Honeywell EXCEL 12 FCU + LIGHT + SUNBLIND PRODUCT DATA

Excel 12

INTEGRATED ROOM CONTROL SOLUTIONS: FCU + LIGHT + SUNBLIND

PRODUCT DATA

FEATURES

 Three-in-one controller for HVAC, Light, and Sunblind

applications reduces hardware costs and engineering

ONWORKS® node instead of three).

ONWORKS

®

bus interface.

ONWORKS® environments.

SUNBLIND

UP

DOWN

WINDOW

CONTACT

HVAC

HEATING

COOLING

VENTILATION

WALL MODULE

OCCUPANCY

CONDENSATION

Excel 12

Fig. 1. Functional overview

Light

LIGHT SENSOR

0...10 VON/OFF

0...10 VON/OFF

effort (one L

 Additional energy savings due to integrated room con-

trol, e.g. use of sunlight to heat unoccupied rooms.

 Increased comfort due to automatic light and sunblind

control depending on available light and occupancy.

 LonMark® certified.
 Flash memory for downloading applications (thus

increasing flexibility and facilitating future upgrading).

 Easily-accessible service button and service LED.
 DIN rail (wiring cabinet / fuse box) mounting and wall-

mounting supported.

 230 Vac, 100 Vac, or 24 Vac power supply (depending

upon model).

 Optional terminal protection covers for wall mounting.
 Optional swivel label holders for wiring information.
 2-wire FTT-10A L
 Application can be configured to user-specific needs

via LNS™-based plug-in.

GENERAL

Excel 12 controllers are LONMARK® certified devices, and can
thus be used in all open L

Excel 12 supports the following LONMARK® objects:

 1 Node Object (LONMARK® object #0).
 1 Space Comfort Controller Fan Coil Object (profile

#8501).

 2 Lamp Actuator Objects (profile #3040).
 1 Occupancy Sensor Object (profile #1060).
 1 Sunblind Actuator Object (object #4).

A variety of hardware models are available, with different
power supplies.

Page 6 provides a detailed overview of the available models.
Select the model fitting your particular needs.
The application can be downloaded into the unit's flash

memory.
Honeywell's LNS™ plug-in allows you to configure the

application to match your specific requirements (e.g. light
switching or constant light control [depending upon the
availability of daylight and/or the occupancy state]; sunblind
up/down depending upon daylight, occupancy, and wind
speed).

The Excel 12 controller is designed for maintained zones.

® U.S. Registered Trademark
Copyright © 2010 Honeywell Inc. • All Rights Reserved EN0B-0367GE51 R0110

EXCEL 12 FCU + LIGHT + SUNBLIND

APPLICATION

The Excel 12 Fan Coil Unit (FCU) + Light + Sunblind
application encompasses the entire room, including one fan
coil unit, two lights, and one sunblind.

The application is delivered together with the plug-in and must
be downloaded into the unit's flash memory during start-up.
Regardless of the given Excel 12 model, the user has the
option of choosing from among the many different available
Excel 12 applications. The user can customize the application
using Honeywell's LNS™ plug-in with CARE or any LNS™
tool (e.g. LonMaker for Windows™). Customizations can be
saved / reloaded for easy configuration of multiple devices.

Application Overview

One Fan-Coil Unit:

 Two sequences configurable for HEAT, COOL, and

CHANGEOVER.

 Support of thermal actuators, floating actuators, PWM,

0...10 Vdc, and staged output via triac outputs or relay
outputs.

 3-stage fan via triac outputs or relay outputs.
 Binary inputs for condensation, occupancy sensor,

window contact, etc.

Two Lights:

 ON / OFF switching dependent on:

 Occupancy sensor.
 Three effective occupancy modes (occupied / standby

/ unoccupied). Effective occupancy is determined on
the basis of the occupancy sensor, the schedule, and
override input (if any).

 Light level (determined on the basis of data received

via the L
sensor).

 Manual switching (via hardwired switches or

L

 Dimming / constant light control for two lights with just one

sensor. Dimming / constant light control is performed via
analog outputs (this requires an HFD [High-Frequency
Device] for dimming with 1...10 Vdc input).

One Sunblind:

 Positioning dependent on:

 The effective occupancy mode (occupied / standby /

unoccupied) determined by occupancy sensor, the
schedule, and override input (if any).

