Hanna Instruments HI 9274, HI 9171, HI 9174, HI 9181, HI 9184 Instruction Manual

Instruction Manual
HI 9171 – HI 9174 HI 9181 – HI 9184 HI 9271 – HI 9274
Portable Microprocessor
Printing and Logging
Thermometers
Foodcare
PRT
ALT
TIME
TEMP
LOG
P
RINTIN
G
AN
D
LO
G
G
ING
TH
ERM
O
M
ETER
Foodcare
5
6
4
3
2
1
0
http://www.hannainst.com
These Instruments are in
Compliance with the CE Directives
2
Dear Customer, Thank you for choosing a Hanna Product. Please read this instruction manual carefully before using the instru-
ment. This manual will provide you with the necessary information for a correct use of the instrument, as well as a precise idea of its versatility. If you need more technical information, do not hesitate to e-mail us at tech@hannainst.com.
These instruments are in compliance with directives EN 50081-1 and 50082-1.
ISO 9000 Certified Company since 1992
PRELIMINARY EXAMINATION......................................................... 3
GENERAL DESCRIPTION ................................................................ 3
LCD DISPLAY FUNCTIONAL DESCRIPTION .......................................4
FUNCTIONAL DESCRIPTION HI 9171 & HI 9174............................ 5
FUNCTIONAL DESCRIPTION HI 9181 & HI 9184............................6
FUNCTIONAL DESCRIPTION HI 9271C/F & HI 9274C/F .................. 7
SPECIFICATIONS HI 9271 & HI 9274 ........................................... 8
OPERATIONAL GUIDE ................................................................... 9
PRINTING/RECORDING WITH HI 9171 & HI 9174 .......................15
PRINTING/RECORDING WITH HI 9271 & HI 9274 .......................18
PRINTING/LOGGING WITH HI 9181 & HI 9184 ...........................20
DATA TRANSFER TO PC............................................................... 30
SELF-DIAGNOSTIC FUNCTIONS ....................................................31
MEMORY ORGANIZATION ............................................................31
PRINTER MAINTENANCE ............................................................. 32
BATTERY REPLACEMENT..............................................................34
CALIBRATION............................................................................. 35
TEMPERATURE PROBES ..............................................................36
UN-HOUSED NTC SENSORS ........................................................38
ACCESSORIES ............................................................................ 40
WARRANTY ................................................................................41
CE DECLARATION OF CONFORMITY .............................................. 43
TABLE OF CONTENTS
3
Remove the instrument from the packing material and examine it carefully to make sure that no damage has occurred during shipping. If there is any damage, notify your Dealer or the nearest Hanna Customer Service Center.
Each Printing Thermometer is supplied with:
• Paper Rolls (5 pcs)
• 1.5V x AA size Batteries (4 pcs)
• Rugged Carrying Case
Note: Save all packing material until you are sure that the instru-
ment functions correctly. All defective items must be returned in its original packaging together with the supplied accesso­ries.
PRELIMINARY EXAMINATION
These Hanna portable thermometers with built-in printers are micro­processor-based to accurately measure temperature and record data.
The instrument housing is made of rugged and lightweight material, specifically designed for the food industry.
Measurements can be performed with lab-grade precision in the field without compromising accuracy. A 12VDC adapter can also be used to power the unit for prolonged use.
Common features include: use of precalibrated and completely inter­changeable probes, user-selectable printing/logging intervals, printing on plain paper, automatic shut-off capability, low battery warning, clock and calendar (HI 9171, HI 9174, HI 9181 and HI 9184), memorization of logged values (HI 9181 and HI 9184), all opera­tions password protected (HI 9171, HI 9174, HI 9181 and HI 9184) and 2 year warranty.
HI 9181 and HI 9184 have a memory capacity of 16,000 individual temperature readings with selectable recording intervals. Using the HI 9200 infrared transmitter, all the recorded data can be fed to a PC for reproduction, storage or elaboration without having to connect and disconnect cables and cords.
GENERAL DESCRIPTION
4
Different versions are divided into: HI 9171, HI 9174, HI 9181, HI 9184, HI 9271C and HI 9274C
measuring in degrees Celsius, and HI 9271F and HI 9274F for Fahrenheit measurements.
