Hanna Instruments HI 9023 User Manual

Instruction Manual

HI 9023C - HI 9023CN

HI 9024C - HI 9025C

HI 9110 - HI 9210

Dear Customer, Thank you for choosing a Hanna Product. Please read this

instruction manual carefully before using the instrument. It will provide you with the necessary information for a correct use of the instrument, as well as a precise idea of its versatility. If you require further technical information, do not hesitate to e-mail us at tech@hannainst.com.

These instruments are in compliance with the

directives.

HI 9210N

Portable Waterproof

pH Meters

TABLE OF CONTENTSTABLE OF CONTENTS

TABLE OF CONTENTS

TABLE OF CONTENTSTABLE OF CONTENTS

PRELIMINARY EXAMINATION ..................................................... 3

GENERAL DESCRIPTION ............................................................ 3

FUNCTIONAL DESCRIPTION HI 9023C & HI 9023CN .................. 5

SPECIFICATIONS HI 9023C & HI 9023CN ................................. 6

FUNCTIONAL DESCRIPTION HI 9024C & HI 9025C ..................... 7

SPECIFICATIONS HI 9024C & HI 9025C.................................... 8

FUNCTIONAL DESCRIPTION HI 9110.......................................... 9

FUNCTIONAL DESCRIPTION HI 9210 & HI 9210N .................... 10

SPECIFICATIONS HI 9110, HI 9210 & 9210N ......................... 11

OPERATIONAL GUIDE ............................................................. 12

pH CALIBRATION ................................................................... 16

pH VALUES AT VARIOUS TEMPERATURES ................................ 24

TROUBLESHOOTING GUIDE ..................................................... 25

ELECTRODE CONDITIONING AND MAINTENANCE......................... 26

TAKING REDOX MEASUREMENTS (HI 9023C & HI 9025C only). 29

BATTERY REPLACEMENT & AUTO-OFF ...................................... 30

ACCESSORIES ....................................................................... 31

ELECTRODE APPLICATION REFERENCE GUIDE ............................. 37

WARRANTY .......................................................................... 38

CE DECLARATION OF CONFORMITY ......................................... 39

Manufacturers since 1978

These Instruments are in

Compliance with the CE Directives

PRELIMINARY EXAMINATIONPRELIMINARY EXAMINATION

PRELIMINARY EXAMINATION

PRELIMINARY EXAMINATIONPRELIMINARY EXAMINATION

Remove the instrument from the packing material and examine it carefully to make sure that no damage has occurred during shipping. If there is any noticeable damage, notify your Dealer immediately.

Note: Save all packing materials until you are sure that the instru-

ment functions correctly. Any damaged or defective item must be returned in its original packing materials together with the supplied accessories.

GENERAL DESCRIPTIONGENERAL DESCRIPTION

GENERAL DESCRIPTION

GENERAL DESCRIPTIONGENERAL DESCRIPTION

These waterproof Hanna instruments are heavy-duty pH meters designed to provide laboratory results and accuracy under harsh industrial conditions.

HI 9023C, pH/mV/°C meter utilizes an advanced customized microprocessor. The meter has three memorized buffer values (4.01, 7.01 and 10.01) and automatic buffer recognition to avoid errors during calibration. There are no trimmers, making calibration an easy process, even for non-technical personnel. Temperature effects are automatically compensated for, or can be manually adjusted. With HI 9023CHI 9023C

HI 9023C you can also measure ORP (Oxidation Reduction Poten-

HI 9023CHI 9023C tial) or Ion Specific. Millivolt measurements automatically switch from

0.1 to 1 mV resolution when the reading reaches 400mV. HI 9023C is supplied with HI 1230B combination double-junction gel

pH electrode, HI 7669/2W temperature probe, pH 4.01 and 7.01 (20 mL each) buffer solutions, sample vessel, 1.5V AA size batteries (4 each) and a rugged carrying case.