 Light level (determined on the basis of data received

via the L

 Manual command.
 Building supervisor command.

 Safety position dependent on:

 Frost / rain from weather station or XL500, etc.
 Wind speed (determined on the basis of data received

via the L

 Open windows (determined on the basis of data

received via the L
hardwired sensor) inhibit moving of sunblind.

ONWORKS® network or read from a hardwired

ONWORKS® wall module).

ONWORKS® network).

ONWORKS® network).

ONWORKS® network or read from a

Occupancy Modes:

 Occupied mode: The Excel 12 operates according to the

"occupied" heating and cooling set-points.

 Bypass: After the bypass button of a hardwired wall

module has been pressed or when corresponding data is
received via the L

ONWORKS® network, the Excel 12

operates temporarily according to the "occupied" heating
and cooling set-points. When the bypass time has
elapsed, the controller reverts to the previous mode. The
bypass time can be configured via plug-in.

 Standby mode: The Excel 12 operates according to the

"standby" heating and cooling set-points.

 Unoccupied mode: The Excel 12 operates according to

the "unoccupied" heating and cooling set-points.

 Occupancy sensor: The occupancy sensor is used for

FCU, light, and sunblind control. Hardwired and
L

ONWORKS® occupancy sensors are supported. The

occupancy sensor determines the effective occupancy
mode during scheduled occupied periods. Depending
upon the actual occupancy sensor state, the effective
mode will be either "occupied" or "standby."

Wall Modules:

 L

ONWORKS® wall modules.

 Hardwired wall modules (e.g. T7460, T7560).
 Wireless wall modules (e.g. W7070+T7270 or RT7070).

Master / Slave Functionality:

The master / slave functionality allows easy adaptation to
changed room usage.

nviEnergyHoldOff

SEQUENCE 0, POSITION *1

SEQUENCE 1, POSITION *1

nvoEnergyHoldOff

master

Excel 12

WINDOW CONTACT

*1: ONLY IF SEQUENCE IS CONFIGURED
*2: ONLY IF FAN IS CONFIGURED
*3: ONLY IF CHANGEOVER SEQUENCE IS CONFIGURED

nvoSequence [0]
nvoSequence [1]

nvoFanSpeed
nvoEffectOcc

nvoHeatCool

THIS NV ALWAYS BINDS THE MASTER XL12 TO THE FINAL SLAVE XL12.

MASTER

FANSPEED, POSITION *2

OCCUPANCY MODE

HEATING/COOLING POSITION *3

SLAVE
nviSequence [0]
nviSequence [1]

nvoFanSpeedCmd

nviOccManCmd

nviApplicMode

nvoEnergyHoldOff

slave

slave

Excel 12

Excel 12

WINDOW CONTACT

slave

Excel 12

WINDOW CONTACT

nviEnergyHoldOff

Fig. 2. Master/slave functionality and window contact

EN0B-0367GE51 R0110

2

EXCEL 12 FCU + LIGHT + SUNBLIND

master

Excel 12

nvoLampValue nviLampValue

LIGHT

nviLampValue

slave

Excel 12

slave

Excel 12

Fig. 3. All lights switched via master pushbutton

NOTE: Binding via LONWORKS results in a short delay

between the switching of the different lamps.

master

Excel 12

THIS NV ALWAYS BINDS THE MASTER XL12 TO THE FINAL SLAVE XL12.

nvoLampValue nvoLampValuenviLampValuenviLampValue

LIGHT LIGHT

nvoLampValue nviLampValue

slave

Excel 12

slave

Excel 12

LIGHT

Fig. 4. All lights switched on via any pushbutton

NOTE: This binding shall not be used for applications

involving dimming or constant light control. Binding
via L

ONWORKS results in a short delay between the

switching of the different lamps. Pressing the
pushbutton repeatedly and rapidly may cause toggle
effects.

master

Excel 12

nvoSblndSetting nviSblndSetting

LIGHT

nviSblndSetting

slave

Excel 12

slave

Excel 12

Fig. 5. All sunblinds controlled via master pushbuttons

NOTE: Binding via L

ONWORKS results in a short delay

between the switching of the different sunblinds.

Benefits of Integrated Room Control

The Excel 12's light management functionality provides you
with a number of significant advantages:

Considerable Reduction in Energy Consumption:

 25...75% savings on electrical energy consumption for

illumination.

