GE Industrial Solutions Lighting Control Panelboards BACnet Protocol User Manual

g
DEH41099 Rev. 1
A Series® Lighting Control Panelboards
A Series® Lighting Controller
BACnet Protocol Implementation Conformance Statement
Date May 13, 2004
Vendor Name GE Consumer & Industrial
Product Name GE A Series® Lighting Controller
Product Model Number 10092046P1/P2
Product Version 3.32 Firmware
BACnet Protocol Revision 3
The GE A Series Lighting Controller provides programmable capabilities for use in lighting applications. Hardware features may vary, but all products use the same BACnet firmware and communicate on a BACnet MS/TP network (some models also support Ethernet and BACnet/IP). All products support all BACnet capabilities indicated, unless otherwise noted.
Device Profile
Product Description Product Model
ROCB Lighting Controller (c/w Ethernet) 10092046P2 99 ROCB Lighting Controller 10092046P1 9
ASC AAC BC
Ethernet
& IP
BACnet Standardized Device Profile (Annex L)
BACnet Device Notes
BACnet Operator Workstation (B-OWS) BACnet Building Controller (B-BC) ; BACnet Advanced Application Controller (B-AAC) See product list above. BACnet Application Specific Controller (B-ASC) BACnet Smart Sensor (B-SS) BACnet Smart Actuator (B-SA)
A Series® Lighting Controller
BACnet Protocol Implementation Conformance Statement
BACnet Interoperability Building Blocks Supported (Annex K)
BACnet Interoperability Building Block Supported
Data Sharing
Data Sharing-ReadProperty-A (DS-RP-A) ; Data Sharing-ReadProperty-B (DS-RP-B) ; Data Sharing-ReadPropertyMultiple-A (DS-RPM-A) ; Data Sharing-ReadPropertyMultiple-B (DS-RPM-B) ; Data Sharing-ReadPropertyConditional-A (DS-RPC-A)  Data Sharing-ReadPropertyConditional-B (DS-RPC-B)  Data Sharing-WriteProperty-A (DS-WP-A) ; Data Sharing-WriteProperty-B (DS-WP-B) ; Data Sharing-WritePropertyMultiple-A (DS-WPM-A)  Data Sharing-WritePropertyMultiple-B (DS-WPM-B) ; Data Sharing-COV-A (DS-COV-A) ; Data Sharing-COV-B (DS-COV-B) ; Data Sharing-COVP-A (DS-COVP-A)  Data Sharing-COVP-B (DS-COVP-B)  Data Sharing-COV-Unsolicited-A (DS-COVU-A) ; Data Sharing-COV-Unsolicited-B (DS-COVU-B) ;
Scheduling
Scheduling-A (SCHED-A) ; Scheduling-Internal-B (SCHED-I-B) ; Scheduling-External-A (SCHED-E-B) ;
Trending
Trending-Viewing and Modifying Trends-A (T-VMT-A)  Trending-Viewing and Modifying Trends-Internal-B (T-VMT-I-B) ; Trending-Viewing and Modifying Trends-External-B (T-VMT-E-B) ; Trending-Automated Trend Retrieval-A (T-ATR-A)  Trending-Automated Trend Retrieval-B (T-ATR-B) ;
Network Management
Network Management-Connection Establishment-A (NM-CE-A) ; Network Management-Connection Establishment-B (NM-CE-B) ; Network Management-Router Configuration-A (NM-RC-A)  Network Management-Router Configuration-B (NM-RC-B)
Alarm and Event Management
Alarm and Event-Notification-A (AE-N-A) ; Alarm and Event-Notification Internal-B (AE-N-I-B) ; Alarm and Event-Notification External-A (AE-N-E-B) ; Alarm and Event-ACK-A (AE-ACK-A)  Alarm and Event-ACK-B (AE-ACK-B) ; Alarm and Event-Alarm Summary-A (AE-ASUM-A)  Alarm and Event-Alarm Summary-B (AE-ASUM-B) ; Alarm and Event-Enrollment Summary-A (AE-ESUM-A)  Alarm and Event-Enrollment Summary-B (AE-ESUM-B) ; Alarm and Event-Information-A (AE-INFO-A)  Alarm and Event-Information-B (AE-INFO-B) ; Alarm and Event-LifeSafety-A (AE-LS-A)  Alarm and Event-LifeSafety-B (AE-LS-B)
Device Management
Device Management-Dynamic Device Binding-A (DM-DDB-A) ; Device Management-Dynamic Device Binding-B (DM-DDB-B) ; Device Management-Dynamic Object Binding-A (DM-DOB-A) ;
2
A Series® Lighting Controller
BACnet Protocol Implementation Conformance Statement
BACnet Interoperability Building Block Supported
