Hafler PH60B User Manual

PH60B

User Guide

Phono Stage

Haer is a division of Radial Engineering Ltd.
1588 Kebet Way, Port Coquitlam
BC, Canada V3C 5M5
[phone] info@haer.com

www.haer.com

Table of Contents Page

Features ..............................................................................1-2

Overview ................................................................................ 3

Set the Load ........................................................................... 4

Connect ...............................................................................5-6

Adjusting the Gain .................................................................. 7

Using ...................................................................................... 8

Warranty .................................................................Back Cover

Thank you for purchasing the Haer PH60B™ phono stage,

one of the best sounding and most versatile phono preamps

ever made. The PH60B will boost the signal from your turn­table and apply the necessary RIAA curve, allowing you to
connect to a HIFI playback system, a pro audio console input

or a recording interface.

Before making any connections, make sure your audio system

is turned off. This will help avoid loud turn-on and connection
transients that can damage more sensitive components such
as tweeters.

The Haer PH60B is designed for a turntable that is equipped
with a moving coil (MC) cartridge, allowing for high quality

playback over balanced or unbalanced outputs. If your turn-

table is equipped with a moving magnet (MM) cartridge, please
consider purchasing the PH50B, which is specically designed

for these types of cartridges.

PH60B PHONO STAGE

USER GUIDE

Hafler

LOW CUT POWER

R

PH60B

LIFT

CE

15VDC · 400mA

GROUND

LEFT RIGHTBALANCED

Hafler is a division of Radial Engineering Ltd.

OUTPUT

LEFT RIGHT

INPUT

LEFT RIGHT

PH60B PHONO PREAMP

FOR MOVING COIL

Hafler

R

PH60B PHONO STAGE

Haer

1

FEATURES

1. LOW CUT: Activates the high-pass lter to control low frequencies

2. LIFT: Ground lift on the XLR outputs to remove hum and buzz

3. POWER: Turns on the PH60B

1

3

2