 Decreased heat generated by electric lights or incoming

solar radiation (by closing sunblind), thus reducing cooling
energy requirements.

 Decreased electrical energy consumption due to constant

light control (see section "Constant Light Control" on page

7).

 Sunlight can be used to heat the room (sunblind up) if the

room is unoccupied and to avoid unnecessary cooling
demands (sunblind down), as needed.

Increased Convenience:

 Occupancy sensor switches the light ON/OFF

automatically.

 Constant light control always provides the correct lighting.
 The sunblind is lowered if the current outdoor light level

exceeds a configurable limit and is raised if the current
light outdoor level drops below the desired limit, or in case
of strong winds.

 Usage styles (e.g. presentation, working, etc.) can be

configured in conjunction with the Web Office Console.

 Wireless control via ZAPP (see ZAPP System

Engineering, EN0B-0286GE51).

Increased Flexibility:

 Flexible room usage if a L

ONWORKS® wall module or

ZAPP (wireless remote control) is used.

Reduced Engineering Effort / Expenses:

 Just one LONWORKS® node (instead of three) is required

to cover HVAC, Light, and Sunblind.
 reduced engineering and installation effort (e.g. wiring,

binding, commissioning, etc.)

 lower cost due to reduced number of LNS™ credits
 lower hardware total loop costs

Interoperability

See also section “Approvals, Certifications, and Standards”
on page 8.

Device Configuration

The controller is configured using Honeywell's LNS™ plug-in.
The plug-in can be started from CARE 4.0 or any LNS™ tool
(e.g. LonMaker for Windows™).

LONMARK® Objects Network Variables

The Excel 12 supports the following LONMARK® objects:

 1 node object (see Fig. 8)
 1 space comfort controller object (#8501 SCC – Fan Coil)

(see Fig. 6)

 2 lamp actuator objects (#3040) (see Fig. 9)
 1 occupancy sensor object (#1060) (see Fig. 7)
 1 sunblind / closed-loop actuator object (#4) (see Fig. 10).

Insofar as a generally agreed-upon LonMark® object is
not yet available, sunblind control is achieved in a generic
fashion.

See also Table 6 through Table 10 in section "Network
Interface" on page 8.

3 EN0B-0367GE51 R0110

EXCEL 12 FCU + LIGHT + SUNBLIND

Space Comfort Controller Object

Space Comfort

Controller Object

(Fan Coil Object profile #8501)

nviSpaceTemp
SNVT_temp_p

nviSetPoint

SNVT_temp_p

nviSetptOffset
SNVT_temp_p

nviOccSchedule

SNVT_tod_event

nviOccManCmd

SNVT_occupancy

nviOccSensor

SNVT_occupancy

nviApplicMode

SNVT_hvac_mode

nviFanSpeedCmd

SNVT_switch

nviEnergyHoldOff

SNVT_switch

1

mandatory

Network

Var iab les

2

3

5

6

7

8

10

14

optional

Network

Var iab le s

nvoSpaceTemp

SNVT_temp_p

nvoUnitStatus

SNVT_hvac_status

nvoEffectOcc

SNVT_occupancy

nvoHeatCool

SNVT_hvac_mode

nvoFanSpeed
SNVT_switch

nvoEnergyHoldOff

SNVT_switch

Node Object

26

27

29

30

33

49

nviRequest

SNVT_obj_request

nviLuxLight

SNVT_lux

nviLuxSblnd

SNVT_lux

nviWindSpeed

SNVT_speed

Lamp Actuator Object

nviLampValue
SNVT_switch

Node Object

(LonMark Object type no. 0)

mandatory

1

Network

Var iable s

optional
Network

Var iabl es

Network

Var iabl es

shared

among Objects

Fig. 8. Node Object

LonMark Lamp Actuator Object

(profile #3040)

mandatory

1

Network

Var iable s

nvoStatus

SNVT_obj_status

nvoFileDirectory

SNVT_address

nvoLampValueFb

SNVT_switch

2

8

2

nviSequence[0]

SNVT_lev_percent

nviSequence[1]

SNVT_lev_percent

manufacturer-

specific

Network

Variables

Fig. 6. Space Comfort Controller Object

Occupancy Sensor Object

LonMark Occupancy

Sensor Object
(profile #1060)

mandatory

Network

Var iab le s

Fig. 7. Occupancy Sensor Object

nvoSequence[0]

