SPRING/SUMMER 2008 CATA LOG HOME/CAR/MULT IMEDIA
02 03
TABLE OF CONTENTS
AT HOME 08
IN THE CAR 34
ON THE GO 40
SPECIFICATIONS 44
WELCOME
As a consumer electronics company, the Harman Kardon® brand dates
back to the days of monaural sound and vacuum tubes. And yet here we
are, still going strong after more than 50 years, still headed by our founder,
Dr. Sidney Harman, and still following our own path, in our own way. Over
the years, landmark Harman Kardon products led the transition from
vacuum tubes to solid state, from mono to hi-fi, and from analog to digital.
With features that often broke new ground, and performance that
always set higher standards, nothing else ever looked or sounded quite like
Harman Kardon components. That’s just the way we always wanted it. And
that’s the way it still is.
04 05
* iPod touc h not included.
TECHNICAL PHILOSOPHY
Harman Kardon products were delivering high bandwidth before most people
realized it was a good thing. Technology leaders can only lead by example, and
we’ve been setting a series of very good examples for more than 50 years.
Many of the technologies found in today’s finest amplifiers were introduced
in Harman Kardon audio equipment. And we’ve always been quick to adopt
and improve on any good ideas we didn’t actually think of ourselves. It doesn’t
happen often, you understand, but it happens.
0706
AT HOME
08 09
AUDIO/VIDEO RECEIVERS
A maximum number of options, a minimum number of buttons.
Harman Kardon A/V receivers employ the industry’s most advanced
technologies to optimize the audio and video clarity of any
entertainment source, old or new. Yet even certified technophobes
will discover that they can operate them successfully.
/ AUDIO/VIDEO RECEIVERS
AVR 354
7 x 75W 7.1-Channel A/V Receiver with HDMI™ 1.3a Repeater, Audio/Video Processing and Upscaling to 1080p
The AVR 354 includes a full complement of Dolby® an d DTS® decoding technologies, HDMI™ repeater capability, Faroudja DCDi Cinema™
processing, EzSet/EQ™ equalization and multiroom capability. It connects to a universe of digital and analog sources, as well as to
external amps. And with The Bridge II docking station (included), it will even play, control and charge your iPod. To ensure that everything
works together seamlessly, the AVR 354 features a full-color graphical user interface and an eight-device programmable remote.
Harman Kardon founder Dr. Sidney Harman has always believed technology should serve users, not intimidate them. The AVR 354 is a
perfect case in point.
10 11
AVR 254
7 x 50W 7.1-Channel A/V Receiver with HDMI 1.3a Repeater, Audio/Video Processing and Upscaling to 1080p
The AVR 254 is the most affordable Harman Kardon receiver to feature both Dolby TrueHD and DTS-HD Master Audio™ decoding on the
audio side, and Faroudja DCDi Cinema video processing to 1080p on the video side. But there’s plenty more to recommend the AVR 254,
including three HDMI inputs, connections for external amplifiers, EzSet/EQ technology to fine-tune your system to the acoustics of your room,
and an RS-232 port for future firmware upgrades. Perhaps the highest recommendation of all? As do all Harman Kardon A/V receivers, the
AVR 254 features a high-current, ultrawide-bandwidth design for maximum fidelity.
AVR 154
5 x 30W 5.1-Channel A/V Receiver with HDMI Switching
The Harman Kardon AVR 154 is all about getting connected. It features three HDMI inputs, two wide-bandwidth HDTV-ready component
video inputs, four S-video inputs, a front-panel input for video game consoles, an auxiliary input for portable media players, and a portfolio of
advanced surround processing technologies, including Dolby Digital, DTS and Logic 7® processing. But the AVR 154 is also about ease of
use, and it features a high-current, ultrawide-bandwidth design for maximum fidelity.
/ DOCKING STATION FOR iPod
12 13
The Bridge II
Docking Station for iPod
Is your home entertainment system incomplete without music from
your iPod? Thanks to The Bridge II docking station, connection and
control are completely within your power. The Bridge II connects
directly to Harman Kardon The Bridge-ready products and allows
you to use your system’s remote to seamlessly select and play audio
and video content – guided by easy-to-read on-screen or front-panel
messages. Let the (gloriously uninterrupted) music begin.
iPod touc h not included.
BUSINESS PHILOSOPHY
We didn’t start with a business plan in 1953 – we started with a product. We
weren’t looking to find a marketing niche for ourselves – we were looking to
build audio components that satisfied our own passion for music. We built our
very first systems for ourselves and a handful of others who could hear what
we heard. These days, Harman Kardon, Inc., has a business plan, R&D labs and
a marketing department – everything a prestigious company should have. But
we’re still building systems for people who hear what we hear.
1514
16 17
STEREO RECEIVERS
Introduced 50 years ago this year, the Harman Kardon Festival TA 230 was the
world’s first stereo receiver. Today, we continue to keep the audio faith with a choice of
powerful stereo receivers engineered by and for people who prefer to be entertained
with their eyes closed. We’re passionate, to be sure, but we’re not zealots. Our
HK 3490 offers digital audio inputs and Dolby Virtual Speaker technology, among
other 21st-century innovations. Time marches on, and Harman Kardon products
march with it.