LCD DISPLAY
FUNCTIONAL DESCRIPTION
LOG INTV
LO BAT
TIME
DATE
°C
1
2
1. Primary Display
2. Secondary Display
5
FUNCTIONAL DESCRIPTION
HI 9171 & HI 9174
3
4
5
6
7
8
9
10
11
1
1
2
2
°C
3
4
5
6
7
8
9
10
11
°C
PRT
PRT
PAPER
PAPER
ALT
ALT
TIME
TIME
TEMP
TEMP
RUN
RUN
PRINTING
THERMOMETER
PRINTING
THERMOMETER
Foodcare
Foodcare
556
6
443
3
221
1
0
0
HI 9171
HI 9174
1. Temperature Probe Connector(s)
2. Socket for External 12VDC Power Supply
3. Liquid Crystal Display
4. PAPER (to move paper up)
5. PRT (to obtain printout of current date, time and temperature)
6. ALT (alternate function key)
7. TEMP (to read temperature and to reactivate meter when in standby mode)
8. (to scan data or to set date, time and printing interval, or to select channel # for HI 9174 only)
9. (to scan data or to set date, time and printing interval, or to select channel # for HI 9174 only)
10. TIME (to display time and printing interval)
11. RUN (to enter and exit recording mode)
6
1. Temperature Probe Connector(s)
2. Socket for External 12VDC Power Supply
3. Liquid Crystal Display
4. PAPER (to move the paper up)
5. PRT (to obtain printout of current date, time and temperature)
6. ALT (alternate function key)
7. TEMP (to read temperature and to reactivate meter when in standby mode)
8. (to scan data or to set date, time and printing interval, or to select channel # for HI 9174 only)
9. (to scan data or to set date, time and printing interval, or to select channel # for HI 9174 only)
10. TIME (to display time and printing interval)
11. LOG (to enter and exit the logging and printing mode)
FUNCTIONAL DESCRIPTION
HI 9181 & HI 9184
3
4
5
6
7
8
9
10
11
1
1
2
2
°C
3
4
5
6
7
8
9
10
11
°C
PRT
PRT
PAPER
PAPER
ALT
ALT
TIME
TIME
TEMP
TEMP
LOG
LOG
PRINTING AND LOGGING THERMOMETER
PRINTING
AND LOGGING
THERMOMETER
Foodcare
Foodcare
556
6
4
4
3
3
221
1
0
0
HI 9181
HI 9184
7
1. Temperature Probe Connector(s)
2. Socket for External 12VDC Power Supply
3. Liquid Crystal Display
4. PAPER (to move paper up)
5. ON/OFF (to switch meter on/off or to reactivate meter when in standby mode)
6. INTV (to select printing interval)
7. 0.1/1 (to select resolution)
8. UP (to set printing interval or to select channel # for HI 9274 only)
9. DOWN (to set printing interval or to select channel # for HI 9274 only)
10. PRINT (to obtain printout of sample # and temperature)
11. LOG (to enter and exit recording mode)
FUNCTIONAL DESCRIPTION
HI 9271C/F & HI 9274C/F
instrum nts
e
3
4
5
6
7
8
9
10
11
1
1
2
2
°C
instrum nts
e
3
4
5
6
7
8
9
10
11
°C
ON/OFF
PAPER
INTV
UP
PRINT
DOWN
0.1/1 LOG
PRINTING
THERMOMETER
-50°C .....+150.0°C
PRINTING
THERMOMETER
-50°C .....+150.0°C
Foodcare
ON/OFF
PAPER
INTV
UP
PRINT
DOWN
0.1/1 LOG
Foodcare
HI 9271C
HI 9274C
8
SPECIFICATIONS
HI 9171 – HI 9174 HI 9271F
HI 9271C – HI 9274C HI 9274F
HI 9181 – HI 9184 Range -50.0 to 150.0°C -55.0 to 300.0°F Resolution 0.1°C / 1°C 0.1°F / 1°F Accuracy ±0.4°C ±0.8°F
(@ 20°C/68°F) for one year, excluding probe error Typical EMC Deviation ±0.4°C ±0.8°F Power Supply 4x1.5V AA size, max. 500 hours with 60' printing
interval. Socket for 12VDC adapter
Auto Shut-off After 5 minutes of non-use Channels 1 for HI 9171, HI 9271, HI 9181 and
4 for HI 9174, HI 9274, HI 9184
Printer Low-power impact belt type, 14 characters per line
using 38 mm plain paper
Printing/Logging 1, 2, 5, 10, 15, 30, 60, 120 and 180 minutes Intervals
Environment 0 to 50 °C (32 to 122°F)
Max. 95% RH non-condensing
Dimensions 220 x 82 x 66 mm (8.7 x 3.2 x 2.6") Shipping Weight 1.4 kg (3.1 lb.)
9
INITIAL PREPARATION
Each meter is supplied complete with batteries. Remove the back cover, unwrap the batteries and install them while paying attention to the polarity (see also page 34).
To switch HI 9171, HI 9174, HI 9181 and HI 9184 on, press TEMP.
To switch HI 9271 and HI 9274 on, press ON/OFF.
If the meter does not switch on check the batteries.
PROBE CONNECTION
Choose the most appropriate temperature probe(s) for your applica­tion (see page 36) and connect it (them) to the probe connector(s) located on the top of the instrument. All the probes have been precalibrated at the factory and no calibration is needed.
HI 9171, HI 9181 and HI 9271 take a single probe while HI 9174, HI 9184 and HI 9274 can take up to four probes.
With the meter facing you, channel #1 is the first connector on the top left corner.
If neither a temperature probe nor a calibration test plug is connected to the instrument, the meter will display "°C ----" to alert the user.
This could also indicate that probe cable is damaged. "CH" and the channel number are displayed together (HI 9174, HI 9184, HI 9274 only).
TEMP
ON/OFF
CH
°C
OPERATIONAL GUIDE
10
Note: To ensure accuracy, it is recommended that the temperature
probes be connected to consecutive channels beginning with channel #1. For example, if only one probe is to be used, connect it to channel #1. If 2, 3 or 4 probes are used, connect them to channels 1, 2, 3, and 4 in ascending order.
AUTO SHUT-OFF
To maximize battery life the display is auto­matically switched off after 5 minutes of non-use. However, the meter will continue to monitor the temperature if in recording/log­ging mode.
To revive the display, press any key (except ALT with HI 9171, HI 9174, HI 9271 and HI 9274).
SETTING DATE, TIME, PRINTING OR LOGGING INTERVAL (FOR HI 9171, HI 9174, HI 9181
& HI 9184 ONLY)
Turn the instrument on by pressing the TEMP key.