SNVT_lev_percent

nvoSequence[1]

SNVT_lev_percent

nvoOccSensor

SNVT_occupancy

nviOccManCmd

SNVT_occupancy

Network

nviLuxLight

SNVT_lux

nviOccSchedule

SNVT_tod_event

nviOccSensor

SNVT_occupancy

Var iabl es

shared

among Objects

Fig. 9. Lamp Actuator Object

1

EN0B-0367GE51 R0110

4

EXCEL 12 FCU + LIGHT + SUNBLIND

g

Sunblind Actuator Object

Sunblind Actuator Object

(LonMark Closed-Loop

Actuator Object) (object #4)

nviSblndSetting

SNVT_setting

nviSblndOvrd
SNVT_setting

nviSblndAuto
SNVT_setting

nviLuxSblnd

SNVT_lux

nviOccSchedule

SNVT_tod_event

nviOccSensor

SNVT_occupancy

nviEnergyHoldOff

SNVT_switch

nviWindSpeed

SNVT_speed

1

among Objects

mandatory

Network

Var iab les

manufacturer-

specific

Network

Variables

Network

Variables

shared

nvoSblndSetting

SNVT_setting

Fig. 10. Sunblind Actuator Object

LONWORKS® Network Interface

The Excel 12 communicates within the LONWORKS® network
at a rate of 78 kbs via an FTT-10A Free Topology
Transceiver, which provides transformer isolation; the bus
wiring is thus insensitive to polarity.

Devices so equipped can be wired in daisy chain, star, loop,
or any combination thereof as long as the max. wire length
requirements are met. The recommended configuration is a
daisy chain with two termination modules. This layout allows
for max. bus length and has the highest communication
reliability, particularly when adding on to an existing bus.
Refer also to http://www.echelon.com

Configuration and Binding

Configuration is performed using Honeywell's LNS™ plug-in,
which can be started from CARE 4.0 or any LNS™ tool (e.g.
LonMaker for Windows™). Likewise, binding is performed
using CARE 4.0 or any LNS™ tool.

LONWORKS® Service Button and LED

All models feature a LONWORKS® service button (accessible
from the outside on top of the module).

The service pin message is broadcast:
 whenever the L

ONWORKS® service button is pressed;

 after each reset due to power-up, software reset;

2

 if a hardwired push button for lighting or sunblind is

pushed for more than 10 seconds.

All models feature a L

ONWORKS® service LED for com-

missioning and troubleshooting. The service LED displays
numerous different behaviors indicating various module states
for use in troubleshooting.

See also Excel 12 Installation Instructions (EN1B-0201GE51)
for more-detailed information.

Priority of Received/Read Sunblind Input

Depending upon the last command received/read before the
wind speed exceeds the set limit, the sunblinds will either
return to the required position or remain in the UP position
(see Table 1). Fig. 11 presents the priorities of sunblind input
received/read by the Excel 12.

Table 1. Wind-dependent behavior of sunblinds

last command return to required pos. remain UP

UP/DOWN button -- YES
nviSblndSetting -- YES
nviSblndAuto YES -­nviSblndOvrd YES -­light sensor YES -­energy optimization YES --

LAST WINS

wall module(s) / sunblind push button(s)

Building Manager

nviSblndSetting

SNVT_setting

outdoor light sensor

nviLuxSblnd

SNVT_lux

e.g. XL500

nviSblndAuto
SNVT_setting

Xl12 (internal logic)

energy-saving

heating/cooling strategy

Building Manager

nviSblndOvrd
SNVT_setting

window contact

nviEnergyHoldOff

INCREASING PRIORITY

Fig. 11. Priority of sunblind input

wind sensor to “slave” controller

nviWindSpeed

SNVT_speed

SNVT_switch

nvoSblndSettin

SNVT_setting

5 EN0B-0367GE51 R0110

EXCEL 12 FCU + LIGHT + SUNBLIND

Models

Table 2. Overview of Excel 12 models

W7704A1004*1

W7704B1002*1

W7704C1000*1

W7704D1008

W7704D1016

W7704F1003*1*2

short housing

long housing

24 Vac

230 Vac

binary input 1

binary input 2

binary input 3

binary input 4

relay 1 (N-O)

relay 2 (N-O)

relay 3 (N-O)

relay 4 (C-O)

relay 5 (C-O)

triac 1

triac 2

triac 3

traic 4

triac 5

triac 6

wall module LED

output

AI1 (NTC20k + V)

