Quick Start Guide
GV-IP Camera
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
IC-QG-AP-EN
© 2016 GeoVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part,
without the written consent of GeoVision.
Every effort has been made to ensure that the information in this manual is
accurate. GeoVision, Inc. makes no expressed or implied warranty of any
kind and assumes no responsibility for errors or omissions. No liability is
assumed for incidental or consequential damages arising from the use of
the information or products contained herein. Features and specifications
are subject to change without notice. Note that memory card slot (local
storage) is not supported for Argentina.
GeoVision, Inc.
9F, No. 246, Sec. 1, Neihu Rd.,
Neihu District, Taipei, Taiwan
Tel: +886-2-8797-8377
Fax: +886-2-8797-8335
http://www.geovision.com.tw
Trademarks used in this manual: GeoVision, the GeoVision logo and GV
series products are trademarks of GeoVision, Inc. Windows is the
registered trademarks of Microsoft Corporation.
April 2016
Contents
Introduction............................................................................... viii
Options ......................................................................................
Note for Connecting to GV-System / GV-VMS......................
Note for Recording..................................................................
Note for Adjusting Focus and Zoom......................................
Note for Installing Camera Outdoor......................................
Note for Closing the Bullet Camera Cover..........................
Note for Bullet Waterproof Failures.......................................
Note for USB Storage and WiFi Adapter................................
Note for Silica Gel Bags ..........................................................
1. Box Camera..............................................................................1
1.1 Packing List...............................................................................1
1.2 Overview...................................................................................2
GV-BX1200 Series / 1500 Series / 2400 Series / 2500 Series
/ 2600 / 3400 Series / 5300 Series / 12201............................2
1.3 Accessory Installation................................................................5
1.3.1 C-Mount Lenses...........................................................5
1.3.2 Infrared Illuminators (Optio nal).....................................6
1.4 Connecting the Camera.............................................................7
GV-BX1200 Series / 1500 Series / 2400 Series / 2500 Series /
2600 / 3400 Series / 5300 Series/ 12201...............................7
2. Ultra Box Camera.....................................................................9
2.1 Packing List...............................................................................9
2.2 Overview.................................................................................10
2.3 Installation...............................................................................11
2.4 Connecting the Camera...........................................................13
3. Target Box Camera................................................................14
3.1 Packing List............................................................................. 14
xxi
xxiii
xxiv
xxv
xxvi
xxviii
xxix
xxx
xxx
i
3.2 Overview.................................................................................15
3.3 Installation...............................................................................16
3.4 Connecting the Camera...........................................................18
4. IR Arctic Box Camera ............................................................19
4.1 Packing List............................................................................. 19
4.2 Overview.................................................................................21
4.3 Installation...............................................................................23
4.4 Connecting the Camera...........................................................28
5. Mini Fixed Dome & Mini Fixed Rugged Dome .....................32
5.1 Packing List............................................................................. 32
5.2 Overview.................................................................................34
GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series
/ 5301 Series.......................................................................34
GV-MDR .............................................................................36
5.3 Installation...............................................................................39
GV-MFD Series...................................................................39
GV-MDR Series..................................................................41
5.4 Connecting the Camera...........................................................45
5.4.1 Wire Definition............................................................45
5.4.2 Power and Network Connection.................................45
5.4.3 Vehicle In s ta lla tio n.....................................................46
6. Target Mini Fixed Dome.........................................................47
6.1 Packing List............................................................................. 47
6.2 Overview.................................................................................48
6.3 Installation...............................................................................49
6.4 Connecting the Camera...........................................................51
7. Target Mini Fixed Rugged Dome..........................................52
7.1 Packing List............................................................................. 52
7.2 Overview.................................................................................54
7.3 Installation...............................................................................55
7.4 Connecting the Camera...........................................................61
ii
8. Bullet Camera (Part I).............................................................62
8.1 Packing List............................................................................. 62
8.2 Overview.................................................................................63
8.3 Installation...............................................................................64
8.3.1 Adjusting th e An g le s..................................................66
8.3.2 Adjusting Lens and Inserting a Memory Card.............69
8.3.3 Inserting the Sun-Shield Cover...................................72
8.4 Connecting the Camera...........................................................73
8.4.1 Wire Definition............................................................73
8.4.2 Connecting the Power Cable......................................75
9. Bullet Camera (Part II)............................................................76
9.1 Packing List............................................................................. 76
9.2 Overview.................................................................................77
9.3 Installation...............................................................................79
9.4 Connecting the Camera...........................................................86
10. Bullet Camera (Part III).........................................................88
10.1 Packing List........................................................................... 88
10.2 Overview...............................................................................89
10.3 Installation.............................................................................90
10.3.1 Adjusting th e An g le s.................................................94
10.3.2 Adjusting Lens..........................................................96
10.4 Connecting the Camera.........................................................97
10.4.1 Wire Definitio n..........................................................97
10.4.2 Power Connection....................................................98
11. Ultra Bullet Camera..............................................................99
11.1 Packing List........................................................................... 99
11.2 Overview.............................................................................100
11.3 Installation...........................................................................102
11.4 Connecting the Camera.......................................................106
11.4.1 Waterproofing the Cable ........................................106
11.4.2 Wire Definition........................................................108
11.4.3 Power Connection..................................................109
iii
12. Target Bullet Camera (Part I).............................................110
12.1 Packing List........... ..............................................................110
12.2 Overview.............................................................................111
12.3 Installation...........................................................................113
12.4 Connecting the Camera.......................................................117
12.4.1 Wire Definition........................................................117
12.4.2 Power Connection..................................................118
13. Target Bullet Camera (Part II)............................................119
13.1 Packing List........... ..............................................................119
13.2 Overview.............................................................................121
13.3 Installation...........................................................................122
13.4 Connecting the Camera.......................................................127
13.4.1 Wire Definition........................................................127
13.4.2 Power Connection..................................................127
14. Vandal Proof IP Dome (Part I)...........................................128
14.1 Packing List........... ..............................................................128
14.2 Overview.............................................................................130
14.3 Installation...........................................................................132
14.3.1 Hard-Ceiling Mount................................................133
14.3.2 In-Ceiling Mount.....................................................138
14.4 Connecting the Camera.......................................................141
14.4.1 Wire Definition........................................................141
14.4.2 Connecting the Power Cable..................................143
15. Vandal Proof IP Dome (Part II)..........................................144
15.1 Packing List........... ..............................................................144
15.2 Overview.............................................................................147
15.3 Installation...........................................................................149
15.4 Connecting the Camera.......................................................159
15.4.1 Connecting the Power Cable..................................159
15.4.2 Connecting the I/O Device......................................160
iv
16. Vandal Proof IP Dome (Part III).........................................161
16.1 Packing List........... ..............................................................161
16.2 Overview.............................................................................163
16.3 Installation...........................................................................165
16.4 Connecting the Camera.......................................................170
16.4.1 Definition................................................................170
16.4.2 Power Connection..................................................171
17. Target Vandal Proof IP Dome............................................172
17.1 Packing List........... ..............................................................172
17.2 Overview.............................................................................175
17.3 Installation...........................................................................177
17.4 Connecting the Camera.......................................................186
18. Fixed IP Dome....................................................................187
18.1 Packing List........... ..............................................................187
18.1.1 Packing List for Hard-Ceiling Mount .......................187
18.1.2 Packing List for In-Ceiling Mount............................188
18.2 Overview.............................................................................189
18.3 Installation...........................................................................191
18.3.1 Hard-Ceiling Mount................................................191
18.3.2 In-Ceiling Mount.....................................................195
18.3.3 Wall-Surface Mount................................................199
18.4 Connecting the Camera.......................................................201
19. Target Fixed IP Dome........................................................202
19.1 Packing List........... ..............................................................202
19.2 Overview.............................................................................203
19.3 Installation...........................................................................205
19.4 Connecting the Camera.......................................................207
20. Cube Camera......................................................................208
20.1 Packing List........... ..............................................................208
20.2 Overview.............................................................................209
20.3 Installation...........................................................................210
v
20.4 Connecting the Camera.......................................................212
21. Advanced Cube Camera....................................................213
21.1 Packing List........... ..............................................................213
21.2 Overview.............................................................................214
21.3 Installation...........................................................................216
21.4 Connecting the Camera.......................................................218
22. PT Camera..........................................................................219
22.1 Packing List........... ..............................................................219
22.2 Overview.............................................................................221
22.3 Installation...........................................................................223
22.3.1 Ceiling Mount.........................................................223
22.3.2 L-Shaped Wall Mount.............................................225
22.4 Connecting the Camera.......................................................228
23. Pinhole Camera..................................................................229
23.1 Packing List........... ..............................................................229
23.2 Overview.............................................................................231
23.3 Installation...........................................................................233
23.4 Connecting the Camera.......................................................237
24. Accessing the Camera.......................................................238
24.1 System Requirement...........................................................238
24.2 Accessing the Live View......................................................239
24.2.1 Checking the Dynamic IP Address.........................240
24.2.2 Configuring the IP Address.....................................242
24.2.3 Configuring the Wireless Connection......................244
24.3 Adjusting Image Clarity........................................................248
24.3.1 Using Focus Adjustment Cap.................................251
25. The Web Interface..............................................................252
26. Upgrading System Firmware.............................................255
vi
27. Restoring to Default Settings............................................257
27.1 Using the Web Interface......................................................257
27.2 Directly on the Camera........................................................258
Box Camera......................................................................258
Ultra Box Camera and Target Box Camera.......................259
Mini Fixed Dome...............................................................260
Mini Fixed Rugged Dome..................................................261
IR Arctic Box Camera........................................................261
Target Mini Fixed Target Mini Fix ed Rugged Dome..........262
Bullet Camera...................................................................263
Ultra Bullet Camera...........................................................264
Target Bullet Camera........................................................264
Vandal Proof IP Dome......................................................265
Target Vandal Proof IP Dome...........................................266
Fixed IP Dome..................................................................266
Target Fixed IP Dome.......................................................267
Cube Camera ...................................................................267
Advanced Cube Camera...................................................268
PT Camera.......................................................................268
Pinhole Camera................................................................269
vii
Introduction
Welcome to the GV-IPCam Quick Start Guide. In this quick guide, you will
find information on the installation and basic configurations of the
GV-IPCam H.264 / H.265 series.