HI 9023CN, pH/mV/°C meter utilizes an advanced customized microprocessor. The meter has three memorized buffer values (4.01,

7.01 and 10.01) and automatic buffer recognition to avoid errors during calibration. Temperature effects are automatically compensated for.

HI 9023CN

electrode, pH 4.01 and 7.01 (20 mL each) buffer solutions, sample vessel, 1.5V AA size batteries (4 each) and a rugged carrying case.

HI 9024C and HI 9025C are pH/°C meters with a built-in microprocessor. A large dual-level LCD displays the pH and temperature simultaneously. The display has graphic symbols to make the calibration procedure easy to follow. The meters have 5 memorized buffer

is supplied with HI 1217D 4-in-1 amplified, gel pH/ C

values (4.01, 6.86, 7.01, 9.18 and 10.01), buffer recognition to avoid errors during calibration and automatic temperature compensation. You can use HI 9025C with ORP (Oxidation Reduction Potential)

or Ion Specific Electrodes. Millivolt measurements automatically switch from 0.1 to 1 mV resolution when the reading reaches 400 mV. To insure trouble-free operation, the meter's circuitry comes with built-in protection against electromagnetic interference.

HI 9024C and HI 9025C are supplied with HI 1230B combination double-junction, gel pH electrode, HI 7669/2W temperature probe, pH 4.01 and 7.01 (20 mL each) buffer solutions, sample vessel, 1.5V AA size batteries (4 each) and a rugged carrying case.

HI 9110 pH meter has simple manual temperature compensation and calibration which make this meter easy to use in laboratory and field. The calibration trimmers are sealed behind a protective cover so that they cannot be accidentally moved or readjusted by unauthorized persons.

HI 9110 is supplied with FC 100B combination double-junction, refillable pH electrode, calibration screwdriver, 1.5V AA size batteries (4 each) and a soft carrying case.

HI 9210 pH meter has simple manual temperature compensation and calibration with only two buttons, making it simple to use for even non-technical personnel. The calibration trimmers are sealed behind a protective cover so that they cannot be accidentally moved or readjusted by unauthorized persons.

HI 9210 is supplied with HI 1230B combination double-junction, gel pH electrode, calibration screwdriver and 1.5V AA size batteries (4 each).

HI 9210N pH/°C meter measures both pH and temperature. It has only two buttons, making it simple to use for even non-technical personnel. The calibration trimmers are sealed behind a protective cover so that they cannot be accidentally moved or readjusted by unauthorized persons.

HI 9210N is supplied with HI 1217D 4-in-1, gel, amplified pH/ C electrode, calibration screwdriver and 1.5V AA size batteries (4 each).

FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION

FUNCTIONAL DESCRIPTION

FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION

HI 9023C & HI 9023CNHI 9023C & HI 9023CN

HI 9023C & HI 9023CN

HI 9023C & HI 9023CNHI 9023C & HI 9023CN

1) Electrode connector (BNC for HI 9023C and DIN for HI 9023CN)

2) Temperature probe socket (HI 9023C only)

3) Liquid Crystal Display

4) CAL key to enter or exit calibration mode

5) CFM key to confirm calibration

6)Ï°C and Ð

9023C only)

7) ON/OFF key to turn the instrument on or off

8) RANGE key to select pH, C or mV

9) Low battery indicator (additional decimal point)

10) Mode indicator

C C

C keys for manual temperature setting (HI

C C

SPECIFICATIONS HI 9023CSPECIFICATIONS HI 9023C

SPECIFICATIONS HI 9023C

SPECIFICATIONS HI 9023CSPECIFICATIONS HI 9023C

& HI 9023CN& HI 9023CN

& HI 9023CN

& HI 9023CN& HI 9023CN

HI 9023C HI 9023CN

Range 0.00 to 14.00 pH

±399.9 mV (ISE); ±1999 mV (ORP)

0.0 to 100.0 C 0.0 to 70.0 C

Resolution 0.01 pH

0.1 mV (ISE); 1 mV (ORP)

0.1 C

Accuracy ±0.01 pH (@20°C/68°F) ±0.2 mV (ISE); ±1 mV (ORP)

