BA24

BA24 - ( )AS05100

Apparecchiatura elettronica

ISTRUZIONI PER L’INSTALLAZIONE

Electronic control unit

INSTRUCTIONS FOR INSTALLATIONS

I UK F E

D P NL

• Questo prodotto è stato collaudato in GI.BI.DI. verificando la perfetta corrispondenza delle caratteristiche

alle direttive vigenti.

• La GI.BI.DI. S.r.l. si riserva la facoltà di modificare i dati tecnici senza avviso, in funzione dell'evoluzione del prodotto.

LEGGERE ATTENTAMENTE QUESTO MANUALE PRIMA DI PROCEDERE ALL’INSTALLAZIONE.

• This product has been tested in Gi.Bi.Di. verifying the perfect correspondence of the characteristics to the current directive.

• Gi.Bi.Di. S.r.l. reserves the right to modify the technical data without prior notice depending on the product development.

PLEASE READ CAREFULLY THIS MANUAL BEFORE PROCEEDING WITH THE INSTALLATION.

• Ce produit a été essayé en Gi.Bi.Di. en vérifiant la correspondance parfaite des caractéristiques aux règles en vigueur.

• Gi.Bi.Di. S.r.l. se réserve la faculté de modifier les données techniques sans aucun préavis suivant l’évolution de ses produits.

S’IL VOUS PLAÎT DE LIRE AVEC ATTENTION CETTE MANUAL AVANT DE PROCÉDER AVEC L’INSTALATION.

• Este producto ha sido probado en Gi.Bi.Di. averiguando la perfecta correspondencia de las

características a las normas vigentes.

• La empresa Gi.Bi.Di. S.r.l. se reserva el derecho de modificar los datos técnicos sin previo aviso, en función de la evolución del producto.

POR FAVOR LEER CON ATENCIÓN ESTE MANUAL ANTES DE PROCEDER CON LA INSTALACIÓN.

BA24

• Dieses Produkt wurde in Gi.Bi.Di. geprüft um die perfekte Entsprechung der merkmäle an die geltende vorschriften zu prüfen.

• Gi.Bi.Di. S.r.l. behält sich das recht vor, die technischen daten der produktentwicklung entsprechend ohne voranzeige abzuändern.

BITTE LESEN SIE VORSICHTIG DIESEN MANUAL BEVOR MIT DER ANGLAGE VORZUGEHEN.

• Este produto foi testado em Gi.Bi.Di. verificando a correspondência perfeita das características ao normas vigentes.

• A Gi.Bi.Di. S.r.l. reserva-se o direito de modificar os dados técnicos sem pré-aviso em função de evolução do produto.

LER COM ATENÇÃO ESTE MANUAL ANTES DE PROCEDER COM A INSTALAÇÃO.

• Dit product werd gekeurd in Gi.Bi.Di. Er werd nauwlettend gecontroleerd of de kenmerken van het product perfect overeenkomen met de geldige richtlijnen.

• Gi.Bi.Di. S.r.l. behoudt zich het recht voor de technische gegevens te wijzigen zonder waarschuwing vooraf, als dat nodig is voor de evolutie van het product.

LEES DEZE GEBRUIKSAANWIJZING ZEER AANDACHTIG ALVORENS DE INSTALLATIE AAN TE VATTEN.

• Η εταιρία GI.BI.DI. S.r.l. έχει ελέγξει αυτό το προιόν όσον αφορά την τέλεια προσαρμογή των χαρακτηριστικών του στην ισχύουσα νομοθεσία.

• Η εταιρία Gi.Bi.Di. S.r.l διατηρεί το δικαίωμα αλλαγής των τεχνικών προδιαγραφών χωρίς προειδοποίηση, όσον αφορά ανάπτυξη των προιόντων της.

LEES DEZE GEBRUIKSAANWIJZING ZEER AANDACHTIG ALVORENS DE INSTALLATIE AAN TE VATTEN.

BA24

24Vac

CF2

CF1

~ 230Vac

JP2

LCD1

BA24

DL4

DL5

DL6

FCA M1

FCC M1

FCA M2

JP4

COM EL

SW1 SW2 SW3 SW4

DL7

DL8

DL9

DL10

FCC M2

COSTA

RISERVA

PHOTO 2

PHOTO 1

RL6 RL7

EL1

EL2

GND

SPIA

24Vcc

+24Vcc

24Vcc 3W MAX

DL11

COM

SEC

+24Vcc

JP5

30 31

GND

RL8 RL9

LED STATUS

ON OFF

JP6

ANT

JP3

DL1

DL2

DL3

18 19 20 21 22 23 24 25 26 27 28 29

PED

STOP

START

RL1 RL2 RL3 RL5

JP1

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17

ACAC+ SK

- SK

MOTOR

OPEN

CB24

(AS05020)

RL4

LAMP

24Vcc 10W MAX

JP3

18 19 20 21 22 23 24 25 26 27 28 29

PED (NO)

STOP (NC)

START (NO)

FCA M2 (NC)

FCA M1 (NC)

FCC M2 (NC)

FCC M1 (NC)

PHOTO 2 (NC)

COM

COSTA (NC)

RISERVA (NC)

PHOTO 1 (NC)

BA24

Control unit

Type

Power supply N° motors Motor power supply Flashing light Warning light

Accessories power supply

Safety device power supply Radio receiver

Operating temperature

Electronic control unit for the automation of one

or two motors - 24V dc - for swinging and sliding gates,

overhead garage doors and barriers

including safety device power supply

24Vdc 8W max including accessories power supply

BA24 / AS05100

230Vac monophase 50/60 Hz

1 or 2

24 Vdc

24Vdc 10W max

24Vdc 3W max 24Vdc 8W max

Plug-in

-20°C +60°C

TECHNICAL SPECIFICATIONS / FUNCTIONS

• Red warning LEDs of N.C. contacts. There isn't the safety devices LED; the possible anomaly is indicated by the writing SAF on the LCD.