Camera Model No. Lens Description
1.3 MP Low Lux / 1.3 MP /
Box
Camera
GV-BX1500-1F
GV-BX2500-1F
Fixed
GV-BX1500-2F
GV-BX2500-2F
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux
1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux / 2
MP Super Low Lux
viii
GV-BX2400-1F
GV-BX3400-1F
GV-BX2400-2F
GV-BX3400-2F
2 MP / 3 MP, WDR Pro,
Varifocal
2 MP / 3 MP, WDR Pro,
Camera Model No. Lens Description
Box
Camera
Box
Camera
(Coming)
Box
Camera
GV-BX1500-3V
GV-BX2500-3V
Varifocal
GV-BX2600
GV-BX3400-5V 3 MP, WDR Pro
GV-BX5300-6V
GV-BX1500-8F
GV-BX2500-8F
GV-BX3400-8F
GV-BX5300-8F
GV-BX1500-3V
GV-BX2500-3V
GV-BX3400-3V
GV-BX5300-6V
GV-BX12201 Varifocal 12 MP
Fixed
Varifocal
1.3 MP Low Lux / 1.3 MP /
1.3 MP Super Low Lux / 2
MP Super Low Lux
2 MP, Super Low Lux,
WDR Pro
5 MP
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro / 5 MP
1.3 MP Low Lux / 2 MP
Super Low Lux / 3 MP
WDR Pro, P-Iris
5 MP, P-Iris
ix
Camera Model No. Lens Description
GV-EBX1100-0F 1.3 MP, Low Lux
Target
Box
Camera
GV-EBX1100-2F 1.3 MP, Low Lux
GV-EBX2100-0F 2 MP, Low Lux
GV-EBX2100-2F
GV-UBX1301-0F
GV-UBX1301-1F
GV-UBX1301-2F
Fixed
2 MP, Low Lux
1.3 MP
Ultra Box
Camera
x
GV-UBX2301-0F
GV-UBX2301-1F
GV-UBX2301-2F
GV-UBX3301-0F
GV-UBX3301-1F
GV-UBX3301-2F
Fixed
2 MP
3 MP
Camera Model No. Lens Description
GV-BX1500-E 1.3 MP, Super Low Lux,
IR Arctic
Box
Camera
GV-BX2400-E
GV-BX3400-E
GV-BX5300-E 5 MP
GV-BX2510-E
GV-BX5310-E
Varifocal
2 MP / 3 MP, WDR Pro
2 MP Super Low Lux,
P-Iris
5 MP, P-Iris
xi
Camera Model No. Lens Description
GV-MDR220
Fixed 2 MP / 3 MP / 5 MP
1.3 MP Super Low Lux / 3 MP
WDR Pro
Fixed
1.3 MP Super Low Lux / 3 MP
WDR Pro / 5 MP
1.3 MP Super Low Lux / 2 MP
WDR Pro / 2 MP Super Low
Fixed
Lux / 3 MP WDR Pro / 5 MP
1.3 MP Super Low Lux / 2 MP
WDR Pro / 2 MP Super Low
Lux / 3 MP WDR Pro / 5 MP
Mini
Fixed
Rugged
Dome
Mini
Fixed
Dome
GV-MDR320
GV-MDR520
GV-MDR1500-1F
GV-MDR3400-1F
GV-MDR5300-1F
GV-MDR1500-2F
GV-MDR3400-2F
GV-MDR5300-2F
GV-MFD1501-0F
GV-MFD2401-0F
GV-MFD2501-0F
GV-MFD3401-0F
GV-MFD5301-0F
GV-MFD1501-1F
GV-MFD2501-1F
xii
Camera Model No. Lens Description
Mini
Fixed
Dome
Target
Mini
Fixed
Dome
GV-MFD1501-2F
GV-MFD2401-2F
GV-MFD2501-2F
GV-MFD3401-2F
GV-MFD5301-2F
GV-MFD1501-3F
GV-MFD2401-3F
GV-MFD2501-3F
GV-MFD3401-3F
GV-MFD5301-3F
GV-MFD1501-4F
GV-MFD2401-4F
GV-MFD1501-5F
GV-MFD2401-5F
GV-MFD2501-5F
GV-MFD3401-5F
GV-MFD5301-5F
GV-MFD2501-6F
GV-MFD3401-6F
GV-EFD1100-0F
GV-EFD2100-0F
GV-EFD1100-2F
GV-EFD2100-2F
Fixed
Fixed
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro / 5
MP
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro / 5
MP
1.3 MP Super Low Lux / 2
MP WDR Pro
1.3 MP Super Low Lux / 2
MP WDR Pro / 5 MP Super
Low Lux
2 MP Super Low Lux / 3 MP
WDR Pro
1.3 MP / 2 MP, Low Lux
1.3 MP / 2 MP, Low Lux
xiii
Camera Model No. Lens Description
Target
Mini
Fixed
Rugged
Dome
Bullet
Camera
GV-EDR1100-0F
GV-EDR2100-0F
GV-EDR1100-2F
GV-EDR2100-2F
GV-BL1500
GV-BL2400
GV-BL2500
GV-BL3400
GV-BL3700
GV-BL5700
GV-BL1210
GV-BL2410
GV-BL3410
GV-BL5310
GV-BL1501
GV-BL2501
GV-BL3401
GV-BL1511
GV-BL2511
GV-BL3411
GV-BL5311
Fixed
Varifocal
Motorized
Varifocal
Motorized
Varifocal
Varifocal
Motorized
varifocal
1.3 MP Low Lux / 2 MP
Low Lux
1.3 MP Low Lux / 2 MP
Low Lux
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro
3 MP, H.265, Super Low
Lux, WDR Pro
5 MP, H.265, Low Lux,
WDR
1.3 MP Low Lux / 2 MP
WDR Pr o / 3 MP WDR P ro,
3X Optical Zoom
5 MP, 2X Optical Zoom
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro, P-Iris
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro, P-Iris, 3X
Optical Zoom
5 MP, 2X Optical Zoom,
P-Iris
xiv
IR Arctic
Bullet
Camera
GV-BL2511-E
GV-BL5311-E
Varifocal
Motorized
2 MP Super Low Lux, 3X
Optical Zoom, P-Iris
5 MP, 2X Optical Zoom,
P-Iris
xv
Camera Model No. Lens Description
Target
Bullet
Camera
GV-EBL1100-1F
GV-EBL2100-1F
GV-EBL1100-2F
GV-EBL2100-2F
GV-EBL2101 Varifocal
Fixed
1.3 MP / 2 MP, Low Lux
1.3 MP Low Lux
2 MP, Super Low Lux,
P-Iris
Ultra
Bullet
Camera
GV-UBL1211
GV-UBL1511
GV-UBL2411
GV-UBL2511
GV-UBL3411
GV-UBL1301-0F
GV-UBL1301-1F
GV-UBL1301-2F
GV-UBL1301-3F
GV-UBL2401-0F
GV-UBL2401-1F
GV-UBL2401-2F
GV-UBL2401-3F
Motorized
Varifocal
Fixed
1.3 MP Low Lux / 1.3 MP
Super Low Lux / 2 MP
WDR Pro / 2 MP Super
Low Lux / 3 MP WDR Pro,
Auto Iris, 3X Optica l Zo om
1.3 MP
2 MP, WDR Pro
xvi
Camera Model No. Lens Description
Ultra
Bullet
Camera
GV-UBL3401-0F 3 MP, WDR Pro
GV-UBL3401-1F
GV-UBL3401-2F
GV-UBL3401-3F
Fixed
3 MP, WDR Pro
Fixed IP
Dome
GV-FD1200
GV-FD2400
GV-FD1500
GV-FD2500
GV-FD3400
GV-FD1210
GV-FD2410
Varifocal
Motorized
Varifocal