Press ALT and TIME simultaneously. These instruments have a pass­word security feature. The default password is 0000. When the meter is used for the first time, it allows time and date to be set until a password is entered. If a password has been entered (see page 12) "----" appears on display and one can only proceed after digiting the password. Otherwise the display will show the date setting with the year blinking (shown as the last 2 digits of the year i.e. 95 = 1995).
Use or to select the year.
TEMP
TEMP
ALT
TIME
+
DATE
11
When the correct year is selected, press TIME to memorize it. The month will start blinking.
Similarly set month by or . Press TIME and the day will start blinking.
Use or to select the correct day. Press the ALT and the TIME keys simultaneously. The display will
switch to the clock mode, and the printing interval will blink.
Any interval can be selected from 1, 2, 5, 10, 15, 30, 60, 120 to 180 minutes by using or .
Memorize the interval by pressing TIME. The hour will start blinking.
TIME
TIME
ALT
TIME
+
TIME
12
To select the hour press or (24 hour clock) and press TIME once more to memorize it. The minutes will start blinking.
Use or to select the minutes. Press the ALT and TIME keys simultaneously. The instrument will now
ask for the password and display "0000".
To return to normal operation enter the password or press the ALT and TIME keys again if the password is not to be changed.
The new date, time and printing interval are now stored in the memory even when the meter is switched off.
SETTING THE PASSWORD (HI 9171, HI 9181, HI 9174 & HI 9184 ONLY)
The password is represented by a 4 digit number each selectable from 0 to 6.
By pressing the ALT and the TIME keys at the end of the time/date setting procedure, four zeros appear on the LCD.
If you wish to enter a password, press any of the keys corresponding to a number. These numbers are printed on the bottom right hand side of the keys as shown below:
TIME
ALT
TIME
+
ALT
TIME
+
PRT
PAPER
ALT
TIME
TEMP
LOG
56
43
2
1
0
56
43
012
13
If no password is necessary, leave the default password as 0000 by pressing and holding ALT down and then pressing TIME.
Once a password has been entered, it is automatically stored in memory. By pressing ALT and TIME simultaneously the display will switch back to normal operation.
Note: If the password is not known or forgotten, remove the batteries
for two minutes and the password is reset to the default 0000.
ENTERING THE PASSWORD
When the display shows "----" it means that the password has to be entered. Press the keys corresponding to the password, e.g. for "1256" press the TIME, TEMP, PRT and PAPER keys in that sequence. If the wrong key is pressed, once all four digits are filled on the LCD, the meter will again show "----" so that the entire password can be re­entered.
VIEWING TEMPERATURE, TIME & DATE (FOR HI 9171, HI 9174, HI 9181 & HI 9184 ONLY):
To view the date press the key.
To view the time and the printing interval press TIME.
To view temperature press TEMP.
ALT
TIME
+
DATE
TIME
INTV
TIME
TEMP
CH
°C
C
HANNEL
14
Using the or keys select channel (HI 9174 and HI 9184 only).
If "°C ----" is displayed, it indicates that the temperature probe or calibration test plug is not connected. This may also indicate the possibility of a damaged probe cable. The channel # is displayed together with "CH" (HI 9174 and HI 9184 only).
SETTING THE PRINTING INTERVAL FOR HI 9271 & HI 9274 ONLY
Turn the meter on by pressing ON/OFF.
Press the INTV and the UP keys and hold down the INTV key. The display will show the log number while the printing interval will start blinking.
Any interval can be selected from 1, 2, 5, 10, 15, 30, 60, 120 and 180 minutes by using the UP and DOWN keys.
CH
°C
ON/OFF
INTV
INTV
UP
UP
DOWN
15
Release the INTV key to exit this mode.
SETTING THE MEASUREMENT RESOLUTION (HI 9271 & HI 9274 ONLY)
Press the 0.1/1 key to select 0.1° or 1° resolution.
With HI 9274, all four channel readings automatically change by pressing this key.
To return the reading to its original resolution, simply press the 0.1/1 key again.
INTV
CH
°C
0.1/1
PRINTING/RECORDING
WITH HI 9171 & HI 9174
To print the measured values shown on the display, press PRT. This function can be acti­vated in normal operation mode as well as during recording mode (see below). When in measurement mode, the printout provides the following information:
a – Running sample number b – Date (DD-MM-YY) c – Time (HH-MM) d – Temperature value(s) e – Channel numbers (HI 9174 only)
RECORDING AT AN INTERVAL
Ensure that the appropriate recording interval has been set (see Operational Guide on page 9).
PRT
16
Press ALT and RUN simultaneously to enter the recording mode.
The log number and the interval time will appear for a few seconds on the display to indicate the correct operational mode.
The meter will print the measurements taken in that moment, and will print at the selected interval thereafter until ALT and RUN are pressed again. The password is also requested to stop printing (unless it remained at default 0000).
Each printout provides the following information: a – Date (DD-MM-YY) b – Printing interval in minutes c – Time (HH-MM) d – Temperature value(s) e – A running log number f – Running sample number (in that particular log) g – Channel number(s) HI 9174 will print only the values of the probes connected. If probes
are added to the remaining channels during the recording mode, the data from the additional probes will not be printed. Data from re­maining channels can only be added if the recording mode is exited and re-entered. A blinking "CH" will appear on the display next to the channel numbers not being utilized and/or recorded.