• Green warning LEDs of N.A. contacts.

• Two electrical locks management.

• Safety test run before the opening and closing movement.

• Photocell 1 test run before the opening and closing movement.

• Amperometric circuit test run before the opening and closing movement.

• Stop and motion inversion for 2 seconds after intervention of the safety devices. At the next Start pulse the motion restarts in the obstacle freeing direction.

• SEPARATE SAFETY DEVICES POWER SUPPLY Connect the safety devices that must be tested to this

clamp.

Digital programming of all functions.

• Working time adjustable independently in opening and closing for each single motor.

• Deceleration time adjustable independently in opening and closing for each single motor in the final motion phase.

• Gate phase shift time adjustable independently in opening and closing.

• Adjustable pedestrian working time.

• Pause time adjustable and differentiated for complete or pedestrian opening.

• Thrust force adjustable on 10 levels for each motor.

• Decelerations selectable and adjustable independently on 10 levels for each motor.

• Absorption (anti-crushing) control adjustable on 100 levels for each single motor both in thrust phase and in deceleration phase.

• Deceleration enable modes: with single or double limit switch.

• 4 possible working functions (step-by-step, step-by-step with stop, condominium or automatic, dead-man).

• Possibility of choosing the system configuration from swing gate (single or double), overhead/barrier and sliding gate (single or double).

BA24

• COSTA choice with N.C. contact or 8K2 resistive.

• Anti-crushing enabling (motion inversion for 2 seconds and stop) or amperometric detection for limit switch.

• Specific menu for the exclusion of the accessories not used (picture 1, picture 2 and safety devices).

• Possibility to program: automatic closing, fast closing, pre-flashing, hammer stroke, final closing and opening

stroke, courtesy light, ending movement additional time, flashing light (both flashing and fixed), external clock management with three different modes, number of cycles for scheduled maintenance, installer code and number of performed cycles.

• Time self-learning.

INSTALLATION

Use glands adequate to ensure proper mechanical connection of cable and maintain the box protection degree IP55. (2)

INSTALLATION WARNINGS

• Before proceeding with the installation, fit a magnetothermal or differential switch with a maximum capacity of

10A upstream of the system. The switch must guarantee omnipolar separation of the contacts with an opening distance of at least 3 mm.

• To prevent possible interference, differentiate and always keep the power cables (minimum cross-section

2,5 mm²) separate from the signal cables (minimum cross-section 0.5 mm²).

• Make the connections referring to the following tables and to the attached screen-print. Be extremely careful to

connect in series all the devices that are connected to the same N.C. (normally closed) input, and in parallel all the devices that share the same N.O. (normally open) input. Incorrect installation or improper use of the product may compromise system safety.

• Keep all the materials contained in the packaging away from children, since they pose a potential risk.

• The manufacturer declines all responsibility for improper functioning of the automated device if the original

components and accessories suitable for the specific application are not used.

• After installation, always check carefully proper functioning of the system and the devices used.

• This instruction manual addresses people qualified for installation of “live equipment”. Therefore, good technical

knowledge and professional practice in compliance with the regulations in force are required.

• Maintenance must be carried out by qualified personnel.

• Before carrying out any cleaning or maintenance operation, disconnect the control unit from the mains.

• This control unit may only be used for the purpose for which it was designed. Check the aim of the final use

and make sure that all safety measures are taken.

• If the control equipment is installed on doors or leaves with wicket door, make sure that in case the wicket door

is open, the equipment is not allowed to work.

• Use of the product for purposes different from the intended use has not been tested by the manufacturer,

therefore any work is carried out on full responsibility of the installer.

• Mark the automated device with visible warning plates.

• Warn the user that children or animals may not play or stand around near the gate.

• Appropriately protect the danger points (for example, using a sensitive frame).

• The only control equipment does not guarantee anti-crushing safety. Please make sure that the security

devices connected to the control equipment are suitable for this purpose.

BA24

WARNINGS FOR THE USER

In the event of an operating fault or failure, cut the power upstream of the control unit and call Technical Service. Periodically check functioning of the safety devices. Any repairs must be carried out by specialised personnel using original and certified materials. The appliance is not to be used by children or people with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction

WARNING: IMPORTANT SAFETY INSTRUCTIONS

It is very important to follow the present instructions for your own safety. Please keep this manual.

ELECTRICAL CONNECTIONS: FASTONS

CF1 CF2

Secondary connection of 24Vac transformer

COLLEGAMENTI ELETTRICI: MORSETTIERE

Terminal

JP1

JP4

JP3

Position

1 2 3 4 5 6 7 8 9

13 14 15 16 17

Signal

LAMP LAMP

COM EL

+ ACC

START

Description

Battery charger equipment connection

+SK

-SK

Battery charger equipment connection Motor 1

Motor 1

Motor 2

Flashing light output 24V 10W max. Flashing light output 24V 10W max.

Electric lock negative (common) Electric lock 1 +24 Vdc positive - motor 112 EL1

EL2

Electric lock 2 +24 Vdc positive - motor 2 External accessory power supply negative (common)

GND

Warning light output 24Vdc 3W MAX

SPIA

+24Vcc external accessory power supply (photocells, radio, etc.) +24Vcc external safety device power supply.

SEC

START input (N.O.) PEDESTRIAN input (N.O.)

After an emergency intervention (SAFETY or AMPEROMETRIC) with motion inversion

PED

of the second leaf, the pedestrian command will activate both leafs to prevent them from overlapping.

