Hikvision DS-K4H250D Specsheet
Spec of DS-K4H250D Double-door Magnetic Lock www.hikvision.com
The DS-K4H250D Double-door magnetic lock is designed for
wooden door, glass door, and steel door with the opening
angle of 90°. The maximum thrust of the lock is 600kg. It can
be used for controlling door opening/closing, and the indicator
shows the door status. It supports signal output of door lock
output status testing.
Model
DS-K4H250D
Dimension of Lock Body
(L×W×H)
480×49×25.5mm (18.9×1.93×1.00")
Dimension of Armature Plate
(L×W×H)
180×38×11mm (7.1×1.5×0.4")
Maximum Thrust
300kg×2 Linear Thrust
Input Voltage
12VDC /24VDC
MAIN FEATURES
DS-K4H250D
Double-door Magnetic Lock
SPECIFICATIONS
AVAILABLE MODEL
DS-K4H250D
The magnetic lock supports static linear thrust of 600kg;
The power supply can be customized to be 12VDC or 24VDC, and the default voltage is 12VDC;
It is equipped with internal voltage dependent resistor (MOV);
It is applied to wooden door, glass door, metal door and fireproof door;
LED indicator displays the status of door lock;
Signal output of door lock status (NO\NC\COM)
Anti-residual magnetism design
Abrasion-proof materials;
The shell is made up of aldural and is hard anodizing electroplated;
No mechanical failure, and the magnetic lock works by electromagnetism force;
1
Spec of DS-K4H250D Double-door Magnetic Lock www.hikvision.com
Model
DS-K4H250D
Working Current
12V/500mA×2 24V/250mA×2
Signal Output
Dry Contact Signal Output, Support Maximum Power Rate of 3A, NO
Output While Locking and NC Output While Unlocking
LED Indicator
Red (Door is Unlocked) Green (Door is Locked)
Suitable Door
Wooden Door, Glass Door, Metal Door, Fireproof Door
Working Temperature
-10°C to +55°C (14°F to 131°F)
Working Humidity
0 to 95% (Relative Humidity)
Shell
Hard Anodizing Electroplating Operated
Lock Body
Eco-friendly Zinc Electroplating Operated
Armature Plate
Eco-friendly Zinc Electroplating Operated
Weight
4.2kg(9.3lb)
Circuit Board Diagram
2