1.3 MP Low Lux / 2 MP
WDR Pro
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro
1.3 MP Low Lux / 2 MP
WDR Pro, 3x Optical
Zoom
xvii
Camera Model No. Lens Description
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro, 3x Optical
Zoom
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro, P-I ris
1.3 MP Super Low Lux / 2
MP Super Low Lux / 3 MP
WDR Pro, 3x Optical
Zoom, P-Iris
2MP Super Low Lux,
WDR, P-iris
3MP Super Low Lux,
WDR Pro, P-Iris
5MP Low Lux, WDR,
P-Iris
1.3 MP / 2 MP
1.3 MP / 2 MP, Wireless
Fixed IP
Dome
Fixed IP
Dome
Target
Fixed IP
Dome
Advanced
Cube
Camera
GV-FD1510
GV-FD2510
GV-FD3410
GV-FD1500
GV-FD2500
GV-FD3400
GV-FD1510
GV-FD2510
GV-FD3410
GV-EFD2101
GV-EFD3101
GV-EFD5101
GV-CA120
GV-CA220
GV-CAW120
GV-CAW220
Motorized
Varifocal
Varifocal
Motorized
Varifocal
Varifocal
Fixed
Cube
Camera
PT
Camera
xviii
GV-CB120
GV-CB220
GV-PT130D
GV-PT220D
GV-PT320D
Fixed 1. 3 MP / 2 MP
Fixed 1. 3 MP / 2 MP / 3 MP
Camera Model No. Lens Description
GV-VD120D
(IK10+, Transparent Cover)
GV-VD121D
(IK10+, Smoked Cover)
GV-VD122D
(IK7, Trans parent Cover)
1.3 MP, Low Lux
GV-VD123D
(IK7, Smoked Cover)
GV-VD220D
(IK10+, Transparent Cover)
GV-VD221D
(IK10+, Smoked Cover)
GV-VD222D
(IK7, Trans parent Cover)
2 MP
GV-VD223D
Vandal
Proof IP
Dome
(IK7, Smoked Cover)
GV-VD320D
(IK10+, Transparent Cover)
Varifocal
GV-VD321D
(IK10+, Smoked Cover)
GV-VD322D
(IK7, Trans parent Cover)
3 MP
GV-VD323D
(IK7, Smoked Cover)
GV-VD1500
(IK10+, Transparent Cover)
GV-VD2400
(IK10+, Transparent Cover)
GV-VD2500
(IK10+, Transparent Cover)
1.3 MP Super Low
Lux / 2 MP WDR
Pro / 2 MP Super
Low Lux / 3 MP
WDR Pro
GV-VD3400
(IK10+, Transparent Cover)
xix
Camera Model No. Lens Description
3 MP H.265, WDR Pro,
Super Low Lux
5 MP H.265, WDR, Low
Lux
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP
Super Low Lux / 3 MP
WDR Pro
1.3 MP Super Low Lux / 2
MP WDR Pro / 2 MP
Super Low Lux / 3 MP
WDR Pro, 3X Optical
Zoom
5 MP, 3X Optical Zoom
Vandal
Proof IP
Dome
GV-VD3700
GV-VD5700
GV-VD1530
GV-VD2430
GV-VD2530
GV-VD3430
GV-VD1540
GV-VD2440
GV-VD2540
GV-VD3440
GV-VD5340
Varifocal
lens
High Power IR
LEDs,
Varifocal
High Power IR
LEDs,
Motorized
Varifocal
GV-VD2540-E
GV-VD5340-E
Target
Vandal
Proof IP
Dome
Pinhole
Camera
For detailed manuals, see GV-IPCAM Firmware Manual and GV-IPCAM
Hardware Manual on the Software DVD.
xx
GV-EVD2100
GV-EVD3100
GV-EVD5100
GV-UNP2500 Fixed 2 MP Super Low Lux
High Power IR
LEDs,
Motorized
Varifocal
Lens, Extreme
Temperature
Tolerance
Varifocal
2 MP Super Low Lux, 3X
Optical Zoom
5 MP, 3X Optical Zoom
2MP Super Low Lux,
WDR, P-Iris
3MP Super Low Lux,
WDR Pro, P-I ris
5MP Low Lux, WDR,
P-Iris
Options
Optional devices can expand your camera’s capabilities and versatility.
Contact your dealer for more information.
Accessory Description
The power adapter is available for all GV-IP Camera
(except for IR Arctic Cameras, Mini Fixed Rugged
Power Adapter
GV-PA191 PoE
Adapter
GV-PA481 PoE
Adapter
GV-PA482 PoE
Adapter
GV-POE Switch
GV-Mount
Accessories
Dome and GV-BL2510-E / 5310-E). Contact your
sales representative for the countries and areas
supported.
The GV-PA191 PoE adapter is designed to provide
power and network connection to the cameras over a
single Ethernet cable.
The GV-PA481 PoE adapter is designed to provide
power and network connection to GV-BX1200-E /
2400-E / 3400-E / 5300-E over a single Ethernet
cable.
The GV-PA482 PoE adapter is designed to provide
power and network connection to GV-BX2510-E /
5310-E over a single Ethernet cable.
The GV-POE Switch is designed to provide power
along with network connection for IP devices. The
GV-POE Switch is available in various models with
different numbers and types of ports.
The GV-Mount Accessories provide a
comprehensive lineup of accessories for installation
on ceiling, wall corner and pole. For details, see
GV-Mount Accessories Installation Guide on the
Software DVD.
xxi
Accessory Description
The GV-WiFi Adapter is a plug-and-play device
designed to connect GV-BX1200 Series / 1500
series / 2400 series / 2500 series / 3400 series /
GV-WiFi Adapter
GV-Relay V2
Smoked Cover
Plastic PG21
Conduit
Connector
Metal PG21
Conduit
Connector
5300 series and GV-MFD1501 series / 2401 series /
2501 series / 3401 series / 5301 series to wireless
network. This product complies with IEEE 802.11
b/g/n (Draft 3.0) standards for wireless networking.
The GV-Relay V2 is designed to expand the voltage
load of GV IP devices. It provides 4 relay outputs,
and each can be set as normally open (NO) or
normally closed (NC) independently as per your
requirement.