Working:

Fast flashing in opening, off during pause, fast flashing in closing

BA24

JP3

STOP

FCAM1

FCCM1

FCAM2

FCCM2

PHOTO 2

PHOTO 1

RESERVE

STOP input (N.C.). If not used, jumper with terminal n° 29.

Opening limit switch input - motor 1 (N.C.). If not used, disable during programming.

Closing limit switch input - motor 1 (N.C.). If not used, disable during programming.

Opening limit switch input - motor 2 (N.C.). If not used, disable during programming.

Closing limit switch input - motor 2 (N.C.). If not used, disable during programming.

PHOTOCELL 2 input (N.C.). If not used, disable during programming.

Operation:

Input active during both opening and closing. If intercepted, it immediately stops the motion and holds it stopped until the photocell is freed. Upon release, motion always restarts in opening. If intercepted when the gate is closed, following a Start command, it does not allow opening the gate and it will be signalled with 5 fast flashes, then the warning light turns on to indicate that the gate is not in stand-by. Upon release, the gate will start opening without further commands. If intercepted during pause, it reloads the pause time.

PHOTOCELL 1 input (N.C.). If not used, disable during programming.

Operation:

Input active only during closing. It stops and inverts the motion, opening the gate completely. If the gate is closed, it does not affect its functioning. If intercepted during pause, it reloads the pause time.

Multifunctional input.

SAFETY DEVICES input (see menu C9) If not used, disable durino programming.

External clock: SEE PROGRAMMING C16-C17-C18

JP5

Operation:

IInput active during both opening and closing.

30 31

EDGE

It stops and inverts the motion for 2 sec. The gate will remain locked until the next Start pulse, which will restart it in the obstacle freeing direction. When active in stand-by, after the start/pedestrian command the door does not move and 3 long flashes (2 sec.) will signal the anomaly. If active in pause, the door does not close automatically (if expected) and 3 long flashes (2 sec.) will signal the anomaly.

THE EDGE ACTIVATION IS SIGNALLED BY THE WRITING “SAF” ON THE LCD.

Common inputs-outputs

COM

ANTENNA BRAID input

GND

ANT

ANTENNA SIGNAL input

PROTECTION FUSES

BA24

Position

F1 F2 F3

10 A 10 A

500 mA

FAST

DescriptionValue Type

Accessories and motor protection, power supply from battery charger circuit.

Equipment, motor and safety devices protection.

Accessories protection.

PROGRAMMING PROCEDURE AND SYSTEM CONFIGURATION

The system adjustments can be accessed via the display. There are 5 different menus marked with the letters A, C, F, H and E.

To enter the programming procedure:

Gbd

ESC

PASS

ESC

- start from the display as is shown in the picture

- Press simultaneously the keys ESC and OK for 3 seconds (The writing Gbd will turn off)

The writing P A S S appears on the display.

Press the OK button to go to step 3.

Press the ESC button to exit and return to step 1.

4 figures appear on the display ( 0 0 0 0 ), the first one is flashing.

0 0 0 0

ESC

4 0 0 0

ESC

With the + or – keys, the user selects the first digit of the installer code.

When the required digit is selected, press the OK key to confirm and go to step 4.

The second figure is flashing.

With the + or – keys, the user selects the second digit of the installer code.

When the required digit is selected, press the OK key to confirm and go to step 5.

BA24

The third figure is flashing.

4 6 0 0

ESC

4 6 8 0

ESC

4 6 8 3

With the + or – keys, the user selects the third digit of the installer code.

When the required digit is selected, press the OK key to confirm and go to step 6.

The last figure is flashing.

With the + or – keys, the user selects the last digit of the installer code.

When the required digit is selected, press the OK key to confirm and go to step 7.

Now the installer code is complete: go to step 8.

If the installer code is not correct, go back to step 2.

MENÙ A

ESC

A C F H E

ESC

A 5

ESC

The 5 main menus appear on the display (letters A C F H E); the A is flashing.

With the + or – keys you can select the other menus (the relative letter will blink).

Press the OK key to enter the selected menu (in the example A).

Use the + and + keys to enter the submenus (A1, A2, A3, A4,…)

Use the OK key to confirm the selected menu; a “Y” will appear next to the menu name to indicate that it is enabled.

A 6

BA24

Use the + and – keys to see the other submenus of the A menu; follow the procedure as before.

Press the ESC key to return to the higher level (menu A, C, F, H E).

MENÙ C

MENÙ H

ESC

A C F H E

ESC

C 1

ESC

A C F H E

ESC

When the 5 main menus are shown on the display (letters A C F H E) and the C is blinking;

Press the OK key to enter the selected menu (in the example C).

Use the + and – keys to select the submenus (C1, C2, C3, C4)

Press the OK button in sequence to:

enable the input (the Y will appear next to C1)

disable the input (the N will appear next to C1)

Enter the H1 submenu to see the setting of the numeric value.

Use the + and – keys to select the menu H; it will blink.

Use the OK key to enter the menu.

Use the + and – keys to select the various submenus (H1, H2, H3, H4)

H 1

ESC

Use the OK key to enter the selected submenu.

BA24

The stored value appears with the first digit blinking.

0 1 0 0

ESC

0 1 0 0

ESC

0 1 0 0

ESC

Use the + or - buttons to modify the value of this digit.

Use the OK key to confirm and go to step 16.

The second digit blinks.

Use the + or - buttons to modify the value of this digit.

Confirm with the OK button and go to step 17.

The third digit blinks.

Use the + or - buttons to modify the value of this digit.

Confirm with the OK button and go to step 18.

The fourth digit blinks.

0 1 5 0

ESC

H 1

ESC

Use the + or - buttons to modify the value of this digit.

Confirm with the OK button and go to step 19.

The H1 menu indication reappears.

