Hitachi AP 720STM User Manual
TM
LCD Panel Guide
AP 720S
OPTIGEN®
Semi-Automated Instrument
Confidentiality Notice
The materials and information contained herein are being provided by Hitachi Chemical
Diagnostics to its customer solely for customer’s use for its internal business purposes.
Hitachi Chemical Diagnostics retains all rights, title, interest in and copyrights to the
materials and information herein. The materials and information contained herein
constitute confidential information of Hitachi Chemical Diagnostics and customer shall
not disclose or transfer any of these materials or information to any third party.
Copyright © 2007
Hitachi Chemical Diagnostics, Inc.
630 Clyde Court
Mountain View, California 94043
_________________
U.S. and Foreign Patents Pending
All rights reserved. No part of this book may be reproduced in any form without written
permission from Hitachi Chemical Diagnostics, Inc.
Document Number: 0781 Revision: 01
Date: November 2007
1
―
Table of Contents ―
Page
1 Operation Key…………………………………………………………... 3
2 Screen Display and Operation Method
2-1 Initialization……………………………………………………… 4
2-2 Main Menu………………………………………………………. 5
2-3 Panel Type Selection…………………………………………….. 6
2-4 Auto-Run (Process 1 to 7)………………………………………. 7
2-5 Auto-Run (Photoreagent Setup and Process 8)…………………. 9
2-6 Auto-Run (Process End)………………………………………… 10
2-7 Maintenance……………………………………………………... 11
2-8 Pause…………………………………………………………….. 13
2-9 Start/End Process and Position Setup……………………………. 16
2-10 Alarm…………………………………………………………….. 17
3 Flowchart………………………………………………………………... 21
2
1 Operation Key
Display:
Liquid Crystal Panel
Operation Key:
Only the touch panel key in the shaded field is executable. Press the Operation Key
to execute the function. See Figure 1.
Numerical Value Input Key:
Numerical value can be registered by ‘ENT’ key. If the value entered is out of the
defined range, beep sounds will be on for 3 times. ‘ESC’ key is used for returning
to the original value. See Figure 2.
(Figure 1)
(Figure 2)
3
2 Screen Display and Operation Method
2-1 Initialization
[Screen Display]
(Figure 3) (Figure 4)
[Summary]
Figure 3 will display approximately 5 seconds after the power is turned on. Then
the screen will change automatically to the initialization screen, Figure 4. After the
completion of initialization, there is a beep sound and Main Menu screen, Figure 5
will display.
[Operation Key]
(Figure 4)
Pause: To Figure 27 Pause screen
4
2 Screen Display and Operation Method
2-2 Main Menu
[Screen Display]
(Figure 5) (Figure 6)
[Summary]
Figure 5 is the Main Menu screen after completion of Figure 4. Panel 36 is the
default panel.
Figure 6 is the Main Menu screen after selecting Panel 20 in Figure 7.
[Operation Key]
Panel 36: To Figure 7 Panel Type Selection screen
Next: To Figure 8 Auto-Run screen
Maintenance: To Figure 19 Maintenance screen
5
2 Screen Display and Operation Method
2-3 Panel Type Selection
[Screen Display]
(Figure 7)
[Summary]
Select 36-allergen or 20-allergen panel in Figure 7.
[Operation Key]
36: To Figure 5 Main Menu screen
20: To Figure 6 Main Menu screen
6