±0.4 C ±0.5 C

Typical EMC ±0.02 pH Deviation ±0.2 mV; ±1 mV

±0.2 C ±0.5 C

Calibration Automatic with 3 memorized standard

buffers (4.01, 7.01, 10.01)

Temperature Automatic or manual Automatic Compensation 0 to 100 C (32-212 F) 0 to 70 C (32-158 F)

Electrode HI1230B plastic body, HI1217D plastic body,

combination pH, BNC 4-in-1 gel pH/ C, DIN

1 m cable (included) 1 m cable (included)

Temperature Probe HI 7669/2W (incl.) not necessary Input Impedance 1012 Ohm Battery Type & Life 4x1.5V, AA size (alkaline batteries)

approx. 400 hours of continuous use

auto-shut off after 10 minutes of non-use

Environment 0 to 50 C (32 to 122 F); 100% RH Dimensions 196x80x60 mm (7.7x3.1x2.4") (meter)

340x230x80 mm (13.8x9x3.1") (kit)

Weight 425 g (15 oz.) (meter)

1.3 Kg (3.0 lb.) (kit)

FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION

FUNCTIONAL DESCRIPTION

FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION

HI 9024C & HI 9025CHI 9024C & HI 9025C

HI 9024C & HI 9025C

HI 9024C & HI 9025CHI 9024C & HI 9025C

1) BNC electrode connector

2) Temperature probe socket

3) Liquid Cristal Display

4) RANGE key to select pH or mV (HI 9025C only)

5) ON/OFF key to turn the meter on or off

6) CAL key to enter or exit calibration mode

7) CFM key to confirm calibration

8)Ï°C and Ð

selecting pH buffer value

9) MEM key to store pH value in memory

10) MR key to recall the stored value from memory

11) User-friendly graphic symbols

12) Primary display

13) Secondary display

C C

C keys for manual temperature setting, or

C C

SPECIFICATIONS HI 9024C & HI 9025CSPECIFICATIONS HI 9024C & HI 9025C

SPECIFICATIONS HI 9024C & HI 9025C

SPECIFICATIONS HI 9024C & HI 9025CSPECIFICATIONS HI 9024C & HI 9025C

HI 9024C HI 9025C

Range 0.00 to 14.00 pH; 0.0 to 100.0 C

— 0.0/±399.9 mV (ISE) —

Resolution 0.01 pH; 0.1 C

— 0.1 mV (ISE) — 1 mV (ORP)

Accuracy ±0.01 pH; ±0.5 C (@20°C/68°F) — ±0.2 mV (ISE)

Typical EMC ±0.01 pH; ±0.1 C Deviation — ±0.3 mV (ISE)

Calibration Automatic with 5 memorized standard

buffers (4.01, 6.86, 7.01, 9.18, 10.01)

Offset Calibration ±1 pH Slope Calibration From 70 to 108% Temperature Automatic or manual from 0 to 100 C

Compensation (32 to 212 F) Electrode HI 1230B pH electrode (included) Temperature Probe HI 7669/2W (included) Input Impedance 1012 Ohm Battery Type & Life 4x1.5V, AA size (alkaline batteries)

approx. 400 hours of continuous use

auto-shut off after 10 minutes of non-use

Environment 0 to 50 C (32 to 122 F); 100% RH Dimensions meter: 196x80x60 mm (7.7x3.1x2.4")

kit: 340x230x80 mm (13.8x9x3.1")

Weight meter: 425 g (15 oz.)

kit: 1.3 Kg (3.0 lb.)

