SPECIFICATIONS

Gateway M325 Notebook

Specifications are subject to change without notice or obligation.

Processor and Core Logic

Processor options

One Intel® Celeron™ M CPU



-OR-



One Intel® Pentium® M CPU



To determine your notebook’s processor, click Start,My Computer,



then click View System Information. The processor is listed.

Processor packaging

478-pinuFCPGA

Level 2 cache

1 MB (Celeron M)



-OR-



2 MB (Pentium M)

Chipset-Northbridge

Intel 910GM (Celeron M)



-OR-



Intel 915GM (Pentium M)

Chipset-Southbridge

Intel ICH6-M

Processor side bus speed

400 MHz (Celeron M)



400/533 MHz (Pentium M)

BIOS

Phoenix BIOS



8 MB Flash ROM



SMBIOS 2.3 support



Advanced Configuration and Power Interface 2.0 (ACPI 2.0)



support



Wired for Management 2.0 (WfM 2.0)

www.gateway.com

1

System memory

Memory type

400/533 MHz DDR2 RAM

Memory expansion options

Two 200-pinindustry standardDDR-SODIMMsockets



Accepts two 400/533 MHz DDR2 RAM memory modules in





memory bay



2 GB maximum system memory



Single channel



To determine your notebook’s memory, click Start,My Computer,



then click View System Information. The memory is listed.

Video





Graphics controller

Intel Extreme Graphics 2



2D hardware acceleration



3D rendering acceleration

Video memory

Shares system memory: 32, 64, or 128 MB

LCD display panel

15.0-inchactive matrix (TFT) LCD color display



Maximum panel resolution: 1024 × 768



Maximum color depth: 32-bit(16.7 million colors)

LCD supported video modes

XGA

LCD maximum refresh rate

60 Hz

Controls

Brightness level selectable through FN keys (up, down)



Auto dim on battery and auto bright on AC power (selectable in





BIOS)

External video

Supports dual display and extended desktop



NOTE: This notebook does not have S-Video.

External CRT resolutions

Supports standard IBM VGA compatible modes



Maximum resolution: 1920 × 1440



Maximum color depth: 32-bit(16.7 million colors)

External CRT maximum refresh rate

60 Hz

2

www.gateway.com

Audio

Sound support

Conexant SmartAMCi Audio Modem Codec (AMC) CX20468-31



AC ’97 Revision 2.3 Compliant



NOTE: This notebook supports S/PDIF.



NOTE: This notebook does not have an internal microphone.

Volume controls

Volume control toggle



Press toggle in to mute the sound



Software control provided through Windows

Internal speakers

Stereo speakers built into front of notebook



1.5 W/4 ohm maximum output for each channel

Audio jacks

Stereo headphone output



Monophonic microphone input

Communications





Modem features

Conexant CX20493-21



56K v.92 Soft Modem



Uses theRJ-11jack on the rear of the notebook



Supports Wake on Ring from S3 power mode

10/100 Mbps Ethernet interface

PCI-E

features

Integrated IEEE 802.3 (10/100/1000 BASE-TX)Ethernet interface



Uses theRJ-45jack on the rear of the notebook



Supports Wake on LAN from S3 power mode

Wireless Ethernet interface features

Intel® PRO/Wireless IEEE 802.11b/g network card,Mini-PCI

(Factory installed option)



(Pentium M models only)





-OR-



Broadcom IEEE 802.11g network card, Mini-PCI(Celeron M





models only)



FN+F2 keyboard combination turns wireless Ethernet on and off.



Antenna: Usesfactory-installeddiversified internal antenna



Operating channels: 11 selectable channels



Security: 128 and 64 bit WEP encryption



Operating Frequency: 2.4 GHz Direct Sequence Spread Spectrum



(IEEE 802.11b and IEEE 802.11g)



Maximum Data Rate



54 Mbps (IEEE802.11g)



11 Mbps (IEEE802.11b)

www.gateway.com

3

Input/Output (I/O)

Keyboard

U.S. English keyboard



Full-sized88-keys



19 mm × 19 mm key pitch



2.5 mm keystroke

Pointing device

Gateway EZ-Pad™touchpad with vertical scroll



2-buttondesign

Status indicators

FN+F1 keyboard combination turns status indicators on and off.