GV-Relay V2 does not support GV-EVD2100 / 3100 /
5100.
The smoked cover is an IK7, tinted camera cover
designed for GV-Fixed IP Dome to conceal the
direction of the camera lens.
The plastic PG21 conduit connector is used for
running the wires of Target Mini Fixed Rugged Dome
through a 1/2” conduit pipe.
The metal PG21 conduit connector is used for
running the wires of GV-VD1530 / 2430 / 2530 /
3430, GV-VD1540 / 2440 / 2540 / 3440 / 5340 and
GV-VD2540-E / 5340-E and GV-EVD2100 / 3100 /
5100 through a 3/4” conduit pipe.
xxii
Note for Connecting to GV-System / GV-VMS
The GV-IPCAM H.264 is designed to work with GV-System / GV-VMS, a
hybrid or digital video management system. Note the following when
GV-IPCAM H.264 is connected to GV-System / GV-VMS:
1. By default, the images are recorded to the memory card inserted to the
GV-IP Camera H.264 (except GV-IR Arctic Camera and Target Series,
which are not equipped with a memory card slot).
2. Once the camera is connected to GV-System / GV-VMS, the
resolution set on GV-System / GV-VMS will override the resolution set
on the camera’s Web interface. You can only change the resolution
settings through the Web interface when the connection to GV-System
/ GV-VMS is interrupted.
xxiii
Note for Recording
1. By default, the images are recorded to the memory card inserted to the
GV-IP Camera (except GV-IR Arctic Camera and Target Series, which
are not equipped with a memory card slot). Make sure the Write
recording data into local storage option is enabled. If this option is
disabled, the camera will stop recording to the memory card while the
live view is accessed through Web browsers or other applications. For
details, see Video Settings, Administrator Chapter, GV-IPCAM
Firmware Manual on the Software DVD).
2. Mind the following when using a memory card for recording:
• Recorded data on the memory card can be damaged or lost if the
data are accessed while the camera is under physical shock,
power interruption, memory card detachment or when the memory
card reaches the end of its lifespan. No guarantee is provided for
such causes.
• The stored data can be lost if the memory card is not accessed for
a long period of time. Back up your data periodically if you seldom
access the memory card.
• Memory cards are expendable and their durability varies according
to the conditions of the installed site and how they are used. Back
up your data regularly and replace the memory card annually.
• Replace the memory card when its read/write speed is lower than
6 MB/s or when the memory card is frequently undetected by the
camera.
3. It is recommended to use memory cards of the following setting and
specifications:
• Apply a battery backup (UPS) to avoid power outage.
• Use Micro SD card of MLC NAND flash, Class 10 for better
performance.
xxiv
Note for Adjusting Focus and Zoom
When adjusting the Focus and Zoom Screws (on Box Camera, IR Arctic
Box Camera, Mini Fixed Dome, Bullet Camera, Vandal Proof IP Dome and
Fixed IP Camera), please do not over tighten the Focus and Zoom screws.
The screws only need to be as tight as your finger can do it; don't bother
using any tools to get them tighter. Doing so can damage the structure of
lens.
For example,
Zoom Screw
Focus Screw
Bullet Camera Fixed IP Camera
The maximum torque value for all the zoom and focus screws is 0.049 N.m
Focus Screw
Zoom Screw
xxv
Note for Installing Camera Outdoor
When installing the IR Arctic Box Camera, Bullet Camera, Ultra Bullet
Camera, Target Bullet Camera, Vandal Proof IP Dome, Mini Fixed
Rugged Dome or Target Mini Fixed Rugged Dome outdoor, be sure that:
1. The camera is set up above the junction box to prevent water from
entering the camera along the cables.
2. Any PoE, power, audio and I/O cables are waterproofed using
waterproof silicon rubber or the like.
xxvi
3. After opening the camera cover, ensure the screws are tightened and
the cover is in place.
4. Make sure the housing cover is properly secured to prevent water from
entering and damaging the inner housing.
xxvii
Note for Closing the Bullet Camera Cover
To ensure that the camera performs its full capacity against water and dust,
tightly close and lock the camera cover as indicated below.
xxviii
Note for Bullet Waterproof Failures
To avoid waterproofing failures, do not open the screw on the camera body.
y The sc rew on Ultra Bull et
Camera
y The sc rew on Target Bullet
Camera
y The sc rew on GV-EBL2101 y The sc rew on GV-BL3700 /
5700
xxix
Note for USB Storage and WiFi Adapter
Mind the following limitations and requirements for using USB storage and
GV-WiFi Adapter:
1. The USB hard drive must be of 2.5’’ or 3.5’’, version 2.0 or above.
2. The USB hard drive’s storage capacity must not exceed 2TB.
3. USB flash drives and USB hubs are not supported.
4. External power supply is required for the USB hard drive.
5. To connect a GV-WiFi Adapter, make sure it is connected before the
camera is powered on.
Note for Silica Gel Bags
1. The silica gel bag loses it effectiveness when the dry camera is
opened. To prevent the lens from fogging up, replace the silica gel bag
every time you open the camera, and conceal the gel bag in camera
within 2 minutes of exposing to open air.
2. When the camera is shipped, a silica gel bag will be included inside
the camera. For the first-time user, replace the silica gel bag prior to
the installation to avoid foggy live view.
xxx
1. Box Camera
1.1 Packing List
• Box Camera
• Terminal Block
• Fixed Focal or Varifocal Megapixel Lens
• Six Lens Rings
• Video Out Wire
• Camera Holder
• Power Adapter
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: The power adapter can be excluded upon request.
1
Box Camera
1
1.2 Overview
GV-BX1200 Series / 1500 Series / 2400 Se ries / 2500 Series / 2600 / 3400 Series / 5300 Series / 12201
5
1 2 4
6 7
8 9
GV-BX1200 Series / 1500 Series /
2400 Series / 2500 Series / 2600 /
3400 Series / 5300 Series
2
10311
GV-BX12201
1
Box Camera
Note:
1. The Auto Iris Connector (No. 8) is only functional for varifocal models
of GV-BX1200 / 1500 / 2400 / 2500 / 2600 / 3400.
2. The Iris Screw (No. 12) is only available for GV-BX5300-6V.
3. The Zoom Screw (No. 13) is only available for varifocal models of
GV-BX1200 / 1500 / 2400 / 2500 / 2600 / 3400 / 5300 / 12201
4. Built-in microphone is not available for GV-BX2600.
5. The Memory Card Slot (No. 2) is currently not supported for
GV-BX12201.
6. Mini USB Slot (No. 3) connected to USB hard drive is currently not
supported for GV-BX12201.
No. Name Description
Connects to a portable monitor for setting the
1 Video Out
Memory Card
2
Slot
3 Mini USB Slot
4 Audio Out Connects a speaker for audio output.
5 Audio In Connects a microphone for audio input.
I/O Terminal
6
Block
7 Power LED
Auto Iris
8
Connector
focus and angle of Box Camera during initial
installation.
Receives a micro SD card (SD/SDHC, version
2.0 only, Class 10) to store recording data.
Connects to a GV-WiFi Adapter or a USB hard
drive.
Connects I/O devices. For details, see I/O
Terminal Block, Box Camera Chapter,
GV-IPCAM Hardware Manual on the Software
DVD.
Indicates the power is supplied. For detail, see
the table below.
Plug the iris control cable to the connector.
3
No. Name Description
9 DC 12V Port Connects to power.
10 LAN / PoE Connects to a 10/100 Ethernet or PoE.
Resets the camera to default settings. See 27.
11 Default
12 Iris Screw Adjusts the iris of the camera.
13 Zoom Screw Adjusts the zoom of the camera.
14 Microphone Records the sounds.
15 Focus Screw A d j u sts the focus of the camera.
16 Status LED
LED Description
Power LED turns green The system powers on and succeeds to boot up.
Status LED turns green The system is ready for use.
Restoring to Default Settings later in the Quick
Start Guide.
Turns on when the unit is ready for use. For
detail, see the table below.