Now press the ESC button to return to the higher level.

BA24

MENÙ E

Enter the submenu E to see the ENABLING/DISABLING setting.

A C F H E

ESC

E 1

ESC

E 2

ESC

E 3

ESC

Press the OK key to enter the menu.

E1 = PHOTOCELL 1

Press the OK button in sequence to: enable the input (the Y will appear next to E1) disable the input (the N will appear next to E1)

Use the + and – keys to enter the following or the previous menu. Use the ESC key to exit the menu; “ACFHE” is now shown on the display.

E2 = PHOTOCELL 2

Press the OK key in sequence to: enable the input (the Y will appear next to E2) disable the input (the N will appear next to E2)

Use the + and – keys to enter the following or the previous menu. Use the ESC key to exit the menu; “ACFHE” is now shown on the display.

E3 = SAFETY DEVICE (EDGE)

Press the OK key in sequence to: enable the input (the Y will appear next to E3) disable the input (the N will appear next to E3)

Use the + and – keys to enter the following or the previous menu. Use the ESC key to exit the menu; “ACFHE” is now shown on the display.

Press the ESC button again to store the settings and exit the programming phase by accessing normal operation.

A C F H E

ESC

BA24

The symbols shown at the beginning reappear.

Gbd

ESC

MENU A: SYSTEM CONFIGURATION AND OPERATING LOGIC SELECTION

KEY + : enters the following menu A1-A2-A3… KEY - : enters the previous menu A3-A2-A1… KEY ESC: leaves the menu KEY OK: enables Y (yes). It activates the function, and automatically disables the complementary function

(example: The activation of A4 = 1 motor automatically disactivates A5 = 2 motors).

In this case, the +, - and OK buttons have the following meanings:

+ » START

- » PEDESTRIAN OK » STOP

Function

SWING GATE /

OVERHEAD DOOR / BARRIER

SLIDING GATE

1 MOTOR CONFIGURATION

2 MOTORS CONFIGURATION

DescriptionMenu

State

It configures the system for swing gate, overhead door or barrier.

The activation of this menu automatically disables A3. It configures the system for a sliding gate.

This configuration automatically excludes:

• gate phase shifts in opening and closing

• hammer stroke

• 2 seconds final opening and closing stroke.

• T3 additional time

NOTE: the limit switches are NOT activated automatically, choose the

best configuration with the menu C5

It configures the system for one motor.

With this setting, the outputs for the electrical lock 2 can be used for

a 3 minutes timed courtesy light 24V max 10W.

The activation of this menu automatically disables A5.

It configures the system for two motors.

The activation of this menu automatically disables A4.

STEP BY STEP

WITH STOP LOGIC

STEP BY STEP LOGICA7 Y

It enables the STEP BY STEP WITH STOP logic

Operation:

Start Next Start Next Start Next Start

If automatic closing has been activated (menu C1) and the opening

phase is at the end of the cycle, when the pause time has elapsed (menu H9), the control unit automatically closes the gate. If the gate is open “Start” closes the gate. Pedestrian is uninfluential during opening. It will be active in pause if the pedestrian automatic closing is disabled. In closing it makes open both doors, only if C14 is not activated.

The activation of this menu automatically disables A7-A8-A9.

It enables the STEP BY STEP logic

Operation:

Start Next start Next start

If automatic closing has been activated (menu C1) and the opening phase is at the end of the cycle, when the pause time has elapsed (menu H9), the control unit automatically closes the gate. If the gate is open, “Start” closes the gate.

Pedestrian is uninfluential during opening. It will be active in pause if the pedestrian automatic closing is disabled. In closing it makes open both doors, only if C14 is not activated.

The activation of this menu automatically disables A6-A8-A9.

open stop close open

open close open

BA24

AUTOMATIC/

CONDOMINIUM LOGIC

It enables the AUTOMATIC/CONDOMINIUM logic

Operation:

Start Following Start commands

When the pause time has elapsed: If the automatic closing is activated, the system closes automatically. If the automatic closing is not activated, a “Start” or a Pedestrian command close the gate (if the opening is pedestrian).

Pedestrian is uninfluential during opening. It will be active in pause if the pedestrian automatic closing is disabled. both doors, only if C14 is not activated.

The activation of this menu automatically disactivates A6-A7-A9.

open not influential if the central is opening or charge again the pause time (if the gate is in pause) and the automatic closure is active.

In closing it makes open

BA24

It activates the DEAD MAN logic

Operation:

Start Pedestrian

In Dead Man's mode the keys on the control unit assume the following meanings: + key

- key

MENU C: FUNCTION SELECTION

KEY +: enters the following menu C1-C2-C3… KEY - : enters the previous menu C3-C2-C1… KEY ESC: leaves the menu KEY OK: activates Y (yes) / disactivates (N) the function.

DEAD MAN LOGIC

The opening and closing movements in the dead man's mode stop always on the first limit switch. Deceleration is never activated.

The only possible regulations are: PHASE SHIFT IN OPENING – PHASE SHIFT IN CLOSING – MOTOR POWER 1 AND 2 – AMPEROMETRIC LEVEL MOTOR 1 AND 2 If the keys are continuously held down, the flashing light remains active even if the motors stopped on the limit switches. Two motors always working. The activation of this menu automatically disables A6-A7-A8.

opens only if the Start key is held down. closes only if the Pedestrian key is held down.

open

AUTOMATIC CLOSINGC1

FAST CLOSING

DescriptionMenu Function

Status

Enables total automatic closing H9. Enables pedestrian automatic closing H11.

Pedestrian key uninfluential when in pause. Enables only total automatic closing H9.

If the pedestrian opening is activated, the pedestrian key determines

the closing. Enables only pedestrian automatic closing H11.

