Handheld Nautiz X5 Quick Start Guide

NAUTIZ X5

Quick Start Guide

1 Package

The pictures shown below may differ from the actual products. To
purchase additional or optional products, contact our customer center.

Nautiz X5 Main Body

Battery (High Capacity)

USB Cable

Desktop Cradle Stylus Pen

Adaptor Spring Wire

2 Your Nautiz X5

The pictures shown below may differ from the actual products.
To purchase additional or optional products, contact our customer
center.

Barcode Scanner Window

Stylus Pen

Side
Scanner
Button

Earphone Jack

Side Scanner
Button

Power Button

Speaker

Power LED

Communication LED

LCD Screen

Front scanner Button

Direction/Send/End/

Number/Character/

Function Buttons

Mice

USB Cable Connector

Stylus Pen Strap

Hand strap holder - Top

Flash

Camera

Speaker

Reset Button

IrDA

Hand strap holder - Bottom

Battery

Battery Fixing Pin

3 Connecting/Disconnecting battery

The pictures shown below may differ from the actual products.
To purchase additional or optional products, contact our customer
center.

To connect the battery

1 Align the battery to the

groove and insert in the
direction of the arrow.

2 Turn the fi xing pins on both

sides of the battery pins
inward until the battery is
secured.

To disconnect the battery

1 Power off the PDA.

2 Turn the fi xing pins on both

sides of the battery pins
outward to disconnect the
battery.

3 Pull out the battery after

lifting it in the direction of
the arrow.

Removing battery without power off may cause a technical problem.
Turn off a PDA by using [Power] button on PDA completely to prevent
causing problem of PDA.
When PDA is failing to turn on due to removing battery witout turn off,
please make hard-reset the PDA.
Please press (# button + Enter button + Reset button) at the same time.
All information from Memory (RAM) will be all deleted after hard-reset.
