Hikvision DS-7716NI-K4-16P User Manual
DS-7700NI-K4/P SERIES NVR
Features and Functions
Professional and Reliable
Dual-OS design to ensure high reliability of system running
ANR technology to enhance the storage reliability when the network is disconnected
HD Input
H.265/ H.265+/H.264/ H.264+/MPEG4 video formats
Connectable to the third-party network cameras
Up to 32 IP cameras can be connected
Recording at up to 8 MP resolution
Supports live view, storage, and playback of the connected camera at up to 8 MP resolution
HD Output
HDMI and VGA independent outputs provided
HDMI Video output at up to 4K (3840 × 2160) resolution
HD Storage
Up to 4 SATA interfaces connectable for recording and backup
Storage space effectively saved by 50% to 70% with the use of H.264+ decoding format
HD Transmission
1 self-adaptive 10 M/100 M/1000 Mbps network interface 8/16 independent PoE network interfaces are provided
Various Applications
Centralized management of IP cameras, including configuration, information import/export, real-time information display, two-way audio, upgrade, etc.
Connectable to smart IP cameras from Hikvision and the recording, playing back, and backing up of VCA alarms can be realized
VCA detection alarm is supported
Instant playback for assigned channel during multi-channel display mode
Smart search for the selected area in the video; and smart playback to improve the playback efficiency
Supports HDD quota and group modes; different capacity can be assigned to different channels
Hik-Connect for easy network management
Specifications
|
Model |
|
|
|
|
|
DS-7708NI-K4/8P |
|
DS-7716NI-K4/16P |
|
DS-7732NI-K4/16P |
|
|
|
IP video input |
|
|
8-ch |
|
16-ch |
|
32-ch |
|
|
Video/ |
|
|
Incoming |
|
|
80 Mbps |
|
160 Mbps |
|
256 Mbps |
|
|
|
bandwidth |
|
|
|
|
||||
|
Audio input |
|
|
|
|
|
|
|
|
|
|
|
|
|
Outgoing |
|
|
160 Mbps |
|
|
|
||
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
bandwidth |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
HDMI output |
|
|
4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, |
||||
|
|
|
|
|
|
1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × |
|||||
|
|
|
|
resolution |
|
|
|||||
|
Video/ |
|
|
|
|
768/60Hz |
|
|
|
||
|
|
|
|
|
|
|
|
|
|||
|
Audio output |
|
|
VGA output |
|
|
1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × |
||||
|
|
|
|
resolution |
|
|
768/60Hz |
|
|
|
|
|
|
|
|
Audio output |
|
|
1-ch, RCA (Linear, 1 KΩ) |
|
|
|
|
|
|
|
|
Decoding format |
|
|
H.265/ H.265+/H.264/H.264+/MPEG4 |
|
|
||
|
|
|
|
Recording |
|
|
8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF |
||||
|
Decoding |
|
|
resolution |
|
|
/2CIF/CIF/QCIF |
|
|
|
|
|
|
|
Synchronous |
|
|
8-ch |
|
16-ch |
|
16-ch |
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
playback |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Capability |
|
|
2-ch @ 8 MP (25fps) / 4-ch @ 4MP (30fps) / 8-ch @ 1080p (30fps) |
||||
|
Network |
|
|
Network |
|
|
TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, |
||||
|
management |
|
|
protocols |
|
|
UPnP™, HTTPS |
|
|
|
|
|
Hard disk |
|
|
SATA |
|
|
4 SATA interfaces |
|
|
|
|
|
|
|
Capacity |
|
|
Up to 6TB capacity for each HDD |
|
|
|||
|
|
|
|
|
|
|
|
||||
|
|
|
|
Two-way audio |
|
|
1-ch, RCA (2.0 Vp-p, 1kΩ) |
|
|
||
|
External |
|
|
Network interface |
|
|
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
||||
|
|
|
Serial interface |
|
|
1 RS-485 (half-duplex), 1 RS-232, 1 keyboard (optional) |
|||||
|
interface |
|
|
|
|
||||||
|
|
|
|
USB interface |
|
|
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
||||
|
|
|
|
Alarm in/out |
|
16/4 |
|
|
|
|
|
|
|
|
|
|
|
|
8, RJ-45 10/100 Mbps |
|
16, RJ-45 10/100 Mbps self-adaptive |
||
|
|
|
|
Interface |
|
|
self-adaptive |
|
|||
|
|
|
|
|
|
|
Ethernet interface |
|
|
||
|
POE Interface |
|
|
|
|
|
Ethernet interface |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Power |
|
|
≤ 200 W |
|
|
|
||
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
Supported |
|
|
IEEE 802.3 af/at |
|
|
|
|
|
|
|
|
standard |
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
|
|
100 to 240 VAC |
|
|
|
|
|
|
|
|
Power |
|
|
≤ 300 W |
|
|
|
|
|
|
|
|
Consumption |
|
|
|
|
|
|
|
|
|
|
|
(without hard |
|
|
≤ 20 W (without enabling PoE) |
|
|
||
|
|
|
|
disk) |
|
|
|
|
|
|
|
|
|
|
|
Working |
|
|
-10 to +55ºC (14 to 131ºF) |
|
|
||
|
General |
|
|
temperature |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Working humidity |
|
|
10 to 90 % |
|
|
|
||
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
Chassis |
|
|
19-inch rack-mounted 1.5U chassis |
|
|
||
|
|
|
|
Dimensions |
|
|
445 × 400 ×71 mm ( 17.5"× 15.7" × 2.8") |
|
|
||
|
|
|
|
(W × D × H) |
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Weight |
|
|
|
|
|
|
|
|
|
|
|
(without hard |
|
|
≤ 5 kg (11. lb) |
|
|
|
|
|
|
|
|
disk) |
|
|
|
|
|
|
|