/ STEREO RECEIVERS
HK 3490
2 x 120W Stereo Receiver
The insanely powerful HK 3490 combines all of an audiophile’s must-haves (high-performance phono preamp,
preout/main-in jacks, high-current amplification) with an array of multichannel extras (digital-audio inputs,
video switching, dual subwoofer outputs and Dolby Virtual Speaker technology). Add The Bridge II docking
station for iPod, and the HK 3490 will connect as elegantly to your newfangled iPod as it does to your time-
honored turntable. The HK 3490 isn’t a snob about where the music comes from, as long as it sounds great
when it reaches its final destination: your ears.
18 19
HK 3390
2 x 80W Stereo Receiver
The HK 3390 was born to make beautiful music and, like all specialists, it’s very good at what it does. It features
high-current, ultrawide bandwidth amplification, a signature Harman Kardon technology that delivers all the
subtlety of an original musical performance, whether reproduced from vinyl or your MP3 player of choice. But
even specialists enjoy a change of pace from time to time. So the HK 3390 also features four high-quality
composite video inputs, and convenient front-panel inputs for video game consoles and portable audio players.
/ DVD PLAYERS
More than a few of the earliest Harman Kardon products – some of them pushing 50 by now – are still in
use today, and some of our earliest CD and DVD players are surely among them. But to fully experience
the very highest resolution of today’s digital sources, you’ll need our newest DVD player. We know
upgrading isn’t always a joy. But we promise that you’ll notice the difference.
20 21
DVD 48
DVD-Audio/Video and SACD™ Player with HDMI Connectivity
One of the most advanced Harman Kardon DVD players, the DVD 48 is among the most sophisticated
of its kind. The DVD 48 features an HDMI connection, scales older video discs to 1080p with DCDi
by Faroudja® technology, and offers unsurpassed fidelity in the reproduction of DVD-Audio and
SACD™ discs, as well as MP3 and WMA files. Do try all of this at home. The DVD 48 makes it easy.
/ DIGITAL MEDIA CENTERS
It has long been a dream to create a media server that works like an entertainment device, not
a computer. This ideal player would be conversant in a universe of digital storage technologies
and formats, serving as the one go-to device to finally bridge the gaping DVD/CD/music
system/cell phone/camera divide. This is no longer just a dream – behold the Harman Kardon
Digital Media Center.
As awarded by The Chicago Athenaeum: Museum of Architecture and Design.
In the Permanent Design Collection of The Chicago Athenaeum: Museum of Architecture and Design.
22 23
DMC 1000
Four-Stream Digital Media Center with Progressive-Scan DVD-Video Playback and 250GB Internal
Hard Drive
Smaller, but vastly smarter and better looking than your average CD storage rack, the DMC 1000 will digitize, catalog and store more than
60,000 songs as you play them, allowing you to banish your CDs – and CD storage racks – to the attic. It will also let you send up to four
different audio selections to other rooms of your house at once. With touch-sensitive front-panel controls (the ultimate no-button design),
a concealed front-panel USB jack and hidden memory card slots, the DMC 1000 will even let you transfer your music for use in portable
players, card-equipped cars and cell phones. And your iPod? Enjoy playback, control and charging with The Bridge II docking station for
iPod (sold separately and very much worth it).
MULTIROOM PRODUCTS
One-room systems are only ideal for one-room apartments. All Harman Kardon
7.1-channel AVR receivers are built with multiroom applications in mind. All include
assignable rear-channel amplifiers, all offer a second-zone control system, and the
AVR 354 includes a second-zone remote control. Which means Harman Kardon
multiroom systems are easy to set up and use. So go ahead, spread out and enjoy
yourself. Your Harman Kardon entertainment system will be there for you.
2524
/ MULTIROOM PRODUCTS
ABH 4000
Four-Zone/Eight-Room A-BUS® Expansion Hub
Different music in different rooms. With an ABH 4000 expansion hub and up to four different input sources (including your
Harman Kardon AVR), you can easily divide your house into four separate entertainment zones, where individual musical tastes
may prevail. Link in an A-BUS®-equipped Harman Kardon product and make its tuner and The Bridge II docking station for iPod
accessible from throughout the realm. May domestic bliss and your favorite music be with you.
26 27
ABH 4
Four-Room A-BUS Expansion Hub
HE 1000
External Infrared Remote Sensor
One ABH 4 = four rooms; more ABH 4’s = many more rooms. With
A-BUS-equipped Harman Kardon products, the more ABH 4’s you
have, the more rooms you can serve − and the more music-hungry
constituents you can satisfy. But even without A-BUS technology,
the ABH 4’s onboard audio inputs allow you to distribute audio from
any receiver’s “Tape” or “Multiroom” outputs to any room. As usual,
Harman Kardon products have got you covered.
AB 2
Amplified In-Wall Module with Onboard Controls for
A-BUS Applications
The ultimate keypad. The AB 2 connects to your A-BUS-equipped
Harman Kardon products or ABH expansion hub to power your local
speakers without an additional amplifier. Also, it easily allows you to
select and control your listening sources as you enter a room (and its key
caps are swappable, to mirror your system), or to power the system off
as you depart. And during your stay? The AB 2 has an infrared sensor
to relay your every wish to the AVR with virtually any Harman Kardon
remote control.
We don’t know of many people hiding Harman Kardon components
behind closed doors, but just in case, a remote sensor for your
system’s IR remote control only makes sense. One or more HE 1000’s
can put you in control of your AVR from anywhere in your home. And
although it’s usually considered impolite to point, the IR sensors don’t
seem to mind.
AB 1
Amplified In-Wall Module for A-BUS Applications
Often located next to the light switch, and every bit as important.