AI2 (NTC20k)

AI3 (fan speed /

bypass)

AI4 (setpoint)

AI5 (NTC20k + V)

X X X X X X X X X X X X X X X X X X X X X X X X X

X X X X X X X X X X X X X X X X X X X X X X X X X X X

X X X X X X X X X X X X X X X X X X X X X X

X X XX X X X X XXXXXXXXX X XX X X X XXXX

X X XX X X X X XXXXXXXXX X XX X X X XXXX

X X X X X X X X X X X X X X

*1 These hardware versions have been discontinued.
*2 The hardware variant W7704F1003 is cost-optimized for light control and does not support hardwired wall modules.

Long and Short Housings

Models powered with line power (W7704A, B, D1016, and
D1024) are equipped with a built-in transformer and feature a
long housing (W X L X H = 180 X 76 X 110 mm).

Models powered with 24 Vac (W7704C, D1008, E1005)
require an external 24 Vac power supply and feature a short
housing (W X L X H = 126 X 76 X 110 mm).

Binary Inputs

The unit is equipped with four dry-contact binary inputs. The
binary inputs are fast (i.e. the signal must be stable for at
least 25 ms).

Binary Outputs

The triac outputs or relay outputs can be configured for
different functions.

Relay Outputs

The unit is equipped with up to two change-over (C-O) relays
and up to three normally-open (N-O) relays.

Analog Outputs

The unit is equipped with up to two 0...11 Vdc analog outputs
(with the exception of the W7704E1005, which supports only
a single such analog output), each of which can drive a max.
of ±1.1 mA.

Example: Floating Drives

You can configure the two triac outputs or two relays to
connect a floating drive (no mixing of triac outputs and relays
allowed). Once the outputs have been configured using
Honeywell's LNS™ plug-in, floating actuators can be directly
connected to them.

Analog Inputs

The unit is equipped with up to 7 analog inputs, all of which
can be configured as slow binary inputs (in which case the
signal must be stable for at least 1.25 sec) for the detection of
a slow signals (e.g. from a window contact).

Table 3. Analog input usage (with wall modules)

analog input voltage NTC wall module

AI1 X X
AI23 X room temperature1
AI33 fan speed or bypass2
AI43 set-point

AI5 X X

AI6 X
AI73 X X

1

For all NTC inputs, temperatures of  -50...-45 °C are interpreted as

being due to a sensor break, and temperatures of  +145...+155 °C
are interpreted as being due to a sensor short-circuit.

2

A contact open for  10 seconds is interpreted as a sensor failure.

3

A resistance of > 15k  is interpreted as being due to a sensor

break, a resistance of < 100  is interpreted as being due to a
sensor short-circuit.

Hardware Limits

 In order to ensure a reliable contact, a min. current of

50 mA is required.

 The normally-open contacts are designed for a max.

continuous current of 16 A. The normally-closed contacts
are designed for a max. continuous current of 1 A.

 In order to reduce the build-up of heat in the housing, the

max. combined allowable current flowing through all relays
simultaneously is 24 A (continuous).

 The max. peak in-rush current (20 ms) at the normally-

open contact is 80 A.

Triac Outputs

The unit is equipped with up to six triac outputs.

AI6 (NTC20k)

AI7 (NTC20k + V)

AO1 (0...10 Vdc)

AO2 (0...10 Vdc)

EN0B-0367GE51 R0110

6

EXCEL 12 FCU + LIGHT + SUNBLIND

Hardware Limits for Excel 12 with Line Power Supply

 Low signal: 0 V; high signal: 24 Vac
 Max. 250 mA continuous current in sum for all triac

outputs together

 550 mA for max. 10 sec.
 cos  > 0.5

Hardware Limits for Excel 12 with 24 Vac Power Supply

 Low signal: 0 V; high signal: 24 Vac
 Max. 500 mA continuous current in sum for all triac

outputs together

 800 mA for max. 10 sec.
 cos  > 0.5

NOTE: For controlling thermal actuators, we recommend

using the 24 Vac models, which provide more
current.

