Hikvision DS-D5019QE-B, DS-D5022QE-B, DS-D5022FC, DS-D5024FC, DS-D5032FC-A User Manual

SEE BETTER, ACT FASTER

HIKVISION MONITORS IN
COMMAND CENTER

www.hikvision.com

01

Flexible and cost-effective solution for small control room with up to 4K resolution and 24/7 operation.

High Definition Solution For Small Control Room

22” 55” 4K

WorkStationDS-1005KI NVR

Product List

NETWORK

28”, 50”, 55” ( 4K )

Resolution: 3840×2160@60Hz
VGA/BNC, USB, Speaker
HDMI 2.0 (4K@60Hz) support
Metal casing, VESA support
24/7 Operation

32”, 40”, 43”, 49”, 55”

Resolution: 1920×1080
HDMI/VGA/BNC, USB, Speaker
Metal casing, VESA support
24/7 Operation

Model

DS-D5028UC, DS-D5050UC,
DS-D5055UL-B

3

Model

DS-D5032FC-A, DS-D5032FL, DS-D5040FC,
DS-D5043FC, DS-D5049FL, DS-D5055FL

Up To 4K UHD

Industrial Grade PID LCD Panel

An ultra-high definition offers not only the most exquisite
image details for an optimal viewing experience, but also
more workspace compared to 1080P to achieve better work
efficiency.

1920 x 1080 3840 x 2160

Wide Viewing Angle

Up to 178°viewing angle allows you to capture every detail.

PID Panel delivers longer service life, making it perfect for the
security environment with non-stop display service and reliable
performance.

PID A+ Panel
24/7

iVMS Software and Flexible Keyboard

Free iVMS-4200 or licensed HikCentral, together with DS-1005KI
keyboard, will provide the ideal solution to manage your security
video and image in a quick and effective manner.

19”, 22”, 24”

Resolution: 1920×1080
HDMI/VGA
BNC(not QE series)
Plastic casing, VESA support
24/7 Operation

Model

DS-D5019QE-B, DS-D5022QE-B,
DS-D5022FC, DS-D5024FC

4

02

Extensible video wall, along with the flexible decoder, can display images from more channels and provide a more advanced video
management ability.

Video Wall Solution For Medium Control Room

2×2 Video Wall

DS-1600KI Decoder WorkStation NVR

Product List

NETWORK

4K Decoder

HDMI/BNC output
Up to 4K @30Hz (Only for odd interface)
Decoding: Up to 16-ch 12MP or 128-ch 1080p
Up to 4×4 video wall control
Division, splicing, cross-window roaming
H.265, H.264+, H.264

Model

DS-6900UDI-T series

5

Easy to Install with VESA Wall Bracket

Longer Life Span

Normal monitors Hikvision monitors

Strong Package Design

Bursting strength up to 2000Kpa. Edge Crush Test up to 1400N/m.
Avoid any damage during transportation.

20,000 –
25,000 Hours

50,000 –
60,000 Hours

Windows Splicing and Division

Powerful decoding ability and flexible window management
with the 4K decoder.

4K output

Max. 16 HDMI output

12MP/1080P decoding

Decoder

Max. 36 divisions

Network Keyboard

10.1” capacitive touch screen
Detachable design for the touchscreen and joystick
Wired and WiFi network connection
2-ch 1080P decoding and up to 16-division window display
PTZ control, setting and calling preset, patrol and pattern
DVI/HDMI output to monitor

Model

DS-1600KI

6

03

Narrow Bezel Video Wall For
High-End Control Room

Product List

OR

Decoder Video Wall Controller

46”, 55”

500 cd/m², 800 cd/m²

5.3mm, 3.5mm, 1.7mm
Input: VGA/DVI/BNC/HDMI/Ypbpr
Output: VGA/DVI/2*BNC

Model

DS-D2046NL-B, DS-D2046NL-C,
DS-D2046NH-C, DS-D2055NL-B/G,
DS-D2055NH-B/G

7

Ultra-narrow Bezel Design

Daisy-Chain Display

World’s slimmest bezel-to-bezel video wall provides
you with an amazing viewing experience.

