Dear Customer,
Thank you for choosing a Hanna Instruments Product.
Please read this instruction manual carefully before using the instrument.
This manual will provide you with all the nec­essary information for the correct use of the instrument, as well as a precise idea of its versatility in a wide range of applications.
These instruments are in compliance with directives.
TABLE OF CONTENTS
Preliminary Examination ........................... 3
General Description .................................. 3
Functional Description HI 9060 ................. 5
PRELIMINARY EXAMINATION
Remove the instrument from the packing ma­terial and examine it carefully to make sure that no damage has occurred during ship­ment. If noticeable damage is found, notify your Dealer.
Note: Save all packing material until you are
sure that the instrument functions cor­rectly. All defective items must be re­turned in the original packaging to­gether with the supplied accessories.
GENERAL DESCRIPTION
HI 9060, HI 9061 and HI 91541 waterproof por-
table thermistor thermometers are very easy to use in any field where high humidity levels and dust could effect the performance of a conventional thermometer.
Functional Description HI 9061 ................. 6
Functional Description HI 91541 ............... 7
Operational Guide ..................................... 8
Display Codes Guide .............................. 12
Calibration .............................................. 13
Battery Replacement ............................... 14
Temperature Probes & Accessories ........ 15
Warranty................................................. 18
CE Declaration of Conformity ................. 19
2
HI 91541 provides accurate and consistent readings not only for lower values but also for temperatures as high as 300°C (570°F).
To prolong battery life, it shuts itself off au­tomatically after half hour of non-use.
HI 91541 and HI 9061 have been specifically designed by Hanna Instruments for use in the food industry and are available in two versions:
HI 9061C to measure in degrees Celsius;
HI 9061F to measure in degrees Fahrenheit.
HI 91541C to measure in degrees Celsius;
HI 91541F to measure in degrees Fahren-
heit.
Each HI9061C and HI 9061F comes supplied
3
complete with 4 batteries (1.5V, AA size). Upon request these meters can be supplied with a Factory Calibration Certificate against NIST standard. Several types of HI765 tem- perature probes are available to meet all your requirements (see page 15). A series of HI765 calibration test plugs are also available to check the meter's accuracy (see page 13).
Each HI91541C or HI 91541F comes sup- plied complete with 4 batteries (1.5V, AA size). Several types of HI 764 temperature probes are available to meet all your re­quirements (see page 16). A series of HI764 calibration test plugs are also available to check the meter's accuracy (see page 13).
HI9060 can measure in Centigrade and in Fahrenheit.
Other features of HI 9060 include: display and clearing of the maximum / minimum tem­perature measured reading hold. These func­tions are easily accessible through the wa­terproof rubber keypad. Self-explanatory sym­bols are used to remind the user of the operating mode or condition.
HI 9060 comes supplied complete with 4 bat­teries (1.5V AA size) and a HI765BL ther­mistor probe with 1 meter (3.3') cable. Sev­eral types of HI 765 temperature probes are available to meet all your requirements (see page 15). A series of HI765 calibration test plugs are also available to check the meter's accuracy (see page 13).
4
FUNCTIONAL DESCRIPTION HI 9060
1
2
1. Battery Cover
2. Temperature Probe Connector
3. LCD Display
4. Temperature Selection (°C or °F)
5. ON/OFF Key
6. Minimum Temperature
7. HOLD Key
8. Maximum Temperature
9. HI/LO Temperatures Clear
Specifications HI 9060
Range -50.0 to 150.0°C
Resolution 0.1°C / 0.1°F and 1°F
Accuracy ±0.3% of Full Scale, for one year, (@20°C/68°F) excluding probe error
Typical EMC ±1°C/±2°F Deviation with HI765BL probe
Probe HI 765BL (included)
Battery Type/Life 4 x 1.5V AA / 200 hours
Environment -10 to 50°C (14 to 122°F);
Dimensions 196 x 80 x 60 mm (7.7 x 3.1 x 2.4")
Weight 425 g (15 oz.)