Device Management-Dynamic Object Binding-B (DM-DOB-B) ; Device Management-DeviceCommunicationControl-A (DM-DCC-A)  Device Management-DeviceCommunicationControl-B (DM-DCC-B) ; Device Management-Private Transfer-A (DM-PT-A) ; Device Management-Private Transfer-B (DM-PT-B) ; Device Management-Text Message-A (DM-TM-A) ; Device Management-Text Message-B (DM-TM-B)  Device Management-TimeSynchronization-A (DM-TS-A) ; Device Management-TimeSynchronization-B (DM-TS-B) ; Device Management-UTCTimeSynchronization-A (DM-UTC-A) ; Device Management-UTCTimeSynchronization-B (DM-UTC-B) ; Device Management-ReinitializeDevice-A (DM-RD-A)  Device Management-ReinitializeDevice-B (DM-RD-B) ; Device Management-Backup and Restore-A (DM-BR-A)  Device Management-Backup and Restore-B (DM-BR-B) ; Device Management-List Manipulation-A (DM-LM-A)  Device Management-List Manipulation-B (DM-LM-B)  Device Management-Object Creation and Deletion-A (DM-OCD-A)  Device Management-Object Creation and Deletion-B (DM-OCD-B) ; Device Management-Virtual Terminal-A (DM-VT-A)  Device Management-Virtual Terminal-B (DM-VT-B)
1 Only supported by B-BC products. Based on the UTC setting in the Device object. When
UTC is enabled, both DM-TS-A and DM-UTC-A is supported, otherwise only DM-TS-A is supported.
2 Based on the UTC setting in the Device object. When UTC is enabled, DM-UTC-B is
supported. When UTC is disabled DM-TS-B is supported. Dates before January 1, 2000 or after December 31, 2099 will be ignored.
1
2
1
2
Segmentation Capability
Segmented Requests Supported ; Window Size 1 Segmented Responses Supported ; Window Size 1
Standard Object Types Supported
Dynamically
Object-Type Supported
Analog Input ;;;
Analog Output ;;;
Analog Value ;;;
Averaging 
Creatable
Dynamically
Deletable Optional Properties Supported Writable Properties
Description, Device Type, Reliability, Min Pres Value, Max Pres Value, Update Interval, Resolution, COV Increment
Description, Device Type, Reliability, Min Pres Value, Max Pres Value, Resolution, COV Increment
Description, Reliability, COV Increment
Object Name, Description, COV Increment, Present Value (conditional), Out of Service, Reliability (conditional)
Object Name, Description, Present Value, COV Increment, Relinquish Default, Out of Service, Reliability (conditional)
Object Name, Description, Present Value (conditional), COV Increment, Out of Service, Reliability (conditional), Units
3
A Series® Lighting Controller
BACnet Protocol Implementation Conformance Statement
Dynamically
Object-Type Supported
Binary Input ;;;
Binary Output ;;;
Binary Value ;;;
Calendar ;;;
Command 
Device ; N/A N/A
Event
Enrollment
File ;
Group 
Life Safety
Point
Life Safety
Zone
Loop ;;;
Multistate
Input
Multistate
Output
;;;


;;;

Creatable
Dynamically
Deletable Optional Properties Supported Writable Properties
Description, Device Type, Reliability, Active Text, Inactive Text, Change Of State Time, Change Of State Count, Time of State Count Reset
Description, Device Type, Reliability, Active Text, Inactive Text, Change Of State Time, Change Of State Count, Time of State Count Reset, Min On Time, Min Off Time
Description, Reliability, Active Text, Inactive Text
Description Object Name, Description,
Description, Location, APDU Seg Timeout, Time Synch Recipients, Max Master, Max Info Frames, Max Segments Accepted, Local Time, Local Date, UTC Offset, DST Status, Active COV Subscription, Backup Failure Timeout, Last Restore Time, Configuration Files
Description, Notification Class Object Name, Description,
Description Object Name, Description, File
Description, Reliability, Update Interval, Proportional Constant, Proportional Units, Integral Constant, Integral Units, Derivative Constant, Derivative Units, Bias, Maximum Output, Minimum Output, COV Increment
Description, Reliability, Device Type, State Text
Object Name, Description, Polarity, Present Value (conditional), Out of Service, Reliability (conditional)
Object Name, Description, Present Value, Polarity, Relinquish Default, Min On Time, Min Off Time, Out of Service, Reliability (conditional)
Object Name, Description, Present Value (conditional), Out of Service, Reliability (conditional)
Date List
Object Name, Description, Location, Time Synch Recipients, UTC Offset, APDU Segment Timeout, APDU Timeout, Number of APDU Retries, Max Master, Max Info Frames
Event Type, Event Parameters, Object Property Reference, Event Enable, Notification Class
Type, Archive
Object Name, Description, Action, Manipulated Var Ref, Controlled Variable Ref, Controlled Var Units, Setpoint, Setpoint Ref, Proportional Constant, Proportional Constant Units, Integral Constant, Derivative Constant, Bias, COV Increment, Out of Service, Present Value (conditional), Reliability (conditional)