Deliver high-quality mirrored contents to different locations, or build a
multi-display, single-image video wall through simply connecting your
media device to the screen via DVI. No splitters required.

DVI-in DVI-out

1.7mm

Client Software for Flexible Video Wall Management

Hikvision video wall management platform provides flexible and powerful functions, such as window roaming,
opening, and division anywhere on screen.

Details need to be checked

Media Player

Open a new window anywhere on screen
Max. 8 windows overlaid
Roaming windows by Click-and-drag

Video Wall Controller

4U/8U/13U casing option
Input: DVI/HDMI/SDI/Ypbpr/BNC/TVI/DP
Output: VGA/HDMI/DVI/SDI
Support decoding board
Windows roaming, opening, and division

Model

DS-C10S-S11/E, DS-C10S-S22/E,
DS-C10S-S41/E

8

Specification Product CCTV Economic Series ( QE ) CCTV Professional Series ( FC )

Model Name DS-D5019QE-B DS-D5022QE-B DS-D5022FC DS-D5024FC DS-D5032FC-A DS-D5040FC DS-D5043FC

Screen Diagonal 18.5" 21.5" 21.5" 23.6" 32" 39.5" 42.5"

Backlight LED-Backlit TFT LCD

Panel

Audio

Input

Output BNC N/A N/A ×1 ×1 ×1 ×1 N/A

Resolution 1366×768 1920×1080

Aspect Ratio 16:9

Brightness (Typical)

(cd/m²)

Contrast Ratio (Typical) 600:1 1000:1 1000:1 1000:1 1000:1 5000:1 1200:1

Viewing Angle (H/V) 90° / 65° 170° / 160° 178° / 178°

Internal Speaker N/A N/A ×2, 2W ×2, 2W ×2, 2W ×2, 2W ×2, 3W

Audio Input N/A N/A ×1 ×1 ×1 ×1 ×1

Audio Output N/A N/A ×1 N/A ×1 ×1 N/A

VGA ×1 ×1 ×1 ×1 ×1 ×1 ×1

HDMI ×1 ×1 ×1 ×1 ×1 ×1 ×1

BNC N/A N/A ×1 ×1 ×1 ×1 ×1

DVI N/A N/A N/A N/A ×1 ×1 ×1

USB N/A N/A ×1 N/A ×1 ×1 N/A

Dimensions (W×H×D) 445×274×44mm 511×313×170mm 511×313×170mm 561×399×218mm 728×528×168mm 906×517×47mm 968×565×78mm

200 250 250 250 300 360 380

Mechanical

Power

Environment

Accessory

Weight (Gross/Net) 3.5kg / 2.8kg 4.5kg / 3.3kg 4.6kg / 3.2kg 6kg / 5.1kg 9.2kg / 5.7kg 11kg / 8.5kg 10.6kg / 9.1kg

Wall Mounting (VESA)

(mm)

Voltage 100V~240V, 50Hz / 60Hz DC12V 100V~240V, 50Hz / 60Hz

Power Consumption

(Maximum / Standby)

Operation Temperature 0°C ~ 40°C

Storage Temperature -20°C ~ 55°C

Usage 24/7

Remote Control N/A ×1

Power Cord ×1

VGA Cable (By Region) N/A N/A N/A ×1 ×1 ×1 N/A

HDMI Cable (By Region) ×1 ×1 ×1 N/A ×1 ×1 N/A

Base Bracket ×1 Optional

Wall Bracket Optional

75×75mm 100×100mm 100×100mm 100×100mm 100×100mm 100×100mm 200×300mm

<25W /<0.5W <30W /<0.4W <30W /<0.5W <30W /<0.5W <45W /<0.5W <60W /<0.5W <65W /<1W

9

Specification Product Industrial Series ( FL ) PVM 4K Series

Model Name DS-D5032FL DS-D5043FL DS-D5049FL DS-D5055FL DS-D5032FL-C DS-D5028UC DS-D5050UC DS-D5055UL-B

Screen Diagonal 32" 43" 49” 55" 32” 28” 50” 55"