4
1
Box Camera
1.3 Accessory Installation
1.3.1 C-Mount Lenses
When you use a C-mount lens, it requires a certain distance from the
camera’s imaging chip to focus the lens. Mount the supplied C-mount lens
adapter / lens ring to the camera, and then attach the lens onto the camera
body.
Box Camera
Three types of lens rings are provided for Box Camera:
• 0.188 mm (transparent color) x 2
• 0.254 mm (black color with a matt surface) x 2
Note: These lens rings are specially designed for varifocal models of
Box Camera. Besides the supplied lens rings, each varifocal model has
already been installed with the necessary lens ring.
5
1.3.2 Infrared Illuminators (Optional)
1. Connect the infrared illuminator to the terminal block on the camera.
See I/O Terminal Block, Box Camera Chapter, GV-IPCAM Hardware
Manual on the Software DVD.
2. Access the Web interface of the camera.
3. Select Video and Motion, select Video Settings, select Streaming 1
and set the IR Check Function setting to Trigger by Input.
4. Click Apply.
For details on the Trigger by Input function, see the Video Settings section,
Administrator Mode Chapter in the GV-IPCAM Firmware Manual in the
Software DVD.
6
1
Box Camera
1.4 Connecting the Camera
The Box Camera is designed for indoor use. Please make sure the
installing site is shielded from rain and moisture.
GV-BX1200 Series / 1500 Series / 2400 Series / 2500 Series / 2600 / 3400 Series / 5300 Series/ 12201
1. If you are using an auto iris model, plug the iris control cable to the
Auto Iris Connector on the camera.
2. Connect to network using one of the following methods:
• Wired Connection: Use a standard network cable to connect the
camera to your network and optionally connect a USB hard drive to
the mini USB port.
7
• Wireless Connection: Optionally purchase and connect the
GV-WiFi Adapter.
3. Optionally connect a speaker and an external microphone.
4. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting your signal format at the TV Out fiel d on the Web
interface. See TV Out setting, in the Video Settings section,
Administrator Mode Chapter, GV-IPCAM Firmware Manual on the
Software DVD.
5. Optionally connect to input / output devices or an infrared illuminator.
For details, see Infrared Illuminator and I/O Terminal Block, Box
Camera Chapter, GV-IPCAM Firmware Manual on the Software DVD.
6. Connect power using one of the following methods:
• Plug the power adapter to the power port.
• Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
7. The status LED of the camera will be on.
8. You are ready to access the live view and adjust the image clarity. See
24. Accessing the Camera in the Quick Start Guide.
Note: For details on limitations and requirements of the mini USB port,
refer to Note for USB Storage and WiFi Adapter at the beginning of this
quick guide.
8
2. Ultra Box Camera
2.1 Packing List
• Ultra Box Camera
• Supporting rack
• Screw x 3
• Screw anchor x 3
• Power Adapter
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: The power adapter can be excluded upon request.
Ultra Box Camera
2
9
2.2 Overview
4
1
5
2
6
3
No. Name Description
1 Audio Out Connects a speaker for audio output.
Resets the camera to default settings. See 27
2 Default
3 LAN / PoE Connects to a 10/100 Ethernet or PoE.
4 Microphone Records sounds.
Memory Card
5
Slot
DC 5V Terminal
6
Block
Restoring to Default Settings in the Quick Start
Guide.
Receives a micro SD card (SD/SDHC, version
2.0 only, Class 10) to store recording data.
Connects to power.
LED Indicator Description
Status LED
Power LED
The status LED turns on (green) when the
system is ready for use.
The power LED turns on (green) when power
is supplied to the camera.
10
Ultra Box Camera
2
2.3 Installation
You can stand the Ultra Box Camera on a plain surface or install it to wall
and ceiling. Follow the steps below to install, connect and adjust your Ultra
Box Camera.
1. To install the device on the wall/ceiling, put the supporting rack on the
desired location and make marks for screw anchors.
2. Drill the marks and insert the screw anchors.
3. Secure the supporting rack onto the wall/ceiling using the supplied
screws.
4. Secure the camera onto the supporting rack and fasten the indicated
screw.
11
5. Connect the network and power cables to the camera. See 2.4
Connecting the Camera in the Quick Start Guide.
6. Access the live view. See 24.2 Accessing the Live View in the Quick
Start Guide.
7. Adjust the angle of the camera based on live view and fasten the
indicated screw.
12
2.4 Connecting the Camera
Ultra Box Camera
2
3
1
2
1. Connect power using one of the following methods:
• Plug the power adapter to the 5V terminal block.
• Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
The power and status LEDs shall turn on (green).
2. Use a standard network cable to connect the camera to your network.
3. Optionally connect a speaker.
4. Insert a micro SD card (SD/SDHC, version 2.0 only, Class 10).
5. You are ready to access the live view, adjust the image clarity and
configure the basics. See 24. Accessing the Camera in the Quick Start
Guide.
13
3. Target Box Camera
3.1 Packing List
• Target Box Camera
• Supporting Rack
• Screw x 3
• Screw Anchor x 3
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: Power adapter can be purchased upon request.
14
3.2 Overview
1
2
Target Box Camera
3
3
4
No. Name Description
Resets the camera to default settings. See 27.
1 Default
2 LAN / PoE Connects to a 10/100 Ethernet or PoE.
3 Microphone Records sounds.
DC 12V
4
Terminal Block
Restoring to Default Settings in the Quick Start
Guide.
Connects to power.
LED Indicator Description
Status LED
Power LED
The status LED turns on (green) when the
system is ready for use.
The power LED turns on (green) when power
is supplied to the camera.
15
3.3 Installation
You can stand the Target Box Camera on a plain surface or install it to wall
and ceiling. Follow the steps below to install, connect and adjust your
Target Box Camera.
1. To install the device on the wall/ceiling, put the supporting rack on the
desired location and make marks for screw anchors.
2. Drill the marks and insert the screw anchors.
3. Secure the supporting rack onto the wall/ceiling using the supplied
screws.
4. Secure the camera onto the supporting rack and fasten the indicated
screw.
16
Target Box Camera
3
5. Connect the network and power cables to the camera. See 3.4
Connecting the Camera in the Quick Start Guide.
6. Access the live view. See 24.2 Accessing the Live View in the Quick
Start Guide.
7. Adjust the angle of the camera based on live view and fasten the
indicated screw.
17
3.4 Connecting the Camera
1. Connect power using one of the following methods:
• Plug the power adapter to the 12V terminal block. The power
adapter is an optional device. For detail, see Options in the
GV-IPCAM Hardware Manual for Target Box Camera on the
Software DVD.
• Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable. The power and status LEDs shall
turn on (green).
2. Use a standard network cable to connect the camera to your network.
3. You are ready to access the live view, adjust the image clarity and
configure the basics. See 24. Accessing the Camera in the Quick Start
Guide.
18
4. IR Arctic Box Camera
4.1 Packing List
For GV-BX1500-E / 2400-E / 3400-E / 5300-E
• IR Arctic Box Camera
• Screw Anchor x 4
• Screw x 4
• Washer x 4
• 4 mm Torx Wrench
• 5 mm Torx Wrench
• Silica Gel Bag x 2
• Adhesive Tape x 2
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: Optionally purchase a GV-PA481 PoE Adapter for GV-BX1500-E
/ 2400-E / 3400-E / 5300-E.
4
IR Arctic Box Camera
19
For GV-BX2510-E / 5310-E
• IR Arctic Box Camera
• Screw Anchor x 4
• Screw x 4
• Washer x 4
• 5 mm Torx Wrench
• Silica Gel Bag
• Adhesive Tape
• Power Adapter (DC 48V, 2.5A, 120 W max.)
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: Optionally purchase a GV-PA482 PoE Adapter for GV-BX2510-E
/ 5310-E.
20
4.2 Overview
For GV-BX1500-E / 2400-E / 3400-E / 5300-E
4
IR Arctic Box Camera
1 2
4
3
5
Note: The Iris Screw (no. 7) is only available in GV-BX5300-E.