Controlling your A-BUS-equipped Harman Kardon products in remote
rooms and powering the remote-room speakers is as simple as a
single connection to the AVR or the nearest ABH expansion hub, and
a link to the speakers. That will give you the option of controlling local
volume with the AVR’s second-zone remote, or directly from the AB 1.
DESIGN PHILOSOPHY
Ludwig Mies van der Rohe borrowed “less is more” from Robert Browning.
We borrowed it from Mies. Minimalism has long been a major force in
architecture, music and design. It’s also been one of our guiding principles
from the very beginning. The Harman Kardon team believes that good
design consists of essential elements presented in their purest form, with
an absence of excess or decoration. We could go on and on about this, but
that would be icing on the cake. We don’t do icing.
2928
30 31
HOME THEATER SPEAKER SYSTEMS
Let Harman Kardon home theater speaker systems make this simple for you. As
you probably know, a 5.1-channel speaker system consists of four satellite speakers,
a center channel speaker primarily for dialogue, and a powered subwoofer. So if
you’re ordering à la carte, that’s four from column A, one from column B and one
from column C. Simple enough. Except the center ought to be voice-matched to the
satellites, the sub shouldn’t overpower the center or the satellites, and all six should
be matched to your electronics. Suddenly, it’s not that simple. Unless you simply
choose one from the column of Harman Kardon HKTS speaker packages.
/ HOME THEATER SPEAKER SYSTEMS
HKTS 18
5.1-Channel Home Theater Speaker System
The speaker package for people who hate it when people talk during movies. The HKTS 18 is a powerful 5.1-channel solution with
dual midrange drivers in both the satellites and the center channel for heightened realism, and a 200-watt powered subwoofer for
bass that isn’t one bit intimidated by all that heightened realism. And those talkers? We guarantee they’ll find this a tough act to
compete against.
HKTS 15
5.1-Channel Home Theater Speaker System
Please have your tickets ready. With a dual-driver center channel speaker for vivid, distinct movie dialogue, four compact but powerful
satellites to pull you into the action, and a 100-watt powered subwoofer for heart-stopping bass, the HKTS 15 system is more than
equal to all the excitement Hollywood is dishing out these days. Worlds colliding? Total nuclear annihilation? Child’s play.
32 33
HKS 6
Surround Speakers
Don’t look behind you. There’s nothing back there but your HKS 6
speakers, faking you out by delivering a back channel that the
5.1 HKTS 15 system, by itself, cannot. We’ll admit that it can be a little
spooky at first, especially if it sounds like the overnight delivery guy
driving up, or anything else that might actually be happening in the
real world. But you’ll learn to cope.
HKS 9
Surround Speakers
No matter how good things get, there’ll always be an upgrade.
HKS 9 speakers are identical to HKTS 18 speakers, except that they’re
available in pairs, for easily upgrading a 5.1-channel HKTS 18 system
to 7.1 channels. The additional speakers add a surround back channel
for the ultimate in cinema-like sound.
HTFS 2
Floor Stands
Designed to position any HKTS satellite at an ideal height for seated
listeners, these aluminum floor stands feature a cable-management
system to keep speaker wires out of sight. (You’re welcome.)
IN THE CAR
CAR SOLUTIONS
We’re one of the world’s leading suppliers of automotive audio and infotainment
systems; our products are found in the premium cars of major manufacturers. But
even if a Logic 7 multichannel audio system isn’t in your budget this year, our elegantly
designed and easy-to-use products mean you can still enjoy superb Harman Kardon
sound in your car.
3534
/ PORTABLE NAVIGATION
HARMAN KARDON GUIDE + PLAY
They’re small. They’re portable. And they’re changing the way drivers drive and how passengers
pass the time. All Harman Kardon Guide + Play
turn-by-turn directions to virtually any destination, with a choice of music along the way. Some add
video and communications capabilities. But none requires drivers to take their eyes off the road.
After all, their first job is to get you where you’re going safely.
™
GPS navigation and entertainment products offer
™
GPS-810
4.3" Portable Navigation System
A bright 4.3" touchscreen display. An innovative, mount-anywhere wireless controller. Superfast route calculation. Bluetooth®
hands-free phone functionality. Real-time traffic.* Text-to-Speech. And all your favorite music, movies and photos along for the
ride. The Harman Kardon GPS-810 has it all – and works more easily and intuitively than any other system out there.
36 37
GPS-510
4" Portable Navigation System
The GPS-510 is a full-featured portable GPS navigation system, digital music player
and widescreen video player that fits in the palm of your hand. Your MP3, WMA and
AAC music and MPEG-4 and WMV9 video files are only a download away. Is there
traffic ahead? The built-in real-time-traffic* receiver will let you know, so you can quickly
calculate an alternate route.
GPS-310
4" Portable Navigation System
The GPS-310 is the ultimate all-in-one navigation and entertainment system. Its
full-browse music player will provide the soundtrack to get you where you need to go.
* Subscr iption req uired (fi rst 90 day s free) .
/ CONTROL FOR iPod
DRIVE + PLAY™ 2
Your car is a great place to listen to music. And the Apple iPod is a great way
to bring your favorite tunes along for the ride. But how can you get at your
songs and playlists without taking your mind off your driving? The innovative
Harman Kardon Drive + Play
capabilities of your iPod. And it is designed to work with existing car audio
systems. Browse by artist, album, song, genre or composer. Scroll through
your playlists. Jump ahead to the next track or play the last one over and
over. All from the driver’s seat. All without taking your eyes off the road.