Object Name, Description, Present Value (conditional), Out of Service, Reliability (conditional)
4
A Series® Lighting Controller
BACnet Protocol Implementation Conformance Statement
Object-Type Supported
Dynamically
Creatable
Dynamically
Deletable Optional Properties Supported Writable Properties
Description, Reliability, State
Multistate
Value
Notification
Class
;;;
;;;
Text
Description Object Name, Description,
Description, Reliability,
Program ;;;
Description of Halt, Reason for Halt
Description, Weekly Schedule, Exception
Schedule ;;;
Schedule
Description, Start Time, Stop Time, Log Device Object Prop, Log Interval, COV Resubscription Interval,
Trend Log ;;;
Notification Threshold, Records Since Notification, Notification Class, Event Enable, Acked Transition, Notify Type, Event Time Stamps
Proprietary ;;;
Object Name, Description, Present Value (conditional), Out Of Service, Reliability (conditional)
Ack Required, Priority, Recipient List
Object Name, Description, Program Change, Out of Service, Reliability (conditional)
Object Name, Description, Effective Period, Weekly Schedule, Exception Schedule, List of Object Property Reference, Priority for Writing
Object Name, Description, Log Enable, Start Time, Stop Time, Log Device Object Prop, Log Interval, Stop When Full, Buffer Size, Record Count
Range Restrictions
Object-Type Property Range Restriction
All Object Types Object Name [1, 67] printable ASCII characters, inclusive Binary Input,
Binary Output Loop Bias [0.0, 100.0] inclusive Calendar
Schedule
Schedule Effective Period End Date > Start Date (End date must be later date than the Start Date)
Change Of State Count Accepts writes of value zero only
Date List Exception Schedule
BACnet Date
Will accept dates that include any wild combinations in the individual fields (example: unspecified day of week, unspecified day of month, January, unspecified year)
BACnet DateRange
Will not accept Start/End dates that include wild combinations in the individual fields (example: unspecified day of week, unspecified day of month, unspecified month, year 2004). Will accept Start/End dates in which all individual fields are wild (example: unspecified day of week, unspecified day of month, unspecified month, unspecified year). Will not accept DateRanges in which both the Start and End date are wild.
WeekNDay
Will accept dates that include any wild combinations in the individual fields (example: Mondays, unspecified week of month, December)
5
A Series® Lighting Controller
BACnet Protocol Implementation Conformance Statement
Data Link Layer Options
Options Notes
; BACnet IP, (Annex J) Only supported by Ethernet-capable products. ; BACnet IP, (Annex J), Foreign Device Only supported by Ethernet-capable products. ; ISO 8802-3, Ethernet (Clause 7) (10Base2, 10Base5, 10BaseT, Fiber) Only supported by Ethernet-capable products. ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8) ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s): ; MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400, 76800 MS/TP slave (Clause 9), baud rate(s): ; Point-To-Point, EIA 232 (Clause 10), baud rate(s): 9600, 1920, 38400 ; Point-To-Point, modem, (Clause 10), baud rate(s): 9600, 19200, 38400 LonTalk, (Clause 11), medium: Other:
Device Address Binding
Is static device binding supported? ; Yes No
(Necessary for two-way communication with MS/TP slaves and certain other devices.)
Networking Options
Router ;
Annex H, BACnet Tunneling BACnet/IP Broadcast Management Device (BBMD) Does the BBMD support registrations by Foreign
Devices?
Router between Ethernet, BACnet/IP, MS/TP and PTP or between MS/TP and PTP (model dependent).
Character Sets Supported
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
; ANSI X3.4 IBM/Microsoft DBCS JIS C 6226 ISO 10646 (ICS-4) ISO 10646 (UCS2) ISO 8859-1
If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that the gateway supports
Not applicable.
6
g
GE Consumer & Industrial
General Electric Company 41 Woodford Ave., Plainville, CT 06062
DEH41099 R01 1004 © 2004 General Electric Company