When the meter is in recording mode "LOG" is displayed on the bottom left corner of the LCD together with time and the printing in­terval.
If no keys are pressed, the meter goes to standby mode to prolong the battery life while the recording function remains active.
To reactivate the display press TEMP.
Notes:
• Once in the recording mode, the printer cannot be stopped unless the password is entered (unless the password is 0000).
ALT
RUN
+
TEMP
17
• The interval cannot be changed during recording mode. Exit the recording mode first (press ALT and LOG and enter the password) before setting the new interval.
• If PRT is pressed while in logging mode, a printout is produced without affecting the running sample number.
TO STOP RECORDING
Press ALT and LOG simultaneously. If a password has been entered the printer will require the operator to enter the correct password whereupon it will generate a log exit status printout.
Note: If the password is unknown or forgotten, remove the batteries
for two minutes to stop printing and reset the password to
0000. Likewise, the running log number can also be reset.
ALT
LOG
+
PRT
ALT
LOG
+
LOG
18
PRINTING/RECORDING
WITH HI 9271 & HI 9274
PRINT
LOG
To print the measured values press PRINT. Each printout provides the following informa­tion:
a – The total accumulative time b – Temperature value(s) c – Channel numbers (HI 9274 only) d – Running sample number
RECORDING AT AN INTERVAL
Ensure that the appropriate recording interval has been set (see Operational Guide on page 9).
Press the LOG key to enter the recording mode.
The log number and the interval time will appear for a few seconds on the display to indicate the correct operational mode.
The meter will print the measurements taken in that moment, and will print at the selected interval thereafter until the ON/OFF key is pressed again.
The printout provides the following informa­tion:
a – A running log number b – A running sample number (in that particular log) c – Channel numbers (HI 9274 only) d – Printing interval indicator in minutes e – The accumulated time since printing started (HH.MM) f – Temperature value(s)
HI 9274 will print only the values of the probes connected. If probes are added to the remaining channels during the recording mode, the data from the additional probes will not be printed. Data from remaining channels can only be added if the recording mode is exited and re-entered. A blinking "CH" will
ON/OFF
CH
°C
LOG
19
appear on the display next to the channel numbers not being utilized and/or recorded.
When the meter is in recording mode "LOG" is displayed on the bottom left corner of the LCD together with temperature.
If no keys are pressed, the meter goes to standby mode to prolong the battery life.
Notes:
• If the PRINT key is pressed while still in recording mode, a printout is produced without affecting the running number.
• Once in recording mode, the printing in­terval cannot be changed. Exit the recording mode first by pressing ON/OFF and reset the new interval.
TO STOP RECORDING
To quit recording mode, press ON/OFF. This will generate a recording exit status printout.
CH
°C
LOG
PRINT
ON/OFF
ON/OFF
--07-- 0005M
<>0016 *1.15
Log number
Total sample number
Exit printing interval & accumulative time
20
PRINTING/LOGGING
WITH HI 9181 & HI 9184
To print the measured values shown on the display, press PRT. This function can be acti­vated in normal operation as well as during logging and scanning data on display (see page 23). When in measurement mode, the printout provides the following information:
a – Running sample number b – Date (DD-MM-YY) c – Time (HH-MM) d – Temperature value(s) e – Channel numbers (HI 9184 only)
LOGGING MODE WITHOUT PRINTING
This function is particularly useful when measurements have to be taken continuously even in the absence of an operator over a long period of time. In this mode data will be stored directly into memory.
Set the appropriate logging interval (see page 9). Press the ALT and LOG keys simultaneously to enter the logging
mode. The current log number and remaining page numbers will appear for a few seconds on the display to indicate the correct operational mode. The printer will print a complete set of data and the "LOG" symbol will appear on the secondary LCD.
To continue logging without printing, press ALT and PAPER at the same time and the "LOG" symbol on display will start to blink.
HI 9184 will print only the values of the probes connected. If probes are added to the remaining channels during the recording mode, the data from the additional probes will not be printed. Data from re-
PRT
ALT
LOG
+
ALT
PAPER
+
CH
°C
LOG
21
maining channels can only be added if the recording mode is exited and re-entered. A blinking "CH" will appear on the display next to the channel numbers not being utilized and/or recorded.
After approximately 5 minutes the display will switch off but the logging function remains active.
To reactivate the display press TEMP. If you wish to restart printing press the ALT
and PAPER keys simultaneously again.
Notes:
• Once in the logging mode, the interval cannot be changed. Exit the logging mode by pressing ALT and LOG and entering the password before setting the new interval.
• If PRT is pressed while in logging mode, a printout is produced without affecting the running sample number.
CH
°C
LOG
TEMP
SAMPLE NUMBER
During logging it is possible to know the running sample number. Press the LOG key twice and the display will show the number of values that have been taken in the current log.
LOGGING MODE WITH PRINTING
This function is useful in a variety of applications from unsupervised monitoring to satisfying regulatory requirements. In addition to the printouts, the measurements are also stored into the memory.
Press the ALT and LOG key simultaneously to enter the logging mode.
ALT
LOG
+
LOG
PRT
LOG
2 x
LOG
ALT
LOG
+
22
The current log number and the remaining page numbers will appear for a few seconds on the display to indicate the correct opera­tional mode. The printer will print a complete set of data and the "LOG" symbol will appear on the secondary LCD.
If no key is pressed, the display goes blank after about 5 minutes and comes back to life only to print the next batch of data. During printing, the display shows the time, preselected interval and the “LOG” symbol.