-58.0 to 199.9 & 200 to 302°F
°C
HI 9060
microcomputer thermometer
CLEAR
HI LO HOLD
100% RH
5
ins
rum n
e
-50 .. .. .. .. +150°C
-58 .. .. .. .. +302°F
°C/°F ON/OFF
s
3
4 59
6 78
FUNCTIONAL DESCRIPTION HI 9061
FUNCTIONAL DESCRIPTION HI 91541
1. Battery Cover
2. Temperature Probe Connector
3. LCD Display
4. ON/OFF Key
ins
rum n
°C
Foodcare
MICROCOMPUTER THERMOMETER
RANGE
-50°C to 150°C
ON/OFF
ACCURACY ±0.4°C
HI 9061
1
2
s
ins
s
e
3
rum n
e
°C
1
2
3
Foodcare
4
RANGE
-50.0°C to 300°C
ON/OFF
ACCURACY
1. Battery Cover
2. Temperature
±0.4°C
MICROCOMPUTER
THERMOMETER
4
Probe Connector
3. LCD Display
HI 91541
4. ON/OFF Key
Specifications HI 9061C HI 9061F
Range -50.0 to 150.0°C -55.0 to 199.9°F
200 to 302°F
Resolution 0.1°C 0.1 / 1°F
Accuracy ±0.4°C (-20 to 80°C) ±0.8°F(-4 to 176°F)
(@20°C/68°F) ±0.3% F.S. (outside) ±0.3% F.S. (outside)
for one year, excluding probe error
Typical EMC ±0.5°C ±1°F Deviation with HI 765BL probe
Probe HI 765 series (optional)
Battery Type/Life 4 x 1.5 V AA / 200 hours
Environment 0 to 50°C (32 to 122°F); 100% RH
Dimensions 196 x 80 x 60 mm (7.7 x 3.1 x 2.4")
Weight 425 g (15 oz.)
6
Specifications HI 91541C HI 91541F
Range -50.0 to 300.0°C -55.0 to 299.9°F
300 to 570°F
Resolution 0.1°C 0.2°F up to 300°F
Accuracy ±0.4°C (up to 150°C) ±0.8°F(up to 300°F)
(@20°C/68°F) ±0.3% F.S. (outside) ±0.3% F.S. (outside)
for one year, excluding probe error
Typical EMC ±0.5°C ±1°F Deviation with HI 764 probe
Probe HI 764 series (optional)
Battery Type/Life 4 x 1.5 V AA / 200 hours
Environment 0 to 50°C (32 to 122°F); 100% RH
Dimensions 196 x 80 x 60 mm (7.7 x 3.1 x 2.4")
Weight 425 g (15 oz.)
7
OPERATIONAL GUIDE
INITIAL PREPARATION
Each meter is supplied com­plete with batteries.
Remove the back cover, un­wrap the batteries and install them while paying attention to their polarity.
To switch on, press the ON/OFF key on the front of the unit.
ON/OFF
ON/OFF
If the meter does not come on, make sure that the batteries securely sit in their place.
Each time the thermometer is switched on, it will carry a self-test to ensure that no segment is missing. The LCD shows a full set of fig­ures during the self-test.
°C
°F
HI
LO
M
After the test the ther­mometer will resume its operational mode.
If a temperature probe is plugged in, the unit displays the probe temperature.
If a probe is not plugged in, or the cable is defective, the display will show "Er" (for HI 9060 and HI 9061) or "
--------
----" (for HI 91541).
--------
HI / LO MEMORIES (for HI 9060 only)
The maximum and minimum temperatures are monitored throughout a continuous measur­ing process. The values may be recalled or cleared at any time during the measurement.
Enquiries of the highest or lowest measured temperature may be made by pressing the respective HI or LO keys.
The appropriate display indicator will appear together with the value retrieved from memory. Release the key to resume normal operation.
°C
HI
°C
LO
HI
LO
By pressing the CLEAR key, the present measurement reading becomes the highest and lowest temperature in memory, i.e. both HI / LO are the same temperature reading.
The "HI/LO" display indicator will blink twice to notify user that clearing process is in progress.
°C
To switch your thermometer off, press the ON/OFF key again.
8
CLEAR
HI
LO
9
HOLD MODE (for HI 9060 only)
The reading hold function is activated by the HOLD key. The measured temperature is frozen on the display when this function key is pressed.
A blinking "M" on the display indicates the operating mode.
°C
HOLD
M
Press the same key again to resume normal opera­tion.
HOLD
MEASURING SCALE (°C/°F) (for HI9060 only)
HI 9060 and HI 9061 stop to operate when the
low battery signal is detected. The user is warned by the code "Eb".
HI 91541 displays "BAT" when the batteries are run down.
See also the Battery
BAT
Replacement section on page 14.
When the meter is
°C
turned on it automatically defaults to the °C scale.
Measurements can be performed in either the Centigrade or Fahrenheit scale. To change the scale, press the °C/°F key once.
