Never tamper with this product
or attempt to fix it. Any tampering with, or
modification of, this product can result in
serious injury, death, or fire. Risk of electric
shock. Do not open, no user serviceable
parts inside.

19. Warning – Do not remove product labels
that contain warnings or safety instruction.

20. Caution – The output of this heater may
vary and its temperature may become
intense enough to burn exposed skin.
Use of this heater is not recommended for
persons with reduced sensitivity to heat or
an inability to react to avoid burns.

21. Caution – Before cleaning, or storage, or
when not in use, turn the fan to the off
position and unplug the heater from the
electrical outlet and allow it to cool.

22. Caution – Place the heater on a firm, level,
open surface free from obstructions and at
least 3 feet (0.9 m) away from any
combustible materials. DO NOT use on an
unstable surface such as bedding or deep
carpeting. Be sure the heater is not in a
position where it may be tripped over by
small children or pets. The heater’s rubber
feet will hold it firmly in position.

23. Caution – If your home has aluminum
wiring have a licensed electrician check
your receptacle’s connections. When using
any 1500 watt heater, aluminum wire
connections can cause a safety issue.

24.

SAVE THESE
INSTRUCTIONS

HZ-0360_OM v7.0.qxd:HZ-2200-3200-3220_OM_Rev1 4/15/10 12:08 PM Page 2

• Place the heater on a firm, level, open surface free from obstructions and at least 3 feet (0.9m)
away from any wall or any combustible material. DO NOT use on an unstable surface such as
bedding or deep carpeting.

BE SURE THE HEATER IS NOT IN A POSITION WHERE IT MAY BE TRIPPED OVER BY
CHILDREN OR PETS.

SET-UP

• Turn off the heater.

• Allow it to cool for ten minutes.

• Unplug heater and move.

MOVING THE HEATER

OPERATION

• NOTE: The 360° Surround Heater™ requires no assembly.

• NOTE: NEVER LEAVE AN OPERATING UNIT UNATTENDED

• The 360° Surround Heater™ is designed to disperse heat in a
360° range.

• With the Power Knob in the OFF (

o) position, plug the heater

into a polarized 120V outlet.
DO NOT FORCE THE POLARIZED PLUG INTO THE OUTLET;
it will only fit one way.

• The Power Knob is equipped with three (3) settings:

Fan Only ( )
Low ( )
High ()

The Low ( ) setting uses 750 watts of power and the High ( ) setting uses 1500 watts of
power. Fan Only ( ) setting uses 19 watts of power. You can select the proper setting to
accommodate your comfort level with the Power Knob. When you choose any setting the amber
Power Light will come on. Because the Low ( ) setting does not require as much electricity to
operate, it is more energy efficient and may be a better option if you are concerned about the
amperage draw on a circuit when the heater is on the High ( ) setting.

• Turn the Thermostat Control fully clockwise to the highest ( ) setting.

• When the room reaches a comfortable temperature, slowly turn the Thermostat Control
counter-clockwise until the heating element goes off (the amber Power Light will not be shut off).
This is the point at which the Thermostat setting equals the room temperature. At this setting,
the Thermostat will automatically turn the heater on and off to maintain the selected temperature.

• Turn the Power Knob to OFF (

o) and unplug the heater when you are finished using it.

Fig. 1

Power Knob

Thermostat Control

Power

Light

HZ-0360_OM v7.0.qxd:HZ-2200-3200-3220_OM_Rev1 4/15/10 12:08 PM Page 3

SAFETY FEATURES

The 360° Surround Heater™ is equipped with several devices and features for added protection:

• 360° SafetyTIP™ is an all-around tip-over switch that disables the heater if it is accidentally

tipped in any direction.

• A high temperature safety control prevents overheating.

• This heater is also equipped with a thermal cut-off fuse that will permanently shut down the

heater should it operate at a higher than normal temperature.

• This heater was created using a high quality safety plastic.

CLEANING

We recommend that the 360° Surround Heater™ be cleaned at least once a month and before
off-season storage.