™
2 system gives you all the music-browsing
38 39
Drive + Play 2
Mobile Media Manager
The next generation of in-car media-player interfaces. The Drive + Play 2 system not only controls your iPod, it offers full access
to audio tracks located on all kinds of USB flash devices. The 3.5" high-resolution color display shows full-color album art and
anti-aliased text. The wireless five-button controller lets you generate your own music mixes and control additional Harman
Kardon accessories. The Drive + Play 2 unit plugs directly into your car’s cigarette-lighter port and plays high-quality
audio through a built-in wireless FM transmitter or 3.5mm line outputs.
ON THE GO
MULTIMEDIA SOLUTIONS
For the last 10 years, Harman Kardon, Inc., along with key computer
manufacturers such as Apple, Dell, Compaq and Toshiba, has been leading
the way in the design and supply of high-quality loudspeakers for use in
multimedia-rich computer systems. Today, our expertise has been applied
to products we’ve designed for use with your own computer and for other
multimedia devices, including the iPod, that you may own. It all began with the
SoundSticks® system, now part of the permanent collection of New York
City’s Museum of Modern Art. Our award-winning loudspeaker systems are
also on display at your local retailer, where you can pick up a piece of design
history for yourself.
4140
/ MULTIMEDIA SOLUTIONS
SoundSticks® II
Self-Powered Satellite Speakers and Subwoofer System
Clearly superior. An awesome 20-watt powered subwoofer. Eight full-range transducers. Plug-and-play compatibility with virtually any
multimedia device. And a museum-honored design that perfectly matches the clarity of the sound. The Harman Kardon SoundSticks II
system brings a new level of excitement to music, games and movies − and looks spectacular doing it.
42 43
iPod not included.
Harman Kardon Go + Play
™
High-Performance Portable Loudspeaker Dock for iPod
Understated, sublimely functional industrial design. Unsurpassed performance and ease of use. From its flat iPod
cradle and smart RF remote to its arching stainless-steel handle, this is the loudspeaker dock that only we could build.
It delivers tight, accurate bass from high-excursion low-frequency drivers and, just as important, its highs are distinct
™
and crystal clear. The Harman Kardon Go + Play
loudspeaker dock is AC- or battery-operated, so it will go anywhere
your iPod or other music player goes − and make your favorite music sound better when it arrives.
/ SPECIFICATIONS
Mod el AVR 354 AVR 254 AVR 154
Desc ription 7.1-Cha nnel AVR 7.1-Cha nnel AVR 5.1-Channel AV R
Ster eo Power 75 x 2 65 x 2 40 x 2
Mult ichannel Po wer 75 x 7 50 x 7 30 x 5
Ampl ifier Type High-c urrent; ± 35 amps High-c urrent; ± 35 amps High-c urrent; ± 25 amps
TH D @ Impedan ce 0.07% @ 8 Ohm s 0.07% @ 8 Ohm s 0.07% @ 8 Ohms
Band width 20Hz – 2 0kHz 20Hz – 2 0kHz 20Hz – 2 0kHz
Band width @ 1W (+0dB /–3dB ) 10Hz – 130k Hz 10Hz – 130k Hz 10H z – 130 kHz
Signal-to-N oise Rati o (IH F-A) 100dB 10 0dB 100 dB
®
Dolby
Digita l Dolby® Digita l Plus Dolby® Digita l Plus Dolby® Digita l
®
Dolby
Pro Logi c® II Pro L ogic® IIx Pro Logic® IIx Pro Logic® II
®
Dolby
Virtu al Speake r Yes Yes Yes
Head phone Modes 2-C hannel, Do lby
®
Dolby
TrueHD Yes Yes No
®
DTS
5.1 Yes Yes Yes
®
DTS-ES
6.1 Discrete & M atrix Yes Yes No
DTS 9 6/24
DTS N eo: 6
DTS
DTS -HD Master Aud io
Logi c 7
iPod P layer Conn ectivi ty
XM Ready
™
Yes Yes Yes
®
Yes Yes Up to 5 cha nnels
®
High Res olution Yes Yes No
®
™
Yes Yes No
(up to 9 6kHz ) Yes Yes Yes
®1
Tuner Yes Yes No
Mult izone Cap ability A udio, with r emote Audio No
Ass ignable Re ar-Channel A mplifiers Yes Yes No
®
EzSet
Capabi lity EzS et/ EQ™ EzSet/ EQ™ No
A /V Inp uts 4 4 4
S-V ideo Inpu ts 4 4 4
Anal og Audio Inputs 6 6 6
Digit al Audio Inputs Rear panel 2/3 , Rear pane l 2/2, Rea r panel 2/ 2,
(Co ax/ Optical) fro nt panel 1/1 front pan el 1/1 front pan el 1/1
Digit al Audio Output s (Coax/ Optical) Rear panel 1/0 Rear panel 1/ 0 Rear pan el 1/0
Digit al Input Polling Yes Yes Yes
Direc t Audio Inputs 7.1 7.1 5.1
™
HDMI
Inputs /Output 3/1 3/1 3 /1
™
HDMI
Type V1.3a with De ep Color; f ull V1.3a w ith Deep C olor; full V1.3a swit ching
A/ V processing & rep eater A/V pro cessing & re peater
1080 p Yes wit h OSD Yes wit h OSD Pas s-through
Pream p Output s 7.1 Cha nnels 7.1 Cha nnels S ubwoofer
Comp onent Video Inpu ts 3 @ 100MH z (Ass ignable ) 2 @ 100M Hz (As signable ) 2 @ 100MHz
Bas s Manageme nt Qu ad crossov er Qu ad crossov er Triple crossover
On-S creen Display HD graphi cal menu sys tem HD graph ical menu sy stem Text- based men us
Inpu t Titling All inputs All inp uts All inputs exc ept tuner
DS P Process or Cirrus
Output DACs 192kHz/ 24- bit 192kHz/ 24- bit 192kHz /24-bit
Vide o Processing /Conv ersion Farou dja DCDi C inema
scaling /processin g to 1080p sc aling/proc essing to 108 0p
Lip S ync Delay 180mS 180mS 180mS
IEC D etachable Power C ord Yes No No
Sys tem Remote 8-Dev ice learni ng & program mable; backlit 7-D evice prog rammable 6 -Devic e programma ble
IR- In/Out Ja cks Yes Yes No
IR Ca rrier Ou tput Yes No No
Disc rete Remot e-On /Off Code s Yes Yes Yes
Upgr ade Data Port RS -232 RS-232 No
Spea ker Ter minals Color-c oded bindi ng posts Colo r-coded bin ding post s Col or-coded binding post s
Dimen sions ( H x W x D) 6-1/2 " x 17-5/ 16" x 15" 6-1/2" x 17-5/16" x 15" 6-1/ 2" x 17-5/16" x 15"
Weight 31.5 lb 27.7 lb 20.5 lb
* Models wit h docking connec tor includi ng iPod tou ch.
