Hikvision DS-2CD2725FWD-IZS Specsheet

BLC/3D DNR/ROI/HLC Smart encoding: Support low bit rate, low
4 behavior analyses and face detection Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux
with IR
Color: 0.0068 Lux @ (F1.4, AGC ON), 0
Lux with IR
1/2.8" Progressive Scan CMOS 1920 × 1080 @30fps Powered by Darkfighter H.265, H.265+ 120dB WDR IP66, IK10 IR range: up to 30 m
Key Features
DS-2CD2725FWD-IZS 2 MP IR Varifocal Dome Network Camera
Specifications
Camera
Image Sensor
1/2.8" Progressive Scan CMOS
Min. Illumination
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR Color: 0.0068 Lux @ (F1.4, AGC ON), 0 Lux with IR
Shutter Speed
1/3 s to 1/100,000 s
Slow Shutter
Yes
Day & Night
IR Cut Filter
Digital Noise Reduction
3D DNR
WDR
120dB
3-Axis Adjustment
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
Lens
Focal length
2.8 to 12 mm
Lens Type
Motorized
Aperture
F1.4
Focus
Auto
FOV
Horizontal field of view: 105° to 35° Vertical field of view: 56° to 20° Diagonal field of view: 126° to 40.5°
Lens Mount
Φ14
IR
IR Range
Up to 30 m
Wavelength
850nm
Compression Standard
Video Compression
Main stream: H.265/H.264 Sub stream: H.265/H.264/MJPEG Third stream: H.265/H.264
H.264 Type
Main Profile/High Profile
H.264+
Main stream supports
H.265 Type
Main Profile
H.265+
Main stream supports
Video Bit Rate
32 Kbps to 16 Mbps
Audio Compression
G722.1/G.711/G726/MP2L2/PCM/MP3
Audio Bit Rate
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3)
Smart Feature-set
Smart Event
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection, face detection, scene change detection
Basic Event
Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
Linkage Method
Trigger recording: memory card, network storage, pre-record and post-record Trigger captured pictures uploading: FTP, HTTP, NAS, Email Trigger notification: HTTP, ISAPI, alarm output, Email
Region of Interest
Support 1 fixed region for main stream and sub stream
Max. Resolution
1920 × 1080
Main Stream
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 288) 60Hz: 30fps (1920 × 1080, 1280 × 720, 640 × 360, 352 × 240)
Image Enhancement
BLC/3D DNR/HLC
Image Setting
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser
Day/Night Switch
Day/Night/Auto/Schedule/Triggered by Alarm In
Network
Network Storage
Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Protocols
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS
General Function
Anti-flicker, three streams, heartbeat, mirror, privacy masks, password reset via e-mail, pixel counter, HTTP listening
API
ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS 1.2, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2
Simultaneous Live View
Up to 6 channels
User/Host
Up to 32 users 3 levels: Administrator, Operator and User
Client
iVMS-4200, Hik-Connect, Hik-Central
Web Browser
Plug-in required live view: IE8+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 11+
Local Service: Chrome 41.0+, Firefox 30.0+
Interface
Audio
1 input (line in, 3.5 mm), 1 output(3.5 mm), mono sound
Communication Interface
1 RJ45 10M/100M self-adaptive Ethernet port Alarm
1 input, 1 output (max. 12 VDC, 30 mA), terminal block
Video Output
1Vp-p composite output (75 Ω) (For adjustment only)
On-board storage
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
SVC
Support H.264 and H.265 encoding
Reset Button
Yes
Audio
Environment Noise Filtering
Yes Audio Sampling Rate
8kHz/16kHz/32kHz/44.1kHZ/48kHz
General
Operating Conditions
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Web Client Language
32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish,
Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil)
Power Supply
12 VDC ± 25%, PoE (802.3af) Terminal block for DC input
Power Consumption and Current
12 VDC, 0.75A, max. 9.5W PoE (802.3af, 36V to 57V), 0.3A to 0.1A, max. 11W
Protection Level
IP66, IK10
Unit: mm(inch)
133
.2
(5.24
")
100.4 (3.95")
83
.6
(3.29
")
Φ45 (1.77")
46 (1.81")
Φ153.4 (6.04")
46 (1.81")
DS-1471ZJ-155
Pendant Mount
DS-1473ZJ-155
Wall Mount
DS-1475ZJ-SUS
Vertical Pole Mount
DS-1476ZJ-SUS
Corner Mount
DS-1227ZJ-DM37
In-ceiling Mount
DS-1471ZJ-155(Black)
Pendant Mount
DS-1473ZJ-155(Black)
Wall Mount
DS-1475ZJ-SUS(Black)
Vertical pole mount
Material
Metal
Dimensions
Φ153.4 × 133.2 mm (Φ6.04" × 5.24")
Weight
Camera: 1287 g (2.84 lb.)
Available Model:
DS-2CD2725FWD-IZS
Accessories
Dimensions
