HETRONIC ERGO-F 2.4 GHz Technical Data Sheet
E
E
E
GGeenneerraall ddeessccrriippttiioonn
• Forward-thinking and safe frequency technology, suitable for multiplex applications
• Ergonomically designed transmitter housing with large push-buttons, ideal for one-hand-
operation
• Range of application: industrial applications, building industry, vehicle technology,
agriculture, etc.
• Standard for 4 driving operations , 3- and 4- wire-technology available
• Stop button, status display, toggle switch for selection of lifting unit or crab (1/1+2/2)
• Combined with the new RX-AC-16 2.4 an ideal solution for standard and customized
applications
CCoonnttrrooll ffuunnccttiioonnss aanndd aacccceessssoorriieess
n Start button
o Stop button and memory chip
p Push buttons
q LED status display
r Toggle switch
s Option: HETRONIC battery charger with battery
(Original parts set of HETRONIC)
R
R
R
G
G
G
T
e
T
e
T
e
O
O
O
n
c
c
c
-
-
-
h
h
h
F
F
F
n
n
n
i
c
i
c
i
c
2
2
2
.
.
.
a
a
a
4
4
l
l
l
4
q
D
D
D
o
a
a
a
G
G
G
t
a
t
a
t
a
H
H
H
S
z
z
z
S
S
r
h
h
h
e
e
e
e
e
e
p
t
t
t
t
©2011 Hetronic Germany GmbH
Version 1.4
hetronic.de
T
SSaaffeettyy cchheecckk
Attention: You have to read and understand the operating manual of the radio remote control
Check the proper operation of the stop button before operating the machine.
Please check the following items each time before using the system!
; Check the transmitter for damages
; Check the function of the stop button by means of the LED status display r
(transmitter ON: LED is flashing green / stop button pushed: LED is flashing red, transmitter off)
OOppeerraattiioonn ooff tthhee ttrraannssmmiitttteerr
The transmitter may only be operated by instructed persons!
Insert a fully charged battery into the battery compartment of the transmitter.
Start the transmitter using the start button
status display q lights up red and fades to flashing green. After the system check you can start the
system by activating the start button n. You can control the designated function with the push buttons
p or the toggle switch r
The acitvated functions are now transmitted to the receiver. The individual functions of the buttons are
described in the enclosed drawings!
Your can stop the system using the stop button
LED status display: flashing (green) = transmitter activated
flashing (red/green) = low voltage of the transmitter
flashing (red) = transmitter stopped
TTeecchhnniiccaall DDaattaa
Material Polyamid with glass fibre
Weight 330 g
Dimensions H 185/ B 82/ T 35 mm
Diagnostics Status LED
RF technology Synthesizer
RF output < 10 mW
Temperature range -25° up to +70° C
Antenna internal
Frequency range 2.4 GHz technology (approved
Safety address 20 bit (1 Mio.)
Protection type IP 65 (exceeds Nema 12/13)
Operating time approx. 8 hours
Power supply 3,6 V DC