The pedestrian input is uninfluential in pause Disables the automatic closing.

If the pedestrian opening is activated, the pedestrian key will cause the closing.

If the total opening is activated, the “Start” will cause the closing and the pedestrian key will be uninfluential.

Enables fast closing function.

Operation:

Active only on photocell 1. Reduces the pause time to 3 seconds following interception and subsequent freeing of the photocells.

It disables the fast closing function

PRE-FLASHING

SAFETY DEVICES TESTC4

LIMIT SWITCHC5

DECELERATION

HAMMER STROKEC7

Enables 3-second pre-flashing before motor start

Disables pre-flashing.

The flashlight and the motors start at the same time.

Enables the safety devices test. See also menu C20. When the device is activated (edge intercepted), the writing SAF appears on the LCD

Operation:

PHASE 1: when the Start or the Pedestrian command is given, the amperometric circuit is tested. If an anomaly is detected, it will be indicated by 4 long flashing (2 sec.) of the flashing light. PHASE 2 : If the edge with N.C. contact is enabled, when the Start or

Pedestrian command is given, the power to the safety devices is cut off for 0,5 seconds and then restored: if the inputs of the safety devices open and immediately return N.C., the motors start, otherwise a fault is signalled with 3 long flashes (2 sec.). PHASE 3 : if the edge 8K2 is enabled, when the Start or the Pedestrian command is given, the COSTA. Input is tested (value 8K2). If the value is not correct, the fault is signalled with 2 long flashes (2 sec.). WARNING: The indication of the fault detected will be only one (the first one to be detected) even if there is more than one fault.

Disables the safety devices test.

Enables the single limit switch reading.

See the paragraph “LIMIT SWITCHES USE” Enables the double limit switch reading.

See the paragraph “LIMIT SWITCHES USE” Disables the limit switch reading.

Enables the deceleration function

Disables the deceleration function

Enables the hammer stroke function in opening to allow the

unhooking of the electrical lock. Enables the hammer stroke function both in opening and in closing to

allow the unhooking of the electrical lock. Disables the hammer stroke function

BA24

C10

FINAL OPENING AND

CLOSING STROKE

ANTI-CRUSHING /

LIMIT SWITCH AMPEROMETRIC

COSTA

Enables the final opening and closing stroke.

Operation:

At the end of the working time during opening and closing without deceleration, a 2 s pulse is given with the power set in menus F1 and F5. When deceleration is active, the pulse is given at the end of the

deceleration time. The final stroke is regulated by the amperometric level in menus F3 and F7.The final stroke is not controlled by the safety devices (edge/anticrushing). Not active with the sliding configuration.

Disables the final closing stroke in opening and closing

8K2

Enables the edge provided with 8K2 in series resistance Enables the edge provided with the N.C. contact (normally closed)

ABILITATO AMPEROMETRICA DI FINE CORSA (The amperometric inverts the motion).

NOTE: ENABLE THE ANTI-CRUSHING ONLY IF ALSO THE LIMIT SWITCHES ARE ENABLED.

ENABLED LIMIT SWITCH AMPEROMETRIC (The amperometric stops

the motion)

Anti-crushing not enabled / limit switch amperometric Active the courtesy light 24V max 10W in presence of 2 motors.

C11

C15

COURTESY LIGHT

WITH TWO MOTORS

T3 ADDITIONAL TIME C13

INVERSION FROM PEDESTRIANC14

FLASHING LIGHT

Operation:

Active on the electrical lock output 2 for 3 minutes after the end of the motors movement.

Courtesy light not activated with 2 motors.

T3 = time set for deceleration (H3 – H6) with the same menus F2 and

F6 settings T3 = time set for deceleration (H3 – H6) with the same menu F1 and

F5 settings

T3 excluded.

During the PEDESTRIAN closing, the PHOTO 1 – PHOTO 2 – PEDESTRIAN command opens only the pedestrian.

The START command causes the complete opening.

During the PEDESTRIAN closing, the PHOTO 1 – PHOTO 2 –

PEDESTRIAN – START command causes the complete opening.

Blinking flashing light output.

Fixed flashing light output.

C16

EXTERNAL CLOCK

CLOSING ALLOWED

(set automatic closing)

Enables the RESERVE input for the connection of an external clock.

Operation:

When the clock closes the contact on the RESERVE input, following a START command the door will open but not close automatically. When the contact on the RESERVE input is opened, the door will

automatically close after the pause time. When the door is open, the closing command can be given with “start” if the menu is STEP-BY-STEP or STEB-BY-STEP with STOP.

BA24

C17

C18

EXTERNAL CLOCK

CLOSING NOT ALLOWED

(set automatic closing)

EXTERNAL CLOCK

AUTOMATIC OPENING AND

CLOSING COMMAND

WARNING: remember to preset the automatic closing, the activation of this menu automatically defuse C17-C18.

Disables the RESERVE input

Enables the RESERVE input for the connection of an external clock.

Operation:

When the clock closes the contact on the RESERVE input, following a START command the door will open but not close automatically. When the contact on the RESERVE input is opened, the door will

automatically close after the pause time. It is not possible to activate the closing with the “start” command.

WARNING: remember to preset the automatic closing,the activation of this menu automatically defuse C16-C18.

Disables the RESERVE input

Enables the RESERVE input for the connection of an external clock.

Operation:

When the clock closes the contact on the RESERVE input, an opening command will automatically be activated without needing to give a

START command. When the contact on the RESERVE input is opened, the door will automatically close after the pause time.

WARNING: remember to preset the automatic closing, the activation of this menu automatically defuse C16-C17.

Disables the RESERVE input

Enables the Photocell 1 test.

The photocell 1 transmitter must be connected to the clamps 14 and 17.