400/±1999 mV (ORP)

FUNCTIONAL DESCRIPTION HI 9110FUNCTIONAL DESCRIPTION HI 9110

FUNCTIONAL DESCRIPTION HI 9110

FUNCTIONAL DESCRIPTION HI 9110FUNCTIONAL DESCRIPTION HI 9110

FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION

FUNCTIONAL DESCRIPTION

FUNCTIONAL DESCRIPTIONFUNCTIONAL DESCRIPTION

HI 9210 & HI 9210NHI 9210 & HI 9210N

HI 9210 & HI 9210N

HI 9210 & HI 9210NHI 9210 & HI 9210N

4 5

Foodcare

pH METER

HI 9210N ATC pH METER

RANGE

0.00 TO 14.00 pH ACCURACY ±0.02pH

HI 9110

OFF

SET

pH °C

RANGE pH: °C:

0.00 - 14.00

0.0 -70.0

ON/OFF

RANGE

8 9

1) Battery cover

2) BNC electrode connector

3) Offset calibration trimmer

4) Slope calibration trimmer

5) Temperature setting trimmer

6) Mode indicator

7) Liquid Crystal Display

8) ON/OFF key to turn the meter on or off

9) pH/°C SET key to select pH measurement or for manual temperature setting

1) Battery cover

2) Electrode connector (BNC for HI 9210 and DIN for HI 9210N)

3) Offset calibration trimmer

4) Slope calibration trimmer

5) Temperature setting trimmer (HI 9210) or Temperature Calibration (HI 9210N)

6) Mode indicator

7) Liquid Crystal Display

8) ON/OFF key to turn the meter on or off

9) RANGE key to visualize the temperature (HI 9210N) or for manual temperature setting (HI 9210)

SPECIFICATIONS HI 9110, HI 9210SPECIFICATIONS HI 9110, HI 9210

SPECIFICATIONS HI 9110, HI 9210

SPECIFICATIONS HI 9110, HI 9210SPECIFICATIONS HI 9110, HI 9210

& HI 9210N& HI 9210N

& HI 9210N

& HI 9210N& HI 9210N

HI 9110 HI 9210 HI 9210N

Range pH 0.00 to 14.00 pH

°C — 0.0 to 70.0 C

Resolution pH 0.01 pH

°C — 0.1 C

Accuracy pH ±0.02 pH (@20°C/68°F) °C — ±0.5 C

Typical EMC pH ±0.05 pH ±0.02 pH Deviation °C — ±0.5 C

Calibration Manual 2 points through trimmers Offset Calibration ±1 pH Slope Calibration From 85 to 105% of nominal value Temperature Manual 0 to 100 C Auto 0 to 70 C

Compensation (32 to 212 F) (32 to 158 F) Electrode FC 100B HI 1230B HI 1217D

pH (incl.) pH (incl.) pH/ C (incl.)

Input Impedance 10

Ohm

Battery Type 4x1.5 volt, AA size (alkaline batteries); Life 2000 hours of continuous use

Environment 0 to 50 C (32 to 122 F); 100% RH Dimensions 196 x 80 x 60 mm (7.7 x 3.1 x 2.4") Weight 320 g (11.3 oz.)

OPERATIONAL GUIDEOPERATIONAL GUIDE

OPERATIONAL GUIDE

OPERATIONAL GUIDEOPERATIONAL GUIDE

INITIAL PREPARATION

Each meter is supplied complete with batteries. Remove the back cover, unwrap the batteries and install them while paying attention to polarity.

HI 9023C, HI 9024C, HI 9025C:

To prepare the instrument for use connect the pH electrode and the temperature probe to the BNC and temperature sockets on the top of the instrument. The temperature probe can be used independently to take temperature measurements, or it can be used in conjunction with the pH electrode to utilize the meter's ATC capability. If the probe is disconnected, temperature can also be set manually with the UP and DOWN keys. To switch the instrument on, press and hold the

ON/OFF key for a fraction of a second. The meter has a built-in protection against electromagnetic interference and the delayed response of the keys assures that the commands are not mistaken for stray signals.

HI 9110 and HI 9210:

Connect the pH electrode to the BNC connector on the top of the instrument and press the ON/OFF key.

HI 9210N and HI 9023CN:

°C

ON/OFF

Connect the pH/ C electrode to the DIN connector on the top of the instrument and press the ON/OFF key.

ON/OFF
