Hatco GRCD-3PDG, GRCDH-2PD, GRCDH-3PD, GRCDH-2PDG, GRCDH-3PDG Specifications

ANSI/NSF 4

GLO-RA Y

Models GRCD-2PDG, GRCD-3PDG, GRCDH-2PDG, GRCDH-3PDG

For hot meals-to-go, the Hatco Glo-Ray
Designer Heated Glass Display Cases
feature innovative technology that
improves heated merchandising while
generating more impulse sales. The
transparent shelf utilizes a patented
heated glass, which radiates heat down
while conducting heat up, allowing you
to hold foods longer and safer at
optimum serving temperatures.

FLEXIBILITY

These Hatco merchandisers are
available in two-pan and three-pan
models, doubling the holding capacity
while using the same amount of
counterspace and increasing product
visibility. The slim-line profile provides
safe and higher clearance.

The patented heated glass shelf
provides an even heat source for top
and bottom heat to safely hold product,
along with superior visibility to promote
and display product.

A vast array of options include
humidified models, mirrored glass doors,
pan skirt (bottom shelf only, standard on
humidified units), backlit base sign holder,

Designer powdercoated colors of

and
warm red, black, gray granite, white
granite, navy blue, and hunter green.

QUALITY

The following features assure the finest
performance for years to come.

• The patented heated glass shelf
provides an even heat source for top
and bottom heat to safely hold
product.

• High visibility merchandiser with
curved tempered glass.

Hinged fr

•
for easy cleaning.

• These merchandisers feature a
thermostatically-controlled heated base
with exclusive cool base construction.

All models are shipped with 4" (102 mm)

•
adjustable legs and factor
6' (1829 mm) cord and plug.

Shatter

•
enhance pr
safeguarding food products from
bulb breakage.

ont glass panel tilts forward

y attached

esistant incandescent lights

-r
oduct display while

ITEM#

®

DESIGNER HEATED GLASS DISPLAY CASES

Model GRCDH-3PDG in

Designer color

optional
with accessory pans

Model GRCD-2PDG in
optional

with accessory pans

Designer color

HEATED GLASS SHELVES AND BASE BLANKET
HEATING ELEMENTS ARE WARRANTED AGAINST
BURNOUT FOR ONE YEAR.

HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A.
[phone] • [phone] • Fax [phone] • Int’l. Fax: [phone]

.hatcocorp.com • E-mail: [e-mail]

www

m No. GRCD-PDG-1006(S)

For

Printed in U.S.A.

ITEM#

321⁄2"or 451⁄2" (826 or 1156 mm)

FRONT VIEW

313⁄4"

(806 mm)

SIDE VIEW

26" (660 mm)

25"

(635 mm)

151⁄4"

(387 mm)

®

GLO-RA Y

DESIGNER HEATED GLASS DISPLAY CASES

Models GRCD-2PDG, GRCD-3PDG, GRCDH-2PDG, GRCDH-3PDG

SPECIFICATIONS

Designer Heated Display Cases

†

•

Model

GRCD-2PDG 321⁄2" (
GRCD-3PDG 45

Designer Heated Display Cases with Humidity

†

•

Model

GRCDH-2PDG 321⁄2" ( 826 mm) 1380 11.5 174 lbs. ( 79 kg)
GRCDH-3PDG 45

†

Model number indicates number of full-size food pans bottom shelf
will accommodate.

•

NSF requires units over 36" (914 mm) in width or weighing more than
80 lbs. (36 kg) to be either sealed, or raised on the installation surface
with the 4" (102 mm) legs included.

‡

Humidity on bottom shelf only.

The use of metal pans or ceramic dishes on the glass shelves may scratch
the glass. Hatco’s warranty does not cover scratches to the shelves.
It is recommended that the glass shelves be used for food products contained
in disposable paper or plastic containers or wrapping.

Width Watts Amps Shipping Weight

826 mm)

1

⁄2" (1156 mm) 1665 13.9 218 lbs. (99 kg)

1130

9.4 170 lbs. (77 kg)

‡

Width Watts Amps Shipping Weight

1

⁄2" (1156 mm) 1915 15.9 222 lbs. (101 kg)

OPTIONS (NOT FOR RETROFIT)

❑ Designer Colors: Warm Red, Black, Gray Granite,

White Granite, Navy Blue, Hunter Green

❑ Pan Skirts (Bottom shelf only, standard on

GRCDH models)

❑ Mirrored Glass Doors on Server's Side
❑ Halogen Bulbs in lieu of Standar

d Display Lights

DIMENSIONS

321/2

" or 451/2

"W x 26"D x 313/4

"H w/legs

(826 or 1156 x 660 x 806 mm).

VOLTAGE

120 volts, single phase.
GRCD-2PDG, -3PDG, and GRCDH-2PDG use NEMA 5-15P
(GRCD-3PDG uses NEMA 5-20P for Canada).
GRCDH-3PDG uses NEMA 5-20P.

CORD LOCATION

Control side at right base corner.

PLUG CONFIGURATIONS

NEMA 5-20PNEMA 5-15P

ACCESSORIES

❑ Display Sign Holder
❑ Food Pans

PRODUCT SPECS

Designer Heated Display Case

The Designer Heated Display Case shall be a Glo-Ray®Model

....as manufactured by the Hatco Corporation, Milwaukee, WI

53234 U.S.A.

The Display Case shall be rated at ....watts, ....volts, and be ....

inches (millimeters) in overall width. It shall consist of a
thermostatically controlled heated base, a patented heated
glass shelf, full view tempered glass sides, incandescent and
fluorescent display lights.

HATCO CORPORATION P.O. Box 340500 Milwaukee, WI 53234-0500 U.S.A. • [phone] • [phone]
Fax [phone] • Int’l. Fax [phone] • www.hatcocorp.com • E-mail: [e-mail]

Form No. GRCD-PDG-1006(S)

The infrared heating element shall be tubular metal sheathed
and the warmer shall have a cord with plug attached.

Printed in U.S.A.