Backlight LED-Backlit TFT LCD

Resolution 1920×1080 3840×2160

Panel

Aspect Ratio 16:9

Brightness (Typical)

(cd/m²)

Contrast Ratio

(Typical)

Viewing Angle (H/V) 178° / 178°

Internal Speaker ×2, 3W ×2, 3W ×2, 3W ×2, 3W N/A ×2, 3W ×2, 8W ×2, 5W

400 400 450 380 400 300 300 500

3000:1 1200:1 1100:1 1200:1 3000:1 1000:1 4000:1 1100:1

Audio

Input

Output

Mechanical

Power

Environment

Audio Input ×1 ×1 ×1 ×1 ×1 ×1 ×1 ×1

Audio Output ×1 ×1 ×1 ×1 ×1 ×1 ×1 ×1

VGA ×1 ×1 ×1 ×1 ×1 ×1 ×1 ×1

HDMI ×1 ×1 ×1 ×1 ×1 ×1 ×2

BNC ×1 ×1 ×1 ×1 N/A N/A ×1 ×1

DVI ×1 ×1 ×1 ×1 N/A ×1 ×1 ×1

USB ×1 ×1 ×1 ×1 ×1 ×2 ×2 ×1

BNC N/A ×1 N/A N/A N/A N/A N/A ×1

LAN N/A N/A N/A N/A ×1 N/A ×1 N/A

Dimensions (W×H×D)

Weight (Gross/Net) 19kg / 12kg 28kg / 20kg 32kg / 24.65kg

Wall Mounting (VESA)

(mm)

Voltage 100V~240V, 50Hz / 60Hz

Power Consumption

(Maximum / Standby)

Operation

Temperature

Storage Temperature -20°C ~ 55°C

737×452

×70mm

200×200mm 400×200mm 300×200mm 400×300mm 200×200mm 100×100mm 400×200mm 300×200mm

<60W /<1W <100W / <1W <60W / <1W <80W /<1W <65W / <0.5W <70W / <0.5W <117W / <0.5W <100W / <1W

996×591

×48mm

1141×677

×69mm

1275×746

×55mm

38.5kg /

33.73kg

737×508

×75mm

22kg / 18kg 10.2kg / 7.8kg 12.35kg / 12kg 41kg / 35kg

0°C ~ 40°C

659×555
×244mm

1123×649

×77mm

×1 HDMI1.4, ×1

HDMI2.0

1262.1×742.9
×55.7mm

Accessory

Usage 24/7 18/7 24/7

Remote Control ×1

Power Cord ×1

VGA Cable (By

Region)

HDMI Cable (By

Region)

Base Bracket Optional ×1 Optional

Wall Bracket Optional

N/A ×1 N/A

N/A

10

Specification Product 1.7mm extreme-narrow bezel series

Model Name DS-D2046NH-E

Screen Diagonal 46” 55”

DS-D2055NL-

E/G

DS-D2055NH-

E/G

Specification Product 5.5 mm narrow bezel series

Model Name DS-D2046NL-B/Z DS-D2046NL-B

Screen Diagonal 46” 46”

Panel

Input

Output

Backlight LED-Backlit TFT LCD

Panel S-PVA

Resolution 1920×1080

Aspect Ratio 16:9

Brightness (Typical)

(cd/m²)

Contrast Ratio (Typical) 4500:1 4500:1 4500:1

Response Time 6ms 8ms 8ms

Viewing Angle (H/V) 178° / 178°

VGA ×1

HDMI ×1

BNC ×1

DVI ×1

YPbPr ×1

IR Jack ×1

VGA ×1

DVI ×1

700 500 700

Panel

Input

Output

Backlight LED-Backlit TFT LCD

Panel S-PVA

Resolution 1920×1080

Aspect Ratio 16:9

Brightness (Typical)