LOG
LOG INTV
TIME
To reactivate the display press the TEMP key. Each printout provides the following informa-
tion: a – Date (DD-MM-YY) b – Printing interval in minutes c – Time (HH-MM) d – Temperature value(s) e – A running log number f – A running sample number (in that particular log) It is always possible to switch from the logging with printing function
to the logging without printouts. Press ALT and PAPER at the same time and the "LOG" symbol will start to blink to indicate that the data are now stored into memory but no longer printed.
Notes:
• It is recommended to use the external power supply during log­ging with printing mode, especially when many printout are going to be taken.
• Before proceeding with logging with printing, make sure there is enough paper for your measurements. When the paper is run out the meter will not advise the operator and the printouts could be lost. If this happens, data will continue to be stored into memory, and it is always possible to print them at later time (see page
25).
TEMP
CH
°C
LOG
ALT
PAPER
+
23
• It is possible to insert a new paper roll during logging session (see page 32).
• Once in the logging mode, the printer cannot be stopped unless the password is entered (unless the password is 0000).
• The interval cannot be changed during logging mode. Exit the recording mode by pressing ALT and LOG and entering the
password before setting the new interval.
• If PRT is pressed while in logging mode, a printout is produced without affecting the running sample number.
TO STOP LOGGING
Press the ALT and the LOG keys simultaneously and enter the pass­word. This will generate an exit status printout.
ALT
LOG
+
LOG
PRT
ALT
LOG
+
10-01-96
==07== 0005M
0016 *16.25 #1 20.0 °C #2 57.3 °C..
Log number
Total sample number
LOG EX
IT
Date/Tim
e
TO SCAN STORED DATA ON DISPLAY
Press the LOG key. The display will show the log number and the remaining page numbers.
LOG
24
While pressing the ALT key, press the key until the log number to scan appears on the secondary display. The primary display will show the number of samples in that particular log.
Press the ALT and the TEMP keys simultaneously. This now shows the date when log started.
Press the key and the time of the most recent sample will be displayed.
ALT
+
ALT
TEMP
+
Press the key and the temperature will be displayed.
Continue pressing the key to display one by one all the memo­rized data of the same log in the above sequence i.e. time and temperature.
Press the key to revert back to sampling time and scan the samples.
To exit from the recall mode press the LOG key.
Note: this mode will not alter data already
in the memory.
LOG
25
TO PRINT STORED DATA
Once a log number is selected (see "TO SCAN STORED DATA ON DISPLAY" on page 23) you can print all or part of that logged section by pressing the ALT and PRT keys. The printer will start to print the logged section begin­ning with the selected sample number without altering the content of the memory.
Note: It is always possible to print
only the sample shown on the display by pressing the PRT key.
Note: Before proceeding with printing, make sure there is enough
paper for the data to be printed. When the paper is finished the meter will not advise the operator and the printouts could be lost. If this happens, stop the printer by pressing ALT and PAPER simultaneously.
Insert a new paper roll and repeat the instructions above starting from the last printed sample number (see chapter "PRINTER MAINTENANCE" on page 32 for changing the paper roll).
ALT
+
ALT
PRT
+
PRT
ALT
PAPER
+
WORKING EXAMPLE (HI 9181 & HI 9184 ONLY)
The following is a step by step procedure of a typical monitoring situation where we have assumed that the batteries have been in­serted and the date and time correctly set.
In this example, the meter stores the temperature every 2 minutes. It will log 10 samples but print only 3, then displays the data contained in sample number 1 and prints samples 5 through 10.
Example:
Step One - Setting the printing/logging interval at 2 minutes:
Press ALT and TIME. The display will now ask for the password (unless it was left at 0000).
ALT
TIME
+
CH
°C
26
Enter password 3434 using the and keys.
Press ALT and TIME again. The time will appear on the primary display with an intermittent number representing the printing/logging interval.
Press either the or keys until "2" appears blinking.
Press the ALT and TIME keys twice to exit. The display will now show the current time together with the selected interval of 2 minutes.
Step Two - Entering the log mode:
Press ALT and LOG. Initially, "L 01" will appear on the primary display.
The meter is now in the printing/logging mode utilizing log number 1, page 16. "LOG" and P 15 shown in the secondary display indicate that the meter has entered the log mode, and has 15 available pages of memory remaining. After the initial printout, the time and printing/ logging interval will reappear.
3
4
34
ALT
TIME
+
INTV
TIME
INTV
TIME
INTV
TIME
ALT
TIME
+
LOG
ALT
LOG
+
INTV
TIME
27
Press the LOG key to view the running log and page numbers.
Press the LOG key again to view the running sample number.
Step Three - Stopping the printer during the log mode:
After the third printout is completed, press the ALT and PAPER keys. At this point the meter will continue to log data every 2 minutes but will no longer print any information. "LOG" will blink on the secondary display for the remainder of "L 01" (log number 1).
Note: If the display is shut off, press TEMP to reactivate it and then
press LOG twice to view the running sample number.
Step Four - Leaving the log mode:
Once the number of samples stored in memory has reached 10, press the ALT and LOG keys. The meter will demand a password.
Enter the password 3434 using the and keys.
The meter will exit the log mode after generating a log exit status printout.