Constant Light Control

If, when configuring your Excel 12 application, you provide for
a light sensor (by selecting the "Daylight Sensing" checkbox
in the appropriate sub-screen of the plug-in), you must
specify, in lux, the desired minimum and maximum light levels
("Daylight: dark level" and "Daylight bright level, respectively).
The values you choose will then be used to switch the lights
ON and OFF.

NOTE: Do not select the “Auto Off Delay Timer” checkbox

insofar as this functionality is currently not supported.

NOTE: The light sensor employed for constant light control

must be suitable for artificial light, and should be
mounted more towards the corridor.

Constant light control helps save additional energy. Over their
lifecycle, fluorescent tubes normally lose about 15% of their
illumination. To compensate for this, rooms are therefore
usually dimensioned with 15% more illumination than actually
necessary. With constant light control, the light level can drop
as low as 85%, and the required brightness can still be
achieved. Further savings and comfort can be achieved if
there is a constant light level in the room and the light is
automatically dimmed when more outside light enters. The
Excel 12 supports window correction in order to reduce the
light output of the window light. Via the plug-in, this can be
selected and the offset also adjusted.

Example: The corridor light provides 400 lux and the window
light 320 lux. It is possible to override the constant light
control by manually dimming the light.

For constant light control, you must specify the set-point, the
darkness level, a correction for window lights (in general,
during the daytime, the window light has a lower light level
than the floor light), and also whether you want it to be
possible to switch on the light manually (e.g. in case of a
bright room).

The light intensities typically encountered in everyday life are
listed in Table 4, while Table 5 presents the recommended
light levels in various environments as set forth by DIN5035.

NOTE: One lux is equivalent to 0.0929 foot-candle.

Refer also to the plug-in help information for details.

Table 4. Typical light intensities

ambient conditions intensity (lux)

summer day, cloudless 100,000
summer day, cloudy 20,000
winter day, cloudy 400
night, with full moon 0.3

Table 5. Recommended light intensities (DIN5035)

area intensity (lux)

storage rooms 50...200
washrooms, cloakrooms, technical
rooms, corridors

100

office rooms (near windows) 300
office rooms (minimal outside light) 500
open-plan office rooms 750
schools (daytime) 300
night schools 500
gymnasiums 200
show rooms 300
commercial kitchens 500

Accessories

Swivel Label Holders

For short or long housings (required for modules equipped
with manual override switches).

 24 Vac models (short), order no.: XAL_LAB_S
 line power supply models (long), order no.: XAL_LAB_L

Terminal Protection Covers

For short or long housings (required for wall/ceiling mounting).

 24 Vac models (short), order no.: XAL_COV_S
 line power supply models (long), order no.: XAL_COV_L

LONWORKS® Termination

One or two LONWORKS® terminations are required, depending
on the given LonWorks bus layout.

Two different L
 L

ONWORKS® termination module,

order no.: 209541B

 LONWORKS® connection / termination module (can be

mounted on DIN rails and in fuse boxes),
order no.: XAL-Term

removable screw-type

3-pole terminal block

Fig. 12. LonWorks® connection and termination module

ONWORKS® terminations are available:

l

l

e

w

y

e

n

o

H

m

r

e

T

-

L

A

X

4

3

L

L

O

O

N

N

shield shield

plug-in
jumper

34

1

06

Termination

5

LON

FTT/LPT Bus
FTT/LPT Free
Park Position

7 EN0B-0367GE51 R0110

EXCEL 12 FCU + LIGHT + SUNBLIND

0

Approvals, Certifications, and Standards

Approvals and Certifications

 CE-approved
 Certified as per LonMark® Application Layer

Guidelines V 3.2, thus interoperable with all other
devices in open L
devices)

 EUBAC-certified as follows:

W7704D1016:

W7704D1008:

ONWORKS® networks (incl. 3

eu.bac

020893

Cert

eu.bac

20896

Cert

rd

-party

Classification according to EN60730-1

Environmental conditions: For use in home (residential,

commercial, and light-industrial)

environments
Pollution degree: Class 2
Protection against shock: Class 0 (without terminal covers)

Class II (with terminal covers)
Software class: Class A

Classification according to EN60529

(Degree of Protection Provided by Enclosures)
Without terminal covers: IP20
With terminal covers: IP30

Ambient Environmental Limits

Operating temperature: 0 … +50 °C at 5…90% r.H.
Storage temperature: -30 … +70 °C at 5…90% r.H.