1
Optional X M® antenna module and sub scripti on to XM ser vice required. Ha rdware and servic e sold separ ately.
XM ser vice is not av ailable in A laska or H awaii.
®
HP 2-Channel, Dol by® HP 2-Channel, D olby® HP
* included ( audio/vi deo playba ck) Mini jack in put (aud io playback) Mini jack in put (aud io playback)
®
CS 4970 0 Cirr us® CS 4970 0 Cirrus® CS 49510
™
F aroudja D CDi Cinem a™ No
44 45
Mod el HK 349 0 HK 339 0
Desc ription St ereo recei ver Stereo r eceiver
Power @ 8 O hms, <0.07% TH D 120 x 2 80 x 2
Power @ 4 O hms, <0.2% TH D 150 x 2 100 x 2
Band width 20Hz – 2 0kHz 20Hz – 2 0kHz
HCC (Amps ) ±4 5 ±42
Band width @ 1W (+0, –3 dB) 10Hz – 110kHz 10Hz – 110kHz
Disc rete Ampli fier Output Devi ces Yes Yes
Digit al Inputs (2- Ch PCM ) (Coax /Optical ) 1/1 0
Audi o Inputs 7 7
Vide o Inputs 4 ( 1 on front pa nel) 4 (1 on fron t panel)
Vide o Outputs 1 1
XM Ready
®1
Tuner Yes No
The B ridge- Ready Yes Include s A/ V cable
Phon o Input Yes Yes
®
Dolby
Virtu al Speake r Yes No
®
Dolby
Headph one Yes No
Tape Moni tor Loop Yes Yes
Tuner AM/FM st ereo with 3 0 presets AM/F M stereo with 30 presets
A /B Spe aker Swit ching Yes Yes
Dual S ubwoofer O utputs Yes Yes
Pream p Output s/ Main Amp Inputs Yes Yes
Accessory O utlets 2 S witched 2 Switch ed
Sys tem Remote Yes Yes
IR- In/Out Ja cks Yes Yes
Separate Remo te On/ Off Button s Yes Yes
Dimen sions ( H x W x D) 6 -7/16" x 17-3/8" x 15" 6-7/16" x 17-3/8" x 15"
Weight 2 3 lb 20.9 lb
1
Optional X M antenna mo dule and sub scriptio n to XM ser vice required. Ha rdware and s ervice s old separately.
XM se rvice is n ot availabl e in Alaska or Hawaii.
Mod el DMC 1000
Desc ription Dig ital media c enter wit h DVD-V ideo playb ack and
c ontent con version to h ard drive, U SB and memory ca rds
Vide o Formats DVD, DVD- R/ RW, DVD +R /RW, VC D, SVCD
Audi o-Playback Formats CD, C D-R/R W, MP3
Audi o-Record Forma ts M P3, CD-R /RW, WAV
Stil l-Image F ormats JPE G
iPod C ompatibility Via o ptional T he Bridge I I
US B Capability ( Read/ Write) F ront and rear panel
Card Typ es Accep ted (R ead/ Write) CF, Memory S tick,
Sto rage Capacity HD D: 250GB ( equal to >750 xD CD s
Reco rd Speed Up to 10x wi th play, up to 16x rec ord-only
®†
SD,† MMC,† xD
††
), card /USB : per card size
†††
Comp ressed- Audio MP3 play: 16 kbps – 320 kbps
Bit R ates MP3 rec ord: 192kbps – 32 0kbps
Vide o Output 480i , 480p, 72 0p, 1080i, 1080p
Vide o DACs 216MH z/10-bit
Audi o DACs 192 kHz/ 24-bit
™
HDMI
Output Version 1.2a
Aux I nput Yes
Playb ack Stre ams 4 Simult aneous
Con tent Ident ificati on Grac enote
Inte rnal Bass Management Yes
Digit al-Audio Outp uts Optica l, coaxial, HDMI
®
with cove r art
™
Ex ternal Control IR-in /out, RS-23 2, IP
Remo te Backlit
Dimen sions ( H x W x D) 4-1/16" x 17-1/8" x 15-15/16"
Weight 19.1 lb
†
MS Duo, SD Mini, M MC Mini, SD M icro and MMC Micro ac commodat ed via opti onal card ad apters.