LOG
LOG
LOG
LOG
LOG
ALT
PAPER
+
ALT
LOG
+
LOG
3 4 3 4
10-01-96
==01== 0002M
0010 *00.18
28
Step Five - Reviewing the stored data in log number 1:
Press LOG to enter the memory recall mode. The next available log and page number will be shown on the display.
Press the ALT and keys until the number 10 and "L1" appear, indicating that a total of 10 samples were recorded in log number 1.
To view the data stored in log number 1 first use the and keys to scroll through the sample numbers.
Once the desired sample number is displayed, press the ALT and TEMP keys. The date in which that sample was taken will appear first.
Press the key to view the time.
Press the key again to view the temperature.
LOG
ALT
+
ALT
TEMP
+
DATE
TIME
CH
°C
29
With HI 9184 when more than one probe have been connected, press the key to view the other channels values.
Step Six - Printing the stored data (samples 5 through 10):
Press and hold the ALT key and press the key until the total number of samples recorded in log number 1 is displayed.
Scroll through the sample numbers by using either the or keys until number "5" appears.
Press the ALT and PRT keys. The meter will automatically printout sample numbers 5, 6, 7, 8, 9 and 10 consecutively.
ALT
PRT
+
30
DATA TRANSFER TO PC
(HI 9181 & HI 9184 only)
HI 9181 and HI 9184 contains infrared emit­ting circuitry. Set the meter to TIME mode and place it on a HI 9200 Infrared Transmitter (ensuring that the infrared LEDs are placed on top of each other). The logged data can be downloaded to your PC through the HI 9200's RS232 port.
During the data transfer the instrument dis­plays "r 232".
TIME
Windows® is a registered Trademark of "Microsoft Co." Excel© Copyright of "Microsoft Co." Lotus 1-2-3© Copyright of "Lotus Co."
Using the HI 9200 Infrared Transmitter, all recorded data can be fed to your Personal Computer for easy reproduction, storage or elabora­tion without having to connect and disconnect cables between the meter and your PC.
Data can be further elaborated with the new optional HI 92000 Windows® compatible application software.
HI 92000 allows use of commonest spread sheet programs (e.g. Excel, Lotus 1-2-3) and offers a variety of features with an on-line help routine. To install HI 92000, you need a 3.5" drive and a couple of minutes to follow the short instructions conveniently printed on the disk label.
31
Capacity
16,000 data samples, divided into 16 pages.
Capacity per page
1000 data with 1 channel monitored; 500 data with 2 channels monitored (four channels versions only); 250 data with 3 or 4 channels monitored (four channels versions only). Each time a new logging mode is entered, it automatically starts a
new page. Once all 16 pages are used up, the meter will overwrite the first lot. During logging, the meter automatically returns to the oldest page in the memory and if it contains data, it will overwrite it. In this case the first log will not correspond to the oldest set of data
It is recommended to periodically “clean” the memory. Save the data in a PC if you need to keep a record and then disconnect the batteries for about 1 minute. If you do this, remember to reset the time and date, once the batteries have been inserted again.
ATTENTION
Data is stored into memory until batteries are removed. If replace­ment of the batteries is needed and data is not to be lost, first plug in an external 12VDC power supply and then proceed with battery replacement as described on page 34. Only once batteries have been replaced, it is possible to unplug the power supply without losing the previously memorized data.
MEMORY ORGANIZATION
(HI 9181 & HI 9184 only)
SELF-DIAGNOSTIC FUNCTIONS
HI 9171, HI 9174, HI 9181, HI 9184, HI 9271 and HI 9274 are factory programmed to automatically diagnose a fault and inform the user by displaying an error code on the LCD.
Error codes are: PEr0, PEr1, PEr2 = Short circuit on the system, the meter should be
returned for repair (see Warranty section).
PEr3 = Printer mechanism fault - repair needed (see Warranty
section). PEr4 = Printer clutch jammed - reset the printer (see page 33). PEr9 = Printer jammed - reset the printer (see page 33).
32
TO CHANGE THE INK CARTRIDGE
When printouts become faint, it might be necessary to change the ink cartridge. Contact your dealer or the nearest Hanna Service Center for this.
TO INSERT PAPER ROLL
HI 9171, HI 9174, HI 9181, HI 9184, HI 9271 and HI 9274 use plain 38 mm wide paper rolls. To insert a new roll gently pull out the printer cover.
Take out the used paper cylinder.
Insert the paper edge in the printer slot and feed the paper through by pressing the PAPER key.
PRINTER MAINTENANCE
PAPER
33
Allow about 5 cm (2") of paper to exit from the printer and then replace the cover.
TO RESET THE PRINTER
Take the battery cover off by removing the screws on the back of the meter. Using a blunt pencil press the black reset but­ton. This will reset the printing mechanism.
Before replacing the battery cover, investigate likely cause of the printer jam (e.g. the pa­per might be caught under the cover preventing the paper from advancing).
Replace the battery cover and tighten the screws.
-
-
+
+
1.5V
1.5V
-
-
+
+
1.5V
1.5V
SCREW
POTS
RESET
34
BATTERY REPLACEMENT
If "LO BAT" appears on the display, it is an indication that the batteries are running down. If it appears during printing, approximately 200 printouts can still be made before the batteries are exhausted. When there is only sufficient power for 100 printouts, the "LO BAT" sign is displayed continuously on the LCD.
Battery replacement must only take place in a non-hazardous area using alkaline AA type 1.5V batteries.
In order to replace run down batteries, simply remove the two screws on the rear cover of the instrument and replace the four 1.5V AA batteries with new alkaline ones, paying attention to the correct polarity.
