Hitachi LE40H405 User Manual
Owner's Guide
Model LE40H405
40” Class (40.00” Diagonal)
Thank you for purchasing this Hitachi product. Please read these instructions carefully.
For additional assistance please call 1-888-333-1899(U.S.A. or Puerto Rico), or 01-800-700-4321(Mexico)
Record the model number and serial number of your LCD Television for future reference.
MODEL NUMBER SERIAL NUMBER
IMPORTANT SAFETY INSTRUCTIONS ....................................................................... 2-6
HOW TO ATTACH / REMOVE THE STAND ..................................................................... 7
FIRST TIME USE
TV OPERATION ........................................................................................................13-18
CONNECTIONS TO OTHER EQUIPMENT .............................................................. 19-21
TROUBLESHOOTING ................................................................................................... 22
SPECIFICATIONS .......................................................................................................... 23
LIMITED WARRANTY ............................................................................................... 24-25
END USER LICENCE AGREEMENT FOR HITACHI DTV SOFTWARE ..................26-27
APPENDIXES................................................................................................................. 28
or visit our website at www.hitachi.us/tv.
Keep this owner’s guide for future reference.
This information is located on the back of the television.
TABLE OF CONTENTS
.......................................................................................................
10-13
ES-J113307
条形码定位框（尺寸：35×10.5mm)
定位框不做印刷处理，编码规则咨
询采购资源。
This product contains lead. Dispose of this product in accordance with applicable environmental laws. For product recycling
and disposal information, contact your local government agency or www.eRecycle.org (in California), the Electronic Industries
Alliance at www.eiae.org (in the US) or the Electronic Product Stewardship Canada at www.epsc.ca (in Canada). For more
information, call 1-888-333-1899.
SAFETY PRECAUTIONS
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating. Do not block
ventilation holes, or set up near radiators. Do not place in direct sunlight. When placing on a shelf leave 4 inches (10 cm) free space
around the entire unit.
4 inches
4 inches
Notes when mounting the LCD TV on a wall
If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV for advice, and have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or damage to the LCD TV.
The screws ISO M6 thread type should be used. The insertion length must be within 12 - 16mm.
If the insertion length is less than 12mm, the weight can not be maintained.
If the insertion length is more than 16mm, a space is created between the Wall Mount Bracket and the Television.
(Insertion Length) = (Screw Length) - (Washers Thickness) - (Mounting Bracket Thickness)
Securing to a Wall
1. Use metallic wire, clamp and screw (not provided) on the rear of the LCD TV as shown below.
2. Use proper hardware (drywall anchor, masonry screw, etc) to secure other end of wire to wall.
4 inches
Wire
Wire
Clamp
Screw（M6×10）
NOTICE FOR TV CABINET
If the unit is to be mounted on a cabinet smaller than the length of the unit, it could result in an unstable location and the unit may tumble
over, making a risk of personal, possibly fatal injury. Also, this would damage the product seriously. Accordingly, Hitachi accepts no
responsibility or liability for any injuries or property damage resulting from the improper installation.
YES !!
YES!!
NO !!
NO!!
The figure below is just for reference,please see the real set.
Insert the bracket to the base,and fix them with 6 screws.
Put the TV set on the level table on which there is a pad cloth or other soft material.
Lay down the TV set and make sure the LCD screen is downward.
Then fix the base to the set with 4 screws.
pedestal
WARNING:
The length of Base Screws must be between 10mm and 12mm,otherwise the TV would be damaged.
（Type B）
（Type A）
4 screws
When you transport this product, remove the stand and pack flat against the back of the unit in the carton. To remove the stand, perform
above steps in reverse order.
For wall mounting, the base must be removed. To disconnect the base/stand remove the 4 screws from the back.
4 screws
40
