RX10
Fully Rugged
Tablet
• Intel® Core™ M vPro™ Processor
Technology
• 10.1” Full HD LumiBond®2.0 display with
Getac sunlight readable technology
• Getac proprietary SnapBack accessories
with keyboard & SmartCard options
• 1D/2D imager barcode reader option
• LifeSupport™ hot-swap battery
technology for uninterrupted power
SnapBack Add-on Office Dock
Rugged Mobile Computing Solutions
Optional 1D/2D
Imager Barcode
Reader
USB 3.0
USB 2.0
Micro HDMI
/ Audio I/O
DC in Jack
Optional
HD WebcamBCR Trigger
Fingerprint Scanner
Or RFID Reader
Docking
Connector
RF Antenna
Pass-through
Mic
Function Key 1
Function Key 2
Windows Key
Volume Up
Volume Down
Power Button
RX10
Specifications
Fully Rugged
10.1” Tablet
Getac recommends Windows.
Operating System Windows 7 Professional
Windows 10 Professional
Mobile Computing Platform Intel
Graphics Intel
Display 10.1” TFT LCD Full HD LumiBond
®
Core™ M Processor Technology
®
Intel
Core™ M 1.2GHz Processor (up to 2.90 GHz
®
with Intel
- 4M Intel
Intel
with Intel
- 4M Intel
Turbo Boost Technology)
®
Smart Cache
®
Core™ M 800MHz Processor (up to 2 GHz
®
Turbo Boost Technology)
®
Smart Cache
®
HD Graphics 5300
®
2.0 display with
Getac sunlight readable technology capacitive
multi-touch screen (1920 x 1200, 800nits)
Memory & Storage 4GB LPDDR3 (expandable to 8GB)
SSD 64GB / 128GB
Keyboard 6 tablet buttons (Windows, Power, Function Key
1, Function Key 2, Barcode Reader Trigger, Volume
Up, Volume Down)
Pointing Device Touchscreen
- Capacitive multi-touch screen
- Optional dual mode touchscreen (multi-touch
and digitizer)
Expansion Slot Optional 1D/2D imager barcode reader
I/0 Interface HD webcam x 1
8M pixels auto focus rear camera x 1
Headphone out/mic-in combo x 1
DC in Jack x 1
USB 3.0 (9-pin) x 1
USB 2.0 (4-pin) x 1
Docking connector (16-pin) x 1
Micro HDMI x 1
Optional RF antenna pass-through for GPS, WLAN
and WWAN
®
Communication Interface Intel
Dual Band Wireless-AC 7265, 802.11ac
Bluetooth (v4.0 class 1)i
Optional dedicated GPS
Optional Gobi™ mobile broadband
Software Getac Utility
Getac Camera
®
Reader®
Adobe
Getac Barcode Manager
Optional CompuTrace
Security Feature TPM 2.0
Optional Intel
®
Persistence module
®
vPro™ Technology
Optional fingerprint scanner or RFID reader
Optional SnapBack add-on :
Hand Strap & Kick Stand & Smart Card Reader
Optional SnapBack add-on :
Hand Strap & Kick Stand & Smart Card Reader &
Detachable Keyboard
Power AC adapter (65W, 100-240VAC, 50 / 60Hz)
Li-Ion battery (15.2V, 2160mAh)
iv
LifeSupport™ hot-swap battery technology
Dimension (W x D x H) &
Weight
280x 245 x 18.8mm
1.2 ~1.3kg
v
Rugged Feature MIL-STD-810G certified and IP65 certified
4 feet drop resistant
Vibration & drop resistant
e-Mark certified for vehicle usage
Optional ANSI/ISA 12.12.01
Optional EN/IEC 60601-1
vi
Environmental Specification Temperature
:
-Operating:-21ºC to 55ºC
- Storage: -40ºC to 71ºC
Humidity:
- 95% RH , non-condensing
Optional Accessories Carry bag
Main battery (15.2V, 2160mAh)
AC adapter (65W, 100-240VAC)
Vehicle adapter (90W, 11-16V DC and 22-32V DC)
Capacitive stylus & tether
Digitizer pen
Shoulder strap (2-point)
Hand-strap & Kick Stand
Hand-Strap & Kick Stand & Smart Card Reader
Hand-Strap & Kick Stand & Smart Card Reader &
Detachable Keyboard
Vehicle dock
Office dock
Protection Film
Multi-Bay Charger (Two Bay)
Multi-Bay Charger (Eight Bay)
ii,iii
Docking Solutions
Serial Port External VGA DC in Jack USB LAN HDMI RF Antenna Connector
Vehicle Dock
Office Dock
i Bluetooth performance and connectable distance may be subject to interference from the environment
and other client devices, users may be able to reduce effects of interference by minimizing the number
of active Bluetooth wireless devices that are operating in the area.
ii RFID and Fingerprint scanner are mutually exclusive options.
iii 13.56MHz Contactless RFID/NFC reader (ISO 15693, 14443 A/B, Mifare and FeliCa™ compliant).
iv Battery life testing conducted under MobileMark 2007. Battery performance will vary dependant upon
1 - 1 2 1 - 3 (Optional)
- 1 1 4 1 1 -
Getac UK Limited
Mitac House, Nedge Hill, Telford,
Shropshire, TF3 3AH, U.K.
Tel: +44 1952 207 231
Email: sales-getac-UK@getac.com
www.getac.co.uk
Copyright© 2015 Getac Technology Corporation and/or any of its affiliates. All rights reserved.
All specifications are subject to change without notice. V01M07Y15UK
software applications, wireless settings, power management settings, LCD brightness, customized
modules and environmental conditions. The battery has a limited number of charge cycles and may
eventually need to be replaced by a Getac service provider. Battery life and charge cycles vary by use and
settings.
v Weight varies from configurations and optional accessories.
vi Tested by an international independent third party test lab following MIL-STD-810G.