• Turn the heater OFF (

o) and unplug it. Allow it to cool.

• Use a dry cloth only to clean the external surfaces of the heater. DO NOT USE WATER, WAXES,

POLISHES OR ANY CHEMICAL SOLUTION.

STORAGE

• Clean your 360° Surround Heater™ using the above-mentioned steps. Wrap the cord around the

unit. Place in its original box and store it in a cool, dry place.

• This heater does not disassemble.

TROUBLESHOOTING

If your 360° Surround Heater™ shuts off unexpectedly or fails to operate, one of your heater safety
features may have been activated to prevent overheating.

• Be sure it is plugged in and that the electrical outlet is working.

• Check your Thermostat Control setting. The unit may simply be off because you have reached

your desired heat setting.

• Check for any obstructions. If you find an obstruction, turn the heater OFF (

o) and unplug it.

Allow the heater to cool completely, then remove the obstruction. Wait at least 10 minutes, then
re-plug the heater in and follow the OPERATION instructions.

ELECTRICAL RATING

This product is rated 12.5 Amps (1500 watts) @ 120V, 60Hz.

HZ-0360_OM v7.0.qxd:HZ-2200-3200-3220_OM_Rev1 4/15/10 12:08 PM Page 4

You should first read all instructions before
attempting to use this product.

A. This 3 year limited warranty applies to

repair or replacement of product found to
be defective in material or workmanship.
This warranty does not apply to damage
resulting from commercial, abusive,
unreasonable use or supplemental damage.
Defects that are the result of normal wear
and tear will not be considered
manufacturing defects under this warranty.

KAZ IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE.
ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE ON THIS PRODUCT IS
LIMITED IN DURATION TO THE DURATION OF
THIS WARRANTY. Some jurisdictions do not

allow the exclusion or limitation of
incidental or consequential damages or
limitations on how long an implied warranty
lasts, so the above limitations or exclusions
may not apply to you. This warranty gives
you specific legal rights, and you also may
have other rights which vary from
jurisdiction to jurisdiction. This warranty
applies only to the original purchaser of this
product from the original date of purchase.

B. At its option, Kaz will repair or replace this

product if it is found to be defective in
material or workmanship.

C. This warranty does not cover damage

resulting from any unauthorized attempts to
repair or from any use not in accordance
with the instruction manual.

D. Return defective product to Kaz,

Incorporated with a brief description of the
problem. Include proof of purchase and a
$10 US/$15.50 CAN check or money order
for handling, return packing and shipping
charges. Please include your name, address
and a daytime phone number.

You must prepay shipping charges.

We suggest having tracking or delivery
confirmation. Send to:

In U.S.:

Kaz USA, Inc.
Attn: Returns Department
4755 Southpoint Drive
Memphis, TN 38118
USA

In Canada:

Kaz Canada, Inc.
Attn: Returns Department
510 Bronte Street South
Milton, ON L9T 2X6
Canada

3 YEAR LIMITED WARRANTY

CONSUMER RELATIONS

Mail questions or comments to:

Kaz USA Inc.
Consumer Relations Dept.
250 Turnpike Road
Southborough, MA 01772

Call us toll-free at: 1-800-477-0457
E-mail: [e-mail]

Or visit our website at: www.kaz.com

Please be sure to specify a model number.

NOTE: IF YOU EXPERIENCE A PROBLEM, PLEASE CONTACT CONSUMER RELATIONS FIRST OR SEE
YOUR WARRANTY. DO NOT RETURN THE HEATER TO THE ORIGINAL PLACE OF PURCHASE. DO NOT
ATTEMPT TO OPEN THE MOTOR HOUSING YOURSELF, DOING SO MAY VOID YOUR WARRANTY AND
CAUSE DAMAGE TO THE PRODUCT OR PERSONAL INJURY.

© 2010 Kaz, Incorporated. All Rights Reserved.

P/N: 3IM306N191

HZ-0360_OM v7.0.qxd:HZ-2200-3200-3220_OM_Rev1 4/15/10 12:08 PM Page 5