No. Name Description
1 Silica gel bag Desiccant that keeps the camera housing dry.
2 IR power plug Supplies power to the built-in IR LEDs.
3 Focus Screw Adjusts the focus of the camera.
4 Module screw Holds the module in place.
5 Status LED Turns on when the camera is ready for use.
6 Zoom Screw Adjusts the z oom of the camera.
7 Iris Screw Adjusts the iris of the camera.
7 6
21
For GV-BX2510-E / 5310-E
1
No. Name Description
1. Silica gel bag Desiccant that keeps the camera housing dry.
Memory Card
2.
Slot
3. Power LED
4. Status LED Turns on when the camera is ready for use.
5. Default
Inserts a micro SD ca rd (SD/SDHC, version
2.0, Class 10) to store recording data.
Turns on when the camera is supplied with
power.
Resets the camera to default settings. See 27.
Restoring to Default Settings later in the Quick
Start Guide.
2
3
4
5
22
4
IR Arctic Box Camera
4.3 Installation
The IR Arctic Box Camera is designed for outdoor use. Follow the steps
below to install your camera.
1. Mark the installation site and drill four holes for screw anchors.
2. Insert the supplied screw anchors.
3. Secure the camera to the wall using the supplied washers and screws.
4. Connect the camera with wires and cables. See 4.4 Connecting the
Camera in the Quick Start Guide.
5. Access the live view. See 24.2 Accessing the Live View in the Quick
Start Guide.
23
6. Based on the live view, adjust the angle of the camera. Loosen the
indicated screw with the supplied big torx wrench and adjust the joint.
Tilt Adjustme nt
Pan Adjustment
24
4
IR Arctic Box Camera
7. For GV-BX1500-E / 2400-E / 3400-E / 5300-E, adjust for image clarity
based on the live view.
A. Unscrew the cover with the supplied 4 mm torx wrench.
B. Hold and unpl ug the connector.
IMPORTANT: Unscrew and remove the cover carefully. Pulling the cover off
may cause damages to the inner wiring of the camera.
25
C. Adjust the focus, zoom and iris screws. For a more precise focus,
use GV-IP Device Utility. For details, see 24.3 Adjusting Image
Clarity in the Quick Start Guide.
Note: Only GV-BX5300-E contains an iris screw.
D. Replace the silica gel bag. Paste the sticker to the front side of
the silica gel bag. Press the sticker several times to make sure it
adheres properly and paste the silica gel bag to the indicated
place.
E. Foll ow st eps 7B and 7A to plug the connectors back and close
the camera cover.
26
4
IR Arctic Box Camera
8. For GV-BX2510-E / 5310-E, optionally insert a memory card.
A. Open the camera cover using the supplied torx wrench.
B. Insert a memory card to the card slot.
Memory card slot
C. Replace the silica gel bag. Paste the sticker to the silica gel bag.
Press the silica gel bag several times onto the camera cover to
make sure it adheres properly.
D. Follow step 8A to close the camera cover.
27
4.4 Connecting the Camera
For GV-BX1500-E / 2400-E / 3400-E / 5300-E
No. Wire Definition
1 RJ-45 PoE
2 Black BNC t TV ou
3 Green RCA Audio Out
4 Pink RCA Audio In
ow t ow to connect t
Foll he steps bel he camera:
1. Optionally connect a speaker (green) and a
(pink).
2. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting your signal format at the TV Out field on the W
interface. See Video Settings section, Administrator Mode Chapter,
GV-IPCAM Firmware Manual on the Software DVD.
n external microphone
eb
28
4
IR Arctic Box Camera
3. Connect the camera to a GV-PA481 PoE adapter as illustrated to
supply power and network access.
POWER &
Rear Panel
Power Hub/Router
DATA OUT
DATA IN
Ethernet Cable
PoE
GV-BX-E
4. The status LED of the camera will be on.
5. You are ready to access the live view.
Note: For using the IR Arctic Box Camera, ensure that you:
1. enable the IR LED function on the Web interface after loading the
default settings.
2. disable the status LED to reduce reflection when a green light
spot appears on the live view.
For details, see Notice for Using th e IR Arctic Box Camer a section, IR
Arctic Box Camera Chapter, GV-IPCAM Firmware Manual on the
Software DVD.
29
For GV-BX2510-E / 5310-E
No. Wire Definition
1. Green RCA Audio Out
2. Pink RCA Audio In
3. Brown wire Digital Output
4. Yellow wire Digital Input
5. White wire GND
6. Terminal Block DC 48V
7. BNC TV Out
8. RJ-45 Ethernet/PoE++
1. Optionally connect the audio out (green), audio in (pink), digital output
(brown), digital input (yellow), and GND.
2. Optionally connect a monitor using a Video Out wire. Enable this
function by selecting your signal format at the TV Out field on the Web
interface. See Video Settings section, Administrator Mode Chapter,
GV-IPCAM Firmware Manual on the Software DVD.
30
4
IR Arctic Box Camera
3. Supply the camera with power and network access using one of the
following methods:
• Use a GV-PA482 Power over Ethernet adapter to connect the
camera to power and network as illustrated below. GV-PA482 PoE
adapter is an optional accessory. For detail, see Options in the Quick
Start Guide.
Rear Panel
DC 48V Power Adaptor
Ethernet Cable
Hub/Router
Power
PoE
• Use the supplied power adapter. Connect the black wire of the power
adaptor to the plus (+) port and the white wire to the negative (-) port.
Connect the camera to network with a network cable.
Terminal Block from
the Camera Cable
4. You are ready to access the live view.
DC 12V Power Adaptor
31
5. Mini Fixed Dome & Mini Fixed Rugged Dome
5.1 Packing List
GV-MFD
• Mini Fixed Dome
• Torx Wrench
• Self Tapping Screw x 2
• Screw Anchor x 2
• Cable stopper
• 2-pin terminal block
• Short-Body RJ-45 Plug (for GV-MFD1501 series / 2401 series / 2501
series / 3401 series / 5301 series)
• USB / Audio Y-cable (for GV-MFD1501 series / 2401 series / 2501
series / 3401 series / 5301 series)
• Power Adapter
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: The power adapter can be excluded upon request.
32
Mini Fixed & Rugged Dome
5
GV-MDR
• Mini Fixed Rugged Dome
• Torx Wrench
• Self Tapping Screw x 2
• Screw Anchor x 2
• Cable stopper
• Cable Connector
• Installation sticker
• Silica gel bag x 2
• Adhesive Tape x 2
• Ferrite core for vehicle installation
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note:
1. The power adapter can be excluded upon request.
2. When purchasing GV-MDR1500 / 3400 / 5300, choose one of the two
LAN connector types (for motor vehicles or for general use). For
details, see LAN Connector, 5.2 Overview in the Quick Start Guide.
33
5.2 Overview
GV-MFD1501 Series / 2401 Series / 2501 Series / 3401 Series / 5301 Series
2
1
3
4
6
5
7
No. Name Description
1 Microphone Receives sound.
2 Pan Screw Loosens the screw to pan.
3 Lens Receives image inputs.
4 Tilt Screw Loosens the screw to adjust tilt angle.
5 Default Button
6 DC 5V Power Port Connects t o power.
7 LAN / PoE Connects to a 10/100 Ethernet or PoE.
8 Memory Card Slot
9 USB and Audio Out
Note: For details on limitations and requirements of the USB port, refer to
Note for USB Storage and WiFi Adapter at the beginning of the Quick
Guide.
Resets the camera to default settings. See
27. Restoring to Default Settings.
Inserts a micro SD ca rd (SD/SDHC,
version 2.0, Class 10) to store recording
data.
Connects to an external hard disk drive and
a speaker through the supplied Y cable.
8
9
34
Mini Fixed & Rugged Dome
5
1
2
3
4
LED Name Description
1. Link Turns on (green) when the network is connected.
2. ACT Turns on (orange) when data are being transmitted.
3. Status Turns on (red) when the system is ready.
4. Power Turns on (green) when power is on.
35
GV-MDR
1
2
3
4
5
8
10
9
11
No. Name Description
1 Silica gel bag Absorbs the moisture inside the camera.
2 Conceal paper
3 Lens Receives image inputs.
4 Rotation Disc Rotates the came ra lens.
5 Pan Disc Pans the camera lens.
6 Tilt Screw Loosens to tilt the camera.
7 Built-In Microphone Provides one-way audio.
8 Default Button
Prevents water or moisture from entering
the camera.
