Hetronic MFS RX 2G4 User Manual

User’s Manual

MFS-RX-2G4

1. DESCRIPTION

The MFS-RX-2G4 is a 2.4GHz MFS Receiver with 16 digital outputs, 1 PWM output, 1 main contact
output, 4 digital inputs, and 4 analog inputs. The 16 digital outputs are individually configurable for on/off
delay, normally open or normally closed (NO/NC) output, output latching, and output assignments of DK or
configurable logic functions. The PWM output is configurable for normal or inverted outputs, dithering, and
up to 4 speed settings defined per DK and selectable by digital output, digital input, load limit, or logic
functions.

Note: Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.

2. TECHNICAL SPECIFICATIONS

Temperature Range -30o to +70o Celsius
Supply Voltage Range 6-36 VDC
Supply Current <80mA @ 12V (No External Load)
Outputs 16 Digital (Max: 6A single, 135°C)

1 PWM (Max: 4A)
1 Main Contact (Max: 25A, 125°C)
1 5 VDC Supply (Max: 300mA)
9 Status LEDs
RF/Cable Backup Feedback

Inputs VSW Supply (6-36VDC)

4 Digital (0-36VDC Digital, High above 4V)
4 Digital/Analog (0-10VDC or 0-20mA)
1 Learning Switch
RF/Cable Backup Data

Note: The user is cautioned that changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to operate the
equipment.