††
Storage c apacit y varies with record bi t rate selec ted.
†††
R ecord spe ed may vary w ith card t ype; MS record s at 1x onl y; 4x only ava ilable when s ource is audio CD.
Mod el The Bri dge II
Desc ription Do cking sta tion for iP od player*
iPod R equirements iPod p layer with d ocking co nnector
( not compatible w ith iPod sh uffle pl ayer)
Prod uct Requir ements Harman K ardon
H arman Kardon
H arman Kardon
®
AVR (AV R 40, 45 or 47 Series, AVR 146 or AV R 354)
®
HK 349 0 stereo receive r
®
DMC 100 0 digital me dia center
Vide o Compatibilit y AVR 146, AV R 47 Series or AVR 35 4
Dimen sions ( H x W x D) 1-3 /16" x 4-1/2" x 4-1/2"
Weight 0. 5 lb
* Models wit h docking connec tor, including i Pod touch .
Mod el DVD 48
Desc ription Pro gressive -scan DVD-A udio/ video and SACD
Vide o Formats DVD, DVD- R/ RW, DVD +R /RW, VC D
Audi o Formats DVD-Audio, SAC D
™
HDMI
Output Yes, HDMI™ 1.1
Stil l-Image F ormats JPEG, Kod ak
™
, CD, CD-R/ RW, MP3, WMA* *
®
Picture C D
™
player wit h HDMI
Audi o DACs 192 kHz/ 24-bit
Vide o DACs 27M Hz – 54M Hz/10 -bit; 216 MHz/12-bit in HD mo de
Vide o Outputs 480 i, 480p, 720p, 108 0i, 1080p
Vide o Test S creen No
Vide o-Off Mode Yes
Scre en Saver Yes
Comp ressed- Audio Bit Rates MP3: 3 2kbps – 320kb ps; WM A: 64kbps – 3 20kbps
JP EG Resolu tion 5 Megapixe ls, 5MB fil e size
Disc -Recog nition Me mory No
Stil l-Image R otation 90° incr ements
Slow P lay Forw ard 1/2 x, 1/4x, 1/ 8x, 1/16x
Slow P lay Revers e 1/ 2x, 1/4x, 1/8x
Fast P lay 1-1/2x, 4x, 6x , 8x, 16x, 32 x
Rand om Play CDs o nly
Repe at Play D isc (CDs only ), group, title, t rack, cha pter, folder, playlist, A-B ***
Prog rammed Play CDs only
Digit al-Audio Outp uts Coax , optical, H DMI
™
1.1
Remo te Backlit
IR- In/Out Ja cks Yes
Dimen sions ( H x W x D) 2" x 17-5 /16" x 11-1/4"
Weight 6 lb
** Windows Media A udio (WMA ) is a proprietar y file format develo ped by Microsof t.
*** A-B Re peat Play is av ailable for D VDs, CDs and VC Ds only (SAC D
™
discs on D VD 48 onl y).
Mod el HTFS 2
Desc ription Floor Stan ds
Alumi num-Ex trusion Column Yes
Wire -Manage ment System Yes
Heig ht (ass embled, not i ncluding 34-1/2 "
floor spi kes and with out speak er)
Bas e 9" x 7" Ova l
Weight 16.7 lb
Some a ssembly required . Available o nly in black-la cquer finis h.
™
/ SPECIFICATIONS
Mod el HKTS 18 HKTS 15 H KS 9 HKS 6
Sate llites Four identi cal 2-way sat ellites Four id entical 2- way satellites with Two identic al 2-way satellites Two identi cal 2-way sat ellites
with 3" midrange and 3/4"-dome twe eter, 3" midran ge and 1/2 "-dome with dua l 3" midrang es and with 3" mid range and 1/ 2"-
video-s hielded twe eter, video -shielded 3 /4"-dome tweeter, video- shielded dome t weeter, vide o-shield ed
Cent er Channel S peaker Voice-ma tched with d ual Voice-m atched wit h dual N /A N /A
3" midranges and 3/ 4"-dome 3" mid ranges and 3 /4"-dome
tweeter, vid eo-shielded tweete r, video-shi elded
Subwoofer 200-W att, bas s-reflex p owered 100 -Watt, bass-r eflex powe red N /A N/ A
subwoofer w ith 10" drive r; subwoofe r with 10" dri ver;
external trigger input extern al trigger i nput
Nominal Impeda nce 8 Ohms (sats & c enter) 8 Ohms (s ats & center) 8 Ohms 8 Ohms
Sens itivit y (SP L @ 1 Watt/M eter) 86dB ( sats & center) 8 6dB (sats & ce nter) 86dB 86 dB
Frequ ency Resp onse S ystem: 25Hz – 2 0kHz ( –6dB ) System : 35Hz – 20kH z (– 6dB ) 105Hz – 20 kHz (– 6dB ) 110Hz – 20kH z (– 6dB)
Line -Level Inputs S tereo RCA jacks a nd dedicated LFE Stere o RCA jack s and dedic ated LF E N/ A N /A
Spea ker-Level Inputs & O utputs Binding posts ( sub); sprin g-lever inp uts Binding p osts (s ub); s pring-le ver inputs S pring lever (inp uts only ) Spring leve r (input s only)
(sats & c enter) (s ats & center)
Reco mmended A mplifier P ower 10W – 120W 10W – 80W 10W – 120W 10W – 80W
Subwoofer-Leve l Control Yes Yes N /A N /A
