Hikvision DS-D5024FC User Manual

Overview

DS-D5024FC is a reliable surveillance display with LED backlit

technology, excellent color reduction and image processing, truly

display the video details. Multiply interfaces are able to meet

various surveillance environments, and build-in speaker is

convenient to audio play. DS-D5024FC is an ideal choice for

security and surveillance application.

key Features

• LED backlit technology with full HD 1920×1080@60Hz

• Wide view angle: 170°(H)/160°(V)

• Image processing: 3D comb filter, 3D De-interlace,

3D noise reduction

• Multiply interface: HDMI, VGA, BNC input, BNC output, audio in

• Support analog signal input

• Build-in speaker

• High reliable components for 7×24 working

• VESA stand bracket

• Green energy: Enter standby mode while no signal input

Model:

DS-D5024FC

DS-D5024FC

23.6” Monitor

Interfaces

NO. Description

1 3.5mm headphone interface

2 AUDIO

3 BNC in and out

4

VGA ：VGA Analog Signal Input

5

HDMI：HDMI Digital Signal Input

DS-D5024FC

23.6” Monitor

Model

DS

-D5024FC

Display

Display Type

LED

-Backlit

Screen Size

23.6”

Pixel

Pitch(H×V)

0.2715mm

×

0.2715mm

Max Resolution

1920

×

1080

Brightness

250cd/m2

(Typical)

Contrast

1000:1(Typical) DCR 30,000,000:1

Response Time

5ms

Color

16.7M

Viewing Angle

Horizontal

170°, Vertical 160°

Interface

HDMI

1

VGA

1

BNC

In

×

1, Out×1

Audio

Audio

Input

1x

3.5 mm mini-jack , 1x RCA type

Speaker

2*2W

Mounting

VESA

100mm

×

100mm

General

Power Supply

AC

100~240V

Consumption

< 30W(on)
< 0.5W(Standby

)

Operation Temperature

0°

C ~ 40 °C

Operating Humidity

10%~85% (No Condensation)

Storage Temperature

-20

°C ~ 60°C

Storage Humidity

5%~95% (No Condensation)

Dimension (W

×H×D)

561x339x218.5 (mm)

22.1x13.3x8.6(inch)

Weight

6.0Kg(Gross

weight) , 5.1(Net weight)

Included Accessories

Power cord

x 1, VGA cable x 1, User manual x 1, warranty card x 1,

base bracket x 1

Specification