LOW BATTERY DETECTION
°F
°C/°F
10
11
DISPLAY CODES GUIDE
Your thermometer is factory programmed to diagnose a fault or warn of low battery levels. This is indicated by the error codes on the LCD. Moreover, self-explanatory sym­bols are used to remind the user of the operating mode or conditions.
DISPLAY DESCRIPTION
Er (for HI9060 The probe is not con-
and HI 9061) nected to the instrument
----(for HI91541) or the reading is out of
range.
Eb (for HI9060 Battery weak, need to be
and HI 9061) replaced.
BAT(for HI 91541)
All segments lit Initial input falls out of in­for more than 3" strument range.
For HI 9060 only:
°C The instrument is read-
ing in the Centigrade scale.
°F The instrument is read-
ing in the Fahrenheit scale.
M (blinking) Freeze current reading
on display.
HI The display reports the
maximum measured tem­perature.
LO The display reports the
minimum measured tem­perature.
HI / LO (blinking) The instrument is clear-
ing the maximum and minimum measured tem­perature.
CALIBRATION
All Hanna Instruments thermometers have been accurately pre-calibrated at the factory.
It is generally recommended to have all ther­mometers recalibrated at least once a year.
For an accurate annual recalibration, contact your nearest Hanna Service Center.
Hanna Test Plugs provide a quick and easy way to test the meter's accuracy by simply connecting these Test Plugs to the probe connector of the meter. If the reading differs by more than 0.4°C (0.8°F) from the Test Plug value, the unit is due for recalibration.
Choose the right Test Plug to suit your needs:
For HI9060 and HI9061:
HI 765-18C Calibration key,-18.0°C ±0.4°C HI765000C Calibration key, 0.0°C ±0.4°C HI765070C Calibration key,+70.0°C±0.4°C HI765-004F Calibration key, -0.4°F ±0.8°F HI765032F Calibration key,+32.0°F ±0.8°F HI765158F Calibration key,+158.0°F±0.8°F
For HI91541:
HI 764-18C Calibration key,-18.0°C ±0.4°C HI764000C Calibration key, 0.0°C ±0.4°C HI764070C Calibration key,+70.0°C±0.4°C HI764-004F Calibration key, -0.4°F ±0.8°F HI764032F Calibration key,+32.0°F ±0.8°F HI764158F Calibration key,+158.0°F±0.8°F
12
13
BATTERY REPLACEMENT
When the batteries be­come weak, the meter displays "Eb" (for HI9060 and HI9061) or "BAT" (for HI91541) to warn the user.
BAT
Battery replacement must only take place in a non hazardous area using the battery types specified in this instruction manual (see page 17).
In order to replace rundown batteries, simply remove the two screws on the rear cover of the instrument and replace the four batteries with new ones paying at­tention to the correct po­larity.
Replace the cover and tighten the two screws.
TEMPERATURE PROBES & ACCESSORIES
Hanna Instruments offers a wide range of probes to meet all your requirements from liquids to air and penetration to surface.
These probes use highly sensitive thermistor sensors which provide greater accuracy, faster response and a temperature range that is superior to conventional thermistor probes.
All Hanna temperature probes are supplied pre-calibrated from the factory and are ready to be used with your meter.
The probes are easily connected to your meter with a standard RCA jack.
Completely interchangeable, these probes make it possible to switch from one to an­other without wasting time and money going through tedious calibration procedures.
