HikVision DS-D6122TH-C, DS-D6122TH-T Data Sheet

DS-D6122TH-C/T Classroom Information Release Screen
1920×1080P@60Hz full HD, 10-point capacitive touch, and 8-millisecond rapid response
27-millimeter-thick body with anti-glare toughened glass, preventing strong light interference and violent destruction
Built-in light sensor module helps automatically adjust screen brightness to match surrounding lighting conditions, displaying clear pictures with energy saved
Built-in 2 MP WDR camera captures clear images when facing against the light
Recognize up to 5 persons in one second, meeting the requirements of quick attendance check for elective class
Built-in omnidirectional microphone picks up sound within a radius of at least one meter
Control access control devices through Wiegand protocol, and door locks with relays
Built-in 13.56 MHz RFID card-swiping module with high response speed, compatible with the standard card of type A and B
Specification
Product Model
Product Model
DS-D6122TH-C/T
Display
Viewing Angle
V 178°, H 178°
Screen Size
21.5 inch
Active Display Area
477.06 mm (H) × 268.79 mm (V)
Backlight
TFT-LCD
Resolution
1920 × 1080
Brightness
400 cd/m²
Color Depth
8 bit
Contrast Ratio
≥ 1000:1
Response Time
≤ 14 ms
Color Gamut
72%
Reliability
7 × 24 h
Built-in System
Operation System
Android 6.0.1
Processor
Cortex-A17, 4 Cores, 1.8 GHz
Memory
2 GB
Built-in Storage
16 GB EMMC
Smart
Lens
2 MP WDR Camera
Face Database
50,000 pictures, JPG format allowed
Face Detection Distance
Up to 5 m (196.86'')
0.3 m to 1.5 m (11.81'' to 59.06'') recommended Adjustable through software
Face Verification Accuracy
99%
Face Verification Time
≤ 0.5 s/person
Touch
Touch Type
Capacitive touch
Glass
3 mm anti-glare toughened glass
Touch Point
10
Interface
Network Interface
LAN × 1
Data Transmission Interface
USB 2.0 × 2, Built-in Wi-Fi, Bluetooth 4.0, Card-swiping for IC card, Access control linkage
Power
Standby Consumption
≤ 0.5 W
Power Consumption
≤ 40 W
Working Environment
Working Temperature
0 ℃ to 40 ℃ (30 ℉ to 104 ℉)
Working Humidity
10% to 90%
General
Gross Weight
8.32 kg (18.34 lb)
Net Weight
7.18 kg (15.83 lb)
Package Dimensions (W × H × D)
660 mm × 584 mm × 113 mm (25.98'' × 22.99'' × 4.45'')
Packing List
21.5-inch screen × 1, L-wrench × 1, power cord × 1, power adapter × 1, torx screw for
security × 2, pack of mounting bolts × 2, quick start guide × 1
Product Dimensions (W × H × D)
518.26 mm × 359.99 mm × 27 mm (20.40'' × 14.17'' × 1.06'') (Without wall-mounting plate)
518.26 mm × 359.99 mm × 28.3 mm (20.40'' × 14.17'' × 1.11'') (With wall-mounting plate)
Temperature Measurement
Temperature Measurement Accuracy
± 0.5 ℃ (± 32.9 ℉)
Temperature Measurement Distance
0.3 m to 1.5 m (11.81'' to 59.06'') recommended Focal Length
3.1 mm
Applicable Scenes
Indoor scenes, no direct light, not directly faced by heat source or air-conditioner outlet
Indoor Temperature Requirement
5 ℃ to 35 ℃ (41 ℉ to 95 ℉) Field Angel
V 50°, H 37°
Dimension
Available Model
DS-D6122TH-C/T(
