GV-AS1520 Controller With
Built-in UHF RFID Reader
Enjoy hassle-free parking management
Anti-Passback (APB) support
Ideal sensing range within 10 m (32.8ft)
Support for external sensors
Special energy-saving design reducing power consumption
Effective identification with specially designed antenna pattern
Time& Attendance
Built-in antenna and RF module
Vehicle counting and parking share space
Area Monitor & track suspicious activity
DC 12V/ PoE+ (IEEE 802.3at)
IOBOX
Integration
Application
AAB856
GV-AS1520, this High Precision UHF RFID Controller includes
exciting features from Proximity Reader for Vehicle Management.
It can work as a standalone device and detect the moving vehicle
up to 10 meters (32.8ft).
Each GV-AS1520 can store up to 100,000 cards, and seamlessly
integrate with GV-Access control platform (GV-ASManager) to
create complete security solution without hassle.
Geovision provides All-in-One parking management solution to
help minimizing cost, maximizing performance, and bettering
user experience.
Car Parks
Tag
GV-VMS
Video Management System
with intelligent video analytics
Condominiums Employee ParkingGated Communities
Trigger IP Camera to take snapshots
Sensing range up to 10m
Video-Integrated
GV-AS1520
GV-ASManager
Internet
LAN/WAN
FREE
Software
NO ANNUALFEE
How It Works?
Unlocked
GV-ASRemote
Remote monitoring
GV-ASWeb
Web Interface
GV-Access
Mobile Application
Professional Access Management Platform
Multilevel Administration Access
Web-interface access method
Time and Attendance Management
Visitor Management
Patrol Management
Manage multiple locations from one place
Supervisor
Visual Map interface
Real-time monitoring and
notification
Reporting / Tracking
IP Camera & VMS Integration
Installation Site
Long Range Reader (2 ~ 10 m)
TAG
Check angle: Recommended height to set RFID reader is 1.8m ~ 2.2m (5.9ft ~ 7.2ft), and no lower than location of RFID tag.
2m10m
15°~20°
1.8m ~ 2.2m
(5.9ft ~ 7.2ft)
TAG
Check orientation: Fully facing antenna, horizontally in parallel.
Product Spec
GV-AS1520
CPU
Number of User Cards
Antenna Gain
Antenna Receiving
Operating Frequency
Supported Transponders
Receiving sensitivity
Reading Range (Avg.)
Operating Voltage
Communication
Digital I/O
Temperature Range
Relative Humidity
Dimension ( L × W × H )
Ingress Protection
Input
Output
AS1520 TW 922-928MHz, AS1520 US 902-928MHz
12V DC, 1.25A / POE+ (IEEE 802.3at, provides up to 25.5 W)
4 relay output (30V DC, 1A; 110V AC~250V AC, 0.3A)
228 × 228 × 52.3 mm (8.97 × 8.97 × 2.04 in)
Horizontal
Vertical
! Away from metal body of vehicle.
Corresponded placement between RFID reader and tag is pictured as above.
ARM-based 32bit RISC
100,000 cards
7.71 dBi (circular polarization)
50 ohm U.FL.
AS1520 EU 865-868MHz
EPC Gen2 (ISO 18000-6C)
-85 dBm
10 m (32.8ft) max.
TCP/IP
2 inputs, dry contact, NO/NC
-20°C ~ 55°C (-7.6°F ~ 131°F)
10 ~ 90% RH (non - condensing)
IP56
TAG
TAG
Dimensions
228
228
201.1
52.3