Operation:

PHOTOCELL 1 TESTC20

When the “Start” or the “Pedestrian” command is given, the power to safety devices is cut off for 0,5 and then restored: if the photocell 1 input opens and immediately returns NC the motors start, otherwise a fault will be signalled by 4 blinks (1 sec.) of the flashing light.

Disables photocell 1 test.

BA24

Enables times programming.

C21 Y

AUTOMATIC PROGRAMMING

MENU F: FORCE AND SPEED ADJUSTEMENT

Operation:

See “Times self-learning Procedure”

Menu Function

MOTOR 1 FORCE

MOTOR 1 DECELERATION

SPEED

MOTOR 1 FORCE AMPEROMETRIC

MOTOR 1 DECELERATION

AMPEROMETRIC

MOTORE 2 FORCE

MOTOR 2 DECELERATION

SPEED

MOTOR 2 FORCE AMPEROMETRIC

MOTOR 2 DECELERATION

AMPEROMETRIC

Description

Adjusts the thrust of motor 1. 0001 = minimum force 0010 = maximum force

Adjusts the thrust of motor 1 during deceleration phase. 0001 = minimum force 0010 = maximum force

Adjusts the amperometric threshold of motor 1 during the full force motion. 0001 = minimum threshold 0100 = maximum threshold

Adjusts the amperometric threshold of motor 1 during the deceleration. 0001 = minimum threshold 0100 = maximum threshold

Adjusts the thrust of motor 2. 0001 = minimum force 0010 = maximum force

Adjusts the thrust of motor 2 during deceleration phase. 0001 = minimum force 0010 = maximum force

Adjusts the amperometric threshold of motor 2 during the full force motion. 0001 = minimum threshold 0100 = maximum threshold

Adjusts the amperometric threshold of motor 1 during the deceleration. 0001 = minimum threshold 0100 = maximum threshold

MENU H: TIME ADJUSTMENT AND SETTINGS

All the times can be set in steps of 1 s.

Menu Function

H4 H5

MOTOR 1 OPENING TIME MOTOR 1 CLOSING TIME

MOTOR 1 DECELERATION

TIME

MOTOR 2 OPENING TIME MOTOR 2 CLOSING TIME

MOTOR 2 DECELERATION

TIME

Description

Leaf 1 opening time.Tmax 300 sec. Leaf 1 closing time.Tmax 300 sec.

Leaf 1 operating time in deceleration mode. Tmax 100 sec.

Leaf 2 opening time. Tmax 300 sec.

Leaf 2 closing time. Tmax 300 sec.

Leaf 2 operating time in deceleration mode.Tmax 100 sec.

BA24

H10

H11

H12

H13

LEAF 2 PHASE SHIFT TIME

IN OPENING

LEAF 1 PHASE SHIFT TIME

IN CLOSING

AUTOMATIC CLOSING

PAUSE TIME

PEDESTRIAN OPENING TIME

AUTOMATIC PEDESTRIAN

CLOSING PAUSE TIME

CYCLES NUMBER

INSTALLER CODE

Delay the start in opening of leaf 2 with respect to leaf 1. In the case of double sliding gate, the time H7 will not be considered. Tmax 100 sec.

Delay the start in opening of leaf 1 with respect to leaf 2. In the case of double sliding gate, the time H8 will not be considered. Tmax 100 sec.

Determines the pause time in opening before automatic closing. Tmax 300 sec.

Determines the pedestrian opening time.Tmax 300 sec.

Determines the pause time in pedestrian opening bifore automatic closing. Tmax 300 sec.

Allows the setting of a number of cycles (opening+ closing) before the maintenance request. The value set will always be multiplied for 10. If 0000 is set, the numbering is excluded. When the set number of cycles is reached, the maintenance request is signalled by a slow blink of 60 sec. at the end of the movement.

WARNING: every time you enter the menu H12 the cycles numbering is reset and starts again.

Allows the input of the installer code to customize the settings during the programming phase. The INSTALLER CODE is the only way to enter the programming menu.

WARNING: in case of loss of the installer code, it will be possible to delete the old one by pressing simultaneously the keys + and – for 3 seconds when the writing PASS appears. In this way, all the existing setting are erased and the default ones are automatically set. Only the settings of the performed cycles are still stored in memory.

H14

H15

SOFTWARE VERSION

NUMBER OF PERFORMED CYCLES

Shows the firmware version installed on the equipment. (R__XX)

Number of performed cycles. The value displayed on the LCD is increased every 10 movements.

MENU E: EXTERNAL DEVICES ENABLING-DISABLING

KEY +: enters the following menu E1-E2-E3... KEY - : accede al menu precedente E3-E2-E1… KEY ESC: leaves the menu KEY OK: enables (Y) / disables (N) the function

WARNING: The STOP key cannot be excluded in menu E. If it is not used, jumper the clamps 20-29.

BA24

DescriptionMenu Function

Status

Photocell 1 enabled

PHOTOCELL 1

PHOTOCELL 2

EDGE (SEFETY DEVICE)

TIMES MANAGEMENT

T3 ADDITIONAL TIME

Additional time at the end of the working time (with full force or during deceleration phase according to the settings) that allows to continue the movement to close the leaf even if there is wind. The T3 function is not active with the sliding configuration. During the T3 time, the anti-crushing is not active, so the T3 time must start as near as possible next to the door stroke. In case of utilisation of double limit switch it's advisable that the second one is not exceeded to maintain the control in case of change of direction.

TIME PROGRAMMING PROCEDURE

Photocell 1 disabled

Photocell 2 enabled

Photocell 2 disabled

Edge enabled

Edge disabled

CAUTION: start with the gate completely closed.

The times are programmed by means of successive START pulses. To enter this procedure select the menu C21. (menu C21 blinking) By pressing OK, the times programming procedure starts (menu C21 Y fixed) then:

1 motor configuration

• START the leaf starts opening.