Resets the camera to default settings. See
27. Restoring to Default Settings later in
the Quick Start Guide.
6
7
36
Mini Fixed & Rugged Dome
5
No. Name Description
Power and status
9
LED
10 LAN LED Turns on when the network is connected.
11 Memory Card Slot
IMPORTANT: In case of damage and possible condensation inside the
camera housing, be sure not to touch or remove the conceal paper.
Turns red when the power is on. Flashes
orange light twice when the system is
ready.
Receives a micr o SD card (SD/SD HC,
version 2.0 only, Class 10) to store
recording data.
37
LAN Connector
Two types of LAN connector are available for GV-MDR1500 series / 3400
series / 5300 series. Select an option based on your installation
environment.
1.
Waterproof M12 4-Pin Female Connector
The M12 connector is used for motor vehicles.
Ø14.7 mm (0.58 ' ')
Small Waterproof Connector
2.
For this connector type, see GV-MDR, 5.3 Installation to install the
supplied cable connector.
38
Mini Fixed & Rugged Dome
5
5.3 Installation
To install a Mini Fixed Dome, make sure the installing site is shielded from
rain and moisture.
GV-MFD Series
1. Unscrew the housing cover using the supplied torx wrench.
2. Put the camera on the desired location and make 2 marks on the
ceiling for screw anchors. If you want to run the cables inside the
ceiling, make a round mark with a diameter of 2.5 cm.
3. Drill the marks and insert the screw anchors.
4. Secure the Mini Fixed Dome to the ceiling with the self-tapping screws.
5. Connect the camera to network and power. For details, see 5.4
Connecting the Camera in the Quick Start Guide.
6. Access the live view. See 24.2 Accessing the Live View in the Quick
Start Guide.
7. Adjust the angles based on the live view.
Pan Adjustment
39
Tilt Adjustment
8. Insert a memory card (SD/SDHC, version 2.0 only, Class 10) into the
memory card slot.
Memory Card Slot
9. Adjust image clarity using the GV-IP Device Utility program. For details,
see 24.3 Adjusting Image Clarity in the Quick Start Guide.
10. Secure the housing cover using the supplied torx wrench.
11. Optionally conceal the cable opening with the supplied cable stopper.
40
Cable stopper
Mini Fixed & Rugged Dome
5
GV-MDR Series
1. Paste the installation sticker on the desired location. The arrow should
point toward the direction that the camera faces.
2. Drill one hole on each of the two curves for screw anchors. Drill the
circle (30 mm in diameter) if you want to run the cable into the ceiling.
30 mm
Drill a hole
on each
3. Insert the screw anchors.
4. Unscrew the housing cover using the supplied torx wrench.
5. Secure the camera body to the ceiling with the self-tapping screws.
41
6. Install the cable connector to waterproof the cable. You should have 5
parts:
1 2 3 4
5
A. Prepare an Ethernet cable with the RJ-45 connector on one end
only.
B. Connect the Ethernet cable to the camera cable.
C. Paste the sticker to the camera cable and slide in all the
components as shown below.
D. Move all the components toward the RJ-45 connector, fit item 4 to
item 2, secure item 3 to the camera cable and finally secure item
5 to item 2 tightly.
42
Mini Fixed & Rugged Dome
5
IMPORTANT: Item 5 must be secured tightly to waterproof the
cable.
7. Access the live view. See 24.2 Accessing the Live View in the Quick
Start Guide.
8. Adjust the angles based on the live view.
Pan Adjustment
Tilt Adjustment
Rotational Adjustment
43
9. Adjust image clarity using the GV-IP Device Utility program. For details,
see 24.3 Adjusting Image Clarity in the Quick Start Guide.
10. Insert a memory card (SD/SDHC, version 2.0 only, Class 10) into the
memory card slot.
11. Repl ace the silica gel bag.
12. Secure the housing cover using the supplied torx wrench.
13. Optionally conceal the cable opening with the supplied cable stopper.
Cable stopper
44
Mini Fixed & Rugged Dome
5
5.4 Connecting the Camera
Refer to the wire definition and illustrations below to connect the power and
network.
5.4.1 Wire Definition
GV-MDR Series
Power and network connectivity is provided through a PoE cable.
Wire Color Definition
Gray PoE, Ethernet
5.4.2 Power and Network Connection
Use one of the following methods to power on and connect your camera to
network:
•
Wired connection with PoE: Use a Power over Ethernet (PoE)
adapter to connect the camera to the network, and the power will be
provided at the same time.
•
Wired connection with network cable (GV-MFD Series only):
Connect the camera with a standard network cable and use the power
adapter to supply power. See Powering On the Camera below to
assemble the terminal block with power adapter.
•
Wireless connection (GV-MFD1501 Series / 2401 Series / 2501
Series / 3401 Series / 5301 Series only):
GV-WiFi Adapter (optional accessory) and use the power adapter to
supply power.
Connect the camera with a
45
5.4.3 Vehicle Installation
To install the Mini Fixed Rugged Dome on a vehicle, clip the ferrite core to
the camera cable. The ferrite core must be attached as close as possible to
the camera with the maximum distance of 15 cm.
Max. 15 cm
Ferrite Core
46
6. Target Mini Fixed Dome
6.1 Packing List
• Target Mini Fixed Dome
• Screw x 2
• Screw Anchor x 2
• Focus Adjustment Clip or Ring
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: The power adapter can be purchased upon request.
Target Mini Fixed Dome
6
47
6.2 Overview
1
a b
3
4
5
2
6
7
No. Name Description
1 Lens Receives image inputs.
2 Pan Screw Loosens the screw to adjust pan angle.
3 Tilt Screw Loosens the screw to adjust tilt angle.
4 Microphone Receives sound.
5 Defaul t Button Resets the camera to default settings. See 27.
Restoring to Default Settings.
6 DC 12V Port Connects to power.
7 LAN / PoE Connects to a 10/100 Ethernet or PoE.
a St atus Turns on (green) when the s ystem is ready.
b Power Turns on (green) when power is on.
c Link Turns on (green) when the network is connected.
d ACT Turns on (orange) when data are being
transmitted.
c
d
48
Target Mini Fixed Dome
6
6.3 Installation
The Target Mini Fixed Dome can be installed on the wall or the ceiling.
Before installing the camera, make sure the installing site is shielded from
rain and moisture.
1. Open the housing cover by turning.
2. Place the camera where you want to install it and make 2 marks on the
ceiling or the wall for screw anchors. If you want to run the cables
inside the ceiling or the wall, make a round mark with a diameter of 2.5
cm.
3. Drill the marks and insert the screw anchors.
49
4. Thread the power and / or network cable(s) through the oval-shaped
hole or the cable opening on the side, and connect the camera to
network and power. For details, see 6.4 Connecting the Camera.
5. Secure the Target Mini Fixed Dome to the ceiling or the wall with the
self-tapping screws.
6. Access the live view. For details, see 24.2 Accessing the Live View in
the Quick Start Guide.
7. Loosen the tile screw and pan screw, adjust the angles based on the
live view as needed, and tighten the screws again.
Tilt Screw
Pan Screw
8. Adjust image clarity using the GV-IP Device Utility program. For details,
see 24.3 Adjusting Image Clarity in the Quick Start Guide.
9. Place the housing cover back and turn to secure it.
50
6.4 Connecting the Camera
Target Mini Fixed Dome
6
1
2
1. Connect power using one of the following methods:
• Plug the power adapter to the 12V terminal block. The power
adapter is an optional device. For detail, see Options in the
GV-IPCAM Hardware Manual for Target Mini Fixed Dome on the
Software DVD.
• Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
The power and status LEDs shall turn on (green).
2. Use a standard network cable to connect the camera to your network.
3. You are ready to access the live view, adjust the image clarity and
configure the basics. See 24. Accessing the Camera in the Quick Start
Guide.
