Heidolph Rotacool User Manual
Instruction manual
ROTACOOL
E
2
E
Key
Page 2
1 Cover
2 Cooling liquid connection
3 Right threaded socket
4 Left threaded socket
Page 3
5 Cup
6 Display
7 ‘Cooling’ LED
8 ‘Pump’ LED
9 On/Off button
10 Main switch
11 ‘SET’ button
12 ‘’ button (decrease value)
13 ‘’ button (increase value)
14 Filling level indicator
15 Extension kit
16 Base of the housing
17 Platform
18 Sealing screw
19 Discharge socket
20 Discharge valve
21 Unit socket
22 Rotary evaporator
23 Vacuum pump
24 Connecting tube
3
E
Important information
Advice about power cord / mains supply
Caution: mandatory action
Description
Quantity
Order Number
Circulating chiller ROTACOOL 230V 50Hz
1
591-00200-00
or
Circulating chiller ROTACOOL 115V 60Hz
1
591-00200-01
Cooling liquid connection
M 16 x 1/NW 8/12
2
11-300-005-23
Cover
1
23-30-01-03-12
Extension kit
1
21-300-005-57
Connection cable for Europe (230V 50Hz)
1
14-007-003-81
or
Connection cable for USA (115V 60Hz)
1
14-007-003-89
Operating instructions
1
01-005-002-77
Thank you for buying this unit. You have acquired a product that was manufactured and
tested by Heidolph in accordance with the highest quality standards. We hope it will enable
you to carry out your work easily and to your complete satisfaction.
CONTENTS
PACKING LIST ..................................................................................................................... 4
OUTLINE DESCRIPTION ..................................................................................................... 5
GENERAL INFORMATION ................................................................................................... 5
SAFETY INSTRUCTIONS .................................................................................................... 6
ASSEMBLY .......................................................................................................................... 6
OPERATION ................................................................ ......................................................... 9
ROUTINE CLEANING AND SERVICING .............................................................................10
DISMANTLING, TRANSPORT AND STORAGE .................................................................10
DISPOSAL ...........................................................................................................................10
TROUBLESHOOTING .........................................................................................................11
TECHNICAL DATA ..............................................................................................................12
WARRANTY / EXCLUSION OF LIABILITY / COPYRIGHT ................................................. 12
QUESTIONS / REPAIR WORK ............................................................................................13
CE DECLARATION OF CONFORMITY ...............................................................................13
PACKING LIST
Please make sure the package contains the following parts:
4
E
Unpack the unit and its components carefully and compare the contents with
the packing list. If you discover any damage or deviations from the packing list,
notify your supplier immediately.
Read the instruction manual carefully and make sure that anyone else who will
be operating the unit also reads it thoroughly before use.
Keep the instruction manual accessible to everyone at all times.
This unit is equipped as standard with a Euro plug (DIN 49441 CEE 7/VII 10/16
A 250 V) or with a US standard plug (NEMA Pub. No. WDI-1961 ASA C 73.1 –
1961 page 8 15 A 125 V) for use in North America. Where connection to a
different mains supply is required you must use an approved adapter or arrange
for an electrician to replace the supplied plug with a 3-pin plug designed and
approved for the mains supply in question. The unit is delivered in earthed
condition. If the original plug is ever changed, make sure that the protective
earthed conductor from the unit is connected to the new plug. Color code used
for wiring inside the unit:
GREEN/YELLOW = earth (PE)
BLUE = neutral (N)
BROWN = live (L)
IN GREAT BRITAIN, AN APPROVED STANDARD 13A PLUG TO BS 1363 (3PIN PLUG) IS NECESSARY.
OUTLINE DESCRIPTION
CFC-free circulating chiller in a L-shaped design for Heidolph rotary evaporators. A Heidolph
rotary evaporator (22) and a Heidolph vacuum pump (23) can be fitted on the circulating
chiller to save space (Heidolph Instruments or your local Heidolph Instruments dealer will be
glad to provide more information about suitable models). The circulating chiller is equipped
with an air-cooled refrigerating machine and a circulating pump. The heat exchanger
(condenser), pump and housing are made of stainless steel. The cooling liquid is contained
in an atmospherically open expansion vessel while the external coolant circuit is closed.
Temperature controller with digital display for actual and target values, constant control,
temperature stability 0.5 K.
GENERAL INFORMATION
5