• When the leaf arrives at the desired opening position START the leaf stops.

• Counting of the pause time.

• When the desired pause time has elapsed START the leaf starts closing.

• When the leaf arrives at the closing position START the leaf stops.

• At this point the procedure has finished, the blinking menu C21 (without Y) reappears.

• If you want to repeat the operation press OK.

• If you want to finish the operation of times learning saving the data, key ESC as long as the horizontal lines and

Gbd inscription do not appear on the display.

2 motors configuration

• START the leaf 1 starts opening.

• After the desired opening phase shift time START the leaf 2 starts opening.

• When the leaf 1 arrives at the desired opening position START the leaf 1 stops.

• When the leaf 2 arrives at the desired opening position START the leaf 2 stops.

• Counting of the pause time.

• When the desired pause time has elapsed START the leaf 2 starts closing.

• After the desired closing phase shift time START the leaf 1 starts closing.

BA24

• When the leaf 2 arrives at the closing position START the leaf 2 stops.

• When the leaf 1 arrives at the closing position START the leaf 1 stops.

• At this point the procedure has finished, the blinking menu C21 (without Y) reappears.

• If you want to repeat the operation press OK.

• If you want to finish the operation of times learning saving the data, key ESC as long as the horizontal lines

and Gbd inscription do not appear on the display.

CAUTION:

During the times programming phase, motion always occurs at a non-decelerated speed. If decelerations are needed, stop the leaves before stroke, so remember to activate the decelerations option (menu C6) and to set deceleration times (menu H3 and H6). During the times programming phase, the limit switches and amperometric thresholds are not considered. The microcontroller does not consider time fractions lower than a second, so the real time is rounded up or down. The defined times can subsequently be modified manually by accessing the dedicated menus and changing the numerical data. If the installation is configured as double sliding gate, the motors will move as indicated in the procedure with the phase shift in opening and closing. During the normal functioning, the phase shift will be reset in any case.

USING THE LIMIT SWITCHES

If the deceleration function is enabled, the limit switches mark the start of the deceleration period. The gate continues the decelerated motion for the time set in the menus H3 and H6. If using two limit switches, the first one starts deceleration and the second one stops deceleration but does not lock the motion if T3 and the final stroke are activated.

Make sure that you set the run times longer than the time necessary to reach the limit switch. If deceleration is not enabled, the limit switches lock the motion if T3 and the final stroke are deactivated.

The additional time T3 and the final closing/opening stroke, if enabled, also work when there are limit switches.

If using only one limit switch with deceleration activated, during the deceleration phase the intervention of the amperometric threshold will determine the end of motion (anti-crushing device not active).

If using two limit switches with deceleration activated, during the deceleration phase the intervention of the amperometric threshold will determine activation of the anti-crushing device (if enabled).

BACKUP BATTERIES USE

If the installation is preset for the use of backup batteries, the amperometric thresholds and the forces must be set checking the correct oeration even when the control equipment is supplied only by the batteries. When the control equipment is supplied only by the batteries, the voltage of the motor power supply is lower, thus the motor absorptions will be lower too.

The control equipment checks the level of the power supply voltage:

• with voltage higher than 24Vdc the control equipment is supplied by main, no restriction;

• with voltage lower than 24Vdc the power supply source is the battery, the motors do not decelerate;

BA24

• with voltage around 20-21Vdc, the battery is exhausted; it is possible to open the door but not to close. When

the leaf should start the motion, it does not move and the fault “exhausted battery” is signalled by 4 slow blinks of the flashing light;

• with voltage around 16V, the battery is almost exhausted, no movement is allowed. Following a command, the

fault “exhausted battery is signalled with 4 s blinks (fast in stand-by, slow in pause). In this case, the battery voltage could be insufficient for both the flashing light and the warning light.

RESET

By pressing simultaneously the + and – keys when the writing “PASS” appears, the default settings are restored (only the number of performed cycles are still stored).

FLASHING LIGHT SIGNALS SUMMARY

Fault

Photo 2 intercepted in stand-by after a start command

Edge intercepted in stand-by after a start command

Signal

5 fast flashings

3 slow flashings

Effect

When released it opens

Blocked closed door

Edge intercepted in pause after a start command or at the beginning closing

Photo 1 test failed at opening. Photo 1 test failed at closing.

Amperometric circuit test failed at opening

Amperometric circuit test failed at closing

Edge N.C. test failed at opening Edge N.C. test failed at closing Edge 8K2 test failed at opening Edge 8K2 test failed at closing

Backup batteries at 20-21Vdc in stand-by after a start command

Backup batteries at 20-21Vdc in pause after a start command or at beginning closing

Backup batteries at 16Vdc in stand-by after a start command

Backup batteries in pause after a start command or at beginning closing

Expired maineinance

(*) When backup batteries voltage is low the switching on of flashing and warning lights could not be visible. (*) If the flashing light setting is with fixed light (C15 d), the blinking is not present but only the fixed switching on.