Phas e Switch Yes Yes N /A N /A
Audi o Sense Turn- On Yes Yes N /A N/A
Low- Pass Filter Swi tch Yes Yes N/ A N/A
Cabl es Included Yes Yes Yes Yes
Wall- Mount Ca pabilit y Bracke ts include d for Bracket s included for Pair of brackets includ ed Pair of brack ets includ ed
center and s atellites center an d satellite s
Dimen sions ( H x W x D) Sats: 9 -9/16" x 3 -15/16" x 3-5/ 8"; Sats : 6-9/ 16" x 3 -15/16" x 3-5/ 8"; 9-9 /16" x 3-15/16" x 3-5/ 8" 6 -9/16" x 3-15/16" x 3- 5/8"
center: 4" x 9 -1/2 " x 3-5/ 8"; center: 4" x 9-1/2" x 3- 5/8 ";
sub: 18-7/8 " x 13-3/8 " x 13-3 /8" sub: 18-7/8" x 13- 3/8 " x 13-3/8 "
Weight S ats: 2.8 lb; cen ter: 2.7 lb; s ub: 35 lb Sats : 1.7 lb; center: 2 .7 lb; sub : 35 lb 2.8 lb 1.7 lb
Finis h Blac k lacquer Black lac quer Bla ck lacquer Black lac quer
Mod el ABH 4000 ABH 4 AB 2 A B 1 HE 1000
Desc ription Four-zone /eight-room Fo ur-room A-B US
A-BUS
Sys tem A B 2, AB 1 or other AB 2, AB 1 or othe r H arman Kardon
Requirem ents A-BUS
connec ts to any anal og input connec ts to any anal og input ABH Se ries expan sion ABH Ser ies expans ion
source ; Harman Kardon
A-BU S-equipped pro duct A-B US-equippe d product A-BU S products A-BUS pro ducts
Sys tem Conne ction Cat. 5/ 5e cable or bet ter Cat. 5/ 5e cable or bett er System: Ca t. 5/ 5e or bett er; System : Cat. 5/5e o r better ; Power sup ply, connect ing block,
speak ers: up to 14 AWG speakers : up to 14 AWG connec ting cable
Dimen sions AB H: 4-3/16" x 9 -1/2 " x 1-1/2" ; A BH: 3-5/ 16" x 7-3 /16" x 1-3/16" ; 4-5/16" x 1-13/16" x 1-5 /16" 4-1/4" x 1-3/4" x 2-1/4" 1" x 3-5/ 16" x 2-5/16"
(H x W x D ) power supply: 2-13/16" x 6 " x 1-1/2" power sup ply: 1-7/16" x 5-15/16" x 2-13/ 16"
Weight ABH : 1 lb; power suppl y: 1 lb A BH: 0.9 lb; p ower suppl y: 1 lb 0.2 5 lb 0.25 lb 1 lb
NOT E: Depth measur ements inc lude knob s, butto ns and termin al connec tions; h eight meas urements include feet a nd chassis . All featu res and spec ificati ons are subje ct to change without n otice.
Harm an Kardo n, EzSe t, Logic 7 an d SoundS ticks are trademarks of Har man Internation al Indust ries, Inc orporat ed, registered in the Un ited Sta tes and /or other c ountries. Atlas , Designed to Entertain, The B ridge II logo, EzS et/EQ, H arman Kar don Guide + P lay,
Drive + Pla y and Harma n Kardon G o + Play are tra demarks o f Harman In ternatio nal Industries, I ncorporated. A -BUS i s a register ed tradema rk of Leisur eTech Electroni cs Pty L td. Cirru s is a register ed tradema rk of Cirr us Logic, In c. The Bluetooth
and logos are registe red tradem arks owne d by the Bluetooth S IG, Inc., a nd any use of su ch marks by H arman Int ernation al Indust ries, Inc orporat ed, is under license. Ot her trade marks and t rade names a re those of t heir respe ctive owne rs. DCD i by Faroudj a is
a registered tradem ark, and Faroudja DC Di Cinema is a tradem ark, of Ge nesis Micr ochip Inc. D olby and Pro Logic ar e registered tradema rks of Dolb y Labora tories. DTS, DTS -ES and DT S Neo:6 are registered t rademarks, and DT S 96/24 and DT S-HD Master
Audio are t rademar ks, of DTS , Inc. Grac enote is a registered tr ademark of G racenote, Inc. H DMI is a tra demark or re gistered t rademar k of HDMI L icensing LLC. A pple and iP od are trad emarks of A pple Inc., registered in the U.S . and other countri es. Shuf fle
is a tradem ark of App le Inc. Kod ak is a registered trade mark of Eas tman Kodak Company. Memor y Stick is a re gistered t rademark , and SACD is a trad emark, of S ony Corporation. SiRFstarI II is a trademark o f SiRF Techno logy, Inc. Mi crosof t, Window s and
Window s Media are re gistered t rademark s of Microsoft C orporat ion in the Un ited Sta tes and /or other c ountries. XM and XM Ready a re registe red tradem arks of XM Satellite R adio. xD-Picture Card is a t rademar k of Fuji Photo Film Co., Ltd .