HI 9171, HI 9174, HI 9181 and HI 9184 will show a clock function that will appear as 0:00 and a default sampling interval of 1 minute.
A 12VDC power source can also be used to power the unit (see Accessories on page 40).
Note: The instrument uses the following configuration.
It is recommended to use Hanna Instruments HI 710005 and HI 710006 voltage adapters that use the proper polarity configura­tion.
CH
°C
LOBAT
+
-
-
-
+
+
1.5V
1.5V
-
-
+
+
1.5V
1.5V
SCREW
POTS
RESET
35
HI 9171, HI 9174, HI 9181, HI 9184, HI 9271 and HI 9274 can also be used with other adapters supplying a 12VDC output. In this case, remember to check the correct polarity of your adapter before connecting it to the meter.
WARNING: With HI 9181 and HI 9184, if the external power
supply or batteries are disconnected, all stored data will be erased. Always employ external power to the instru­ment when changing the batteries to prevent loss of data.
All Hanna thermometers have been accurately precalibrated at the factory.
However, as a general rule, it is recommended to have all thermom­eters recalibrated at least once a year.
For an accurate annual recalibration, contact your dealer or the nearest Hanna Customer Service Center.
Hanna Test Plugs provide a quick and easy way to check the accuracy of the meter by simply connecting these Test Plugs to the probe connector of the meter.
If the reading differs by more than ±0.4°C (±0.8°F) from the Test Plug values, the unit is due for recalibration.
Choose the right Test Plug to suit your needs:
HI 762-18C Calibration key, –18.0°C ±0.4°C HI 762000C Calibration key, 0.0°C ±.0.4°C HI 762070C Calibration key, +70.0°C ±0.4°C HI 762-004F Calibration key, –0.4°F ±0.8°F HI 762032F Calibration key, +32.0°F ±0.8°F HI 762158F Calibration key, +158.0°F ±0.8°F
CALIBRATION
36
Hanna Instruments offers a wide range of probes to meet all your requirements (from liquids to air and penetration to surface). These probes use highly sensitive thermistor sensors which provide greater accuracy, faster response and a temperature range that is superior to conventional thermistor probes. All Hanna temperature probes are supplied precalibrated from the factory and are ready to be used with your meter. The probes are easily to your meter with a standard connector. Completely interchangeable, these probes make it possible for you to switch from one to another without wasting time and money going through tedious calibration procedures. They are available with different handle colors to avoid cross contamination during testing:
HI 762A Air probe, with 1 m (3.3') cable and white handle HI 762A/10 Air probe, with 10 m (33') cable and white handle HI 762BL General purpose liquid probe, with 1 m (3.3') cable
and black handle
HI 762L General purpose liquid probe, with 1 m (3.3') cable
and white handle
HI 762L/2 General purpose liquid probe, with 2 m (6.6') cable
and white handle
HI 762L/10 General purpose liquid probe, with 10 m (33') cable
and white handle
HI 762PBL Penetration probe with 1 m (3.3') cable and blue
handle
HI 762PBL/10 Penetration probe with 10 m (33') cable and blue
handle
HI 762PG Penetration probe with 1 m (3.3') cable and green
handle
HI 762PG/10 Penetration probe with 10 m (33') cable and green
handle
HI 762PR Penetration probe with 1 m (3.3') cable and red
handle
HI 762PR/10 Penetration probe with 10 m (33') cable and red
handle
HI 762PW Penetration probe with 1 m (3.3') cable and white
handle
HI 762PW/10 Penetration probe with 10 m (33') cable and white
handle
TEMPERATURE PROBES
37
HI 762W Wire probe, without handle (hard-to-reach places)
with 1 m (3.3') cable
HI 762W/10 Wire probe, without handle (hard-to-reach places)
with 10 m (33') cable
HANNA INSTRUMENTS TEMPERATURE PROBES
38
UN-HOUSED NTC SENSORS
It is often necessary to "customize" tests to meet specific criteria. For this reason, Hanna offers a wide range of NTC thermistor sensors that can be custom mounted in almost any application. Select the sensor that matches your requirements, attach it to the Phono style adaptor and plug it into the meter. You now have a temperature sensor that is custom built for your application. The following is a list of the NTC Thermistor sensors available:
HI 76P2-1/P Phono style plug with 1 meter (3 foot) cord (4 pcs)
HI 76S2-1/P NTC Thermistor sensor. Teflon® coated with hole for
mounting (2 pcs)
HI 76S2-2/P NTC Thermistor sensor. Self-adhesive, foam disk for
mounting (4 pcs)
HI 76S2-3/P NTC Thermistor sensor. Eye-connector for mounting
(4 pcs)
DIA 3.8mm
0.15"
7.1mm
0.28"
4.8mm
0.19"
ALUMINUM
HOUSING
19mm
0.75"
300mm
12"
25.4mm
1.0"
6.4mm
0.25"
TEFLON TUBING
6.4mm
0.25"
38mm
15"
RELEASE
LINER
MYLAR
FOIL
25.4mm
1.00"
38mm
1.5"
FOAM
DISK
3mm
0.12"
6.4mm
0.25"
406mm
16"
19mm
0.74"
9.6mm
0.38"
#6 STUD SIZE
TIN PLATED Cu
EPOXY
5.5mm
0.22"
1mm
0.04"
Teflon® is a registered Trademark of "du Pont de Nemours & Co."