51
7. Target Mini Fixed Rugged Dome
7.1 Packing List
• Target Mini Fixed Rugged Dome
• Screw x 2
• Screw Anchor x 2
• Focus Adjustment Ring
• Installation Sticker
• Conduit Converter
• RJ-45 Connector
• Waterproof Rubber Set (for RJ45 and DC12V)
• Torx Wrench
• Silica Gel Bag x 2
• Adhesive Tape x 2
• Concave Hexagon Wrench
• Ruler
• Screw for Conduit Converter x 2
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
52
Target Mini Fixed Rugged Dome
7
Note:
1. Power adapter can be purchased upon request.
2. You can choose to run the wires through a conduit pipe. After you
have threaded all the wires, install the supplied conduit converter
with a PG21 conduit connector and a self-prepared conduit pipe (of
1/2’’, 3/4’’ or 1’’) to the camera. Do not use a 1/2’’ pipe if you use the
power adapter for power supply because the adapter cannot be
threaded through. A plastic PG21 conduit connector for 1/2” pipe can
be purchased upon request.
Plastic PG21
conduit connector
Conduit pipe
Conduit converter
53
7.2 Overview
1
a b
2
3
4
5
6
No. Name Description
1 Lens Receives image inputs.
2 Pan Screw Loosens the screw to adjust pan angle.
3 Tilt Screw Loosens the screw to adjust tilt angle.
4 Default Button
5 DC 12V Port Connects to power.
6 LAN / PoE Connects to a 10/100 Ethernet or PoE.
a Status Turns on (green) when the system is ready.
b Power Turns on (green) when power is on.
c Link
d ACT
Resets the camera to default settings. See 27.
Restoring to Default Settings.
Turns on (green) when the network is
connected.
Turns on (orange) when data are being
transmitted.
c
d
54
Target Mini Fixed Rugged Dome
7
7.3 Installation
The Target Mini Fixed Rugged Dome can be installed on the wall or ceiling.
You must use the supplied waterproof rubber set to waterproof the cable.
1. Paste the installation sticker where you want to install, and drill two
holes that are at a diagonal. To run the cables inside the wall or ceiling,
drill a larger opening as shown below.
2. Insert the supplied screw anchors into the two drilled holes.
3. Open the camera’s housing cover using the supplied torx wrench.
55
4. Unscrew the three screws as indicated below. A back plate can be
separated from the bottom.
5. Use the 2 supplied screws to secure the back plate onto the ceiling or
the wall where the screw anchors were inserted.
6. Prepare an Ethernet cable with the RJ-45 connector on one end only.
7. Remove the waterproof cap from the cable opening and thread the
power and / or network cable(s) through the opening.
56
Target Mini Fixed Rugged Dome
7
8. Install the supplied waterproof rubber set onto the cable(s). The rubber
set has two parts. Item 1 comes in two types.
21
For power cable
For network cable
For network cable (PoE)
A. Slide the waterproof rubber set, and the waterproof c ap you
previously removed through the cable(s) as shown below.
21
B. Connect the supplied RJ-45 connector to the Ethernet cable.
C. If you are using a power adapter, insert the striped wire to the left
pin (+) and the other wire to the right pin (-).
57
D. Fit item 1 to item 2, and insert them in the cable opening. Use the
supplied ruler to make sure the length of the cable(s) from the
bottom of the opening to the end of the cable is under 10 cm.
E. Cap the cable opening with the waterproof cap. Use the supplied
concave hexagon wrench to tighten.
58
Target Mini Fixed Rugged Dome
7
9. Thread the cable(s) under the black cable holder. You can loosen the
screw on the cable holder if needed.
10. Connect the camera to network and power. For details, see 7.4
Connecting the Camera.
11. Secure the camera to the back plate by tightening the three screws as
shown in Step 4.
12. Access the live view. For details, see 24.2 Accessing the Live View.
13. Adjust image clarity using the GV-IP Device Utility program. For details,
see 24.3 Adjusting Image Clarity.
14. Loosen the tile screw and pan screw, adjust the angles based on the
live view as needed, and tighten the screws again.
59
15. Attach the silica gel bag to the place indicated below, and secure the
housing cover using the torx wrench.
60
7.4 Connecting the Camera
Target Mini Fixed Rugged Dome
7
1
1. Connect power using one of the following methods:
2
• Plug the power adapter to the 12V terminal block. The power
adapter is an optional device. For detail, see Options, GV-IPCAM
Hardware Manual for Target Mini Fixed Rugged Dome on the
Software DVD.
• Use the Power over Ethernet (PoE) function and the power will be
provided over the network cable.
The power and status LEDs shall turn on (green).
2. Use a standard network cable to connect the camera to your network.
3. You are ready to access the live view, adjust the image clarity and
configure the basics. See 24. Accessing the Camera in the Quick Start
Guide.
61
8. Bullet Camera (Part I)
8.1 Packing List
• Bullet Camera
• Self Tapping Screw x 3
• Plastic Screw Anchor x 3
• Torx Wrench x 2
• Sun-Shield Cover Kit (Sun-Shield Cover, Philips Head Screws x 2,
Plastic Screw Spacer x 2 and Hexagon Screw x 2)
• Silica Gel Bag x 2
• 2-Pin Terminal Block
• Power Adapter
• GV-IPCAM Software DVD
• GV-NVR Software DVD
• Warranty Card
Note: The power adapter can be excluded upon request.
62
Bullet Camera (Part I)
8
8.2 Overview
No. Name Description
1 Memory Card Slot
2 Zoom Screw Ho lds t he zoom lens in place.
3 Focus Screw Holds the focus lens in place
4 Default Button
Receives a micr o SD card (SD/SD HC,
version 2.0 only, Class 10).
Resets the camera to default settings. See
27. Restoring to Default Settings later in the
Quick Start Guide.
63
8.3 Installation
The Bullet Camera is designed for outdoor use and can be mounted on
ceiling and wall.
1. Slide the cable clamp to the camera base.
Cable Clamp
2. Install the Bullet Camera to the wall / ceiling.
3. Remove the protection sticker from the camera’s cover.
4. Connect the power, network and other cables to the camera. See 8.4
Connecting the Camera in the Quick Start Guide.
5. Access the live view. See 24.2 Accessing the Live View in the Quick
Start Guide.
6. Adjust the angles of the camera body based on the live view. Three
shafts can be adjusted. For details, see 8.3.1 Adjusting the Angles in
the Quick Start Guide.
64
Bullet Camera (Part I)
8
7. Loosen the camera’s cover, adjust the lens and focus, and insert a
micro SD card (SD/SDHC, version 2.0 only, Class 10) into the memory
card slot. Se e 8 .3.2 Adjusting Lens and Inserting a Memory Card in the
Quick Start Guide.
8. Fasten the camera’s cover.
9. Install the sun-shield cover to the Bullet Camera. For details, see 8.3.3
Installing the Sun-Shield Cover in the Quick Start Guide.
65
8.3.1 Adjusting the Angles
The Bullet Camera is designed to be adjustable in three shafts.
Tip: The three shafts are designed to offer easy and flexible ceiling / wall
mount installation.
First Shaft
You can adjust the camera body by 360 degrees to the right or the left.
1. Unscrew the panning lock screw with the torx wrench.
Panning Lock Screw
Torx Wrench
2. Adjust the angle of camera body to the right or the left, and fasten the
panning lock screw.
0 ~ 360°
66
Bullet Camera (Part I)
8
Second Shaft
You can adjust the camera body up and down by 90, 112.5, 135, 157.5 or
180 degrees by using the gears inside the camera body and the camera
base.
1. Unscrew the tilting lock screw with the torx wrench.
Tilting Lock Screw
Torx Wrench
2. Hold the camera body, and move the camera base to the right to
separate the camera gears.
Move the Camera
Base to the Right
Camera Body
Camera Gears
3. Adjust the angle of camera body to 90, 112.5, 135, 157.5 or 180
degrees. Then move the camera base to the left to combine the gears.
180
°
157.5°
135°
112.5°
90°
4. Fasten the tilting lock screw.
67
Third Shaf t
You can adjust the camera base by 360 degrees.
1. Unscrew the base fixing screw with the torx wrench.
Base Fixing Screw
2. Adjust the angle of camera base, and fasten the base fixing screw.
0~360°
Torx Wrench
68