(cd/m²)

Contrast Ratio (Typical) 4500:1 4500:1

Response Time 6ms 8ms

Viewing Angle (H/V) 178° / 178°

VGA ×1

HDMI N/A ×1

BNC ×1

DVI ×1

YPbPr ×1

IR Jack ×1

VGA N/A ×1

DVI N/A ×1

700 500

Mechanical

Power

Environment

Accessory

BNC ×2

Dimensions (W×H×D)

Weight (Net) 23kg 33kg 33kg

Physical Seam 1.7mm

Voltage 90V~264V, 50Hz / 60Hz

Power Consumption <139W <192W <192W

Operating Temperature 0°C~40°C

Life Expectancy ≥60,000 Hours

Usage 24/7

Remote Control ×1

Power Cord ×1

Cable HDMI / DVI / VGA Optional

User's Manual ×1

Base Bracket Optional

Wall Bracket Optional

1020×574

×116mm

1121×682

×112mm

1211×682

×112mm

Mechanical

Power

Environment

Accessory

BNC N/A ×2

Dimensions (W×H×D) 1020×574×116mm 1121×682×112mm

Weight (Net) 23kg 33kg

Physical Seam 5.5mm

Voltage 90V~264V, 50Hz / 60Hz

Power Consumption <139W <192W

Operating Temperature 0°C~40°C

Life Expectancy ≥60,000 Hours

Usage 24/7

Remote Control ×1

Power Cord ×1

Cable HDMI / DVI / VGA Optional

User's Manual ×1

Base Bracket Optional

Wall Bracket Optional

11

Specification Product 3.5 mm ultra-narrow bezel series

Model Name DS-D2046NL-C DS-D2046NH-C DS-D2049NL-B DS-D2055NL-B DS-D2055NH-B DS-D2055NL-B/G DS-D2055NH-B/G

Screen Diagonal 46” 49” 55”

Backlight LED-Backlit TFT LCD

Panel S-PVA

Panel

Input

Output

Resolution 1920×1080

Aspect Ratio 16:9

Brightness (Typical)

(cd/m²)

Contrast Ratio

(Typical)

Response Time 8ms 8ms 8ms 8ms 8ms 8ms 8ms

Viewing Angle (H / V) 178° / 178°

VGA ×1

HDMI ×1

BNC ×1

DVI ×1

YPbPr ×1

IR Jack ×1

VGA ×1

DVI ×1

BNC ×2

Dimension (W×H×D) 1022×576×120mm 1022×576×120mm 1077×607×113mm 1213×684×113mm 1213×684×111mm 1213×684×113mm 1213×684×111mm