3 slow flashings

4 fast flashings 4 fast flashings

4 slow flashings

3 slow flashings 3 slow flashings 2 slow flashings 2 slow flashings

4 seconds slow flashing (*)

4 seconds fast flashing (*)

4 seconds slow flashing (*)

1 minute slow flashing

with closed door

Blocked open door

Blocked closed door

Blocked open door

Blocked closed door

Blocked open door

Blocked closed door

Blocked open door

Blocked closed door

Blocked open door

The only opening is allowed

Blocked open door

Blocked closed door

Blocked open door

None

DEFAULT SETTINGS

• Active parameters type A:

A2 A5 Y A8

• Active parameters type C:

C1 C2 C3 C4 C5 E1 C6 C7 C8 N C9 C10 C11 C13 C14 C15 C16 C17 C18 C20

YT N Y N

N N

NC Y1 N N N Y N N N N

BA24

SWING GATE/OVERHEAD DOOR/BARRIER TYPE 2 MOTORS AUTOMATIC-CONDOMINIUM USING

AUTOMATIC CLOSING ENABLED (GENERAL AND PEDESTRIAN) FAST CLOSING DISABLED PRE-FLASHING ENABLED SAFETY DEVICES TEST DISABLED LIMIT SWITCH ENABLED (SINGLE PAIR) DECELERATIONS DISABLED WATER HAMMER DISABLED FINALE CLOSING STROKE DISABLED SAFETY DEVICE (EDGE) WITH N.C. CONTACT ANTI-CRUSHING ENABLED COURTESY LIGHT WITH 2 MOTORS DISABLED T3 DISABLED IN “PEDESTRIAN CLOSING, ACTIVATES COMPLETE OPENING INTERMITTENT FLASHING LIGHT EXTERNAL CLOCK CONTACT DISABLED EXTERNAL CLOCK CONTACT DISABLED EXTERNAL CLOCK CONTACT DISABLED oPHOTO 1 TEST DISABLED

• Parameters type F

F1 F2 F3 F4 F5 10 F6 F7 F8

• Parameters type H:

H1 H2 25 H3 H4

10 05 80 50

05 80 50

20 25

MOTOR 1 FORCE MOTOR 1 DECELERATION AMPEROMETRIC MOTOR 1 FORCE AMPEROMETRIC MOTOR 1 DECELERATION MOTOR 2 FORCE MOTOR 2 DECELERATION AMPEROMETRIC MOTOR 2 FORCE AMPEROMETRIC MOTOR 2 FORCE

MOTOR 1 OPENING TIME MOTOR 1 CLOSING TIME MOTOR 1 DECELERATION TIME MOTOR 2 OPENING TIME

BA24

H5 H6 H7 5 H8 H9 H10 H11 H12 0000 H13 H14 H15

• Parameters type E:

E1 E2 E3

MOTOR 2 CLOSING TIME

MOTOR 2 DECELERATION TIME LEAF 2 PHASE SHIFT TIME IN OPENING

LEAF 1 PHASE SHIFT TIME IN CLOSING

PAUSE TIME

PEDESTRIAN OPENING TIME

PEDESTRIAN PAUSE TIME NUMBER OF CYCLES

0000

INSTALLER CODE

xxxx

SOFTWARE VERSION (format: R__xx)

0000

NUMBER OF CYCLES DONE

PHOTOCELL 1 ENABLED

PHOTOCELL 2 ENABLED

SAFETY DEVICE (EDGE) ENABLED

FINAL CHECKS AND TESTING

Before powering the control unit , run the following tests:

Check the electrical connections: improper connection may be harmful to both the control unit and the operator.

Check proper position of the limit switches.

Preset the mechanical stops in opening and closing.

Power the equipment.

Check that the red LEDs of the normally closed contacts are on and the green LEDs of the normally open contacts are off.

Check that the writing SAF does not appear on the LCD (intercepted or faulty edge).

Check that the relative LEDs turn off when limit switches work.

Check that the relative LED turns off when the photocells ray is intercepted. Check that the relative LED turns off when the safety devices work.

Check that the motors are locked and ready to work with the “GATE COMPLETELY CLOSED”.

10-

Remove possible obstacles in the operating area of the gate, then give the command START. At the first

11-

command, the equipment starts opening, then check that the motion direction is correct. If not invert the wires in the terminals M1 and/or M2. The gate will stop upon reaching the first opening limit switch. It is necessary a complete movement to

12-

activate the regular working of the decelerations.

BA24 DISPOSAL

Gi.Bi.Di advises recycling the plastic components and to dispose of them at special authorised centres for electronic components thus protecting the environment from polluting substances.

UKUK

SIMPLIFIED PROGRAMMING

Connect all the connections (wire motors using a 1.5 mm² wire)

Enter the installation code, and then set the type of function desired from menu A2/A3.

Set the number of motors used. Menu A4/A5.

Set the operation mode. Menu A6/A7/A8/A9.

Go to menu C21, and select «Y» to activate automatic time programming, then press «START» (+ key) (see page 20 "Time learning procedure")

Go to menu C5 to program slowdowns.

Go to menu C6 to choose the number of limit switches. We recommend programming a single limit switch when stopping points are present.

Use the dedicated menus to adjust each time parameter.

Press «ESC» to exit programming.

10-

Check whether the force used by operators on the gate is either sufficient or excessive. Go to menu F to adjust, if necessary.

BA24

CE Declaration of conformity

The manufacturer:

GI.BI.DI. S.r.l.

Via Abetone Brennero, 177/B,

46025 Poggio Rusco (MN) ITALY

Declares that the products:

ELECTRONIC CONTROL UNIT BA24

are in conformity with the following CEE Directives:

LVD Directive 2006/95/CE and subsequent amendments;

•

• EMC Directive 2004/108/CE and subsequent amendments;

and that the following harmonised standards have been applied:

•

EN60335-1,EN60335-2-103, EN50366

•

EN61000-6-2, EN61000-6-3

Date 10/12/08

Managing Director

Oliviero Arosio

Cod. AIC4976 - 12/2008 - Rev. 01

GI.BI.DI. S.r.l.

Via Abetone Brennero, 177/B 46025 Poggio Rusco (MN) - ITALY Tel. +39.0386.52.20.11 Fax +39.0386.52.20.31 E-mail: comm@gibidi.com

Numero Verde: 800.290156

w w w . g i b i d i . c o m

Gibidi BA24 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