39
HI 76S2-4/P NTC Thermistor sensor. Molded tip with epoxy seal for
aggressive environments (5 pcs)
HI 76S2-5/P NTC Thermistor sensor. Aluminum tab with mounting
hole (4 pcs)
HI 76S2-6/P NTC Thermistor sensor. PVC encapsulated tip for pro-
tection in aggressive environments (4 pcs)
HI 76S2-7/P NTC Thermistor sensor. Can be housed and used in any
custom application (10 pcs)
6.4mm
0.25"
406mm
16"
9.6mm
0.38"
EPOXY FILLET
MOLDED TIP
2mm
0.08"
1.6mm
0.06"
4.7mm
0.19"
12.7mm
0.50"
ALUMINUM
HOUSING
EPOXY
DIA 3mm
0.12"
300mm
12"
8mm
0.31"
6.4mm
0.25"
6.4mm
0.25"
25.4mm
1.0"
300mm
12"
15.8mm
0.625"
7.1mm
0.28"
MOLDED
PVC TIP
2.4mm
0.095"
LEAD DIA
0.2mm
0.008"
38mm
1.50"
40
ACCESSORIES
Calibration Test Plugs see page 35 Temperature Probes see page 36 Un-housed NTC Sensors see page 38
ADAPTERS/TRANSFORMERS
HI 710005 Voltage adapter from 110VAC to 12 VDC HI 710006 Voltage adapter from 220VAC to 12 VDC
OTHER ACCESSORIES
HI 9200 Infrared Transmitter (for HI 9181 and HI 9184 only) HI 92000 Windows® software for data transfer to PC (for
HI 9181 and HI 9184 only)
HI 710034 10 Plain Paper Spare Rolls HI 710035 1 Spare Ink Cartridge HI 710031 Rugged carrying case MANPRNFCR2 Instruction manual
Windows® is a registered Trademark of "Microsoft Co."
41
WARRANTY
All Hanna Instruments meters are warranted for two years against defects in workmanship and materials when used for their intended purpose and maintained according to instructions.
The probes are warranted for a period of six months.
This warranty is limited to repair or replacement free of charge. Damages due to accidents, misuse, tampering or lack of prescribed
maintenance are not covered. If service is required, contact the dealer from whom you purchased
the instrument. If under warranty, report the model number, date of purchase, serial number and the nature of the failure. If the repair is not covered by the warranty, you will be notified of the charges incurred.
If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization Number from the Customer Service department and then send it with shipment costs prepaid. When shipping any instrument, make sure it is properly packaged for complete protection.
To validate your warranty, fill out and return the enclosed warranty card within 14 days from the date of purchase.
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner, Hanna Instruments Inc., 584 Park East Drive, Woonsocket, Rhode Island, 02895, USA.
Hanna Instruments reserves the right to modify the design, con­struction and appearance of its products without advance notice.
42
OTHER PRODUCTS FROM HANNA
• CALIBRATION AND MAINTENANCE SOLUTIONS
• CHEMICAL TEST KITS
• CHLORINE METERS
• CONDUCTIVITY/TDS METERS
• DISSOLVED OXYGEN METERS
• HYGROMETERS
• ION SPECIFIC METERS (Colorimeters)
• MAGNETIC STIRRERS
• Na/NaCl METERS
• pH/ORP/Na ELECTRODES
• pH METERS
• PROBES (DO, µS/cm, RH, T, TDS)
• PUMPS
• REAGENTS
• SOFTWARE
• THERMOMETERS
• TITRATORS
• TRANSMITTERS
• TURBIDITY METERS
• Wide Range of Accessories
Most Hanna meters are available in the following formats:
• BENCH-TOP METERS
• POCKET-SIZED METERS
• PORTABLE METERS
• PRINTING/LOGGING METERS
• PROCESS METERS (Panel and Wall-mounted)
• WATERPROOF METERS
• METERS FOR FOOD INDUSTRY
For additional information, contact your dealer or the nearest Hanna Customer Service Center. You can also e-mail us at tech@hannainst.com.
43
CE DECLARATION OF CONFORMITY
Recommendations for Users
Before using these products, make sure that they are entirely suitable for the environment in which they are used.
Operation of these instruments in residential areas could cause unacceptable interference to radio and TV equipment.
Any variation introduced by the user to the supplied equipment may degrade the instruments' EMC performance.
Unplug the instruments from power supply before replacing the fuse or making any electrical connections.
DECLARATION OF CONFORMITY
We
Hanna Instruments Srl V.le delle industrie 12 35010 Ronchi di Villafranca (PD) ITALY
herewith certify that the thermometers
have been tested and found to be in compliance with the following regulations:
IEC 801-2 Electrostatic Discharge IEC 801-3 RF Radiated IEC 801-4 Fast Transient EN 55022 Radiated, Class B
Date of Issue: 19-02-1996
D.Volpato - Engineering Manager
On behalf of
Hanna Instruments S.r.l.
HI9171 HI9174 HI9181 HI9184 HI9271 HI9274
http://www.hannainst.com
HANNA LITERATURE
PRINTED IN ITALY
LAB RECORDING WATER ANALYSIS
ENVIROCARE GENERAL CATALOG
These and many others catalogs, handbooks and leaflets are avail­able from Hanna. To receive your free copy, contact your dealer or the nearest Hanna Customer Service Center.
MANPRNFCR2 03/97
Loading...