500 800 500 500 800 500 700

4500:1 4500:1 4000:1 4000:1 4000:1 4000:1 4000:1

Mechanical

Power

Environment

Accessory

Weight (Net) 23kg 23kg 28kg 33kg 33kg 33kg 33kg

Physical Seam 3.5mm

Voltage 90V~264V, 50Hz / 60Hz

Power Consumption <139W <139W <134W <192W <192W <192W <192W

Operation

Temperature

Working Life ≥60,000 Hours

Usage 24/7

Remote Control ×1

Power Cord ×1

Cable HDMI / DVI / VGA Optional

User's Manual ×1

Base Bracket Optional

Wall Bracket Optional

0°C ~ 40°C

12

Specification

Input

Product Decoder

Model Name DS-6901UDI DS-6904UDI DS-6908UDI DS-6910UDI DS-6912UDI DS-6916UDI

VGA N/A ×1

DVI N/A ×1

HDMI ×1 ×4 ×8 ×10 ×12 ×16

Output

External

Decoding Ability

Mechanical

4K@30Hz (HDMI) Yes Odd ports support

VGA ×1 N/A

10/100/1000Mbps

Ethernet

Alarm in ×8

Alarm out ×8

Audio out (BNC) ×1 1 DB 15×2 1 DB 15×4 2 DB 15×5 2 DB 15×6 2 DB 15×8

12MP@20fps ×2 ×4 ×8 ×10 ×12 ×16

8MP@30fps ×4 ×8 ×16 ×20 ×24 ×32

1080P@30fps ×16 ×32 ×64 ×80 ×96 ×128

Screen Division ×16 ×25 ×36

Dimensions (W×H×D) 220×148×45mm 440×311×44.5mm 440×311×80mm

Weight ≤ 1.2kg ≤ 5.2kg ≤ 6.4kg

×1 ×2

13

Specification

Slot

Pluggable Board

Mechanical

Specification

Product Video Wall Controller

Model Name DS-C10S-S11/E DS-C10S-S22/E DS-C10S-S41/E

Input ×6 ×12 ×23

Output ×5 ×10 ×18

Input VGA, HDMI, DVI, Ypbpr, DVI Dual-link, BNC, SDI, TVI, DP, Decoding board

Output VGA, HDMI, DVI, SDI

Dimensions (W×H×D) 352×177×442.4mm 352×354×442.4mm 417×576.6×442.4mm

Weight ≤ 20kg (full-loaded) ≤ 35kg (full-loaded) ≤ 50kg (full-loaded)

Product Keyboard

Model Name DS-1005KI DS-1600KI

Interface Type USB 2.0 10/100/100M Ethernet

Interface

External

Decoding Ability

Mechanical

Audio N/A 3.5mm AUDIO port

Video Interface N/A HDMI / DVI

Joystick 3-axis joystick 4-axis joystick

WIFI N/A Yes

Screen N/A 10.2”, TFT touch

Resolution N/A 1024×600

Operation System N/A Android 4.4

Dimensions (W×H×D) 167×116×177.5mm 404×180×163mm

Weight 1.1kg 1.7kg

14

SEE BETTER, ACT FASTER

HIKVISION MONITORS IN
COMMAND CENTER

Distributed by

Headquarters

No.555 Qianmo Road, Binjiang District,
Hangzhou 310051, China
T [phone]
[e-mail]

Hikvision USA

T [phone]
[e-mail]

Hikvision Australia

T [phone]
[e-mail]

Hikvision India

T [phone]
[e-mail]

Hikvision Canada

T [phone]
[e-mail]

Hikvision Thailand

T [phone]
[e-mail]

Follow us on social media to get the latest product and solution information

Hikvision HikvisionHQ Hikvision_Global

Hikvision Europe

T [phone]
[e-mail]

Hikvision Italy

T [phone]
[e-mail]

Hikvision Brazil

T [phone]
[e-mail]

Hikvision Turkey

T [phone]- 7074
[e-mail]

Hikvision Malaysia

T [phone]
[e-mail]

Hikvision UK & Ireland

T +01628-902140
[e-mail]

Hikvision South Africa

Tel: [phone]
[e-mail]

Hikvision France

T [phone]
[e-mail]

Hikvision Kazakhstan

T [phone]
[e-mail]

Hikvision Vietnam

T [phone]
[e-mail]

HikvisionHQ hikvisionhq

Hikvision UAE

T [phone]
[e-mail]

Hikvision Singapore

T [phone]
[e-mail]

Hikvision Spain

T [phone]
[e-mail]

Hikvision Tashkent

T [phone]
[e-mail]

Hikvision Hong Kong

T [phone]
[e-mail]

Hikvision
Corporate Channel

Hikvision Russia

T [phone]
[e-mail]

Hikvision Korea

T [phone]
[e-mail]

Hikvision Poland

T [phone]
[e-mail]

Hikvision Indonesia

T [phone]
[e-mail]

Hikvision Colombia

[e-mail]

www.hikvision.com