They are available in different colors to avoid cross contamination during testing:
For HI 9060 and HI 9061:
HI765A Air probe, with 1 m (3.3') cable and
white handle
HI765A/10 Air probe, with 10 m (33') cable
and white handle
HI765BL General purpose liquid probe, with
1 m (3.3') cable and black handle
HI765BL/10 General purpose liquid probe, with
10 m (33') cable and black handle
HI765L General purpose liquid probe, with
1 m (3.3') cable and white handle
HI765L/10 General purpose liquid probe, with
10 m (33') cable and white handle
HI765PBL Penetration probe with 1 m (3.3')
cable and blue handle
HI765PBL/10 Penetration probe with 10 m (33')
cable and blue handle
HI765PG Penetration probe with 1 m (3.3')
14
15
cable and green handle
HI765PG/10Penetration probe with 10 m (33')
cable and green handle
HI765PR Penetration probe with 1 m (3.3')
cable and red handle
HI 765PR/10 Penetration probe with 10 m
(33') cable and red handle
HI 765PW Penetration probe with 1 m 3.3')
cable and white handle
HI 765PW/10Penetration probe with 10 m (33')
cable and white handle
HI 765W Wire probe, without handle (hard-
to-reach places) with 1 m (3.3') cable
HI 765W/10 Wire probe, without handle (hard-
to-reach places) with 10 m (33')cable
For HI 91541: HI764A Air probe, with 1 m (3.3') cable and
white handle
HI764A/10 Air probe, with 10 m (33') cable
and white handle
HI764L General purpose liquid probe, with
1 m (3.3') cable and white handle
HI764L/10 General purpose liquid probe, with
10 m (33') cable and white handle
HI764PBL Penetration probe with 1 m (3.3')
cable and blue handle
HI764PBL/10 Penetration probe with 10 m (33')
cable and blue handle
HI764PG Penetration probe with 1 m (3.3')
cable and green handle
HI764PG/10 Penetration probe with 10 m (33')
cable and green handle
HI764PR Penetration probe with 1 m (3.3')
cable and red handle
HI 764PR/10 Penetration probe with 10 m
(33') cable and red handle
HI 764PW Penetration probe with 1 m 3.3')
cable and white handle
HI 764PW/10Penetration probe with 10 m (33')
16
cable and white handle
HI 764W Wire probe, without handle (hard-
to-reach places) with 1 m (3.3') cable
HI 764W/10 Wire probe, without handle (hard-
to-reach places) with 10 m
(33')cable
Hanna Instruments Temperature Probes
205 mm
8.1" 100 mm
3.9"
3 mm
0.12"
HI764P - HI765P
205 mm
8.1" 100 mm
3.9"
3 mm
0.12"
HI764A - HI765A
205 mm
8.1"
100 mm
3.9"
3 mm
0.12"
HI764L - HI765L
3mm
0.12"
HI764W - HI765W
Other Accessories:
HI 710002 Soft carrying case measuring
280 x 120 x 50 mm
HI 721308 1.5V, AA size alkaline battery
(10 pcs)
HI 721317 Hard carrying case (dimen-
sions: 340x 230 x 90 mm)
MAN60R3 Instruction Manual
17
WARRANTY
All Hanna Instruments meters are warranted for two years against defects in workmanship
and materials when used for their intended purpose and maintained according to instruc­tions.
The probes and calibration keys are war­ranted for a period of six months.
This warranty is limited to repair or replace­ment free of charge.
Damages due to accident, misuse, tampering or lack of prescribed maintenance are not covered.
If service is required, contact the dealer from whom you purchased the instrument. If under warranty, report the model number, date of purchase, serial number and the nature of the failure. If the repair is not covered by the warranty, you will be notified of the charges incurred. If the instrument is to be returned to Hanna Instruments, first obtain a Returned Goods Authorization Number from the Cus­tomer Service department and then send it with shipment costs prepaid. When shipping any instrument, make sure it is properly pack­aged for complete protection.
To validate your warranty, fill out and return the enclosed warranty card within 14 days from the date of purchase.
All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner.
Hanna Instruments reserves the right to modify the design, construction and ap­pearance of its products without advance notice.
18
CE DECLARATION OF CONFORMITY
Recommendations for Users
Before using these products, make sure that they are entirely suitable for the environment in which they are used.
Operation of these instruments in residential area could cause unacceptable interferences to radio and TV equipments, requiring the operator to take all necessary steps to correct interferences.
Any variation introduced by the user to the supplied equipment may degrade the instruments' EMC performance.
To avoid electrical shock, do not use these instruments when voltages at the measurement surface exceed 24VAC or 60VDC.
To avoid damages or burns, do not perform any measurement in microwave ovens.
In particular cases HI9060 could switch from °C to °F or vice-versa. In such cases press the °C/°F key to resume the proper measurement range.
In particular cases the meters could turn off. In such cases they can be turned on by pressing the ON/ OFF key.
19
HANNA LITERATUREHANNA LITERATURE
HANNA LITERATURE
HANNA LITERATUREHANNA LITERATURE
Hanna publishes a wide range of catalogs and hand­books for an equally wide range of applications. The reference literature currently covers areas such as:
• Water Treatment
• Process
• Swimming Pools
• Agriculture
• Food
• Laboratory
• Thermometry
and many others. New reference material is constantly being added to the library.
For these and other catalogs, handbooks and leaflets, contact your dealer or the Hanna Customer Service Center nearest to you. To find the Hanna Office in your vicinity, check our home page at www.hannainst.com.
MAN60R4 02/00
http://www.hannainst.com
Loading...