AC power



Wireless Ethernet



Caps lock



PAD (Num) lock



Hard drive access



Battery status



Power/Suspend

Input/Output (I/O) ports

Three USB 2.0 (4-pin)



IEEE 1394(4-pin)



V.92, 56K Modem(RJ-11)



10/100/1000 Ethernet(RJ-45)



External monitor (VGA)



Stereo headphone output



Monophonic microphone input



PC Card socket (one Type II)



DC input

PCMCIA

Accepts one Type II device



TIPCI-7411controller



NOTE: This notebook does not support Zoom Video.

Storage





Hard drive

2.5-inchdiameter



9.5 mm height

Memory card reader

(factory installed option)

To find the hard drive capacity, click Start, then clickMy Computer.Right-clickthe drive letter, then clickProperties. The drive’s capacity and available space appears. If the drive has multiple partitions (for example, C: and D:), add the capacities of each partition to determine the drive’s total capacity.

Supports the following card types:

Memory Stick®

Memory Stick Pro®

MultiMediaCard™

Secure Digital™

4

www.gateway.com

Optical drive

(factory installed)

Power

Available drives include:

CD

Combination DVD/CD-RW

Combination CD-RW/DVD+/-RW

To determine the type of optical drive in your system, examine the drive tray’s plastic cover. A DVD logo in combination with a CD-R/RWlogo indicates a DVD drive that also is a recordable/rewritable CD drive, and aDVD-ROM/R/RWlogo in combination with aCD-R/RWlogo indicates a recordable/rewritable DVD drive that also is a recordable/rewritable CD drive.

AC adapter

19 VDC, 3.42A, 65 W output



Automatically adjusts for 100 to 240 VAC, 50 to 60 Hz power





sources



Two-wiredesign

Battery type

Removable Lithium Ion battery pack



Embedded controller inside to support smart battery

Battery capacity

6-cellLi-Ion



4.4 Ah



11.1 V nominal



48 Whr



Battery life varies depending on configuration, programs, power



management settings, and features used. Recharge time varies,



depending on usage.

Power management

Advanced Configuration and Power Interface 2.0 (ACPI 2.0)





support



SMBIOS 2.3



PC 2001 compliant



CPU may support Intel® Speedstep™ technology

Controls

Icon on taskbar shows battery charge as a percentage remaining

Power switch

Supports Power On/Off, Standby/Resume, Hibernate, Shutdown

Lid switch

LCD On/Off, Standby, Hibernate

Security





Passwords

Power-onpassword (user/supervisor password set in BIOS)



Hard drive password

Physical

Main system memory compartment screw



Hard drive kit screw



Mini PCI bay screw



Kensington® security slot on notebook back

www.gateway.com

5

System software

Operating system

Microsoft® Windows® XP Professional



Microsoft® Windows® XP Home Edition

System management

SMBIOS 2.3 BIOS support



Advanced Configuration and Power Interface 2.0 (ACPI 2.0)





support



Support for Wake on LAN from S3 power mode



Support for Intel® LANDesk® Client manager 6.0



Wired for Management 2.0 (WfM 2.0) enabled

System compatibility

PC2001 specification



Advanced Configuration and Power Interface 2.0 (ACPI 2.0)





support



SMBIOS 2.3



Windows Hardware Quality Labs (WHQL) certified

Quick boot

Supported

Physical specifications





Dimensions

~12.9 × 10.5 × 1.0 in. (W × D × H)



~328 × 268 × 26 mm (W × D × H)

System weight

~5.5 lbs. (~2.5 kg) Includes optical drive and 6-cellbattery



~6.1 lbs. (~2.75 kg) Includes optical drive and optional 9-cellbattery

AC adapter weight

~11.5 ounces (~357 g)



Includes cord

Battery weight

~10.4 ounces (~322.5 g)

Environment





Operating temperature

50°F to 90°F (10°C to 32°C)

Storage temperature

4°F to 140°F(-15°Cto 60°C)

Operating humidity

20% to 80% relative humidity; no condensation

MAN M325 SPECS R0 6/05