®
expansi on hub exp ansion hub onboard co ntrols and built-in am plifier with built-i n amplifier
®
-compa tible modu les; A-B US®-compa tible modu les; A -BUS®-equipp ed produc t, A-B US®-equipp ed produc t, product s with “I R Remote- In” jack
®
sourc e; Harman Kardon® hu b or compatible hub or compa tible
®
A-BUS® in-wall mo dule with A-BU S® in-wall mo dule E xternal infrar ed remote sensor
®
Ha rman Kard on® Harma n Kardon® or compat ible
®
word mark
46 47
Mod el GPS-810 GPS- 510 G PS-310
Desc ription Port able naviga tion syst em Port able navigation system Portab le navigati on system
Key Fe atures
Map C overage Full U.S., Ca nada, Puer to Rico Full U.S ., Canada, P uerto Ri co Full U.S ., Canada, P uerto Ri co
Map Date Q2 /2007 Q2 /2007 Q2/2 007
Supp orted L anguages 17 17 17
CP U 530 MHz 400M Hz 400M Hz
GP S Chipset Si RFsta rIII
™
Centra lity Aut onomy Ce ntralit y Autonomy
RA M 128M B 128M B 64MB
Flas h Memory 2 GB 2 GB 2G B
Scre en Size 4.3" 4" 4"
Built- in Real-Time Traf fic
§
Yes Yes Yes
Built- in Wireles s FM Transmit ter Yes No No
Built- in Light Se nsor Yes No No
US B 2.0 Inter face High spe ed Hi gh speed Stand ard speed
Medi a Player
Sto rage S D & SDHC SD & SDHC SD & SD HC
Vide o Player MPEG -4, WMV9, H. 264 M PEG-4, WM V9 No
Pict ure Viewer JPEG No No
Audi o Player MP 3, WMA, M4A MP 3, WMA, M4 A MP3 , WMA
Wind ows Media
®
DRM 10 Yes (audi o, video ) Yes (aud io, video ) N o
Incl uded Acc essories
Car C harger Yes Yes Yes
Wall Ch arger Yes Yes Yes
Wireless Remot e Controller Yes No No
Act ive Docki ng Mount Yes No N o
Fold -Flat Mo unting Bracket Yes Yes Yes
Bluetooth
®
Technolo gy
Hand s-Free C apabilit y Yes No No
Dual -Beam- Forming Noise- Canceling Micr ophones Yes No No
Phon e-Boo k Access ( PBAP) Yes No No
Hardware
Color Dark-gray/hi gh-glos s black Sil ver/black Silver/da rk-gray
Dimen sions ( W x H x D) 5" x 3-1/8" x 3 /4" 4-5 /8" x 2-15/16" x 3 /4" 4-5 /8" x 2-15/16" x 3/4"
Weight 0.51 lb 0.44 lb 0.4 4 lb
§ Sub scription require d (first 90 days f ree).
Mod el Drive + Pl ay™ 2
Desc ription A pple iPod and US B flash-drive int erface
Display Type 3.5 LCD (f ull color )
Resoluti on 320 x 240 p ixels
Light Sensor Yes
Picture Ad justment B rightne ss
Display Th emes Vari ous color s
Controller Type 5 -Button wire less (2 .4GHz )
Rotatio n 360° S croll wheel
Hub U SB 2.0 Acc essor y Port Yes
USB Fla sh-Dri ve Suppor t Yes
Softw are Upgra deable Yes
Detachab le Lighter P lug Yes
iPod S uppor t Audi o/ Photo /Vid eo Playback Yes/ No/N o
Album-A rt Displ ay Yes
Playlists /Audio Boo ks/ Podcasts Yes/ Yes/Yes
Audi o Outpu t 3.5mm Lin e Level Yes
Wireless F M Trans mitter Yes
Wired FM Trans mitter Yes
Mod el Sound Sticks® II
Desc ription Se lf-powere d satellite s peakers a nd subwoofe r system
System Fr equency R ange 44Hz – 2 0kHz
Power Co nsumptio n 4W idle, 6 5W maximum
Input Re quirement 3.5mm Ste reo mini jack
Subwoofer Transduc er (1) 152mm Woofer
Amplifi er Output Power 20W RM S
Dimensi ons (hei ght x diamete r) 10 -3/16" x 9 -3/16"
Weight 4.8 lb
Satellite Transducers (4 ) 25mm Full range per ch annel
Amplifi er Output Power 10W RMS per channel
Dimensi ons (hei ght x diamete r) 10" x 2 "
Weight 1.5 lb
Mod el Harma n Kardon G o + Play
Desc ription Por table loudspe aker dock for iPod
Availa ble In Matt e black, wit h stainless-ste el detail s
Inpu t Requirement Main connection iPo d docking connec tor
Auxilia ry conne ction 3. 5mm Stere o mini jack; S -video connect ion; USB
connec tion for synchronizing iPod w ith compu ter
Driv er Two Ridge and two Atla s
Power 2 x 15W for t weeters ; 2 x 30W for woofers
Frequ ency Resp onse 40Hz – 2 0kHz
Dimen sions ( W x H x D) 19-11/16" x 9-1/16" x 9-1/2"
Weight 4 l b
Inpu t Impedan ce >10k ohms
Signal-to-N oise Rati o >85 dB
™
™
transdu cers
250 Crossways Park Drive, Woodbury, NY 11797
Designed, edited and digitally produced by the
Harman Consumer Group Marketing & Design Center
©2008 Harman International Industries, Incorporated. All rights reserved.
Harman Kardon, Inc.
Woodbury, NY
Part No. HKLITUSA5/08 Printed in USA
516.255.HKHK (4545)
FAX 516.682.3520
www.harmankardon.com
Loading...