W7704D1008, W7704D1016 Temperature CA

Chilled ceiling: 0.5 K
Electric convector: 0.3 K
Electric floor heating: 1.2 K
Radiator heating: 0.5 K
FCU heating mode: 0.4 K
FCU cooling mode: 0.2 K
(min. Temperature Control Accuracy values requested by

EUBAC: ≤ 1.4 K for hot water radiator heating, fan coil unit,
VAV, and chilled ceiling applications; ≤ 1.8 K for water floor
heating, electric convector, electric floor heating, and electric
ceiling heating applications)

Applicable Literature

 Excel 12 Installation Instructions (EN1B-0201GE51)
 Excel 50/500 L

0270GE51)

 Excel 10 FTT/LPT 209541B Termination Module

Installation Instructions (95-7554)

 ZAPP System Engineering (EN0B-0286GE51)
 Honeywell's XL12 / Excel Smart I/O plug-in help

ONWORKS® Mechanisms (EN0B-

NETWORK INTERFACE

The following tables list the NV's associated with the various
L

ONMARK® objects serving as network interfaces to the Excel

12 FCU + Light + Sunblind application.

Table 6. NV's associated with Space Comfort Controller

FCU Object (profile # 8051)

name type heartbeat

nviSpaceTemp SNVT_temp_p yes
nviSetPoint SNVT_temp_p no
nviSetptOffset SNVT_temp_p yes
nviOccSchedule SNVT_tod_event yes
nviOccManCmd SNVT_occupancy no
nviOccSensor SNVT_occupancy yes
nviApplicMode SNVT_hvac_mode yes
nviFanSpeedCmd SNVT_switch no
nviEnergyHoldOff SNVT_switch yes
nviSequence[2] SNVT_lev_percent yes
nvoSequence[2] SNVT_lev_percent yes
nvoSpaceTemp SNVT_temp_p yes
nvoUnitStatus SNVT_hvac_status yes
nvoEffectOcc SNVT_occupancy no
nvoHeatCool SNVT_hvac_mode yes
nvoFanSpeed SNVT_switch yes
nvoEnergyHoldOff SNVT_switch yes

Table 7. NV's associated with Occupancy Sensor Object

(profile #1060)

name type heartbeat

nvoOccSensor SNVT_occupancy yes

Table 8. NV's associated with Lamp Actuator Object

(profile #3040)

name type heartbeat

nviLampValue[2] SNVT_switch no
nvoLampValueFb[2] SNVT_switch no

Table 9. NV's associated with Sunblind Actuator Object

(object #4)

name type heartbeat

nviSblndSetting[1] SNVT_setting no
nviSblndOvrd[1] SNVT_setting no
nviSblndAuto[1] SNVT_setting yes
nvoSblndSetting[1] SNVT_setting yes

Table 10. NV's associated with the Node Object

(LONMARK® object #0)

name type heartbeat

nviRequest SNVT_obj_request no
nviLuxLight SNVT_lux no
nviLuxSblnd SNVT_lux no
nviWindSpeed SNVT_speed yes
nvoStatus SNVT_obj_status yes
nvoFileDirectory SNVT_address n/a

EN0B-0367GE51 R0110

8

DIMENSIONS

swivel label

holders (optional)

EXCEL 12 FCU + LIGHT + SUNBLIND

terminal protection

cover (optional)

terminal protection

cover (optional)

cut-out tabs

(to expose terminal pins)

leverage slot

LonWorks

service button

long housing (with built-in transformer): 180 m (7-7/8 in.)

Short housing (without transformer): 126 mm (4-15/16 in.)

LonWorks

service LED

ventilation slits

Manufactured for and on behalf of the Environmental and Combustion Controls Division of Honeywell Technologies Sàrl, Rolle, Z.A. La Pièce 16, Switzerland by its Authorized Representative:

Automation and Control Solutions

Honeywell GmbH
Böblinger Strasse 17
71101 Schönaich
Germany
Phone: [phone]
Fax: [phone]
http://ecc.emea.honeywell.com
Subject to change without notice. Printed in Germany

EN0B-0367GE51 R0110
